KDFW
Dallas-Fort Worth, United States
Runway 35L
Elevation564 ft asl
Weight37,970 kg
Fuel3,871 kg
Wind20° · 7 kn · 2 kn cross

Flight Score

95.77 %
KELP
El Paso, United States
Runway 22
Elevation3,914 ft asl
Weight35,497 kg
Fuel1,319 kg
Wind30° · 9 kn · 3 kn cross
3 Dec 2024 2:32 517 nm Douglas DC-6B 2,552 kg
Departure Score
98.32 %
Enroute Score
91.43 %
Arrival Score
97.55 %

What went well

Touched down at -42 fpm — a soft arrival
Touchdown 316 m in — inside the full-score zone
Threshold crossed at 25 ft and 87 kt — both inside band

What held you back

Enroute Descent — speed limits at 0 %, −1.90 points
Enroute Level — stall warning; speed limits at 0 %, −0.95 points
Arrival Rollout — Runway alignment max 13.37 m right at 74 %, −0.79 points

Next time

Departure

Make small rudder corrections against a point at the far end to hold the centreline.

What happened: During the ground roll you drifted 12 m off the runway centreline.

Watch for: Watch runway alignment against the centreline, correcting with small rudder inputs.

See Departure Roll

Arrival

Use small rudder inputs against a point at the far end of the runway to hold the centreline during rollout.

What happened: During the rollout the aircraft drifted 13 m off the centreline.

Watch for: Runway centreline marks: hold the aircraft tracking straight down the centreline through rollout

See Arrival Rollout

Below 10,000 ft you are typically limited to 250 kt indicated (a US rule that much of the world mirrors in some form, though not universally). This forces a deceleration around 10,000 ft whether the profile wants one or not, so plan for it rather than discovering it.

Read more in Descent Planning

Start to finish · 19 stages, 17 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 96.20Taxiing from the parking to the runway took 23 minutes and covered 8 nm.
ScoreDescriptionStartProfileEnd
91 % Average speed 20 kt0 kt min to max 32 kt 0 10 kt
100 % Average speed turning corners 12 ktmax 17 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.02 g 1.00 1.00 g
Info Average pitch angle 1.3 °-0.4 ° min to max 2.3 ° 1.5 1.2 °
Info Average bank angle 0.7 °0.0 ° min to max 2.2 ° 0.0 0.4 °

Events

Info Engine 4 Started 8 ft agl
Info Engine 2 Started 8 ft agl
Info Engine 1 Started 8 ft agl
Info Landing Lights Switched On 8 ft agl
Info Parking Brake Off 8 ft agl
Info Parking Brake On 8 ft agl · 1 kt
Info Flaps Position 1 8 ft agl · 1 kt
Info Flaps Position 2 8 ft agl · 1 kt
Info Flaps Position 3 8 ft agl · 1 kt
Info Parking Brake Off 8 ft agl · 2 kt
Departure Runway Entry Entering runway 35L at KDFW Dallas Fort Worth International Airport, Average speed was 15 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 10 kt0 kt min to max 20 kt 10 20 kt
Info Average pitch angle 1.6 °1.3 ° min to max 1.8 ° 1.3 1.7 °
Info Average bank angle 0.4 °0.3 ° min to max 0.5 ° 0.4 0.3 °
Info Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g

Events

Info Parking Brake On 8 ft agl · 5 kt
Info Parking Brake Off 8 ft agl · 5 kt
Departure Roll 97.67Departure roll runway 35L at KDFW Dallas Fort Worth International Airport. Takeoff distance 1,129 m 28 % of runway. Rotation speed was 108 kt. Local weather - Temperature 4 °C. Wind 7 kt at 20 °. Crosswind: 2 kt Headwind: 7 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 1,129 m28 % of runway
100 % Rotation speed was 108 ktTarget 109 kt
88 % Runway alignment max 11.98 m right0.63 m left to 11.98 m right 0.63 -10.32 m
100 % Average g force 1.00 g0.98 g min to max 1.04 g 0.99 1.04 g
100 % Takeoff Bounce
Info Average pitch angle 1.1 °0.4 ° min to max 3.6 ° 1.6 3.6 °
Info Average bank angle 0.2 °0.0 ° min to max 0.6 ° 0.3 0.6 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 35L KDFW Dallas Fort Worth International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.4 °0.2 ° min to max 0.5 ° 0.5 0.2 °
100 % Average speed 117 kt112 kt min to max 120 kt 112 120 kt
100 % Steepest bank angle 0.9 °0.5 ° min to max 0.9 ° 0.7 0.7 °
100 % Average g force 1.02 g0.99 g min to max 1.07 g 1.05 0.99 g
Info Average VSI 425 fpm244 fpm min to max 516 fpm 244 516 fpm
Info Average altitude 21 ft agl0 ft agl min to max 48 ft agl 0 48 ft agl
Info Average pitch angle 4.8 °3.7 ° min to max 5.2 ° 3.7 5.2 °
Departure Climb 2 100.00Departure climb to 400 ft agl from 35L KDFW Dallas Fort Worth International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.0 °-0.2 ° min to max 0.2 ° 0.2 0.1 °
100 % Average speed 129 kt120 kt min to max 167 kt 120 166 kt
100 % Steepest bank angle 1.4 °0.0 ° min to max 1.4 ° 0.7 0.8 °
100 % Average g force 0.99 g0.88 g min to max 1.09 g 0.99 1.06 g
Info Average VSI 467 fpm-136 fpm min to max 1,709 fpm 516 1,709 fpm
Info Average altitude 98 ft agl49 ft agl min to max 375 ft agl 49 375 ft agl
Info Average pitch angle 4.3 °2.3 ° min to max 8.2 ° 5.2 8.2 °

Events

Info Landing Gear Up 92 ft agl · 123 kt
Info Flaps Position 2 112 ft agl · 126 kt
Info Flaps Position 1 128 ft agl · 128 kt
Info Flaps Fully Retracted 138 ft agl · 129 kt
Departure Climb 3 97.73Departure climb to 1,000 ft agl from 35L KDFW Dallas Fort Worth International Airport.
ScoreDescriptionStartProfileEnd
94 % Climb speed 168 kt159 kt min to max 175 ktTarget 145 kt, 23 kt fast 165 175 kt
100 % Steepest bank angle 9.0 °0.1 ° min to max 9.0 ° 0.9 9.0 °
100 % Average g force 0.99 g0.88 g min to max 1.08 g 1.05 0.99 g
100 % Landing gear up at 84 ft aglTarget by 400 ft agl
Info Heading variation 0.6 °0.2 ° min to max 1.0 ° 0.2 0.8 °
Info Average VSI 949 fpm363 fpm min to max 2,115 fpm 1,840 950 fpm
Info Average altitude 736 ft agl407 ft agl min to max 960 ft agl 407 960 ft agl
Info Average pitch angle 4.5 °2.7 ° min to max 9.2 ° 8.8 3.8 °
Enroute Climb 100.00Enroute climb started overhead Coppell (Texas, United States). Climbing from 1,568 ft asl to 9,812 ft asl, an increase of 8,244 ft in 7 minutes and covering 21 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 171 kt157 kt min to max 184 kt 176 182 kt
100 % Steepest bank angle 14.7 °0.0 ° min to max 14.7 ° 8.5 0.0 °
100 % Average g force 1.01 g0.86 g min to max 1.08 g 0.98 0.99 g
Info Average VSI 1,187 fpm-223 fpm min to max 1,700 fpm 895 -40 fpm
Info Average altitude 4,020 ft asl1,568 ft asl min to max 9,851 ft asl 1,568 9,812 ft asl
Info Average pitch angle 5.0 °0.3 ° min to max 6.2 ° 3.5 0.3 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Master Switched On 1,581 ft agl · 181 kt
Info Autopilot Heading Hold Activated 1,581 ft agl · 181 kt
Info Autopilot Flight Director Activated 1,581 ft agl · 181 kt
Info Autopilot Master Switched Off 6,194 ft agl · 176 kt
Info Autopilot Heading Hold Deactivated 6,194 ft agl · 176 kt
Info Autopilot Flight Director Deactivated 6,194 ft agl · 176 kt
Info Autopilot Master Switched On 6,486 ft agl · 177 kt
Info Autopilot Heading Hold Activated 6,486 ft agl · 177 kt
Info Autopilot Flight Director Activated 6,486 ft agl · 177 kt
Info Autopilot Altitude Hold Activated 9,004 ft agl · 197 kt
Enroute Level 100.00Enroute level cruise started 3 miles east of Newark (Texas, United States) and lasted 110 minutes, covering 433 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±991 ft of 9,893 ft asl9,778 ft asl min to max 9,989 ft asl 9,812 9,983 ft asl
100 % Average speed 205 kt168 kt min to max 209 kt 185 168 kt
100 % Steepest bank angle 20.6 °0.0 ° min to max 20.6 ° 0.1 0.1 °
100 % Average g force 1.01 g0.97 g min to max 1.10 g 0.97 1.02 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle -0.3 °-0.9 ° min to max 1.6 ° 0.4 1.6 °

Events

Info Autopilot Nav1 Lock Activated 9,008 ft agl · 219 kt
Info Autopilot Heading Hold Deactivated 9,008 ft agl · 219 kt
Info Pitot Heat Switched On 8,945 ft agl · 240 kt
Info Landing Lights Switched Off 6,738 ft agl · 239 kt
Enroute Descent 100.00Enroute descent started 3 miles north west of 65TX Flying Eagle Ranch Airport Salt Flat (Texas, United States). Descent from 9,984 ft asl to 9,094 ft asl, a decrease of 890 ft in 2 minutes and covering 6 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 175 kt164 kt min to max 191 kt 166 191 kt
100 % Steepest bank angle 0.2 °0.0 ° min to max 0.2 ° 0.0 0.1 °
100 % Average g force 0.99 g0.88 g min to max 1.01 g 1.01 1.00 g
Info Average VSI -518 fpm-856 fpm min to max -1 fpm -60 -751 fpm
Info Average altitude 9,664 ft asl9,094 ft asl min to max 9,991 ft asl 9,984 9,094 ft asl
Info Average pitch angle -0.7 °-1.9 ° min to max 1.4 ° 1.2 -1.9 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Altitude Hold Deactivated 5,594 ft agl · 192 kt
Enroute Level 2 100.00Enroute level cruise started 6 miles south west of KHOS Homestead Meadows South Airport Homestead Meadows South (Texas, United States) and lasted 9 minutes, covering 24 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±949 ft of 8,830 ft asl8,808 ft asl min to max 8,972 ft asl 8,972 8,875 ft asl
100 % Average speed 162 kt134 kt min to max 194 kt 193 134 kt
100 % Steepest bank angle 18.3 °0.0 ° min to max 18.3 ° 0.1 0.2 °
100 % Average g force 1.00 g0.94 g min to max 1.09 g 1.00 0.95 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 1.4 °-2.0 ° min to max 2.6 ° -2.0 0.6 °

Events

Info Autopilot Altitude Hold Activated 4,178 ft agl · 222 kt
Info Pitot Heat Switched Off 3,695 ft agl · 187 kt
Info Flaps Position 1 2,916 ft agl · 179 kt
Info Flaps Position 2 3,643 ft agl · 178 kt
Info Flaps Position 3 4,329 ft agl · 162 kt
Info Flaps Position 4 4,353 ft agl · 161 kt
Info Autopilot Heading Hold Activated 4,417 ft agl · 154 kt
Info Autopilot Altitude Hold Deactivated 4,417 ft agl · 154 kt
Enroute Descent 2 100.00Enroute descent started 8 miles north east of Homestead Meadows North (Texas, United States). Descent from 8,822 ft asl to 5,856 ft asl, a decrease of 2,966 ft in 3 minutes and covering 8 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 123 kt109 kt min to max 134 kt 131 109 kt
100 % Steepest bank angle 12.8 °0.0 ° min to max 12.8 ° 0.6 12.8 °
100 % Average g force 1.02 g0.94 g min to max 1.11 g 0.98 0.94 g
Info Average VSI -647 fpm-1,220 fpm min to max 420 fpm -810 308 fpm
Info Average altitude 6,587 ft asl5,822 ft asl min to max 8,822 ft asl 8,822 5,856 ft asl
Info Average pitch angle -1.6 °-4.7 ° min to max 4.0 ° -3.4 3.2 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Altitude Hold Activated 2,682 ft agl · 139 kt
Info Autopilot Altitude Hold Deactivated 2,666 ft agl · 136 kt
Info Autopilot Nav1 Lock Deactivated 1,998 ft agl · 133 kt
Info Autopilot Master Switched Off 1,883 ft agl · 132 kt
Info Autopilot Heading Hold Deactivated 1,856 ft agl · 132 kt
Info Autopilot Flight Director Deactivated 1,856 ft agl · 132 kt
Info Autopilot Master Switched On 1,830 ft agl · 132 kt
Info Autopilot Heading Hold Activated 1,830 ft agl · 132 kt
Info Autopilot Flight Director Activated 1,830 ft agl · 132 kt
Info Autopilot Altitude Hold Activated 1,802 ft agl · 132 kt
Enroute Level 3 80.00Enroute level cruise started 6 miles north of Homestead Meadows North (Texas, United States) and lasted 2 minutes, covering 3 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±793 ft of 5,667 ft asl5,486 ft asl min to max 5,858 ft asl 5,858 5,553 ft asl
0 % Average speed 100 kt91 kt min to max 113 kt 108 91 kt
100 % Steepest bank angle 21.6 °0.2 ° min to max 21.6 ° 14.7 1.2 °
100 % Average g force 1.00 g0.93 g min to max 1.17 g 0.94 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 5.5 °0.5 ° min to max 9.5 ° 2.6 8.2 °

Events

Fail Stall Warning Activated 1,539 ft agl · 99 kt
Info Flaps Position 4 1,747 ft agl · 103 kt
Info Flaps Position 3 1,746 ft agl · 102 kt
Enroute Descent 3 60.00Enroute descent started 5 miles north west of Homestead Meadows North (Texas, United States). Descent from 5,547 ft asl to 4,685 ft asl, a decrease of 862 ft in 2 minutes and covering 4 nm.
ScoreDescriptionStartProfileEnd
0 % Average speed 92 kt80 kt min to max 110 kt 90 110 kt
100 % Steepest bank angle 24.7 °0.1 ° min to max 24.7 ° 0.8 5.2 °
100 % Average g force 1.00 g0.85 g min to max 1.17 g 1.01 1.10 g
Info Average VSI -361 fpm-1,659 fpm min to max 1,017 fpm -360 -1,101 fpm
Info Average altitude 5,153 ft asl4,685 ft asl min to max 5,547 ft asl 5,547 4,685 ft asl
Info Average pitch angle 9.9 °3.0 ° min to max 15.6 ° 8.4 6.2 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Position 2 1,503 ft agl · 90 kt
Info Autopilot Nav1 Lock Activated 1,382 ft agl · 96 kt
Info Autopilot Heading Hold Deactivated 1,382 ft agl · 96 kt
Info Flaps Position 1 1,107 ft agl · 93 kt
Info Autopilot Altitude Hold Deactivated 857 ft agl · 112 kt
Info Autopilot Master Switched Off 843 ft agl · 113 kt
Info Autopilot Nav1 Lock Deactivated 843 ft agl · 113 kt
Info Autopilot Flight Director Deactivated 843 ft agl · 113 kt
Info Stall Warning Deactivated 834 ft agl · 114 kt
Info Stall Warning Activated 852 ft agl · 108 kt
Info Flaps Fully Retracted 967 ft agl · 95 kt
Arrival Approach 100.00Final approach to runway 22 at KELP El Paso International Airport. Descent from 856 ft agl to 69 ft agl in 126 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed
100 % Landing flappassed
100 % Sink ratepassed
100 % On glideslopepassed
100 % On centrelinepassed
100 % On speedpassed
100 % Wings levelpassed

Events

Fail Landing Lights OFF should be ON 4,685 ft agl
Info Stall Warning Deactivated 649 ft agl · 120 kt
Info Landing Gear Down 646 ft agl · 118 kt
Info Stall Warning Activated 646 ft agl · 118 kt
Info Stall Warning Deactivated 661 ft agl · 117 kt
Info Stall Warning Activated 720 ft agl · 109 kt
Info Flaps Position 1 595 ft agl · 111 kt
Info Stall Warning Deactivated 561 ft agl · 111 kt
Info Flaps Position 2 626 ft agl · 105 kt
Info Flaps Position 3 623 ft agl · 105 kt
Info Flaps Position 4 623 ft agl · 107 kt
Info Flaps Position 5 660 ft agl · 98 kt
Info Flaps Position 6 481 ft agl · 103 kt
Arrival Landing 99.66Landing on runway 22 at KELP El Paso International Airport, runway length 3,661 m. Good threshold height. Threshold speed was good at 87 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 87 kt. Target 87 kt
100 % Good threshold height.Target 50 ft agl
100 % Perfect landing flare
100 % Runway alignment max 4.48 m left4.48 m left to 1.40 m left 1.40 3.83 m
97 % Steepest bank angle 3.5 °1.2 ° min to max 3.5 ° 3.4 1.2 °
100 % Peak g force 1.09 g0.95 g min to max 1.09 g 0.95 1.01 g
Info Average speed 85 kt82 kt min to max 88 kt 87 83 kt
Info Average VSI -309 fpm-484 fpm min to max -48 fpm -389 -48 fpm
Info Average altitude 6 ft agl-2 ft agl min to max 25 ft agl 25 -2 ft agl
Info Average pitch angle 5.3 °2.7 ° min to max 6.8 ° 2.8 6.6 °
07515022530037501123344657Runway Distance mLanding Height ft075150225300375-24-20-16-12-8-404812162024Runway Distance mRunway Width m
Arrival Touchdown 100.00Touchdown distance was good at 316 m. Touchdown speed at 83 kt was good. Touchdown rate was perfect at -42 fpm. Runway touchdown position was slightly misaligned by 3.8 m from centreline. Local weather - Temperature 7 °C. Wind 7 kt at 29 °. Crosswind: 2 kt Tailwind: 6 kt.
ScoreDescriptionStartProfileEnd
100 % Touchdown rate was -42 fpm.
100 % Touchdown distance was 316 mTarget 457 m
100 % Speed at touchdown 83 ktTarget below 87 kt
100 % Runway alignment max 3.83 m left3.66 m left 3.83 3.48 m
100 % Steepest bank angle 1.2 °0.6 ° min to max 1.2 ° 1.2 0.6 °
100 % Peak g force 1.03 g1.01 g min to max 1.03 g 1.01 1.02 g
100 % Landing Bounce
Info Average speed 82 kt81 kt min to max 83 kt 83 81 kt
Info Average pitch angle 6.6 °6.6 ° min to max 6.6 ° 6.6 6.6 °
Arrival Rollout 88.08Total landing distance 1,463 m, 40 % of runway. Runway rollout alignment was slightly misaligned by 13.4 m from centreline.
ScoreDescriptionStartProfileEnd
100 % Landing distance 1,463 m40 % of runway.
74 % Runway alignment max 13.37 m right0.00 m left to 13.37 m right -2.82 -3.28 m
100 % Average g force 1.00 g0.94 g min to max 1.03 g 1.02 1.00 g
Info Average speed 87 kt48 kt min to max 93 kt 93 48 kt
Info Average pitch angle 4.4 °0.7 ° min to max 7.0 ° 6.6 1.0 °
Info Average bank angle 0.6 °0.0 ° min to max 1.2 ° 0.6 0.5 °
Runway Exit Exiting runway, average speed 18 kt
ScoreDescriptionStartProfileEnd
Info Average speed 25 kt11 kt min to max 45 kt 45 11 kt
Info Average pitch angle 1.1 °0.8 ° min to max 1.6 ° 1.0 0.9 °
Info Average bank angle 0.2 °0.1 ° min to max 0.5 ° 0.5 0.2 °
Info Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.01 g
Arrival Taxi 100.00Taxiing to the parking from the runway took 7 minutes and covered 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 15 kt0 kt min to max 21 kt 10 0 kt
100 % Average speed turning corners 16 ktmax 16 kt 0 0 kt
100 % Average g force 1.00 g0.97 g min to max 1.01 g 1.01 0.97 g
Info Average pitch angle 1.4 °0.9 ° min to max 1.9 ° 0.9 1.0 °
Info Average bank angle 0.2 °0.0 ° min to max 0.6 ° 0.1 0.4 °

Events

Info Parking Brake On 8 ft agl
Info Parking Brake Off 8 ft agl
Info Parking Brake On 8 ft agl · 3 kt

Takeoff from KDFW 35L

Taxi out

LightsOk
All on
Taxi speed95.25
32kt peak12 kt in turns

The roll

Takeoff roll100.00
1,129m28 %
Runway alignment88.36
11.98m R
Rotation speed100.00
108kttarget 109, 1 early

On speed, but the nose came up slowly

Rotation started at 108 kt, 1 kt before the 109 kt rotate speed. The nose then rose at 1.2° a second, slower than the 2 to 3° a second airliners use.

The rotation started on speed but the nose came up slowly. Make it one positive, continuous pull at the normal rate for this aircraft, rather than easing the nose up in steps.

Liftoff and climb

Liftoff
112ktat 3.7°
Rotation
1.2°/sover 2.0 s, gaining 4 kt
35 ft
119ktat 5.2°, 5.1 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
0.9°steepest
Gear up100.00
84ftfull marks to 400 ft
Climb 3 speed94.32
168kttarget 145

Plan view the roll down the 4,094 m runway.

Rolled from 221 m in, drifted right of the centreline, 12 m at the widest, and lifted off 10 m right. Airborne 27 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

1,0002,0003,0004,000THRESHOLDLEFT ↑RIGHT ↓CROSS2 kn75 %widest 11.99 m RROLL 221 M INAirborne 1,133 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,133 m of 4,094 m · 28 %
Behind the start of the roll, 221 mTakeoff roll, 911 m Left ahead, 2,961 m

Side view from the start of the roll to the end of Climb 3 at 961 ft.

Reached 35 ft with 2,674 m of runway left; gear up at 84 ft, inside the 400 ft that gets full marks; then climbing at 720 fpm on average to 961 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3168 kt avgtarget 145THRESHOLDRUNWAY END6080KNOTS ALONG THE ROLLnose up on the runway · 101 m · 2.0 sRotate 108 kttarget 109Liftoff 112 ktGear up 84 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 145180 kt12060020°10°0°nose up on the runway · 101 m · 2.0 sROTATELIFTOFFGEAR UPtarget 109held 4.5°3.7° off · 1.2°/s5° at 35 ftAIRSPEEDPITCH0306090 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2 to 3° a second, the rates airliners are rotated at: a trace steeper than both is a faster rotation, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate.

20°10°0°ROTATELIFTOFF35 FT2°/s3°/s3.7° off · 1.2°/s5° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5+6+7+8 sseconds from rotation
PitchRotation began2 to 3°/s from rotationNose up, wheels on the runway

The stabilisation gates

One stabilised approach gate: seven checks where the approach path is 500 ft above the runway. The 1,000 ft gate was not assessed, because the approach did not join final that far out. These checks are the approach's score.

Seven checks, one gate500 ft 100.007 of 7
Gear down
Landing flap
Sink rate910 fpm
On glideslope3.4°
On centreline0.5° off
On speed+8.0 kt
Wings level2° bank

When the approach was stable

Every check met from 0.6 to 0.3 nm, then not again: low from 0.2 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to KELP 22

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Low from 4 nm to 3.4 nm (up to 560 ft under), then back on it to 0.2 nm, then low to the threshold (up to 40 ft under).

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND813693623410177500 ft gate7 of 7605 ft · 95 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 3× larger than distances along the final.

Joined 295 m right of the centreline, then inside it from 3.6 to 3.2 nm, then drifted 172 m left between 3.2 and 2.2 nm, then inside the band from 2.2 nm to the threshold.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR305 m L0305 m RLEFT ↑RIGHT ↓1° BAND295 m R155 m L43 m L6 m R14 m L23 m L
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 22 kt fast at the 1,000 ft gate, closing to 13 at 500 ft and 10 at the threshold.

Fast from 4 nm to 3.5 nm (up to +25 kt), then inside the band to 1.0 nm, then fast to 0.6 nm (up to +13 kt), then inside the band to the threshold.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

80100120140 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 87+17 kt+16 kt+12 kt+12 kt+9 kt+0 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on KELP 22

Over the threshold

Threshold height100.00
25ft
Threshold speed100.00
87kton target
Centreline offset100.00
4.48m L
Bank96.57
3.5°steepest
Flare100.00

Perfect landing flare

Touchdown

Past threshold100.00
316m
Centreline100.00
3.83m L
Speed100.00
82kttarget 87 or less
Touchdown rate100.00
-42fpm
Impact100.00
1.03G
BouncesOk
None
Bank100.00
1.2°as the wheels touched

Rollout

Rollout distance100.00
1,119m39 % used
Rollout alignment73.51
13.37m R

Taxi in

LightsOk
All set
Taxi speed100.00
21kt peak16 kt in turns

Side view — the last 1,557 m of the approach.

Crossed the threshold at 25 ft, 25 ft below the 50 ft target; began the flare at 11 ft. Touched down 316 m in, close to the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,557 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

25 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 11 ft · −446 fpm · 3.9° · 86 ktdescent slowed at 1 ft · −36 fpm · 6.7°−41 fpm · 6.6° nose up · 83 kt Ideal — 50 ft, down at 305 m This flight — 25 ft, down at 316 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 450 fpm at the flare to 40 fpm at touchdown. The nose came up 2.7° on the way down. Into the flare at 86 kt, on the 87 kt approach speed, and 83 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−41 fpm at touchdown6.6° at touchdown, +2.7° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,557 m of the 3,661 m runway, to the same scale as the side view.

Touched down 3.5 m left of the centreline and drifted to 12 m right on the rollout, back to 4.1 m right by the end. Little crosswind (2 kt): nothing to correct for. Touched down with the nose 5° right of the track, wings level.

Wind 030° at 9 kt · 8 kt tail · 2 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ CROSS 2 kn FULL SCORE TO 503 M 316 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

The 316 m touchdown sits inside the full-score zone. The arrival was smooth.

Runway used 1,436 m of 3,661 m · 39 %
In the air over the runway, 316 mRollout, 1,119 m Left over, 2,226 m

The rest of the report

Explore in detail

Flight narrative

The flight in the Douglas DC-6B began with a 19-minute taxi from the parking area to the runway at KDFW Dallas Fort Worth International Airport. The departure roll from runway 35L covered 2 nm, with a takeoff distance of 1,009 m, utilizing 25% of the runway. The liftoff speed was 112 kn. The local weather at departure was 4 °C with a wind of 7 kn at 12 °, resulting in a crosswind of 1 kn and a headwind of 7 kn.

The enroute climb started overhead Coppell (Texas, United States), climbing from 1,568 ft asl to 9,799 ft asl, covering 19 nm in 7 minutes. The enroute level cruise began 3 miles east of Newark and lasted 111 minutes, covering 416 nm. The enroute descent started 4 miles south west of KHOS Homestead Meadows South Airport, descending from 9,736 ft asl to 8,811 ft asl in 2 minutes and covering 8 nm.

Another enroute level cruise commenced 10 miles west of KHOS Homestead Meadows South Airport and lasted 7 minutes, covering 17 nm. The second descent started 9 miles north east of Homestead Meadows North, descending from 8,840 ft asl to 5,810 ft asl in 4 minutes and covering 11 nm. A brief level cruise followed, starting 6 miles north west of Homestead Meadows North and lasting 4 minutes, covering 7 nm.

The final approach to runway 22 at KELP El Paso International Airport was made from the north east at 4 nm and 757 ft agl. The landing on runway 22 had good threshold height and touchdown distance, with a slightly below target threshold speed of 87 kn and a good touchdown speed of 83 kn. The touchdown rate was perfect at -48 ft/m, and the runway touchdown alignment was very good. The total landing distance was 1,461 m, covering 45% of the runway, with a misalignment of 15.4 m from the centerline.

After landing, the taxi from the runway to the parking area took 7 minutes and covered less than 1 nm. The total flight distance was 490 nm, taking 152 minutes and utilizing 2,552 kg of fuel.

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
