KDEN
Denver, United States
Runway 34L
Elevation5,322 ft asl
Weight64,557 kg
Fuel7,358 kg
Wind10° · 35 kn · 6 kn cross

Flight Score

97.63 %
KLAX
Los Angeles, United States
Runway 24R
Elevation125 ft asl
Weight59,855 kg
Fuel2,478 kg
Wind240° · 7 kn · 3 kn cross
15 Mar 2026 2:12 765 nm Boeing 737-800 4,880 kg
Departure Score
93.39 %
Enroute Score
100.00 %
Arrival Score
99.49 %

What went well

Touched down at -213 fpm — a soft arrival
Touchdown 486 m in — inside the full-score zone
Threshold crossed at 29 ft and 133 kt — both inside band

What held you back

Departure Climb 3 — gear not retracted; Landing gear up at 0 ft agl at 0 %, −2.06 points
Departure Taxi — peak taxi speed 31 kt at 95 %, −0.15 points
Arrival Landing — Runway alignment max 12.78 m left at 93 %, −0.12 points

Next time

Departure

Raise the gear lever promptly once a positive rate of climb is confirmed after liftoff.

What happened: The landing gear was never raised during the initial climb and was still down when the climb ended.

Watch for: Landing gear lever: UP promptly after confirming a positive rate of climb.

See Departure Climb 3

Arrival

Make small rudder corrections against a point at the far end of the runway to track the centreline.

What happened: The aircraft drifted off the centreline during the landing roll.

Watch for: Heading indicator: wings aligned with the runway centreline

See Arrival Landing

Make sure that you retract the landing gear once you have a positive rate of climb and there is no usable runway left to land back on.

Read more in Improve Your Take-Offs

Start to finish · 15 stages, 13 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 97.80Taxiing from the parking to the runway took 10 minutes and covered 2 nm.
ScoreDescriptionStartProfileEnd
95 % Average speed 15 kt0 kt min to max 31 kt 0 8 kt
100 % Average speed turning corners 15 ktmax 15 kt 0 0 kt
100 % Average g force 1.00 g0.98 g min to max 1.03 g 1.00 1.00 g
Info Average pitch angle -1.0 °-2.4 ° min to max 0.5 ° -0.8 -1.0 °
Info Average bank angle 0.2 °0.0 ° min to max 0.8 ° 0.1 0.4 °

Events

Info Battery Master On 8 ft agl · 26 kt
Info Engine 2 Started 8 ft agl · 26 kt
Info Beacon Lights Switched On 8 ft agl · 26 kt
Info Navigation Lights Switched On 8 ft agl · 26 kt
Info Autopilot Master Switched On 8 ft agl · 26 kt
Info Landing Gear Down 8 ft agl · 26 kt
Info Engine 1 Started 8 ft agl
Info Parking Brake On 8 ft agl
Info Flaps Position 3 8 ft agl
Info Flaps Position 1 8 ft agl
Info Flaps Position 2 8 ft agl
Info Flaps Position 3 8 ft agl
Info Taxi Lights Switched On 8 ft agl
Info Parking Brake Off 8 ft agl
Info Landing Lights Switched On 8 ft agl · 10 kt
Info Taxi Lights Switched Off 8 ft agl · 12 kt
Info Strobe Lights Switched On 8 ft agl · 15 kt
Departure Runway Entry Entering runway 34L at KDEN Denver International Airport, Average speed was 41 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 12 kt8 kt min to max 17 kt 8 17 kt
Info Average pitch angle -0.9 °-1.0 ° min to max -0.9 ° -1.0 -0.9 °
Info Average bank angle 0.3 °0.3 ° min to max 0.4 ° 0.3 0.4 °
Info Average g force 1.01 g1.00 g min to max 1.01 g 1.00 1.01 g
Departure Roll 100.00Departure roll runway 34L at KDEN Denver International Airport. Takeoff distance 910 m 19 % of runway. Rotation speed was 145 kt. Local weather - Temperature -2 °C. Wind 40 kt at 9 °. Crosswind: 7 kt Headwind: 40 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 910 m19 % of runway
100 % Rotation speed was 145 ktTarget 142 kt
100 % Runway alignment max 9.26 m left9.26 m left to 6.01 m right -1.27 -6.01 m
100 % Average g force 1.00 g0.95 g min to max 1.05 g 1.00 1.04 g
100 % Takeoff Bounce
Info Average pitch angle -0.2 °-0.9 ° min to max 11.2 ° -0.9 11.1 °
Info Average bank angle 0.4 °0.0 ° min to max 2.0 ° 0.4 0.6 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 34L KDEN Denver International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.5 °0.4 ° min to max 0.6 ° 0.4 0.6 °
100 % Average speed 148 kt147 kt min to max 150 kt 148 150 kt
100 % Steepest bank angle 1.7 °0.0 ° min to max 1.7 ° 0.7 1.7 °
100 % Average g force 1.28 g1.16 g min to max 1.38 g 1.17 1.24 g
Info Average VSI 644 fpm166 fpm min to max 1,262 fpm 166 1,262 fpm
Info Average altitude 6 ft agl0 ft agl min to max 20 ft agl 0 20 ft agl
Info Average pitch angle 15.5 °11.2 ° min to max 18.0 ° 11.2 15.6 °

Events

Info Stall Warning Activated 26 ft agl · 156 kt
Info Stall Warning Deactivated 52 ft agl · 159 kt
Departure Climb 2 100.00Departure climb to 400 ft agl from 34L KDEN Denver International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.7 °0.6 ° min to max 1.3 ° 0.6 1.3 °
100 % Average speed 150 kt147 kt min to max 164 kt 150 164 kt
100 % Steepest bank angle 2.2 °0.2 ° min to max 2.2 ° 1.8 1.8 °
100 % Average g force 0.96 g0.81 g min to max 1.22 g 1.22 0.93 g
Info Average VSI 1,659 fpm1,297 fpm min to max 2,254 fpm 1,297 2,172 fpm
Info Average altitude 79 ft agl21 ft agl min to max 324 ft agl 21 324 ft agl
Info Average pitch angle 13.7 °12.6 ° min to max 16.7 ° 15.3 12.6 °
Departure Climb 3 69.15Departure climb to 1,000 ft agl from 34L KDEN Denver International Airport.
ScoreDescriptionStartProfileEnd
100 % Climb speed 182 kt163 kt min to max 203 ktTarget 179 kt, 3 kt fast 165 203 kt
96 % Steepest bank angle 25.8 °0.9 ° min to max 25.8 ° 1.4 25.8 °
99.7 % Average g force 0.99 g0.84 g min to max 1.31 g 0.91 1.31 g
0 % Landing gear up at 0 ft aglTarget by 400 ft agl
Info Heading variation 2.2 °1.4 ° min to max 2.7 ° 1.4 1.7 °
Info Average VSI 1,267 fpm702 fpm min to max 2,128 fpm 2,105 2,128 fpm
Info Average altitude 644 ft agl361 ft agl min to max 1,007 ft agl 361 1,007 ft agl
Info Average pitch angle 8.4 °7.1 ° min to max 11.8 ° 11.7 11.8 °

Events

Fail Gear Not Retracted
Info Flaps Position 1 759 ft agl · 213 kt
Info Flaps Position 2 811 ft agl · 209 kt
Info Flaps Position 1 938 ft agl · 217 kt
Enroute Climb 100.00Enroute climb started 1 mile north west of KDEN Denver International Airport Denver (Colorado, United States). Climbing from 6,398 ft asl to 35,978 ft asl, an increase of 29,580 ft in 18 minutes and covering 107 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 252 kt181 kt min to max 288 kt 201 253 kt
100 % Steepest bank angle 28.8 °0.0 ° min to max 28.8 ° 25.5 0.9 °
100 % Average g force 1.02 g0.82 g min to max 1.27 g 1.25 1.01 g
Info Average VSI 1,646 fpm-232 fpm min to max 4,266 fpm 2,443 516 fpm
Info Average altitude 18,666 ft asl6,398 ft asl min to max 36,004 ft asl 6,398 35,978 ft asl
Info Average pitch angle 6.3 °2.9 ° min to max 16.2 ° 12.2 3.9 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Fully Retracted 1,579 ft agl · 210 kt
Info Landing Gear Up 2,529 ft agl · 212 kt
Info Landing Lights Switched Off 4,440 ft agl · 280 kt
Enroute Level 100.00Enroute level cruise started overhead Aspen (Colorado, United States) and lasted 63 minutes, covering 473 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,301 ft of 35,993 ft asl35,915 ft asl min to max 36,026 ft asl 36,014 35,985 ft asl
100 % Average speed 249 kt245 kt min to max 255 kt 252 248 kt
100 % Steepest bank angle 18.2 °0.0 ° min to max 18.2 ° 0.2 0.2 °
100 % Average g force 1.00 g0.90 g min to max 1.09 g 0.99 0.99 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 3.5 °2.9 ° min to max 4.4 ° 3.0 3.6 °
Enroute Descent 100.00Enroute descent started 10 miles north west of CL29 Camino Airstrip Goffs (California, United States). Descent from 35,999 ft asl to 1,369 ft asl, a decrease of 34,630 ft in 34 minutes and covering 174 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 198 kt134 kt min to max 252 kt 248 135 kt
100 % Steepest bank angle 26.8 °0.0 ° min to max 26.8 ° 0.3 0.1 °
100 % Average g force 1.00 g0.87 g min to max 1.17 g 0.99 1.00 g
Info Average VSI -1,010 fpm-1,852 fpm min to max 229 fpm 13 -734 fpm
Info Average altitude 15,424 ft asl1,369 ft asl min to max 36,004 ft asl 35,999 1,369 ft asl
Info Average pitch angle 1.8 °-0.6 ° min to max 7.8 ° 3.4 0.8 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Position 1 14,202 ft agl · 258 kt
Info Flaps Position 2 10,770 ft agl · 217 kt
Info Flaps Position 1 10,727 ft agl · 217 kt
Info Flaps Position 2 10,710 ft agl · 216 kt
Info Landing Lights Switched On 9,098 ft agl · 208 kt
Info Flaps Position 3 9,044 ft agl · 206 kt
Info Flaps Position 4 9,037 ft agl · 206 kt
Info Flaps Position 2 9,032 ft agl · 205 kt
Info Flaps Position 3 9,031 ft agl · 201 kt
Info Autopilot Approach Localizer Activated 7,373 ft agl · 189 kt
Info Flaps Position 4 4,898 ft agl · 183 kt
Info Flaps Position 5 3,908 ft agl · 178 kt
Info Landing Gear Down 3,910 ft agl · 174 kt
Info Flaps Position 6 3,855 ft agl · 160 kt
Info Flaps Position 5 3,854 ft agl · 158 kt
Info Flaps Position 6 3,885 ft agl · 157 kt
Info Flaps Position 8 3,897 ft agl · 149 kt
Info Flaps Position 6 3,920 ft agl · 149 kt
Info Flaps Position 7 3,904 ft agl · 149 kt
Info Flaps Position 8 3,876 ft agl · 147 kt
Arrival Approach 100.00Final approach to runway 24R at KLAX Los Angeles International Airport. Descent from 1,283 ft agl to 13 ft agl in 105 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates
Arrival Landing 98.26Landing on runway 24R at KLAX Los Angeles International Airport, runway length 2,713 m. Good threshold height. Threshold speed was good at 134 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 134 kt. Target 133 kt
100 % Good threshold height.Target 50 ft agl
96 % Excellent landing flare. It lost 3.7 points, mostly for the nose going up and down 3 times.
93 % Runway alignment max 12.78 m left12.78 m left to 5.90 m left 12.78 5.90 m
99 % Steepest bank angle 2.5 °0.0 ° min to max 2.5 ° 0.3 0.5 °
99 % Peak g force 1.26 g0.88 g min to max 1.26 g 1.05 0.93 g
Info Average speed 130 kt125 kt min to max 134 kt 134 125 kt
Info Average VSI -331 fpm-721 fpm min to max -135 fpm -721 -168 fpm
Info Average altitude 4 ft agl-11 ft agl min to max 30 ft agl 30 -11 ft agl
Info Average pitch angle 3.2 °1.1 ° min to max 5.0 ° 1.3 1.1 °
07515022530037545052501223354658Runway Distance mLanding Height ft075150225300375450525-25-20-15-10-50510152025Runway Distance mRunway Width m
Arrival Touchdown 100.00Touchdown point was 66 m beyond the touchdown zone. Touchdown speed at 125 kt was good. Touchdown rate was fair at -213 fpm. Runway touchdown position was slightly misaligned by 6.1 m from centreline. Local weather - Temperature 19 °C. Wind 6 kt at 240 °. Crosswind: 2 kt Headwind: 6 kt.
ScoreDescriptionStartProfileEnd
100 % Touchdown rate was -213 fpm.
100 % Touchdown distance was 486 mTarget 457 m
100 % Speed at touchdown 125 ktTarget below 133 kt
100 % Runway alignment max 6.11 m left5.94 m left 5.90 6.11 m
100 % Steepest bank angle 1.4 °0.5 ° min to max 1.4 ° 0.5 1.4 °
100 % Peak g force 1.22 g0.84 g min to max 1.22 g 0.93 1.19 g
100 % Landing Bounce
Info Average speed 124 kt124 kt min to max 125 kt 125 124 kt
Info Average pitch angle 0.3 °-0.6 ° min to max 1.1 ° 1.1 -0.6 °
Arrival Rollout 99.20Total landing distance 1,482 m, 55 % of runway. Runway rollout alignment was slightly misaligned by 7.9 m from centreline.
ScoreDescriptionStartProfileEnd
100 % Landing distance 1,482 m55 % of runway.
98 % Runway alignment max 7.87 m left7.87 m left to 0.00 m left 7.87 6.40 m
100 % Average g force 1.02 g0.98 g min to max 1.14 g 1.14 0.99 g
Info Average speed 104 kt64 kt min to max 118 kt 118 64 kt
Info Average pitch angle -0.8 °-1.2 ° min to max -0.6 ° -0.7 -1.2 °
Info Average bank angle 0.3 °0.0 ° min to max 1.3 ° 1.3 0.1 °
Runway Exit Exiting runway, average speed 42 kt
ScoreDescriptionStartProfileEnd
Info Average speed 35 kt15 kt min to max 57 kt 57 17 kt
Info Average pitch angle -1.0 °-1.2 ° min to max -0.8 ° -1.0 -0.9 °
Info Average bank angle 0.2 °0.0 ° min to max 0.4 ° 0.0 0.2 °
Info Average g force 1.00 g0.98 g min to max 1.01 g 0.98 1.01 g

Events

Info Taxi Lights Switched On 8 ft agl · 43 kt
Info Landing Lights Switched Off 8 ft agl · 23 kt
Info Navigation Lights Switched Off 8 ft agl · 24 kt
Info Strobe Lights Switched Off 8 ft agl · 24 kt
Info Navigation Lights Switched On 8 ft agl · 24 kt
Arrival Taxi 100.00Taxiing to the parking from the runway took 6 minutes and covered 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 16 kt0 kt min to max 30 kt 18 4 kt
100 % Average speed turning corners 13 ktmax 21 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 0.99 1.00 g
Info Average pitch angle -0.9 °-1.2 ° min to max -0.8 ° -0.9 -0.8 °
Info Average bank angle 0.1 °0.0 ° min to max 0.4 ° 0.2 0.0 °

Events

Info Flaps Position 7 8 ft agl · 8 kt
Info Flaps Position 6 8 ft agl · 10 kt
Info Flaps Position 5 8 ft agl · 7 kt
Info Flaps Position 4 8 ft agl · 7 kt
Info Flaps Position 3 8 ft agl · 8 kt
Info Flaps Position 2 8 ft agl · 6 kt
Info Flaps Position 1 8 ft agl · 6 kt
Info Flaps Fully Retracted 8 ft agl · 6 kt

Takeoff from KDEN 34L

Taxi out

LightsOk
All on
Taxi speed97.25
31kt peak15 kt in turns

The roll

Takeoff roll100.00
910m19 %
Runway alignment100.00
9.26m L
Rotation speed100.00
145kttarget 142, 3 late

Liftoff pitch close to a tail strike

The wheels left at 11.2°, at or past this aircraft's 11° tail strike.

The tail can only touch while the main wheels are still on the runway, so the margin that matters is the one at liftoff. Rotate at the rotate speed, at the normal rate, and let the aircraft fly itself off at its own attitude: keep the pull going towards the climb attitude only once the wheels have left. Rotating early, or pulling faster than the aircraft can lift off, is what eats the margin.

Liftoff and climb

Liftoff
147ktat 11.2°
Rotation
6.8°/sover 1.7 s, gaining 2 kt
35 ft
148ktat 13.1°, 3.2 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
1.7°steepest
Climb 3 speed100.00
182kttarget 179

Plan view the roll down the 4,885 m runway.

Rolled from 81 m in, drifted left of the centreline, 9.3 m at the widest, and lifted off 6.1 m right, in 5 kn of crosswind from the right. Airborne 18 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

1,0002,0003,0004,000THRESHOLDLEFT ↑RIGHT ↓CROSS5 kn75 %widest 9.27 m LROLL 81 M INAirborne 914 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 914 m of 4,885 m · 19 %
Behind the start of the roll, 81 mTakeoff roll, 832 m Left ahead, 3,971 m

Side view from the start of the roll to the end of Climb 3 at 1,007 ft.

Reached 35 ft with 3,773 m of runway left; then climbing at 1,520 fpm on average to 1,007 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The shaded stretch is Climb 3, scored on its average speed against the target.

1,250 ft625 ft0CLIMB 3182 kt avgtarget 179THRESHOLDRUNWAY END6080100120KNOTS ALONG THE ROLLnose up on the runway · 104 m · 1.7 sRotate 145 kttarget 142Liftoff 147 kt
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 179210 kt14070020°10°0°nose up on the runway · 104 m · 1.7 sROTATELIFTOFFtarget 142held 10.8°11.2° off · 6.8°/s13° at 35 ftAIRSPEEDPITCH0204060 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2.1 to 4.1° a second, the middle half of rotation rates flown by other Boeing 737-800 pilots over the last 180 days (290 takeoffs); the grey pair are 2 to 3° a second, the rates airliners are rotated at. A trace steeper than both green lines is a faster rotation than most, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 11°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 11°ROTATELIFTOFF35 FT11.2° off · 6.8°/s4.1°/s3°/s2.1°/s2°/s13° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5+6 sseconds from rotation
PitchRotation began2.1 to 4.1°/s, other Boeing 737-800 pilots2 to 3°/s from rotation, airlinersTail strikeNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate750 fpm530 fpm
On glideslope3.0°3.3°
On centreline0.0° off0.3° off
On speed+2.5 kt+4.8 kt
Wings level0° bank0° bank

When the approach was stable

Every check met from 4 nm to 0.3 nm, then not again: left of the centreline from 0.3 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to KLAX 24R

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 40 ft above the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,3006803951891,000 ft gate7 of 71,034 ft · 136 kt500 ft gate7 of 7574 ft · 138 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 14× larger than distances along the final.

Inside the 1° band from 4 nm to 0.3 nm, then 16 m left of it from 0.3 nm to the threshold.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR67 m L067 m RLEFT ↑RIGHT ↓1° BAND9 m R3 m R25 m R8 m R6 m R16 m R
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 33 kt fast at the 1,000 ft gate, closing to 20 at 500 ft and 10 at the threshold.

Inside the speed band all the way, between +0 kt and +6 kt on the approach speed of 133 kt.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

120140160180 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 133+2 kt+2 kt+2 kt+2 kt+1 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on KLAX 24R

Over the threshold

Threshold height100.00
29ft
Threshold speed100.00
133kton target
Centreline offset93.06
12.78m L
Bank99.23
2.5°steepest
Flare96.25

Excellent landing flare

It lost 3.7 points, mostly for the nose going up and down 3 times.

Touchdown

Past threshold100.00
486m
Centreline100.00
6.11m L
Speed100.00
124kttarget 133 or less
Touchdown rate100.00
-213fpm
Impact100.00
1.22G
BouncesOk
None
Bank100.00
1.4°as the wheels touched

Rollout

Rollout distance100.00
957m53 % used
Rollout alignment98.22
7.87m L

Taxi in

LightsOk
All set
Taxi speed100.00
30kt peak13 kt in turns

Side view — the last 1,565 m of the approach.

Crossed the threshold at 29 ft, 21 ft below the 50 ft target; began the flare at 26 ft. Touched down 486 m in, 181 m past the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,565 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

29 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 26 ft · −629 fpm · 2° · 134 ktdescent slowed at 2 ft · −65 fpm · 5°−212 fpm · 1.1° nose up · 125 kt Ideal — 50 ft, down at 305 m This flight — 29 ft, down at 486 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 630 fpm at the flare to 210 fpm at touchdown. The nose went down 0.9° on the way down. Into the flare at 134 kt, on the 133 kt approach speed, and 125 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−212 fpm at touchdown1.1° at touchdown, −0.9° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,565 m of the 2,713 m runway, to the same scale as the side view.

Touched down 6.1 m left of the centreline, and stayed about there down the rollout, 8 m left at the widest. Little crosswind (2 kt): nothing to correct for. Touched down with the nose 2° left of the track, wings level.

Wind 240° at 7 kt · 6 kt head · 2 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ CROSS 2 kn FULL SCORE TO 503 M 486 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

The 486 m touchdown sits inside the full-score zone. The arrival was smooth.

Runway used 1,443 m of 2,713 m · 53 %
In the air over the runway, 486 mRollout, 957 m Left over, 1,270 m

The stop — touchdown to taxi speed.

From 120 kt at touchdown to taxi speed (30 kt) in 38 s, an average deceleration of 0.13 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 1,025 m30 kt · 1,335 mtouchdown1,388 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Flight narrative

Taxiing from the parking area to the runway at KDEN Denver International Airport took approximately 10 minutes, covering a distance of 2 nautical miles. The Boeing 737-800 then began its departure roll on runway 34L, utilizing 19% of the 910-meter runway to achieve liftoff at a speed of 148 knots. The local weather conditions at the time of departure featured a temperature of -2°C, with a 40-knot headwind and a 7-knot crosswind.

As the aircraft climbed away from KDEN, it began its enroute climb approximately 1 mile northwest of the airport, rising from 6,398 feet above sea level to 35,978 feet in 18 minutes, covering a distance of 107 nautical miles. The climb phase was followed by a 63-minute enroute level cruise, during which the aircraft maintained a steady altitude of 35,978 feet while covering 473 nautical miles. The cruise phase took the aircraft over Aspen, Colorado, before it began its enroute descent approximately 10 miles northwest of CL29 Camino Airstrip Goffs, California. The descent phase saw the aircraft drop from 35,999 feet to 1,369 feet in 34 minutes, covering a distance of 174 nautical miles.

The final approach to runway 24R at KLAX Los Angeles International Airport was initiated from the east, with the aircraft maintaining a heading of 263.0° at 4 nautical miles and 1,232 feet above ground level. The landing was executed with a threshold speed of 134 knots, and the touchdown point was located 67 meters beyond the touchdown zone. The touchdown speed of 125 knots and the touchdown rate of -168 feet per minute were both within acceptable limits. The total landing distance of 1,482 meters represented 55% of the 2,712-meter runway. Following the landing, the aircraft taxied to the parking area, covering a distance of 1 nautical mile in 6 minutes. The total flight distance of 765 nautical miles was achieved in 132 minutes, with the aircraft consuming 4,880 kilograms of fuel.

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
