KAUS
Austin, United States
Runway 36R
Elevation499 ft asl
Weight138,243 lbs
Fuel17,334 lbs
Wind335° · 7 kn · 3 kn cross

Flight Score

96.85 %
KTPA
Tampa, United States
Runway 19R
Elevation10 ft asl
Weight128,880 lbs
Fuel7,517 lbs
Wind300° · 4 kn · 3 kn cross
19 Mar 2025 2:11 841 nm FNX320_TCACFM 9,817 lbs
Departure Score
98.38 %
Enroute Score
100.00 %
Arrival Score
92.16 %

What went well

Touchdown 925 ft in — inside the full-score zone
Threshold crossed at 50 ft and 135 kt — both inside band
Straight touchdown — 6.2 ft off the centreline, no bounce

What held you back

Firm touchdown — 594 fpm, −1.51 points across the landing and the touchdown
  • Arrival Touchdown · sink rate 594 fpm−1.02
  • Arrival Landing · flare: the descent was not taken out−0.46
  • Arrival Touchdown · 1.52 G at contact−0.04
Arrival Rollout — Runway alignment max 44.1 ft right at 74 %, −0.77 points
Departure Climb 3 — climb speed 198 kt against 164 kt at 80 %, −0.54 points

Next time

Departure

Reduce climb power to bring speed back to 164 kt and hold it there.

What happened: Climb speed was 34 kt fast at 198 kt during the climb.

Watch for: Airspeed indicator: 164 kt in the climb

See Departure Climb 3

Arrival

Begin the flare with progressive back pressure and keep it coming until the sink is arrested, rather than flying it on flat.

What happened: The nose was barely raised in the flare and little of the sink was taken out, flying the aircraft onto the runway. This pattern usually carries through to a firm touchdown with a noticeable sink rate.

Watch for: Vertical speed indicator: a smoothly reducing sink through the normal flare band, not a steady rate into the runway.

See Arrival LandingArrival Touchdown

There are several things that can go wrong during the flare, carrying too much speed over the threshold, starting the flare at the wrong height and inconsistent flight control inputs, all contribute to a poor flare resulting in a hard touchdown or a float down the runway.

Read more in Flare Timing

Start to finish · 17 stages, 15 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 16 minutes and covered 3 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 13 kt0 kt min to max 23 kt 3 5 kt
100 % Average speed turning corners 15 ktmax 17 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.02 g 1.00 1.00 g
Info Average pitch angle -0.2 °-1.0 ° min to max 0.5 ° 0.1 -0.3 °
Info Average bank angle 0.2 °0.0 ° min to max 0.7 ° 0.4 0.4 °

Events

Info Engine 1 Started 9 ft agl
Info Parking Brake On 9 ft agl
Info Flaps Position 2 9 ft agl
Info Taxi Lights Switched On 9 ft agl
Info Landing Lights Switched On 9 ft agl
Info Parking Brake Off 9 ft agl
Info Parking Brake On 9 ft agl
Info Parking Brake Off 9 ft agl
Info Parking Brake On 9 ft agl
Info Landing Lights Switched Off 9 ft agl
Info Taxi Lights Switched Off 9 ft agl
Info Strobe Lights Switched On 9 ft agl
Info Landing Lights Switched On 9 ft agl
Info Parking Brake Off 9 ft agl
Departure Runway Entry Entering runway 36R at KAUS Austin Bergstrom International Airport, Average speed was 10 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 5 kt0 kt min to max 13 kt 0 13 kt
Info Average pitch angle -0.4 °-0.7 ° min to max -0.1 ° -0.5 -0.2 °
Info Average bank angle 0.0 °0.0 ° min to max 0.0 ° 0.0 0.0 °
Info Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g

Events

Info Parking Brake Off 9 ft agl · 12 kt
Departure Roll 100.00Departure roll runway 36R at KAUS Austin Bergstrom International Airport. Takeoff distance 4,114 ft 46 % of runway. Rotation speed was 144 kt. Local weather - Temperature 81 °F. Wind 8 kt at 335 °. Crosswind: 3 kt Headwind: 7 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 4,114 ft46 % of runway
100 % Rotation speed was 144 ktTarget 148 kt
100 % Runway alignment max 18.0 ft left18.0 ft left to 0.0 ft left 3.5 18.0 ft
100 % Average g force 1.00 g0.96 g min to max 1.06 g 1.00 0.99 g
100 % Takeoff Bounce
Info Average pitch angle 1.1 °-0.2 ° min to max 8.9 ° -0.2 8.9 °
Info Average bank angle 0.1 °0.0 ° min to max 0.3 ° 0.0 0.3 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 36R KAUS Austin Bergstrom International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.3 °-0.3 ° min to max -0.2 ° -0.2 -0.3 °
100 % Average speed 159 kt153 kt min to max 166 kt 154 165 kt
100 % Steepest bank angle 0.3 °0.2 ° min to max 0.3 ° 0.3 0.3 °
100 % Average g force 1.12 g1.00 g min to max 1.17 g 1.00 1.07 g
Info Average VSI 654 fpm258 fpm min to max 1,088 fpm 258 1,088 fpm
Info Average altitude 18 ft agl0 ft agl min to max 46 ft agl 0 46 ft agl
Info Average pitch angle 11.2 °9.1 ° min to max 12.0 ° 9.1 11.2 °
Departure Climb 2 100.00Departure climb to 400 ft agl from 36R KAUS Austin Bergstrom International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.3 °-0.4 ° min to max -0.3 ° -0.3 -0.4 °
100 % Average speed 174 kt166 kt min to max 197 kt 166 197 kt
100 % Steepest bank angle 0.5 °0.0 ° min to max 0.5 ° 0.3 0.5 °
100 % Average g force 0.98 g0.91 g min to max 1.10 g 1.06 1.04 g
Info Average VSI 1,306 fpm1,108 fpm min to max 1,647 fpm 1,108 1,647 fpm
Info Average altitude 119 ft agl47 ft agl min to max 388 ft agl 47 388 ft agl
Info Average pitch angle 10.1 °8.9 ° min to max 11.1 ° 11.1 10.5 °

Events

Info Landing Gear Up 169 ft agl · 184 kt
Departure Climb 3 91.89Departure climb to 1,000 ft agl from 36R KAUS Austin Bergstrom International Airport.
ScoreDescriptionStartProfileEnd
80 % Climb speed 198 kt195 kt min to max 200 ktTarget 164 kt, 34 kt fast 198 200 kt
100 % Steepest bank angle 0.6 °0.1 ° min to max 0.6 ° 0.6 0.3 °
100 % Average g force 1.06 g0.96 g min to max 1.15 g 1.11 1.05 g
100 % Landing gear up at 131 ft aglTarget by 400 ft agl
Info Heading variation -0.4 °-0.5 ° min to max -0.4 ° -0.4 -0.5 °
Info Average VSI 2,727 fpm1,816 fpm min to max 3,507 fpm 1,816 3,507 fpm
Info Average altitude 666 ft agl420 ft agl min to max 950 ft agl 420 950 ft agl
Info Average pitch angle 12.2 °11.4 ° min to max 13.7 ° 11.4 13.7 °
Enroute Climb 100.00Enroute climb started 1 mile north east of KAUS Austin Bergstrom International Airport Austin (Texas, United States). Climbing from 1,512 ft asl to 38,469 ft asl, an increase of 36,957 ft in 20 minutes and covering 143 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 232 kt195 kt min to max 247 kt 199 238 kt
100 % Steepest bank angle 30.4 °0.0 ° min to max 30.4 ° 0.1 0.0 °
100 % Average g force 1.00 g0.86 g min to max 1.15 g 1.05 1.00 g
Info Average VSI 1,943 fpm475 fpm min to max 4,121 fpm 3,667 633 fpm
Info Average altitude 23,627 ft asl1,512 ft asl min to max 38,469 ft asl 1,512 38,469 ft asl
Info Average pitch angle 7.3 °4.1 ° min to max 15.5 ° 14.0 4.6 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Position 1 2,451 ft agl · 213 kt
Info Flaps Fully Retracted 2,793 ft agl · 224 kt
Info Landing Lights Switched Off 9,613 ft agl · 276 kt
Enroute Level 100.00Enroute level cruise started 1 mile east of Crosby (Texas, United States) and lasted 51 minutes, covering 448 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,429 ft of 39,022 ft asl38,581 ft asl min to max 39,089 ft asl 38,581 39,051 ft asl
100 % Average speed 235 kt234 kt min to max 238 kt 238 236 kt
100 % Steepest bank angle 3.4 °0.0 ° min to max 3.4 ° 0.0 0.1 °
100 % Average g force 1.00 g0.98 g min to max 1.01 g 1.00 1.01 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 3.9 °3.7 ° min to max 4.8 ° 4.7 3.8 °
Enroute Descent 100.00Enroute descent started 84 miles south of FM01 Pensacola Moving Carrier - CVN78 (Florida, United States). Descent from 39,001 ft asl to 5,053 ft asl, a decrease of 33,948 ft in 36 minutes and covering 225 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 219 kt185 kt min to max 275 kt 236 185 kt
100 % Steepest bank angle 16.9 °0.0 ° min to max 16.9 ° 0.2 0.0 °
100 % Average g force 1.01 g0.80 g min to max 1.12 g 0.80 1.01 g
Info Average VSI -800 fpm-2,418 fpm min to max -291 fpm -1,133 -441 fpm
Info Average altitude 19,766 ft asl5,053 ft asl min to max 39,001 ft asl 39,001 5,053 ft asl
Info Average pitch angle 2.3 °-1.7 ° min to max 4.0 ° 0.7 1.8 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Landing Lights Switched On 9,810 ft agl · 270 kt
Info Flaps Position 1 9,573 ft agl · 264 kt
Info Flaps Position 2 6,533 ft agl · 224 kt
Info Flaps Position 3 6,486 ft agl · 224 kt
Enroute Level 2 100.00Enroute level cruise started overhead Keystone (Florida, United States) and lasted 2 minutes, covering 5 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±749 ft of 4,793 ft asl4,669 ft asl min to max 4,989 ft asl 4,989 4,669 ft asl
100 % Average speed 178 kt150 kt min to max 185 kt 185 150 kt
100 % Steepest bank angle 21.6 °0.0 ° min to max 21.6 ° 0.0 10.6 °
100 % Average g force 1.05 g1.00 g min to max 1.09 g 1.00 1.02 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 3.3 °1.9 ° min to max 6.3 ° 1.9 6.3 °

Events

Info Landing Gear Down 4,780 ft agl · 201 kt
Enroute Descent 2 100.00Enroute descent started 3 miles north east of 3FD1 Tampa Bay Executive Airport New Port Richey (Florida, United States). Descent from 4,665 ft asl to 1,305 ft asl, a decrease of 3,360 ft in 4 minutes and covering 10 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 138 kt134 kt min to max 148 kt 148 144 kt
100 % Steepest bank angle 10.4 °0.0 ° min to max 10.4 ° 10.4 0.8 °
100 % Average g force 1.00 g0.94 g min to max 1.03 g 1.02 1.03 g
Info Average VSI -718 fpm-1,582 fpm min to max -238 fpm -238 -875 fpm
Info Average altitude 3,131 ft asl1,305 ft asl min to max 4,665 ft asl 4,665 1,305 ft asl
Info Average pitch angle 5.6 °1.3 ° min to max 7.9 ° 6.5 4.6 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Position 4 4,535 ft agl · 148 kt
Arrival Approach 100.00Final approach to runway 19R at KTPA Tampa International Airport. Descent from 1,340 ft agl to 66 ft agl in 95 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates
Arrival Landing 93.14Landing on runway 19R at KTPA Tampa International Airport, runway length 11,014 ft. Good threshold height. Threshold speed was good at 135 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 135 kt. Target 140 kt
100 % Good threshold height.Target 50 ft agl
73 % The flare wandered off the target profile. The aircraft was flown onto the runway - pitch changed 0.3° and the descent was barely arrested. Touchdown was 925 ft past the threshold. Start the flare with progressive back pressure rather than one pull, and keep it coming.
100 % Runway alignment max 4.8 ft right0.2 ft left to 4.8 ft right 0.2 -4.8 ft
100 % Steepest bank angle 0.1 °0.0 ° min to max 0.1 ° 0.1 0.0 °
100 % Peak g force 1.03 g1.00 g min to max 1.03 g 1.00 1.03 g
Info Average speed 135 kt135 kt min to max 135 kt 135 135 kt
Info Average VSI -722 fpm-795 fpm min to max -606 fpm -795 -606 fpm
Info Average altitude 26 ft agl6 ft agl min to max 50 ft agl 50 6 ft agl
Info Average pitch angle 5.9 °5.5 ° min to max 6.0 ° 5.5 6.0 °
02505007501,00001223354658Runway Distance ftLanding Height ft02505007501,000-90-72-54-36-1801836547290Runway Distance ftRunway Width ft
Arrival Touchdown 84.13Touchdown distance was good at 925 ft. Touchdown speed at 135 kt was a little fast. Touchdown rate was very hard at -594 fpm. Runway touchdown alignment was very good. Local weather - Temperature 68 °F. Wind 2 kt at 300 °. Crosswind: 2 kt Tailwind: 1 kt.
ScoreDescriptionStartProfileEnd
24 % Touchdown rate was -594 fpm.
100 % Touchdown distance was 925 ftTarget 1,500 ft
100 % Speed at touchdown 135 ktTarget below 133 kt
100 % Runway alignment max 6.2 ft right5.3 ft right -4.8 -6.2 ft
100 % Steepest bank angle 0.9 °0.0 ° min to max 0.9 ° 0.0 0.3 °
88 % Peak g force 1.52 g1.03 g min to max 1.52 g 1.03 1.22 g
100 % Landing Bounce
Info Average speed 135 kt135 kt min to max 135 kt 135 135 kt
Info Average pitch angle 5.8 °5.6 ° min to max 6.0 ° 6.0 5.7 °
Arrival Rollout 88.47Total landing distance 3,720 ft, 34 % of runway. Runway rollout alignment was slightly misaligned by 44 ft from centreline.
ScoreDescriptionStartProfileEnd
100 % Landing distance 3,720 ft34 % of runway.
74 % Runway alignment max 44.1 ft right0.0 ft left to 44.1 ft right -27.0 -44.1 ft
100 % Average g force 1.02 g0.97 g min to max 1.13 g 1.13 1.00 g
Info Average speed 130 kt73 kt min to max 139 kt 139 73 kt
Info Average pitch angle 5.1 °-0.6 ° min to max 6.6 ° 5.7 -0.6 °
Info Average bank angle 0.2 °0.0 ° min to max 0.3 ° 0.1 0.2 °
Runway Exit Exiting runway, average speed 16 kt
ScoreDescriptionStartProfileEnd
Info Average speed 17 kt3 kt min to max 67 kt 67 6 kt
Info Average pitch angle -0.3 °-1.1 ° min to max 0.3 ° -0.6 0.3 °
Info Average bank angle 0.1 °0.0 ° min to max 0.5 ° 0.1 0.1 °
Info Average g force 1.00 g0.99 g min to max 1.00 g 0.99 1.00 g
Arrival Taxi 95.05Taxiing to the parking from the runway took 3 minutes and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 8 kt0 kt min to max 16 kt 6 1 kt
100 % Average speed turning corners 11 ktmax 11 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle 0.3 °-0.2 ° min to max 0.8 ° 0.3 0.4 °
Info Average bank angle 0.1 °0.0 ° min to max 0.4 ° 0.1 0.4 °

Events

Fail Landing Lights
Info Strobe Lights Switched Off 9 ft agl · 4 kt
Info Flaps Position 3 9 ft agl · 7 kt
Info Flaps Position 2 9 ft agl · 10 kt
Info Flaps Position 1 9 ft agl · 11 kt
Info Flaps Fully Retracted 9 ft agl · 8 kt
Info Parking Brake On 9 ft agl
Info Landing Lights Switched Off 9 ft agl
Info Parking Brake Off 9 ft agl

Takeoff from KAUS 36R

Taxi out

LightsOk
All on
Taxi speed100.00
23kt peak15 kt in turns

The roll

Takeoff roll100.00
4,114ft46 %
Runway alignment100.00
18.0ft L
Rotation speed100.00
144kttarget 148, 4 early

On speed, but the nose came up quickly

Rotation started at 144 kt, 4 kt before the 148 kt rotate speed. The nose then rose at 3.1° a second, faster than the 2.0 to 2.9° a second other FNX320_TCACFM pilots fly.

The rotation started on speed but the nose came up quickly. A fast pull raises the nose faster than the aircraft can lift off, which brings the tail closer to the runway. Pull smoothly at the normal rate for this aircraft and let it fly off at its own attitude.

Liftoff and climb

Liftoff
153ktat 9.1°
Rotation
3.1°/sover 2.6 s, gaining 9 kt
35 ft
162ktat 11.7°, 2.8 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
0.3°steepest
Gear up100.00
131ftfull marks to 400 ft
Climb 3 speed79.73
198kttarget 164

Plan view the roll down the 9,007 ft runway.

Rolled from 281 ft in, drifted left of the centreline, 18 ft at the widest, and lifted off 18 ft left. Airborne 45 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

2,0004,0006,0008,000THRESHOLDLEFT ↑RIGHT ↓CROSS2 kn75 %widest 18.0 ft LROLL 281 FT INAirborne 4,136 ft from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 4,136 ft of 9,007 ft · 46 %
Behind the start of the roll, 281 ftTakeoff roll, 3,855 ft Left ahead, 4,871 ft

Side view from the start of the roll to the end of Climb 3 at 950 ft.

Reached 35 ft with 4,125 ft of runway left; gear up at 131 ft, inside the 400 ft that gets full marks; then climbing at 1,870 fpm on average to 950 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3198 kt avgtarget 164THRESHOLDRUNWAY END6080100120KNOTS ALONG THE ROLLnose up on the runway · 648 ft · 2.6 sRotate 144 kttarget 148Liftoff 153 ktGear up 131 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 164210 kt14070020°10°0°nose up on the runway · 648 ft · 2.6 sROTATELIFTOFFGEAR UPtarget 148held 10.7°9.1° off · 3.1°/s12° at 35 ftAIRSPEEDPITCH02040 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2.0 to 2.9° a second, the middle half of rotation rates flown by other FNX320_TCACFM pilots over the last 180 days (481 takeoffs); the grey pair are 2 to 3° a second, the rates airliners are rotated at. A trace steeper than both green lines is a faster rotation than most, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 11.7°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 11.7°ROTATELIFTOFF35 FT9.1° off · 3.1°/s3°/s2.9°/s2°/s2.0°/s12° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5+6 sseconds from rotation
PitchRotation began2.0 to 2.9°/s, other FNX320_TCACFM pilots2 to 3°/s from rotation, airlinersTail strikeNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate830 fpm680 fpm
On glideslope3.0°3.1°
On centreline0.1° off0.1° off
On speed+3.7 kt+4.6 kt
Wings level2° bank1° bank

When the approach was stable

Every check met from 4 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to KTPA 19R

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 20 ft above the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 1,000 ft past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,3266913732111,000 ft gate7 of 71,052 ft · 144 kt500 ft gate7 of 7564 ft · 145 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 39× larger than distances along the final.

Inside the 1° band all the way from 4 nm, never more than 30 ft off the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR80 ft L080 ft RLEFT ↑RIGHT ↓1° BAND12 ft L17 ft L11 ft L9 ft L26 ft L21 ft L
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 35 kt fast at the 1,000 ft gate, closing to 21 at 500 ft and 10 at the threshold.

Inside the speed band all the way, between −5 kt and +5 kt on the approach speed of 140 kt.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

140160180200 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 140+4 kt+4 kt−3 kt−5 kt−5 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on KTPA 19R

Over the threshold

Threshold height100.00
50ft
Threshold speed100.00
135kttarget 140, 5 slow
Centreline offset100.00
4.8ft R
Bank100.00
0.1°steepest
Flare72.57

The flare wandered off the target profile

The aircraft was flown onto the runway - pitch changed 0.3° and the descent was barely arrested. Touchdown was 925 ft past the threshold. Start the flare with progressive back pressure rather than one pull, and keep it coming.

Touchdown

Past threshold100.00
925ft
Centreline100.00
6.2ft R
Speed100.00
135kttarget 132, 3 fast
Touchdown rate23.64
-594fpm
Impact88.10
1.52G
BouncesOk
None
Bank100.00
0.9°as the wheels touched

Rollout

Rollout distance100.00
2,636ft32 % used
Rollout alignment74.39
44.1ft R

Taxi in

Lights50.50
Onlanding lights, 99% of the taxi
Taxi speed100.00
16kt peak11 kt in turns

Side view — the last 5,000 ft of the approach.

Crossed the threshold at 50 ft, close to the 50 ft target; began the flare at 36 ft. Touched down 925 ft in, close to the ideal 1,000 ft.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 5,000 ft across. The dashed line is the ideal, 50 ft over the threshold and down 1,000 ft in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

50 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 36 ft · −874 fpm · 5.8° · 135 ktdescent slowed at 4 ft · −553 fpm · 6°−593 fpm · 6° nose up · 135 kt Ideal — 50 ft, down at 1,000 ft This flight — 50 ft, down at 925 ft

Sink and pitch — through the flare, lined up with the side view.

The sink went from 870 fpm at the flare to 590 fpm at touchdown. The pitch barely changed. Into the flare at 135 kt, 5 kt under the 140 kt approach speed, and 135 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−593 fpm at touchdown6° at touchdown, +0.2° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 5,000 ft of the 11,014 ft runway, to the same scale as the side view.

Touched down 6 ft right of the centreline and drifted to 37 ft right on the rollout. 3 kt across from the right, which takes about 1° of crab to hold the centreline at 135 kt. Touched down with 1° of it still on, wings level.

Wind 300° at 4 kt · 2 kt tail · 3 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

1,0002,0003,0004,0005,000 THRESHOLD LEFT ↑ RIGHT ↓ CROSS 3 kn FULL SCORE TO 1,650 FT 925 ft past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

The 925 ft touchdown sits inside the full-score zone. The 593 fpm arrival was firm.

Runway used 3,561 ft of 11,014 ft · 32 %
In the air over the runway, 925 ftRollout, 2,636 ft Left over, 7,453 ft

The stop — touchdown to taxi speed.

From 139 kt at touchdown to taxi speed (30 kt) in 23 s, an average deceleration of 0.26 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012016060 kt · 3,114 ft30 kt · 3,465 fttouchdown3,603 ftkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Flight narrative

The flight began with taxiing from the parking to the runway at KAUS Austin Bergstrom International Airport, which took 14 minutes and covered a distance of 3 nautical miles. The aircraft then departed from runway 36R, with a takeoff distance of 3,795 feet, which was 42% of the runway. The liftoff speed was 153 knots.

The local weather conditions at the time of departure were characterized by a temperature of 81°F and a wind speed of 8 knots at 335°. The crosswind was 3 knots, while the headwind was 7 knots. The aircraft then began its enroute climb, starting 1 mile northeast of KAUS Austin Bergstrom International Airport, and climbed from an altitude of 1,512 feet above sea level to 38,469 feet above sea level, an increase of 36,957 feet, in 20 minutes and covering a distance of 137 nautical miles.

Following the enroute climb, the aircraft entered a level cruise, starting 1 mile east of Crosby, Texas, and lasted for 51 minutes, covering a distance of 448 nautical miles. The aircraft then began its enroute descent, starting 84 miles south of FM01 Pensacola Moving Carrier - CVN78, Florida, and descended from 39,001 feet above sea level to 5,053 feet above sea level, a decrease of 33,948 feet, in 36 minutes and covering a distance of 215 nautical miles.

The aircraft then entered another level cruise, starting overhead Keystone, Florida, and lasted for 2 minutes, covering a distance of 4 nautical miles. The aircraft then began its final descent, starting 3 miles northeast of 3FD1 Tampa Bay Executive Airport New Port Richey, Florida, and descended from 4,665 feet above sea level to 1,305 feet above sea level, a decrease of 3,360 feet, in 4 minutes and covering a distance of 9 nautical miles.

The final approach to runway 19R at KTPA Tampa International Airport was made from the north, with a heading of 182.0° at 4 nautical miles and 1,282 feet above ground level. The landing was made on runway 19R, which had a length of 11,040 feet. The threshold height was good, and the threshold speed was also good at 135 knots.

The touchdown distance was good at 934 feet, and the touchdown speed was also good at 135 knots. However, the touchdown rate was heavy at -606 feet per minute. The runway touchdown alignment was very good. The local weather conditions at the time of landing were characterized by a temperature of 68°F and a wind speed of 2 knots at 300°. The crosswind was 2 knots, while the tailwind was 1 knot.

The total landing distance was 3,719 feet, which was 34% of the runway. The runway rollout alignment was slightly misaligned by 44 feet from the centerline. The aircraft then taxied to the parking from the runway, which took 3 minutes and covered a distance of less than 1 nautical mile. The total flight distance was 822 nautical miles, and the flight duration was 131 minutes. The aircraft used 9,817 pounds of fuel during the flight.

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
