TKPK
Basseterre, Saint Kitts and Nevis
Runway 25
Elevation161 ft asl
Weight31,971 kg
Fuel4,610 kg
Wind240° · 12 kn · 1 kn cross

Flight Score

97.51 %
TGPY
Saint George's, Grenada
Runway 10
Elevation36 ft asl
Weight30,004 kg
Fuel2,599 kg
Wind150° · 11 kn · 9 kn cross
22 Oct 2023 1:31 568 nm Embraer E170 2,011 kg
Departure Score
97.49 %
Enroute Score
100.00 %
Arrival Score
95.04 %

What went well

Touchdown 288 m in — inside the full-score zone
Rollout controlled — 26 % of the runway used
Rollout held the centreline — 8.52 m off at taxi speed

What held you back

Departure Roll — Landing Lights at 0 %, Strobe Lights at 0 %, −0.83 points
Firm touchdown — 370 fpm, −0.70 points across the landing and the touchdown
  • Arrival Touchdown · sink rate 370 fpm−0.35
  • Arrival Landing · flare: the descent was not taken out−0.33
  • Arrival Touchdown · 1.40 G at contact−0.02
Arrival Approach — GPWS warning; 1,000 ft gate 86 %, 500 ft gate 100 %, −0.48 points

Next time

Arrival

Begin the flare with progressive back pressure and keep it coming until the sink is arrested, rather than flying it on flat.

What happened: The nose was barely raised in the flare and little of the sink was taken out, flying the aircraft onto the runway. This pattern usually carries through to a firm touchdown with a noticeable sink rate.

Watch for: Vertical speed indicator: a smoothly reducing sink through the normal flare band, not a steady rate into the runway.

See Arrival LandingArrival Touchdown

The rudder input is a changing profile through the roll rather than one that is held. So the demand on your right foot starts large at power application, eases as speed builds and the rudder gains authority, then jumps again at rotation.

Read more in Improve Your Take-Offs

Start to finish · 14 stages, 13 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Roll 90.00Departure roll runway 25 at TKPK Robert L. Bradshaw International Airport. Takeoff distance 972 m 44 % of runway. Rotation speed was 113 kt. Local weather - Temperature 29 °C. Wind 16 kt at 240 °. Crosswind: 1 kt Headwind: 16 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 972 m44 % of runway
100 % Rotation speed was 113 ktTarget 114 kt
100 % Runway alignment max 2.02 m left2.02 m left to 0.36 m right -0.24 1.45 m
100 % Average g force 0.99 g0.97 g min to max 1.01 g 1.00 0.98 g
100 % Takeoff Bounce
Info Average pitch angle 2.0 °0.5 ° min to max 7.1 ° 0.6 7.1 °
Info Average bank angle 0.2 °0.0 ° min to max 0.8 ° 0.0 0.4 °

Events

Fail Landing Lights
Fail Strobe Lights
Info Parking Brake Off 6 ft agl · 12 kt
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 25 TKPK Robert L. Bradshaw International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.0 °-0.1 ° min to max 0.1 ° -0.1 0.1 °
100 % Average speed 151 kt139 kt min to max 162 kt 142 162 kt
100 % Steepest bank angle 0.5 °0.0 ° min to max 0.5 ° 0.4 0.3 °
100 % Average g force 1.07 g0.98 g min to max 1.18 g 0.98 1.18 g
Info Average VSI 584 fpm266 fpm min to max 1,027 fpm 266 1,027 fpm
Info Average altitude 17 ft agl0 ft agl min to max 51 ft agl 0 51 ft agl
Info Average pitch angle 8.6 °7.3 ° min to max 10.8 ° 7.3 10.8 °

Events

Info Landing Gear Up 32 ft agl · 157 kt
Departure Climb 2 99.98Departure climb to 400 ft agl from 25 TKPK Robert L. Bradshaw International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.1 °0.1 ° min to max 0.2 ° 0.1 0.2 °
100 % Average speed 162 kt159 kt min to max 174 kt 162 174 kt
100 % Steepest bank angle 0.4 °0.0 ° min to max 0.4 ° 0.3 0.1 °
99.8 % Average g force 1.18 g1.12 g min to max 1.26 g 1.18 1.26 g
Info Average VSI 1,579 fpm1,050 fpm min to max 3,787 fpm 1,050 3,787 fpm
Info Average altitude 99 ft agl53 ft agl min to max 355 ft agl 53 355 ft agl
Info Average pitch angle 12.5 °10.9 ° min to max 17.8 ° 10.9 17.4 °

Events

Info Autopilot Master Switched On 291 ft agl · 173 kt
Info Autopilot Wing Leveler Activated 291 ft agl · 173 kt
Info Autopilot Altitude Hold Deactivated 291 ft agl · 173 kt
Info Autopilot Vertical Hold Activated 291 ft agl · 173 kt
Departure Climb 3 100.00Departure climb to 1,000 ft agl from 25 TKPK Robert L. Bradshaw International Airport.
ScoreDescriptionStartProfileEnd
100 % Climb speed 175 kt170 kt min to max 182 ktTarget 174 kt, 1 kt fast 175 182 kt
100 % Steepest bank angle 8.4 °0.1 ° min to max 8.4 ° 2.5 8.4 °
100 % Average g force 0.93 g0.87 g min to max 0.97 g 0.95 0.92 g
100 % Landing gear up at 26 ft aglTarget by 400 ft agl
Info Heading variation 0.3 °0.3 ° min to max 0.4 ° 0.3 0.3 °
Info Average VSI 4,156 fpm4,011 fpm min to max 4,266 fpm 4,187 4,011 fpm
Info Average altitude 708 ft agl428 ft agl min to max 981 ft agl 428 981 ft agl
Info Average pitch angle 15.3 °12.6 ° min to max 17.3 ° 16.9 12.6 °

Events

Info Autopilot Wing Leveler Deactivated 573 ft agl · 180 kt
Info Autopilot Nav1 Lock Activated 573 ft agl · 180 kt
Enroute Climb 100.00Enroute climb started overhead Basseterre (Saint George Basseterre, Saint Kitts and Nevis). Climbing from 1,219 ft asl to 32,256 ft asl, an increase of 31,038 ft in 18 minutes and covering 111 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 232 kt169 kt min to max 312 kt 183 281 kt
100 % Steepest bank angle 29.2 °0.0 ° min to max 29.2 ° 7.6 9.8 °
100 % Average g force 1.01 g0.80 g min to max 1.16 g 0.90 1.00 g
Info Average VSI 2,082 fpm-206 fpm min to max 4,141 fpm 3,918 51 fpm
Info Average altitude 17,036 ft asl1,219 ft asl min to max 32,256 ft asl 1,219 32,256 ft asl
Info Average pitch angle 7.3 °-0.1 ° min to max 15.2 ° 12.0 1.0 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Fully Retracted 2,499 ft agl · 215 kt
Info Landing Lights Switched Off 13,041 ft agl · 252 kt
Info Taxi Lights Switched Off 13,367 ft agl · 246 kt
Info Navigation Lights Switched Off 13,950 ft agl · 248 kt
Info Autopilot Vertical Hold Deactivated 17,842 ft agl · 234 kt
Info Autopilot Nav1 Lock Deactivated 18,473 ft agl · 346 kt
Info Autopilot Altitude Hold Activated 31,348 ft agl · 479 kt
Info Autopilot Wing Leveler Activated 32,228 ft agl · 456 kt
Info Autopilot Wing Leveler Deactivated 32,250 ft agl · 459 kt
Info Autopilot Heading Hold Activated 32,250 ft agl · 459 kt
Enroute Level 100.00Enroute level cruise started 46 miles south of Saint Croix (Saint Croix Island, United States Virgin Islands) and lasted 44 minutes, covering 339 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,113 ft of 32,318 ft asl32,253 ft asl min to max 32,378 ft asl 32,257 32,369 ft asl
100 % Average speed 280 kt276 kt min to max 281 kt 281 276 kt
100 % Steepest bank angle 28.1 °0.0 ° min to max 28.1 ° 18.9 0.1 °
100 % Average g force 1.05 g0.99 g min to max 1.15 g 1.03 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 1.0 °0.8 ° min to max 1.3 ° 1.0 0.9 °

Events

Info Autopilot Nav1 Lock Activated 32,276 ft agl · 460 kt
Info Autopilot Heading Hold Deactivated 32,276 ft agl · 460 kt
Enroute Descent 99.99Enroute descent started 13 miles north of Georgetown (Parish of Charlotte, Saint Vincent and the Grenadines). Descent from 32,369 ft asl to 2,123 ft asl, a decrease of 30,246 ft in 23 minutes and covering 108 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 207 kt141 kt min to max 278 kt 277 144 kt
100 % Steepest bank angle 28.9 °0.0 ° min to max 28.9 ° 0.1 0.3 °
99.9 % Average g force 1.02 g0.60 g min to max 1.20 g 1.00 1.00 g
Info Average VSI -1,163 fpm-3,981 fpm min to max 115 fpm -8 -1 fpm
Info Average altitude 14,324 ft asl2,123 ft asl min to max 32,369 ft asl 32,369 2,123 ft asl
Info Average pitch angle 0.0 °-3.4 ° min to max 3.8 ° 0.9 3.1 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Altitude Hold Deactivated 32,341 ft agl · 403 kt
Info Autopilot Vertical Hold Activated 29,606 ft agl · 403 kt
Info Autopilot Vertical Hold Deactivated 28,106 ft agl · 381 kt
Info Autopilot Vertical Hold Activated 18,502 ft agl · 332 kt
Info Landing Lights Switched On 12,670 ft agl · 295 kt
Info Taxi Lights Switched On 12,503 ft agl · 294 kt
Info Navigation Lights Switched On 12,368 ft agl · 293 kt
Info Flaps Position 2 8,395 ft agl · 239 kt
Info Flaps Position 3 8,151 ft agl · 218 kt
Info Flaps Fully Retracted 8,130 ft agl · 217 kt
Info Flaps Position 1 8,121 ft agl · 217 kt
Info Flaps Position 2 8,110 ft agl · 216 kt
Info Flaps Position 3 7,496 ft agl · 210 kt
Info Landing Gear Down 7,478 ft agl · 210 kt
Info Flaps Position 4 6,693 ft agl · 172 kt
Info Autopilot Altitude Hold Activated 2,313 ft agl · 151 kt
Info Autopilot Vertical Hold Deactivated 2,313 ft agl · 151 kt
Enroute Level 2 100.00Enroute level cruise started 8 miles west of TGPY Maurice Bishop International Airport Saint George's (Saint George, Grenada) and lasted 2 minutes, covering 4 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±606 ft of 1,997 ft asl1,807 ft asl min to max 2,116 ft asl 2,116 1,807 ft asl
100 % Average speed 130 kt119 kt min to max 143 kt 142 120 kt
100 % Steepest bank angle 3.0 °0.0 ° min to max 3.0 ° 3.0 0.5 °
100 % Average g force 1.00 g0.95 g min to max 1.02 g 0.99 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 2.2 °0.4 ° min to max 3.9 ° 3.2 0.8 °

Events

Info Flaps Position 5 2,094 ft agl · 150 kt
Info Flaps Position 6 2,085 ft agl · 141 kt
Info Autopilot Altitude Hold Deactivated 2,071 ft agl · 124 kt
Info Autopilot Vertical Hold Activated 2,071 ft agl · 124 kt
Info Autopilot Master Switched Off 1,819 ft agl · 126 kt
Info Autopilot Nav1 Lock Deactivated 1,819 ft agl · 126 kt
Info Autopilot Altitude Hold Activated 1,819 ft agl · 126 kt
Info Autopilot Vertical Hold Deactivated 1,819 ft agl · 126 kt
Arrival Approach 92.86Final approach to runway 10 at TGPY Maurice Bishop International Airport. Descent from 1,839 ft agl to 36 ft agl in 112 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
50 % Sink ratefailed at one of the two gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates

Events

Fail GPWS Warning Activated 859 ft agl · 124 kt
Fail GPWS Warning Activated 793 ft agl · 130 kt
Info Autopilot Master Switched Off 1,819 ft agl · 126 kt
Info Autopilot Nav1 Lock Deactivated 1,819 ft agl · 126 kt
Info Autopilot Altitude Hold Activated 1,819 ft agl · 126 kt
Info Autopilot Vertical Hold Deactivated 1,819 ft agl · 126 kt
Info GPWS Warning Deactivated 809 ft agl · 129 kt
Info GPWS Warning Deactivated 768 ft agl · 132 kt
Arrival Landing 94.31Landing on runway 10 at TGPY Maurice Bishop International Airport, runway length 2,733 m. Good threshold height. Threshold speed was slightly below target at 116 kt.
ScoreDescriptionStartProfileEnd
97 % Threshold speed was slightly below target at 116 kt. Target 123 kt
100 % Good threshold height.Target 50 ft agl
80 % The flare wandered off the target profile. The aircraft was flown onto the runway - pitch changed 2.8° and the descent was barely arrested. Touchdown was 288 m past the threshold. Start the flare with progressive back pressure rather than one pull, and keep it coming.
100 % Runway alignment max 6.76 m left6.76 m left to 6.61 m left 6.75 6.61 m
100 % Steepest bank angle 0.7 °0.0 ° min to max 0.7 ° 0.7 0.4 °
100 % Peak g force 1.06 g0.99 g min to max 1.06 g 1.04 1.06 g
Info Average speed 113 kt109 kt min to max 116 kt 116 109 kt
Info Average VSI -494 fpm-616 fpm min to max -374 fpm -616 -374 fpm
Info Average altitude 24 ft agl6 ft agl min to max 44 ft agl 44 6 ft agl
Info Average pitch angle 3.4 °2.2 ° min to max 5.5 ° 2.3 5.5 °
07515022530001223354658Runway Distance mLanding Height ft075150225300-24-20-16-12-8-404812162024Runway Distance mRunway Width m
Arrival Touchdown 94.36Touchdown distance was good at 287 m. Touchdown speed at 109 kt was good. Touchdown rate was firm at -370 fpm. Runway touchdown position was slightly misaligned by 6.6 m from centreline. Local weather - Temperature 33 °C. Wind 11 kt at 150 °. Crosswind: 9 kt Headwind: 6 kt.
ScoreDescriptionStartProfileEnd
73 % Touchdown rate was -370 fpm.
100 % Touchdown distance was 288 mTarget 457 m
100 % Speed at touchdown 109 ktTarget below 120 kt
99.5 % Runway alignment max 6.61 m left6.31 m left 6.61 5.86 m
100 % Steepest bank angle 2.5 °0.2 ° min to max 2.5 ° 0.4 2.5 °
95 % Peak g force 1.40 g1.06 g min to max 1.40 g 1.06 1.15 g
100 % Landing Bounce
Info Average speed 109 kt108 kt min to max 109 kt 109 108 kt
Info Average pitch angle 5.4 °5.2 ° min to max 5.5 ° 5.5 5.2 °
Arrival Rollout 98.63Total landing distance 747 m, 27 % of runway. Runway rollout alignment was slightly misaligned by 9.1 m from centreline.
ScoreDescriptionStartProfileEnd
100 % Landing distance 747 m27 % of runway.
97 % Runway alignment max 9.14 m right0.00 m left to 9.14 m right -8.46 -8.52 m
100 % Average g force 1.00 g0.96 g min to max 1.12 g 1.12 0.99 g
Info Average speed 99 kt62 kt min to max 105 kt 105 62 kt
Info Average pitch angle 3.3 °0.2 ° min to max 5.2 ° 5.2 0.2 °
Info Average bank angle 3.8 °0.7 ° min to max 5.1 ° 2.8 1.1 °
Runway Exit Exiting runway, average speed 32 kt
ScoreDescriptionStartProfileEnd
Info Average speed 30 kt15 kt min to max 53 kt 53 18 kt
Info Average pitch angle 0.4 °-0.1 ° min to max 0.6 ° 0.2 0.2 °
Info Average bank angle 0.5 °0.0 ° min to max 1.4 ° 1.4 0.1 °
Info Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g

Events

Info Flaps Position 4 6 ft agl · 41 kt
Info Flaps Fully Retracted 6 ft agl · 41 kt
Arrival Taxi 95.05Taxiing to the parking from the runway took 3 minutes and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 11 kt0 kt min to max 20 kt 18 0 kt
100 % Average speed turning corners 0 ktmax 0 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle 0.9 °0.1 ° min to max 1.4 ° 0.2 1.4 °
Info Average bank angle 0.3 °0.0 ° min to max 0.9 ° 0.2 0.4 °

Events

Fail Landing Lights
Info Parking Brake On 6 ft agl
Info Autopilot Altitude Hold Deactivated 6 ft agl
Info Autopilot Yaw Damper Deactivated 6 ft agl

Takeoff from TKPK 25

Taxi out

Lights0.00
Offlanding and strobes

The roll

Takeoff roll100.00
972m44 %
Runway alignment100.00
2.02m L
Rotation speed100.00
113kttarget 114, 1 early

The nose wandered in the climb

From 35 ft to the end of the climb the nose moved between 9.9° and 17.8°, and the speed between 154 kt and 182 kt.

Once clear of the runway the nose moved through a wide range, and the speed moved with it. Set the climb attitude, hold it and trim, and give the speed a few seconds to settle before correcting it with a degree or two of pitch. Chasing the airspeed with large pitch changes makes it wander more.

Liftoff and climb

Liftoff
141ktat 7.3°
Rotation
0.9°/sover 5.6 s, gaining 28 kt
35 ft
155ktat 9.9°, 4.4 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
0.5°steepest
Gear up100.00
26ftfull marks to 400 ft
Climb 3 speed100.00
175kttarget 174

Plan view the roll down the 2,199 m runway.

Rolled from 71 m in, drifted left of the centreline, 2.1 m at the widest, and lifted off 1.5 m left. Airborne 44 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length.

5001,0001,5002,000THRESHOLDLEFT ↑RIGHT ↓75 %widest 2.07 m LROLL 71 M INAirborne 977 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 977 m of 2,199 m · 44 %
Behind the start of the roll, 71 mTakeoff roll, 906 m Left ahead, 1,222 m

Side view from the start of the roll to the end of Climb 3 at 982 ft.

Reached 35 ft with 900 m of runway left; gear up at 26 ft, inside the 400 ft that gets full marks; then climbing at 2,780 fpm on average to 982 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3175 kt avgtarget 174THRESHOLDRUNWAY END6080100KNOTS ALONG THE ROLLnose up on the runway · 350 m · 5.6 sRotate 113 kttarget 114Liftoff 141 ktGear up 26 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 174210 kt14070020°10°0°nose up on the runway · 350 m · 5.6 sROTATELIFTOFFtarget 114held 12.4°7.3° off · 0.9°/s10° at 35 ftAIRSPEEDPITCH0204060 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2 to 3° a second, the rates airliners are rotated at: a trace steeper than both is a faster rotation, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 14.5°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 14.5°ROTATELIFTOFF35 FT2°/s3°/s7.3° off · 0.9°/s10° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5+6+7+8+9+10+11 sseconds from rotation
PitchRotation began2 to 3°/s from rotationTail strikeNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 85.716 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate1,450 fpm830 fpm
On glideslope3.8°3.6°
On centreline0.1° off0.0° off
On speed−0.4 kt+4.3 kt
Wings level2° bank1° bank

At the 1,000 ft gate: sink rate more than 600 fpm beyond what the glideslope needed.

When the approach was stable

Not every check held at once from 0.2 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to TGPY 10

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

High from 4 nm to 3.3 nm (up to 520 ft over), then back on it to the threshold.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,8478154342211,000 ft gate6 of 7sink rate1,347 ft · 124 kt500 ft gate7 of 7658 ft · 128 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 16× larger than distances along the final.

Inside the 1° band all the way from 4 nm, never more than 24 m off the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR61 m L061 m RLEFT ↑RIGHT ↓1° BAND8 m L19 m L8 m L13 m L12 m L2 m L
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 31 kt fast at the 1,000 ft gate, closing to 19 at 500 ft and 10 at the threshold.

Inside the speed band all the way, between −8 kt and +6 kt on the approach speed of 124 kt.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

120140160180 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 124−4 kt−4 kt+1 kt−1 kt−8 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on TGPY 10

Over the threshold

Threshold height100.00
43ft
Threshold speed96.81
116kttarget 123, 7 slow
Centreline offset100.00
6.76m L
Bank100.00
0.7°steepest
Flare80.42

The flare wandered off the target profile

The aircraft was flown onto the runway - pitch changed 2.8° and the descent was barely arrested. Touchdown was 288 m past the threshold. Start the flare with progressive back pressure rather than one pull, and keep it coming.

Touchdown

Past threshold100.00
288m
Centreline99.52
6.61m L
Speed100.00
109kttarget 120 or less
Touchdown rate73.38
-370fpm
Impact95.24
1.40G
BouncesOk
None
Bank100.00
2.5°as the wheels touched

Rollout

Rollout distance100.00
424m26 % used
Rollout alignment96.95
9.14m R

Taxi in

Lights50.50
Onlanding lights, 99% of the taxi
Taxi speed100.00
20kt peak

Side view — the last 1,524 m of the approach.

Crossed the threshold at 43 ft, close to the 50 ft target; began the flare at 23 ft. Touched down 288 m in, close to the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,524 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

43 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 23 ft · −556 fpm · 2.7° · 114 ktdescent slowed at 0 ft · −369 fpm · 5.5°−369 fpm · 5.5° nose up · 109 kt Ideal — 50 ft, down at 305 m This flight — 43 ft, down at 288 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 560 fpm at the flare to 370 fpm at touchdown. The nose came up 2.7° on the way down. Into the flare at 114 kt, 9 kt under the 123 kt approach speed, and 109 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−369 fpm at touchdown5.5° at touchdown, +2.7° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,524 m of the 2,733 m runway, to the same scale as the side view.

Touched down 5.9 m left of the centreline, and stayed about there down the rollout, 8.6 m right at the widest. 9 kt across from the right, which takes about 5° of crab to hold the centreline at 109 kt. Touched down with 5° of it still on, 2.5° of bank.

Wind 150° at 11 kt · 6 kt head · 9 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ CROSS 9 kn FULL SCORE TO 503 M 288 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

The 288 m touchdown sits inside the full-score zone. The 369 fpm arrival was firm.

Runway used 712 m of 2,733 m · 26 %
In the air over the runway, 288 mRollout, 424 m Left over, 2,021 m

The stop — touchdown to taxi speed.

From 107 kt at touchdown to taxi speed (30 kt) in 36 s, an average deceleration of 0.11 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 490 m30 kt · 963 mtouchdown1,001 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
