KHAF
Half Moon Bay, United States
Runway 30
Elevation46 ft asl
Weight2,908 kg
Fuel544 kg
Wind280° · 5 kn · 3 kn cross

Flight Score

98.90 %
L05
Kernville, United States
Runway 35
Elevation2,612 ft asl
Weight2,664 kg
Fuel268 kg
Wind281° · 4 kn · 4 kn cross
20 May 2024 1:26 306 nm Black Square Turbine Duke N323N 276 kg
Departure Score
100.00 %
Enroute Score
100.00 %
Arrival Score
96.69 %

What went well

Touched down at -173 fpm — a soft arrival
Touchdown 311 m in — inside the full-score zone
Threshold crossed at 29 ft and 96 kt — both inside band

What held you back

Arrival Approach — 500 ft gate 86 %, −0.95 points
Arrival Touchdown — Touchdown rate was -173 fpm at 91 %, −0.13 points

Next time

Arrival

Keep the back pressure coming once the flare is established, holding the nose up through to touchdown instead of easing it.

What happened: The flare arrested the sink but 302 fpm of it came back before touchdown, and in flights like this one that returning sink usually carries through to a firm or hard touchdown at 173 fpm.

Watch for: Vertical speed indicator: the sink held near zero all the way through touchdown, not allowed to build back up.

See Arrival LandingArrival Touchdown

Preparing for a stable approach will give you time to decide on whether to attempt the landing or going around. Too much altitude with a high sink rate will result in carrying too much speed onto the runway. Configuring flaps and the gear late also won't help the speed decay.

Read more in The Stabilised Approach

Start to finish · 15 stages, 13 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 15 minutes and covered 2 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 7 kt0 kt min to max 16 kt 0 7 kt
100 % Average speed turning corners 6 ktmax 9 kt 0 7 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle 3.1 °1.5 ° min to max 4.0 ° 3.5 2.0 °
Info Average bank angle 0.3 °0.0 ° min to max 0.7 ° 0.4 0.1 °

Events

Info Engine 1 Started 3 ft agl · 9 kt
Info Taxi Lights Switched On 3 ft agl · 7 kt
Info Parking Brake Off 3 ft agl · 6 kt
Info Flaps Position 1 3 ft agl · 6 kt
Info Parking Brake On 3 ft agl · 6 kt
Info Pitot Heat Switched On 3 ft agl · 5 kt
Info Landing Lights Switched On 3 ft agl · 4 kt
Info Taxi Lights Switched Off 3 ft agl · 4 kt
Info Strobe Lights Switched On 3 ft agl · 5 kt
Info Parking Brake Off 3 ft agl · 5 kt
Departure Runway Entry Entering runway 30 at KHAF Half Moon Bay Airport, Average speed was 4 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 6 kt0 kt min to max 8 kt 6 0 kt
Info Average pitch angle 2.3 °1.0 ° min to max 3.2 ° 2.2 1.0 °
Info Average bank angle 0.2 °0.1 ° min to max 0.3 ° 0.1 0.3 °
Info Average g force 1.00 g0.99 g min to max 1.00 g 1.00 1.00 g
Departure Roll 100.00Departure roll runway 30 at KHAF Half Moon Bay Airport. Takeoff distance 297 m 23 % of runway. Rotation speed was 101 kt. Local weather - Temperature 12 °C. Wind 6 kt at 280 °. Crosswind: 4 kt Headwind: 5 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 297 m23 % of runway
100 % Rotation speed was 101 ktTarget 90 kt
100 % Runway alignment max 1.72 m left1.72 m left to 1.02 m right 1.64 -1.02 m
100 % Average g force 0.98 g0.96 g min to max 1.09 g 0.98 1.09 g
100 % Takeoff Bounce
Info Average pitch angle 3.6 °3.1 ° min to max 5.5 ° 3.1 5.5 °
Info Average bank angle 0.3 °0.0 ° min to max 1.9 ° 0.2 1.9 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 30 KHAF Half Moon Bay Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.4 °0.2 ° min to max 0.5 ° 0.2 0.5 °
100 % Average speed 109 kt104 kt min to max 114 kt 104 114 kt
100 % Steepest bank angle 2.3 °0.0 ° min to max 2.3 ° 2.0 1.4 °
100 % Average g force 1.11 g1.04 g min to max 1.24 g 1.12 1.05 g
Info Average VSI 731 fpm455 fpm min to max 940 fpm 455 940 fpm
Info Average altitude 20 ft agl0 ft agl min to max 48 ft agl 0 48 ft agl
Info Average pitch angle 8.1 °5.8 ° min to max 9.1 ° 5.8 9.1 °

Events

Info Landing Gear Up 33 ft agl · 115 kt
Departure Climb 2 100.00Departure climb to 400 ft agl from 30 KHAF Half Moon Bay Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.6 °0.5 ° min to max 0.6 ° 0.5 0.5 °
100 % Average speed 118 kt114 kt min to max 135 kt 114 135 kt
100 % Steepest bank angle 2.1 °0.1 ° min to max 2.1 ° 1.4 1.4 °
100 % Average g force 1.05 g0.88 g min to max 1.14 g 1.04 1.02 g
Info Average VSI 1,270 fpm950 fpm min to max 2,090 fpm 950 1,850 fpm
Info Average altitude 106 ft agl49 ft agl min to max 371 ft agl 49 371 ft agl
Info Average pitch angle 10.4 °9.1 ° min to max 13.3 ° 9.1 12.3 °

Events

Info Flaps Fully Retracted 153 ft agl · 123 kt
Departure Climb 3 100.00Departure climb to 1,000 ft agl from 30 KHAF Half Moon Bay Airport.
ScoreDescriptionStartProfileEnd
100 % Climb speed 141 kt139 kt min to max 148 ktTarget 125 kt, 16 kt fast 139 148 kt
100 % Steepest bank angle 1.1 °0.1 ° min to max 1.1 ° 1.1 0.3 °
100 % Average g force 0.99 g0.86 g min to max 1.13 g 1.07 0.95 g
100 % Landing gear up at 28 ft aglTarget by 400 ft agl
Info Heading variation 0.7 °0.6 ° min to max 0.9 ° 0.6 0.9 °
Info Average VSI 2,741 fpm1,971 fpm min to max 3,352 fpm 1,971 2,605 fpm
Info Average altitude 686 ft agl405 ft agl min to max 980 ft agl 405 980 ft agl
Info Average pitch angle 14.7 °12.9 ° min to max 17.2 ° 12.9 12.9 °
Enroute Climb 100.00Enroute climb started overhead Moss Beach (California, United States). Climbing from 1,080 ft asl to 27,013 ft asl, an increase of 25,933 ft in 15 minutes and covering 60 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 161 kt144 kt min to max 174 kt 147 162 kt
100 % Steepest bank angle 25.8 °0.0 ° min to max 25.8 ° 0.6 0.3 °
100 % Average g force 1.02 g0.82 g min to max 1.14 g 0.94 0.94 g
Info Average VSI 1,938 fpm803 fpm min to max 3,687 fpm 2,550 1,078 fpm
Info Average altitude 12,826 ft asl1,080 ft asl min to max 27,013 ft asl 1,080 27,013 ft asl
Info Average pitch angle 8.5 °4.5 ° min to max 15.8 ° 12.8 4.5 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Nav1 Lock Activated 1,058 ft agl · 151 kt
Info Autopilot Heading Hold Deactivated 1,058 ft agl · 151 kt
Info Autopilot Master Switched On 3,746 ft agl · 161 kt
Info Landing Lights Switched Off 11,228 ft agl · 190 kt
Info Autopilot Altitude Hold Activated 26,331 ft agl · 247 kt
Enroute Level 100.00Enroute level cruise started 4 miles north of Morgan Hill (California, United States) and lasted 34 minutes, covering 170 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±1,853 ft of 27,177 ft asl27,055 ft asl min to max 27,391 ft asl 27,055 27,229 ft asl
100 % Average speed 180 kt166 kt min to max 183 kt 166 180 kt
100 % Steepest bank angle 18.0 °0.1 ° min to max 18.0 ° 0.4 0.4 °
100 % Average g force 1.00 g0.90 g min to max 1.11 g 0.97 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 1.9 °0.6 ° min to max 3.6 ° 2.5 1.8 °
Enroute Descent 100.00Enroute descent started 6 miles west of Greenfield (California, United States). Descent from 27,230 ft asl to 3,618 ft asl, a decrease of 23,612 ft in 18 minutes and covering 69 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 167 kt124 kt min to max 194 kt 180 126 kt
100 % Steepest bank angle 26.0 °0.0 ° min to max 26.0 ° 0.5 3.1 °
100 % Average g force 1.02 g0.84 g min to max 1.21 g 1.00 1.16 g
Info Average VSI -1,254 fpm-1,837 fpm min to max 23 fpm -11 -665 fpm
Info Average altitude 13,111 ft asl3,618 ft asl min to max 27,230 ft asl 27,230 3,618 ft asl
Info Average pitch angle -1.1 °-2.7 ° min to max 3.6 ° 1.8 2.4 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Nav1 Lock Deactivated 26,905 ft agl · 274 kt
Info Autopilot Heading Hold Activated 26,905 ft agl · 274 kt
Info Autopilot Nav1 Lock Activated 26,905 ft agl · 274 kt
Info Autopilot Heading Hold Deactivated 26,905 ft agl · 274 kt
Info Autopilot Altitude Hold Deactivated 26,912 ft agl · 274 kt
Info Landing Lights Switched On 6,406 ft agl · 194 kt
Info Autopilot Nav1 Lock Deactivated 3,443 ft agl · 193 kt
Info Autopilot Heading Hold Activated 3,443 ft agl · 193 kt
Info Autopilot Master Switched Off 2,063 ft agl · 161 kt
Info Autopilot Master Switched On 2,043 ft agl · 162 kt
Info Autopilot Altitude Hold Activated 1,476 ft agl · 160 kt
Info Autopilot Nav1 Lock Activated 1,232 ft agl · 149 kt
Info Autopilot Heading Hold Deactivated 1,232 ft agl · 149 kt
Info Autopilot Nav1 Lock Deactivated 1,220 ft agl · 151 kt
Info Autopilot Approach Mode Activated 1,220 ft agl · 151 kt
Info Autopilot Master Switched Off 1,082 ft agl · 145 kt
Info Landing Gear Down 998 ft agl · 142 kt
Arrival Approach 85.71Final approach to runway 35 at L05 Kern Valley. Descent from 1,132 ft agl to 28 ft agl in 90 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed
100 % Landing flappassed
0 % Sink ratefailed
100 % On glideslopepassed
100 % On centrelinepassed
100 % On speedpassed
100 % Wings levelpassed

Events

Info Autopilot Master Switched Off 1,082 ft agl · 145 kt
Info Landing Gear Down 998 ft agl · 142 kt
Info Flaps Position 1 705 ft agl · 132 kt
Info Flaps Position 2 625 ft agl · 128 kt
Arrival Landing 99.66Landing on runway 35 at L05 Kern Valley, runway length 1,072 m. Good threshold height. Threshold speed was slightly above target at 97 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was slightly above target at 97 kt. Target 92 kt
100 % Good threshold height.Target 50 ft agl
99 % Excellent landing flare. It lost 1.4 points, for the nose going up and down 2 times.
100 % Runway alignment max 0.74 m right0.20 m left to 0.74 m right 0.20 -0.51 m
100 % Steepest bank angle 1.6 °0.8 ° min to max 1.6 ° 0.8 1.4 °
100 % Peak g force 1.22 g0.86 g min to max 1.22 g 1.04 0.97 g
Info Average speed 91 kt85 kt min to max 97 kt 97 85 kt
Info Average VSI -394 fpm-888 fpm min to max -15 fpm -887 -139 fpm
Info Average altitude 10 ft agl3 ft agl min to max 30 ft agl 30 3 ft agl
Info Average pitch angle 3.8 °0.4 ° min to max 5.7 ° 0.4 5.2 °
07515022530037501223354658Runway Distance mLanding Height ft075150225300375-9-8-7-6-5-4-3-2-10123456789Runway Distance mRunway Width m
Arrival Touchdown 98.11Touchdown distance was good at 311 m. Touchdown speed at 85 kt was good. Touchdown rate was good at -173 fpm. Runway touchdown alignment was perfect. Local weather - Temperature 17 °C. Wind 6 kt at 278 °. Crosswind: 6 kt Headwind: 0 kt.
ScoreDescriptionStartProfileEnd
91 % Touchdown rate was -173 fpm.
100 % Touchdown distance was 311 mTarget 457 m
100 % Speed at touchdown 85 ktTarget below 91 kt
100 % Runway alignment max 0.51 m right0.30 m right -0.51 0.00 m
100 % Steepest bank angle 1.4 °0.1 ° min to max 1.4 ° 1.4 1.4 °
100 % Peak g force 1.23 g0.97 g min to max 1.23 g 0.97 1.07 g
100 % Landing Bounce
Info Average speed 84 kt84 kt min to max 85 kt 85 84 kt
Info Average pitch angle 5.2 °5.2 ° min to max 5.3 ° 5.2 5.2 °
Arrival Rollout 100.00Total landing distance 678 m, 63 % of runway. Runway rollout alignment was very good.
ScoreDescriptionStartProfileEnd
100 % Landing distance 678 m63 % of runway.
100 % Runway alignment max 3.30 m left3.30 m left to 0.00 m left 3.30 2.58 m
100 % Average g force 1.00 g0.98 g min to max 1.06 g 1.06 1.01 g
Info Average speed 84 kt49 kt min to max 91 kt 91 49 kt
Info Average pitch angle 4.7 °2.4 ° min to max 5.5 ° 5.2 5.0 °
Info Average bank angle 0.7 °0.1 ° min to max 1.6 ° 1.5 0.4 °
Runway Exit Exiting runway, average speed 1 kt
ScoreDescriptionStartProfileEnd
Info Average speed 9 kt4 kt min to max 44 kt 44 9 kt
Info Average pitch angle 3.4 °2.4 ° min to max 5.0 ° 5.0 4.0 °
Info Average bank angle 0.5 °0.0 ° min to max 1.2 ° 0.2 1.2 °
Info Average g force 1.00 g0.99 g min to max 1.01 g 1.01 1.00 g

Events

Info Flaps Fully Retracted 3 ft agl · 11 kt
Info Landing Lights Switched Off 3 ft agl · 5 kt
Info Taxi Lights Switched On 3 ft agl · 5 kt
Info Strobe Lights Switched Off 3 ft agl · 12 kt
Info Pitot Heat Switched Off 3 ft agl · 16 kt
Arrival Taxi 100.00Taxiing to the parking from the runway took 5 minutes and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 8 kt0 kt min to max 15 kt 9 0 kt
100 % Average speed turning corners 5 ktmax 7 kt 0 0 kt
100 % Average g force 1.00 g0.98 g min to max 1.01 g 0.99 1.00 g
Info Average pitch angle 3.7 °0.9 ° min to max 5.2 ° 4.4 4.8 °
Info Average bank angle 1.3 °0.0 ° min to max 2.5 ° 1.2 0.2 °

Events

Info Parking Brake On 3 ft agl
Info Taxi Lights Switched Off 3 ft agl

Takeoff from KHAF 30

Taxi out

LightsOk
All on
Taxi speed100.00
16kt peak6 kt in turns

The roll

Takeoff roll100.00
297m23 %
Runway alignment100.00
1.72m L
Rotation speed100.00
101kttarget 90, 11 late

Rotated late

Rotation started at 101 kt, 11 kt after the 90 kt rotate speed.

The pull started after the rotate speed had gone by. Bring the airspeed into the scan as it approaches the rotate speed, so the pull starts on the number rather than when you notice it has passed.

Liftoff and climb

Liftoff
103ktat 5.5°
35 ft
112ktat 8.8°, 2.9 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
2.3°steepest
Gear up100.00
28ftfull marks to 400 ft
Climb 3 speed100.00
141kttarget 125

Plan view the roll down the 1,292 m runway.

Rolled from the start of the runway, drifted left of the centreline, 1.7 m at the widest, and lifted off 1 m right. Airborne 23 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

5001,000THRESHOLDLEFT ↑RIGHT ↓CROSS3 kn75 %widest 1.70 m LAirborne 297 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 297 m of 1,292 m · 23 %
Takeoff roll, 297 m Left ahead, 995 m

Side view from the start of the roll to the end of Climb 3 at 981 ft.

Reached 35 ft with 835 m of runway left; gear up at 28 ft, inside the 400 ft that gets full marks; then climbing at 2,140 fpm on average to 981 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3141 kt avgtarget 125THRESHOLDRUNWAY END6080KNOTS ALONG THE ROLLnose up on the runway · 26 m · 0.5 sRotate 101 kttarget 90Liftoff 103 ktGear up 28 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figure at liftoff is the pitch then. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 125150 kt10050020°10°0°nose up on the runway · 26 m · 0.5 sROTATELIFTOFFtarget 90held 10.9°5.5° off9° at 35 ftAIRSPEEDPITCH02040 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

The stabilisation gates

One stabilised approach gate: seven checks where the approach path is 500 ft above the runway. The 1,000 ft gate was not assessed, because the approach did not join final that far out. These checks are the approach's score.

Seven checks, one gate500 ft 85.716 of 7
Gear down
Landing flap
Sink rate1,220 fpm
On glideslope4.6°
On centreline0.5° off
On speed+12 kt
Wings level1° bank

At the 500 ft gate: sink rate more than 600 fpm beyond what the glideslope needed.

When the approach was stable

Every check met from 1.9 nm, about 970 ft above the runway, to the threshold, before the 500 ft gate.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to L05 35

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 2° band in green.

Inside the glideslope band from 3.8 nm, where the final began, to the threshold, never more than 340 ft above the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,0002,500 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 2° BAND1,123976557273500 ft gate6 of 7sink rate844 ft · 105 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 3× larger than distances along the final.

Joined 1,715 m left of the centreline at 3.8 nm, then inside the band from 1.9 nm to the threshold.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR305 m L0305 m RLEFT ↑RIGHT ↓1° BAND452 m L67 m L16 m L1 m R26 m L
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 47 kt fast at the 1,000 ft gate, closing to 28 at 500 ft and 10 at the threshold.

Fast from 3.8 nm, where the final began, to 3.3 nm (up to +54 kt), then inside the band to 2.7 nm, then fast to 2.4 nm (up to +43 kt), then inside the band to the threshold.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

80100120140160 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 93+44 kt+29 kt+9 kt+9 kt+4 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on L05 35

Over the threshold

Threshold height100.00
29ft
Threshold speed100.00
96kttarget 92, 4 fast
Centreline offset100.00
0.74m R
Bank100.00
1.6°steepest
Flare98.62

Excellent landing flare

It lost 1.4 points, for the nose going up and down 2 times.

Touchdown

Past threshold100.00
311m
Centreline100.00
0.51m R
Speed100.00
84kttarget 91 or less
Touchdown rate90.53
-173fpm
Impact100.00
1.23G
BouncesOk
None
Bank100.00
1.4°as the wheels touched

Rollout

Rollout distance100.00
339m61 % used
Rollout alignment100.00
3.30m L

Taxi in

LightsOk
All set
Taxi speed100.00
15kt peak5 kt in turns

Side view — the last 1,072 m of the approach.

Began the flare at 32 ft, 3 m before the threshold; crossed the threshold at 29 ft, 21 ft below the 50 ft target. Touched down 311 m in, close to the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,072 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

29 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare began at 32 ft, 3 m before the threshold−836 fpm · 0.3° · 97 ktdescent slowed at 6 ft · −62 fpm · 5.5°−173 fpm · 5.2° nose up · 85 kt Ideal — 50 ft, down at 305 m This flight — 29 ft, down at 311 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 840 fpm at the flare to 170 fpm at touchdown. The nose came up 4.9° on the way down. Into the flare at 97 kt, 5 kt over the 92 kt approach speed, and 85 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°descent slowedtouchdown−173 fpm at touchdown5.2° at touchdown, +4.9° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the full 1,072 m runway, to the same scale as the side view.

Touched down on the centreline and drifted to 7.5 m right on the rollout. 4 kt across from the left, which takes about 3° of crab to hold the centreline at 85 kt. Touched down with the nose 4° into wind, wings level.

Wind 281° at 4 kt · 0 kt head · 4 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,000 THRESHOLD LEFT ↑ RIGHT ↓ CROSS 4 kn FULL SCORE TO 503 M 311 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

The 311 m touchdown sits inside the full-score zone. The arrival was smooth.

Runway used 651 m of 1,072 m · 61 %
In the air over the runway, 311 mRollout, 339 m Left over, 422 m

The stop — touchdown to taxi speed.

From 93 kt at touchdown to taxi speed (30 kt) in 15 s, an average deceleration of 0.25 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

02040608010060 kt · 312 m30 kt · 462 mtouchdown480 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
