My FS Flights logo MY FS FLIGHTS
KDEN
Denver, United States
Runway 34L
Elevation5,322 ft asl
Weight38,421 kg
Fuel6,295 kg
Wind110° · 4 kn · 3 kn cross

Flight Score

99.25 %
KLAX
Los Angeles, United States
Runway 24R
Elevation125 ft asl
Weight34,210 kg
Fuel1,978 kg
Wind260° · 4 kn
6 Dec 2025 1:17 776 nm RJ85 4,317 kg
Departure Score
100.00 %
Enroute Score
100.00 %
Arrival Score
97.74 %

What went well

Touchdown 212 m in — inside the full-score zone
Threshold crossed at 44 ft and 114 kt — both inside band
Straight touchdown — 0.43 m off the centreline, no bounce

What held you back

Firm touchdown — 392 fpm, −0.70 points across the landing and the touchdown
  • Arrival Touchdown · sink rate 392 fpm−0.42
  • Arrival Landing · flare: the descent was not taken out−0.28
Arrival Landing — scored 95.00 %, −0.05 points

Next time

Arrival

Apply steady, continuous back pressure through the flare to arrest the sink smoothly and hold the normal profile, rather than letting it drift.

What happened: The flare did not hold its target profile, with the sink most arrested at 15 ft, and this flight then touched down at 391 fpm of sink - a firm arrival. An unsettled flare profile like this usually carries through to a firmer touchdown.

Watch for: Vertical speed indicator: a smooth, steadily decreasing sink rate through the flare to touchdown.

See Arrival LandingArrival Touchdown

There are several things that can go wrong during the flare, carrying too much speed over the threshold, starting the flare at the wrong height and inconsistent flight control inputs, all contribute to a poor flare resulting in a hard touchdown or a float down the runway.

Read more in Flare Timing

Start to finish · 17 stages, 15 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 8 minutes and covered 2 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 15 kt0 kt min to max 27 kt 3 11 kt
100 % Average speed turning corners 0 ktmax 0 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle 0.0 °-3.0 ° min to max 2.3 ° 2.3 -0.3 °
Info Average bank angle 0.1 °0.0 ° min to max 0.8 ° 0.0 0.6 °

Events

Info Engine 3 Started 8 ft agl · 4 kt
Info Engine 2 Started 8 ft agl · 10 kt
Info Engine 1 Started 8 ft agl · 14 kt
Info Pitot Heat Switched On 8 ft agl · 7 kt
Info Taxi Lights Switched On 8 ft agl · 10 kt
Info Flaps Position 1 8 ft agl · 10 kt
Info Parking Brake Off 8 ft agl
Departure Runway Entry Entering runway 34L at KDEN Denver International Airport, Average speed was 6 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 7 kt0 kt min to max 13 kt 11 13 kt
Info Average pitch angle -0.2 °-0.3 ° min to max -0.1 ° -0.2 -0.1 °
Info Average bank angle 0.3 °0.2 ° min to max 0.5 ° 0.5 0.2 °
Info Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g

Events

Info Landing Lights Switched On 8 ft agl
Info Strobe Lights Switched On 8 ft agl
Info Taxi Lights Switched Off 8 ft agl
Departure Roll 100.00Departure roll runway 34L at KDEN Denver International Airport. Takeoff distance 1,544 m 32 % of runway. Rotation speed was 130 kt. Local weather - Temperature 3 °C. Wind 4 kt at 110 °. Crosswind: 3 kt Tailwind: 1 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 1,544 m32 % of runway
100 % Rotation speed was 130 ktTarget 116 kt
100 % Runway alignment max 1.94 m left1.94 m left to 0.00 m left 0.99 1.80 m
100 % Average g force 1.00 g0.95 g min to max 1.15 g 1.00 1.15 g
100 % Takeoff Bounce
Info Average pitch angle 0.3 °-0.5 ° min to max 8.3 ° -0.1 8.3 °
Info Average bank angle 0.2 °0.0 ° min to max 0.6 ° 0.2 0.0 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 34L KDEN Denver International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.0 °-0.1 ° min to max -0.0 ° -0.1 -0.0 °
100 % Average speed 137 kt135 kt min to max 138 kt 135 138 kt
100 % Steepest bank angle 0.9 °0.0 ° min to max 0.9 ° 0.0 0.9 °
100 % Average g force 1.17 g0.98 g min to max 1.28 g 1.19 0.98 g
Info Average VSI 1,183 fpm703 fpm min to max 1,369 fpm 703 1,354 fpm
Info Average altitude 22 ft agl0 ft agl min to max 51 ft agl 0 51 ft agl
Info Average pitch angle 10.5 °8.5 ° min to max 11.2 ° 8.5 10.3 °
Departure Climb 2 100.00Departure climb to 400 ft agl from 34L KDEN Denver International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.1 °-0.0 ° min to max 0.6 ° -0.0 0.6 °
100 % Average speed 142 kt139 kt min to max 155 kt 139 155 kt
100 % Steepest bank angle 1.3 °0.7 ° min to max 1.3 ° 0.9 0.7 °
100 % Average g force 0.97 g0.94 g min to max 1.01 g 0.97 1.00 g
Info Average VSI 1,311 fpm1,138 fpm min to max 1,491 fpm 1,349 1,491 fpm
Info Average altitude 125 ft agl53 ft agl min to max 387 ft agl 53 387 ft agl
Info Average pitch angle 10.0 °8.8 ° min to max 10.7 ° 10.3 8.9 °

Events

Info Landing Gear Up 107 ft agl · 151 kt
Departure Climb 3 100.00Departure climb to 1,000 ft agl from 34L KDEN Denver International Airport.
ScoreDescriptionStartProfileEnd
100 % Climb speed 160 kt156 kt min to max 161 ktTarget 158 kt, 2 kt fast 156 161 kt
100 % Steepest bank angle 1.1 °0.0 ° min to max 1.1 ° 0.6 1.1 °
100 % Average g force 1.02 g0.99 g min to max 1.04 g 1.01 0.99 g
100 % Landing gear up at 98 ft aglTarget by 400 ft agl
Info Heading variation 1.0 °0.7 ° min to max 1.4 ° 0.7 1.4 °
Info Average VSI 2,140 fpm1,544 fpm min to max 2,602 fpm 1,544 2,602 fpm
Info Average altitude 671 ft agl412 ft agl min to max 987 ft agl 412 987 ft agl
Info Average pitch angle 10.6 °9.1 ° min to max 11.7 ° 9.1 11.7 °
Enroute Climb 100.00Enroute climb started 2 miles north west of KDEN Denver International Airport Denver (Colorado, United States). Climbing from 6,363 ft asl to 10,000 ft asl, an increase of 3,637 ft in 2 minutes and covering 7 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 197 kt155 kt min to max 248 kt 160 248 kt
100 % Steepest bank angle 33.6 °0.1 ° min to max 33.6 ° 1.2 27.7 °
100 % Average g force 1.02 g0.71 g min to max 1.27 g 1.00 1.07 g
Info Average VSI 2,020 fpm198 fpm min to max 4,252 fpm 2,640 307 fpm
Info Average altitude 8,561 ft asl6,363 ft asl min to max 10,000 ft asl 6,363 10,000 ft asl
Info Average pitch angle 8.9 °2.6 ° min to max 14.0 ° 12.0 3.2 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Master Switched On 2,258 ft agl · 176 kt
Info Flaps Fully Retracted 2,593 ft agl · 207 kt
Info Autopilot Airspeed Hold Activated 4,454 ft agl · 244 kt
Info Autopilot AutoThrottle Arm Armed 4,454 ft agl · 244 kt
Info Autopilot Vertical Hold Activated 4,454 ft agl · 244 kt
Enroute Level 100.00Enroute level cruise started 1 mile north west of CO12 Brighton Van-Aire Estates Airport Brighton (Colorado, United States) and lasted 2 minutes, covering 8 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±1,000 ft of 10,046 ft asl10,004 ft asl min to max 10,066 ft asl 10,004 10,047 ft asl
100 % Average speed 249 kt247 kt min to max 280 kt 248 278 kt
100 % Steepest bank angle 28.1 °0.2 ° min to max 28.1 ° 27.9 1.3 °
100 % Average g force 1.09 g0.98 g min to max 1.18 g 1.09 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 2.8 °1.8 ° min to max 3.2 ° 3.2 1.8 °

Events

Info Autopilot Altitude Hold Activated 4,978 ft agl · 288 kt
Info Autopilot Vertical Hold Deactivated 4,978 ft agl · 288 kt
Enroute Climb 2 100.00Enroute climb started 2 miles south of CO14 Reasoner Airport Brighton (Colorado, United States). Climbing from 10,039 ft asl to 30,004 ft asl, an increase of 19,966 ft in 16 minutes and covering 92 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 276 kt239 kt min to max 282 kt 277 239 kt
100 % Steepest bank angle 18.5 °0.0 ° min to max 18.5 ° 1.9 0.2 °
99.98 % Average g force 1.01 g0.89 g min to max 1.36 g 1.02 0.99 g
Info Average VSI 1,174 fpm-56 fpm min to max 2,993 fpm -29 245 fpm
Info Average altitude 16,834 ft asl10,001 ft asl min to max 30,004 ft asl 10,039 30,004 ft asl
Info Average pitch angle 3.8 °1.8 ° min to max 7.2 ° 1.8 3.2 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Altitude Hold Deactivated 4,753 ft agl · 322 kt
Info Autopilot Airspeed Hold Deactivated 4,753 ft agl · 322 kt
Info Autopilot AutoThrottle Arm Disarmed 4,753 ft agl · 322 kt
Info Autopilot Vertical Hold Activated 12,407 ft agl · 388 kt
Enroute Level 2 100.00Enroute level cruise started 10 miles north east of Aspen (Colorado, United States) and lasted 20 minutes, covering 573 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,002 ft of 30,133 ft asl30,026 ft asl min to max 30,240 ft asl 30,038 30,240 ft asl
100 % Average speed 270 kt241 kt min to max 277 kt 241 276 kt
100 % Steepest bank angle 16.4 °0.0 ° min to max 16.4 ° 0.4 0.6 °
100 % Average g force 1.00 g0.82 g min to max 1.13 g 0.97 0.82 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 2.1 °0.6 ° min to max 3.0 ° 3.0 0.6 °

Events

Info Autopilot Altitude Hold Activated 19,444 ft agl · 385 kt
Info Autopilot Vertical Hold Deactivated 19,444 ft agl · 385 kt
Info Autopilot Yaw Damper Activated 28,529 ft agl · 433 kt
Info Autopilot Yaw Damper Deactivated 29,399 ft agl · 434 kt
Info Autopilot Altitude Hold Deactivated 26,591 ft agl · 436 kt
Info Autopilot Airspeed Hold Deactivated 26,591 ft agl · 436 kt
Info Autopilot AutoThrottle Arm Disarmed 26,591 ft agl · 436 kt
Enroute Descent 100.00Enroute descent started 5 miles west of 6CA5 Valley Vista Airport Yucca Valley (California, United States). Descent from 29,601 ft asl to 1,412 ft asl, a decrease of 28,188 ft in 15 minutes and covering 85 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 233 kt145 kt min to max 290 kt 280 145 kt
100 % Steepest bank angle 10.5 °0.0 ° min to max 10.5 ° 0.4 0.3 °
100 % Average g force 1.01 g0.85 g min to max 1.29 g 1.29 0.99 g
Info Average VSI -1,571 fpm-5,148 fpm min to max -88 fpm -5,148 -833 fpm
Info Average altitude 10,234 ft asl1,412 ft asl min to max 29,601 ft asl 29,601 1,412 ft asl
Info Average pitch angle -0.9 °-4.2 ° min to max 3.9 ° -4.2 -0.2 °
Info Turn coordination 00 min to max 0 0 0

Events

Fail Exceeded 250 kn below 10000 ft 6,506 ft agl
Info Autopilot Airspeed Hold Activated 19,969 ft agl · 418 kt
Info Autopilot AutoThrottle Arm Armed 19,969 ft agl · 418 kt
Info Autopilot Vertical Hold Activated 19,969 ft agl · 418 kt
Info Autopilot Airspeed Hold Deactivated 17,260 ft agl · 421 kt
Info Autopilot AutoThrottle Arm Disarmed 17,260 ft agl · 421 kt
Info Autopilot Vertical Hold Deactivated 17,260 ft agl · 421 kt
Info Autopilot Airspeed Hold Activated 16,202 ft agl · 364 kt
Info Autopilot AutoThrottle Arm Armed 16,202 ft agl · 364 kt
Info Autopilot Vertical Hold Activated 16,202 ft agl · 364 kt
Info Autopilot Heading Hold Deactivated 2,609 ft agl · 246 kt
Info Autopilot Approach Mode Activated 2,609 ft agl · 246 kt
Info Autopilot Altitude Hold Activated 2,450 ft agl · 217 kt
Info Autopilot Vertical Hold Deactivated 2,450 ft agl · 217 kt
Info Autopilot Altitude Hold Deactivated 2,430 ft agl · 200 kt
Info Flaps Position 1 2,422 ft agl · 198 kt
Info Landing Gear Down 2,027 ft agl · 188 kt
Info Flaps Position 2 1,376 ft agl · 165 kt
Arrival Approach 100.00Final approach to runway 24R at KLAX Los Angeles International Airport. Descent from 1,328 ft agl to 45 ft agl in 117 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates

Events

Info Flaps Position 4 1,023 ft agl · 135 kt
Info Autopilot AutoThrottle Arm Disarmed 535 ft agl · 123 kt
Info Autopilot Master Switched Off 511 ft agl · 123 kt
Arrival Landing 95.00Landing on runway 24R at KLAX Los Angeles International Airport, runway length 2,713 m. Good threshold height. Threshold speed was good at 114 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 114 kt. Target 110 kt
100 % Good threshold height.Target 50 ft agl
80 % The flare wandered off the target profile. The flare began at 49 ft agl above the runway, higher than this aircraft wants. Touchdown was 212 m past the threshold. Hold the aim point and let the runway come to you rather than anticipating the flare.
100 % Runway alignment max 1.50 m right0.45 m right to 1.50 m right -0.45 -1.50 m
100 % Steepest bank angle 0.9 °0.0 ° min to max 0.9 ° 0.2 0.9 °
100 % Peak g force 1.07 g1.00 g min to max 1.07 g 1.07 1.01 g
Info Average speed 111 kt108 kt min to max 114 kt 114 108 kt
Info Average VSI -431 fpm-551 fpm min to max -392 fpm -551 -392 fpm
Info Average altitude 29 ft agl17 ft agl min to max 44 ft agl 44 17 ft agl
Info Average pitch angle 3.8 °3.3 ° min to max 4.0 ° 3.3 4.0 °
07515022530037545001123344657Runway Distance mLanding Height ft075150225300375450-25-20-15-10-50510152025Runway Distance mRunway Width m
Arrival Touchdown 93.70Touchdown distance was good at 212 m. Touchdown speed at 108 kt was good. Touchdown rate was firm at -392 fpm. Runway touchdown alignment was perfect. Local weather - Temperature 17 °C. Wind 4 kt at 260 °. Crosswind: 0 kt Headwind: 4 kt.
ScoreDescriptionStartProfileEnd
69 % Touchdown rate was -392 fpm.
100 % Touchdown distance was 212 mTarget 457 m
100 % Speed at touchdown 108 ktTarget below 110 kt
100 % Runway alignment max 1.50 m right0.71 m right -1.50 -0.43 m
100 % Steepest bank angle 0.9 °0.6 ° min to max 0.9 ° 0.9 0.7 °
100 % Peak g force 1.02 g0.98 g min to max 1.02 g 1.01 1.00 g
100 % Landing Bounce
Info Average speed 104 kt102 kt min to max 108 kt 108 102 kt
Info Average pitch angle 3.9 °3.2 ° min to max 4.5 ° 4.0 3.2 °
Arrival Rollout 100.00Total landing distance 960 m, 35 % of runway. Runway rollout alignment was perfect.
ScoreDescriptionStartProfileEnd
100 % Landing distance 960 m35 % of runway.
100 % Runway alignment max 1.57 m right0.00 m left to 1.57 m right -0.42 -1.38 m
100 % Average g force 1.00 g0.99 g min to max 1.02 g 1.00 1.00 g
Info Average speed 85 kt50 kt min to max 98 kt 98 50 kt
Info Average pitch angle -0.2 °-1.6 ° min to max 3.1 ° 3.1 -0.3 °
Info Average bank angle 0.5 °0.0 ° min to max 0.8 ° 0.7 0.0 °

Events

Info Taxi Lights Switched On 8 ft agl · 73 kt
Info Landing Lights Switched Off 8 ft agl · 68 kt
Info Strobe Lights Switched Off 8 ft agl · 68 kt
Info Flaps Position 3 8 ft agl · 58 kt
Runway Exit Exiting runway, average speed 36 kt
ScoreDescriptionStartProfileEnd
Info Average speed 32 kt15 kt min to max 50 kt 50 15 kt
Info Average pitch angle -0.3 °-0.4 ° min to max -0.2 ° -0.2 -0.3 °
Info Average bank angle 0.0 °0.0 ° min to max 0.4 ° 0.0 0.1 °
Info Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g

Events

Info Flaps Position 2 8 ft agl · 45 kt
Info Flaps Fully Retracted 8 ft agl · 35 kt
Arrival Taxi 100.00Taxiing to the parking from the runway took 11 minutes and covered 3 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 17 kt0 kt min to max 24 kt 15 0 kt
100 % Average speed turning corners 12 ktmax 15 kt 0 0 kt
100 % Average g force 1.00 g0.98 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle -0.3 °-0.4 ° min to max -0.2 ° -0.3 -0.3 °
Info Average bank angle 0.0 °0.0 ° min to max 0.5 ° 0.1 0.0 °

Events

Info Taxi Lights Switched Off 8 ft agl · 9 kt
Info Parking Brake On 8 ft agl · 4 kt

Takeoff from KDEN 34L

Taxi out

LightsOk
All on
Taxi speed100.00
27kt peak

The roll

Takeoff roll100.00
1,544m32 %
Runway alignment100.00
1.94m L
Rotation speed100.00
130kttarget 116, 14 late

Rotated late, and the nose came up quickly

Rotation started at 130 kt, 14 kt after the 116 kt rotate speed, and the nose then rose at 3.8° a second, faster than the 2 to 3° a second airliners use.

The pull started late and then came quickly, as if to make up the time. Start it on the rotate speed instead, so there is nothing to catch up, and keep it to the normal rate for this aircraft.

Liftoff and climb

Liftoff
134ktat 8.5°
Rotation
3.8°/sover 1.9 s, gaining 4 kt
35 ft
138ktat 10.9°, 2.1 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
0.9°steepest
Gear up100.00
98ftfull marks to 400 ft
Climb 3 speed100.00
160kttarget 158

Plan view the roll down the 4,885 m runway.

Rolled from 86 m in, drifted left of the centreline, 1.9 m at the widest, and lifted off 1.8 m left. Airborne 31 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

1,0002,0003,0004,000THRESHOLDLEFT ↑RIGHT ↓CROSS3 kn75 %widest 1.93 m LROLL 86 M INAirborne 1,548 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,548 m of 4,885 m · 32 %
Behind the start of the roll, 86 mTakeoff roll, 1,462 m Left ahead, 3,337 m

Side view from the start of the roll to the end of Climb 3 at 988 ft.

Reached 35 ft with 3,170 m of runway left; gear up at 98 ft, inside the 400 ft that gets full marks; then climbing at 1,680 fpm on average to 988 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3160 kt avgtarget 158THRESHOLDRUNWAY END6080100KNOTS ALONG THE ROLLnose up on the runway · 142 m · 1.9 sRotate 130 kttarget 116Liftoff 134 ktGear up 98 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 158180 kt12060020°10°0°nose up on the runway · 142 m · 1.9 sROTATELIFTOFFtarget 116held 10.2°8.5° off · 3.8°/s11° at 35 ftAIRSPEEDPITCH0204060 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2 to 3° a second, the rates airliners are rotated at: a trace steeper than both is a faster rotation, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate.

20°10°0°ROTATELIFTOFF35 FT8.5° off · 3.8°/s3°/s2°/s11° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5 sseconds from rotation
PitchRotation began2 to 3°/s from rotationNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate610 fpm620 fpm
On glideslope3.0°3.0°
On centreline0.0° off0.1° off
On speed+19 kt+12 kt
Wings level0° bank1° bank

When the approach was stable

Every check met from 3.5 nm, about 1,150 ft above the runway, to the threshold, before the 1,000 ft gate, so through both gates. The last to settle was the speed.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to KLAX 24R

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 20 ft below the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,3276883741981,000 ft gate7 of 71,030 ft · 129 kt500 ft gate7 of 7552 ft · 122 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 52× larger than distances along the final.

Inside the 1° band all the way from 4 nm, never more than 5 m off the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR18 m L018 m RLEFT ↑RIGHT ↓1° BAND2 m L3 m L4 m L0 m R1 m L5 m L
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 28 kt fast at the 1,000 ft gate, closing to 17 at 500 ft and 10 at the threshold.

Fast from 4 nm to 3.5 nm (up to +38 kt), then inside the band to the threshold.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

100120140160 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 110+38 kt+12 kt+10 kt+9 kt+4 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on KLAX 24R

Over the threshold

Threshold height100.00
44ft
Threshold speed100.00
114kttarget 110, 4 fast
Centreline offset100.00
1.50m R
Bank100.00
0.9°steepest
Flare79.99

The flare wandered off the target profile

The flare began at 49 ft agl above the runway, higher than this aircraft wants. Touchdown was 212 m past the threshold. Hold the aim point and let the runway come to you rather than anticipating the flare.

Touchdown

Past threshold100.00
212m
Centreline100.00
1.50m R
Speed100.00
108kttarget 110 or less
Touchdown rate68.51
-392fpm
Impact100.00
1.02G
BouncesOk
None
Bank100.00
0.9°as the wheels touched

Rollout

Rollout distance100.00
521m27 % used
Rollout alignment100.00
1.57m R

Taxi in

LightsOk
All set
Taxi speed100.00
24kt peak12 kt in turns

Side view — the last 1,524 m of the approach.

Began the flare high, at 49 ft, 33 m before the threshold; crossed the threshold at 44 ft, close to the 50 ft target. Touched down 212 m in, 93 m short of the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,524 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

44 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare began at 49 ft, 33 m before the threshold−631 fpm · 2.9° · 115 ktdescent slowed at 15 ft · −391 fpm · 4°−391 fpm · 4° nose up · 108 kt Ideal — 50 ft, down at 305 m This flight — 44 ft, down at 212 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 630 fpm at the flare to 390 fpm at touchdown. The nose came up 1.1° on the way down. Into the flare at 115 kt, 5 kt over the 110 kt approach speed, and 108 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°descent slowedtouchdown−391 fpm at touchdown4° at touchdown, +1.1° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,524 m of the 2,713 m runway, to the same scale as the side view.

Touched down on the centreline, and stayed within 1.4 m of it down the rollout.

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ FULL SCORE TO 503 M 212 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

The 212 m touchdown sits inside the full-score zone. The 391 fpm arrival was firm.

Runway used 733 m of 2,713 m · 27 %
In the air over the runway, 212 mRollout, 521 m Left over, 1,980 m

The stop — touchdown to taxi speed.

From 100 kt at touchdown to taxi speed (30 kt) in 83 s, an average deceleration of 0.04 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 370 m30 kt · 1,886 mtouchdown1,961 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Flight narrative

The flight began with a taxiing period from the parking to the runway, which took 7 minutes and covered a distance of 2 nautical miles. The aircraft then departed from runway 34L at KDEN Denver International Airport, with a takeoff distance of 1,448 meters, which was 30% of the runway. The aircraft lifted off at a speed of 135 knots.

The local weather at the time of departure was characterized by a temperature of 3 degrees Celsius and wind speeds of 4 knots at 110 degrees. The crosswind and tailwind were 3 and 1 knots, respectively. The aircraft then began its enroute climb from 6,363 feet above sea level to 10,000 feet above sea level, an increase of 3,637 feet in just 2 minutes, covering a distance of 6 nautical miles.

The climb then continued from 10,039 feet above sea level to 30,004 feet above sea level, a significant increase of 19,966 feet in 16 minutes, covering a distance of 90 nautical miles. The aircraft then entered its level cruise phase, which lasted for 20 minutes and covered a distance of 566 nautical miles. The cruise phase was initiated 10 miles north east of Aspen, Colorado.

As the aircraft approached its destination, it began its enroute descent from 29,601 feet above sea level to 1,412 feet above sea level, a decrease of 28,188 feet in 15 minutes, covering a distance of 84 nautical miles. The descent phase was initiated 5 miles west of 6CA5 Valley Vista Airport in Yucca Valley, California.

The final approach to runway 24R at KLAX Los Angeles International Airport was made from the east, heading 263.0 degrees at a distance of 4 nautical miles and an altitude of 1,259 feet above ground level. The aircraft landed on the runway, which was 2,712 meters long, at a speed of 114 knots. The touchdown distance was 212 meters, and the touchdown speed was 108 knots.

The local weather at the time of landing was characterized by a temperature of 17 degrees Celsius and wind speeds of 4 knots at 260 degrees. The crosswind and headwind were 0 and 4 knots, respectively. The aircraft's touchdown rate was firm at -392 feet per minute, and the runway touchdown alignment was perfect. The total landing distance was 960 meters, which was 35% of the runway.

After landing, the aircraft taxied to the parking area, which took 11 minutes and covered a distance of 2 nautical miles. The total flight distance was 765 nautical miles, and the flight duration was 77 minutes. The aircraft used a total of 4,317 kilograms of fuel throughout the flight.

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
