KIAD
Dulles, United States
Runway 19C
Elevation285 ft asl
Weight59,784 kg
Fuel10,850 kg
Wind150° · 6 kn · 3 kn cross

Flight Score

99.23 %
KLRD
Laredo, United States
Runway 18R
Elevation502 ft asl
Weight51,861 kg
Fuel2,845 kg
Wind130° · 12 kn · 9 kn cross
27 Apr 2024 3:00 1309 nm Boeing 737-800 8,005 kg
Departure Score
98.12 %
Enroute Score
100.00 %
Arrival Score
99.57 %

What went well

Touched down at -262 fpm — a soft arrival
Threshold crossed at 47 ft and 129 kt — both inside band
Straight touchdown — 0.37 m off the centreline, no bounce

What held you back

Departure Climb 3 — bank angle up to 32.1 ° at 65 %, g force 0.25 to 1.98 g at 81 %, −0.60 points
Arrival Touchdown — Touchdown distance was 556 m at 89 %, −0.14 points

Next time

Departure

Use smaller, smoother aileron inputs to hold the climb bank angle near wings-level.

What happened: During Climb 3 the bank angle averaged 32°, well beyond a steady wings-level climb.

Watch for: Attitude indicator - bank angle, keeping it close to wings-level through the climb.

See Departure Climb 3

Arrival

Adjust your approach path so you touch down at the 457 m aim point instead of beyond it.

What happened: Touchdown point came 99 m past the target, landing at 556 m against the 457 m aim point. Landings that touch down this far beyond the aim point typically leave less runway available for stopping.

Watch for: Touchdown distance marker: 457 m from the threshold.

See Arrival Touchdown

Below a thousand feet the aeroplane is slow, heavy and close to the ground. A steep turn loses lift, raises the stall speed and flattens the climb just when the gradient matters most. A normal turn on course is a rate one — fifteen degrees or so, twenty-five at the outside, this penalty is to acknowledge when a turn has stopped being a turn and become a manoeuvre.

Read more in Improve Your Take-Offs

Start to finish · 16 stages, 14 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 3 minutes and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 17 kt0 kt min to max 24 kt 0 24 kt
100 % Average speed turning corners 0 ktmax 0 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle -1.0 °-1.3 ° min to max -0.7 ° -0.9 -0.7 °
Info Average bank angle 0.2 °0.0 ° min to max 0.3 ° 0.1 0.0 °

Events

Info Engine 1 Started 8 ft agl · 3 kt
Info Parking Brake Off 8 ft agl · 3 kt
Info Landing Lights Switched On 8 ft agl · 24 kt
Info Strobe Lights Switched On 8 ft agl · 24 kt
Info Taxi Lights Switched Off 8 ft agl · 25 kt
Departure Runway Entry Entering runway 19C at KIAD Washington Dulles International Airport, Average speed was 31 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 23 kt23 kt min to max 24 kt 24 23 kt
Info Average pitch angle -0.8 °-0.9 ° min to max -0.7 ° -0.8 -0.9 °
Info Average bank angle 0.1 °0.0 ° min to max 0.2 ° 0.2 0.1 °
Info Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Departure Roll 100.00Departure roll runway 19C at KIAD Washington Dulles International Airport. Takeoff distance 2,221 m 63 % of runway. Rotation speed was 142 kt. Local weather - Temperature 15 °C. Wind 6 kt at 150 °. Crosswind: 3 kt Headwind: 5 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 2,221 m63 % of runway
100 % Rotation speed was 142 ktTarget 134 kt
100 % Runway alignment max 2.96 m left2.96 m left to 0.00 m left 1.59 2.96 m
100 % Average g force 1.01 g0.97 g min to max 1.12 g 1.00 1.12 g
100 % Takeoff Bounce
Info Average pitch angle -0.3 °-1.0 ° min to max 8.6 ° -0.9 8.6 °
Info Average bank angle 0.2 °0.0 ° min to max 0.5 ° 0.1 0.5 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 19C KIAD Washington Dulles International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.1 °-0.1 ° min to max -0.1 ° -0.1 -0.1 °
100 % Average speed 155 kt151 kt min to max 160 kt 151 160 kt
100 % Steepest bank angle 0.6 °0.4 ° min to max 0.6 ° 0.5 0.4 °
100 % Average g force 1.29 g1.16 g min to max 1.38 g 1.17 1.16 g
Info Average VSI 752 fpm244 fpm min to max 1,348 fpm 244 1,348 fpm
Info Average altitude 17 ft agl0 ft agl min to max 47 ft agl 0 47 ft agl
Info Average pitch angle 11.7 °9.3 ° min to max 12.6 ° 9.3 12.6 °

Events

Info Landing Gear Up 26 ft agl · 154 kt
Info Flaps Fully Retracted 26 ft agl · 154 kt
Info Flaps Position 5 51 ft agl · 159 kt
Departure Climb 2 99.60Departure climb to 400 ft agl from 19C KIAD Washington Dulles International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.1 °-0.2 ° min to max -0.1 ° -0.1 -0.1 °
100 % Average speed 164 kt160 kt min to max 172 kt 160 172 kt
98 % Steepest bank angle 5.6 °0.3 ° min to max 5.6 ° 0.4 3.8 °
100 % Average g force 1.14 g0.91 g min to max 1.20 g 1.16 0.91 g
Info Average VSI 1,951 fpm1,375 fpm min to max 3,241 fpm 1,375 3,232 fpm
Info Average altitude 110 ft agl48 ft agl min to max 379 ft agl 48 379 ft agl
Info Average pitch angle 14.0 °12.6 ° min to max 15.5 ° 12.6 14.3 °

Events

Info Flaps Position 4 225 ft agl · 167 kt
Info Flaps Position 3 384 ft agl · 172 kt
Departure Climb 3 91.00Departure climb to 1,000 ft agl from 19C KIAD Washington Dulles International Airport.
ScoreDescriptionStartProfileEnd
100 % Climb speed 195 kt173 kt min to max 212 ktTarget 179 kt, 16 kt fast 173 212 kt
65 % Steepest bank angle 32.1 °0.0 ° min to max 32.1 ° 1.2 9.3 °
81 % Average g force 1.01 g0.25 g min to max 1.98 g 0.93 0.95 g
100 % Landing gear up at 13 ft aglTarget by 400 ft agl
Info Heading variation -0.5 °-1.8 ° min to max 0.0 ° -0.1 -1.8 °
Info Average VSI 2,262 fpm121 fpm min to max 4,736 fpm 3,201 4,736 fpm
Info Average altitude 665 ft agl433 ft agl min to max 996 ft agl 433 996 ft agl
Info Average pitch angle 10.7 °0.9 ° min to max 16.8 ° 14.3 15.4 °

Events

Info Flaps Position 2 592 ft agl · 180 kt
Info Flaps Position 1 623 ft agl · 194 kt
Info Flaps Fully Retracted 997 ft agl · 214 kt
Enroute Climb 100.00Enroute climb started 1 mile south of KIAD Washington Dulles International Airport Dulles (Virginia, United States). Climbing from 1,363 ft asl to 40,167 ft asl, an increase of 38,803 ft in 28 minutes and covering 188 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 259 kt212 kt min to max 300 kt 213 243 kt
100 % Steepest bank angle 28.6 °0.0 ° min to max 28.6 ° 13.6 0.8 °
100 % Average g force 1.00 g0.76 g min to max 1.29 g 0.93 1.00 g
Info Average VSI 1,514 fpm286 fpm min to max 6,048 fpm 4,772 606 fpm
Info Average altitude 27,232 ft asl1,363 ft asl min to max 40,167 ft asl 1,363 40,167 ft asl
Info Average pitch angle 5.5 °2.6 ° min to max 16.2 ° 14.9 4.2 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Landing Lights Switched Off 9,978 ft agl · 266 kt
Enroute Level 100.00Enroute level cruise started 3 miles west of Parrott (Virginia, United States) and lasted 130 minutes, covering 951 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,513 ft of 40,197 ft asl39,944 ft asl min to max 40,464 ft asl 40,262 39,950 ft asl
100 % Average speed 245 kt242 kt min to max 248 kt 242 245 kt
100 % Steepest bank angle 16.4 °0.0 ° min to max 16.4 ° 0.1 1.4 °
100 % Average g force 1.00 g0.98 g min to max 1.06 g 0.99 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 3.2 °2.9 ° min to max 4.2 ° 4.2 3.0 °
Enroute Descent 100.00Enroute descent started overhead 9XS0 Dobbs Ranch Airport Yoakum (Texas, United States). Descent from 39,941 ft asl to 2,629 ft asl, a decrease of 37,312 ft in 11 minutes and covering 144 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 268 kt235 kt min to max 338 kt 245 248 kt
100 % Steepest bank angle 6.9 °0.0 ° min to max 6.9 ° 0.4 0.0 °
100 % Average g force 1.00 g0.93 g min to max 1.06 g 1.00 0.99 g
Info Average VSI -1,235 fpm-2,591 fpm min to max 18 fpm -48 -137 fpm
Info Average altitude 23,921 ft asl2,629 ft asl min to max 39,941 ft asl 39,941 2,629 ft asl
Info Average pitch angle 0.2 °-2.2 ° min to max 3.1 ° 2.9 0.7 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Landing Lights Switched On 19,850 ft agl · 447 kt
Info Taxi Lights Switched On 19,809 ft agl · 447 kt
Info Flaps Position 1 16,645 ft agl · 337 kt
Info Flaps Fully Retracted 16,619 ft agl · 336 kt
Info Flaps Position 1 16,563 ft agl · 334 kt
Info Flaps Fully Retracted 16,530 ft agl · 333 kt
Info Flaps Position 1 16,420 ft agl · 331 kt
Info Flaps Position 2 16,211 ft agl · 321 kt
Enroute Level 2 100.00Enroute level cruise started 5 miles east of 90TX Callaghan Ranch Airport Callaghan (Texas, United States) and lasted 4 minutes, covering 18 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±630 ft of 2,260 ft asl1,782 ft asl min to max 2,595 ft asl 2,595 1,782 ft asl
100 % Average speed 235 kt157 kt min to max 252 kt 248 157 kt
100 % Steepest bank angle 30.2 °0.0 ° min to max 30.2 ° 0.0 0.1 °
100 % Average g force 1.01 g0.87 g min to max 1.23 g 1.01 1.02 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 1.0 °-1.5 ° min to max 2.6 ° 0.8 -0.0 °

Events

Info Landing Gear Down 2,047 ft agl · 262 kt
Info Flaps Position 3 1,624 ft agl · 250 kt
Info Flaps Position 4 1,599 ft agl · 218 kt
Info Flaps Position 3 1,584 ft agl · 213 kt
Info Flaps Position 4 1,577 ft agl · 211 kt
Info Flaps Position 5 1,552 ft agl · 204 kt
Info Flaps Position 7 1,416 ft agl · 188 kt
Info Flaps Position 5 1,399 ft agl · 187 kt
Info Flaps Position 6 1,369 ft agl · 184 kt
Info Flaps Position 7 1,338 ft agl · 180 kt
Arrival Approach 100.00Final approach to runway 18R at KLRD Laredo International Airport. Descent from 1,325 ft agl to 58 ft agl in 109 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates

Events

Info Flaps Position 8 1,146 ft agl · 162 kt
Arrival Landing 100.00Landing on runway 18R at KLRD Laredo International Airport, runway length 2,667 m. Good threshold height. Threshold speed was good at 130 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 130 kt. Target 128 kt
100 % Good threshold height.Target 50 ft agl
100 % Perfect landing flare
100 % Runway alignment max 1.04 m right0.73 m right to 1.04 m right -1.04 -0.73 m
100 % Steepest bank angle 0.6 °0.2 ° min to max 0.6 ° 0.4 0.6 °
100 % Peak g force 1.09 g0.99 g min to max 1.09 g 1.01 0.99 g
Info Average speed 127 kt121 kt min to max 130 kt 130 121 kt
Info Average VSI -400 fpm-732 fpm min to max -197 fpm -732 -223 fpm
Info Average altitude 15 ft agl-4 ft agl min to max 47 ft agl 47 -4 ft agl
Info Average pitch angle 2.0 °0.3 ° min to max 2.6 ° 0.3 2.6 °
07515022530037545052560067501223354658Runway Distance mLanding Height ft075150225300375450525600675-24-20-16-12-8-404812162024Runway Distance mRunway Width m
Arrival Touchdown 97.83Touchdown point was 129 m beyond the touchdown zone. Touchdown speed at 121 kt was good. Touchdown rate was fair at -262 fpm. Runway touchdown alignment was perfect. Local weather - Temperature 27 °C. Wind 12 kt at 130 °. Crosswind: 9 kt Headwind: 7 kt.
ScoreDescriptionStartProfileEnd
97 % Touchdown rate was -262 fpm.
89 % Touchdown distance was 556 mTarget 457 m
100 % Speed at touchdown 121 ktTarget below 127 kt
100 % Runway alignment max 0.73 m right0.59 m right -0.73 -0.37 m
100 % Steepest bank angle 0.7 °0.0 ° min to max 0.7 ° 0.6 0.2 °
100 % Peak g force 1.19 g0.99 g min to max 1.19 g 0.99 1.16 g
100 % Landing Bounce
Info Average speed 120 kt120 kt min to max 121 kt 121 120 kt
Info Average pitch angle 2.6 °2.4 ° min to max 2.6 ° 2.6 2.4 °
Arrival Rollout 100.00Total landing distance 982 m, 37 % of runway. Runway rollout alignment was perfect.
ScoreDescriptionStartProfileEnd
100 % Landing distance 982 m37 % of runway.
100 % Runway alignment max 1.20 m left1.20 m left to 0.00 m left 1.20 0.60 m
100 % Average g force 1.00 g0.95 g min to max 1.14 g 1.14 1.00 g
Info Average speed 109 kt65 kt min to max 116 kt 116 65 kt
Info Average pitch angle -0.2 °-1.4 ° min to max 2.3 ° 2.3 -0.8 °
Info Average bank angle 1.0 °0.0 ° min to max 2.3 ° 0.3 0.1 °
Runway Exit Exiting runway, average speed 39 kt
ScoreDescriptionStartProfileEnd
Info Average speed 36 kt15 kt min to max 57 kt 57 19 kt
Info Average pitch angle -1.1 °-1.4 ° min to max -0.8 ° -0.8 -1.2 °
Info Average bank angle 0.3 °0.1 ° min to max 0.4 ° 0.2 0.3 °
Info Average g force 1.00 g0.97 g min to max 1.01 g 0.99 1.00 g

Events

Info Flaps Position 7 8 ft agl · 55 kt
Info Flaps Position 6 8 ft agl · 53 kt
Info Flaps Position 5 8 ft agl · 50 kt
Info Flaps Position 4 8 ft agl · 44 kt
Info Flaps Position 3 8 ft agl · 29 kt
Info Flaps Position 2 8 ft agl · 17 kt
Info Landing Lights Switched Off 8 ft agl · 9 kt
Info Strobe Lights Switched Off 8 ft agl · 9 kt
Info Flaps Position 1 8 ft agl · 9 kt
Arrival Taxi 100.00Taxiing to the parking from the runway took 1 minutes and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 13 kt3 kt min to max 24 kt 20 3 kt
100 % Average speed turning corners 11 ktmax 12 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.02 g 1.00 1.00 g
Info Average pitch angle -0.8 °-1.2 ° min to max -0.4 ° -1.1 -1.1 °
Info Average bank angle 0.2 °0.0 ° min to max 0.7 ° 0.3 0.0 °

Events

Info Flaps Fully Retracted 8 ft agl · 15 kt

Takeoff from KIAD 19C

Taxi out

LightsOk
All on
Taxi speed100.00
24kt peak

The roll

Takeoff roll100.00
2,221m63 %
Runway alignment100.00
2.96m L
Rotation speed100.00
142kttarget 134, 8 late

Rotated late, and the nose came up quickly

Rotation started at 142 kt, 8 kt after the 134 kt rotate speed, and the nose then rose at 5.7° a second, faster than the 2.1 to 4.0° a second other Boeing 737-800 pilots fly.

The pull started late and then came quickly, as if to make up the time. Start it on the rotate speed instead, so there is nothing to catch up, and keep it to the normal rate for this aircraft.

Liftoff and climb

Liftoff
150ktat 9.3°
Rotation
5.7°/sover 1.7 s, gaining 8 kt
35 ft
159ktat 12.2°, 1.9 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
0.6°steepest
Gear up100.00
13ftfull marks to 400 ft
Climb 3 speed100.00
195kttarget 179

Plan view the roll down the 3,510 m runway.

Rolled from 1,347 m in, drifted left of the centreline, 3 m at the widest, and lifted off 3.1 m left. Airborne 63 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

1,0002,0003,000THRESHOLDLEFT ↑RIGHT ↓CROSS3 kn75 %widest 2.96 m LROLL 1,347 M INAirborne 2,229 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 2,229 m of 3,510 m · 63 %
Behind the start of the roll, 1,347 mTakeoff roll, 881 m Left ahead, 1,281 m

Side view from the start of the roll to the end of Climb 3 at 997 ft.

Reached 35 ft with 1,131 m of runway left; gear up at 13 ft, inside the 400 ft that gets full marks; then climbing at 2,330 fpm on average to 997 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3195 kt avgtarget 179THRESHOLDRUNWAY END6080100120KNOTS ALONG THE ROLLnose up on the runway · 124 m · 1.7 sRotate 142 kttarget 134Liftoff 150 ktGear up 13 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 179240 kt16080020°10°0°nose up on the runway · 124 m · 1.7 sROTATELIFTOFFtarget 134held 12.7°9.3° off · 5.7°/s12° at 35 ftAIRSPEEDPITCH02040 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2.1 to 4.0° a second, the middle half of rotation rates flown by other Boeing 737-800 pilots over the last 180 days (293 takeoffs); the grey pair are 2 to 3° a second, the rates airliners are rotated at. A trace steeper than both green lines is a faster rotation than most, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 11°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 11°ROTATELIFTOFF35 FT9.3° off · 5.7°/s4.0°/s3°/s2.1°/s2°/s12° at 35 ftROTATION DETAIL-2-10+1+2+3+4 sseconds from rotation
PitchRotation began2.1 to 4.0°/s, other Boeing 737-800 pilots2 to 3°/s from rotation, airlinersTail strikeNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate780 fpm710 fpm
On glideslope3.0°3.0°
On centreline0.0° off0.0° off
On speed+4.9 kt+1.9 kt
Wings level0° bank0° bank

When the approach was stable

Every check met from 4 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to KLRD 18R

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 10 ft below the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,3166913692151,000 ft gate7 of 71,040 ft · 133 kt500 ft gate7 of 7541 ft · 130 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 52× larger than distances along the final.

Inside the 1° band all the way from 4 nm, never more than 2 m off the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR18 m L018 m RLEFT ↑RIGHT ↓1° BAND1 m L2 m L1 m L0 m R1 m R1 m L
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 32 kt fast at the 1,000 ft gate, closing to 19 at 500 ft and 10 at the threshold.

Inside the speed band all the way, between −2 kt and +32 kt on the approach speed of 128 kt.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

120140160180 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 128+32 kt+4 kt−1 kt+4 kt+2 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on KLRD 18R

Over the threshold

Threshold height100.00
47ft
Threshold speed100.00
129kttarget 128, 1 fast
Centreline offset100.00
1.04m R
Bank100.00
0.6°steepest
Flare100.00

Perfect landing flare

Touchdown

Past threshold89.18
556m
Centreline100.00
0.73m R
Speed100.00
120kttarget 127 or less
Touchdown rate97.24
-262fpm
Impact100.00
1.19G
BouncesOk
None
Bank100.00
0.7°as the wheels touched

Rollout

Rollout distance100.00
394m36 % used
Rollout alignment100.00
1.20m L

Taxi in

LightsOk
All set
Taxi speed100.00
24kt peak11 kt in turns

Side view — the last 1,524 m of the approach.

Crossed the threshold at 47 ft, close to the 50 ft target; began the flare at 23 ft. Touched down 556 m in, 251 m past the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,524 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

47 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 23 ft · −496 fpm · 1.5° · 129 ktdescent slowed at 10 ft · −78 fpm · 2.5°−262 fpm · 2.6° nose up · 121 kt Ideal — 50 ft, down at 305 m This flight — 47 ft, down at 556 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 500 fpm at the flare to 260 fpm at touchdown. The nose came up 1.1° on the way down. Into the flare at 129 kt, on the 128 kt approach speed, and 121 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−262 fpm at touchdown2.6° at touchdown, +1.1° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,524 m of the 2,667 m runway, to the same scale as the side view.

Touched down on the centreline, and stayed within 2.4 m of it down the rollout. 9 kt across from the left, which takes about 4° of crab to hold the centreline at 121 kt. Touched down with 3° of it still on, wings level.

Wind 130° at 12 kt · 7 kt head · 9 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ CROSS 9 kn FULL SCORE TO 503 M 556 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

Touched down 556 m past the threshold — beyond the full-score zone. The arrival was smooth.

Runway used 950 m of 2,667 m · 36 %
In the air over the runway, 556 mRollout, 394 m Left over, 1,717 m

The stop — touchdown to taxi speed.

From 117 kt at touchdown to taxi speed (30 kt) in 34 s, an average deceleration of 0.14 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 457 m30 kt · 1,020 mtouchdown1,061 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
