ZSPD
Shanghai (Pudong), China
Runway 34L
Elevation10 ft asl
Weight390,452 kg
Fuel135,566 kg
Wind30° · 7 kn · 5 kn cross

Flight Score

99.85 %
NZCH
Christchurch, New Zealand
Runway 02
Elevation105 ft asl
Weight280,925 kg
Fuel24,999 kg
Wind70° · 8 kn · 4 kn cross
4 Oct 2024 11:26 5652 nm Boeing 747-8 110,568 kg
Departure Score
100.00 %
Enroute Score
100.00 %
Arrival Score
99.55 %

What went well

Touched down at -241 fpm — a soft arrival
Threshold crossed at 47 ft and 145 kt — both inside band
Straight touchdown — 1.90 m off the centreline, no bounce

What held you back

Arrival Touchdown — Touchdown distance was 586 m at 86 %, −0.14 points

Next time

Arrival

Keep the back pressure coming once the flare is established, holding the attitude instead of letting the nose drop.

What happened: Sink came back after the flare had arrested it, and that pattern usually carries the touchdown long - here it landed at 586 m against the 457 m aim point.

Watch for: Vertical speed indicator: a steady, shallow rate through the flare with no renewed sink before touchdown

See Arrival LandingArrival Touchdown

Ground effect becomes significant below about one wingspan of height. A Cessna 172, with a 36 ft span, enters ground effect at flare height - the float it feels in the hold-off is ground effect arriving on cue. An A320, with a span around 117 ft, has been in ground effect since before the threshold and there is no sudden cushion to feel, only a gradual reduction in induced drag that lengthens any float you allow.

Read more in Flare Timing

Start to finish · 21 stages, 19 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 9 minutes and covered 2 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 14 kt0 kt min to max 21 kt 3 13 kt
100 % Average speed turning corners 12 ktmax 13 kt 0 0 kt
100 % Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Info Average pitch angle -0.6 °-0.8 ° min to max -0.6 ° -0.6 -0.8 °
Info Average bank angle 0.1 °0.0 ° min to max 0.3 ° 0.1 0.2 °

Events

Info Engine 2 Started 15 ft agl
Info Engine 3 Started 15 ft agl
Info Taxi Lights Switched On 15 ft agl
Info Flaps Position 1 15 ft agl
Info Flaps Position 3 15 ft agl
Info Flaps Position 4 15 ft agl
Info Parking Brake On 15 ft agl
Info Parking Brake Off 15 ft agl
Info Autopilot AutoThrottle Arm Armed 15 ft agl · 15 kt
Info Autopilot AutoThrottle Arm Disarmed 15 ft agl · 14 kt
Info Landing Lights Switched On 15 ft agl · 14 kt
Info Strobe Lights Switched On 15 ft agl · 13 kt
Departure Runway Entry Entering runway 34L at ZSPD Shanghai Pudong International Airport, Average speed was 19 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 13 kt13 kt min to max 14 kt 13 14 kt
Info Average pitch angle -0.7 °-0.8 ° min to max -0.6 ° -0.8 -0.6 °
Info Average bank angle 0.2 °0.1 ° min to max 0.2 ° 0.2 0.2 °
Info Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Departure Roll 100.00Departure roll runway 34L at ZSPD Shanghai Pudong International Airport. Takeoff distance 1,769 m 47 % of runway. Rotation speed was 157 kt. Local weather - Temperature 26 °C. Wind 7 kt at 30 °. Crosswind: 5 kt Headwind: 5 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 1,769 m47 % of runway
100 % Rotation speed was 157 ktTarget 156 kt
100 % Runway alignment max 2.04 m right0.33 m left to 2.04 m right -0.48 -2.04 m
100 % Average g force 1.00 g0.97 g min to max 1.06 g 1.00 1.04 g
100 % Takeoff Bounce
Info Average pitch angle -0.1 °-0.7 ° min to max 8.7 ° -0.6 8.7 °
Info Average bank angle 0.5 °0.0 ° min to max 2.4 ° 0.2 2.4 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 34L ZSPD Shanghai Pudong International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.1 °0.0 ° min to max 0.1 ° 0.1 0.0 °
100 % Average speed 170 kt165 kt min to max 175 kt 165 175 kt
100 % Steepest bank angle 3.3 °0.6 ° min to max 3.3 ° 2.5 0.6 °
100 % Average g force 1.09 g0.97 g min to max 1.25 g 1.04 0.98 g
Info Average VSI 472 fpm133 fpm min to max 944 fpm 133 944 fpm
Info Average altitude 15 ft agl0 ft agl min to max 42 ft agl 0 42 ft agl
Info Average pitch angle 10.4 °8.8 ° min to max 12.1 ° 8.8 10.2 °
Departure Climb 2 100.00Departure climb to 400 ft agl from 34L ZSPD Shanghai Pudong International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.0 °-0.5 ° min to max 0.0 ° 0.0 -0.5 °
100 % Average speed 180 kt175 kt min to max 201 kt 175 201 kt
100 % Steepest bank angle 4.8 °0.0 ° min to max 4.8 ° 0.6 1.7 °
100 % Average g force 1.06 g0.91 g min to max 1.13 g 0.99 0.97 g
Info Average VSI 1,259 fpm952 fpm min to max 1,734 fpm 952 1,544 fpm
Info Average altitude 110 ft agl43 ft agl min to max 386 ft agl 43 386 ft agl
Info Average pitch angle 10.5 °7.2 ° min to max 11.5 ° 10.4 7.2 °

Events

Info Autopilot Heading Hold Activated 83 ft agl · 179 kt
Info Landing Gear Up 137 ft agl · 184 kt
Info Flaps Position 3 332 ft agl · 198 kt
Info Flaps Position 2 385 ft agl · 203 kt
Departure Climb 3 100.00Departure climb to 1,000 ft agl from 34L ZSPD Shanghai Pudong International Airport.
ScoreDescriptionStartProfileEnd
100 % Climb speed 214 kt203 kt min to max 222 ktTarget 202 kt, 12 kt fast 203 222 kt
100 % Steepest bank angle 6.2 °0.2 ° min to max 6.2 ° 4.7 2.1 °
100 % Average g force 1.02 g0.92 g min to max 1.14 g 0.95 1.06 g
100 % Landing gear up at 87 ft aglTarget by 400 ft agl
Info Heading variation -0.8 °-0.9 ° min to max -0.6 ° -0.6 -0.9 °
Info Average VSI 2,338 fpm1,527 fpm min to max 2,917 fpm 1,527 2,917 fpm
Info Average altitude 653 ft agl412 ft agl min to max 944 ft agl 412 944 ft agl
Info Average pitch angle 9.2 °7.9 ° min to max 10.1 ° 7.9 10.1 °
Enroute Climb 100.00Enroute climb started 1 mile north east of ZSPD Shanghai Pudong International Airport Shanghai (Pudong) (Shanghai Shi, China). Climbing from 1,030 ft asl to 35,204 ft asl, an increase of 34,174 ft in 21 minutes and covering 162 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 314 kt223 kt min to max 351 kt 223 297 kt
100 % Steepest bank angle 32.8 °0.0 ° min to max 32.8 ° 1.9 2.8 °
100 % Average g force 1.05 g0.82 g min to max 1.21 g 0.96 1.06 g
Info Average VSI 1,617 fpm-576 fpm min to max 4,165 fpm 2,952 -64 fpm
Info Average altitude 18,779 ft asl1,030 ft asl min to max 35,264 ft asl 1,030 35,204 ft asl
Info Average pitch angle 5.0 °1.9 ° min to max 15.5 ° 9.6 3.7 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Master Switched On 2,041 ft agl · 239 kt
Info Autopilot AutoThrottle Arm Armed 2,224 ft agl · 241 kt
Info Autopilot RPM Hold Activated 2,224 ft agl · 241 kt
Info Autopilot Airspeed Hold Activated 3,429 ft agl · 251 kt
Info Autopilot Vertical Hold Activated 3,429 ft agl · 251 kt
Info Autopilot RPM Hold Deactivated 3,429 ft agl · 251 kt
Info Autopilot Airspeed Hold Deactivated 4,521 ft agl · 268 kt
Info Autopilot Vertical Hold Deactivated 4,521 ft agl · 268 kt
Info Autopilot RPM Hold Activated 4,521 ft agl · 268 kt
Info Autopilot Airspeed Hold Activated 4,646 ft agl · 271 kt
Info Autopilot Vertical Hold Activated 4,646 ft agl · 271 kt
Info Autopilot RPM Hold Deactivated 4,646 ft agl · 271 kt
Info Autopilot Airspeed Hold Deactivated 10,054 ft agl · 291 kt
Info Autopilot Vertical Hold Deactivated 10,054 ft agl · 291 kt
Info Autopilot RPM Hold Activated 10,054 ft agl · 291 kt
Info Landing Lights Switched Off 10,520 ft agl · 347 kt
Info Taxi Lights Switched Off 10,552 ft agl · 350 kt
Info Autopilot Airspeed Hold Activated 35,079 ft agl · 512 kt
Info Autopilot Vertical Hold Activated 35,079 ft agl · 512 kt
Info Autopilot RPM Hold Deactivated 35,079 ft agl · 512 kt
Enroute Level 100.00Enroute level cruise started Latitude: 31.6764072 Longitude: 124.297355 and lasted 66 minutes, covering 599 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,260 ft of 35,171 ft asl35,065 ft asl min to max 35,272 ft asl 35,209 35,272 ft asl
100 % Average speed 294 kt292 kt min to max 296 kt 296 295 kt
100 % Steepest bank angle 27.1 °0.0 ° min to max 27.1 ° 4.6 0.0 °
100 % Average g force 1.02 g0.93 g min to max 1.18 g 1.00 1.03 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 3.4 °2.7 ° min to max 4.5 ° 3.3 3.2 °

Events

Info Autopilot Heading Hold Deactivated 35,071 ft agl · 509 kt
Info Autopilot Heading Hold Activated 35,070 ft agl · 509 kt
Info Autopilot Airspeed Hold Deactivated 35,230 ft agl · 507 kt
Info Autopilot Vertical Hold Deactivated 35,230 ft agl · 507 kt
Info Autopilot RPM Hold Activated 35,230 ft agl · 507 kt
Enroute Climb 2 100.00Enroute climb started Latitude: 27.358989 Longitude: 133.5509229. Climbing from 35,347 ft asl to 37,049 ft asl, an increase of 1,702 ft in 2 minutes and covering 15 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 290 kt285 kt min to max 296 kt 296 286 kt
100 % Steepest bank angle 2.0 °0.0 ° min to max 2.0 ° 0.0 0.1 °
100 % Average g force 0.99 g0.88 g min to max 1.05 g 1.05 1.02 g
Info Average VSI 990 fpm-118 fpm min to max 1,357 fpm 902 -118 fpm
Info Average altitude 36,309 ft asl35,347 ft asl min to max 37,083 ft asl 35,347 37,049 ft asl
Info Average pitch angle 4.4 °3.0 ° min to max 5.1 ° 4.4 3.7 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Airspeed Hold Activated 36,928 ft agl · 509 kt
Info Autopilot RPM Hold Deactivated 36,928 ft agl · 509 kt
Info Autopilot Vertical Hold Activated 36,951 ft agl · 509 kt
Enroute Level 2 100.00Enroute level cruise started Latitude: 27.1325585 Longitude: 133.7291016 and lasted 104 minutes, covering 878 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,353 ft of 36,974 ft asl36,879 ft asl min to max 37,275 ft asl 37,066 37,275 ft asl
100 % Average speed 282 kt262 kt min to max 287 kt 286 283 kt
100 % Steepest bank angle 25.1 °0.0 ° min to max 25.1 ° 2.6 0.2 °
100 % Average g force 1.00 g0.94 g min to max 1.16 g 0.94 1.01 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 3.7 °3.1 ° min to max 5.2 ° 3.4 4.6 °

Events

Info Autopilot Airspeed Hold Deactivated 37,082 ft agl · 497 kt
Info Autopilot Vertical Hold Deactivated 37,082 ft agl · 497 kt
Info Autopilot RPM Hold Activated 37,082 ft agl · 497 kt
Enroute Climb 3 100.00Enroute climb started Latitude: 15.4027421 Longitude: 143.0148123. Climbing from 37,455 ft asl to 38,871 ft asl, an increase of 1,417 ft in 2 minutes and covering 14 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 277 kt271 kt min to max 282 kt 282 271 kt
100 % Steepest bank angle 1.9 °0.0 ° min to max 1.9 ° 1.0 0.2 °
100 % Average g force 0.99 g0.93 g min to max 1.02 g 1.01 1.01 g
Info Average VSI 850 fpm-273 fpm min to max 1,128 fpm 1,126 175 fpm
Info Average altitude 38,301 ft asl37,455 ft asl min to max 38,874 ft asl 37,455 38,871 ft asl
Info Average pitch angle 4.7 °4.0 ° min to max 5.0 ° 4.8 4.4 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Airspeed Hold Activated 38,762 ft agl · 501 kt
Info Autopilot Vertical Hold Activated 38,762 ft agl · 501 kt
Info Autopilot RPM Hold Deactivated 38,762 ft agl · 501 kt
Enroute Level 3 100.00Enroute level cruise started Latitude: 15.2076138 Longitude: 143.1890851 and lasted 73 minutes, covering 601 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,444 ft of 38,873 ft asl38,837 ft asl min to max 38,914 ft asl 38,878 38,870 ft asl
100 % Average speed 271 kt270 kt min to max 271 kt 271 270 kt
100 % Steepest bank angle 24.9 °0.0 ° min to max 24.9 ° 0.3 0.2 °
100 % Average g force 1.00 g0.80 g min to max 1.22 g 1.00 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 4.0 °2.7 ° min to max 6.1 ° 4.1 3.9 °
Enroute Climb 4 100.00Enroute climb started 54 miles north of PTHO Houk Airport Houk (State of Chuuk, Micronesia). Climbing from 38,870 ft asl to 40,865 ft asl, an increase of 1,995 ft in 3 minutes and covering 29 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 267 kt259 kt min to max 272 kt 270 259 kt
100 % Steepest bank angle 2.5 °0.0 ° min to max 2.5 ° 1.0 1.7 °
100 % Average g force 1.00 g0.95 g min to max 1.05 g 1.02 1.00 g
Info Average VSI 549 fpm-319 fpm min to max 1,060 fpm 12 257 fpm
Info Average altitude 39,730 ft asl38,870 ft asl min to max 40,869 ft asl 38,870 40,865 ft asl
Info Average pitch angle 4.7 °3.6 ° min to max 5.4 ° 4.1 4.9 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Airspeed Hold Deactivated 39,005 ft agl · 496 kt
Info Autopilot Vertical Hold Deactivated 39,005 ft agl · 496 kt
Info Autopilot RPM Hold Activated 39,005 ft agl · 496 kt
Info Autopilot Airspeed Hold Activated 40,780 ft agl · 498 kt
Info Autopilot RPM Hold Deactivated 40,780 ft agl · 498 kt
Info Autopilot Vertical Hold Activated 40,793 ft agl · 498 kt
Enroute Level 4 100.00Enroute level cruise started 42 miles north east of PTHO Houk Airport Houk (State of Chuuk, Micronesia) and lasted 381 minutes, covering 3,215 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,544 ft of 40,993 ft asl40,821 ft asl min to max 41,168 ft asl 40,874 40,833 ft asl
100 % Average speed 257 kt255 kt min to max 260 kt 259 255 kt
100 % Steepest bank angle 24.6 °0.0 ° min to max 24.6 ° 1.5 1.4 °
100 % Average g force 1.00 g0.88 g min to max 1.17 g 0.99 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 4.0 °2.8 ° min to max 5.1 ° 4.4 3.4 °
Enroute Descent 100.00Enroute descent started 18 miles south of Karamea (West Coast, New Zealand). Descent from 40,818 ft asl to 1,378 ft asl, a decrease of 39,440 ft in 20 minutes and covering 129 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 241 kt175 kt min to max 370 kt 254 175 kt
100 % Steepest bank angle 27.8 °0.0 ° min to max 27.8 ° 2.1 0.4 °
99.96 % Average g force 1.02 g0.67 g min to max 1.30 g 1.02 1.11 g
Info Average VSI -1,584 fpm-3,385 fpm min to max 389 fpm -267 -1,130 fpm
Info Average altitude 10,846 ft asl1,378 ft asl min to max 40,836 ft asl 40,818 1,378 ft asl
Info Average pitch angle -0.3 °-4.0 ° min to max 6.0 ° 3.4 0.1 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Airspeed Hold Deactivated 31,713 ft agl · 498 kt
Info Autopilot Mach Hold Activated 31,713 ft agl · 498 kt
Info Autopilot Mach Hold Deactivated 31,946 ft agl · 498 kt
Info Autopilot Airspeed Hold Activated 11,432 ft agl · 384 kt
Info Landing Lights Switched On 9,857 ft agl · 285 kt
Info Taxi Lights Switched On 9,741 ft agl · 284 kt
Info Flaps Position 1 3,317 ft agl · 218 kt
Info Flaps Position 2 3,154 ft agl · 212 kt
Info Autopilot Approach Mode Activated 2,004 ft agl · 194 kt
Info Autopilot Heading Hold Deactivated 1,994 ft agl · 195 kt
Info Flaps Position 3 1,950 ft agl · 195 kt
Info Landing Gear Down 1,907 ft agl · 188 kt
Info Autopilot Vertical Hold Deactivated 1,848 ft agl · 187 kt
Info Flaps Position 4 1,643 ft agl · 185 kt
Arrival Approach 100.00Final approach to runway 02 at NZCH Christchurch International Airport. Descent from 1,333 ft agl to 77 ft agl in 102 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates

Events

Fail GPWS Warning Activated 870 ft agl · 148 kt
Info Flaps Position 5 969 ft agl · 155 kt
Info Flaps Position 6 941 ft agl · 153 kt
Info GPWS Warning Deactivated 876 ft agl · 149 kt
Info Autopilot AutoThrottle Arm Disarmed 804 ft agl · 148 kt
Info Autopilot Master Switched Off 783 ft agl · 146 kt
Arrival Landing 99.89Landing on runway 02 at NZCH Christchurch International Airport, runway length 3,283 m. Good threshold height. Threshold speed was good at 145 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 145 kt. Target 139 kt
100 % Good threshold height.Target 50 ft agl
99.5 % Excellent landing flare. It lost 0.5 points, for 320 fpm of sink coming back after the flare.
100 % Runway alignment max 2.72 m left2.72 m left to 2.21 m left 2.72 2.21 m
100 % Steepest bank angle 0.7 °0.0 ° min to max 0.7 ° 0.6 0.0 °
100 % Peak g force 1.10 g0.90 g min to max 1.10 g 1.04 1.04 g
Info Average speed 143 kt141 kt min to max 145 kt 145 141 kt
Info Average VSI -378 fpm-596 fpm min to max -245 fpm -596 -287 fpm
Info Average altitude 22 ft agl0 ft agl min to max 47 ft agl 47 0 ft agl
Info Average pitch angle 4.5 °3.5 ° min to max 5.2 ° 3.7 4.8 °
07515022530037545052560067501123344657Runway Distance mLanding Height ft075150225300375450525600675-20-16-12-8-4048121620Runway Distance mRunway Width m
Arrival Touchdown 97.88Touchdown point was 171 m beyond the touchdown zone. Touchdown speed at 141 kt was a little fast. Touchdown rate was fair at -241 fpm. Runway touchdown alignment was very good. Local weather - Temperature 17 °C. Wind 8 kt at 70 °. Crosswind: 4 kt Headwind: 7 kt.
ScoreDescriptionStartProfileEnd
100 % Touchdown rate was -241 fpm.
86 % Touchdown distance was 586 mTarget 457 m
100 % Speed at touchdown 141 ktTarget below 139 kt
100 % Runway alignment max 2.21 m left2.08 m left 2.21 1.90 m
100 % Steepest bank angle 0.7 °0.0 ° min to max 0.7 ° 0.0 0.4 °
100 % Peak g force 1.12 g1.00 g min to max 1.12 g 1.04 1.07 g
100 % Landing Bounce
Info Average speed 141 kt140 kt min to max 141 kt 141 140 kt
Info Average pitch angle 4.9 °4.8 ° min to max 5.1 ° 4.8 5.1 °
Arrival Rollout 100.00Total landing distance 1,486 m, 45 % of runway. Runway rollout alignment was very good.
ScoreDescriptionStartProfileEnd
100 % Landing distance 1,486 m45 % of runway.
100 % Runway alignment max 3.62 m right0.00 m left to 3.62 m right -3.62 -2.51 m
100 % Average g force 1.01 g0.95 g min to max 1.07 g 1.07 1.01 g
Info Average speed 123 kt73 kt min to max 134 kt 134 73 kt
Info Average pitch angle 3.6 °-0.7 ° min to max 5.2 ° 5.1 -0.7 °
Info Average bank angle 1.5 °0.0 ° min to max 2.8 ° 0.6 0.1 °
Runway Exit Exiting runway, average speed 26 kt
ScoreDescriptionStartProfileEnd
Info Average speed 18 kt5 kt min to max 64 kt 64 5 kt
Info Average pitch angle -0.9 °-1.4 ° min to max -0.6 ° -0.6 -1.0 °
Info Average bank angle 0.1 °0.0 ° min to max 0.3 ° 0.0 0.3 °
Info Average g force 1.00 g0.99 g min to max 1.00 g 1.00 1.00 g

Events

Info Flaps Fully Retracted 15 ft agl · 23 kt
Info Landing Lights Switched Off 15 ft agl · 22 kt
Info Strobe Lights Switched Off 15 ft agl · 22 kt
Arrival Taxi 100.00Taxiing to the parking from the runway took 6 minutes and covered 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 12 kt0 kt min to max 21 kt 4 3 kt
100 % Average speed turning corners 11 ktmax 11 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle -0.6 °-1.2 ° min to max 0.3 ° -1.1 -0.4 °
Info Average bank angle 0.2 °0.0 ° min to max 1.4 ° 0.3 0.0 °

Takeoff from ZSPD 34L

Taxi out

LightsOk
All on
Taxi speed100.00
21kt peak12 kt in turns

The roll

Takeoff roll100.00
1,769m47 %
Runway alignment100.00
2.04m R
Rotation speed100.00
157kttarget 156, 1 late

On speed, but the nose came up quickly

Rotation started at 157 kt, 1 kt after the 156 kt rotate speed. The nose then rose at 3.5° a second, faster than the 2 to 3° a second airliners use.

The rotation started on speed but the nose came up quickly. A fast pull raises the nose faster than the aircraft can lift off, which brings the tail closer to the runway. Pull smoothly at the normal rate for this aircraft and let it fly off at its own attitude.

Liftoff and climb

Liftoff
164ktat 8.8°
Rotation
3.5°/sover 2.6 s, gaining 7 kt
35 ft
174ktat 9.7°, 3.0 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
3.3°steepest
Gear up100.00
87ftfull marks to 400 ft
Climb 3 speed100.00
214kttarget 202

Plan view the roll down the 3,803 m runway.

Rolled from 119 m in, drifted right of the centreline, 1.9 m at the widest, and lifted off 2 m right, in 5 kn of crosswind from the right. Airborne 46 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

1,0002,0003,000THRESHOLDLEFT ↑RIGHT ↓CROSS5 kn75 %widest 1.94 m RROLL 119 M INAirborne 1,774 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,774 m of 3,803 m · 47 %
Behind the start of the roll, 119 mTakeoff roll, 1,655 m Left ahead, 2,029 m

Side view from the start of the roll to the end of Climb 3 at 944 ft.

Reached 35 ft with 1,765 m of runway left; gear up at 87 ft, inside the 400 ft that gets full marks; then climbing at 1,830 fpm on average to 944 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3214 kt avgtarget 202THRESHOLDRUNWAY END6080100120140KNOTS ALONG THE ROLLnose up on the runway · 216 m · 2.6 sRotate 157 kttarget 156Liftoff 164 ktGear up 87 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 202240 kt16080020°10°0°nose up on the runway · 216 m · 2.6 sROTATELIFTOFFGEAR UPtarget 156held 10.1°8.8° off · 3.5°/s10° at 35 ftAIRSPEEDPITCH0204060 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2 to 3° a second, the rates airliners are rotated at: a trace steeper than both is a faster rotation, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 12.1°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 12.1°ROTATELIFTOFF35 FT8.8° off · 3.5°/s3°/s2°/s10° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5+6 sseconds from rotation
PitchRotation began2 to 3°/s from rotationTail strikeNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate950 fpm930 fpm
On glideslope2.7°2.8°
On centreline0.2° off0.2° off
On speed+11 kt+3.2 kt
Wings level0° bank1° bank

When the approach was stable

Every check met from 3.8 nm, about 1,220 ft above the runway, to the threshold, before the 1,000 ft gate, so through both gates. The last to settle was the speed.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to NZCH 02

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 120 ft below the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,3046803071701,000 ft gate7 of 7932 ft · 150 kt500 ft gate7 of 7497 ft · 142 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 4× larger than distances along the final.

Inside the 1° band all the way from 4 nm, never more than 87 m off the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR219 m L0219 m RLEFT ↑RIGHT ↓1° BAND87 m R16 m L2 m L1 m R24 m R11 m L
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 35 kt fast at the 1,000 ft gate, closing to 21 at 500 ft and 10 at the threshold.

Fast from 4 nm to 3.8 nm (up to +37 kt), then inside the band to the threshold.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

140160180200 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 139+37 kt+3 kt+3 kt+6 kt+6 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on NZCH 02

Over the threshold

Threshold height100.00
47ft
Threshold speed100.00
145kttarget 139, 6 fast
Centreline offset100.00
2.72m L
Bank100.00
0.7°steepest
Flare99.55

Excellent landing flare

It lost 0.5 points, for 320 fpm of sink coming back after the flare.

Touchdown

Past threshold85.86
586m
Centreline100.00
2.21m L
Speed100.00
141kttarget 139, 2 fast
Touchdown rate100.00
-241fpm
Impact100.00
1.12G
BouncesOk
None
Bank100.00
0.7°as the wheels touched

Rollout

Rollout distance100.00
859m44 % used
Rollout alignment100.00
3.62m R

Taxi in

LightsOk
All set
Taxi speed100.00
21kt peak11 kt in turns

Side view — the last 1,567 m of the approach.

Crossed the threshold at 47 ft, close to the 50 ft target; began the flare at 41 ft. Touched down 586 m in, 282 m past the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,567 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

47 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 41 ft · −439 fpm · 4.2° · 145 ktdescent slowed at 0 ft · −121 fpm · 4.8°−241 fpm · 4.8° nose up · 141 kt Ideal — 50 ft, down at 305 m This flight — 47 ft, down at 586 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 440 fpm at the flare to 240 fpm at touchdown. The nose came up 0.7° on the way down. Into the flare at 145 kt, 6 kt over the 139 kt approach speed, and 141 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−241 fpm at touchdown4.8° at touchdown, +0.7° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,567 m of the 3,283 m runway, to the same scale as the side view.

Touched down 1.9 m left of the centreline, and stayed within 2.8 m of it down the rollout. 4 kt across from the right, which takes about 2° of crab to hold the centreline at 141 kt. Touched down with 2° of it still on, wings level.

Wind 070° at 8 kt · 7 kt head · 4 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ CROSS 4 kn FULL SCORE TO 503 M 586 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

Touched down 586 m past the threshold — beyond the full-score zone. The arrival was smooth.

Runway used 1,445 m of 3,283 m · 44 %
In the air over the runway, 586 mRollout, 859 m Left over, 1,838 m

The stop — touchdown to taxi speed.

From 135 kt at touchdown to taxi speed (30 kt) in 22 s, an average deceleration of 0.26 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 967 m30 kt · 1,050 mtouchdown1,093 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Flight narrative

The Boeing 747-8 flight began at ZSPD Pudong in Shanghai, China. The taxi from the parking area to the runway lasted 8 minutes, covering 2 nm. The departure took place on runway 34L with a takeoff distance of 5,387 ft, equivalent to 43% of the runway length. The liftoff speed was 165 knots. The local weather at the time of departure was 74°F with a wind of 7 knots at 30°, resulting in a 5-knot crosswind and a 5-knot headwind.

The initial enroute climb started 1 mile northeast of the airport, climbing from 1,030 ft to 35,195 ft, a total increase of 34,165 ft in 20 minutes, covering 124 nm. The next enroute level cruise started at a specific latitude and longitude point and lasted 66 minutes, covering 548 nm.

Further enroute climbs and descents occurred at different points, with details provided for each climb and corresponding level cruise segments. The flight eventually descended near Murchison, New Zealand, from 40,833 ft to 2,256 ft in 18 minutes, covering 120 nm.

The final approach and landing took place on runway 02 at NZCH Christchurch Intl, with an approach height of 48 ft agl and a speed of 145 knots at threshold. The touchdown occurred 1,952 ft from the threshold at a speed of 141 knots, with a vertical speed indicator reading of -287 ft/m. The total landing distance was 4,906 ft, equivalent to 45% of the runway length. The local weather at the time of landing was 62°F with a wind of 8 knots at 70°, resulting in a 4-knot crosswind and a 7-knot headwind.

After landing, the aircraft taxied to the parking area, which took 7 minutes and covered less than 1 nm. In total, the flight covered a distance of 5,502 nm, lasting 686 minutes and consuming 243,774 lbs of fuel.

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
