My FS Flights logo MY FS FLIGHTS
LRUR
Urleta, Romania
Runway 23
Elevation1,204 ft asl
Weight2,119 kg
Fuel559 kg
Wind270° · 1 kn · 1 kn cross

Flight Score

88.15 %
LRPW
Romania
Runway 27
Elevation571 ft asl
Weight2,020 kg
Fuel459 kg
Wind269° · 1 kn
12 Feb 2024 0:18 35 nm Pilatus PC-6 100 kg
Departure Score
87.41 %
Enroute Score
88.96 %
Arrival Score
88.07 %

What went well

Touched down at -149 fpm — a soft arrival
Touchdown 154 m in — inside the full-score zone
Threshold crossed at 16 ft and 60 kt — both inside band

What held you back

Departure Roll — Runway alignment max 34.73 m left at 0 %, Strobe Lights at 0 %, −2.77 points
Enroute Descent — bank angle up to 71.7 ° at 37 %, g force 0.51 to 2.04 g at 86 %, −1.78 points
Arrival Taxi — Taxi Lights at 0 %, Landing Lights at 1 %, −1.55 points

Next time

Departure

Make small rudder corrections against a fixed point at the far end of the runway to hold the centreline during the roll.

What happened: The aircraft drifted 35 m off the runway centreline during the ground roll. In the climb that followed, bank angle reached 7.1° in the first segment and 10° in the second.

Watch for: Heading indicator: steady on the runway centreline during the roll, then wings level through the climb.

See Departure RollDeparture Climb 1Departure Climb 2

Arrival

Make small rudder corrections against a fixed point at the far end of the runway to stop the drift as soon as it starts in the flare.

What happened: On the landing you drifted 10 m off the centreline, and that kind of lateral drift usually carries through to a touchdown point 11 m off centreline and into a rollout that is still skewed off the runway centreline.

Watch for: Heading indicator: track straight down the extended runway centreline through touchdown and rollout.

See Arrival LandingArrival TouchdownArrival Rollout

A small uncorrected heading error at 40 knots becomes a metre of offset per second by 100 knots, noticed only at rotation, producing a crabbed liftoff. Root cause is nearly always eyes on the tape instead of the far end of the runway. Small heading changes displace a distant point visibly long before the nearby centreline stripes look wrong.

Read more in Improve Your Take-Offs

Start to finish · 17 stages, 14 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Runway Entry Entering runway 23 at LRUR Banesti, Average speed was 0 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 6 kt0 kt min to max 19 kt 0 19 kt
Info Average pitch angle 8.0 °7.7 ° min to max 8.7 ° 8.7 7.8 °
Info Average bank angle 0.1 °0.0 ° min to max 0.2 ° 0.0 0.0 °
Info Average g force 0.98 g0.96 g min to max 1.00 g 1.00 0.96 g

Events

Info Battery Master On 4 ft agl
Info Engine 1 Started 4 ft agl
Info Beacon Lights Switched On 4 ft agl
Info Landing Lights Switched On 4 ft agl
Info Navigation Lights Switched On 4 ft agl
Info Parking Brake On 4 ft agl
Info Flaps Position 1 4 ft agl
Info Parking Brake Off 4 ft agl · 1 kt
Info Parking Brake On 4 ft agl · 1 kt
Info Flaps Fully Retracted 4 ft agl · 1 kt
Info Flaps Position 1 4 ft agl · 1 kt
Info Parking Brake Off 4 ft agl · 1 kt
Departure Roll 66.79Departure roll runway 23 at LRUR Banesti. Takeoff distance 580 m 85 % of runway. Rotation speed was 72 kt. Local weather - Temperature 16 °C. Wind 1 kt at 270 °. Crosswind: 1 kt Headwind: 1 kt.
ScoreDescriptionStartProfileEnd
59 % Takeoff distance 580 m85 % of runway
100 % Rotation speed was 72 ktTarget 65 kt
0 % Runway alignment max 34.73 m left34.73 m left to 0.00 m left 13.43 34.73 m
100 % Average g force 0.97 g0.94 g min to max 1.01 g 0.96 1.01 g
100 % Takeoff Bounce
Info Average pitch angle 5.0 °1.5 ° min to max 8.0 ° 7.9 2.5 °
Info Average bank angle 1.3 °0.0 ° min to max 7.3 ° 0.2 7.2 °

Events

Fail Strobe Lights
Departure Climb 1 91.87Departure climb to 50 ft agl from runway 23 LRUR Banesti.
ScoreDescriptionStartProfileEnd
73 % Heading variation -2.5 °-3.4 ° min to max -1.5 ° -3.4 -1.5 °
100 % Average speed 78 kt74 kt min to max 80 kt 74 79 kt
94 % Steepest bank angle 7.1 °1.0 ° min to max 7.1 ° 7.1 1.7 °
100 % Average g force 1.10 g1.01 g min to max 1.18 g 1.01 1.02 g
Info Average VSI 743 fpm293 fpm min to max 1,085 fpm 293 1,085 fpm
Info Average altitude 19 ft agl0 ft agl min to max 62 ft agl 0 62 ft agl
Info Average pitch angle 7.9 °2.6 ° min to max 11.3 ° 2.6 11.3 °
Departure Climb 2 96.41Departure climb to 400 ft agl from 23 LRUR Banesti.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.5 °-1.4 ° min to max 1.6 ° -1.4 1.1 °
100 % Average speed 79 kt78 kt min to max 81 kt 79 81 kt
86 % Steepest bank angle 10.0 °0.6 ° min to max 10.0 ° 1.7 10.0 °
100 % Average g force 0.98 g0.94 g min to max 1.04 g 1.01 1.01 g
Info Average VSI 1,073 fpm726 fpm min to max 1,177 fpm 1,094 1,021 fpm
Info Average altitude 128 ft agl63 ft agl min to max 340 ft agl 63 340 ft agl
Info Average pitch angle 10.4 °7.9 ° min to max 11.2 ° 11.2 9.8 °
Departure Climb 3 94.56Departure climb to 1,000 ft agl from 23 LRUR Banesti.
ScoreDescriptionStartProfileEnd
86 % Climb speed 80 kt80 kt min to max 83 ktTarget 95 kt, 15 kt slow 81 83 kt
100 % Steepest bank angle 11.1 °7.1 ° min to max 11.1 ° 10.5 7.1 °
100 % Average g force 1.01 g0.86 g min to max 1.02 g 1.01 0.90 g
100 % Landing gear fixed
Info Heading variation 0.1 °-1.5 ° min to max 0.6 ° 0.6 -1.5 °
Info Average VSI 1,002 fpm403 fpm min to max 1,046 fpm 1,036 403 fpm
Info Average altitude 404 ft agl357 ft agl min to max 442 ft agl 357 442 ft agl
Info Average pitch angle 9.5 °3.7 ° min to max 9.9 ° 9.8 3.7 °
Enroute Climb 100.00Enroute climb started overhead Floresti (Prahova, Romania). Climbing from 1,647 ft asl to 4,388 ft asl, an increase of 2,741 ft in 4 minutes and covering 7 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 107 kt79 kt min to max 132 kt 84 132 kt
100 % Steepest bank angle 14.4 °0.0 ° min to max 14.4 ° 5.7 0.8 °
99.95 % Average g force 1.01 g0.82 g min to max 1.36 g 0.92 0.99 g
Info Average VSI 868 fpm-730 fpm min to max 1,616 fpm 232 280 fpm
Info Average altitude 2,673 ft asl1,647 ft asl min to max 4,388 ft asl 1,647 4,388 ft asl
Info Average pitch angle 6.0 °-2.8 ° min to max 11.0 ° 2.7 1.4 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Fully Retracted 854 ft agl · 91 kt
Enroute Descent 97.13Enroute descent started 1 mile east of Aricestii-Rahtivani (Prahova, Romania). Descent from 4,409 ft asl to 2,484 ft asl, a decrease of 1,925 ft in 3 minutes and covering 7 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 145 kt119 kt min to max 168 kt 135 145 kt
95 % Steepest bank angle 42.6 °0.5 ° min to max 42.6 ° 0.6 14.2 °
92 % Average g force 1.06 g-0.03 g min to max 1.70 g 1.04 1.00 g
Info Average VSI -632 fpm-6,223 fpm min to max 3,291 fpm 137 -916 fpm
Info Average altitude 3,485 ft asl2,313 ft asl min to max 4,523 ft asl 4,409 2,484 ft asl
Info Average pitch angle -2.1 °-23.9 ° min to max 13.7 ° 0.7 -3.3 °
Info Turn coordination 00 min to max 0 0 0
Enroute Level 84.95Enroute level cruise started 1 mile west of Paulesti (Prahova, Romania) and lasted 3 minutes, covering 3 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±624 ft of 2,236 ft asl2,059 ft asl min to max 2,689 ft asl 2,484 2,292 ft asl
100 % Average speed 146 kt115 kt min to max 161 kt 145 161 kt
66 % Steepest bank angle 56.8 °0.0 ° min to max 56.8 ° 14.2 2.0 °
84 % Average g force 1.28 g0.10 g min to max 1.54 g 1.00 1.11 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle -0.6 °-14.2 ° min to max 6.9 ° -3.3 -7.4 °
Enroute Descent 2 73.25Enroute descent started 1 mile south of Paulesti (Prahova, Romania). Descent from 2,262 ft asl to 1,242 ft asl, a decrease of 1,020 ft in 2 minutes and covering 2 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 145 kt129 kt min to max 176 kt 162 130 kt
37 % Steepest bank angle 71.7 °0.1 ° min to max 71.7 ° 2.2 71.0 °
86 % Average g force 1.32 g0.51 g min to max 2.04 g 1.14 1.84 g
Info Average VSI -1,675 fpm-3,588 fpm min to max 1,149 fpm -1,918 -1,658 fpm
Info Average altitude 1,560 ft asl1,242 ft asl min to max 2,262 ft asl 2,262 1,242 ft asl
Info Average pitch angle -11.1 °-21.4 ° min to max 1.2 ° -6.4 -21.4 °
Info Turn coordination 00 min to max 0 0 0
Enroute Level 2 89.46Enroute level cruise started overhead Ploiesti (Prahova, Romania) and lasted 5 minutes, covering 2 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±560 ft of 1,036 ft asl944 ft asl min to max 1,191 ft asl 1,191 1,128 ft asl
100 % Average speed 132 kt126 kt min to max 138 kt 130 126 kt
74 % Steepest bank angle 52.9 °0.9 ° min to max 52.9 ° 52.9 27.7 °
98 % Average g force 1.12 g0.17 g min to max 2.27 g 1.88 0.77 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 1.5 °-20.7 ° min to max 11.4 ° -20.7 0.2 °
Go-around Go-Around runway 27 at LRPW Gheorghe Valentin Bibescu at 209 ft agl.
ScoreDescriptionStartProfileEnd
100 % Average speed 116 kt18 kt min to max 140 kt 140 78 kt
0 % Steepest bank angle 179.5 °0.1 ° min to max 179.5 ° 11.3 2.9 °
96 % Average g force 1.10 g0.02 g min to max 3.59 g 2.01 1.03 g
Info Average altitude 720 ft agl173 ft agl min to max 1,215 ft agl 209 504 ft agl
Info Average pitch angle 0.5 °-72.0 ° min to max 83.7 ° 6.0 -2.3 °

Events

Info Flaps Position 1 757 ft agl · 117 kt
Arrival Approach 80.00Final approach to runway 27 at LRPW Gheorghe Valentin Bibescu. Descent from 639 ft agl to 18 ft agl in 101 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed
100 % Landing flappassed
100 % Sink ratepassed
100 % On glideslopepassed
0 % On speedfailed

Events

Info Flaps Position 2 122 ft agl · 87 kt
Arrival Landing 97.89Landing on runway 27 at LRPW Gheorghe Valentin Bibescu, runway length 938 m. Good threshold height. Threshold speed was good at 61 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 61 kt. Target 61 kt
100 % Good threshold height.Target 50 ft agl
100 % Perfect landing flare
95 % Runway alignment max 10.14 m left10.14 m left to 1.55 m right -1.55 10.14 m
84 % Steepest bank angle 8.0 °0.0 ° min to max 8.0 ° 8.0 1.5 °
100 % Peak g force 1.10 g0.97 g min to max 1.10 g 1.10 0.97 g
Info Average speed 56 kt52 kt min to max 61 kt 61 52 kt
Info Average VSI -254 fpm-478 fpm min to max -124 fpm -478 -142 fpm
Info Average altitude 8 ft agl3 ft agl min to max 17 ft agl 17 3 ft agl
Info Average pitch angle 5.9 °4.1 ° min to max 7.5 ° 4.3 5.6 °
07515001223354658Runway Distance mLanding Height ft075150-15-12-9-6-303691215Runway Distance mRunway Width m
Arrival Touchdown 95.17Touchdown distance was good at 154 m. Touchdown speed at 52 kt was a little fast. Touchdown rate was smooth at -149 fpm. Runway touchdown position was misaligned by 11.4 m from centreline. Local weather - Temperature 15 °C. Wind 1 kt at 270 °. Crosswind: 0 kt Headwind: 1 kt.
ScoreDescriptionStartProfileEnd
97 % Touchdown rate was -149 fpm.
100 % Touchdown distance was 154 mTarget 457 m
100 % Speed at touchdown 52 ktTarget below 52 kt
71 % Runway alignment max 11.39 m left10.76 m left 10.14 11.39 m
100 % Steepest bank angle 1.5 °0.1 ° min to max 1.5 ° 1.5 0.1 °
100 % Peak g force 1.18 g0.93 g min to max 1.18 g 0.97 1.15 g
100 % Landing Bounce
Info Average speed 52 kt51 kt min to max 52 kt 52 51 kt
Info Average pitch angle 7.1 °5.6 ° min to max 8.5 ° 5.6 8.3 °
Arrival Rollout 90.47Total landing distance 326 m, 35 % of runway. Runway rollout alignment was slightly misaligned by 9.4 m from centreline.
ScoreDescriptionStartProfileEnd
100 % Landing distance 326 m35 % of runway.
79 % Runway alignment max 9.42 m left9.42 m left to 0.00 m left 9.24 9.42 m
100 % Average g force 1.02 g0.98 g min to max 1.13 g 1.13 1.03 g
Info Average speed 58 kt35 kt min to max 62 kt 62 35 kt
Info Average pitch angle 6.7 °3.9 ° min to max 8.3 ° 8.3 7.6 °
Info Average bank angle 0.5 °0.0 ° min to max 1.4 ° 0.0 0.6 °
Runway Exit Exiting runway, average speed 5 kt
ScoreDescriptionStartProfileEnd
Info Average speed 20 kt15 kt min to max 28 kt 28 21 kt
Info Average pitch angle 7.8 °7.0 ° min to max 8.0 ° 7.5 7.0 °
Info Average bank angle 0.3 °0.0 ° min to max 0.7 ° 0.1 0.3 °
Info Average g force 0.99 g0.98 g min to max 1.04 g 1.03 0.99 g

Events

Info Flaps Position 1 4 ft agl · 16 kt
Info Flaps Fully Retracted 4 ft agl · 21 kt
Arrival Taxi 76.80Taxiing to the parking from the runway took 1 minutes and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 21 kt9 kt min to max 22 kt 21 9 kt
67 % Average speed turning corners 20 ktmax 21 kt 0 0 kt
100 % Average g force 0.99 g0.97 g min to max 1.05 g 0.98 1.05 g
Info Average pitch angle 7.7 °6.9 ° min to max 8.2 ° 6.9 7.2 °
Info Average bank angle 0.2 °0.0 ° min to max 1.2 ° 0.3 0.1 °

Events

Fail Landing Lights
Fail Taxi Lights

Takeoff from LRUR 23

Taxi out

Lights50.00
Offstrobes

The roll

Takeoff roll59.11
580m85 %
Runway alignment0.00
34.73m L
Rotation speed100.00
72kttarget 65, 7 late

Rotated late

Rotation started at 72 kt, 7 kt after the 65 kt rotate speed.

The pull started after the rotate speed had gone by. Bring the airspeed into the scan as it approaches the rotate speed, so the pull starts on the number rather than when you notice it has passed.

Liftoff and climb

Liftoff
73ktat 2.6°
35 ft
80ktat 10.8°, 4.4 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff94.15
7.1°steepest
Climb 3 speed86.41
80kttarget 95

Plan view the roll down the 681 m runway.

Rolled from 79 m in, drifted left of the centreline, 35 m at the widest, and lifted off 35 m left. Airborne 86 % of the way down the runway, past the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length.

100200300400500600THRESHOLDLEFT ↑RIGHT ↓75 %widest 34.73 m LROLL 79 M INAirborne 583 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 583 m of 681 m · 86 %
Behind the start of the roll, 79 mTakeoff roll, 504 m Left ahead, 98 m

Side view from the start of the roll to the end of Climb 3 at 442 ft. The distance scale changes past the runway end.

Reached 35 ft 102 m past the runway end; then climbing at 350 fpm on average to 442 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The shaded stretch is Climb 3, scored on its average speed against the target.

500 ft250 ft0CLIMB 380 kt avgtarget 95THRESHOLDRUNWAY END30405060KNOTS ALONG THE ROLLnose up on the runway · 22 m · 0.5 sRotate 72 kttarget 65Liftoff 73 ktSCALE CHANGES1.3 km past the runway
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figure at liftoff is the pitch then. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 9590 kt6030020°10°0°nose up on the runway · 22 m · 0.5 sROTATELIFTOFFtarget 65held 10.2°2.6° off11° at 35 ftAIRSPEEDPITCH0306090 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

The stabilisation gates

One stabilised approach gate: five checks where the approach path is 500 ft above the runway. The 1,000 ft gate was not assessed, because the approach did not join final that far out. These checks are the approach's score.

Five checks, one gate500 ft 80.004 of 5
Gear down
Landing flap
Sink rate630 fpm
On glideslope3.4°
On speed+39 kt

At the 500 ft gate: speed more than 18 kt above the approach speed of 61 kt.

Still turning onto final at the lower gate, so the centreline and wings level are not asked there - the aeroplane was not lined up yet, and was banked because it was turning. The other checks are marked as usual.

When the approach was stable

Never every check met at once: fast all the way, banked until 1.4 nm, left of the centreline from 1.4 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Landing flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to LRPW 27

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 2° band in green.

Inside the glideslope band from 1.7 nm, where the final began, to the threshold, never more than 110 ft above the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,0002,500 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 2° BAND363247500 ft gate4 of 5on speed627 ft · 100 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 3× larger than distances along the final.

Joined 325 m right of the centreline at 1.7 nm, then 76 m left of it from 1.4 nm to the threshold.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR305 m L0305 m RLEFT ↑RIGHT ↓1° BAND67 m L18 m L65 m R
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 31 kt fast at the 1,000 ft gate, closing to 18 at 500 ft and 10 at the threshold.

Fast from 1.7 nm, where the final began, to the threshold (up to +50 kt).

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

6080100120 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 61+25 kt+22 kt−0 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on LRPW 27

Over the threshold

Threshold height100.00
16ft
Threshold speed100.00
60kttarget 61, 1 slow
Centreline offset94.82
10.14m L
Bank84.09
8.0°steepest
Flare100.00

Perfect landing flare

Touchdown

Past threshold100.00
154m
Centreline71.40
11.39m L
Speed100.00
52kttarget 52 or less
Touchdown rate97.29
-149fpm
Impact100.00
1.18G
BouncesOk
None
Bank100.00
1.5°as the wheels touched

Rollout

Rollout distance100.00
158m33 % used
Rollout alignment78.83
9.42m L

Taxi in

Lights0.50
Wrongtaxi lights off, landing lights on
Taxi speed83.44
22kt peak20 kt in turns

Side view — the last 938 m of the approach.

Began the flare at 25 ft, 42 m before the threshold; crossed the threshold at 16 ft, 34 ft below the 50 ft target. Touched down 154 m in, 151 m short of the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 938 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

16 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare began at 25 ft, 42 m before the threshold−663 fpm · 3° · 62 ktdescent slowed at 3 ft · −96 fpm · 7.1°−149 fpm · 5.6° nose up · 52 kt Ideal — 50 ft, down at 305 m This flight — 16 ft, down at 154 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 660 fpm at the flare to 150 fpm at touchdown. The nose came up 2.7° on the way down. Into the flare at 62 kt, on the 61 kt approach speed, and 52 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°descent slowedtouchdown−149 fpm at touchdown5.6° at touchdown, +2.7° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the full 938 m runway, to the same scale as the side view.

Touched down 11 m left of the centreline, and stayed about there down the rollout, 12 m left at the widest. No crosswind: nothing to correct for. Touched down with the nose 5° right of the track, wings level.

Wind 269° at 1 kt · 1 kt head · 0 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

500 THRESHOLD LEFT ↑ RIGHT ↓ FULL SCORE TO 503 M 154 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

The 154 m touchdown sits inside the full-score zone. The arrival was smooth.

Runway used 312 m of 938 m · 33 %
In the air over the runway, 154 mRollout, 158 m Left over, 627 m

The stop — touchdown to taxi speed.

From 63 kt at touchdown to taxi speed (30 kt) in 8 s, an average deceleration of 0.22 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

02040608060 kt · 49 m30 kt · 189 mtouchdown197 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
