NZAA
Auckland, New Zealand
Runway 23L
Elevation16 ft asl
Weight295,664 kg
Fuel40,735 kg
Wind320° · 2 kn · 2 kn cross

Flight Score

99.67 %
YBBN
Brisbane, Australia
Runway 01L
Elevation10 ft asl
Weight267,892 kg
Fuel12,365 kg
Wind0° · 4 kn · 2 kn cross
5 Oct 2024 3:24 1277 nm Boeing 747-8 28,370 kg
Departure Score
100.00 %
Enroute Score
99.96 %
Arrival Score
99.04 %

What went well

Threshold crossed at 35 ft and 142 kt — both inside band
Flare on profile — 100 %
1.26 G at touchdown — inside band

What held you back

Arrival Touchdown — Touchdown distance was 595 m at 85 %, Touchdown rate was -307 fpm at 87 %, −0.32 points

Next time

Arrival

Adjust your approach path so you touch down at the 457 m aim point instead of beyond it.

What happened: Touchdown point came 138 m past the target, landing at 595 m against the 457 m aim point. Landings that touch down this far beyond the aim point typically leave less runway available for stopping.

Watch for: Touchdown distance marker: 457 m from the threshold.

See Arrival Touchdown

Start to finish · 16 stages, 14 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 8 minutes and covered 2 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 15 kt0 kt min to max 21 kt 0 14 kt
100 % Average speed turning corners 2 ktmax 2 kt 0 0 kt
100 % Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Info Average pitch angle -0.7 °-0.7 ° min to max -0.6 ° -0.7 -0.7 °
Info Average bank angle 0.0 °0.0 ° min to max 0.2 ° 0.0 0.1 °

Events

Info Battery Master On 15 ft agl
Info Engine 1 Started 15 ft agl
Info Engine 4 Started 15 ft agl
Info Beacon Lights Switched On 15 ft agl
Info Navigation Lights Switched On 15 ft agl
Info Autopilot Flight Director Activated 15 ft agl
Info Autopilot Yaw Damper Activated 15 ft agl
Info Landing Gear Down 15 ft agl
Info Pitot Heat Switched On 15 ft agl
Info Engine 2 Started 15 ft agl
Info Engine 3 Started 15 ft agl
Info Parking Brake On 15 ft agl
Info Flaps Position 1 15 ft agl
Info Flaps Position 3 15 ft agl
Info Landing Lights Switched On 15 ft agl
Info Taxi Lights Switched On 15 ft agl
Info Landing Lights Switched Off 15 ft agl
Info Parking Brake Off 15 ft agl
Info Landing Lights Switched On 15 ft agl · 17 kt
Info Strobe Lights Switched On 15 ft agl · 17 kt
Departure Runway Entry Entering runway 23L at NZAA Auckland International Airport, Average speed was 16 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 15 kt14 kt min to max 16 kt 14 16 kt
Info Average pitch angle -0.7 °-0.7 ° min to max -0.7 ° -0.7 -0.7 °
Info Average bank angle 0.1 °0.1 ° min to max 0.1 ° 0.1 0.1 °
Info Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Departure Roll 100.00Departure roll runway 23L at NZAA Auckland International Airport. Takeoff distance 1,037 m 28 % of runway. Rotation speed was 133 kt. Local weather - Temperature 16 °C. Wind 2 kt at 319 °. Crosswind: 2 kt Headwind: 1 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 1,037 m28 % of runway
100 % Rotation speed was 133 ktTarget 145 kt
100 % Runway alignment max 1.39 m right0.78 m left to 1.39 m right 0.69 -1.39 m
100 % Average g force 1.00 g0.98 g min to max 1.08 g 1.00 1.08 g
100 % Takeoff Bounce
Info Average pitch angle 0.2 °-0.7 ° min to max 10.6 ° -0.7 10.6 °
Info Average bank angle 0.2 °0.0 ° min to max 0.8 ° 0.0 0.8 °

Events

Info Runway Surface Conditions 15 ft agl · 120 kt
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 23L NZAA Auckland International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.1 °0.0 ° min to max 0.1 ° 0.1 0.0 °
100 % Average speed 156 kt146 kt min to max 165 kt 146 165 kt
100 % Steepest bank angle 2.3 °0.8 ° min to max 2.3 ° 0.8 2.0 °
100 % Average g force 1.04 g0.90 g min to max 1.15 g 1.10 1.04 g
Info Average VSI 511 fpm141 fpm min to max 776 fpm 141 776 fpm
Info Average altitude 19 ft agl0 ft agl min to max 42 ft agl 0 42 ft agl
Info Average pitch angle 9.4 °8.4 ° min to max 11.0 ° 10.8 9.0 °
Departure Climb 2 100.00Departure climb to 400 ft agl from 23L NZAA Auckland International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.0 °-0.3 ° min to max 0.0 ° 0.0 -0.3 °
100 % Average speed 175 kt166 kt min to max 203 kt 166 203 kt
100 % Steepest bank angle 3.6 °0.1 ° min to max 3.6 ° 1.9 1.4 °
100 % Average g force 1.04 g1.00 g min to max 1.10 g 1.03 1.05 g
Info Average VSI 1,157 fpm788 fpm min to max 2,614 fpm 788 2,614 fpm
Info Average altitude 92 ft agl43 ft agl min to max 358 ft agl 43 358 ft agl
Info Average pitch angle 8.9 °8.3 ° min to max 10.2 ° 9.0 10.2 °

Events

Info Autopilot Heading Hold Activated 84 ft agl · 172 kt
Info Landing Gear Up 126 ft agl · 180 kt
Departure Climb 3 100.00Departure climb to 1,000 ft agl from 23L NZAA Auckland International Airport.
ScoreDescriptionStartProfileEnd
100 % Climb speed 212 kt206 kt min to max 217 ktTarget 202 kt, 10 kt fast 206 217 kt
100 % Steepest bank angle 1.9 °0.2 ° min to max 1.9 ° 0.8 0.2 °
100 % Average g force 1.08 g1.02 g min to max 1.15 g 1.15 1.04 g
100 % Landing gear up at 99 ft aglTarget by 400 ft agl
Info Heading variation -0.4 °-0.4 ° min to max -0.3 ° -0.3 -0.4 °
Info Average VSI 3,951 fpm2,850 fpm min to max 4,784 fpm 2,850 4,784 fpm
Info Average altitude 671 ft agl407 ft agl min to max 969 ft agl 407 969 ft agl
Info Average pitch angle 13.0 °11.3 ° min to max 14.5 ° 11.3 14.5 °

Events

Info Flaps Position 1 484 ft agl · 210 kt
Enroute Climb 100.00Enroute climb started 1 mile south west of NZAA Auckland International Airport Auckland (Auckland, New Zealand). Climbing from 1,091 ft asl to 38,031 ft asl, an increase of 36,940 ft in 15 minutes and covering 93 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 302 kt218 kt min to max 329 kt 218 270 kt
100 % Steepest bank angle 28.4 °0.0 ° min to max 28.4 ° 0.8 0.8 °
100 % Average g force 1.03 g0.83 g min to max 1.16 g 1.06 1.00 g
Info Average VSI 3,020 fpm-117 fpm min to max 6,233 fpm 4,949 26 fpm
Info Average altitude 20,048 ft asl1,091 ft asl min to max 38,055 ft asl 1,091 38,031 ft asl
Info Average pitch angle 6.0 °2.2 ° min to max 18.4 ° 14.9 2.8 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Master Switched On 1,532 ft agl · 224 kt
Info Autopilot Master Switched Off 2,340 ft agl · 228 kt
Info Autopilot Master Switched On 3,453 ft agl · 234 kt
Info Autopilot AutoThrottle Arm Armed 4,129 ft agl · 235 kt
Info Autopilot RPM Hold Activated 4,129 ft agl · 235 kt
Info Flaps Fully Retracted 4,497 ft agl · 243 kt
Info Landing Lights Switched Off 10,434 ft agl · 312 kt
Info Taxi Lights Switched Off 10,376 ft agl · 315 kt
Info Autopilot Airspeed Hold Activated 37,855 ft agl · 486 kt
Info Autopilot Vertical Hold Activated 37,855 ft agl · 486 kt
Info Autopilot RPM Hold Deactivated 37,855 ft agl · 486 kt
Enroute Level 100.00Enroute level cruise started 50 miles south west of NZRW Ruawai Aerodrome Dargaville (Auckland, New Zealand) and lasted 146 minutes, covering 1,030 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,402 ft of 38,041 ft asl37,966 ft asl min to max 38,130 ft asl 38,034 37,968 ft asl
100 % Average speed 268 kt267 kt min to max 272 kt 270 267 kt
100 % Steepest bank angle 8.3 °0.0 ° min to max 8.3 ° 0.5 1.4 °
100 % Average g force 1.00 g0.93 g min to max 1.08 g 1.03 1.01 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 2.6 °2.1 ° min to max 3.1 ° 3.0 2.4 °
Enroute Descent 100.00Enroute descent started 85 miles east of Kingscliff (State of New South Wales, Australia). Descent from 37,982 ft asl to 2,014 ft asl, a decrease of 35,967 ft in 21 minutes and covering 124 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 280 kt236 kt min to max 330 kt 267 239 kt
100 % Steepest bank angle 27.9 °0.0 ° min to max 27.9 ° 4.2 0.1 °
100 % Average g force 1.01 g0.79 g min to max 1.28 g 1.06 0.98 g
Info Average VSI -1,496 fpm-2,321 fpm min to max 226 fpm 226 88 fpm
Info Average altitude 13,881 ft asl1,988 ft asl min to max 37,990 ft asl 37,982 2,014 ft asl
Info Average pitch angle -0.5 °-3.0 ° min to max 3.6 ° 3.0 2.9 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Airspeed Hold Deactivated 34,329 ft agl · 491 kt
Info Autopilot Airspeed Hold Activated 11,255 ft agl · 393 kt
Info Landing Lights Switched On 10,680 ft agl · 326 kt
Info Taxi Lights Switched On 10,643 ft agl · 316 kt
Info Autopilot Airspeed Hold Deactivated 7,975 ft agl · 281 kt
Info Autopilot Vertical Hold Deactivated 7,975 ft agl · 281 kt
Info Autopilot RPM Hold Activated 7,975 ft agl · 281 kt
Info Autopilot RPM Hold Deactivated 7,656 ft agl · 276 kt
Info Autopilot Airspeed Hold Activated 4,724 ft agl · 262 kt
Info Autopilot Vertical Hold Activated 4,724 ft agl · 262 kt
Enroute Level 2 99.84Enroute level cruise started overhead Logan Central (State of Queensland, Australia) and lasted 6 minutes, covering 19 nm.
ScoreDescriptionStartProfileEnd
99 % Altitude held within ±601 ft of 1,925 ft asl1,301 ft asl min to max 2,157 ft asl 2,015 1,301 ft asl
100 % Average speed 189 kt144 kt min to max 241 kt 238 145 kt
100 % Steepest bank angle 29.9 °0.0 ° min to max 29.9 ° 0.6 2.6 °
100 % Average g force 1.02 g0.81 g min to max 1.28 g 0.95 1.02 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 3.4 °-1.1 ° min to max 7.1 ° 2.6 2.8 °

Events

Info Flaps Position 2 1,870 ft agl · 211 kt
Info Flaps Position 3 1,900 ft agl · 205 kt
Info Landing Gear Down 1,921 ft agl · 188 kt
Info Autopilot Heading Hold Deactivated 1,903 ft agl · 188 kt
Info Autopilot Approach Mode Activated 1,903 ft agl · 188 kt
Info Flaps Position 4 1,958 ft agl · 181 kt
Info Flaps Position 5 2,006 ft agl · 168 kt
Info Autopilot Vertical Hold Deactivated 1,946 ft agl · 163 kt
Info Flaps Position 6 1,605 ft agl · 151 kt
Arrival Approach 100.00Final approach to runway 01L at YBBN Brisbane International Airport. Descent from 1,328 ft agl to 55 ft agl in 100 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates

Events

Info Autopilot AutoThrottle Arm Disarmed 998 ft agl · 148 kt
Info Autopilot Master Switched Off 985 ft agl · 147 kt
Arrival Landing 100.00Landing on runway 01L at YBBN Brisbane International Airport, runway length 3,301 m. Good threshold height. Threshold speed was good at 142 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 142 kt. Target 137 kt
100 % Good threshold height.Target 50 ft agl
100 % Perfect landing flare
100 % Runway alignment max 9.32 m right6.37 m right to 9.32 m right -9.31 -6.37 m
100 % Steepest bank angle 1.5 °0.3 ° min to max 1.5 ° 1.5 0.5 °
100 % Peak g force 1.14 g0.96 g min to max 1.14 g 1.03 0.96 g
Info Average speed 139 kt133 kt min to max 142 kt 142 133 kt
Info Average VSI -311 fpm-740 fpm min to max -156 fpm -740 -256 fpm
Info Average altitude 15 ft agl0 ft agl min to max 35 ft agl 35 0 ft agl
Info Average pitch angle 5.2 °4.0 ° min to max 5.5 ° 4.0 5.5 °
07515022530037545052560067501123344657Runway Distance mLanding Height ft075150225300375450525600675-30-24-18-12-60612182430Runway Distance mRunway Width m
Arrival Touchdown 95.19Touchdown point was 175 m beyond the touchdown zone. Touchdown speed at 133 kt was good. Touchdown rate was firm at -307 fpm. Runway touchdown position was slightly misaligned by 6.4 m from centreline. Local weather - Temperature 18 °C. Wind 4 kt at 0 °. Crosswind: 2 kt Headwind: 3 kt.
ScoreDescriptionStartProfileEnd
87 % Touchdown rate was -307 fpm.
85 % Touchdown distance was 595 mTarget 457 m
100 % Speed at touchdown 133 ktTarget below 137 kt
100 % Runway alignment max 6.37 m right6.13 m right -6.37 -5.88 m
100 % Steepest bank angle 1.1 °0.0 ° min to max 1.1 ° 0.5 0.1 °
100 % Peak g force 1.26 g0.96 g min to max 1.26 g 0.96 1.11 g
100 % Landing Bounce
Info Average speed 132 kt132 kt min to max 133 kt 133 132 kt
Info Average pitch angle 5.3 °5.1 ° min to max 5.5 ° 5.5 5.1 °
Arrival Rollout 100.00Total landing distance 1,421 m, 43 % of runway. Runway rollout alignment was perfect.
ScoreDescriptionStartProfileEnd
100 % Landing distance 1,421 m43 % of runway.
100 % Runway alignment max 2.50 m right0.00 m left to 2.50 m right -2.50 -1.83 m
100 % Average g force 1.01 g0.99 g min to max 1.08 g 1.08 0.99 g
Info Average speed 118 kt72 kt min to max 129 kt 129 72 kt
Info Average pitch angle 2.8 °-0.6 ° min to max 5.0 ° 5.0 -0.6 °
Info Average bank angle 0.4 °0.0 ° min to max 0.8 ° 0.1 0.2 °
Runway Exit Exiting runway, average speed 33 kt
ScoreDescriptionStartProfileEnd
Info Average speed 30 kt19 kt min to max 64 kt 64 19 kt
Info Average pitch angle -0.7 °-0.9 ° min to max -0.5 ° -0.7 -0.7 °
Info Average bank angle 0.1 °0.0 ° min to max 0.2 ° 0.2 0.2 °
Info Average g force 1.00 g0.99 g min to max 1.00 g 1.00 1.00 g

Events

Info Flaps Fully Retracted 15 ft agl · 33 kt
Info Landing Lights Switched Off 15 ft agl · 24 kt
Info Strobe Lights Switched Off 15 ft agl · 24 kt
Arrival Taxi 100.00Taxiing to the parking from the runway took 7 minutes and covered 2 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 17 kt0 kt min to max 24 kt 18 3 kt
100 % Average speed turning corners 14 ktmax 16 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.00 g 1.00 1.00 g
Info Average pitch angle -0.7 °-0.9 ° min to max -0.6 ° -0.8 -0.7 °
Info Average bank angle 0.1 °0.0 ° min to max 0.3 ° 0.2 0.0 °

Takeoff from NZAA 23L

Taxi out

LightsOk
All on
Taxi speed100.00
21kt peak2 kt in turns

The roll

Takeoff roll100.00
1,037m28 %
Runway alignment100.00
1.39m R
Rotation speed100.00
133kttarget 145, 12 early

Rotated early, and the nose came up quickly

Rotation started at 133 kt, 12 kt before the 145 kt rotate speed, and the nose then rose at 4.0° a second, faster than the 2 to 3° a second airliners use.

Early and quick together is the classic tail-strike setup: the nose reaches its liftoff attitude before the aircraft has the speed to fly. Wait for the rotate speed, then pull smoothly at the normal rate for this aircraft and let it lift off at its own attitude.

Liftoff and climb

Liftoff
145ktat 10.8°
Rotation
4.0°/sover 2.7 s, gaining 12 kt
35 ft
163ktat 9.2°, 3.2 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
2.3°steepest
Gear up100.00
99ftfull marks to 400 ft
Climb 3 speed100.00
212kttarget 202

Plan view the roll down the 3,671 m runway.

Rolled from 103 m in, drifted right of the centreline, 1.7 m at the widest, and lifted off 1.7 m right. Airborne 28 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

1,0002,0003,000THRESHOLDLEFT ↑RIGHT ↓CROSS1 kn75 %widest 1.70 m RROLL 103 M INAirborne 1,043 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,043 m of 3,671 m · 28 %
Behind the start of the roll, 103 mTakeoff roll, 939 m Left ahead, 2,628 m

Side view from the start of the roll to the end of Climb 3 at 970 ft.

Reached 35 ft with 2,367 m of runway left; gear up at 99 ft, inside the 400 ft that gets full marks; then climbing at 2,470 fpm on average to 970 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3212 kt avgtarget 202THRESHOLDRUNWAY END6080100120KNOTS ALONG THE ROLLnose up on the runway · 197 m · 2.7 sRotate 133 kttarget 145Liftoff 145 ktGear up 99 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 202240 kt16080020°10°0°nose up on the runway · 197 m · 2.7 sROTATELIFTOFFGEAR UPtarget 145held 9.6°10.8° off · 4.0°/s9° at 35 ftAIRSPEEDPITCH02040 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2 to 3° a second, the rates airliners are rotated at: a trace steeper than both is a faster rotation, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 12.1°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 12.1°ROTATELIFTOFF35 FT10.8° off · 4.0°/s3°/s2°/s9° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5+6+7 sseconds from rotation
PitchRotation began2 to 3°/s from rotationTail strikeNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate750 fpm590 fpm
On glideslope3.0°3.2°
On centreline0.2° off0.1° off
On speed+7.5 kt+6.0 kt
Wings level0° bank2° bank

When the approach was stable

Every check met from 4 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to YBBN 01L

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 30 ft below the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,3086633772181,000 ft gate7 of 71,046 ft · 145 kt500 ft gate7 of 7559 ft · 143 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 16× larger than distances along the final.

Inside the 1° band all the way from 4 nm, never more than 22 m off the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR58 m L058 m RLEFT ↑RIGHT ↓1° BAND18 m L3 m R9 m R8 m R14 m L7 m L
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 34 kt fast at the 1,000 ft gate, closing to 21 at 500 ft and 10 at the threshold.

Inside the speed band all the way, between +3 kt and +8 kt on the approach speed of 137 kt.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

140160180200 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 137+7 kt+8 kt+7 kt+4 kt+5 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on YBBN 01L

Over the threshold

Threshold height100.00
35ft
Threshold speed100.00
142kttarget 137, 5 fast
Centreline offset100.00
9.32m R
Bank100.00
1.5°steepest
Flare100.00

Perfect landing flare

Touchdown

Past threshold84.88
595m
Centreline100.00
6.37m R
Speed100.00
132kttarget 137 or less
Touchdown rate87.29
-307fpm
Impact100.00
1.26G
BouncesOk
None
Bank100.00
1.1°as the wheels touched

Rollout

Rollout distance100.00
789m42 % used
Rollout alignment100.00
2.50m R

Taxi in

LightsOk
All set
Taxi speed100.00
24kt peak14 kt in turns

Side view — the last 1,524 m of the approach.

Began the flare at 35 ft, 5 m before the threshold; crossed the threshold at 35 ft, 15 ft below the 50 ft target. Touched down 595 m in, 291 m past the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,524 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

35 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare began at 35 ft, 5 m before the threshold−666 fpm · 3.9° · 142 ktdescent slowed at 13 ft · −98 fpm · 5.3°−307 fpm · 5.5° nose up · 133 kt Ideal — 50 ft, down at 305 m This flight — 35 ft, down at 595 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 670 fpm at the flare to 310 fpm at touchdown. The nose came up 1.6° on the way down. Into the flare at 142 kt, 5 kt over the 137 kt approach speed, and 133 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°descent slowedtouchdown−307 fpm at touchdown5.5° at touchdown, +1.6° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,524 m of the 3,301 m runway, to the same scale as the side view.

Touched down 5.9 m right of the centreline, and steered back to 1.9 m right by the end of the rollout. Little crosswind (1 kt): nothing to correct for. Touched down straight, wings level.

Wind 000° at 4 kt · 3 kt head · 1 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ CROSS 1 kn FULL SCORE TO 503 M 595 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

Touched down 595 m past the threshold — beyond the full-score zone. The arrival was smooth.

Runway used 1,385 m of 3,301 m · 42 %
In the air over the runway, 595 mRollout, 789 m Left over, 1,916 m

The stop — touchdown to taxi speed.

From 131 kt at touchdown to taxi speed (30 kt) in 29 s, an average deceleration of 0.18 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 966 m30 kt · 1,158 mtouchdown1,204 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Flight narrative

The flight in the Boeing 747-8 began at Auckland International Airport (NZAA), where the aircraft taxied from the parking area to the runway, covering 2 nm in 8 minutes. The departure roll was from runway 23L, with a takeoff distance of 925 m, representing 28% of the total runway length. The liftoff speed was 146 knots, with the local weather showing a temperature of 14°C, wind at 2 knots coming from 319° resulting in a crosswind of 2 knots and a headwind of 1 knot.

The enroute climb started 1 mile southwest of Auckland International Airport, climbing from 1,091 ft above sea level to 38,036 ft, an increase of 36,945 ft over 15 minutes and covering 91 nm. The level cruise portion of the flight began 52 miles southwest of Ruawai Aerodrome in Dargaville, lasting 146 minutes and covering a distance of 1,032 nm.

The descent phase of the flight commenced 81 miles east of Kingscliff in New South Wales, Australia. The aircraft descended from 37,483 ft to 2,153 ft, a decrease of 35,329 ft over a span of 20 minutes and covering 107 nm. The landing occurred on runway 01L at Brisbane International Airport (YBBN), with a runway length of 3,308 m. The aircraft was at a height of 35 ft above ground level at the threshold, with a speed of 142 knots. The touchdown happened 595 m from the threshold, at a speed of 133 knots and a Vertical Speed Indicator (VSI) reading of -258 ft/m. The local weather at Brisbane showed a temperature of 20°C, with a wind speed of 4 knots coming from 0°, resulting in a crosswind of 2 knots and a headwind of 3 knots.

The total landing distance was 1,421 m, accounting for 43% of the runway length. After landing, the aircraft taxied from the runway to the parking area, covering 1 nm in 7 minutes. The total flight distance was 1,252 nm, with a duration of 211 minutes and fuel consumption of 28,374 kg.

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
