LEBL
Barcelona, Spain
Runway 24R
Elevation7 ft asl
Weight79,802 kg
Fuel8,845 kg
Wind30° · 8 kn · 4 kn cross

Flight Score

93.28 %
LIPE
Bologna, Italy
Runway 30
Elevation118 ft asl
Weight75,436 kg
Fuel4,294 kg
Wind278° · 11 kn · 4 kn cross
18 Sep 2024 1:29 472 nm Vueling EC-LUN 4,551 kg
Departure Score
89.73 %
Enroute Score
92.00 %
Arrival Score
97.79 %

What went well

Touched down at -301 fpm — a soft arrival
Touchdown 215 m in — inside the full-score zone
Threshold crossed at 18 ft and 145 kt — both inside band

What held you back

Enroute Descent — 250 kt exceeded below 10,000 ft; speed limits at 0 %, −2.67 points
Departure Taxi — peak taxi speed 37 kt at 21 %, −2.15 points
Departure Roll — Landing Lights at 0 %, Strobe Lights at 0 %, −1.19 points

Next time

Maintain the centreline

See Departure Roll

A small uncorrected heading error at 40 knots becomes a metre of offset per second by 100 knots, noticed only at rotation, producing a crabbed liftoff. Root cause is nearly always eyes on the tape instead of the far end of the runway. Small heading changes displace a distant point visibly long before the nearby centreline stripes look wrong.

Read more in Improve Your Take-Offs

Start to finish · 18 stages, 16 in the score

The flight story

The approach before the go-around was abandoned. Its marks are shown, but only the approach that landed counts.

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 67.77Taxiing from the parking to the runway took 7 minutes and covered 4 nm.
ScoreDescriptionStartProfileEnd
21 % Average speed 30 kn0 kn min to max 37 kn 3 6 kn
99 % Average speed turning corners 15 knmax 17 kn 0 0 kn
100 % Average g force 1.00 g0.98 g min to max 1.03 g 1.00 1.00 g
Info Average pitch angle -0.0 °-0.8 ° min to max 0.3 ° 0.0 -0.0 °
Info Average bank angle 0.1 °0.0 ° min to max 0.4 ° 0.0 0.1 °

Events

Info Engine 1 Started 9 ft agl · 1 kt
Info Parking Brake On 9 ft agl · 1 kt
Info Flaps Position 2 9 ft agl
Info Flaps Position 3 9 ft agl · 1 kt
Info Taxi Lights Switched On 9 ft agl · 1 kt
Info Parking Brake Off 9 ft agl · 2 kt
Info Taxi Lights Switched Off 9 ft agl · 8 kt
Departure Runway Entry Entering runway 24R at LEBL El Prat, Average speed was 12 kn.
ScoreDescriptionStartProfileEnd
Info Average speed 12 kn0 kn min to max 19 kn 4 19 kn
Info Average pitch angle 0.0 °-0.2 ° min to max 0.2 ° -0.2 -0.1 °
Info Average bank angle 0.0 °0.0 ° min to max 0.1 ° 0.1 0.0 °
Info Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Departure Roll 82.09Departure roll runway 24R at LEBL El Prat. Takeoff distance 1,868 m 64 % of runway. Liftoff speed was 167 kn. Local weather - Temperature 19 °C. Wind 8 kn at 30 °. Crosswind: 4 kn Tailwind: 6 kn.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 1,868 m64 % of runway
100 % Liftoff speed was 167 knTarget 150 kn
60 % Runway alignment max 22.78 m8.88 m left to 13.90 m right 0.23 -12.96 m
100 % Average g force 1.00 g0.93 g min to max 1.04 g 1.00 0.94 g
100 % Takeoff Bounce
Info Average pitch angle 0.6 °-0.1 ° min to max 2.1 ° -0.1 2.1 °
Info Average bank angle 0.2 °0.0 ° min to max 0.7 ° 0.1 0.3 °

Events

Fail Landing Lights
Fail Strobe Lights
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 24R LEBL El Prat.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.1 °-0.2 ° min to max 0.4 ° 0.4 -0.2 °
100 % Average speed 182 kn168 kn min to max 194 kn 168 194 kn
100 % Average bank angle 0.4 °0.0 ° min to max 0.7 ° 0.3 0.1 °
100 % Average g force 1.06 g0.94 g min to max 1.13 g 0.94 1.13 g
Info Average VSI 467 ft/m141 ft/m min to max 799 ft/m 141 799 ft/m
Info Average altitude 3 ft agl-5 ft agl min to max 35 ft agl 0 35 ft agl
Info Average pitch angle 3.0 °1.4 ° min to max 5.9 ° 2.1 5.9 °

Events

Info Strobe Lights Switched On 11 ft agl · 179 kt
Departure Climb 2 100.00Departure climb to 400 ft agl from 24R LEBL El Prat.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.3 °-0.7 ° min to max -0.2 ° -0.2 -0.7 °
100 % Average speed 196 kn194 kn min to max 205 kn 194 205 kn
100 % Average bank angle 0.3 °0.0 ° min to max 0.6 ° 0.1 0.6 °
100 % Average g force 1.08 g0.96 g min to max 1.15 g 1.13 1.00 g
Info Average VSI 1,227 ft/m814 ft/m min to max 1,779 ft/m 814 1,721 ft/m
Info Average altitude 101 ft agl36 ft agl min to max 370 ft agl 36 370 ft agl
Info Average pitch angle 6.4 °6.0 ° min to max 6.9 ° 6.0 6.8 °

Events

Info Flaps Position 2 185 ft agl · 200 kt
Info Bounce during liftoff 273 ft agl · 203 kt
Departure Climb 3 98.78Departure climb to 1,000 ft agl from 24R LEBL El Prat.
ScoreDescriptionStartProfileEnd
100 % Heading variation -1.1 °-1.4 ° min to max -0.8 ° -0.8 -1.4 °
100 % Average speed 213 kn205 kn min to max 220 kn 206 220 kn
94 % Average bank angle 1.3 °0.1 ° min to max 4.3 ° 0.5 2.9 °
100 % Average g force 1.00 g0.93 g min to max 1.11 g 0.99 1.01 g
100 % Landing gear up
Info Average VSI 1,812 ft/m1,648 ft/m min to max 2,283 ft/m 1,736 2,283 ft/m
Info Average altitude 685 ft agl399 ft agl min to max 977 ft agl 399 977 ft agl
Info Average pitch angle 7.7 °6.7 ° min to max 10.5 ° 6.7 10.5 °

Events

Info Flaps Position 1 586 ft agl · 213 kt
Info Flaps Fully Retracted 852 ft agl · 222 kt
Enroute Climb 100.00Enroute climb started 2 miles south east of Gava (Catalunya, Spain). Climbing from 1,040 ft asl to 31,666 ft asl, an increase of 30,626 ft in 22 minutes and covering 106 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 277 kn216 kn min to max 315 kn 221 284 kn
100 % Average bank angle 10.4 °0.0 ° min to max 24.6 ° 2.7 0.0 °
100 % Average g force 1.02 g0.84 g min to max 1.14 g 1.00 1.00 g
Info Average VSI 1,601 ft/m696 ft/m min to max 2,511 ft/m 2,340 782 ft/m
Info Average altitude 14,376 ft asl1,040 ft asl min to max 31,666 ft asl 1,040 31,666 ft asl
Info Average pitch angle 5.9 °2.5 ° min to max 11.3 ° 10.9 3.4 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Landing Gear Up 3,868 ft agl · 234 kt
Enroute Level 100.00Enroute level cruise started 53 miles east of Tamariu (Catalunya, Spain) and lasted 38 minutes, covering 272 nm.
ScoreDescriptionStartProfileEnd
100 % Average altitude 31,827 ft asl31,779 ft asl min to max 31,888 ft asl 31,797 31,849 ft asl
100 % Average speed 283 kn283 kn min to max 284 kn 283 283 kn
100 % Average bank angle 6.0 °0.0 ° min to max 15.2 ° 0.1 0.0 °
100 % Average g force 1.01 g0.92 g min to max 1.08 g 0.97 0.92 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 2.5 °1.4 ° min to max 3.2 ° 3.2 1.4 °
Enroute Descent 100.00Enroute descent started 1 mile north east of Casarza Ligure (Liguria, Italy). Descent from 31,648 ft asl to 17,085 ft asl, a decrease of 14,563 ft in 5 minutes and covering 37 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 303 kn284 kn min to max 308 kn 284 308 kn
100 % Average bank angle 4.6 °0.0 ° min to max 12.2 ° 0.1 0.0 °
100 % Average g force 1.00 g0.92 g min to max 1.08 g 0.92 1.02 g
Info Average VSI -3,020 ft/m-3,994 ft/m min to max -677 ft/m -1,704 -677 ft/m
Info Average altitude 25,526 ft asl17,085 ft asl min to max 31,648 ft asl 31,648 17,085 ft asl
Info Average pitch angle -2.1 °-3.2 ° min to max 0.6 ° -0.3 0.6 °
Info Turn coordination 00 min to max 0 0 0
Enroute Level 2 100.00Enroute level cruise started 3 miles north of Ligonchio (Emilia-Romagna, Italy) and lasted 2 minutes, covering 15 nm.
ScoreDescriptionStartProfileEnd
100 % Average altitude 17,087 ft asl17,069 ft asl min to max 17,091 ft asl 17,069 17,090 ft asl
100 % Average speed 308 kn307 kn min to max 310 kn 308 308 kn
100 % Average bank angle 0.4 °0.0 ° min to max 4.0 ° 0.1 4.0 °
100 % Average g force 1.00 g0.99 g min to max 1.02 g 1.00 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 1.3 °0.7 ° min to max 1.6 ° 1.6 1.4 °
Enroute Descent 2 60.00Enroute descent started 2 miles south of Prignano sulla Secchia (Emilia-Romagna, Italy). Descent from 17,090 ft asl to 1,985 ft asl, a decrease of 15,105 ft in 11 minutes and covering 31 nm.
ScoreDescriptionStartProfileEnd
0 % Average speed 272 kn148 kn min to max 309 kn 308 148 kn
100 % Average bank angle 13.4 °0.0 ° min to max 30.0 ° 6.9 0.1 °
100 % Average g force 1.04 g0.79 g min to max 1.22 g 1.01 1.00 g
Info Average VSI -1,575 ft/m-3,082 ft/m min to max 78 ft/m 26 -1,056 ft/m
Info Average altitude 10,905 ft asl1,985 ft asl min to max 17,091 ft asl 17,090 1,985 ft asl
Info Average pitch angle -0.6 °-4.5 ° min to max 5.5 ° 1.3 0.9 °
Info Turn coordination 00 min to max 0 0 0

Events

Fail Exceeded 250 kn below 10000 ft 8,439 ft agl
Info Landing Lights Switched On 8,445 ft agl · 290 kt
Info Flaps Position 1 5,607 ft agl · 248 kt
Info Flaps Position 2 3,869 ft agl · 222 kt
Info Flaps Position 3 3,674 ft agl · 219 kt
Info Flaps Position 4 2,813 ft agl · 205 kt
Info Flaps Position 5 2,791 ft agl · 205 kt
Info Landing Gear Down 2,736 ft agl · 198 kt
Arrival 100.00Not counted in the flight scoreArrival started 2 miles south of Prignano sulla Secchia (Emilia-Romagna, Italy).
ScoreDescriptionStartProfileEnd
100 % Average speed 146 kn145 kn min to max 148 kn 148 146 kn
100 % Average bank angle 0.1 °0.0 ° min to max 0.2 ° 0.0 0.1 °
100 % Average g force 1.00 g1.00 g min to max 1.03 g 1.00 1.03 g
Info Average VSI -996 ft/m-1,054 ft/m min to max -974 ft/m -1,054 -977 ft/m
Info Average altitude 1,793 ft asl1,621 ft asl min to max 1,968 ft asl 1,968 1,621 ft asl
Info Average pitch angle 1.5 °1.1 ° min to max 1.6 ° 1.1 1.5 °
Info Turn coordination 00 min to max 0 0 0
Arrival Final 4 100.00Approaching runway 30 at LIPE Borgo Panigale from 4 nm to 3 nm. Descent from 1,472 ft agl to 1,131 ft agl. A decrease of 341 ft in 21 seconds.
ScoreDescriptionStartProfileEnd
100 % Approach angle 3.5 °3.5 ° min to max 3.5 °Target 3.0 ° 3.5 3.5 °
100 % Average speed 146 kn146 kn min to max 147 kn 146 146 kn
100 % Heading variation 0.1 °0.1 ° min to max 0.1 ° 0.1 0.1 °
100 % Average bank angle 0.1 °0.0 ° min to max 0.1 ° 0.1 0.0 °
100 % Average g force 1.00 g0.99 g min to max 1.02 g 0.99 1.00 g
Info Average VSI -973 ft/m-1,010 ft/m min to max -921 ft/m -921 -968 ft/m
Info Average altitude 1,301 ft agl1,131 ft agl min to max 1,472 ft agl 1,472 1,131 ft agl
Info Average pitch angle 1.0 °0.7 ° min to max 1.2 ° 1.0 1.0 °
33.253.53.7541,0501,1001,1501,2001,2501,3001,3501,4001,4501,500Distance to Touchdown NMApproach Height ft33.253.53.754-110-83-55-280285583110Distance to Touchdown NMApproach Runway Alignment m
Arrival Final 3 100.00Approaching runway 30 at LIPE Borgo Panigale from 3 nm to 2 nm. Descent from 1,100 ft agl to 758 ft agl. A decrease of 342 ft in 22 seconds.
ScoreDescriptionStartProfileEnd
100 % Approach angle 3.5 °3.5 ° min to max 3.5 °Target 3.0 ° 3.5 3.5 °
100 % Average speed 147 kn146 kn min to max 149 kn 146 146 kn
100 % Heading variation 0.1 °0.1 ° min to max 0.1 ° 0.1 0.1 °
100 % Average bank angle 0.2 °0.0 ° min to max 0.8 ° 0.0 0.2 °
100 % Average g force 1.00 g0.98 g min to max 1.03 g 1.02 1.00 g
Info Average VSI -934 ft/m-1,046 ft/m min to max -807 ft/m -925 -807 ft/m
Info Average altitude 928 ft agl758 ft agl min to max 1,100 ft agl 1,100 758 ft agl
Info Average pitch angle 1.1 °0.2 ° min to max 1.9 ° 0.7 1.7 °
22.252.52.7536507007508008509009501,0001,0501,100Distance to Touchdown NMApproach Height ft22.252.52.753-90-68-45-23023456890Distance to Touchdown NMApproach Runway Alignment m
Arrival Final 2 91.35Approaching runway 30 at LIPE Borgo Panigale from 2 nm to 1 nm. Descent from 745 ft agl to 392 ft agl. A decrease of 353 ft in 24 seconds.
ScoreDescriptionStartProfileEnd
73 % Approach angle 3.6 °3.5 ° min to max 3.7 °Target 3.0 ° 3.5 3.6 °
100 % Average speed 147 kn145 kn min to max 150 kn 147 147 kn
100 % Heading variation 0.0 °-0.1 ° min to max 0.1 ° 0.1 0.1 °
97 % Average bank angle 1.6 °0.1 ° min to max 4.2 ° 1.3 0.6 °
100 % Average g force 1.00 g0.97 g min to max 1.02 g 1.01 1.00 g
Info Average VSI -842 ft/m-1,058 ft/m min to max -726 ft/m -793 -1,058 ft/m
Info Average altitude 577 ft agl392 ft agl min to max 745 ft agl 745 392 ft agl
Info Average pitch angle 0.9 °-0.2 ° min to max 1.8 ° 1.7 -0.1 °
11.251.51.752300350400450500550600650700750Distance to Touchdown NMApproach Height ft11.251.51.752-70-53-35-18018355370Distance to Touchdown NMApproach Runway Alignment m
Arrival Final 1 100.00Approaching runway 30 at LIPE Borgo Panigale from 1 nm to 0 nm. Descent from 373 ft agl to 29 ft agl. A decrease of 344 ft in 21 seconds.
ScoreDescriptionStartProfileEnd
100 % Approach angle 1.8 °1.5 ° min to max 3.6 °Target 3.0 ° 3.6 1.6 °
100 % Average speed 144 kn143 kn min to max 146 kn 146 145 kn
100 % Heading variation 0.1 °0.0 ° min to max 0.1 ° 0.1 0.1 °
100 % Average bank angle 0.7 °0.0 ° min to max 2.6 ° 0.1 1.2 °
100 % Average g force 1.04 g0.98 g min to max 1.09 g 0.99 1.00 g
Info Average VSI -655 ft/m-1,300 ft/m min to max -271 ft/m -1,073 -271 ft/m
Info Average altitude 73 ft agl29 ft agl min to max 373 ft agl 373 29 ft agl
Info Average pitch angle 3.0 °-0.2 ° min to max 3.8 ° -0.1 2.8 °
00.250.50.751050100150200250300350Distance to Touchdown NMApproach Height ft00.250.50.751-50-38-25-13013253850Distance to Touchdown NMApproach Runway Alignment m
Arrival Landing 98.30Landing on runway 30 at LIPE Borgo Panigale, runway length 2,132 m. Good threshold height. Threshold speed was slightly above target at 145 kn.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was slightly above target at 145 kn. Target 135 kn
93 % Landing and flare profile
100 % Heading variation 0.1 °0.1 ° min to max 0.2 ° 0.1 0.2 °
100 % Average bank angle 0.9 °0.0 ° min to max 1.3 ° 1.2 1.0 °
100 % Average g force 0.99 g0.98 g min to max 1.00 g 1.00 1.00 g
Info Average speed 145 kn145 kn min to max 145 kn 145 145 kn
Info Average VSI -273 ft/m-301 ft/m min to max -256 ft/m -270 -301 ft/m
Info Average altitude 11 ft agl3 ft agl min to max 18 ft agl 18 3 ft agl
Info Average pitch angle 2.1 °1.6 ° min to max 2.8 ° 2.8 1.6 °
07515022501223354658Runway Distance mLanding Height ft075150225-24-20-16-12-8-404812162024Runway Distance mRunway Width m
Arrival Touchdown 97.10Touchdown distance was good at 215 m. Touchdown speed at 145 kn was a little fast. Touchdown rate was firm at -301 ft/m. Runway touchdown position was slightly misaligned by 5.2 m from centreline. Local weather - Temperature 16 °C. Wind 11 kn at 278 °. Crosswind: 4 kn Headwind: 11 kn.
ScoreDescriptionStartProfileEnd
93 % Touchdown VSI was -301 ft/m.
100 % Touchdown distance was 215 mTarget 457 m
100 % Speed at touchdown 145 knTarget 143 kn
92 % Runway alignment max 5.19 m5.16 m left 5.12 5.18 m
100 % Average bank angle 0.8 °0.7 ° min to max 1.0 ° 1.0 0.7 °
100 % Average g force 1.20 g1.00 g min to max 1.34 g 1.00 1.19 g
100 % Landing Bounce
Info Average speed 145 kn145 kn min to max 145 kn 145 145 kn
Info Average pitch angle 1.3 °1.1 ° min to max 1.6 ° 1.6 1.1 °

Speed and pitch

From brake release to the end of the climb, against time, then the takeoff point by point.

Lifted off at 167 kt with 2.1° of pitch.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The figure at liftoff is the pitch then. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

240 kt16080020°10°0°LIFTOFF2.1° off6° at 35 ftAIRSPEEDPITCH020406080 sfrom brake release
AirspeedPitchClimb 3

The takeoff, point by point

PointSpeedPitchTime
Brake release0 m 15 kt -0.1° 0 s
80 kt406 m 80 kt 0.3° 17.7 s
Liftoff1,876 m 167 kt 2.1° 39.2 s
35 ft2,727 m · 8.7 s after liftoff 194 kt 6.0° 47.9 s
End of Climb 36,240 m · 977 ft 220 kt 10.5° 80 s

Takeoff from LEBL 24R

Lights50.00
Offlanding and strobes
Taxi speed59.71
37kt peak15 kt in turns
Takeoff roll100.00
1,868m64 %
Runway alignment60.44
13.90m R
Liftoff speed100.00
167kt
Bounce on takeoffOk
None
Bank after liftoff100.00
0.7°steepest

Side view from the start of the roll to the end of Climb 3 at 977 ft. The distance scale changes past the runway end.

Reached 35 ft with 127 m of runway left; then climbing at 1,420 fpm on average to 977 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3THRESHOLDRUNWAY END6080100120140KNOTS ALONG THE ROLLLiftoff 167 ktSCALE CHANGES3.4 km past the runway
On the runwayClimbingLast quarter of the runwayClimb 3

Plan view the roll down the 2,914 m runway.

Rolled from 60 m in, drifted right of the centreline, 14 m at the widest, and lifted off 13 m right. Airborne 66 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

1,0002,000THRESHOLDLEFT ↑RIGHT ↓CROSS4 kn75 %widest 13.64 m RROLL 60 M INAirborne 1,935 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,935 m of 2,914 m · 66 %
Behind the start of the roll, 60 mTakeoff roll, 1,876 m Left ahead, 978 m

The approach to LIPE 30

The final from 4 nm.

Profile height against the 3° glideslope, with its 1° band in green.

On the glideslope from 4 nm to 0.3 nm, then low to the threshold (up to 60 ft under).

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,5251,168802617451202
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height there

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 28× larger than distances along the final.

Inside the 1° band all the way from 4 nm, never more than 13 m off the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR34 m L034 m RLEFT ↑RIGHT ↓1° BAND13 m L10 m L8 m L1 m L3 m L2 m L
Extended centreline1° either sideYour trackOutside the band

Landing and touchdown on LIPE 30

Over the threshold

Threshold height100.00
18ft
Threshold speed100.00
145kt
Centreline offset100.00
0.05m L
Bank100.00
1.3°steepest

Touchdown

Past threshold100.00
215m
Centreline92.20
5.19m L
Speed100.00
145kt
Touchdown rate93.07
-301fpm
Impact100.00
1.34G
BouncesOk
None
Bank100.00
1.0°as the wheels touched

Side view — the last 1,524 m of the approach.

Crossed the threshold at 18 ft, 32 ft below the 50 ft target. Touched down 215 m in, 90 m short of the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,524 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

18 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 −300 fpm · 1.6° nose up · 145 kt Ideal — 50 ft, down at 305 m This flight — 18 ft, down at 215 m

Sink and pitch — through the flare, lined up with the side view.

The sink grew from 250 fpm at 18 ft to 300 fpm at touchdown. The nose went down 1.1° on the way down.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°touchdown−300 fpm at touchdown1.6° at touchdown
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,524 m of the 2,132 m runway, to the same scale as the side view.

Touched down 5.2 m left of the centreline. No crosswind: nothing to correct for. Touched down straight, wings level.

Wind 278° at 11 kt · 11 kt head · 0 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ FULL SCORE TO 503 M 215 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

The 215 m touchdown sits inside the full-score zone. The arrival was smooth.

Runway used 215 m of 2,132 m · 10 %
In the air over the runway, 215 mRollout, 0 m Left over, 1,917 m

The rest of the report

Explore in detail

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
