My FS Flights logo MY FS FLIGHTS
LOWW
Vienna, Austria
Runway 16
Elevation587 ft asl
Weight282,651 kg
Fuel28,040 kg
Wind140° · 7 kn · 3 kn cross

Flight Score

99.99 %
EHAM
Amsterdam, The Netherlands
Runway 18C
Elevation-10 ft asl
Weight271,061 kg
Fuel15,701 kg
Wind149° · 1 kn · 1 kn cross
9 Oct 2024 1:30 570 nm Boeing 747-8 12,339 kg
Departure Score
100.00 %
Enroute Score
100.00 %
Arrival Score
99.98 %

What went well

Touched down at -206 fpm — a soft arrival
Touchdown 368 m in — inside the full-score zone
Threshold crossed at 41 ft and 136 kt — both inside band

What held you back

Nothing — every scored stage stayed inside its band. Clean flight.

Start to finish · 15 stages, 13 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 7 minutes and covered 2 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 14 kt0 kt min to max 21 kt 0 14 kt
100 % Average speed turning corners 12 ktmax 12 kt 0 0 kt
100 % Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Info Average pitch angle -0.7 °-0.7 ° min to max -0.6 ° -0.6 -0.7 °
Info Average bank angle 0.1 °0.0 ° min to max 0.4 ° 0.0 0.1 °

Events

Info Battery Master On 15 ft agl
Info Engine 1 Started 15 ft agl
Info Engine 4 Started 15 ft agl
Info Beacon Lights Switched On 15 ft agl
Info Navigation Lights Switched On 15 ft agl
Info Autopilot Flight Director Activated 15 ft agl
Info Autopilot Yaw Damper Activated 15 ft agl
Info Landing Gear Down 15 ft agl
Info Engine 2 Started 15 ft agl · 3 kt
Info Engine 3 Started 15 ft agl · 3 kt
Info Taxi Lights Switched On 15 ft agl · 4 kt
Info Flaps Position 3 15 ft agl · 5 kt
Info Autopilot Vertical Hold Activated 15 ft agl · 6 kt
Info Parking Brake On 15 ft agl · 6 kt
Info Parking Brake Off 15 ft agl · 6 kt
Info Landing Lights Switched On 15 ft agl · 9 kt
Info Strobe Lights Switched On 15 ft agl · 9 kt
Departure Runway Entry Entering runway 16 at LOWW Vienna International Airport, Average speed was 21 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 15 kt14 kt min to max 15 kt 15 14 kt
Info Average pitch angle -0.7 °-0.7 ° min to max -0.7 ° -0.7 -0.7 °
Info Average bank angle 0.1 °0.1 ° min to max 0.2 ° 0.1 0.2 °
Info Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Departure Roll 100.00Departure roll runway 16 at LOWW Vienna International Airport. Takeoff distance 999 m 28 % of runway. Rotation speed was 136 kt. Local weather - Temperature 18 °C. Wind 7 kt at 140 °. Crosswind: 3 kt Headwind: 6 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 999 m28 % of runway
100 % Rotation speed was 136 ktTarget 142 kt
100 % Runway alignment max 1.19 m right0.00 m left to 1.19 m right -1.16 -0.62 m
100 % Average g force 1.00 g1.00 g min to max 1.05 g 1.00 1.05 g
100 % Takeoff Bounce
Info Average pitch angle 0.1 °-0.7 ° min to max 9.3 ° -0.7 9.3 °
Info Average bank angle 0.2 °0.0 ° min to max 0.6 ° 0.1 0.6 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 16 LOWW Vienna International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.0 °0.0 ° min to max 0.0 ° 0.0 0.0 °
100 % Average speed 157 kt147 kt min to max 165 kt 147 165 kt
100 % Steepest bank angle 0.7 °0.0 ° min to max 0.7 ° 0.6 0.6 °
100 % Average g force 1.07 g1.00 g min to max 1.13 g 1.06 1.10 g
Info Average VSI 532 fpm131 fpm min to max 887 fpm 131 887 fpm
Info Average altitude 18 ft agl0 ft agl min to max 43 ft agl 0 43 ft agl
Info Average pitch angle 9.5 °8.9 ° min to max 10.1 ° 9.5 9.9 °
Departure Climb 2 100.00Departure climb to 400 ft agl from 16 LOWW Vienna International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.0 °-0.1 ° min to max 0.0 ° 0.0 -0.1 °
100 % Average speed 174 kt166 kt min to max 199 kt 166 199 kt
100 % Steepest bank angle 1.7 °0.1 ° min to max 1.7 ° 0.6 1.7 °
100 % Average g force 1.09 g0.95 g min to max 1.12 g 1.11 0.97 g
Info Average VSI 1,375 fpm909 fpm min to max 2,652 fpm 909 2,652 fpm
Info Average altitude 101 ft agl45 ft agl min to max 372 ft agl 45 372 ft agl
Info Average pitch angle 10.1 °9.0 ° min to max 10.4 ° 10.0 9.0 °

Events

Info Landing Gear Up 68 ft agl · 170 kt
Info Autopilot Heading Hold Activated 90 ft agl · 175 kt
Info Flaps Position 2 394 ft agl · 205 kt
Departure Climb 3 100.00Departure climb to 1,000 ft agl from 16 LOWW Vienna International Airport.
ScoreDescriptionStartProfileEnd
100 % Climb speed 217 kt202 kt min to max 230 ktTarget 202 kt, 15 kt fast 202 230 kt
100 % Steepest bank angle 23.3 °0.3 ° min to max 23.3 ° 2.1 23.3 °
100 % Average g force 0.99 g0.93 g min to max 1.03 g 1.02 1.03 g
100 % Landing gear up at 45 ft aglTarget by 400 ft agl
Info Heading variation -0.0 °-0.1 ° min to max 0.0 ° -0.1 -0.1 °
Info Average VSI 3,007 fpm2,696 fpm min to max 3,241 fpm 2,696 2,878 fpm
Info Average altitude 697 ft agl418 ft agl min to max 976 ft agl 418 976 ft agl
Info Average pitch angle 8.7 °7.9 ° min to max 9.4 ° 9.2 8.1 °

Events

Info Autopilot Master Switched On 585 ft agl · 218 kt
Enroute Climb 100.00Enroute climb started overhead Klein-Neusiedl (Niederoesterreich, Austria). Climbing from 1,645 ft asl to 35,609 ft asl, an increase of 33,963 ft in 13 minutes and covering 92 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 284 kt233 kt min to max 325 kt 233 281 kt
100 % Steepest bank angle 30.5 °0.0 ° min to max 30.5 ° 25.5 7.3 °
100.00 % Average g force 1.05 g0.79 g min to max 1.31 g 1.02 0.99 g
Info Average VSI 2,823 fpm-482 fpm min to max 4,858 fpm 2,843 -46 fpm
Info Average altitude 15,612 ft asl1,645 ft asl min to max 35,624 ft asl 1,645 35,609 ft asl
Info Average pitch angle 6.5 °1.2 ° min to max 13.7 ° 7.9 1.8 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Fully Retracted 1,360 ft agl · 252 kt
Info Autopilot AutoThrottle Arm Armed 1,616 ft agl · 253 kt
Info Autopilot Airspeed Hold Activated 1,663 ft agl · 253 kt
Info Autopilot Airspeed Hold Deactivated 2,753 ft agl · 266 kt
Info Autopilot Vertical Hold Deactivated 2,753 ft agl · 266 kt
Info Autopilot RPM Hold Activated 2,753 ft agl · 266 kt
Info Landing Lights Switched Off 10,139 ft agl · 308 kt
Info Taxi Lights Switched Off 10,169 ft agl · 310 kt
Info Autopilot Airspeed Hold Activated 33,484 ft agl · 492 kt
Info Autopilot Vertical Hold Activated 33,484 ft agl · 492 kt
Info Autopilot RPM Hold Deactivated 33,484 ft agl · 492 kt
Enroute Level 100.00Enroute level cruise started 2 miles south west of Gastern (Niederoesterreich, Austria) and lasted 47 minutes, covering 372 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,280 ft of 35,393 ft asl35,190 ft asl min to max 35,607 ft asl 35,607 35,193 ft asl
100 % Average speed 295 kt280 kt min to max 299 kt 281 297 kt
100 % Steepest bank angle 12.2 °0.0 ° min to max 12.2 ° 7.8 1.0 °
100 % Average g force 1.00 g0.92 g min to max 1.08 g 0.99 1.02 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 1.4 °0.9 ° min to max 2.1 ° 1.8 1.4 °
Enroute Descent 100.00Enroute descent started overhead Gronau (Nordrhein-Westfalen, Germany). Descent from 35,192 ft asl to 1,278 ft asl, a decrease of 33,915 ft in 19 minutes and covering 98 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 234 kt142 kt min to max 305 kt 297 142 kt
100 % Steepest bank angle 27.3 °0.0 ° min to max 27.3 ° 7.2 0.5 °
100 % Average g force 1.03 g0.80 g min to max 1.27 g 1.01 0.99 g
Info Average VSI -1,544 fpm-4,529 fpm min to max 1,135 fpm -34 -676 fpm
Info Average altitude 13,651 ft asl1,278 ft asl min to max 35,218 ft asl 35,192 1,278 ft asl
Info Average pitch angle 0.2 °-4.6 ° min to max 6.3 ° 1.3 3.2 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Airspeed Hold Deactivated 35,066 ft agl · 508 kt
Info Autopilot Vertical Hold Deactivated 35,066 ft agl · 508 kt
Info Autopilot RPM Hold Activated 35,066 ft agl · 508 kt
Info Autopilot RPM Hold Deactivated 34,499 ft agl · 493 kt
Info Autopilot Airspeed Hold Activated 31,794 ft agl · 494 kt
Info Autopilot Vertical Hold Activated 31,794 ft agl · 494 kt
Info Landing Lights Switched On 9,816 ft agl · 308 kt
Info Taxi Lights Switched On 9,752 ft agl · 301 kt
Info Flaps Position 1 6,311 ft agl · 233 kt
Info Flaps Position 2 6,313 ft agl · 231 kt
Info Flaps Position 3 3,893 ft agl · 216 kt
Info Landing Gear Down 3,614 ft agl · 204 kt
Info Flaps Position 4 3,323 ft agl · 187 kt
Info Autopilot Heading Hold Deactivated 3,168 ft agl · 168 kt
Info Autopilot Approach Mode Activated 3,168 ft agl · 168 kt
Info Autopilot Vertical Hold Deactivated 3,168 ft agl · 168 kt
Info Flaps Position 6 2,624 ft agl · 152 kt
Info Autopilot AutoThrottle Arm Disarmed 1,458 ft agl · 147 kt
Info Autopilot Master Switched Off 1,436 ft agl · 147 kt
Arrival Approach 100.00Final approach to runway 18C at EHAM Amsterdam Airport Schiphol. Descent from 1,321 ft agl to 58 ft agl in 99 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates
Arrival Landing 99.98Landing on runway 18C at EHAM Amsterdam Airport Schiphol, runway length 3,291 m. Good threshold height. Threshold speed was good at 136 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 136 kt. Target 137 kt
100 % Good threshold height.Target 50 ft agl
100 % Perfect landing flare
100 % Runway alignment max 3.36 m left3.36 m left to 2.30 m left 3.36 2.66 m
99.8 % Steepest bank angle 2.2 °0.3 ° min to max 2.2 ° 1.2 0.7 °
100 % Peak g force 1.11 g1.00 g min to max 1.11 g 1.01 1.06 g
Info Average speed 135 kt132 kt min to max 136 kt 136 132 kt
Info Average VSI -532 fpm-721 fpm min to max -296 fpm -721 -296 fpm
Info Average altitude 18 ft agl2 ft agl min to max 41 ft agl 41 2 ft agl
Info Average pitch angle 5.9 °4.6 ° min to max 7.0 ° 4.6 6.4 °
07515022530037545001123344657Runway Distance mLanding Height ft075150225300375450-25-20-15-10-50510152025Runway Distance mRunway Width m
Arrival Touchdown 99.94Touchdown distance was good at 368 m. Touchdown speed at 132 kt was good. Touchdown rate was fair at -206 fpm. Runway touchdown position was slightly misaligned by 3.1 m from centreline. Local weather - Temperature 15 °C. Wind 1 kt at 149 °. Crosswind: 1 kt Headwind: 1 kt.
ScoreDescriptionStartProfileEnd
100 % Touchdown rate was -206 fpm.
100 % Touchdown distance was 368 mTarget 457 m
100 % Speed at touchdown 132 ktTarget below 137 kt
100 % Runway alignment max 3.05 m left2.82 m left 2.66 3.05 m
100 % Steepest bank angle 0.9 °0.0 ° min to max 0.9 ° 0.7 0.0 °
99 % Peak g force 1.34 g1.00 g min to max 1.34 g 1.06 1.09 g
100 % Landing Bounce
Info Average speed 132 kt131 kt min to max 132 kt 132 131 kt
Info Average pitch angle 6.3 °6.1 ° min to max 6.4 ° 6.4 6.1 °
Arrival Rollout 100.00Total landing distance 1,244 m, 38 % of runway. Runway rollout alignment was very good.
ScoreDescriptionStartProfileEnd
100 % Landing distance 1,244 m38 % of runway.
100 % Runway alignment max 5.09 m left5.09 m left to 0.00 m left 5.09 0.34 m
100 % Average g force 0.98 g0.92 g min to max 1.09 g 1.09 1.00 g
Info Average speed 122 kt73 kt min to max 132 kt 132 73 kt
Info Average pitch angle 4.3 °-0.8 ° min to max 6.1 ° 6.1 -0.8 °
Info Average bank angle 0.2 °0.0 ° min to max 0.8 ° 0.0 0.4 °
Runway Exit Exiting runway, average speed 27 kt
ScoreDescriptionStartProfileEnd
Info Average speed 26 kt16 kt min to max 65 kt 65 19 kt
Info Average pitch angle -0.8 °-1.0 ° min to max -0.4 ° -0.7 -0.4 °
Info Average bank angle 0.2 °0.0 ° min to max 0.6 ° 0.6 0.0 °
Info Average g force 1.00 g0.99 g min to max 1.01 g 1.01 1.00 g

Events

Info Flaps Fully Retracted 15 ft agl · 18 kt
Arrival Taxi 100.00Taxiing to the parking from the runway took 4 minutes and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 8 kt2 kt min to max 19 kt 19 2 kt
100 % Average speed turning corners 5 ktmax 5 kt 0 0 kt
100 % Average g force 1.00 g1.00 g min to max 1.01 g 1.01 1.00 g
Info Average pitch angle -0.7 °-1.5 ° min to max -0.1 ° -0.4 -0.8 °
Info Average bank angle 0.0 °0.0 ° min to max 0.7 ° 0.0 0.0 °

Events

Info Landing Lights Switched Off 15 ft agl · 12 kt
Info Strobe Lights Switched Off 15 ft agl · 12 kt

Takeoff from LOWW 16

Taxi out

LightsOk
All on
Taxi speed100.00
21kt peak12 kt in turns

The roll

Takeoff roll100.00
999m28 %
Runway alignment100.00
1.19m R
Rotation speed100.00
136kttarget 142, 6 early

Rotated early, and the nose came up quickly

Rotation started at 136 kt, 6 kt before the 142 kt rotate speed, and the nose then rose at 4.1° a second, faster than the 2 to 3° a second airliners use.

Early and quick together is the classic tail-strike setup: the nose reaches its liftoff attitude before the aircraft has the speed to fly. Wait for the rotate speed, then pull smoothly at the normal rate for this aircraft and let it lift off at its own attitude.

Liftoff and climb

Liftoff
147ktat 9.5°
Rotation
4.1°/sover 2.3 s, gaining 11 kt
35 ft
163ktat 9.5°, 3.0 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
0.7°steepest
Gear up100.00
45ftfull marks to 400 ft
Climb 3 speed100.00
217kttarget 202

Plan view the roll down the 3,596 m runway.

Rolled from 100 m in, never more than 1.5 m off the centreline. Airborne 27 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

1,0002,0003,000THRESHOLDLEFT ↑RIGHT ↓CROSS2 kn75 %widest 1.46 m RROLL 100 M INAirborne 1,004 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,004 m of 3,596 m · 28 %
Behind the start of the roll, 100 mTakeoff roll, 903 m Left ahead, 2,592 m

Side view from the start of the roll to the end of Climb 3 at 977 ft.

Reached 35 ft with 2,355 m of runway left; gear up at 45 ft, inside the 400 ft that gets full marks; then climbing at 2,320 fpm on average to 977 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3217 kt avgtarget 202THRESHOLDRUNWAY END6080100120KNOTS ALONG THE ROLLnose up on the runway · 168 m · 2.3 sRotate 136 kttarget 142Liftoff 147 ktGear up 45 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 202240 kt16080020°10°0°nose up on the runway · 168 m · 2.3 sROTATELIFTOFFtarget 142held 9.7°9.5° off · 4.1°/s10° at 35 ftAIRSPEEDPITCH02040 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2 to 3° a second, the rates airliners are rotated at: a trace steeper than both is a faster rotation, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 12.1°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 12.1°ROTATELIFTOFF35 FT9.5° off · 4.1°/s3°/s2°/s10° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5+6 sseconds from rotation
PitchRotation began2 to 3°/s from rotationTail strikeNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate790 fpm940 fpm
On glideslope3.0°2.9°
On centreline0.1° off0.0° off
On speed+3.7 kt+1.7 kt
Wings level1° bank1° bank

When the approach was stable

Every check met from 4 nm to 0.4 nm, then not again: left of the centreline from 0.4 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to EHAM 18C

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 50 ft below the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,3056753331881,000 ft gate7 of 71,022 ft · 142 kt500 ft gate7 of 7509 ft · 140 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 18× larger than distances along the final.

Inside the 1° band from 4 nm to 0.4 nm, then 14 m left of it from 0.4 nm to the threshold.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR52 m L052 m RLEFT ↑RIGHT ↓1° BAND6 m R13 m L1 m R14 m L6 m R1 m R
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 35 kt fast at the 1,000 ft gate, closing to 21 at 500 ft and 10 at the threshold.

Inside the speed band all the way, between −2 kt and +5 kt on the approach speed of 138 kt.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

140160180200 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 138+4 kt+2 kt+2 kt+0 kt−2 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on EHAM 18C

Over the threshold

Threshold height100.00
41ft
Threshold speed100.00
136kttarget 137, 1 slow
Centreline offset100.00
3.36m L
Bank99.75
2.2°steepest
Flare100.00

Perfect landing flare

Touchdown

Past threshold100.00
368m
Centreline100.00
3.05m L
Speed100.00
132kttarget 137 or less
Touchdown rate100.00
-206fpm
Impact98.81
1.34G
BouncesOk
None
Bank100.00
0.9°as the wheels touched

Rollout

Rollout distance100.00
832m36 % used
Rollout alignment100.00
5.09m L

Taxi in

LightsOk
All set
Taxi speed100.00
19kt peak5 kt in turns

Side view — the last 1,524 m of the approach.

Crossed the threshold at 41 ft, close to the 50 ft target; began the flare at 32 ft. Touched down 368 m in, 63 m past the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,524 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

41 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 32 ft · −752 fpm · 5.3° · 136 ktdescent slowed at 15 ft · −342 fpm · 5.6°−206 fpm · 6.4° nose up · 132 kt Ideal — 50 ft, down at 305 m This flight — 41 ft, down at 368 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 750 fpm at the flare to 210 fpm at touchdown. The nose came up 1.2° on the way down. Into the flare at 136 kt, on the 137 kt approach speed, and 132 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−206 fpm at touchdown6.4° at touchdown, +1.2° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,524 m of the 3,291 m runway, to the same scale as the side view.

Touched down 3.1 m left of the centreline, and steered back to 0.3 m left by the end of the rollout. No crosswind: nothing to correct for. Touched down straight, wings level.

Wind 149° at 1 kt · 1 kt head · 0 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ FULL SCORE TO 503 M 368 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

The 368 m touchdown sits inside the full-score zone. The arrival was smooth.

Runway used 1,200 m of 3,291 m · 36 %
In the air over the runway, 368 mRollout, 832 m Left over, 2,091 m

The stop — touchdown to taxi speed.

From 134 kt at touchdown to taxi speed (30 kt) in 24 s, an average deceleration of 0.23 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 941 m30 kt · 1,089 mtouchdown1,132 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Flight narrative

The flight in the Boeing 747-8 started with a 6-minute taxi from the parking area to the runway at LOWW Schwechat. The departure roll from runway 16 covered a distance of 2,924 ft, with liftoff speed recorded at 147 kn. The local weather at the time showed a temperature of 61 °F with a 7 kn wind coming from 140 °, resulting in a crosswind of 3 kn and a headwind of 6 kn.

The enroute climb began over Klein-Neusiedl (Niederoesterreich, Austria), with an ascent from 1,645 ft asl to 35,612 ft asl, covering 67 nm in 13 minutes. The climb was followed by a level cruise starting over Waidhofen an der Thaya (Niederoesterreich, Austria) lasting 48 minutes and covering 379 nm.

The enroute descent commenced 1 mile northeast of Enschede (Provincie Overijssel, The Netherlands), descending from 35,210 ft asl to 1,814 ft asl over 81 nm in 18 minutes. The landing on runway 18C at EHAM Schiphol had a runway length of 9,341 ft, with the aircraft touching down 1,221 ft from the threshold at a speed of 132 kn and a VSI of -296 ft/m. The total landing distance covered was 4,097 ft, which accounted for 44% of the runway.

Following the landing, the aircraft taxied back to the parking area from the runway in 4 minutes, covering less than 1 nm. The total flight distance for this journey was recorded at 537 nm, with a total flight time of 103 minutes and fuel consumption of 27,203 lbs. The local weather during landing showed a temperature of 60 °F with a 1 kn wind coming from 149 °, resulting in minimal crosswind and headwind components.

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
