WSSS
Singapore, Singapore
Runway 02C
Elevation13 ft asl
Weight223,556 kg
Fuel21,828 kg
Wind180° · 5 kn · 2 kn cross

Flight Score

99.27 %
VTBS
Bangkok, Thailand
Runway 01R
Elevation3 ft asl
Weight210,749 kg
Fuel8,694 kg
Wind0° · 1 kn
15 Feb 2025 1:55 780 nm Boeing 777-300 13,134 kg
Departure Score
100.00 %
Enroute Score
100.00 %
Arrival Score
97.80 %

What went well

Touched down at -200 fpm — a soft arrival
Straight touchdown — 0.61 m off the centreline, no bounce
Flare on profile — 100 %

What held you back

Arrival Touchdown — Touchdown distance was 840 m at 58 %, −0.42 points
Arrival Landing — Threshold height at 64 ft agl was above target at 81 %, −0.31 points

Next time

Arrival

Fly a slightly steeper approach path to cross the threshold at 50 ft agl instead of 64 ft agl.

What happened: The aircraft crossed the threshold at 64 ft agl against a 50 ft agl target, above the normal profile. This fault pattern is often followed by a long touchdown beyond the target point, and here the aircraft touched down at 840 m against a 457 m target.

Watch for: Radio altimeter against the 50 ft threshold crossing target on short final.

See Arrival LandingArrival Touchdown

Ground effect becomes significant below about one wingspan of height. A Cessna 172, with a 36 ft span, enters ground effect at flare height - the float it feels in the hold-off is ground effect arriving on cue. An A320, with a span around 117 ft, has been in ground effect since before the threshold and there is no sudden cushion to feel, only a gradual reduction in induced drag that lengthens any float you allow.

Read more in Flare Timing

Start to finish · 15 stages, 13 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 9 minutes and covered 3 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 22 kt0 kt min to max 26 kt 0 20 kt
100 % Average speed turning corners 9 ktmax 12 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle -0.5 °-1.1 ° min to max -0.4 ° -0.5 -0.4 °
Info Average bank angle 0.1 °0.0 ° min to max 0.4 ° 0.0 0.1 °

Events

Info Battery Master On 13 ft agl
Info Engine 1 Started 13 ft agl
Info Engine 2 Started 13 ft agl
Info Beacon Lights Switched On 13 ft agl
Info Navigation Lights Switched On 13 ft agl
Info Landing Gear Down 13 ft agl
Info Parking Brake On 13 ft agl
Info Flaps Position 1 13 ft agl
Info Flaps Position 2 13 ft agl
Info Taxi Lights Switched On 13 ft agl
Info Parking Brake Off 13 ft agl
Info Landing Lights Switched On 13 ft agl · 22 kt
Info Strobe Lights Switched On 13 ft agl · 22 kt
Departure Runway Entry Entering runway 02C at WSSS Singapore Changi Airport, Average speed was 23 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 20 kt20 kt min to max 20 kt 20 20 kt
Info Average pitch angle -0.4 °-0.4 ° min to max -0.3 ° -0.4 -0.4 °
Info Average bank angle 0.1 °0.1 ° min to max 0.2 ° 0.2 0.1 °
Info Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Departure Roll 100.00Departure roll runway 02C at WSSS Singapore Changi Airport. Takeoff distance 1,121 m 28 % of runway. Rotation speed was 158 kt. Local weather - Temperature 31 °C. Wind 5 kt at 180 °. Crosswind: 2 kt Tailwind: 4 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 1,121 m28 % of runway
100 % Rotation speed was 158 ktTarget 155 kt
100 % Runway alignment max 2.66 m left2.66 m left to 0.45 m right -0.45 2.29 m
100 % Average g force 1.00 g0.97 g min to max 1.03 g 1.00 0.99 g
100 % Takeoff Bounce
Info Average pitch angle -0.0 °-0.4 ° min to max 6.1 ° -0.4 6.1 °
Info Average bank angle 0.1 °0.0 ° min to max 0.4 ° 0.0 0.4 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 02C WSSS Singapore Changi Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.1 °-0.1 ° min to max -0.0 ° -0.1 -0.0 °
100 % Average speed 184 kt171 kt min to max 196 kt 171 196 kt
100 % Steepest bank angle 0.4 °0.3 ° min to max 0.4 ° 0.4 0.3 °
100 % Average g force 1.13 g1.00 g min to max 1.15 g 1.00 1.12 g
Info Average VSI 543 fpm84 fpm min to max 1,159 fpm 84 1,159 fpm
Info Average altitude 18 ft agl0 ft agl min to max 50 ft agl 0 50 ft agl
Info Average pitch angle 8.0 °6.3 ° min to max 8.7 ° 6.3 8.6 °

Events

Info Landing Gear Up 53 ft agl · 199 kt
Departure Climb 2 100.00Departure climb to 400 ft agl from 02C WSSS Singapore Changi Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.0 °-0.0 ° min to max 0.1 ° -0.0 0.1 °
100 % Average speed 205 kt197 kt min to max 223 kt 197 223 kt
100 % Steepest bank angle 1.8 °0.3 ° min to max 1.8 ° 0.3 1.8 °
100 % Average g force 1.05 g0.98 g min to max 1.14 g 1.11 1.07 g
Info Average VSI 1,583 fpm1,188 fpm min to max 2,468 fpm 1,188 2,468 fpm
Info Average altitude 111 ft agl52 ft agl min to max 396 ft agl 52 396 ft agl
Info Average pitch angle 8.5 °8.0 ° min to max 9.9 ° 8.6 9.9 °
Departure Climb 3 100.00Departure climb to 1,000 ft agl from 02C WSSS Singapore Changi Airport.
ScoreDescriptionStartProfileEnd
100 % Climb speed 221 kt220 kt min to max 223 ktTarget 204 kt, 17 kt fast 223 222 kt
100 % Steepest bank angle 2.5 °0.1 ° min to max 2.5 ° 1.8 2.3 °
100 % Average g force 0.99 g0.91 g min to max 1.21 g 1.21 0.93 g
100 % Landing gear up at 38 ft aglTarget by 400 ft agl
Info Heading variation 0.4 °0.2 ° min to max 0.5 ° 0.2 0.5 °
Info Average VSI 3,103 fpm2,680 fpm min to max 3,272 fpm 2,680 2,903 fpm
Info Average altitude 711 ft agl443 ft agl min to max 969 ft agl 443 969 ft agl
Info Average pitch angle 11.1 °10.5 ° min to max 11.7 ° 11.5 10.5 °
Enroute Climb 100.00Enroute climb started overhead WSSS Singapore Changi Airport Singapore (South West, Singapore). Climbing from 1,055 ft asl to 37,973 ft asl, an increase of 36,918 ft in 17 minutes and covering 125 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 287 kt224 kt min to max 321 kt 224 266 kt
100 % Steepest bank angle 30.6 °0.0 ° min to max 30.6 ° 2.2 0.9 °
100 % Average g force 1.02 g0.89 g min to max 1.18 g 0.92 1.01 g
Info Average VSI 2,439 fpm-338 fpm min to max 4,178 fpm 2,800 -54 fpm
Info Average altitude 18,677 ft asl1,055 ft asl min to max 37,975 ft asl 1,055 37,973 ft asl
Info Average pitch angle 6.4 °2.6 ° min to max 11.7 ° 10.5 3.0 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Fully Retracted 1,433 ft agl · 245 kt
Info Landing Lights Switched Off 10,720 ft agl · 309 kt
Info Taxi Lights Switched Off 10,754 ft agl · 311 kt
Enroute Level 100.00Enroute level cruise started 9 miles south of Pekan (Pahang, Malaysia) and lasted 63 minutes, covering 519 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,399 ft of 37,973 ft asl37,955 ft asl min to max 37,985 ft asl 37,971 37,972 ft asl
100 % Average speed 266 kt262 kt min to max 268 kt 266 266 kt
100 % Steepest bank angle 15.3 °0.0 ° min to max 15.3 ° 0.0 0.0 °
100 % Average g force 1.00 g0.97 g min to max 1.04 g 1.00 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 2.8 °2.6 ° min to max 3.1 ° 2.8 2.7 °
Enroute Descent 100.00Enroute descent started 54 miles south west of VTKC Ko Chang Tai Airport Ko Chang Tai (Changwat Trat, Thailand). Descent from 37,973 ft asl to 1,287 ft asl, a decrease of 36,685 ft in 21 minutes and covering 124 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 233 kt142 kt min to max 313 kt 266 142 kt
100 % Steepest bank angle 27.0 °0.0 ° min to max 27.0 ° 0.0 0.1 °
100 % Average g force 1.00 g0.75 g min to max 1.15 g 0.99 1.01 g
Info Average VSI -1,404 fpm-3,933 fpm min to max 4 fpm 4 -862 fpm
Info Average altitude 11,448 ft asl1,287 ft asl min to max 37,973 ft asl 37,973 1,287 ft asl
Info Average pitch angle 1.3 °-2.8 ° min to max 5.6 ° 2.7 2.0 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Landing Lights Switched On 10,268 ft agl · 312 kt
Info Taxi Lights Switched On 10,222 ft agl · 309 kt
Info Flaps Position 1 4,501 ft agl · 246 kt
Info Flaps Position 2 3,350 ft agl · 212 kt
Info Landing Gear Down 2,744 ft agl · 198 kt
Info Flaps Position 3 2,175 ft agl · 175 kt
Info Flaps Position 4 2,051 ft agl · 169 kt
Info Flaps Position 5 1,678 ft agl · 152 kt
Info Flaps Position 6 1,613 ft agl · 151 kt
Arrival Approach 100.00Final approach to runway 01R at VTBS Suvarnabhumi Airport. Descent from 1,327 ft agl to 80 ft agl in 99 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates

Events

Fail GPWS Warning Activated 564 ft agl · 144 kt
Fail GPWS Warning Activated 517 ft agl · 144 kt
Info GPWS Warning Deactivated 546 ft agl · 144 kt
Info GPWS Warning Deactivated 282 ft agl · 145 kt
Arrival Landing 95.28Landing on runway 01R at VTBS Suvarnabhumi Airport, runway length 4,134 m. Threshold height at 64 ft agl was above target. Threshold speed was good at 142 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 142 kt. Target 139 kt
81 % Threshold height at 64 ft agl was above target.Target 50 ft agl
100 % The flare tracked the target profile exactly. The aircraft floated down the runway before touching. Touchdown was 840 m past the threshold. Threshold speed was not the cause here - hold the aim point on the approach and let the aircraft settle rather than holding it off, and the touchdown comes back to the numbers.
100 % Runway alignment max 0.57 m right0.25 m left to 0.57 m right -0.33 -0.57 m
100 % Steepest bank angle 2.0 °0.0 ° min to max 2.0 ° 0.2 0.2 °
100 % Peak g force 1.12 g0.93 g min to max 1.12 g 0.97 1.03 g
Info Average speed 138 kt131 kt min to max 142 kt 142 131 kt
Info Average VSI -359 fpm-655 fpm min to max -142 fpm -532 -217 fpm
Info Average altitude 23 ft agl0 ft agl min to max 64 ft agl 64 0 ft agl
Info Average pitch angle 3.6 °1.5 ° min to max 4.6 ° 2.1 4.6 °
07515022530037545052560067575082590097501325385063Runway Distance mLanding Height ft075150225300375450525600675750825900975-30-24-18-12-60612182430Runway Distance mRunway Width m
Arrival Touchdown 93.72Touchdown point was 429 m beyond the touchdown zone. Touchdown speed at 131 kt was good. Touchdown rate was good at -200 fpm. Runway touchdown alignment was perfect. Local weather - Temperature 32 °C. Wind 1 kt at 360 °. Crosswind: 0 kt Headwind: 1 kt.
ScoreDescriptionStartProfileEnd
100 % Touchdown rate was -200 fpm.
58 % Touchdown distance was 840 mTarget 457 m
100 % Speed at touchdown 131 ktTarget below 136 kt
100 % Runway alignment max 0.61 m right0.59 m right -0.57 -0.61 m
100 % Steepest bank angle 0.4 °0.1 ° min to max 0.4 ° 0.2 0.2 °
100 % Peak g force 1.18 g1.01 g min to max 1.18 g 1.03 1.08 g
100 % Landing Bounce
Info Average speed 130 kt130 kt min to max 131 kt 131 130 kt
Info Average pitch angle 4.5 °4.3 ° min to max 4.7 ° 4.6 4.3 °
Arrival Rollout 100.00Total landing distance 1,976 m, 48 % of runway. Runway rollout alignment was perfect.
ScoreDescriptionStartProfileEnd
100 % Landing distance 1,976 m48 % of runway.
100 % Runway alignment max 1.41 m right0.00 m left to 1.41 m right -1.01 -0.72 m
100 % Average g force 1.01 g0.99 g min to max 1.07 g 1.07 1.00 g
Info Average speed 121 kt69 kt min to max 133 kt 133 69 kt
Info Average pitch angle 1.3 °-0.7 ° min to max 4.2 ° 4.2 -0.6 °
Info Average bank angle 0.1 °0.0 ° min to max 0.9 ° 0.1 0.0 °
Runway Exit Exiting runway, average speed 30 kt
ScoreDescriptionStartProfileEnd
Info Average speed 30 kt19 kt min to max 66 kt 66 19 kt
Info Average pitch angle -0.5 °-0.9 ° min to max -0.4 ° -0.7 -0.4 °
Info Average bank angle 0.2 °0.0 ° min to max 0.3 ° 0.1 0.2 °
Info Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g

Events

Info Flaps Position 5 13 ft agl · 29 kt
Info Flaps Position 4 13 ft agl · 20 kt
Arrival Taxi 100.00Taxiing to the parking from the runway took 4 minutes and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 16 kt0 kt min to max 27 kt 19 4 kt
100 % Average speed turning corners 14 ktmax 17 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.00 g 1.00 1.00 g
Info Average pitch angle -0.5 °-0.7 ° min to max -0.4 ° -0.4 -0.5 °
Info Average bank angle 0.1 °0.0 ° min to max 0.3 ° 0.1 0.0 °

Events

Info Flaps Position 3 13 ft agl · 20 kt
Info Landing Lights Switched Off 13 ft agl · 20 kt
Info Flaps Position 2 13 ft agl · 20 kt
Info Strobe Lights Switched Off 13 ft agl · 20 kt
Info Flaps Position 1 13 ft agl · 20 kt
Info Flaps Fully Retracted 13 ft agl · 2 kt

Takeoff from WSSS 02C

Taxi out

LightsOk
All on
Taxi speed100.00
26kt peak9 kt in turns

The roll

Takeoff roll100.00
1,121m28 %
Runway alignment100.00
2.66m L
Rotation speed100.00
158kttarget 155, 3 late

On speed, but the nose came up quickly

Rotation started at 158 kt, 3 kt after the 155 kt rotate speed. The nose then rose at 3.7° a second, faster than the 1.9 to 2.9° a second other Boeing 777-300 pilots fly.

The rotation started on speed but the nose came up quickly. A fast pull raises the nose faster than the aircraft can lift off, which brings the tail closer to the runway. Pull smoothly at the normal rate for this aircraft and let it fly off at its own attitude.

Liftoff and climb

Liftoff
170ktat 6.3°
Rotation
3.7°/sover 1.7 s, gaining 12 kt
35 ft
192ktat 8.7°, 2.9 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
0.4°steepest
Gear up100.00
38ftfull marks to 400 ft
Climb 3 speed100.00
221kttarget 204

Plan view the roll down the 4,010 m runway.

Rolled from 139 m in, drifted left of the centreline, 2.7 m at the widest, and lifted off 2.3 m left. Airborne 28 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

1,0002,0003,0004,000THRESHOLDLEFT ↑RIGHT ↓CROSS1 kn75 %widest 2.66 m LROLL 139 M INAirborne 1,129 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,129 m of 4,010 m · 28 %
Behind the start of the roll, 139 mTakeoff roll, 990 m Left ahead, 2,882 m

Side view from the start of the roll to the end of Climb 3 at 969 ft.

Reached 35 ft with 2,603 m of runway left; gear up at 38 ft, inside the 400 ft that gets full marks; then climbing at 2,400 fpm on average to 969 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3221 kt avgtarget 204THRESHOLDRUNWAY END6080100120140KNOTS ALONG THE ROLLnose up on the runway · 147 m · 1.7 sRotate 158 kttarget 155Liftoff 170 ktGear up 38 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 204240 kt16080020°10°0°nose up on the runway · 147 m · 1.7 sROTATELIFTOFFtarget 155held 9.1°6.3° off · 3.7°/s9° at 35 ftAIRSPEEDPITCH02040 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 1.9 to 2.9° a second, the middle half of rotation rates flown by other Boeing 777-300 pilots over the last 180 days (149 takeoffs); the grey pair are 2 to 3° a second, the rates airliners are rotated at. A trace steeper than both green lines is a faster rotation than most, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 9.5°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 9.5°ROTATELIFTOFF35 FT6.3° off · 3.7°/s3°/s2.9°/s2°/s1.9°/s9° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5 sseconds from rotation
PitchRotation began1.9 to 2.9°/s, other Boeing 777-300 pilots2 to 3°/s from rotation, airlinersTail strikeNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate820 fpm860 fpm
On glideslope3.0°2.7°
On centreline0.0° off0.0° off
On speed+2.8 kt−0.2 kt
Wings level1° bank2° bank

When the approach was stable

Every check met from 4 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to VTBS 01R

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 60 ft below the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,3116473291961,000 ft gate7 of 71,044 ft · 142 kt500 ft gate7 of 7493 ft · 139 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 20× larger than distances along the final.

Inside the 1° band all the way from 4 nm, never more than 18 m off the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR49 m L049 m RLEFT ↑RIGHT ↓1° BAND6 m L12 m R6 m R1 m R4 m L0 m R
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 35 kt fast at the 1,000 ft gate, closing to 21 at 500 ft and 10 at the threshold.

Inside the speed band all the way, between −1 kt and +3 kt on the approach speed of 139 kt.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

140160180200 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 139+3 kt+0 kt+2 kt+3 kt+3 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on VTBS 01R

Over the threshold

Threshold height81.11
63ft
Threshold speed100.00
141kttarget 139, 2 fast
Centreline offset100.00
0.57m R
Bank100.00
2.0°steepest
Flare100.00

The flare tracked the target profile exactly

The aircraft floated down the runway before touching. Touchdown was 840 m past the threshold. Threshold speed was not the cause here - hold the aim point on the approach and let the aircraft settle rather than holding it off, and the touchdown comes back to the numbers.

Touchdown

Past threshold58.15
840m
Centreline100.00
0.61m R
Speed100.00
130kttarget 136 or less
Touchdown rate100.00
-200fpm
Impact100.00
1.18G
BouncesOk
None
Bank100.00
0.4°as the wheels touched

Rollout

Rollout distance100.00
1,089m47 % used
Rollout alignment100.00
1.41m R

Taxi in

LightsOk
All set
Taxi speed100.00
27kt peak14 kt in turns

Side view — the last 2,051 m of the approach.

Crossed the threshold at 63 ft, 13 ft above the 50 ft target; began the flare at 36 ft. Touched down 840 m in, 535 m past the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 2,051 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

63 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 36 ft · −662 fpm · 3° · 142 ktdescent slowed at 15 ft · −133 fpm · 4.2°−199 fpm · 4.6° nose up · 131 kt Ideal — 50 ft, down at 305 m This flight — 63 ft, down at 840 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 660 fpm at the flare to 200 fpm at touchdown. The nose came up 1.6° on the way down. Into the flare at 142 kt, 3 kt over the 139 kt approach speed, and 131 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−199 fpm at touchdown4.6° at touchdown, +1.6° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 2,051 m of the 4,134 m runway, to the same scale as the side view.

Touched down on the centreline, and stayed within 1.3 m of it down the rollout. No crosswind: nothing to correct for. Touched down straight, wings level.

Wind 000° at 1 kt · 1 kt head · 0 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,5002,000 THRESHOLD LEFT ↑ RIGHT ↓ FULL SCORE TO 503 M 840 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

Touched down 840 m past the threshold — beyond the full-score zone. The arrival was smooth.

Runway used 1,929 m of 4,134 m · 47 %
In the air over the runway, 840 mRollout, 1,089 m Left over, 2,205 m

The stop — touchdown to taxi speed.

From 134 kt at touchdown to taxi speed (30 kt) in 34 s, an average deceleration of 0.16 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 1,206 m30 kt · 1,442 mtouchdown1,500 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Flight narrative

The flight began with a taxiing period from the parking to the runway, which took 9 minutes and covered a distance of 3 nautical miles. The aircraft, a Boeing 777-300, then departed from runway 02C at Singapore Changi Airport (WSSS). The takeoff distance was 963 meters, which accounted for 24% of the runway. The liftoff speed was 170 knots.

As the aircraft took to the skies, it encountered local weather conditions with a temperature of 31 degrees Celsius and winds blowing at 5 knots from a direction of 180 degrees. The crosswind was 2 knots, while the tailwind was 4 knots. The aircraft then began its enroute climb, which started overhead the airport and took it up to an altitude of 37,975 feet above sea level. This climb phase covered a distance of 119 nautical miles and took 17 minutes, with the aircraft increasing its altitude by 36,920 feet.

Following the climb, the aircraft entered a level cruise phase, which lasted for 65 minutes and covered a distance of 523 nautical miles. This phase took place 12 miles south of Pekan, Malaysia. The aircraft then began its enroute descent, which started 54 miles south of Rayong, Thailand. During this phase, the aircraft descended from an altitude of 37,134 feet to 1,287 feet above sea level, a decrease of 35,847 feet, in 20 minutes and covering a distance of 115 nautical miles.

As the aircraft approached its destination, it began its final approach to runway 01R at Suvarnabhumi Airport (VTBS). The approach was made from the south, with the aircraft heading at 14.0 degrees and at an altitude of 1,270 feet above ground level. The aircraft landed on the runway, which had a length of 4,019 meters. The threshold height was above the target, but the threshold speed was good at 142 knots. The touchdown point was 424 meters beyond the touchdown zone, with a touchdown speed of 131 knots, which was good. However, the touchdown rate was fair at -217 feet per minute.

The local weather conditions at the time of landing were a temperature of 32 degrees Celsius and winds blowing at 1 knot from a direction of 360 degrees. The crosswind was 0 knots, while the headwind was 1 knot. The total landing distance was 1,970 meters, which accounted for 49% of the runway. The runway rollout alignment was perfect. After landing, the aircraft took 4 minutes to taxi to the parking, covering a distance of less than 1 nautical mile. The total flight distance was 768 nautical miles, and the flight used 13,134 kilograms of fuel.

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
