KTPA
Tampa, United States
Runway 01L
Elevation10 ft asl
Weight132,350 lbs
Fuel11,495 lbs
Wind299° · 4 kn · 4 kn cross

Flight Score

98.06 %
KMIA
Miami, United States
Runway 12
Elevation7 ft asl
Weight128,290 lbs
Fuel6,552 lbs
Wind70° · 5 kn · 4 kn cross
21 Mar 2025 0:59 242 nm FNX320_TCACFM 4,943 lbs
Departure Score
95.66 %
Enroute Score
100.00 %
Arrival Score
98.51 %

What went well

Touched down at -202 fpm — a soft arrival
Touchdown 1,553 ft in — inside the full-score zone
Straight touchdown — 5.7 ft off the centreline, no bounce

What held you back

Departure Climb 3 — climb speed 210 kt against 164 kt at 59 %, −1.09 points
Departure Roll — Runway alignment max 45.2 ft left at 73 %, −0.36 points
Arrival Taxi — Landing Lights at 1 %, −0.33 points

Next time

Departure

Reduce climb power to bring speed back to 164 kt and hold it there.

What happened: Climb speed was 46 kt fast at 210 kt during the climb.

Watch for: Airspeed indicator: 164 kt in the climb

See Departure Climb 3

Arrival

Fly a steeper descent on final so you cross the threshold at 50 ft.

What happened: You crossed the threshold at 59 ft agl, above the 50 ft agl target. Crossing high like this usually reduces your margin before the touchdown zone ends.

Watch for: Radio altimeter against 50 ft at the threshold.

See Arrival Landing

Speed at this height is usually bought with gradient. It's rarely dangerous and it's often just an early acceleration, but with flaps still out you may be heading towards the flap limit and a flat fast climb puts you at the acceleration altitude with the cleaning-up still to do.

Read more in Improve Your Take-Offs

Start to finish · 15 stages, 13 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 27 minutes and covered 4 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 10 kt0 kt min to max 22 kt 3 13 kt
100 % Average speed turning corners 0 ktmax 0 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle -0.0 °-1.7 ° min to max 1.5 ° 1.5 0.2 °
Info Average bank angle 0.3 °0.0 ° min to max 6.9 ° 0.0 0.1 °

Events

Info Engine 1 Started 9 ft agl · 3 kt
Info Parking Brake On 9 ft agl · 6 kt
Info Flaps Position 2 9 ft agl · 5 kt
Info Landing Lights Switched On 9 ft agl · 5 kt
Info Taxi Lights Switched On 9 ft agl · 5 kt
Info Parking Brake Off 9 ft agl
Info Parking Brake On 9 ft agl · 6 kt
Info Strobe Lights Switched On 9 ft agl · 3 kt
Info Taxi Lights Switched Off 9 ft agl · 3 kt
Info Parking Brake Off 9 ft agl · 3 kt
Departure Runway Entry Entering runway 01L at KTPA Tampa International Airport, Average speed was 14 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 13 kt13 kt min to max 14 kt 13 14 kt
Info Average pitch angle 0.2 °0.2 ° min to max 0.2 ° 0.2 0.2 °
Info Average bank angle 0.0 °0.0 ° min to max 0.1 ° 0.1 0.0 °
Info Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Departure Roll 94.64Departure roll runway 01L at KTPA Tampa International Airport. Takeoff distance 4,106 ft 37 % of runway. Rotation speed was 143 kt. Local weather - Temperature 67 °F. Wind 4 kt at 299 °. Crosswind: 4 kt Headwind: 2 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 4,106 ft37 % of runway
100 % Rotation speed was 143 ktTarget 146 kt
73 % Runway alignment max 45.2 ft left45.2 ft left to 0.0 ft left 7.0 45.2 ft
100 % Average g force 1.00 g0.96 g min to max 1.02 g 1.00 1.01 g
100 % Takeoff Bounce
Info Average pitch angle 0.8 °0.0 ° min to max 8.7 ° 0.2 8.7 °
Info Average bank angle 0.1 °0.0 ° min to max 0.2 ° 0.0 0.1 °

Events

Info Parking Brake On 9 ft agl · 11 kt
Info Parking Brake Off 9 ft agl · 11 kt
Info Parking Brake On 9 ft agl · 11 kt
Info Parking Brake Off 9 ft agl · 4 kt
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 01L KTPA Tampa International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.7 °-0.7 ° min to max -0.6 ° -0.6 -0.7 °
100 % Average speed 158 kt152 kt min to max 163 kt 152 163 kt
100 % Steepest bank angle 1.9 °0.1 ° min to max 1.9 ° 0.1 1.8 °
100 % Average g force 1.16 g1.02 g min to max 1.21 g 1.02 1.12 g
Info Average VSI 583 fpm100 fpm min to max 1,113 fpm 100 1,113 fpm
Info Average altitude 16 ft agl0 ft agl min to max 44 ft agl 0 44 ft agl
Info Average pitch angle 11.8 °9.0 ° min to max 12.7 ° 9.0 12.5 °
Departure Climb 2 100.00Departure climb to 400 ft agl from 01L KTPA Tampa International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.6 °-0.7 ° min to max -0.4 ° -0.7 -0.4 °
100 % Average speed 170 kt163 kt min to max 196 kt 163 196 kt
100 % Steepest bank angle 1.7 °0.2 ° min to max 1.7 ° 1.7 0.2 °
100 % Average g force 1.04 g0.88 g min to max 1.11 g 1.11 1.00 g
Info Average VSI 1,476 fpm1,143 fpm min to max 1,949 fpm 1,143 1,452 fpm
Info Average altitude 120 ft agl46 ft agl min to max 391 ft agl 46 391 ft agl
Info Average pitch angle 11.5 °7.7 ° min to max 12.5 ° 12.5 7.7 °

Events

Info Landing Gear Up 187 ft agl · 176 kt
Departure Climb 3 83.64Departure climb to 1,000 ft agl from 01L KTPA Tampa International Airport.
ScoreDescriptionStartProfileEnd
59 % Climb speed 210 kt199 kt min to max 214 ktTarget 164 kt, 46 kt fast 199 214 kt
100 % Steepest bank angle 4.9 °0.0 ° min to max 4.9 ° 0.3 3.3 °
100 % Average g force 1.07 g0.99 g min to max 1.18 g 1.00 1.06 g
100 % Landing gear up at 142 ft aglTarget by 400 ft agl
Info Heading variation -0.4 °-0.5 ° min to max -0.3 ° -0.4 -0.5 °
Info Average VSI 2,538 fpm1,497 fpm min to max 3,861 fpm 1,497 3,861 fpm
Info Average altitude 644 ft agl416 ft agl min to max 960 ft agl 416 960 ft agl
Info Average pitch angle 10.8 °7.3 ° min to max 14.6 ° 7.6 14.6 °

Events

Info Flaps Position 1 582 ft agl · 214 kt
Enroute Climb 100.00Enroute climb started 1 mile north of KTPA Tampa International Airport Tampa (Florida, United States). Climbing from 1,083 ft asl to 24,832 ft asl, an increase of 23,749 ft in 8 minutes and covering 39 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 238 kt212 kt min to max 257 kt 214 240 kt
100 % Steepest bank angle 30.3 °0.0 ° min to max 30.3 ° 2.9 0.1 °
100 % Average g force 1.04 g0.79 g min to max 1.24 g 1.05 0.97 g
Info Average VSI 3,473 fpm1,917 fpm min to max 5,489 fpm 4,053 2,311 fpm
Info Average altitude 11,204 ft asl1,083 ft asl min to max 24,832 ft asl 1,083 24,832 ft asl
Info Average pitch angle 10.2 °6.6 ° min to max 15.6 ° 15.0 6.6 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Fully Retracted 1,792 ft agl · 220 kt
Info Landing Lights Switched Off 11,811 ft agl · 273 kt
Enroute Level 100.00Enroute level cruise started 1 mile south east of 48X Airport Manatee Airport Palmetto (Florida, United States) and lasted 7 minutes, covering 43 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±1,753 ft of 25,178 ft asl25,061 ft asl min to max 25,184 ft asl 25,061 25,182 ft asl
100 % Average speed 237 kt237 kt min to max 239 kt 239 237 kt
100 % Steepest bank angle 11.2 °0.0 ° min to max 11.2 ° 0.1 0.2 °
100 % Average g force 1.01 g0.96 g min to max 1.02 g 0.96 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 3.4 °3.3 ° min to max 4.2 ° 4.2 3.3 °
Enroute Descent 100.00Enroute descent started 4 miles south west of Port Charlotte (Florida, United States). Descent from 25,182 ft asl to 1,302 ft asl, a decrease of 23,880 ft in 33 minutes and covering 149 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 183 kt133 kt min to max 248 kt 237 133 kt
100 % Steepest bank angle 21.0 °0.0 ° min to max 21.0 ° 0.0 0.1 °
100 % Average g force 1.02 g0.81 g min to max 1.15 g 1.00 0.99 g
Info Average VSI -953 fpm-3,805 fpm min to max 0 fpm 0 -750 fpm
Info Average altitude 12,275 ft asl1,302 ft asl min to max 25,182 ft asl 25,182 1,302 ft asl
Info Average pitch angle 2.6 °-3.5 ° min to max 5.8 ° 3.3 2.7 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Position 1 15,369 ft agl · 260 kt
Info Flaps Position 2 14,419 ft agl · 256 kt
Info Flaps Position 3 14,150 ft agl · 260 kt
Info Landing Lights Switched On 9,885 ft agl · 236 kt
Info Landing Gear Down 3,969 ft agl · 176 kt
Info Flaps Position 4 3,853 ft agl · 176 kt
Info Flaps Position 5 3,352 ft agl · 147 kt
Arrival Approach 100.00Final approach to runway 12 at KMIA Miami International Airport. Descent from 1,332 ft agl to 68 ft agl in 109 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates
Arrival Landing 97.51Landing on runway 12 at KMIA Miami International Airport, runway length 9,353 ft. Threshold height at 59 ft agl was slightly above target. Threshold speed was good at 132 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 132 kt. Target 132 kt
90 % Threshold height at 59 ft agl was slightly above target.Target 50 ft agl
100 % Perfect landing flare
100 % Runway alignment max 5.6 ft right4.6 ft right to 5.6 ft right -4.8 -5.6 ft
100 % Steepest bank angle 0.3 °0.0 ° min to max 0.3 ° 0.1 0.1 °
100 % Peak g force 1.08 g1.00 g min to max 1.08 g 1.00 1.02 g
Info Average speed 130 kt125 kt min to max 132 kt 132 125 kt
Info Average VSI -539 fpm-670 fpm min to max -248 fpm -670 -248 fpm
Info Average altitude 25 ft agl2 ft agl min to max 59 ft agl 59 2 ft agl
Info Average pitch angle 4.5 °3.0 ° min to max 6.4 ° 3.1 5.0 °
02505007501,0001,2501,5001,75001123344657Runway Distance ftLanding Height ft02505007501,0001,2501,5001,750-80-64-48-32-1601632486480Runway Distance ftRunway Width ft
Arrival Touchdown 100.00Touchdown point was 185 ft beyond the touchdown zone. Touchdown speed at 125 kt was a little fast. Touchdown rate was fair at -202 fpm. Runway touchdown alignment was very good. Local weather - Temperature 74 °F. Wind 5 kt at 70 °. Crosswind: 4 kt Headwind: 3 kt.
ScoreDescriptionStartProfileEnd
100 % Touchdown rate was -202 fpm.
100 % Touchdown distance was 1,553 ftTarget 1,500 ft
100 % Speed at touchdown 125 ktTarget below 124 kt
100 % Runway alignment max 5.7 ft right5.7 ft right -5.6 -5.7 ft
100 % Steepest bank angle 0.3 °0.0 ° min to max 0.3 ° 0.1 0.1 °
100 % Peak g force 1.19 g0.98 g min to max 1.19 g 1.02 1.15 g
100 % Landing Bounce
Info Average speed 125 kt125 kt min to max 125 kt 125 125 kt
Info Average pitch angle 4.5 °4.1 ° min to max 5.0 ° 5.0 4.1 °
Arrival Rollout 100.00Total landing distance 5,100 ft, 55 % of runway. Runway rollout alignment was perfect.
ScoreDescriptionStartProfileEnd
100 % Landing distance 5,100 ft55 % of runway.
100 % Runway alignment max 8.0 ft left8.0 ft left to 0.0 ft left 0.4 8.0 ft
100 % Average g force 1.01 g0.98 g min to max 1.13 g 1.13 1.00 g
Info Average speed 113 kt62 kt min to max 123 kt 123 62 kt
Info Average pitch angle 2.2 °-0.3 ° min to max 4.1 ° 4.1 -0.2 °
Info Average bank angle 0.2 °0.0 ° min to max 0.3 ° 0.1 0.1 °
Runway Exit Exiting runway, average speed 31 kt
ScoreDescriptionStartProfileEnd
Info Average speed 27 kt0 kt min to max 59 kt 59 0 kt
Info Average pitch angle -0.1 °-0.6 ° min to max 0.2 ° -0.1 0.1 °
Info Average bank angle 0.1 °0.0 ° min to max 0.2 ° 0.0 0.0 °
Info Average g force 1.00 g0.99 g min to max 1.00 g 1.00 1.00 g

Events

Info Parking Brake On 9 ft agl · 5 kt
Info Landing Lights Switched Off 9 ft agl · 5 kt
Info Taxi Lights Switched On 9 ft agl · 5 kt
Info Landing Lights Switched On 9 ft agl · 5 kt
Info Strobe Lights Switched Off 9 ft agl · 5 kt
Arrival Taxi 95.05Taxiing to the parking from the runway took 1 minutes and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 9 kt3 kt min to max 16 kt 3 4 kt
100 % Average speed turning corners 12 ktmax 12 kt 0 0 kt
100 % Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Info Average pitch angle 0.0 °-0.5 ° min to max 0.2 ° 0.2 -0.0 °
Info Average bank angle 0.1 °0.0 ° min to max 0.2 ° 0.0 0.0 °

Events

Fail Landing Lights
Info Landing Lights Switched Off 9 ft agl · 7 kt

Takeoff from KTPA 01L

Taxi out

LightsOk
All on
Taxi speed100.00
22kt peak

The roll

Takeoff roll100.00
4,106ft37 %
Runway alignment73.21
45.2ft L
Rotation speed100.00
143kttarget 146, 3 early

On speed, but the nose came up quickly

Rotation started at 143 kt, 3 kt before the 146 kt rotate speed. The nose then rose at 3.9° a second, faster than the 2.0 to 2.9° a second other FNX320_TCACFM pilots fly.

The rotation started on speed but the nose came up quickly. A fast pull raises the nose faster than the aircraft can lift off, which brings the tail closer to the runway. Pull smoothly at the normal rate for this aircraft and let it fly off at its own attitude.

Liftoff and climb

Liftoff
151ktat 9.1°
Rotation
3.9°/sover 2.0 s, gaining 8 kt
35 ft
162ktat 12.6°, 2.7 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
1.9°steepest
Gear up100.00
142ftfull marks to 400 ft
Climb 3 speed59.10
210kttarget 164

Plan view the roll down the 11,014 ft runway.

Rolled from 277 ft in, drifted left of the centreline, 45 ft at the widest, and lifted off 46 ft left. Airborne 37 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

2,0004,0006,0008,00010,000THRESHOLDLEFT ↑RIGHT ↓CROSS3 kn75 %widest 45.2 ft LROLL 277 FT INAirborne 4,127 ft from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 4,127 ft of 11,014 ft · 37 %
Behind the start of the roll, 277 ftTakeoff roll, 3,851 ft Left ahead, 6,887 ft

Side view from the start of the roll to the end of Climb 3 at 961 ft.

Reached 35 ft with 6,157 ft of runway left; gear up at 142 ft, inside the 400 ft that gets full marks; then climbing at 2,000 fpm on average to 961 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3210 kt avgtarget 164THRESHOLDRUNWAY END6080100120KNOTS ALONG THE ROLLnose up on the runway · 516 ft · 2.0 sRotate 143 kttarget 146Liftoff 151 ktGear up 142 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 164240 kt16080020°10°0°nose up on the runway · 516 ft · 2.0 sROTATELIFTOFFtarget 146held 11.5°9.1° off · 3.9°/s13° at 35 ftAIRSPEEDPITCH0306090 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2.0 to 2.9° a second, the middle half of rotation rates flown by other FNX320_TCACFM pilots over the last 180 days (483 takeoffs); the grey pair are 2 to 3° a second, the rates airliners are rotated at. A trace steeper than both green lines is a faster rotation than most, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 11.7°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 11.7°ROTATELIFTOFF35 FT9.1° off · 3.9°/s3°/s2.9°/s2°/s2.0°/s13° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5 sseconds from rotation
PitchRotation began2.0 to 2.9°/s, other FNX320_TCACFM pilots2 to 3°/s from rotation, airlinersTail strikeNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate690 fpm670 fpm
On glideslope3.1°3.1°
On centreline0.0° off0.1° off
On speed+0.1 kt−0.2 kt
Wings level0° bank0° bank

When the approach was stable

Every check met from 4 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to KMIA 12

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 10 ft above the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 1,000 ft past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,3247003822221,000 ft gate7 of 71,058 ft · 132 kt500 ft gate7 of 7564 ft · 132 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 52× larger than distances along the final.

Inside the 1° band all the way from 4 nm, never more than 10 ft off the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR60 ft L060 ft RLEFT ↑RIGHT ↓1° BAND8 ft R7 ft R6 ft R6 ft R7 ft R7 ft R
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 33 kt fast at the 1,000 ft gate, closing to 20 at 500 ft and 10 at the threshold.

Inside the speed band all the way, between −0 kt and +3 kt on the approach speed of 132 kt.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

120140160180 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 132+3 kt−0 kt+0 kt−0 kt−0 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on KMIA 12

Over the threshold

Threshold height90.04
59ft
Threshold speed100.00
131kttarget 132, 1 slow
Centreline offset100.00
5.6ft R
Bank100.00
0.3°steepest
Flare100.00

Perfect landing flare

Touchdown

Past threshold100.00
1,553ft
Centreline100.00
5.7ft R
Speed100.00
125kttarget 124, 1 fast
Touchdown rate100.00
-202fpm
Impact100.00
1.19G
BouncesOk
None
Bank100.00
0.3°as the wheels touched

Rollout

Rollout distance100.00
3,416ft53 % used
Rollout alignment100.00
8.0ft L

Taxi in

Lights50.50
Onlanding lights, 99% of the taxi
Taxi speed100.00
16kt peak12 kt in turns

Side view — the last 5,369 ft of the approach.

Crossed the threshold at 59 ft, close to the 50 ft target; began the flare at 20 ft. Touched down 1,553 ft in, 553 ft past the ideal 1,000 ft.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 5,369 ft across. The dashed line is the ideal, 50 ft over the threshold and down 1,000 ft in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

59 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 20 ft · −554 fpm · 4.6° · 131 ktdescent slowed at 3 ft · −199 fpm · 5.8°−202 fpm · 5° nose up · 125 kt Ideal — 50 ft, down at 1,000 ft This flight — 59 ft, down at 1,553 ft

Sink and pitch — through the flare, lined up with the side view.

The sink went from 550 fpm at the flare to 200 fpm at touchdown. The pitch barely changed. Into the flare at 131 kt, on the 132 kt approach speed, and 125 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−202 fpm at touchdown5° at touchdown, +0.4° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 5,369 ft of the 9,353 ft runway, to the same scale as the side view.

Touched down 6 ft right of the centreline, and stayed within 7 ft of it down the rollout. 3 kt across from the left, which takes about 1° of crab to hold the centreline at 125 kt. Touched down straight - the crab taken out before the wheels touched, wings level.

Wind 070° at 5 kt · 3 kt head · 3 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

1,0002,0003,0004,0005,000 THRESHOLD LEFT ↑ RIGHT ↓ CROSS 3 kn FULL SCORE TO 1,650 FT 1,553 ft past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

The 1,553 ft touchdown sits inside the full-score zone. The arrival was smooth.

Runway used 4,969 ft of 9,353 ft · 53 %
In the air over the runway, 1,553 ftRollout, 3,416 ft Left over, 4,384 ft

The stop — touchdown to taxi speed.

From 124 kt at touchdown to taxi speed (30 kt) in 31 s, an average deceleration of 0.16 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 3,641 ft30 kt · 4,292 fttouchdown4,463 ftkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Flight narrative

The flight began with a taxiing period from the parking to the runway, which took 26 minutes and covered a distance of 4 nautical miles. The aircraft, a FNX320_TCACFM, then departed from runway 01L at KTPA Tampa International Airport. The takeoff distance was 3,804 feet, which accounted for 34% of the runway. The liftoff speed was 152 knots.

The local weather conditions at the time of departure were characterized by a temperature of 67 degrees Fahrenheit and a wind speed of 4 knots from a direction of 299 degrees. This resulted in a crosswind of 4 knots and a headwind of 2 knots. The aircraft then began its enroute climb, starting 1 mile north of KTPA Tampa International Airport and ascending from an altitude of 1,083 feet above sea level to 24,832 feet above sea level. This climb, which covered a distance of 22 nautical miles, took 8 minutes and resulted in an increase of 23,749 feet in altitude.

Following the enroute climb, the aircraft entered a level cruise phase, which started 1 mile southeast of 48X Airport Manatee Airport Palmetto. This cruise phase lasted for 7 minutes and covered a distance of 43 nautical miles. The aircraft then began its enroute descent, starting 4 miles southwest of Port Charlotte. The descent, which covered a distance of 118 nautical miles, took 33 minutes and resulted in a decrease of 23,880 feet in altitude, from 25,182 feet above sea level to 1,302 feet above sea level.

The final approach to runway 12 at KMIA Miami International Airport was made from the northwest, with the aircraft heading 120.0 degrees at an altitude of 1,283 feet above ground level and a distance of 4 nautical miles from the runway. The landing was made on runway 12, which had a length of 8,405 feet. The threshold height at 59 feet above ground level was slightly above the target, but the threshold speed was good at 132 knots.

The touchdown point was 184 feet beyond the touchdown zone, with a touchdown speed of 125 knots, which was good. However, the touchdown rate was fair at -248 feet per minute. The runway touchdown alignment was very good, and the runway rollout alignment was perfect. The local weather conditions at the time of landing were characterized by a temperature of 74 degrees Fahrenheit and a wind speed of 5 knots from a direction of 70 degrees, resulting in a crosswind of 4 knots and a headwind of 3 knots.

The total landing distance was 5,100 feet, which accounted for 61% of the runway. The taxiing period from the runway to the parking took 3 minutes and covered a distance of less than 1 nautical mile. The total flight distance was 194 nautical miles, and the flight duration was 59 minutes. The aircraft used 4,943 pounds of fuel during the flight.

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
