KDFW
Dallas-Fort Worth, United States
Runway 36L
Elevation564 ft asl
Weight147,166 lbs
Fuel147,562 lbs
WindCalm

Flight Score

94.43 %
KELP
El Paso, United States
Runway 22
Elevation3,914 ft asl
Weight136,835 lbs
Fuel136,835 lbs
WindCalm
15 Jan 2024 2:13 498 nm A20N 10,727 lbs
Departure Score
93.83 %
Enroute Score
100.00 %
Arrival Score
89.46 %

What went well

Touched down at -228 fpm — a soft arrival
Touchdown 925 ft in — inside the full-score zone
Threshold crossed at 32 ft and 132 kt — both inside band

What held you back

Departure Climb 3 — gear not retracted; Landing gear up at 0 ft agl at 0 %, −2.00 points
Arrival Rollout — Runway alignment max 68.0 ft left at 41 %, −1.78 points
Arrival Touchdown — Runway alignment max 152.4 ft left at 0 %, −1.04 points

Next time

Departure

Raise the gear lever promptly once a positive rate of climb is confirmed after liftoff.

What happened: The landing gear was never raised during the initial climb and was still down when the climb ended.

Watch for: Landing gear lever: UP promptly after confirming a positive rate of climb.

See Departure Climb 3

Arrival

Track the centreline through touchdown using small rudder corrections against a point at the far end of the runway.

What happened: The aircraft touched down off the centreline at 184 ft, and drifting off centreline at touchdown usually carries through into the rollout, as it did here with alignment reaching 68 ft.

Watch for: Watch runway centreline position, keeping deviation inside the limit through touchdown and rollout.

See Arrival LandingArrival Rollout

There are several things that can go wrong during the flare, carrying too much speed over the threshold, starting the flare at the wrong height and inconsistent flight control inputs, all contribute to a poor flare resulting in a hard touchdown or a float down the runway.

Read more in Flare Timing

Start to finish · 19 stages, 17 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 29 minutes and covered 3 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 7 kt0 kt min to max 10 kt 0 3 kt
100 % Average speed turning corners 8 ktmax 10 kt 0 0 kt
100 % Average g force 1.00 g0.98 g min to max 1.02 g 1.00 1.00 g
Info Average pitch angle 0.2 °-0.3 ° min to max 0.7 ° 0.6 0.4 °
Info Average bank angle 0.3 °0.0 ° min to max 1.8 ° 0.2 1.2 °

Events

Info Parking Brake Off  · 14 kt
Info Flaps Position 1  · 14 kt
Info Taxi Lights On  · 8 kt
Info Parking Brake On  · 13 kt
Info Parking Brake Off  · 13 kt
Info Landing Lights On  · 4 kt
Info Strobe Lights On  · 6 kt
Departure Runway Entry Entering runway 36L at KDFW Dallas Fort Worth International Airport, Average speed was 19 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 4 kt1 kt min to max 8 kt 1 8 kt
Info Average pitch angle 0.8 °0.8 ° min to max 0.9 ° 0.8 0.9 °
Info Average bank angle 0.2 °0.2 ° min to max 0.3 ° 0.2 0.3 °
Info Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Departure Roll 100.00Departure roll runway 36L at KDFW Dallas Fort Worth International Airport. Takeoff distance 4,146 ft 31 % of runway. Rotation speed was 152 kt. Local weather - Temperature 22 °F. .
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 4,146 ft31 % of runway
100 % Rotation speed was 152 ktTarget 146 kt
100 % Runway alignment max 17.0 ft left17.0 ft left to 2.0 ft right -2.0 17.0 ft
99.98 % Average g force 1.00 g0.82 g min to max 1.15 g 1.00 1.15 g
100 % Takeoff Bounce
Info Average pitch angle 0.9 °0.0 ° min to max 8.9 ° 0.9 8.9 °
Info Average bank angle 0.3 °0.0 ° min to max 0.8 ° 0.1 0.7 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 36L KDFW Dallas Fort Worth International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.2 °-0.2 ° min to max -0.2 ° -0.2 -0.2 °
100 % Average speed 163 kt160 kt min to max 166 kt 160 166 kt
100 % Steepest bank angle 2.8 °0.9 ° min to max 2.8 ° 0.9 2.8 °
100 % Average g force 1.27 g1.22 g min to max 1.30 g 1.23 1.29 g
Info Average VSI 1,008 fpm662 fpm min to max 1,407 fpm 662 1,407 fpm
Info Average altitude 11 ft agl0 ft agl min to max 32 ft agl 0 32 ft agl
Info Average pitch angle 12.8 °10.3 ° min to max 15.6 ° 10.3 15.6 °
Departure Climb 2 99.14Departure climb to 400 ft agl from 36L KDFW Dallas Fort Worth International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.2 °-0.2 ° min to max 0.5 ° -0.2 0.5 °
100 % Average speed 167 kt166 kt min to max 169 kt 166 169 kt
97 % Steepest bank angle 6.2 °1.1 ° min to max 6.2 ° 2.9 1.1 °
99.6 % Average g force 1.16 g0.94 g min to max 1.31 g 1.30 1.02 g
Info Average VSI 2,026 fpm1,438 fpm min to max 2,816 fpm 1,438 2,816 fpm
Info Average altitude 92 ft agl34 ft agl min to max 365 ft agl 34 365 ft agl
Info Average pitch angle 15.5 °13.6 ° min to max 16.1 ° 15.8 15.2 °

Events

Info Taxi Lights Off 278 ft agl · 164 kt
Departure Climb 3 70.00Departure climb to 1,000 ft agl from 36L KDFW Dallas Fort Worth International Airport.
ScoreDescriptionStartProfileEnd
100 % Climb speed 170 kt169 kt min to max 170 ktTarget 170 kt 169 170 kt
100 % Steepest bank angle 4.6 °0.7 ° min to max 4.6 ° 1.3 0.7 °
100 % Average g force 0.99 g0.96 g min to max 1.02 g 1.02 1.01 g
0 % Landing gear up at 0 ft aglTarget by 400 ft agl
Info Heading variation 1.0 °0.8 ° min to max 1.1 ° 0.8 1.1 °
Info Average VSI 3,199 fpm2,945 fpm min to max 3,419 fpm 2,945 3,419 fpm
Info Average altitude 691 ft agl419 ft agl min to max 1,027 ft agl 419 1,027 ft agl
Info Average pitch angle 16.0 °15.4 ° min to max 16.8 ° 15.4 16.8 °

Events

Fail Gear Not Retracted
Info Landing Gear Down 463 ft agl · 165 kt
Enroute Climb 100.00Enroute climb started overhead KDFW Dallas Fort Worth International Airport Dallas-Fort Worth (Texas, United States). Climbing from 1,347 ft asl to 33,987 ft asl, an increase of 32,640 ft in 17 minutes and covering 91 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 263 kt165 kt min to max 297 kt 171 278 kt
100 % Steepest bank angle 26.5 °0.0 ° min to max 26.5 ° 0.7 0.0 °
100 % Average g force 1.01 g0.86 g min to max 1.10 g 1.00 0.99 g
Info Average VSI 2,230 fpm-94 fpm min to max 3,944 fpm 3,497 -26 fpm
Info Average altitude 15,706 ft asl1,347 ft asl min to max 33,987 ft asl 1,347 33,987 ft asl
Info Average pitch angle 7.0 °1.6 ° min to max 17.4 ° 16.9 1.8 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Position 1 2,122 ft agl · 165 kt
Info Flaps Fully Retracted 2,158 ft agl · 167 kt
Info Landing Lights Off 10,003 ft agl · 283 kt
Enroute Level 100.00Enroute level cruise started 8 miles north of Ranger (Texas, United States) and lasted 80 minutes, covering 267 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,200 ft of 34,002 ft asl33,708 ft asl min to max 34,041 ft asl 33,992 33,708 ft asl
100 % Average speed 264 kt260 kt min to max 278 kt 278 262 kt
100 % Steepest bank angle 4.5 °0.0 ° min to max 4.5 ° 0.2 0.0 °
100 % Average g force 1.00 g0.98 g min to max 1.04 g 0.98 0.99 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 2.1 °0.8 ° min to max 2.4 ° 1.9 0.8 °
Enroute Descent 100.00Enroute descent started 30 miles south east of KCAX Carlsbad Airport Carlsbad (New Mexico, United States). Descent from 33,524 ft asl to 20,132 ft asl, a decrease of 13,392 ft in 11 minutes and covering 57 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 253 kt209 kt min to max 284 kt 262 209 kt
100 % Steepest bank angle 5.4 °0.0 ° min to max 5.4 ° 0.0 0.6 °
100 % Average g force 1.00 g0.97 g min to max 1.08 g 0.99 1.04 g
Info Average VSI -1,202 fpm-1,662 fpm min to max -921 fpm -983 -1,050 fpm
Info Average altitude 27,066 ft asl20,132 ft asl min to max 33,524 ft asl 33,524 20,132 ft asl
Info Average pitch angle 1.0 °-0.3 ° min to max 3.7 ° 0.8 3.7 °
Info Turn coordination 00 min to max 0 0 0
Enroute Level 2 100.00Enroute level cruise started 11 miles east of 2E5 Dell City Mun Dell City (Texas, United States) and lasted 7 minutes, covering 24 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±1,501 ft of 20,006 ft asl19,989 ft asl min to max 20,086 ft asl 20,020 20,003 ft asl
100 % Average speed 186 kt180 kt min to max 203 kt 203 180 kt
100 % Steepest bank angle 1.2 °0.0 ° min to max 1.2 ° 0.0 0.4 °
100 % Average g force 0.99 g0.95 g min to max 1.03 g 1.03 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 1.7 °-1.6 ° min to max 6.6 ° 5.6 -0.8 °

Events

Info Flaps Position 1 16,781 ft agl · 267 kt
Info Flaps Position 2 16,780 ft agl · 266 kt
Info Flaps Position 3 16,861 ft agl · 251 kt
Enroute Descent 2 100.00Enroute descent started 2 miles south east of KHOS Homestead Meadows South Airport Homestead Meadows South (Texas, United States). Descent from 19,998 ft asl to 7,388 ft asl, a decrease of 12,610 ft in 13 minutes and covering 39 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 174 kt145 kt min to max 181 kt 180 145 kt
100 % Steepest bank angle 5.0 °0.0 ° min to max 5.0 ° 0.2 0.0 °
100 % Average g force 1.00 g0.94 g min to max 1.09 g 1.01 0.99 g
Info Average VSI -994 fpm-2,209 fpm min to max 38 fpm -44 38 fpm
Info Average altitude 12,473 ft asl7,375 ft asl min to max 20,010 ft asl 19,998 7,388 ft asl
Info Average pitch angle -3.2 °-5.5 ° min to max 3.1 ° -0.8 3.1 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Position 4 4,847 ft agl · 199 kt
Info Landing Lights On 4,847 ft agl · 201 kt
Enroute Level 3 100.00Enroute level cruise started 3 miles north west of Homestead Meadows North (Texas, United States) and lasted 2 minutes, covering 4 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±870 ft of 7,387 ft asl7,371 ft asl min to max 7,400 ft asl 7,391 7,392 ft asl
100 % Average speed 141 kt133 kt min to max 145 kt 144 133 kt
100 % Steepest bank angle 26.5 °0.0 ° min to max 26.5 ° 0.0 0.2 °
100 % Average g force 1.03 g0.99 g min to max 1.12 g 1.00 0.99 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 4.3 °3.0 ° min to max 6.0 ° 3.3 5.9 °
Enroute Descent 3 100.00Enroute descent started 4 miles east of KBIF Biggs Army Air Field (Fort Bliss) Fort Bliss/El Paso (Texas, United States). Descent from 7,394 ft asl to 5,732 ft asl, a decrease of 1,662 ft in 2 minutes and covering 4 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 132 kt131 kt min to max 134 kt 132 132 kt
100 % Steepest bank angle 0.3 °0.0 ° min to max 0.3 ° 0.3 0.0 °
100 % Average g force 0.99 g0.91 g min to max 1.01 g 0.99 1.00 g
Info Average VSI -1,149 fpm-1,684 fpm min to max 13 fpm 2 -1,580 fpm
Info Average altitude 6,603 ft asl5,732 ft asl min to max 7,396 ft asl 7,394 5,732 ft asl
Info Average pitch angle 1.7 °0.2 ° min to max 6.2 ° 6.0 0.3 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Landing Gear Down 3,493 ft agl · 148 kt
Info Taxi Lights On 3,481 ft agl · 148 kt
Arrival Approach 100.00Final approach to runway 22 at KELP El Paso International Airport. Descent from 831 ft agl to 69 ft agl in 95 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed
100 % Landing flappassed
100 % Sink ratepassed
100 % On glideslopepassed
100 % On speedpassed
Arrival Landing 89.60Landing on runway 22 at KELP El Paso International Airport, runway length 12,012 ft. Good threshold height. Threshold speed was good at 132 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 132 kt. Target 131 kt
100 % Good threshold height.Target 50 ft agl
100 % Perfect landing flare
0 % Runway alignment max 183.8 ft left183.8 ft left to 152.4 ft left 183.7 152.4 ft
96 % Steepest bank angle 3.5 °0.0 ° min to max 3.5 ° 0.9 2.4 °
100 % Peak g force 1.11 g1.00 g min to max 1.11 g 1.00 1.06 g
Info Average speed 131 kt128 kt min to max 132 kt 132 128 kt
Info Average VSI -678 fpm-771 fpm min to max -450 fpm -771 -450 fpm
Info Average altitude 10 ft agl-8 ft agl min to max 33 ft agl 33 -8 ft agl
Info Average pitch angle 4.7 °2.6 ° min to max 6.0 ° 2.6 5.6 °
02505007501,00001123344557Runway Distance ftLanding Height ft02505007501,000-80-64-48-32-1601632486480Runway Distance ftRunway Width ft
Arrival Touchdown 84.40Touchdown distance was good at 925 ft. Touchdown speed at 128 kt was good. Touchdown rate was fair at -228 fpm. Runway touchdown position was excessively misaligned by 152 ft from centreline. Local weather - Temperature 58 °F. .
ScoreDescriptionStartProfileEnd
100 % Touchdown rate was -228 fpm.
100 % Touchdown distance was 925 ftTarget 1,500 ft
100 % Speed at touchdown 128 ktTarget below 130 kt
0 % Runway alignment max 152.4 ft left148.4 ft left 152.4 143.6 ft
95 % Steepest bank angle 2.4 °0.1 ° min to max 2.4 ° 2.4 0.8 °
93 % Peak g force 1.43 g0.99 g min to max 1.43 g 1.06 0.99 g
100 % Landing Bounce
Info Average speed 128 kt128 kt min to max 128 kt 128 128 kt
Info Average pitch angle 5.2 °4.6 ° min to max 5.6 ° 5.6 4.6 °
Arrival Rollout 73.30Total landing distance 3,399 ft, 28 % of runway. Runway rollout alignment was misaligned by 68 ft from centreline.
ScoreDescriptionStartProfileEnd
100 % Landing distance 3,399 ft28 % of runway.
41 % Runway alignment max 68.0 ft left68.0 ft left to 0.0 ft left 68.0 28.2 ft
99.8 % Average g force 0.96 g0.82 g min to max 1.28 g 0.89 0.96 g
Info Average speed 66 kt37 kt min to max 71 kt 71 37 kt
Info Average pitch angle 1.5 °-1.0 ° min to max 4.4 ° 4.4 -0.6 °
Info Average bank angle 0.4 °0.0 ° min to max 1.0 ° 0.7 0.8 °
Runway Exit Exiting runway, average speed 22 kt
ScoreDescriptionStartProfileEnd
Info Average speed 12 kt3 kt min to max 34 kt 34 9 kt
Info Average pitch angle -0.1 °-1.1 ° min to max 0.6 ° -0.7 0.6 °
Info Average bank angle 0.6 °0.0 ° min to max 2.7 ° 0.0 1.0 °
Info Average g force 1.00 g0.98 g min to max 1.01 g 1.01 1.01 g

Events

Info Parking Brake On  · 4 kt
Info Parking Brake Off  · 4 kt
Info Flaps Position 3  · 17 kt
Info Flaps Fully Retracted  · 19 kt
Info Strobe Lights Off  · 20 kt
Info Landing Lights Off  · 20 kt
Arrival Taxi 100.00Taxiing to the parking from the runway took 9 minutes and covered 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 7 kt0 kt min to max 10 kt 8 0 kt
100 % Average speed turning corners 7 ktmax 8 kt 0 0 kt
100 % Average g force 1.00 g0.98 g min to max 1.02 g 0.99 1.00 g
Info Average pitch angle 0.1 °-0.7 ° min to max 0.6 ° 0.3 0.2 °
Info Average bank angle 0.2 °0.0 ° min to max 1.3 ° 0.8 0.3 °

Takeoff from KDFW 36L

Taxi out

LightsOk
All on
Taxi speed100.00
10kt peak8 kt in turns

The roll

Takeoff roll100.00
4,146ft31 %
Runway alignment100.00
17.0ft L
Rotation speed100.00
152kttarget 146, 6 late

Rotated late, and the nose came up quickly

Rotation started at 152 kt, 6 kt after the 146 kt rotate speed, and the nose then rose at 3.4° a second, faster than the 2.0 to 2.9° a second other A20N pilots fly.

The pull started late and then came quickly, as if to make up the time. Start it on the rotate speed instead, so there is nothing to catch up, and keep it to the normal rate for this aircraft.

Liftoff and climb

Liftoff
158ktat 10.3°
Rotation
3.4°/sover 2.9 s, gaining 6 kt
35 ft
166ktat 15.8°, 2.4 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
2.8°steepest
Climb 3 speed100.00
170kttarget 170

Plan view the roll down the 13,436 ft runway.

Rolled from 353 ft in, drifted left of the centreline, 17 ft at the widest, and lifted off 18 ft left. Airborne 31 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length.

2,0004,0006,0008,00010,00012,000THRESHOLDLEFT ↑RIGHT ↓75 %widest 17.0 ft LROLL 353 FT INAirborne 4,269 ft from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 4,269 ft of 13,436 ft · 32 %
Behind the start of the roll, 353 ftTakeoff roll, 3,916 ft Left ahead, 9,167 ft

Side view from the start of the roll to the end of Climb 3 at 1,029 ft.

Reached 35 ft with 8,568 ft of runway left; then climbing at 3,010 fpm on average to 1,029 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The shaded stretch is Climb 3, scored on its average speed against the target.

1,250 ft625 ft0CLIMB 3170 kt avgtarget 170THRESHOLDRUNWAY END6080100120140KNOTS ALONG THE ROLLnose up on the runway · 621 ft · 2.9 sRotate 152 kttarget 146Liftoff 158 kt
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 170180 kt12060020°10°0°nose up on the runway · 621 ft · 2.9 sROTATELIFTOFFtarget 146held 15.7°10.3° off · 3.4°/s16° at 35 ftAIRSPEEDPITCH02040 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2.0 to 2.9° a second, the middle half of rotation rates flown by other A20N pilots over the last 180 days (207 takeoffs); the grey pair are 2 to 3° a second, the rates airliners are rotated at. A trace steeper than both green lines is a faster rotation than most, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 11.7°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 11.7°ROTATELIFTOFF35 FT10.3° off · 3.4°/s3°/s2.9°/s2°/s2.0°/s16° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5+6 sseconds from rotation
PitchRotation began2.0 to 2.9°/s, other A20N pilots2 to 3°/s from rotation, airlinersTail strikeNose up, wheels on the runway

The stabilisation gates

One stabilised approach gate: five checks where the approach path is 500 ft above the runway. The 1,000 ft gate was not assessed, because the approach did not join final that far out. These checks are the approach's score.

Five checks, one gate500 ft 100.005 of 5
Gear down
Landing flap
Sink rate800 fpm
On glideslope2.9°
On speed+2.1 kt

Still turning onto final at the lower gate, so the centreline and wings level are not asked there - the aeroplane was not lined up yet, and was banked because it was turning. The other checks are marked as usual.

When the approach was stable

Never every check met at once: left of the centreline all the way and low until 3.6 nm.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to KELP 22

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Low from 4 nm to 3.6 nm (up to 520 ft under), then back on it to the threshold.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 1,000 ft past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND799837653336193500 ft gate5 of 5520 ft · 133 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 3× larger than distances along the final.

Joined 5,590 ft left of the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR1000 ft L01000 ft RLEFT ↑RIGHT ↓1° BAND5587 ft L3674 ft L1577 ft L501 ft L300 ft L992 ft L
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 33 kt fast at the 1,000 ft gate, closing to 20 at 500 ft and 10 at the threshold.

Inside the speed band all the way, between +1 kt and +10 kt on the approach speed of 131 kt.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

120140160180 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 131+10 kt+9 kt+3 kt+2 kt+2 kt+1 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on KELP 22

Over the threshold

Threshold height100.00
32ft
Threshold speed100.00
132kttarget 131, 1 fast
Centreline offset0.00
183.8ft L
Bank96.00
3.5°steepest
Flare100.00

Perfect landing flare

Touchdown

Past threshold100.00
925ft
Centreline0.00
152.4ft L
Speed100.00
128kttarget 130 or less
Touchdown rate100.00
-228fpm
Impact93.45
1.43G
BouncesOk
None
Bank94.50
2.4°as the wheels touched

Rollout

Rollout distance100.00
2,358ft27 % used
Rollout alignment40.70
68.0ft L

Taxi in

LightsOk
All set
Taxi speed100.00
10kt peak7 kt in turns

Side view — the last 5,000 ft of the approach.

Crossed the threshold at 32 ft, 18 ft below the 50 ft target; began the flare at 19 ft. Touched down 925 ft in, close to the ideal 1,000 ft.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 5,000 ft across. The dashed line is the ideal, 50 ft over the threshold and down 1,000 ft in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

32 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 19 ft · −629 fpm · 4° · 132 ktdescent slowed at 0 ft · −232 fpm · 5.6°−228 fpm · 5.6° nose up · 128 kt Ideal — 50 ft, down at 1,000 ft This flight — 32 ft, down at 925 ft

Sink and pitch — through the flare, lined up with the side view.

The sink went from 630 fpm at the flare to 230 fpm at touchdown. The nose came up 1.6° on the way down. Into the flare at 132 kt, on the 131 kt approach speed, and 128 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−228 fpm at touchdown5.6° at touchdown, +1.6° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 5,000 ft of the 12,012 ft runway, to the same scale as the side view.

Touched down 144 ft left of the centreline, and steered back to 33 ft left by the end of the rollout. Calm: nothing to correct for. Touched down with the nose 9° right of the track, 2.4° of bank.

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

1,0002,0003,0004,0005,000 THRESHOLD LEFT ↑ RIGHT ↓ FULL SCORE TO 1,650 FT 925 ft past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

The 925 ft touchdown sits inside the full-score zone. The arrival was smooth.

Runway used 3,283 ft of 12,012 ft · 27 %
In the air over the runway, 925 ftRollout, 2,358 ft Left over, 8,729 ft

The stop — touchdown to taxi speed.

From 72 kt at touchdown to taxi speed (30 kt) in 16 s, an average deceleration of 0.14 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

02040608060 kt · 1,351 ft30 kt · 2,839 fttouchdown2,952 ftkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
