EGSS
London, England
Runway 22
Elevation338 ft asl
Weight273,873 kg
Fuel18,754 kg
Wind190° · 6 kn · 3 kn cross

Flight Score

99.98 %
EDDL
Düsseldorf, Germany
Runway 23L
Elevation125 ft asl
Weight267,477 kg
Fuel12,071 kg
Wind200° · 5 kn · 2 kn cross
8 Oct 2024 0:56 293 nm Boeing 747-8 6,684 kg
Departure Score
100.00 %
Enroute Score
99.95 %
Arrival Score
100.00 %

What went well

Touched down at -227 fpm — a soft arrival
Touchdown 134 m in — inside the full-score zone
Threshold crossed at 14 ft and 134 kt — both inside band

What held you back

Nothing — every scored stage stayed inside its band. Clean flight.

Start to finish · 17 stages, 15 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 4 minutes and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 11 kt0 kt min to max 20 kt 3 16 kt
100 % Average speed turning corners 0 ktmax 0 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle -0.7 °-1.0 ° min to max -0.6 ° -0.6 -1.0 °
Info Average bank angle 0.1 °0.0 ° min to max 0.3 ° 0.3 0.1 °

Events

Info Engine 2 Started 15 ft agl
Info Engine 3 Started 15 ft agl
Info Parking Brake On 15 ft agl
Info Flaps Position 2 15 ft agl
Info Flaps Position 3 15 ft agl
Info Taxi Lights Switched On 15 ft agl
Info Parking Brake Off 15 ft agl
Info Autopilot AutoThrottle Arm Armed 15 ft agl · 4 kt
Info Autopilot Airspeed Hold Activated 15 ft agl · 6 kt
Info Autopilot Vertical Hold Activated 15 ft agl · 6 kt
Info Autopilot AutoThrottle Arm Disarmed 15 ft agl · 12 kt
Info Landing Lights Switched On 15 ft agl
Info Strobe Lights Switched On 15 ft agl
Departure Runway Entry Entering runway 22 at EGSS London Stansted Airport, Average speed was 20 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 16 kt16 kt min to max 16 kt 16 16 kt
Info Average pitch angle -0.9 °-1.0 ° min to max -0.9 ° -1.0 -0.9 °
Info Average bank angle 0.1 °0.0 ° min to max 0.1 ° 0.0 0.1 °
Info Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Departure Roll 100.00Departure roll runway 22 at EGSS London Stansted Airport. Takeoff distance 1,004 m 33 % of runway. Rotation speed was 135 kt. Local weather - Temperature 18 °C. Wind 6 kt at 190 °. Crosswind: 3 kt Headwind: 5 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 1,004 m33 % of runway
100 % Rotation speed was 135 ktTarget 141 kt
100 % Runway alignment max 1.34 m left1.34 m left to 0.00 m left 0.25 1.34 m
100 % Average g force 1.00 g0.93 g min to max 1.06 g 1.00 1.01 g
100 % Takeoff Bounce
Info Average pitch angle -0.0 °-0.8 ° min to max 7.1 ° -0.8 7.1 °
Info Average bank angle 0.3 °0.0 ° min to max 1.4 ° 0.0 1.4 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 22 EGSS London Stansted Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.1 °-0.1 ° min to max -0.0 ° -0.1 -0.0 °
100 % Average speed 163 kt150 kt min to max 174 kt 150 174 kt
100 % Steepest bank angle 1.8 °0.0 ° min to max 1.8 ° 1.5 1.3 °
100 % Average g force 1.07 g1.02 g min to max 1.10 g 1.02 1.07 g
Info Average VSI 423 fpm29 fpm min to max 842 fpm 29 842 fpm
Info Average altitude 16 ft agl0 ft agl min to max 43 ft agl 0 43 ft agl
Info Average pitch angle 7.6 °7.2 ° min to max 8.2 ° 7.2 8.2 °

Events

Info Landing Gear Up 52 ft agl · 174 kt
Departure Climb 2 100.00Departure climb to 400 ft agl from 22 EGSS London Stansted Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.1 °-0.2 ° min to max -0.0 ° -0.0 -0.2 °
100 % Average speed 181 kt174 kt min to max 209 kt 174 209 kt
100 % Steepest bank angle 1.3 °0.0 ° min to max 1.3 ° 1.3 0.1 °
100 % Average g force 1.15 g0.96 g min to max 1.24 g 1.08 1.24 g
Info Average VSI 1,342 fpm856 fpm min to max 2,763 fpm 856 2,763 fpm
Info Average altitude 98 ft agl44 ft agl min to max 383 ft agl 44 383 ft agl
Info Average pitch angle 9.2 °7.9 ° min to max 10.7 ° 8.3 10.7 °

Events

Info Autopilot Heading Hold Activated 90 ft agl · 183 kt
Info Flaps Position 2 197 ft agl · 196 kt
Info Flaps Position 1 411 ft agl · 214 kt
Departure Climb 3 100.00Departure climb to 1,000 ft agl from 22 EGSS London Stansted Airport.
ScoreDescriptionStartProfileEnd
100 % Climb speed 220 kt212 kt min to max 226 ktTarget 202 kt, 18 kt fast 212 226 kt
100 % Steepest bank angle 13.1 °0.2 ° min to max 13.1 ° 0.3 13.1 °
100 % Average g force 1.03 g0.93 g min to max 1.12 g 1.12 0.97 g
100 % Landing gear up at 29 ft aglTarget by 400 ft agl
Info Heading variation -0.2 °-0.3 ° min to max -0.2 ° -0.2 -0.3 °
Info Average VSI 3,912 fpm3,184 fpm min to max 4,288 fpm 3,184 4,253 fpm
Info Average altitude 673 ft agl440 ft agl min to max 918 ft agl 440 918 ft agl
Info Average pitch angle 11.0 °10.7 ° min to max 11.4 ° 10.7 10.8 °
Enroute Climb 100.00Enroute climb started overhead EGSS London Stansted Airport London (Essex, England). Climbing from 1,349 ft asl to 4,002 ft asl, an increase of 2,653 ft in 2 minutes and covering 8 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 249 kt228 kt min to max 263 kt 228 251 kt
100 % Steepest bank angle 29.2 °0.0 ° min to max 29.2 ° 16.0 0.0 °
99.99 % Average g force 1.05 g0.69 g min to max 1.30 g 1.03 0.99 g
Info Average VSI 1,931 fpm-1,771 fpm min to max 4,702 fpm 4,235 -241 fpm
Info Average altitude 3,307 ft asl1,349 ft asl min to max 4,153 ft asl 1,349 4,002 ft asl
Info Average pitch angle 5.5 °-1.8 ° min to max 11.9 ° 11.2 2.2 °
Info Turn coordination 00 min to max 0 0 0

Events

Fail Exceeded 250 kn below 10000 ft 2,759 ft agl
Info Autopilot Master Switched On 1,494 ft agl · 243 kt
Info Autopilot AutoThrottle Arm Armed 2,814 ft agl · 277 kt
Info Flaps Fully Retracted 3,345 ft agl · 267 kt
Info Autopilot Vertical Hold Deactivated 3,720 ft agl · 268 kt
Info Autopilot Vertical Hold Activated 3,766 ft agl · 268 kt
Enroute Level 99.99Enroute level cruise started 1 mile north east of High Easter (Essex, England) and lasted 2 minutes, covering 8 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±700 ft of 4,016 ft asl3,994 ft asl min to max 4,172 ft asl 4,001 4,172 ft asl
100 % Average speed 250 kt250 kt min to max 256 kt 250 256 kt
100 % Steepest bank angle 2.9 °0.0 ° min to max 2.9 ° 2.5 0.7 °
99.9 % Average g force 1.03 g0.93 g min to max 1.31 g 1.02 1.31 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 3.3 °2.4 ° min to max 10.9 ° 2.6 10.9 °

Events

Info Autopilot Airspeed Hold Deactivated 3,722 ft agl · 269 kt
Info Autopilot Vertical Hold Deactivated 3,722 ft agl · 269 kt
Info Autopilot RPM Hold Activated 3,722 ft agl · 269 kt
Info Autopilot Airspeed Hold Activated 3,719 ft agl · 270 kt
Info Autopilot Vertical Hold Activated 3,719 ft agl · 270 kt
Info Autopilot RPM Hold Deactivated 3,719 ft agl · 270 kt
Info Autopilot Airspeed Hold Deactivated 3,801 ft agl · 269 kt
Info Autopilot Vertical Hold Deactivated 3,801 ft agl · 269 kt
Info Autopilot RPM Hold Activated 3,801 ft agl · 269 kt
Enroute Climb 2 99.97Enroute climb started 1 mile south west of Silver End (Essex, England). Climbing from 5,065 ft asl to 36,542 ft asl, an increase of 31,477 ft in 14 minutes and covering 100 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 302 kt247 kt min to max 327 kt 247 270 kt
100 % Steepest bank angle 38.8 °0.0 ° min to max 38.8 ° 0.5 1.3 °
99.7 % Average g force 1.01 g0.35 g min to max 1.42 g 0.80 0.91 g
Info Average VSI 2,531 fpm-1,220 fpm min to max 5,934 fpm 5,486 165 fpm
Info Average altitude 23,572 ft asl5,011 ft asl min to max 36,542 ft asl 5,065 36,542 ft asl
Info Average pitch angle 4.4 °0.1 ° min to max 13.4 ° 12.1 1.8 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Airspeed Hold Deactivated 4,934 ft agl · 272 kt
Info Autopilot Vertical Hold Deactivated 4,934 ft agl · 272 kt
Info Autopilot RPM Hold Activated 4,934 ft agl · 272 kt
Info Autopilot Airspeed Hold Activated 5,415 ft agl · 278 kt
Info Autopilot Vertical Hold Activated 5,415 ft agl · 278 kt
Info Autopilot RPM Hold Deactivated 5,415 ft agl · 278 kt
Info Autopilot Airspeed Hold Deactivated 6,341 ft agl · 274 kt
Info Autopilot Vertical Hold Deactivated 6,341 ft agl · 274 kt
Info Autopilot RPM Hold Activated 6,341 ft agl · 274 kt
Info Landing Lights Switched Off 13,876 ft agl · 380 kt
Info Taxi Lights Switched Off 14,002 ft agl · 381 kt
Info Autopilot Airspeed Hold Activated 36,334 ft agl · 485 kt
Info Autopilot Vertical Hold Activated 36,334 ft agl · 485 kt
Info Autopilot RPM Hold Deactivated 36,334 ft agl · 485 kt
Enroute Level 2 99.79Enroute level cruise started 23 miles north west of Nieuw-Haamstede (Provincie Zeeland, The Netherlands) and lasted 5 minutes, covering 40 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,327 ft of 36,533 ft asl36,361 ft asl min to max 36,598 ft asl 36,538 36,570 ft asl
100 % Average speed 270 kt267 kt min to max 273 kt 270 271 kt
100 % Steepest bank angle 18.0 °0.1 ° min to max 18.0 ° 1.7 8.7 °
98 % Average g force 1.00 g0.32 g min to max 1.44 g 1.04 1.01 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 2.3 °-1.4 ° min to max 5.5 ° 2.4 1.9 °
Enroute Descent 100.00Enroute descent started 2 miles north west of Schiedam (Provincie Zuid-Holland, The Netherlands). Descent from 36,542 ft asl to 1,485 ft asl, a decrease of 35,057 ft in 23 minutes and covering 130 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 231 kt143 kt min to max 297 kt 269 143 kt
100 % Steepest bank angle 29.1 °0.0 ° min to max 29.1 ° 7.0 1.1 °
99.98 % Average g force 1.02 g0.68 g min to max 1.30 g 0.96 1.05 g
Info Average VSI -1,114 fpm-3,087 fpm min to max 616 fpm -266 -664 fpm
Info Average altitude 12,767 ft asl1,485 ft asl min to max 36,600 ft asl 36,542 1,485 ft asl
Info Average pitch angle 1.1 °-4.8 ° min to max 8.2 ° 2.8 3.8 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Airspeed Hold Deactivated 33,495 ft agl · 485 kt
Info Autopilot Airspeed Hold Activated 24,809 ft agl · 434 kt
Info Autopilot Airspeed Hold Deactivated 24,536 ft agl · 421 kt
Info Autopilot Vertical Hold Deactivated 24,536 ft agl · 421 kt
Info Autopilot RPM Hold Activated 24,536 ft agl · 421 kt
Info Autopilot Airspeed Hold Activated 23,978 ft agl · 422 kt
Info Autopilot RPM Hold Deactivated 23,978 ft agl · 422 kt
Info Autopilot Vertical Hold Activated 23,929 ft agl · 422 kt
Info Autopilot Airspeed Hold Deactivated 17,202 ft agl · 377 kt
Info Autopilot Vertical Hold Deactivated 17,202 ft agl · 377 kt
Info Autopilot RPM Hold Activated 17,202 ft agl · 377 kt
Info Autopilot RPM Hold Deactivated 16,338 ft agl · 374 kt
Info Autopilot Airspeed Hold Activated 14,157 ft agl · 362 kt
Info Autopilot Vertical Hold Activated 14,157 ft agl · 362 kt
Info Landing Lights Switched On 10,700 ft agl · 283 kt
Info Taxi Lights Switched On 10,656 ft agl · 284 kt
Info Flaps Position 1 3,859 ft agl · 225 kt
Info Flaps Position 2 3,449 ft agl · 224 kt
Info Flaps Position 3 2,916 ft agl · 196 kt
Info Landing Gear Down 2,708 ft agl · 196 kt
Info Autopilot Heading Hold Deactivated 2,606 ft agl · 180 kt
Info Autopilot Approach Mode Activated 2,606 ft agl · 180 kt
Info Autopilot Vertical Hold Deactivated 2,580 ft agl · 170 kt
Info Flaps Position 4 2,611 ft agl · 170 kt
Info Flaps Position 5 1,492 ft agl · 163 kt
Info Flaps Position 6 1,278 ft agl · 149 kt
Arrival Approach 100.00Final approach to runway 23L at EDDL Düsseldorf Airport. Descent from 1,370 ft agl to 54 ft agl in 100 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates

Events

Info Autopilot AutoThrottle Arm Disarmed 1,021 ft agl · 148 kt
Info Autopilot Master Switched Off 1,051 ft agl · 148 kt
Arrival Landing 100.00Landing on runway 23L at EDDL Düsseldorf Airport, runway length 2,690 m. Good threshold height. Threshold speed was good at 135 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 135 kt. Target 137 kt
100 % Good threshold height.Target 50 ft agl
100 % Perfect landing flare
100 % Runway alignment max 4.09 m right3.34 m right to 4.09 m right -4.09 -3.34 m
100 % Steepest bank angle 0.2 °0.0 ° min to max 0.2 ° 0.2 0.0 °
100 % Peak g force 1.10 g0.97 g min to max 1.10 g 0.98 1.10 g
Info Average speed 134 kt133 kt min to max 135 kt 135 133 kt
Info Average VSI -407 fpm-440 fpm min to max -320 fpm -428 -320 fpm
Info Average altitude 8 ft agl3 ft agl min to max 14 ft agl 14 3 ft agl
Info Average pitch angle 6.4 °5.2 ° min to max 6.9 ° 5.2 6.8 °
07515001123344657Runway Distance mLanding Height ft075150-24-20-16-12-8-404812162024Runway Distance mRunway Width m
Arrival Touchdown 100.00Touchdown distance was good at 134 m. Touchdown speed at 133 kt was good. Touchdown rate was fair at -227 fpm. Runway touchdown position was slightly misaligned by 3.3 m from centreline. Local weather - Temperature 18 °C. Wind 5 kt at 200 °. Crosswind: 2 kt Headwind: 4 kt.
ScoreDescriptionStartProfileEnd
100 % Touchdown rate was -227 fpm.
100 % Touchdown distance was 134 mTarget 457 m
100 % Speed at touchdown 133 ktTarget below 136 kt
100 % Runway alignment max 3.34 m right3.19 m right -3.34 -2.98 m
100 % Steepest bank angle 0.7 °0.0 ° min to max 0.7 ° 0.0 0.7 °
100 % Peak g force 1.28 g1.07 g min to max 1.28 g 1.10 1.15 g
100 % Landing Bounce
Info Average speed 132 kt132 kt min to max 133 kt 133 132 kt
Info Average pitch angle 6.6 °6.3 ° min to max 6.8 ° 6.8 6.3 °
Arrival Rollout 100.00Total landing distance 1,250 m, 46 % of runway. Runway rollout alignment was perfect.
ScoreDescriptionStartProfileEnd
100 % Landing distance 1,250 m46 % of runway.
100 % Runway alignment max 0.57 m left0.57 m left to 0.48 m right 0.37 0.38 m
100 % Average g force 1.00 g0.96 g min to max 1.10 g 1.10 0.99 g
Info Average speed 113 kt67 kt min to max 130 kt 130 67 kt
Info Average pitch angle 2.9 °-0.7 ° min to max 6.2 ° 6.2 -0.7 °
Info Average bank angle 1.2 °0.0 ° min to max 2.2 ° 0.7 0.2 °
Runway Exit Exiting runway, average speed 35 kt
ScoreDescriptionStartProfileEnd
Info Average speed 31 kt0 kt min to max 62 kt 62 6 kt
Info Average pitch angle -0.6 °-0.9 ° min to max -0.4 ° -0.9 -0.7 °
Info Average bank angle 0.3 °0.0 ° min to max 0.6 ° 0.1 0.0 °
Info Average g force 1.00 g0.99 g min to max 1.01 g 1.01 1.00 g

Events

Info Flaps Fully Retracted 15 ft agl · 61 kt
Info Landing Lights Switched Off 15 ft agl · 7 kt
Info Strobe Lights Switched Off 15 ft agl · 8 kt
Arrival Taxi 100.00Taxiing to the parking from the runway took 4 minutes and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 9 kt0 kt min to max 15 kt 7 6 kt
100 % Average speed turning corners 0 ktmax 0 kt 0 0 kt
100 % Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Info Average pitch angle -0.7 °-0.8 ° min to max -0.7 ° -0.7 -0.8 °
Info Average bank angle 0.1 °0.0 ° min to max 0.4 ° 0.0 0.0 °

Takeoff from EGSS 22

Taxi out

LightsOk
All on
Taxi speed100.00
20kt peak

The roll

Takeoff roll100.00
1,004m33 %
Runway alignment100.00
1.34m L
Rotation speed100.00
135kttarget 141, 6 early

Rotated early

Rotation started at 135 kt, 6 kt before the 141 kt rotate speed.

The rotate speed is set for the weight and the flap, and the nose should not start up before it. Lifting it early brings the aircraft to its liftoff attitude with less speed in hand, and on a long fuselage that is the tail-strike case. Keep the hands still until the speed is there, then make one smooth, continuous pull.

Liftoff and climb

Liftoff
150ktat 7.2°
Rotation
2.8°/sover 2.7 s, gaining 15 kt
35 ft
172ktat 7.5°, 3.7 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
1.8°steepest
Gear up100.00
29ftfull marks to 400 ft
Climb 3 speed100.00
220kttarget 202

Plan view the roll down the 3,034 m runway.

Rolled from 93 m in, drifted left of the centreline, 1.6 m at the widest, and lifted off 1.6 m left. Airborne 33 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

1,0002,0003,000THRESHOLDLEFT ↑RIGHT ↓CROSS2 kn75 %widest 1.62 m LROLL 93 M INAirborne 1,010 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,010 m of 3,034 m · 33 %
Behind the start of the roll, 93 mTakeoff roll, 918 m Left ahead, 2,024 m

Side view from the start of the roll to the end of Climb 3 at 918 ft.

Reached 35 ft with 1,713 m of runway left; gear up at 29 ft, inside the 400 ft that gets full marks; then climbing at 2,520 fpm on average to 918 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3220 kt avgtarget 202THRESHOLDRUNWAY END6080100120KNOTS ALONG THE ROLLnose up on the runway · 201 m · 2.7 sRotate 135 kttarget 141Liftoff 150 ktGear up 29 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 202240 kt16080020°10°0°nose up on the runway · 201 m · 2.7 sROTATELIFTOFFtarget 141held 9.2°7.2° off · 2.8°/s8° at 35 ftAIRSPEEDPITCH02040 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2 to 3° a second, the rates airliners are rotated at: a trace steeper than both is a faster rotation, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 12.1°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 12.1°ROTATELIFTOFF35 FT3°/s7.2° off · 2.8°/s2°/s8° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5+6+7 sseconds from rotation
PitchRotation began2 to 3°/s from rotationTail strikeNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate800 fpm800 fpm
On glideslope3.1°3.0°
On centreline0.1° off0.3° off
On speed+6.2 kt+6.3 kt
Wings level6° bank1° bank

When the approach was stable

Every check met from 4 nm to 0.6 nm, then not again: low from 0.6 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to EDDL 23L

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

On the glideslope from 4 nm to 0.6 nm, then low to the threshold (up to 90 ft under).

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,3306763331331,000 ft gate7 of 71,052 ft · 143 kt500 ft gate7 of 7521 ft · 143 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 8× larger than distances along the final.

Inside the 1° band all the way from 4 nm, never more than 50 m off the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR125 m L0125 m RLEFT ↑RIGHT ↓1° BAND50 m R33 m R2 m R4 m R3 m L17 m R
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 34 kt fast at the 1,000 ft gate, closing to 21 at 500 ft and 10 at the threshold.

Inside the speed band all the way, between −2 kt and +12 kt on the approach speed of 137 kt.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

140160180200 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 137+6 kt+9 kt+7 kt+5 kt−2 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on EDDL 23L

Over the threshold

Threshold height100.00
14ft
Threshold speed100.00
134kttarget 137, 3 slow
Centreline offset100.00
4.09m R
Bank100.00
0.2°steepest
Flare100.00

Perfect landing flare

Touchdown

Past threshold100.00
134m
Centreline100.00
3.34m R
Speed100.00
132kttarget 136 or less
Touchdown rate100.00
-227fpm
Impact100.00
1.28G
BouncesOk
None
Bank100.00
0.7°as the wheels touched

Rollout

Rollout distance100.00
1,086m45 % used
Rollout alignment100.00
0.57m L

Taxi in

LightsOk
All set
Taxi speed100.00
15kt peak

Side view — the last 1,524 m of the approach.

Began the flare at 30 ft, 175 m before the threshold; crossed the threshold at 14 ft, 36 ft below the 50 ft target. Touched down 134 m in, 170 m short of the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,524 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

14 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare began at 30 ft, 175 m before the threshold−430 fpm · 4.4° · 137 ktdescent slowed at 1 ft · −264 fpm · 6.9°−227 fpm · 6.8° nose up · 133 kt Ideal — 50 ft, down at 305 m This flight — 14 ft, down at 134 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 430 fpm at the flare to 230 fpm at touchdown. The nose came up 2.5° on the way down. Into the flare at 137 kt, on the 137 kt approach speed, and 133 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°descent slowedtouchdown−227 fpm at touchdown6.8° at touchdown, +2.5° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,524 m of the 2,690 m runway, to the same scale as the side view.

Touched down 3 m right of the centreline, and stayed about there down the rollout, 3.3 m right at the widest. Little crosswind (2 kt): nothing to correct for. Touched down with the nose 1° left of the track, wings level.

Wind 200° at 5 kt · 4 kt head · 2 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ CROSS 2 kn FULL SCORE TO 503 M 134 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

The 134 m touchdown sits inside the full-score zone. The arrival was smooth.

Runway used 1,220 m of 2,690 m · 45 %
In the air over the runway, 134 mRollout, 1,086 m Left over, 1,469 m

The stop — touchdown to taxi speed.

From 132 kt at touchdown to taxi speed (30 kt) in 52 s, an average deceleration of 0.10 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 1,223 m30 kt · 1,738 mtouchdown1,808 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Flight narrative

The flight in the Boeing 747-8 began with a 4-minute taxi from the parking area to the runway at EGSS Stansted. The departure roll on runway 22 covered a distance of 904 meters, which was 33% of the total runway length. The liftoff speed was 150 knots. The local weather at the time of departure was 16°C with a 6 knot wind coming from 190° resulting in a 3 knot crosswind and 5 knot headwind.

The enroute climb started over EGSS Stansted in London, ascending from 1,349 feet above sea level (asl) to 3,930 feet asl, covering a distance of 4 nautical miles in just 1 minute. The next phase of level cruise started over Hatfield Broad Oak and lasted 2 minutes over a distance of 10 nautical miles.

Another enroute climb began 1 mile east of Great Leighs, climbing from 3,995 ft asl to 36,535 ft asl, covering a distance of 94 nautical miles in 13 minutes. This was followed by a 6-minute level cruise segment covering 51 nautical miles.

The descent phase of the flight started over Schiebroek, descending from 36,572 ft asl to 2,159 ft asl, over a distance of 98 nautical miles in 21 minutes. The landing was executed on runway 23L at EDDL Dusseldorf, with a runway length of 2,395 meters. The aircraft approached with a height of 15 feet above ground level and a speed of 135 knots. The touchdown occurred 138 meters from the threshold at a speed of 133 knots with a vertical speed indicator showing a descent rate of -320 feet per minute. The local weather at the destination was 20°C with a 5 knot wind coming from 200°, resulting in a 2 knot crosswind and 4 knot headwind. The total landing distance was 1,256 meters, which was 52% of the total runway length.

After landing, the aircraft taxied for 4 minutes from the runway to the parking area covering less than 1 nautical mile. The total flight distance covered was 265 nautical miles, with a total duration of 65 minutes. The flight consumed 6,688 kilograms of fuel during the journey.

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
