LBSF
Sofia, Bulgaria
Runway 27
Elevation1,739 ft asl
Weight42,470 kg
Fuel6,052 kg
Wind210° · 6 kn · 5 kn cross

Flight Score

93.36 %
EDDF
Frankfurt am Main, Germany
Runway 25L
Elevation338 ft asl
Weight37,913 kg
Fuel1,370 kg
Wind90° · 3 kn · 1 kn cross
27 Oct 2024 2:47 951 nm Embraer E190 4,682 kg
Departure Score
99.41 %
Enroute Score
99.33 %
Arrival Score
81.34 %

What went well

Flare on profile — 90 %
1.29 G at touchdown — inside band
Rollout controlled — 33 % of the runway used

What held you back

Arrival Approach — GPWS warning; 500 ft gate 67 %, −2.22 points
Arrival Landing — GPWS warning; Threshold height at 92 ft agl was significantly above target at 17 %, Runway alignment max 13.09 m left at 76 %, −2.06 points
Arrival Touchdown — Touchdown rate was -405 fpm at 65 %, Touchdown distance was 681 m at 75 %, −0.90 points

Next time

Departure

Make small rudder corrections against a point at the far end to hold the centreline.

What happened: During the ground roll you drifted 10 m off the runway centreline.

Watch for: Watch runway alignment against the centreline, correcting with small rudder inputs.

See Departure Roll

Arrival

Be established on the glideslope by the gate, and take the power back earlier on final so the height and the speed come back together. Do not push down for the height: that only adds speed.

What happened: The approach was off the glideslope at the gate, and the aircraft then crossed the threshold at 92 ft agl, 42 ft agl above the 50 ft agl target, and at 139 kt, 17 kt over the 122 kt threshold speed. High and fast together is energy the runway has to absorb, and this touchdown came 224 m beyond the aim point.

Watch for: Glideslope indication at the gate, then airspeed: 122 kt on short final

See Arrival ApproachArrival LandingArrival Touchdown

Preparing for a stable approach will give you time to decide on whether to attempt the landing or going around. Too much altitude with a high sink rate will result in carrying too much speed onto the runway. Configuring flaps and the gear late also won't help the speed decay.

Read more in The Stabilised Approach

Start to finish · 18 stages, 16 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 9 minutes and covered 2 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 15 kt0 kt min to max 28 kt 3 1 kt
100 % Average speed turning corners 6 ktmax 11 kt 0 1 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle -1.1 °-1.4 ° min to max -0.6 ° -1.1 -1.4 °
Info Average bank angle 0.1 °0.0 ° min to max 0.4 ° 0.0 0.2 °

Events

Info Parking Brake On 7 ft agl · 5 kt
Info Engine 1 Started 7 ft agl · 5 kt
Info Flaps Position 1 7 ft agl · 5 kt
Info Flaps Position 2 7 ft agl · 5 kt
Info Taxi Lights Switched On 7 ft agl · 5 kt
Info Parking Brake Off 7 ft agl · 5 kt
Info Flaps Position 1 7 ft agl · 7 kt
Info Landing Lights Switched On 7 ft agl · 5 kt
Info Taxi Lights Switched Off 7 ft agl · 5 kt
Info Strobe Lights Switched On 7 ft agl · 5 kt
Departure Runway Entry Entering runway 27 at LBSF Sofia Airport, Average speed was 13 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 10 kt6 kt min to max 14 kt 6 14 kt
Info Average pitch angle -1.0 °-1.1 ° min to max -1.0 ° -1.1 -1.0 °
Info Average bank angle 0.1 °0.0 ° min to max 0.3 ° 0.3 0.0 °
Info Average g force 1.00 g0.99 g min to max 1.00 g 1.00 1.00 g
Departure Roll 97.84Departure roll runway 27 at LBSF Sofia Airport. Takeoff distance 1,490 m 42 % of runway. Rotation speed was 139 kt. Local weather - Temperature 16 °C. Wind 6 kt at 210 °. Crosswind: 5 kt Headwind: 3 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 1,490 m42 % of runway
100 % Rotation speed was 139 ktTarget 140 kt
89 % Runway alignment max 10.06 m left10.06 m left to 0.00 m left 3.87 10.06 m
100 % Average g force 1.00 g0.95 g min to max 1.04 g 1.00 0.97 g
100 % Takeoff Bounce
Info Average pitch angle -0.5 °-1.2 ° min to max 8.6 ° -1.0 8.6 °
Info Average bank angle 0.2 °0.0 ° min to max 1.0 ° 0.0 0.4 °
Departure Climb 1 99.23Departure climb to 50 ft agl from runway 27 LBSF Sofia Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.2 °-0.4 ° min to max 0.1 ° -0.4 0.1 °
100 % Average speed 161 kt151 kt min to max 170 kt 151 170 kt
97 % Steepest bank angle 6.6 °0.0 ° min to max 6.6 ° 0.5 0.2 °
100 % Average g force 1.05 g0.92 g min to max 1.25 g 0.98 0.96 g
Info Average VSI 403 fpm106 fpm min to max 965 fpm 134 965 fpm
Info Average altitude 13 ft agl0 ft agl min to max 46 ft agl 0 46 ft agl
Info Average pitch angle 9.0 °6.8 ° min to max 11.4 ° 8.6 8.6 °

Events

Info Autopilot Flight Director Activated 11 ft agl · 156 kt
Info Autopilot Vertical Hold Activated 11 ft agl · 156 kt
Departure Climb 2 100.00Departure climb to 400 ft agl from 27 LBSF Sofia Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.3 °0.1 ° min to max 0.8 ° 0.1 0.8 °
100 % Average speed 175 kt171 kt min to max 190 kt 171 190 kt
100 % Steepest bank angle 1.8 °0.4 ° min to max 1.8 ° 0.4 1.5 °
100 % Average g force 1.03 g0.96 g min to max 1.10 g 0.96 1.01 g
Info Average VSI 1,292 fpm973 fpm min to max 2,428 fpm 973 2,428 fpm
Info Average altitude 105 ft agl48 ft agl min to max 374 ft agl 48 374 ft agl
Info Average pitch angle 9.7 °8.6 ° min to max 11.0 ° 8.6 10.5 °

Events

Info Landing Gear Up 228 ft agl · 189 kt
Departure Climb 3 100.00Departure climb to 1,000 ft agl from 27 LBSF Sofia Airport.
ScoreDescriptionStartProfileEnd
100 % Climb speed 198 kt192 kt min to max 203 ktTarget 178 kt, 20 kt fast 192 202 kt
100 % Steepest bank angle 1.6 °1.1 ° min to max 1.6 ° 1.2 1.2 °
100 % Average g force 1.01 g0.93 g min to max 1.08 g 1.04 0.94 g
100 % Landing gear up at 215 ft aglTarget by 400 ft agl
Info Heading variation 0.8 °0.8 ° min to max 0.8 ° 0.8 0.8 °
Info Average VSI 2,949 fpm2,518 fpm min to max 3,400 fpm 2,518 3,400 fpm
Info Average altitude 640 ft agl417 ft agl min to max 930 ft agl 417 930 ft agl
Info Average pitch angle 11.2 °9.7 ° min to max 12.5 ° 10.6 12.1 °

Events

Info Flaps Fully Retracted 565 ft agl · 203 kt
Enroute Climb 96.30Enroute climb started overhead LBSF Sofia Airport Sofia (Sofia-Grad, Bulgaria). Climbing from 2,738 ft asl to 38,200 ft asl, an increase of 35,461 ft in 22 minutes and covering 138 nm.
ScoreDescriptionStartProfileEnd
91 % Average speed 255 kt202 kt min to max 277 kt 202 230 kt
100 % Steepest bank angle 27.6 °0.0 ° min to max 27.6 ° 0.8 0.1 °
99.9 % Average g force 1.02 g0.57 g min to max 1.40 g 0.88 1.00 g
Info Average VSI 1,796 fpm-1,381 fpm min to max 5,674 fpm 3,322 -24 fpm
Info Average altitude 18,652 ft asl2,728 ft asl min to max 38,203 ft asl 2,738 38,200 ft asl
Info Average pitch angle 5.5 °-0.1 ° min to max 13.7 ° 11.8 3.7 °
Info Turn coordination 00 min to max 0 0 0

Events

Fail Exceeded 250 kn below 10000 ft 3,024 ft agl
Info Autopilot Nav1 Lock Activated 1,053 ft agl · 210 kt
Info Autopilot Master Switched On 1,097 ft agl · 211 kt
Info Autopilot Vertical Hold Deactivated 1,249 ft agl · 222 kt
Info Autopilot Vertical Hold Activated 1,123 ft agl · 250 kt
Info Autopilot Vertical Hold Deactivated 1,024 ft agl · 256 kt
Info Landing Lights Switched Off 7,345 ft agl · 302 kt
Info Autopilot Vertical Hold Activated 37,543 ft agl · 420 kt
Enroute Level 100.00Enroute level cruise started 3 miles north east of Markovac (Central Serbia, Serbia) and lasted 93 minutes, covering 634 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,410 ft of 38,090 ft asl37,565 ft asl min to max 38,197 ft asl 38,197 37,565 ft asl
100 % Average speed 232 kt230 kt min to max 234 kt 232 234 kt
100 % Steepest bank angle 17.2 °0.0 ° min to max 17.2 ° 0.1 15.5 °
100.00 % Average g force 1.01 g0.67 g min to max 1.07 g 1.00 1.05 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 3.4 °-3.0 ° min to max 3.8 ° 3.6 -2.2 °

Events

Info Autopilot Vertical Hold Deactivated 37,448 ft agl · 421 kt
Enroute Descent 100.00Enroute descent started 2 miles north of Nidda (Hessen, Germany). Descent from 37,497 ft asl to 10,260 ft asl, a decrease of 27,237 ft in 11 minutes and covering 69 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 274 kt235 kt min to max 283 kt 235 251 kt
100 % Steepest bank angle 28.3 °0.2 ° min to max 28.3 ° 15.1 15.9 °
100.00 % Average g force 1.07 g0.95 g min to max 1.31 g 1.08 1.03 g
Info Average VSI -2,626 fpm-4,114 fpm min to max -50 fpm -4,114 -67 fpm
Info Average altitude 22,482 ft asl10,260 ft asl min to max 37,497 ft asl 37,497 10,260 ft asl
Info Average pitch angle -2.2 °-4.0 ° min to max 1.8 ° -1.9 1.8 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Vertical Hold Activated 9,909 ft agl · 294 kt
Enroute Level 2 100.00Enroute level cruise started overhead Grossostheim (Bavaria, Germany) and lasted 12 minutes, covering 58 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±1,013 ft of 10,248 ft asl10,223 ft asl min to max 10,278 ft asl 10,259 10,236 ft asl
100 % Average speed 250 kt249 kt min to max 251 kt 251 250 kt
100 % Steepest bank angle 28.4 °0.0 ° min to max 28.4 ° 16.2 0.0 °
100 % Average g force 1.07 g0.97 g min to max 1.19 g 1.02 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 2.1 °1.6 ° min to max 2.5 ° 1.9 1.8 °

Events

Info Autopilot Nav1 Lock Deactivated 9,866 ft agl · 291 kt
Info Autopilot Heading Hold Activated 9,866 ft agl · 291 kt
Enroute Descent 2 100.00Enroute descent started 1 mile north of Bad Soden-Salmuenster (Hessen, Germany). Descent from 10,241 ft asl to 3,200 ft asl, a decrease of 7,040 ft in 9 minutes and covering 31 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 187 kt180 kt min to max 252 kt 250 181 kt
100 % Steepest bank angle 28.6 °0.0 ° min to max 28.6 ° 0.2 7.9 °
100 % Average g force 1.05 g0.96 g min to max 1.19 g 0.99 1.02 g
Info Average VSI -910 fpm-2,398 fpm min to max 43 fpm 33 -125 fpm
Info Average altitude 5,875 ft asl3,200 ft asl min to max 10,241 ft asl 10,241 3,200 ft asl
Info Average pitch angle 2.0 °-2.4 ° min to max 4.6 ° 1.8 3.3 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Vertical Hold Deactivated 9,385 ft agl · 291 kt
Info Landing Lights Switched On 9,413 ft agl · 290 kt
Info Flaps Position 1 5,283 ft agl · 198 kt
Info Autopilot Vertical Hold Activated 3,046 ft agl · 191 kt
Info Autopilot Nav1 Lock Activated 2,831 ft agl · 189 kt
Info Autopilot Heading Hold Deactivated 2,831 ft agl · 189 kt
Enroute Level 3 99.70Enroute level cruise started overhead Hanau am Main (Hessen, Germany) and lasted 4 minutes, covering 12 nm.
ScoreDescriptionStartProfileEnd
99 % Altitude held within ±660 ft of 2,924 ft asl2,221 ft asl min to max 3,220 ft asl 3,199 2,221 ft asl
100 % Average speed 178 kt170 kt min to max 181 kt 180 172 kt
100 % Steepest bank angle 7.4 °0.0 ° min to max 7.4 ° 7.4 0.2 °
100 % Average g force 1.01 g0.90 g min to max 1.11 g 1.01 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 1.8 °-2.3 ° min to max 3.9 ° 3.3 -2.2 °

Events

Info Autopilot Nav1 Lock Deactivated 2,410 ft agl · 187 kt
Info Flaps Position 3 2,233 ft agl · 177 kt
Info Landing Gear Down 1,861 ft agl · 177 kt
Info Flaps Position 5 1,861 ft agl · 177 kt
Arrival Approach 66.67Final approach to runway 25L at EDDF Frankfurt Airport. Descent from 1,997 ft agl to 146 ft agl in 71 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed
100 % Sink ratepassed
0 % On glideslopefailed
100 % On centrelinepassed
0 % On speedfailed
100 % Wings levelpassed

Events

Fail GPWS Warning Activated 801 ft agl · 142 kt
Fail GPWS Warning Activated 279 ft agl · 140 kt
Info Landing Gear Down 1,861 ft agl · 177 kt
Info Flaps Position 5 1,861 ft agl · 177 kt
Info Flaps Position 6 1,382 ft agl · 168 kt
Info Autopilot Master Switched Off 699 ft agl · 143 kt
Info GPWS Warning Deactivated 328 ft agl · 142 kt
Info GPWS Warning Deactivated 142 ft agl · 140 kt
Arrival Landing 69.15Landing on runway 25L at EDDF Frankfurt Airport, runway length 3,986 m. Threshold height at 92 ft agl was significantly above target. Threshold speed was well above target at 140 kt.
ScoreDescriptionStartProfileEnd
85 % Threshold speed was well above target at 140 kt. Target 122 kt
17 % Threshold height at 92 ft agl was significantly above target.Target 50 ft agl
90 % The flare mostly held the target profile. The flare began at 63 ft agl above the runway, higher than this aircraft wants. Touchdown was 681 m past the threshold. Hold the aim point and let the runway come to you rather than anticipating the flare.
76 % Runway alignment max 13.09 m left13.09 m left to 10.59 m left 13.09 10.59 m
90 % Steepest bank angle 5.9 °0.0 ° min to max 5.9 ° 0.0 2.8 °
89 % Peak g force 1.44 g0.80 g min to max 1.44 g 0.80 0.89 g
Info Average speed 133 kt125 kt min to max 141 kt 140 125 kt
Info Average VSI -669 fpm-1,678 fpm min to max -108 fpm -1,382 -266 fpm
Info Average altitude 12 ft agl-8 ft agl min to max 92 ft agl 92 -8 ft agl
Info Average pitch angle 1.5 °-6.3 ° min to max 4.3 ° -6.3 0.9 °

Events

Fail GPWS Warning Activated 100 ft agl · 139 kt
Info Autopilot Vertical Hold Deactivated 45 ft agl · 139 kt
Info GPWS Warning Deactivated 29 ft agl · 137 kt
Info Autopilot Vertical Hold Activated 21 ft agl · 133 kt
07515022530037545052560067575082501837557392Runway Distance mLanding Height ft075150225300375450525600675750825-24-20-16-12-8-404812162024Runway Distance mRunway Width m
Arrival Touchdown 86.50Touchdown point was 258 m beyond the touchdown zone. Touchdown speed at 125 kt was a little fast. Touchdown rate was hard at -405 fpm. Runway touchdown position was misaligned by 10.6 m from centreline. Local weather - Temperature 11 °C. Wind 3 kt at 90 °. Crosswind: 1 kt Tailwind: 3 kt.
ScoreDescriptionStartProfileEnd
65 % Touchdown rate was -405 fpm.
75 % Touchdown distance was 681 mTarget 457 m
100 % Speed at touchdown 125 ktTarget below 122 kt
84 % Runway alignment max 10.59 m left10.26 m left 10.59 10.08 m
91 % Steepest bank angle 2.8 °0.9 ° min to max 2.8 ° 2.8 0.9 °
100 % Peak g force 1.29 g0.88 g min to max 1.29 g 0.89 1.21 g
100 % Landing Bounce
Info Average speed 124 kt124 kt min to max 125 kt 125 124 kt
Info Average pitch angle 0.5 °-0.1 ° min to max 0.9 ° 0.9 -0.1 °

Events

Info Autopilot Vertical Hold Deactivated 8 ft agl · 123 kt
Arrival Rollout 92.18Total landing distance 1,362 m, 34 % of runway. Runway rollout alignment was slightly misaligned by 11.0 m from centreline.
ScoreDescriptionStartProfileEnd
100 % Landing distance 1,362 m34 % of runway.
83 % Runway alignment max 11.01 m left11.01 m left to 0.00 m left 10.62 1.02 m
100 % Average g force 1.01 g0.99 g min to max 1.13 g 1.13 0.99 g
Info Average speed 114 kt67 kt min to max 125 kt 125 67 kt
Info Average pitch angle -1.5 °-1.6 ° min to max -0.4 ° -0.4 -1.3 °
Info Average bank angle 0.2 °0.0 ° min to max 0.9 ° 0.4 0.0 °
Runway Exit Exiting runway, average speed 29 kt
ScoreDescriptionStartProfileEnd
Info Average speed 31 kt15 kt min to max 60 kt 60 17 kt
Info Average pitch angle -1.2 °-1.9 ° min to max -1.0 ° -1.2 -1.6 °
Info Average bank angle 0.2 °0.0 ° min to max 0.9 ° 0.0 0.6 °
Info Average g force 1.00 g0.99 g min to max 1.00 g 0.99 1.00 g
Arrival Taxi 92.20Taxiing to the parking from the runway took 8 minutes and covered 1 nm.
ScoreDescriptionStartProfileEnd
81 % Average speed 15 kt0 kt min to max 34 kt 18 5 kt
100 % Average speed turning corners 12 ktmax 16 kt 0 0 kt
100 % Average g force 1.00 g0.97 g min to max 1.03 g 1.00 1.00 g
Info Average pitch angle -1.1 °-1.6 ° min to max -0.2 ° -1.6 -1.1 °
Info Average bank angle 0.2 °0.0 ° min to max 1.2 ° 0.4 0.0 °

Events

Info Flaps Position 2 7 ft agl · 2 kt
Info Flaps Fully Retracted 7 ft agl · 3 kt
Info Landing Lights Switched Off 7 ft agl · 8 kt
Info Taxi Lights Switched On 7 ft agl · 9 kt
Info Strobe Lights Switched Off 7 ft agl · 11 kt

Takeoff from LBSF 27

Taxi out

LightsOk
All on
Taxi speed100.00
28kt peak6 kt in turns

The roll

Takeoff roll100.00
1,490m42 %
Runway alignment89.21
10.06m L
Rotation speed100.00
139kttarget 140, 1 early

A clean takeoff

Rotated at 139 kt against the 140 kt rotate speed, the nose rising at 2.7° a second, then held 9.8° from 35 ft, within 3.9° top to bottom.

Rotated on speed at a steady rate, and the climb attitude held. This is the takeoff to repeat: the same speed check, the same pull, the same attitude.

Liftoff and climb

Liftoff
150ktat 8.6°
Rotation
2.7°/sover 3.4 s, gaining 11 kt
35 ft
168ktat 9.0°, 5.1 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff96.93
6.6°steepest
Gear up100.00
215ftfull marks to 400 ft
Climb 3 speed100.00
198kttarget 178

Plan view the roll down the 3,578 m runway.

Rolled from 147 m in, drifted left of the centreline, 11 m at the widest, and lifted off 11 m left, in 5 kn of crosswind from the left. Airborne 41 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

1,0002,0003,000THRESHOLDLEFT ↑RIGHT ↓CROSS5 kn75 %widest 10.51 m LROLL 147 M INAirborne 1,495 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,495 m of 3,578 m · 42 %
Behind the start of the roll, 147 mTakeoff roll, 1,348 m Left ahead, 2,083 m

Side view from the start of the roll to the end of Climb 3 at 930 ft.

Reached 35 ft with 1,647 m of runway left; gear up at 215 ft, inside the 400 ft that gets full marks; then climbing at 2,080 fpm on average to 930 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3198 kt avgtarget 178THRESHOLDRUNWAY END6080100120KNOTS ALONG THE ROLLnose up on the runway · 261 m · 3.4 sRotate 139 kttarget 140Liftoff 150 ktGear up 215 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 178210 kt14070020°10°0°nose up on the runway · 261 m · 3.4 sROTATELIFTOFFGEAR UPtarget 140held 9.8°8.6° off · 2.7°/s9° at 35 ftAIRSPEEDPITCH02040 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2 to 3° a second, the rates airliners are rotated at: a trace steeper than both is a faster rotation, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 10°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 10°ROTATELIFTOFF35 FT3°/s8.6° off · 2.7°/s2°/s9° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5+6+7+8+9 sseconds from rotation
PitchRotation began2 to 3°/s from rotationTail strikeNose up, wheels on the runway

The stabilisation gates

One stabilised approach gate: six checks where the approach path is 500 ft above the runway. The 1,000 ft gate was not assessed, because the approach did not join final that far out. These checks are the approach's score.

Six checks, one gate500 ft 66.674 of 6
Gear down
Sink rate1,300 fpm
On glideslope6.5°
On centreline0.2° off
On speed+35 kt
Wings level0° bank

At the 500 ft gate: glideslope more than 1° off the runway's 3° and speed more than 18 kt above the approach speed of 122 kt.

When the approach was stable

Never every check met at once: high all the way, fast all the way, gear up until 3.0 nm, sinking too fast from 1.3 nm and left of the centreline from 0.5 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to EDDF 25L

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

High from 3.9 nm, where the final began, to the threshold (up to 1,050 ft over).

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,0002,500 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND2,3391,9191,403876437500 ft gate4 of 6on glideslopeon speed1,202 ft · 157 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 21× larger than distances along the final.

Inside the 1° band from 3.9 nm, where the final began, to 0.5 nm, then 18 m left of it from 0.5 nm to the threshold.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR46 m L046 m RLEFT ↑RIGHT ↓1° BAND16 m L14 m L11 m L8 m L18 m L10 m L
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 31 kt fast at the 1,000 ft gate, closing to 18 at 500 ft and 10 at the threshold.

Fast from 3.9 nm, where the final began, to the threshold (up to +51 kt).

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

120140160180 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 122+48 kt+50 kt+42 kt+19 kt+21 kt+18 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on EDDF 25L

Over the threshold

Threshold height17.38
92ft
Threshold speed84.51
139kttarget 122, 17 fast
Centreline offset75.98
13.09m L
Bank90.03
5.9°steepest
Flare90.46

The flare mostly held the target profile

The flare began at 63 ft agl above the runway, higher than this aircraft wants. Touchdown was 681 m past the threshold. Hold the aim point and let the runway come to you rather than anticipating the flare.

Touchdown

Past threshold75.47
681m
Centreline83.53
10.59m L
Speed100.00
124kttarget 122, 2 fast
Touchdown rate65.46
-405fpm
Impact100.00
1.29G
BouncesOk
None
Bank91.19
2.8°as the wheels touched

Rollout

Rollout distance100.00
666m33 % used
Rollout alignment82.62
11.01m L

Taxi in

LightsOk
All set
Taxi speed90.25
34kt peak12 kt in turns

Side view — the last 1,524 m of the approach.

Crossed the threshold at 92 ft, 42 ft above the 50 ft target; began the flare high, at 63 ft. Touched down 681 m in, 377 m past the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,524 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

92 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 63 ft · −1,999 fpm · −3.9° · 141 ktdescent slowed at 6 ft · −89 fpm · 4.3°−405 fpm · 0.9° nose up · 125 kt Ideal — 50 ft, down at 305 m This flight — 92 ft, down at 681 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 2,000 fpm at the flare to 400 fpm at touchdown. The nose came up 4.8° on the way down. Into the flare at 141 kt, 19 kt over the 122 kt approach speed, and 125 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−1,250−2,500−7°2°10°flaredescent slowedtouchdown−405 fpm at touchdown0.9° at touchdown, +4.8° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,524 m of the 3,986 m runway, to the same scale as the side view.

Touched down 10 m left of the centreline, and steered back to 3 m left by the end of the rollout. Little crosswind (1 kt): nothing to correct for. Touched down with the nose 1° left of the track, 2.8° of bank.

Wind 090° at 3 kt · 3 kt tail · 1 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ CROSS 1 kn FULL SCORE TO 503 M 681 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

Touched down 681 m past the threshold — beyond the full-score zone. The 405 fpm arrival was firm.

Runway used 1,348 m of 3,986 m · 34 %
In the air over the runway, 681 mRollout, 666 m Left over, 2,638 m

The stop — touchdown to taxi speed.

From 126 kt at touchdown to taxi speed (30 kt) in 31 s, an average deceleration of 0.17 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 761 m30 kt · 1,051 mtouchdown1,094 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Flight narrative

The flight in the Embraer E190 started with a smooth taxi from the parking to the runway, taking 8 minutes to cover 2 nm. The departure roll was from runway 27 at LBSF Sofia, with a takeoff distance of 1,327 m, which was 37% of the total runway length. The liftoff speed was 151 kn. The local weather at the time of departure was 16 °C, with a 6 kn wind coming from 210°, resulting in a crosswind of 5 kn and a headwind of 3 kn.

The enroute climb began overhead LBSF Sofia, climbing from 2,738 ft asl to 37,856 ft asl, covering 127 nm in 21 minutes. The level cruise phase started 8 miles east of Markovac in Central Serbia and lasted 94 minutes, covering 624 nm. The descent phase commenced 2 miles north of Nidda in Germany, descending from 37,771 ft asl to 10,571 ft asl, covering 31 nm in 10 minutes.

Another level cruise phase began 1 mile southwest of Haibach in Bavaria, lasting 13 minutes and covering 22 nm. The subsequent descent phase started 2 miles south of Birstein in Germany, descending from 9,999 ft asl to 3,202 ft asl, covering 19 nm in 9 minutes. A brief level cruise phase followed, starting 1 mile southwest of Hanau am Main and lasting 3 minutes, covering 10 nm.

The landing was smooth on runway 25L at EDDF Frankfurt/Main, with a runway length of 3,984 m. The height at the threshold was 62 ft agl, with a speed of 140 kn. The touchdown occurred 585 m from the threshold at a speed of 125 kn, with a VSI of -288 ft/m. The total landing distance was 1,285 m, which was 32% of the runway length. The local weather at landing was 13 °C, with a 3 kn wind coming from 90°, resulting in a crosswind of 1 kn and a tailwind of 3 kn.

Finally, taxiing from the runway to the parking took 8 minutes, covering less than 1 nm. The total flight distance for this journey was 841 nm, taking 174 minutes and consuming 4,682 kg of fuel.

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
