ZBAA
Beijing, China
Runway 36R
Elevation98 ft asl
Weight70,476 kg
Fuel7,820 kg
Wind270° · 3 kn · 3 kn cross

Flight Score

98.67 %
ZMCK
Ulaanbaatar (Sergelen), Mongolia
Runway 11
Elevation4,485 ft asl
Weight65,564 kg
Fuel2,832 kg
Wind69° · 7 kn · 4 kn cross
22 Feb 2024 2:01 700 nm Boeing 737-800 4,988 kg
Departure Score
98.60 %
Enroute Score
100.00 %
Arrival Score
97.40 %

What went well

Touchdown 442 m in — inside the full-score zone
Threshold crossed at 43 ft and 150 kt — both inside band
Straight touchdown — 3.82 m off the centreline, no bounce

What held you back

Firm touchdown — 378 fpm, −0.54 points across the landing and the touchdown
  • Arrival Touchdown · sink rate 378 fpm−0.38
  • Arrival Landing · flare: the descent was not taken out−0.14
  • Arrival Touchdown · 1.42 G at contact−0.02
Departure Taxi — peak speed in a turn 20 kt at 83 %, −0.47 points
Arrival Taxi — Landing Lights at 1 %, −0.33 points

Next time

Arrival

Begin the flare with progressive back pressure and keep it coming until the sink is arrested, rather than flying it on flat.

What happened: The nose was barely raised in the flare and little of the sink was taken out, flying the aircraft onto the runway. This pattern usually carries through to a firm touchdown with a noticeable sink rate.

Watch for: Vertical speed indicator: a smoothly reducing sink through the normal flare band, not a steady rate into the runway.

See Arrival LandingArrival Touchdown

Twenty knots on a monitor produces the visual sensation of about ten. The advice to "taxi at a walking pace" cannot fix this, because your sense of walking pace is exactly the thing that's broken. Put the groundspeed readout in your scan and obey it for the next fifty flights, the way a student pilot leans on the airspeed indicator before learning to read attitude.

Read more in How to Taxi Anywhere

Start to finish · 17 stages, 15 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 93.00Taxiing from the parking to the runway took 6 minutes and covered 2 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 16 kt0 kt min to max 22 kt 0 13 kt
83 % Average speed turning corners 18 ktmax 20 kt 0 0 kt
100 % Average g force 1.00 g0.98 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle -1.1 °-1.3 ° min to max -0.8 ° -1.0 -0.8 °
Info Average bank angle 0.1 °0.0 ° min to max 0.3 ° 0.0 0.1 °

Events

Info Battery Master On 8 ft agl
Info Engine 2 Started 8 ft agl
Info Beacon Lights Switched On 8 ft agl
Info Navigation Lights Switched On 8 ft agl
Info Strobe Lights Switched On 8 ft agl
Info Landing Gear Down 8 ft agl
Info Engine 1 Started 8 ft agl
Info Flaps Position 1 8 ft agl
Info Flaps Position 2 8 ft agl
Info Flaps Position 3 8 ft agl
Info Taxi Lights Switched On 8 ft agl · 18 kt
Info Taxi Lights Switched Off 8 ft agl · 15 kt
Info Taxi Lights Switched On 8 ft agl · 16 kt
Info Landing Lights Switched On 8 ft agl · 16 kt
Departure Runway Entry Entering runway 36R at ZBAA Beijing Capital International Airport, Average speed was 14 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 13 kt13 kt min to max 13 kt 13 13 kt
Info Average pitch angle -0.8 °-0.8 ° min to max -0.8 ° -0.8 -0.8 °
Info Average bank angle 0.0 °0.0 ° min to max 0.1 ° 0.1 0.0 °
Info Average g force 1.00 g1.00 g min to max 1.01 g 1.00 1.00 g
Departure Roll 100.00Departure roll runway 36R at ZBAA Beijing Capital International Airport. Takeoff distance 1,684 m 44 % of runway. Rotation speed was 160 kt. Local weather - Temperature 4 °C. Wind 3 kt at 270 °. Crosswind: 3 kt Headwind: 0 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 1,684 m44 % of runway
100 % Rotation speed was 160 ktTarget 149 kt
100 % Runway alignment max 5.34 m left5.34 m left to 0.00 m left 2.86 5.34 m
100 % Average g force 1.01 g0.97 g min to max 1.05 g 1.00 1.01 g
100 % Takeoff Bounce
Info Average pitch angle -0.4 °-1.2 ° min to max 6.3 ° -0.8 6.3 °
Info Average bank angle 0.2 °0.0 ° min to max 1.4 ° 0.1 1.4 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 36R ZBAA Beijing Capital International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.3 °-0.3 ° min to max -0.2 ° -0.2 -0.3 °
100 % Average speed 182 kt175 kt min to max 186 kt 175 186 kt
100 % Steepest bank angle 2.6 °1.4 ° min to max 2.6 ° 1.4 2.6 °
100 % Average g force 1.14 g1.02 g min to max 1.24 g 1.02 1.17 g
Info Average VSI 585 fpm236 fpm min to max 1,102 fpm 236 1,102 fpm
Info Average altitude 18 ft agl0 ft agl min to max 46 ft agl 0 46 ft agl
Info Average pitch angle 8.8 °6.4 ° min to max 10.8 ° 6.4 10.8 °
Departure Climb 2 100.00Departure climb to 400 ft agl from 36R ZBAA Beijing Capital International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.2 °-0.3 ° min to max 0.0 ° -0.3 0.0 °
100 % Average speed 189 kt186 kt min to max 194 kt 186 194 kt
100 % Steepest bank angle 3.2 °0.0 ° min to max 3.2 ° 2.6 0.0 °
100 % Average g force 1.12 g1.10 g min to max 1.17 g 1.17 1.12 g
Info Average VSI 1,646 fpm1,121 fpm min to max 3,447 fpm 1,121 3,447 fpm
Info Average altitude 102 ft agl47 ft agl min to max 374 ft agl 47 374 ft agl
Info Average pitch angle 11.7 °10.8 ° min to max 16.7 ° 10.8 16.7 °

Events

Info Landing Gear Up 132 ft agl · 185 kt
Departure Climb 3 100.00Departure climb to 1,000 ft agl from 36R ZBAA Beijing Capital International Airport.
ScoreDescriptionStartProfileEnd
100 % Climb speed 191 kt185 kt min to max 194 ktTarget 179 kt, 12 kt fast 194 185 kt
100 % Steepest bank angle 1.7 °0.3 ° min to max 1.7 ° 0.3 1.7 °
100 % Average g force 1.08 g1.00 g min to max 1.11 g 1.11 1.00 g
100 % Landing gear up at 100 ft aglTarget by 400 ft agl
Info Heading variation 0.2 °0.1 ° min to max 0.3 ° 0.1 0.3 °
Info Average VSI 4,568 fpm3,757 fpm min to max 5,287 fpm 3,757 5,287 fpm
Info Average altitude 670 ft agl439 ft agl min to max 922 ft agl 439 922 ft agl
Info Average pitch angle 20.1 °17.5 ° min to max 22.1 ° 17.5 22.1 °
Enroute Climb 100.00Enroute climb started overhead ZBAA Beijing Capital International Airport Beijing (Beijing Shi, China). Climbing from 1,126 ft asl to 12,901 ft asl, an increase of 11,775 ft in 5 minutes and covering 22 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 242 kt171 kt min to max 303 kt 183 302 kt
100 % Steepest bank angle 31.5 °0.0 ° min to max 31.5 ° 4.7 11.6 °
99.97 % Average g force 1.03 g0.76 g min to max 1.33 g 0.95 0.90 g
Info Average VSI 2,005 fpm326 fpm min to max 5,379 fpm 5,368 1,627 fpm
Info Average altitude 6,269 ft asl1,126 ft asl min to max 12,901 ft asl 1,126 12,901 ft asl
Info Average pitch angle 8.5 °3.5 ° min to max 22.2 ° 22.1 4.0 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Position 2 3,464 ft agl · 197 kt
Info Flaps Position 1 3,531 ft agl · 204 kt
Info Flaps Fully Retracted 3,744 ft agl · 228 kt
Info Landing Lights Switched Off 9,493 ft agl · 283 kt
Info Taxi Lights Switched Off 9,537 ft agl · 285 kt
Enroute Level 100.00Enroute level cruise started 9 miles south of ZGUO Gulou Airport Gulou (Beijing Shi, China) and lasted 2 minutes, covering 10 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±1,146 ft of 12,966 ft asl12,922 ft asl min to max 12,985 ft asl 12,922 12,972 ft asl
100 % Average speed 302 kt301 kt min to max 303 kt 302 303 kt
100 % Steepest bank angle 27.9 °0.2 ° min to max 27.9 ° 15.0 0.5 °
100 % Average g force 1.06 g0.87 g min to max 1.22 g 0.87 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 2.4 °1.7 ° min to max 3.5 ° 3.5 2.2 °
Enroute Climb 2 100.00Enroute climb started 6 miles east of ZGUO Gulou Airport Gulou (Beijing Shi, China). Climbing from 12,975 ft asl to 35,108 ft asl, an increase of 22,133 ft in 17 minutes and covering 114 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 289 kt258 kt min to max 307 kt 303 258 kt
100 % Steepest bank angle 27.0 °0.0 ° min to max 27.0 ° 6.3 0.3 °
100 % Average g force 1.03 g0.97 g min to max 1.23 g 0.98 0.97 g
Info Average VSI 1,007 fpm-178 fpm min to max 2,984 fpm 30 322 fpm
Info Average altitude 26,359 ft asl12,956 ft asl min to max 35,108 ft asl 12,975 35,108 ft asl
Info Average pitch angle 4.1 °2.0 ° min to max 6.8 ° 2.2 3.9 °
Info Turn coordination 00 min to max 0 0 0
Enroute Level 2 100.00Enroute level cruise started 4 miles east of Luotuoshan (Inner Mongolia Autonomous Region, China) and lasted 63 minutes, covering 419 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,257 ft of 34,956 ft asl34,642 ft asl min to max 35,149 ft asl 35,135 34,647 ft asl
100 % Average speed 256 kt243 kt min to max 260 kt 259 243 kt
100 % Steepest bank angle 18.4 °0.0 ° min to max 18.4 ° 0.0 0.1 °
100 % Average g force 1.00 g0.98 g min to max 1.06 g 1.00 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 3.7 °3.5 ° min to max 4.0 ° 3.8 4.0 °
Enroute Descent 100.00Enroute descent started 5 miles east of Choyr (Govi-Sumber, Mongolia). Descent from 34,649 ft asl to 5,475 ft asl, a decrease of 29,174 ft in 24 minutes and covering 126 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 224 kt164 kt min to max 248 kt 242 164 kt
100 % Steepest bank angle 29.5 °0.0 ° min to max 29.5 ° 0.1 0.0 °
100 % Average g force 1.03 g0.93 g min to max 1.21 g 1.00 1.14 g
Info Average VSI -1,045 fpm-1,968 fpm min to max 10 fpm -3 -409 fpm
Info Average altitude 13,765 ft asl5,475 ft asl min to max 34,649 ft asl 34,649 5,475 ft asl
Info Average pitch angle 2.3 °0.1 ° min to max 5.0 ° 4.1 5.0 °
Info Turn coordination 00 min to max 0 0 0

Events

Fail Landing Lights OFF should be ON 8,545 ft agl
Info Landing Lights Switched On 3,689 ft agl · 252 kt
Info Taxi Lights Switched On 3,602 ft agl · 252 kt
Info Flaps Position 1 2,448 ft agl · 226 kt
Info Flaps Position 2 1,977 ft agl · 202 kt
Info Flaps Position 3 1,834 ft agl · 199 kt
Info Landing Gear Down 1,825 ft agl · 194 kt
Info Flaps Position 4 1,701 ft agl · 190 kt
Info Flaps Position 5 1,404 ft agl · 181 kt
Info Flaps Position 6 1,310 ft agl · 172 kt
Arrival Approach 100.00Final approach to runway 11 at ZMCK Ulaanbaatar Chinggis Khaan International Airport. Descent from 1,017 ft agl to 54 ft agl in 94 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates

Events

Fail GPWS Warning Activated 839 ft agl · 150 kt
Fail GPWS Warning Activated 735 ft agl · 150 kt
Info Flaps Position 7 1,208 ft agl · 163 kt
Info GPWS Warning Deactivated 808 ft agl · 150 kt
Info GPWS Warning Deactivated 733 ft agl · 149 kt
Arrival Landing 97.94Landing on runway 11 at ZMCK Ulaanbaatar Chinggis Khaan International Airport, runway length 3,580 m. Good threshold height. Threshold speed was good at 151 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 151 kt. Target 145 kt
100 % Good threshold height.Target 50 ft agl
92 % The flare held the target profile well. The aircraft was flown onto the runway - pitch changed 2.0° and the descent was barely arrested. Touchdown was 442 m past the threshold. Start the flare with progressive back pressure rather than one pull, and keep it coming.
100 % Runway alignment max 4.35 m right3.45 m right to 4.35 m right -3.45 -4.35 m
100 % Steepest bank angle 0.4 °0.0 ° min to max 0.4 ° 0.4 0.3 °
100 % Peak g force 1.20 g0.96 g min to max 1.20 g 1.02 0.97 g
Info Average speed 148 kt145 kt min to max 151 kt 151 145 kt
Info Average VSI -550 fpm-818 fpm min to max -334 fpm -818 -374 fpm
Info Average altitude 16 ft agl-3 ft agl min to max 44 ft agl 44 -3 ft agl
Info Average pitch angle 3.3 °2.1 ° min to max 5.0 ° 2.1 3.0 °
07515022530037545052501123344657Runway Distance mLanding Height ft075150225300375450525-24-20-16-12-8-404812162024Runway Distance mRunway Width m
Arrival Touchdown 94.03Touchdown distance was good at 442 m. Touchdown speed at 145 kt was a little fast. Touchdown rate was firm at -378 fpm. Runway touchdown position was slightly misaligned by 4.4 m from centreline. Local weather - Temperature -16 °C. Wind 8 kt at 70 °. Crosswind: 4 kt Headwind: 6 kt.
ScoreDescriptionStartProfileEnd
72 % Touchdown rate was -378 fpm.
100 % Touchdown distance was 442 mTarget 457 m
100 % Speed at touchdown 145 ktTarget below 145 kt
100 % Runway alignment max 4.38 m right4.18 m right -4.35 -3.82 m
100 % Steepest bank angle 1.6 °0.3 ° min to max 1.6 ° 0.3 1.6 °
94 % Peak g force 1.42 g0.96 g min to max 1.42 g 0.97 1.20 g
100 % Landing Bounce
Info Average speed 144 kt144 kt min to max 145 kt 145 144 kt
Info Average pitch angle 2.7 °2.1 ° min to max 3.0 ° 3.0 2.1 °
Arrival Rollout 100.00Total landing distance 1,470 m, 41 % of runway. Runway rollout alignment was perfect.
ScoreDescriptionStartProfileEnd
100 % Landing distance 1,470 m41 % of runway.
100 % Runway alignment max 1.80 m left1.80 m left to 1.27 m right -0.35 1.62 m
100 % Average g force 1.01 g0.95 g min to max 1.13 g 1.13 1.02 g
Info Average speed 128 kt72 kt min to max 140 kt 140 72 kt
Info Average pitch angle -0.1 °-1.6 ° min to max 2.0 ° 2.0 -1.0 °
Info Average bank angle 0.5 °0.0 ° min to max 1.6 ° 1.6 0.1 °
Runway Exit Exiting runway, average speed 45 kt
ScoreDescriptionStartProfileEnd
Info Average speed 39 kt27 kt min to max 68 kt 68 27 kt
Info Average pitch angle -1.4 °-1.7 ° min to max -1.1 ° -1.1 -1.4 °
Info Average bank angle 0.1 °0.0 ° min to max 0.4 ° 0.0 0.4 °
Info Average g force 0.99 g0.97 g min to max 1.01 g 0.98 1.00 g
Arrival Taxi 95.05Taxiing to the parking from the runway took 2 minutes and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 7 kt6 kt min to max 23 kt 23 6 kt
100 % Average speed turning corners 6 ktmax 6 kt 0 0 kt
100 % Average g force 1.00 g0.97 g min to max 1.03 g 1.02 0.99 g
Info Average pitch angle -1.0 °-1.6 ° min to max -0.6 ° -1.6 -1.5 °
Info Average bank angle 0.2 °0.0 ° min to max 0.6 ° 0.2 0.2 °

Events

Fail Landing Lights
Info Flaps Position 6 7 ft agl · 12 kt
Info Flaps Position 5 7 ft agl · 12 kt
Info Flaps Position 4 8 ft agl · 12 kt
Info Flaps Position 3 7 ft agl · 12 kt
Info Flaps Position 2 7 ft agl · 12 kt
Info Flaps Position 1 8 ft agl · 12 kt
Info Flaps Fully Retracted 8 ft agl · 12 kt

Takeoff from ZBAA 36R

Taxi out

LightsOk
All on
Taxi speed91.25
22kt peak18 kt in turns

The roll

Takeoff roll100.00
1,684m44 %
Runway alignment100.00
5.34m L
Rotation speed100.00
160kttarget 149, 11 late

Rotated late, and the nose came up slowly

Rotation started at 160 kt, 11 kt after the 149 kt rotate speed, and the nose then rose at 1.9° a second, slower than the 2.1 to 4.0° a second other Boeing 737-800 pilots fly.

The pull started after the rotate speed and was then slow. Start it on the rotate speed and make it one positive, continuous movement at the normal rate for this aircraft.

Liftoff and climb

Liftoff
174ktat 6.4°
Rotation
1.9°/sover 3.5 s, gaining 14 kt
35 ft
185ktat 10.5°, 3.2 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
2.6°steepest
Gear up100.00
100ftfull marks to 400 ft
Climb 3 speed100.00
191kttarget 179

Plan view the roll down the 3,806 m runway.

Rolled from 86 m in, drifted left of the centreline, 5.4 m at the widest, and lifted off 5.6 m left. Airborne 44 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

1,0002,0003,000THRESHOLDLEFT ↑RIGHT ↓CROSS3 kn75 %widest 5.40 m LROLL 86 M INAirborne 1,693 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,693 m of 3,806 m · 44 %
Behind the start of the roll, 86 mTakeoff roll, 1,608 m Left ahead, 2,112 m

Side view from the start of the roll to the end of Climb 3 at 922 ft.

Reached 35 ft with 1,819 m of runway left; gear up at 100 ft, inside the 400 ft that gets full marks; then climbing at 2,930 fpm on average to 922 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3191 kt avgtarget 179THRESHOLDRUNWAY END6080100120140KNOTS ALONG THE ROLLnose up on the runway · 293 m · 3.5 sRotate 160 kttarget 149Liftoff 174 ktGear up 100 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 179210 kt14070025°13°0°nose up on the runway · 293 m · 3.5 sROTATELIFTOFFGEAR UPtarget 149held 12.8°6.4° off · 1.9°/s11° at 35 ftAIRSPEEDPITCH02040 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2.1 to 4.0° a second, the middle half of rotation rates flown by other Boeing 737-800 pilots over the last 180 days (291 takeoffs); the grey pair are 2 to 3° a second, the rates airliners are rotated at. A trace steeper than both green lines is a faster rotation than most, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 11°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 11°ROTATELIFTOFF35 FT2°/s2.1°/s3°/s4.0°/s6.4° off · 1.9°/s11° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5+6+7 sseconds from rotation
PitchRotation began2.1 to 4.0°/s, other Boeing 737-800 pilots2 to 3°/s from rotation, airlinersTail strikeNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate220 fpm650 fpm
On glideslope2.7°2.9°
On centreline0.2° off0.3° off
On speed+11 kt+4.7 kt
Wings level0° bank1° bank

When the approach was stable

Every check met from 4 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to ZMCK 11

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 320 ft below the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,0076153842221,000 ft gate7 of 7946 ft · 156 kt500 ft gate7 of 7514 ft · 150 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 9× larger than distances along the final.

Inside the 1° band all the way from 4 nm, never more than 43 m off the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR110 m L0110 m RLEFT ↑RIGHT ↓1° BAND41 m L24 m R16 m R1 m R24 m L14 m R
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 36 kt fast at the 1,000 ft gate, closing to 22 at 500 ft and 10 at the threshold.

Inside the speed band all the way, between +0 kt and +21 kt on the approach speed of 145 kt.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

140160180200 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 145+21 kt+1 kt+5 kt+9 kt+6 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on ZMCK 11

Over the threshold

Threshold height100.00
43ft
Threshold speed100.00
150kttarget 145, 5 fast
Centreline offset100.00
4.35m R
Bank100.00
0.4°steepest
Flare91.77

The flare held the target profile well

The aircraft was flown onto the runway - pitch changed 2.0° and the descent was barely arrested. Touchdown was 442 m past the threshold. Start the flare with progressive back pressure rather than one pull, and keep it coming.

Touchdown

Past threshold100.00
442m
Centreline100.00
4.38m R
Speed100.00
144kttarget 144 or less
Touchdown rate71.64
-378fpm
Impact94.05
1.42G
BouncesOk
None
Bank100.00
1.6°as the wheels touched

Rollout

Rollout distance100.00
984m40 % used
Rollout alignment100.00
1.80m L

Taxi in

Lights50.50
Onlanding lights, 99% of the taxi
Taxi speed100.00
23kt peak6 kt in turns

Side view — the last 1,548 m of the approach.

Crossed the threshold at 43 ft, close to the 50 ft target; began the flare at 22 ft. Touched down 442 m in, 137 m past the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,548 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

43 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 22 ft · −527 fpm · 3.4° · 150 ktdescent slowed at 14 ft · −206 fpm · 4.2°−377 fpm · 3° nose up · 145 kt Ideal — 50 ft, down at 305 m This flight — 43 ft, down at 442 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 530 fpm at the flare to 210 fpm at 14 ft, then back up to 380 fpm at touchdown. The pitch barely changed. Into the flare at 150 kt, 5 kt over the 145 kt approach speed, and 145 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−377 fpm at touchdown3° at touchdown, −0.4° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,548 m of the 3,580 m runway, to the same scale as the side view.

Touched down 3.8 m right of the centreline, and steered back to 1.5 m left by the end of the rollout. 4 kt across from the left, which takes about 2° of crab to hold the centreline at 145 kt. Touched down with 2° of it still on, wings level.

Wind 069° at 7 kt · 6 kt head · 4 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ CROSS 4 kn FULL SCORE TO 503 M 442 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

The 442 m touchdown sits inside the full-score zone. The 377 fpm arrival was firm.

Runway used 1,426 m of 3,580 m · 40 %
In the air over the runway, 442 mRollout, 984 m Left over, 2,154 m

The stop — touchdown to taxi speed.

From 141 kt at touchdown to taxi speed (30 kt) in 33 s, an average deceleration of 0.18 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012016060 kt · 1,132 m30 kt · 1,325 mtouchdown1,378 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
