LTFM
Arnavutköy, Turkey
Runway 17L
Elevation200 ft asl
Weight64,002 kg
Fuel11,619 kg
Wind220° · 18 kn · 12 kn cross

Flight Score

97.77 %
LIMC
Ferno (VA), Italy
Runway 17L
Elevation722 ft asl
Weight57,730 kg
Fuel5,125 kg
Wind110° · 4 kn · 4 kn cross
21 Oct 2023 1:47 1019 nm Boeing 737-700 6,495 kg
Departure Score
98.72 %
Enroute Score
100.00 %
Arrival Score
94.59 %

What went well

Held the centreline on the roll in a 12 kn crosswind — 4.96 m off at liftoff
Touched down at -175 fpm — a soft arrival
1.15 G at touchdown — inside band

What held you back

Arrival Landing — Flare profile at 76 %, Threshold height at 66 ft agl was above target at 77 %, −0.79 points
Arrival Touchdown — Touchdown distance was 900 m at 52 %, −0.48 points
Arrival Approach — 1,000 ft gate 86 %, 500 ft gate 100 %, −0.48 points
Departure Roll — Strobe Lights at 0 %, −0.33 points

Next time

Arrival

Once the sink is arrested, keep easing the aircraft down toward the runway rather than holding it off; let it settle smoothly to touchdown near 457 m.

What happened: The sink was arrested well above the runway at 26 ft and held there instead of being let down. Holding off high like this usually carries the touchdown long, and here it landed at 900 m, 443 m past the target.

Watch for: Watch radio altitude through the flare and touchdown distance against 457 m.

See Arrival LandingArrival Touchdown

The rudder input is a changing profile through the roll rather than one that is held. So the demand on your right foot starts large at power application, eases as speed builds and the rudder gains authority, then jumps again at rotation.

Read more in Improve Your Take-Offs

Start to finish · 19 stages, 17 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 18 minutes and covered 4 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 12 kt0 kt min to max 20 kt 0 4 kt
100 % Average speed turning corners 12 ktmax 13 kt 0 0 kt
100 % Average g force 1.00 g0.98 g min to max 1.01 g 1.00 0.99 g
Info Average pitch angle -1.2 °-1.5 ° min to max -1.2 ° -1.2 -1.3 °
Info Average bank angle 0.0 °0.0 ° min to max 0.2 ° 0.0 0.0 °

Events

Info Flaps Position 1 8 ft agl
Info Flaps Position 2 8 ft agl
Info Flaps Position 3 8 ft agl
Info Taxi Lights Switched On 8 ft agl
Info Landing Lights Switched On 8 ft agl · 10 kt
Departure Runway Entry Entering runway 17L at LTFM İstanbul Airport, Average speed was 20 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 4 kt0 kt min to max 13 kt 4 13 kt
Info Average pitch angle -1.2 °-1.3 ° min to max -1.0 ° -1.3 -1.0 °
Info Average bank angle 0.0 °0.0 ° min to max 0.1 ° 0.0 0.0 °
Info Average g force 1.00 g1.00 g min to max 1.01 g 1.00 1.01 g
Departure Roll 95.00Departure roll runway 17L at LTFM İstanbul Airport. Takeoff distance 1,191 m 29 % of runway. Rotation speed was 139 kt. Local weather - Temperature 22 °C. Wind 19 kt at 219 °. Crosswind: 12 kt Headwind: 14 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 1,191 m29 % of runway
100 % Rotation speed was 139 ktTarget 138 kt
100 % Runway alignment max 4.96 m right0.87 m left to 4.96 m right -0.68 -4.96 m
100 % Average g force 1.01 g1.00 g min to max 1.07 g 1.00 1.07 g
100 % Takeoff Bounce
Info Average pitch angle -0.4 °-1.0 ° min to max 12.4 ° -1.0 12.4 °
Info Average bank angle 0.2 °0.0 ° min to max 2.4 ° 0.0 2.4 °

Events

Fail Strobe Lights
Departure Climb 1 99.52Departure climb to 50 ft agl from runway 17L LTFM İstanbul Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.4 °0.2 ° min to max 0.5 ° 0.2 0.5 °
100 % Average speed 149 kt145 kt min to max 153 kt 145 153 kt
98 % Steepest bank angle 6.8 °1.9 ° min to max 6.8 ° 2.7 1.9 °
100 % Average g force 1.09 g1.02 g min to max 1.18 g 1.08 1.03 g
Info Average VSI 672 fpm246 fpm min to max 1,008 fpm 246 1,008 fpm
Info Average altitude 19 ft agl0 ft agl min to max 45 ft agl 0 45 ft agl
Info Average pitch angle 13.5 °12.7 ° min to max 14.2 ° 12.7 13.8 °
Departure Climb 2 100.00Departure climb to 400 ft agl from 17L LTFM İstanbul Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.5 °0.5 ° min to max 0.5 ° 0.5 0.5 °
100 % Average speed 156 kt154 kt min to max 161 kt 154 161 kt
100 % Steepest bank angle 1.6 °0.0 ° min to max 1.6 ° 1.6 0.9 °
100 % Average g force 1.09 g1.03 g min to max 1.18 g 1.04 1.09 g
Info Average VSI 1,452 fpm1,020 fpm min to max 3,263 fpm 1,020 3,263 fpm
Info Average altitude 98 ft agl46 ft agl min to max 366 ft agl 46 366 ft agl
Info Average pitch angle 15.6 °13.9 ° min to max 20.5 ° 13.9 19.9 °

Events

Info Landing Gear Up 88 ft agl · 158 kt
Info Landing Gear Down 117 ft agl · 160 kt
Info Landing Gear Up 151 ft agl · 162 kt
Departure Climb 3 99.06Departure climb to 1,000 ft agl from 17L LTFM İstanbul Airport.
ScoreDescriptionStartProfileEnd
98 % Climb speed 160 kt159 kt min to max 162 ktTarget 176 kt, 16 kt slow 162 159 kt
100 % Steepest bank angle 2.3 °0.7 ° min to max 2.3 ° 0.7 1.4 °
100 % Average g force 0.96 g0.89 g min to max 1.01 g 0.96 0.94 g
100 % Landing gear up at 75 ft aglTarget by 400 ft agl
Info Heading variation 0.4 °0.3 ° min to max 0.5 ° 0.5 0.3 °
Info Average VSI 3,751 fpm3,514 fpm min to max 3,916 fpm 3,514 3,772 fpm
Info Average altitude 666 ft agl427 ft agl min to max 938 ft agl 427 938 ft agl
Info Average pitch angle 20.0 °19.1 ° min to max 20.8 ° 19.1 19.8 °
Enroute Climb 100.00Enroute climb started 1 mile west of LTFM İstanbul Airport Arnavutköy (Istanbul, Turkey). Climbing from 1,306 ft asl to 34,420 ft asl, an increase of 33,114 ft in 13 minutes and covering 125 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 245 kt158 kt min to max 271 kt 159 256 kt
100 % Steepest bank angle 31.0 °0.0 ° min to max 31.0 ° 1.0 1.2 °
100 % Average g force 1.04 g0.80 g min to max 1.27 g 0.89 1.00 g
Info Average VSI 2,218 fpm-350 fpm min to max 4,684 fpm 3,744 5 fpm
Info Average altitude 17,899 ft asl1,306 ft asl min to max 34,607 ft asl 1,306 34,420 ft asl
Info Average pitch angle 7.9 °2.6 ° min to max 19.5 ° 19.3 3.3 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Position 2 1,417 ft agl · 164 kt
Info Flaps Position 1 2,431 ft agl · 219 kt
Info Flaps Fully Retracted 2,636 ft agl · 235 kt
Info Taxi Lights Switched Off 5,823 ft agl · 266 kt
Info Landing Lights Switched Off 26,687 ft agl · 386 kt
Enroute Level 100.00Enroute level cruise started 8 miles north east of Bolyarovo (Oblast Yambol, Bulgaria) and lasted 11 minutes, covering 444 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,223 ft of 34,420 ft asl34,165 ft asl min to max 34,546 ft asl 34,456 34,204 ft asl
100 % Average speed 261 kt251 kt min to max 269 kt 256 256 kt
100 % Steepest bank angle 20.2 °0.0 ° min to max 20.2 ° 0.9 0.0 °
100 % Average g force 1.01 g0.98 g min to max 1.07 g 1.00 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 3.0 °2.7 ° min to max 3.6 ° 3.3 3.1 °
Enroute Descent 100.00Enroute descent started 6 miles north east of Celinac (Republika Srpska, Bosnia and Herzegovina). Descent from 34,183 ft asl to 9,028 ft asl, a decrease of 25,155 ft in 32 minutes and covering 364 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 252 kt238 kt min to max 266 kt 258 238 kt
100 % Steepest bank angle 31.4 °0.0 ° min to max 31.4 ° 0.1 8.2 °
100 % Average g force 1.02 g0.86 g min to max 1.25 g 1.00 0.97 g
Info Average VSI -742 fpm-2,485 fpm min to max 370 fpm -58 347 fpm
Info Average altitude 22,800 ft asl8,998 ft asl min to max 34,183 ft asl 34,183 9,028 ft asl
Info Average pitch angle 1.8 °-0.5 ° min to max 4.2 ° 3.0 3.6 °
Info Turn coordination 00 min to max 0 0 0
Enroute Level 2 100.00Enroute level cruise started overhead Cislago (Lombardia, Italy) and lasted 10 minutes, covering 43 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±952 ft of 9,022 ft asl8,995 ft asl min to max 9,062 ft asl 9,032 9,009 ft asl
100 % Average speed 231 kt224 kt min to max 243 kt 238 232 kt
100 % Steepest bank angle 30.5 °0.0 ° min to max 30.5 ° 6.6 0.0 °
100 % Average g force 1.07 g0.91 g min to max 1.28 g 0.94 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 3.8 °2.6 ° min to max 5.5 ° 3.2 3.4 °

Events

Info Landing Lights Switched On 8,235 ft agl · 277 kt
Info Taxi Lights Switched On 8,669 ft agl · 270 kt
Enroute Descent 2 100.00Enroute descent started overhead Cassolnovo (Lombardia, Italy). Descent from 9,004 ft asl to 3,261 ft asl, a decrease of 5,742 ft in 7 minutes and covering 24 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 183 kt136 kt min to max 228 kt 228 139 kt
100 % Steepest bank angle 23.9 °0.0 ° min to max 23.9 ° 0.1 0.0 °
100 % Average g force 1.02 g0.92 g min to max 1.17 g 1.01 1.00 g
Info Average VSI -856 fpm-1,181 fpm min to max 15 fpm 15 -716 fpm
Info Average altitude 5,636 ft asl3,261 ft asl min to max 9,004 ft asl 9,004 3,261 ft asl
Info Average pitch angle 2.8 °0.9 ° min to max 6.8 ° 3.6 2.8 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Position 1 5,698 ft agl · 242 kt
Info Flaps Position 2 5,556 ft agl · 239 kt
Info Flaps Position 3 5,490 ft agl · 237 kt
Info Landing Gear Down 4,569 ft agl · 206 kt
Info Flaps Position 4 4,061 ft agl · 177 kt
Info Flaps Position 5 4,056 ft agl · 177 kt
Info Flaps Position 6 3,302 ft agl · 163 kt
Info Flaps Position 7 3,277 ft agl · 162 kt
Enroute Level 3 100.00Enroute level cruise started overhead Sesto Calende (Lombardia, Italy) and lasted 2 minutes, covering 4 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±658 ft of 2,986 ft asl2,956 ft asl min to max 3,153 ft asl 3,153 2,957 ft asl
100 % Average speed 138 kt136 kt min to max 140 kt 138 136 kt
100 % Steepest bank angle 28.8 °0.0 ° min to max 28.8 ° 0.0 25.0 °
100 % Average g force 1.08 g0.89 g min to max 1.19 g 1.01 1.12 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 6.7 °3.1 ° min to max 9.4 ° 3.1 8.0 °
Enroute Descent 3 100.00Enroute descent started overhead Comabbio (Lombardia, Italy). Descent from 2,959 ft asl to 2,198 ft asl, a decrease of 762 ft in 2 minutes and covering 4 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 137 kt133 kt min to max 143 kt 136 135 kt
100 % Steepest bank angle 25.9 °0.1 ° min to max 25.9 ° 25.6 4.6 °
100 % Average g force 1.00 g0.88 g min to max 1.12 g 1.12 0.98 g
Info Average VSI -404 fpm-1,223 fpm min to max 262 fpm 103 -88 fpm
Info Average altitude 2,585 ft asl2,198 ft asl min to max 2,991 ft asl 2,959 2,198 ft asl
Info Average pitch angle 4.0 °0.2 ° min to max 8.5 ° 8.4 5.4 °
Info Turn coordination 00 min to max 0 0 0
Arrival Approach 92.86Final approach to runway 17L at LIMC Milan Malpensa International Airport. Descent from 1,482 ft agl to 96 ft agl in 104 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
50 % On centrelinefailed at one of the two gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates
Arrival Landing 88.09Landing on runway 17L at LIMC Milan Malpensa International Airport, runway length 2,974 m. Threshold height at 66 ft agl was above target. Threshold speed was good at 137 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 137 kt. Target 133 kt
77 % Threshold height at 66 ft agl was above target.Target 50 ft agl
76 % The flare wandered off the target profile. The flare took the sink out 26 ft agl above the runway and the aircraft flew down from there. Touchdown was 900 m past the threshold. Let it come lower before checking the descent - holding off high uses runway and leaves the touchdown to chance.
100 % Runway alignment max 5.57 m left5.57 m left to 4.36 m left 4.36 5.57 m
100 % Steepest bank angle 0.7 °0.0 ° min to max 0.7 ° 0.4 0.4 °
100 % Peak g force 1.11 g0.96 g min to max 1.11 g 1.01 1.02 g
Info Average speed 130 kt121 kt min to max 137 kt 137 121 kt
Info Average VSI -390 fpm-801 fpm min to max -168 fpm -801 -341 fpm
Info Average altitude 20 ft agl-13 ft agl min to max 66 ft agl 66 -13 ft agl
Info Average pitch angle 5.2 °2.4 ° min to max 6.3 ° 2.4 6.3 °
0751502253003754505256006757508259009751,05001325385164Runway Distance mLanding Height ft0751502253003754505256006757508259009751,050-30-24-18-12-60612182430Runway Distance mRunway Width m
Arrival Touchdown 92.73Touchdown point was 483 m beyond the touchdown zone. Touchdown speed at 121 kt was good. Touchdown rate was good at -175 fpm. Runway touchdown position was slightly misaligned by 6.0 m from centreline. Local weather - Temperature 16 °C. Wind 5 kt at 109 °. Crosswind: 4 kt Headwind: 3 kt.
ScoreDescriptionStartProfileEnd
100 % Touchdown rate was -175 fpm.
52 % Touchdown distance was 900 mTarget 457 m
100 % Speed at touchdown 121 ktTarget below 132 kt
100 % Runway alignment max 5.97 m left5.73 m left 5.57 5.97 m
100 % Steepest bank angle 0.5 °0.1 ° min to max 0.5 ° 0.4 0.5 °
100 % Peak g force 1.15 g1.01 g min to max 1.15 g 1.02 1.12 g
100 % Landing Bounce
Info Average speed 120 kt120 kt min to max 121 kt 121 120 kt
Info Average pitch angle 6.4 °6.3 ° min to max 6.4 ° 6.3 6.4 °
Arrival Rollout 99.28Total landing distance 1,744 m, 59 % of runway. Runway rollout alignment was slightly misaligned by 10.4 m from centreline.
ScoreDescriptionStartProfileEnd
100 % Landing distance 1,744 m59 % of runway.
98 % Runway alignment max 10.38 m left10.38 m left to 0.00 m left 10.38 6.96 m
100 % Average g force 1.01 g0.96 g min to max 1.11 g 1.11 0.96 g
Info Average speed 114 kt69 kt min to max 121 kt 121 69 kt
Info Average pitch angle 4.1 °-1.8 ° min to max 6.5 ° 6.4 -1.8 °
Info Average bank angle 1.3 °0.0 ° min to max 2.3 ° 0.6 0.2 °
Runway Exit Exiting runway, average speed 23 kt
ScoreDescriptionStartProfileEnd
Info Average speed 22 kt5 kt min to max 58 kt 58 6 kt
Info Average pitch angle -1.5 °-2.0 ° min to max -1.0 ° -1.9 -1.1 °
Info Average bank angle 0.1 °0.0 ° min to max 0.5 ° 0.1 0.5 °
Info Average g force 1.00 g0.97 g min to max 1.02 g 0.97 1.00 g

Events

Info Flaps Position 6 8 ft agl · 32 kt
Info Flaps Position 5 8 ft agl · 32 kt
Info Flaps Position 4 8 ft agl · 32 kt
Info Flaps Position 3 8 ft agl · 32 kt
Info Flaps Position 2 8 ft agl · 32 kt
Info Flaps Position 1 8 ft agl · 32 kt
Info Flaps Fully Retracted 8 ft agl · 29 kt
Arrival Taxi 100.00Taxiing to the parking from the runway took 11 minutes and covered 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 8 kt0 kt min to max 18 kt 6 0 kt
100 % Average speed turning corners 0 ktmax 0 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.02 g 1.00 1.00 g
Info Average pitch angle -1.0 °-1.6 ° min to max -0.8 ° -1.1 -1.4 °
Info Average bank angle 0.2 °0.0 ° min to max 0.5 ° 0.4 0.3 °

Events

Info Landing Lights Switched Off 8 ft agl
Info Pitot Heat Switched Off 8 ft agl · 2 kt

Takeoff from LTFM 17L

Taxi out

Lights75.00
Offstrobes
Taxi speed100.00
20kt peak12 kt in turns

The roll

Takeoff roll100.00
1,191m29 %
Runway alignment100.00
4.96m R
Rotation speed100.00
139kttarget 138, 1 late

On speed, but the nose came up quickly

Rotation started at 139 kt, 1 kt after the 138 kt rotate speed. The nose then rose at 6.7° a second, faster than the 2.6 to 4.8° a second other Boeing 737-700 pilots fly.

The rotation started on speed but the nose came up quickly. A fast pull raises the nose faster than the aircraft can lift off, which brings the tail closer to the runway. Pull smoothly at the normal rate for this aircraft and let it fly off at its own attitude.

Liftoff and climb

Liftoff
144ktat 12.7°
Rotation
6.7°/sover 2.0 s, gaining 5 kt
35 ft
152ktat 13.2°, 2.6 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff98.07
6.8°steepest
Gear up100.00
75ftfull marks to 400 ft
Climb 3 speed97.66
160kttarget 176

Plan view the roll down the 4,105 m runway.

Rolled from 259 m in, drifted right of the centreline, 5 m at the widest, and lifted off 5.2 m right, in 12 kn of crosswind from the right. Airborne 29 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

1,0002,0003,0004,000THRESHOLDLEFT ↑RIGHT ↓CROSS12 kn75 %widest 4.96 m RROLL 259 M INAirborne 1,195 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,195 m of 4,105 m · 29 %
Behind the start of the roll, 259 mTakeoff roll, 936 m Left ahead, 2,910 m

Side view from the start of the roll to the end of Climb 3 at 939 ft.

Reached 35 ft with 2,729 m of runway left; gear up at 75 ft, inside the 400 ft that gets full marks; then climbing at 2,760 fpm on average to 939 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3160 kt avgtarget 176THRESHOLDRUNWAY END6080100120KNOTS ALONG THE ROLLnose up on the runway · 135 m · 2.0 sRotate 139 kttarget 138Liftoff 144 ktGear up 75 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 176180 kt12060025°13°0°nose up on the runway · 135 m · 2.0 sROTATELIFTOFFGEAR UPtarget 138held 15.9°12.7° off · 6.7°/s13° at 35 ftAIRSPEEDPITCH02040 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2.6 to 4.8° a second, the middle half of rotation rates flown by other Boeing 737-700 pilots over the last 180 days (90 takeoffs); the grey pair are 2 to 3° a second, the rates airliners are rotated at. A trace steeper than both green lines is a faster rotation than most, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 14.7°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 14.7°ROTATELIFTOFF35 FT12.7° off · 6.7°/s4.8°/s3°/s2.6°/s2°/s13° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5 sseconds from rotation
PitchRotation began2.6 to 4.8°/s, other Boeing 737-700 pilots2 to 3°/s from rotation, airlinersTail strikeNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 85.716 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate1,110 fpm600 fpm
On glideslope3.6°3.3°
On centreline5.1° off0.6° off
On speed+6.7 kt+2.8 kt
Wings level0° bank4° bank

At the 1,000 ft gate: centreline more than 1° off.

When the approach was stable

Every check met from 2.1 nm, about 760 ft above the runway, to the threshold, after the 1,000 ft gate and before the 500 ft gate. The last to settle was the centreline.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to LIMC 17L

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3.2° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 170 ft above the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3.2° here, which is about 340 ft for every nautical mile out, crossing the threshold at about 60 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,4101,0807404003.2° GLIDESLOPE · 1° BAND1,4527423652341,000 ft gate6 of 7on centreline1,162 ft · 140 kt500 ft gate7 of 7552 ft · 136 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 3× larger than distances along the final.

Joined 838 m right of the centreline, then inside the band from 2.1 nm to the threshold.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR305 m L0305 m RLEFT ↑RIGHT ↓1° BAND838 m R50 m R13 m L0 m R486 m R31 m L
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 33 kt fast at the 1,000 ft gate, closing to 20 at 500 ft and 10 at the threshold.

Inside the speed band all the way, between −3 kt and +7 kt on the approach speed of 133 kt.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

120140160180 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 133+4 kt−3 kt+3 kt+6 kt+4 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on LIMC 17L

Over the threshold

Threshold height76.53
65ft
Threshold speed100.00
136kttarget 133, 3 fast
Centreline offset100.00
5.57m L
Bank100.00
0.7°steepest
Flare75.81

The flare wandered off the target profile

The flare took the sink out 26 ft agl above the runway and the aircraft flew down from there. Touchdown was 900 m past the threshold. Let it come lower before checking the descent - holding off high uses runway and leaves the touchdown to chance.

Touchdown

Past threshold51.54
900m
Centreline100.00
5.97m L
Speed100.00
120kttarget 132 or less
Touchdown rate100.00
-175fpm
Impact100.00
1.15G
BouncesOk
None
Bank100.00
0.5°as the wheels touched

Rollout

Rollout distance100.00
803m57 % used
Rollout alignment98.41
10.38m L

Taxi in

LightsOk
All set
Taxi speed100.00
18kt peak

Side view — the last 1,826 m of the approach.

Crossed the threshold at 65 ft, 15 ft above the 50 ft target; began the flare at 44 ft. Touched down 900 m in, 596 m past the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,826 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

65 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 44 ft · −684 fpm · 4° · 136 ktdescent slowed at 26 ft · −96 fpm · 5.6°−174 fpm · 6.3° nose up · 121 kt Ideal — 50 ft, down at 305 m This flight — 65 ft, down at 900 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 680 fpm at the flare to 170 fpm at touchdown. The nose came up 2.3° on the way down. Into the flare at 136 kt, 3 kt over the 133 kt approach speed, and 121 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−174 fpm at touchdown6.3° at touchdown, +2.3° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,826 m of the 2,974 m runway, to the same scale as the side view.

Touched down 6 m left of the centreline and drifted to 10 m left on the rollout. 3 kt across from the left, which takes about 1° of crab to hold the centreline at 121 kt. Touched down with the nose 2° into wind, wings level.

Wind 110° at 4 kt · 2 kt head · 3 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ CROSS 3 kn FULL SCORE TO 503 M 900 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

Touched down 900 m past the threshold — beyond the full-score zone. The arrival was smooth.

Runway used 1,704 m of 2,974 m · 57 %
In the air over the runway, 900 mRollout, 803 m Left over, 1,270 m

The stop — touchdown to taxi speed.

From 122 kt at touchdown to taxi speed (30 kt) in 37 s, an average deceleration of 0.13 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 877 m30 kt · 1,228 mtouchdown1,277 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
