EGNV
Darlington, England
Runway 23
Elevation115 ft asl
Weight54,191 kg
Fuel4,042 kg
Wind270° · 1 kn · 1 kn cross

Flight Score

94.46 %
EGXE
Leeming, England
Runway 34
Elevation118 ft asl
Weight54,045 kg
Fuel3,833 kg
Wind269° · 1 kn · 1 kn cross
26 Apr 2024 0:11 33 nm Airbus A320 Neo 209 kg
Departure Score
93.04 %
Enroute Score
99.95 %
Arrival Score
90.38 %

What went well

Touchdown 379 m in — inside the full-score zone
Straight touchdown — 0.54 m off the centreline, no bounce
Rollout controlled — 41 % of the runway used

What held you back

Firm touchdown — 760 fpm, −2.37 points across the landing and the touchdown
  • Arrival Touchdown · sink rate 760 fpm−1.33
  • Arrival Landing · flare: the descent was not taken out−0.95
  • Arrival Touchdown · 1.74 G at contact−0.08
Departure Climb 3 — climb speed 246 kt against 170 kt at 14 %, −2.32 points
Arrival Approach — GPWS warning; 1,000 ft gate 100 %, 500 ft gate 86 %, −0.48 points
Arrival Landing — GPWS warning; Flare profile at 36 %, Threshold speed was well above target at 151 kt at 88 %, −1.28 points

Next time

Departure

Reduce climb power to bring speed back to 170 kt and hold it there.

What happened: Climb speed was 76 kt fast at 246 kt during the climb.

Watch for: Airspeed indicator: 170 kt in the climb

See Departure Climb 3

Arrival

Close the throttles further on final so you cross the threshold at 134 kt, removing the excess energy before the flare.

What happened: The aircraft crossed the threshold at 150 kt, 16 kt above the 134 kt target, and the flare was not begun until 1.4 ft, well inside the normal flare band. Carrying excess speed that late into the approach usually leaves the flare started late and the touchdown arriving firm.

Watch for: Airspeed indicator: 134 kt at the threshold

See Arrival LandingArrival Touchdown

Fast at the threshold, normal flare, and the runway seems to refuse the aircraft. The instinctive fix - pushing it on - causes the next one. A fast aircraft forced onto the runway touches nosewheel-first or nearly so. The tell is a touchdown that feels soft followed by a bounce that steepens. Pilots fix the bounce recovery; the cause was the 10 knots at the threshold.

Read more in VRef Explained

Start to finish · 16 stages, 15 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took less than 1 minute. and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 0 kt0 kt min to max 0 kt 0 0 kt
100 % Average speed turning corners 0 ktmax 0 kt 0 0 kt
100 % Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Info Average pitch angle -0.4 °-0.4 ° min to max -0.3 ° -0.3 -0.4 °
Info Average bank angle 0.0 °0.0 ° min to max 0.0 ° 0.0 0.0 °

Events

Info Battery Master On 115 ft agl
Info Engine 1 Started 115 ft agl
Info Engine 2 Started 115 ft agl
Info Beacon Lights Switched On 115 ft agl
Info Landing Lights Switched On 115 ft agl
Info Navigation Lights Switched On 115 ft agl
Info Strobe Lights Switched On 115 ft agl
Info Autopilot Flight Director Activated 115 ft agl
Info Landing Gear Down 115 ft agl
Info Parking Brake On 115 ft agl
Info Flaps Position 1 115 ft agl
Info Parking Brake Off 8 ft agl
Info Landing Lights Switched Off 8 ft agl
Info Taxi Lights Switched On 8 ft agl
Info Parking Brake On 8 ft agl
Info Flaps Fully Retracted 8 ft agl
Departure Roll 100.00Departure roll runway 23 at EGNV Teesside International Airport. Takeoff distance 1,132 m 50 % of runway. Rotation speed was 138 kt. Local weather - Temperature 17 °C. Wind 1 kt at 270 °. Crosswind: 1 kt Headwind: 1 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 1,132 m50 % of runway
100 % Rotation speed was 138 ktTarget 143 kt
100 % Runway alignment max 0.66 m right0.00 m left to 0.66 m right -0.62 -0.27 m
100 % Average g force 1.00 g0.96 g min to max 1.05 g 1.00 1.03 g
100 % Takeoff Bounce
Info Average pitch angle 0.2 °-0.4 ° min to max 5.6 ° -0.1 5.6 °
Info Average bank angle 0.1 °0.0 ° min to max 0.2 ° 0.1 0.1 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 23 EGNV Teesside International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.0 °0.0 ° min to max 0.0 ° 0.0 0.0 °
100 % Average speed 164 kt151 kt min to max 178 kt 151 178 kt
100 % Steepest bank angle 0.5 °0.0 ° min to max 0.5 ° 0.1 0.3 °
100 % Average g force 1.06 g0.97 g min to max 1.13 g 1.04 0.97 g
Info Average VSI 599 fpm254 fpm min to max 831 fpm 254 831 fpm
Info Average altitude 19 ft agl0 ft agl min to max 49 ft agl 0 49 ft agl
Info Average pitch angle 5.5 °3.8 ° min to max 6.4 ° 5.8 3.8 °
Departure Climb 2 99.99Departure climb to 400 ft agl from 23 EGNV Teesside International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.0 °-0.1 ° min to max 0.0 ° 0.0 -0.1 °
100 % Average speed 188 kt178 kt min to max 199 kt 178 198 kt
100 % Steepest bank angle 0.7 °0.0 ° min to max 0.7 ° 0.3 0.2 °
99.9 % Average g force 1.01 g0.79 g min to max 1.26 g 0.96 0.88 g
Info Average VSI 984 fpm818 fpm min to max 2,121 fpm 833 1,060 fpm
Info Average altitude 105 ft agl50 ft agl min to max 362 ft agl 50 362 ft agl
Info Average pitch angle 4.4 °3.4 ° min to max 7.2 ° 3.8 6.3 °

Events

Info Autopilot Yaw Damper Activated 61 ft agl · 180 kt
Info Landing Gear Up 208 ft agl · 199 kt
Info Flaps Fully Retracted 208 ft agl · 199 kt
Departure Climb 3 65.23Departure climb to 1,000 ft agl from 23 EGNV Teesside International Airport.
ScoreDescriptionStartProfileEnd
14 % Climb speed 246 kt201 kt min to max 264 ktTarget 170 kt, 76 kt fast 201 251 kt
98 % Steepest bank angle 25.3 °0.0 ° min to max 25.3 ° 0.1 25.1 °
100 % Average g force 1.00 g0.80 g min to max 1.14 g 0.85 1.10 g
100 % Landing gear up at 160 ft aglTarget by 400 ft agl
Info Heading variation -0.5 °-2.1 ° min to max -0.1 ° -0.1 -2.1 °
Info Average VSI 699 fpm238 fpm min to max 1,531 fpm 898 280 fpm
Info Average altitude 551 ft agl376 ft agl min to max 672 ft agl 376 672 ft agl
Info Average pitch angle 3.4 °1.2 ° min to max 5.5 ° 5.4 2.8 °

Events

Info Autopilot Airspeed Hold Activated 614 ft agl · 259 kt
Info Autopilot AutoThrottle Arm Armed 614 ft agl · 259 kt
Enroute Climb 99.75Enroute climb started 2 miles south west of EGNV Teesside International Airport Darlington (Darlington, England). Climbing from 803 ft asl to 2,822 ft asl, an increase of 2,019 ft in 1 minutes and covering 4 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 250 kt243 kt min to max 253 kt 251 250 kt
100 % Steepest bank angle 25.6 °0.5 ° min to max 25.6 ° 25.0 2.2 °
98 % Average g force 1.06 g0.69 g min to max 1.68 g 1.10 1.06 g
Info Average VSI 1,856 fpm271 fpm min to max 4,454 fpm 279 2,123 fpm
Info Average altitude 1,379 ft asl803 ft asl min to max 2,822 ft asl 803 2,822 ft asl
Info Average pitch angle 6.1 °2.4 ° min to max 13.4 ° 2.8 6.1 °
Info Turn coordination 00 min to max 0 0 0
Enroute Level 99.99Enroute level cruise started 2 miles south east of East Cowton (North Yorkshire, England) and lasted 2 minutes, covering 7 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±658 ft of 3,255 ft asl3,168 ft asl min to max 3,314 ft asl 3,168 3,306 ft asl
100 % Average speed 252 kt247 kt min to max 260 kt 250 250 kt
100 % Steepest bank angle 14.4 °0.0 ° min to max 14.4 ° 4.6 0.1 °
99.9 % Average g force 0.96 g0.62 g min to max 1.06 g 0.91 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 1.9 °0.9 ° min to max 4.7 ° 4.7 1.6 °

Events

Fail Exceeded 250 kn below 10000 ft 3,267 ft agl
Info Autopilot AutoThrottle Arm Disarmed 3,086 ft agl · 263 kt
Enroute Descent 99.99Enroute descent started 1 mile north west of Pickhill (North Yorkshire, England). Descent from 3,302 ft asl to 2,663 ft asl, a decrease of 639 ft in 2 minutes and covering 7 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 251 kt242 kt min to max 256 kt 250 242 kt
100 % Steepest bank angle 25.6 °0.0 ° min to max 25.6 ° 0.1 23.4 °
99.9 % Average g force 1.06 g0.76 g min to max 1.36 g 1.01 1.36 g
Info Average VSI -1,232 fpm-1,969 fpm min to max 51 fpm -25 -1,202 fpm
Info Average altitude 3,063 ft asl2,663 ft asl min to max 3,316 ft asl 3,302 2,663 ft asl
Info Average pitch angle -1.6 °-3.6 ° min to max 1.6 ° 1.6 -0.7 °
Info Turn coordination 00 min to max 0 0 0

Events

Fail Exceeded 250 kn below 10000 ft 3,133 ft agl
Fail Overspeed Warning Activated 2,670 ft agl · 260 kt
Info Landing Gear Down 2,899 ft agl · 265 kt
Info Flaps Position 1 2,899 ft agl · 265 kt
Enroute Level 2 100.00Enroute level cruise started overhead Sharow (North Yorkshire, England) and lasted 1 minutes, covering 4 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±633 ft of 2,672 ft asl2,543 ft asl min to max 2,708 ft asl 2,653 2,543 ft asl
100 % Average speed 176 kt157 kt min to max 240 kt 240 160 kt
100 % Steepest bank angle 26.2 °5.3 ° min to max 26.2 ° 22.7 5.3 °
100 % Average g force 1.07 g0.86 g min to max 1.33 g 1.33 0.99 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 1.5 °-1.1 ° min to max 3.9 ° 0.1 -0.7 °

Events

Fail Overspeed Warning Activated 2,513 ft agl · 224 kt
Info Flaps Position 2 2,492 ft agl · 242 kt
Info Overspeed Warning Deactivated 2,494 ft agl · 230 kt
Info Overspeed Warning Deactivated 2,495 ft agl · 212 kt
Info Flaps Position 3 2,486 ft agl · 208 kt
Enroute Descent 2 100.00Enroute descent started 1 mile north west of Dishforth (North Yorkshire, England). Descent from 2,427 ft asl to 1,527 ft asl, a decrease of 901 ft in 1 minutes and covering 3 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 158 kt156 kt min to max 159 kt 158 159 kt
100 % Steepest bank angle 3.9 °0.0 ° min to max 3.9 ° 3.9 1.2 °
100 % Average g force 1.01 g0.91 g min to max 1.08 g 1.00 1.04 g
Info Average VSI -845 fpm-963 fpm min to max -515 fpm -515 -714 fpm
Info Average altitude 1,806 ft asl1,527 ft asl min to max 2,427 ft asl 2,427 1,527 ft asl
Info Average pitch angle -0.4 °-0.7 ° min to max -0.0 ° -0.2 -0.2 °
Info Turn coordination 00 min to max 0 0 0
Arrival Approach 92.86Final approach to runway 34 at EGXE RAF Leeming Air Base. Descent from 1,447 ft agl to 76 ft agl in 88 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
50 % On speedfailed at one of the two gates
100 % Wings levelpassed at both gates

Events

Fail GPWS Warning Activated 988 ft agl · 160 kt
Arrival Landing 80.84Landing on runway 34 at EGXE RAF Leeming Air Base, runway length 2,275 m. Good threshold height. Threshold speed was well above target at 151 kt.
ScoreDescriptionStartProfileEnd
88 % Threshold speed was well above target at 151 kt. Target 134 kt
100 % Good threshold height.Target 50 ft agl
36 % The flare strayed well off the target profile. Crossing the threshold 17 kt above target, the flare began at 1 ft agl above the runway, lower than this aircraft wants. Touchdown was 379 m past the threshold. Begin raising the nose earlier - a late flare leaves no time to arrest the sink.
99.7 % Runway alignment max 7.04 m right1.75 m right to 7.04 m right -7.04 -1.75 m
99 % Steepest bank angle 2.5 °0.4 ° min to max 2.5 ° 0.4 2.2 °
100 % Peak g force 1.10 g0.96 g min to max 1.10 g 1.08 0.98 g
Info Average speed 148 kt145 kt min to max 151 kt 151 145 kt
Info Average VSI -699 fpm-896 fpm min to max -616 fpm -896 -718 fpm
Info Average altitude 28 ft agl1 ft agl min to max 55 ft agl 55 1 ft agl
Info Average pitch angle 1.3 °0.5 ° min to max 2.2 ° 1.9 0.5 °

Events

Fail GPWS Warning Activated still on from Arrival Approach 988 ft agl · 160 kt
Info Autopilot Yaw Damper Deactivated 45 ft agl · 149 kt
07515022530037545001123344657Runway Distance mLanding Height ft075150225300375450-24-20-16-12-8-404812162024Runway Distance mRunway Width m
Arrival Touchdown 78.22Touchdown distance was good at 379 m. Touchdown speed at 145 kt was a little fast. Touchdown rate was very heavy at -760 fpm. Runway touchdown alignment was very good. Local weather - Temperature 18 °C. Wind 1 kt at 269 °. Crosswind: 1 kt Headwind: 0 kt.
ScoreDescriptionStartProfileEnd
0 % Touchdown rate was -760 fpm.
100 % Touchdown distance was 379 mTarget 457 m
98 % Speed at touchdown 145 ktTarget below 134 kt
100 % Runway alignment max 1.75 m right1.15 m right -1.75 -0.54 m
99 % Steepest bank angle 2.2 °0.0 ° min to max 2.2 ° 2.2 0.0 °
75 % Peak g force 1.74 g0.98 g min to max 1.74 g 0.98 1.22 g
100 % Landing Bounce
Info Average speed 145 kt144 kt min to max 145 kt 145 144 kt
Info Average pitch angle 0.2 °0.1 ° min to max 0.5 ° 0.5 0.2 °

Events

Fail GPWS Warning Activated still on from Arrival Approach 988 ft agl · 160 kt
Info GPWS Warning Deactivated 9 ft agl · 144 kt
Arrival Rollout 100.00Total landing distance 977 m, 43 % of runway. Runway rollout alignment was perfect.
ScoreDescriptionStartProfileEnd
100 % Landing distance 977 m43 % of runway.
100 % Runway alignment max 0.61 m left0.61 m left to 0.27 m right 0.61 -0.27 m
100 % Average g force 1.01 g0.96 g min to max 1.15 g 1.15 0.99 g
Info Average speed 131 kt74 kt min to max 143 kt 143 74 kt
Info Average pitch angle -0.1 °-0.4 ° min to max 0.2 ° 0.2 -0.2 °
Info Average bank angle 0.1 °0.0 ° min to max 0.2 ° 0.0 0.1 °
Runway Exit Exiting runway, average speed 12 kt
ScoreDescriptionStartProfileEnd
Info Average speed 12 kt4 kt min to max 65 kt 65 4 kt
Info Average pitch angle -0.7 °-0.9 ° min to max -0.4 ° -0.4 -0.8 °
Info Average bank angle 0.1 °0.0 ° min to max 0.2 ° 0.1 0.1 °
Info Average g force 1.00 g0.98 g min to max 1.01 g 0.98 1.00 g

Events

Info Flaps Fully Retracted 8 ft agl · 52 kt
Arrival Taxi 100.00Taxiing to the parking from the runway took less than 1 minute. and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 4 kt4 kt min to max 4 kt 4 4 kt
100 % Average speed turning corners 0 ktmax 0 kt 0 0 kt
100 % Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Info Average pitch angle -0.7 °-0.8 ° min to max -0.6 ° -0.7 -0.7 °
Info Average bank angle 0.1 °0.1 ° min to max 0.1 ° 0.1 0.1 °

Takeoff from EGNV 23

Taxi out

LightsOk
All on

The roll

Takeoff roll100.00
1,132m50 %
Runway alignment100.00
0.66m R
Rotation speed100.00
138kttarget 143, 5 early

The nose wandered in the climb

From 35 ft to the end of the climb the nose moved between 1.2° and 7.3°, and the speed between 172 kt and 264 kt.

Once clear of the runway the nose moved through a wide range, and the speed moved with it. Set the climb attitude, hold it and trim, and give the speed a few seconds to settle before correcting it with a degree or two of pitch. Chasing the airspeed with large pitch changes makes it wander more.

Liftoff and climb

Liftoff
150ktat 5.8°
Rotation
2.8°/sover 1.9 s, gaining 12 kt
35 ft
172ktat 4.7°, 3.4 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
0.5°steepest
Gear up100.00
160ftfull marks to 400 ft
Climb 3 speed13.93
246kttarget 170

Plan view the roll down the 2,284 m runway.

Rolled from 305 m in, never more than 0.5 m off the centreline. Airborne 49 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length.

5001,0001,5002,000THRESHOLDLEFT ↑RIGHT ↓75 %widest 0.53 m RROLL 305 M INAirborne 1,138 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,138 m of 2,284 m · 50 %
Behind the start of the roll, 305 mTakeoff roll, 834 m Left ahead, 1,145 m

Side view from the start of the roll to the end of Climb 3 at 672 ft. The distance scale changes past the runway end.

Reached 35 ft with 862 m of runway left; gear up at 160 ft, inside the 400 ft that gets full marks; then climbing at 910 fpm on average to 672 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

750 ft375 ft0CLIMB 3246 kt avgtarget 170THRESHOLDRUNWAY END6080100120KNOTS ALONG THE ROLLnose up on the runway · 147 m · 1.9 sRotate 138 kttarget 143Liftoff 150 ktGear up 160 ftfull marks to 400 ftSCALE CHANGES3.9 km past the runway
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 170270 kt18090020°10°0°nose up on the runway · 147 m · 1.9 sROTATELIFTOFFGEAR UPtarget 143held 4.1°5.8° off · 2.8°/s5° at 35 ftAIRSPEEDPITCH0204060 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2.0 to 2.9° a second, the middle half of rotation rates flown by other Airbus A320 Neo pilots over the last 180 days (207 takeoffs); the grey pair are 2 to 3° a second, the rates airliners are rotated at. A trace steeper than both green lines is a faster rotation than most, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 11.7°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 11.7°ROTATELIFTOFF35 FT2.9°/s3°/s5.8° off · 2.8°/s2°/s2.0°/s5° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5+6 sseconds from rotation
PitchRotation began2.0 to 2.9°/s, other Airbus A320 Neo pilots2 to 3°/s from rotation, airlinersTail strikeNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 85.716 of 7
Gear down
Landing flap
Sink rate930 fpm930 fpm
On glideslope3.4°3.5°
On centreline0.9° off0.9° off
On speed+22 kt+24 kt
Wings level0° bank0° bank

At the 500 ft gate: speed more than 20 kt above the approach speed of 134 kt.

When the approach was stable

Every check met from 4 nm to 2.4 nm, then not again: fast from 2.1 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to EGXE 34

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 120 ft above the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,4277744372461,000 ft gate7 of 71,171 ft · 156 kt500 ft gate6 of 7on speed642 ft · 158 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 4× larger than distances along the final.

Inside the 1° band from 4 nm to 2.4 nm, then drifted 77 m left between 2.4 and 1.9 nm, then inside the band from 1.9 nm to the threshold.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR223 m L0223 m RLEFT ↑RIGHT ↓1° BAND76 m L64 m L13 m L6 m R88 m L45 m L
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 34 kt fast at the 1,000 ft gate, closing to 20 at 500 ft and 10 at the threshold.

Inside the speed band from 4 nm to 2.1 nm, then fast to the threshold (up to +25 kt).

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

120140160180 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 134+24 kt+25 kt+23 kt+23 kt+17 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on EGXE 34

Over the threshold

Threshold height100.00
54ft
Threshold speed87.89
150kttarget 134, 16 fast
Centreline offset99.69
7.04m R
Bank98.90
2.5°steepest
Flare36.03

The flare strayed well off the target profile

Crossing the threshold 17 kt above target, the flare began at 1 ft agl above the runway, lower than this aircraft wants. Touchdown was 379 m past the threshold. Begin raising the nose earlier - a late flare leaves no time to arrest the sink.

Touchdown

Past threshold100.00
379m
Centreline100.00
1.75m R
Speed97.53
145kttarget 133, 12 fast
Touchdown rate0.00
-760fpm
Impact75.00
1.74G
BouncesOk
None
Bank99.26
2.2°as the wheels touched

Rollout

Rollout distance100.00
554m41 % used
Rollout alignment100.00
0.61m L

Taxi in

LightsOk
All set
Taxi speed100.00
4kt peak

Side view — the last 1,524 m of the approach.

Crossed the threshold at 54 ft, close to the 50 ft target; began the flare late, at 1 ft. Touched down 379 m in, 74 m past the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,524 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

54 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 1 ft · −651 fpm · 0.5° · 145 ktdescent slowed at 1 ft · −650 fpm · 0.5°−759 fpm · 0.5° nose up · 145 kt Ideal — 50 ft, down at 305 m This flight — 54 ft, down at 379 m

Sink and pitch — through the flare, lined up with the side view.

The sink grew from 650 fpm at the flare to 760 fpm at touchdown. The pitch barely changed. Into the flare at 145 kt, 11 kt over the 134 kt approach speed, and 145 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−759 fpm at touchdown0.5° at touchdown, −0° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,524 m of the 2,275 m runway, to the same scale as the side view.

Touched down on the centreline, and stayed within 1.7 m of it down the rollout. No crosswind: nothing to correct for. Touched down straight, 2.2° of bank.

Wind 269° at 1 kt · 0 kt head · 0 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ FULL SCORE TO 503 M 379 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

The 379 m touchdown sits inside the full-score zone. The 759 fpm arrival was firm.

Runway used 933 m of 2,275 m · 41 %
In the air over the runway, 379 mRollout, 554 m Left over, 1,341 m

The stop — touchdown to taxi speed.

From 145 kt at touchdown to taxi speed (30 kt) in 17 s, an average deceleration of 0.36 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012016060 kt · 666 m30 kt · 775 mtouchdown806 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
