SAWH
Ushuaia, Argentina
Runway 25
Elevation79 ft asl
Weight40,964 kg
Fuel8,096 kg
Wind354° · 3 kn · 3 kn cross

Flight Score

92.30 %
SCRM
Villa Las Estrellas, Falkland Islands
Runway 11
Elevation141 ft asl
Weight37,539 kg
Fuel4,569 kg
Wind270° · 1 kn
13 Apr 2024 1:49 597 nm British Aerospace 146-200 3,527 kg
Departure Score
95.22 %
Enroute Score
99.98 %
Arrival Score
81.69 %

What went well

Touchdown 100 m in — inside the full-score zone
Threshold crossed at 14 ft and 123 kt — both inside band
Rotated at 146 kt — on the 132 kt rotation target

What held you back

Arrival Rollout — Runway alignment max 23.02 m left at 30 %, −2.10 points
Firm touchdown — 449 fpm with 2 bounces, −1.86 points across the landing and the touchdown
  • Arrival Landing · flare: the descent was not taken out−0.67
  • Arrival Touchdown · sink rate 449 fpm−0.59
  • Arrival Touchdown · bounced 2 times−0.53
  • Arrival Touchdown · 1.65 G at contact−0.07
Departure Climb 3 — climb speed 175 kt against 132 kt at 48 %, −1.39 points
Arrival Approach — GPWS warning; 1,000 ft gate 71 %, 500 ft gate 100 %, −0.95 points

Next time

Departure

Reduce climb power to bring speed back to 132 kt and hold it there.

What happened: Climb speed was 43 kt fast at 175 kt during the climb.

Watch for: Airspeed indicator: 132 kt in the climb

See Departure Climb 3

Arrival

On final, make small rudder corrections against a point at the far end of the runway to hold the centreline.

What happened: The approach drifted off the centreline, and the aircraft touched down 24 m off the centreline before the rollout continued 23 m off it. Drifting off the centreline on approach usually carries through to touchdown and the rollout in the same direction.

Watch for: Centreline: track it with small rudder corrections, wings level.

See Arrival ApproachArrival LandingArrival Rollout

Preparing for a stable approach will give you time to decide on whether to attempt the landing or going around. Too much altitude with a high sink rate will result in carrying too much speed onto the runway. Configuring flaps and the gear late also won't help the speed decay.

Read more in The Stabilised Approach

Start to finish · 16 stages, 13 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 13 minutes and covered 4 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 18 kt0 kt min to max 29 kt 0 6 kt
100 % Average speed turning corners 7 ktmax 11 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle -0.3 °-0.7 ° min to max 0.2 ° -0.2 -0.1 °
Info Average bank angle 0.1 °0.0 ° min to max 0.6 ° 0.0 0.2 °

Events

Info Engine 2 Started 8 ft agl · 3 kt
Info Engine 1 Started 8 ft agl · 3 kt
Info Pitot Heat Switched On 8 ft agl · 2 kt
Info Flaps Position 1 8 ft agl · 2 kt
Info Taxi Lights Switched On 8 ft agl · 2 kt
Info Parking Brake Off 8 ft agl · 2 kt
Info Landing Lights Switched On 8 ft agl
Info Taxi Lights Switched Off 8 ft agl
Info Strobe Lights Switched On 8 ft agl
Departure Runway Entry Entering runway 25 at SAWH Malvinas Argentinas Airport, Average speed was 5 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 6 kt6 kt min to max 6 kt 6 6 kt
Info Average pitch angle -0.1 °-0.1 ° min to max -0.0 ° -0.0 -0.1 °
Info Average bank angle 0.3 °0.2 ° min to max 0.3 ° 0.2 0.3 °
Info Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Departure Roll 100.00Departure roll runway 25 at SAWH Malvinas Argentinas Airport. Takeoff distance 1,402 m 53 % of runway. Rotation speed was 146 kt. Local weather - Temperature 12 °C. Wind 3 kt at 353 °. Crosswind: 3 kt Headwind: 0 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 1,402 m53 % of runway
100 % Rotation speed was 146 ktTarget 132 kt
100 % Runway alignment max 4.28 m right0.00 m left to 4.28 m right -0.73 -4.28 m
100 % Average g force 1.00 g0.92 g min to max 1.14 g 1.00 1.14 g
100 % Takeoff Bounce
Info Average pitch angle 0.3 °-0.3 ° min to max 7.6 ° -0.2 7.6 °
Info Average bank angle 0.3 °0.0 ° min to max 1.5 ° 0.3 1.5 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 25 SAWH Malvinas Argentinas Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.2 °0.2 ° min to max 0.2 ° 0.2 0.2 °
100 % Average speed 155 kt153 kt min to max 158 kt 153 158 kt
100 % Steepest bank angle 2.9 °0.0 ° min to max 2.9 ° 1.6 0.2 °
100 % Average g force 1.08 g0.87 g min to max 1.26 g 1.20 0.88 g
Info Average VSI 699 fpm263 fpm min to max 894 fpm 263 870 fpm
Info Average altitude 21 ft agl0 ft agl min to max 45 ft agl 0 45 ft agl
Info Average pitch angle 7.8 °6.4 ° min to max 8.9 ° 7.7 6.4 °

Events

Info Autopilot Yaw Damper Activated 21 ft agl · 153 kt
Departure Climb 2 96.88Departure climb to 400 ft agl from 25 SAWH Malvinas Argentinas Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.3 °0.2 ° min to max 0.4 ° 0.2 0.4 °
100 % Average speed 162 kt158 kt min to max 173 kt 158 173 kt
88 % Steepest bank angle 9.4 °0.1 ° min to max 9.4 ° 0.3 9.4 °
100 % Average g force 0.99 g0.88 g min to max 1.09 g 0.88 1.02 g
Info Average VSI 947 fpm785 fpm min to max 1,623 fpm 863 1,623 fpm
Info Average altitude 96 ft agl46 ft agl min to max 341 ft agl 46 341 ft agl
Info Average pitch angle 7.3 °6.4 ° min to max 9.0 ° 6.4 8.6 °

Events

Info Landing Gear Up 160 ft agl · 167 kt
Departure Climb 3 79.22Departure climb to 1,000 ft agl from 25 SAWH Malvinas Argentinas Airport.
ScoreDescriptionStartProfileEnd
48 % Climb speed 175 kt174 kt min to max 176 ktTarget 132 kt, 43 kt fast 174 175 kt
100 % Steepest bank angle 21.0 °12.8 ° min to max 21.0 ° 12.8 21.0 °
100 % Average g force 1.10 g1.03 g min to max 1.24 g 1.03 1.10 g
100 % Landing gear up at 154 ft aglTarget by 400 ft agl
Info Heading variation -0.5 °-1.8 ° min to max 0.2 ° 0.2 -1.8 °
Info Average VSI 2,185 fpm1,671 fpm min to max 2,781 fpm 1,671 2,781 fpm
Info Average altitude 499 ft agl368 ft agl min to max 685 ft agl 368 685 ft agl
Info Average pitch angle 11.0 °8.8 ° min to max 12.7 ° 8.8 12.7 °
Enroute Climb 99.98Enroute climb started 1 mile west of SAWH Malvinas Argentinas Airport Ushuaia (Tierra del Fuego Province, Argentina). Climbing from 824 ft asl to 29,974 ft asl, an increase of 29,150 ft in 20 minutes and covering 105 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 223 kt173 kt min to max 262 kt 174 238 kt
100 % Steepest bank angle 32.5 °0.0 ° min to max 32.5 ° 21.4 3.2 °
99.8 % Average g force 1.07 g0.71 g min to max 1.54 g 1.08 0.98 g
Info Average VSI 1,704 fpm-609 fpm min to max 6,438 fpm 2,874 590 fpm
Info Average altitude 16,129 ft asl824 ft asl min to max 29,974 ft asl 824 29,974 ft asl
Info Average pitch angle 7.6 °1.8 ° min to max 17.9 ° 12.8 4.1 °
Info Turn coordination 00 min to max 0 0 0

Events

Fail Exceeded 250 kn below 10000 ft 1,827 ft agl
Info Flaps Fully Retracted 1,102 ft agl · 175 kt
Info Autopilot Master Switched On 4,637 ft agl · 249 kt
Info Autopilot Master Switched Off 8,676 ft agl · 202 kt
Info Autopilot Master Switched On 9,162 ft agl · 223 kt
Info Landing Lights Switched Off 10,087 ft agl · 229 kt
Info Autopilot Master Switched Off 13,710 ft agl · 243 kt
Info Autopilot Master Switched On 15,056 ft agl · 300 kt
Enroute Level 100.00Enroute level cruise started 46 miles south of SCGZ Guardiamarina Zañartu Airport Puerto Williams (Region de Magallanes y Antartica Chilena, Chile) and lasted 49 minutes, covering 377 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,000 ft of 29,881 ft asl29,376 ft asl min to max 30,367 ft asl 29,998 29,376 ft asl
100 % Average speed 258 kt215 kt min to max 287 kt 238 275 kt
100 % Steepest bank angle 23.3 °0.1 ° min to max 23.3 ° 1.3 0.8 °
100 % Average g force 1.00 g0.98 g min to max 1.13 g 1.04 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 2.7 °1.9 ° min to max 4.3 ° 4.3 2.1 °

Events

Fail Overspeed Warning Activated 30,147 ft agl · 446 kt
Info Autopilot Altitude Hold Activated 30,132 ft agl · 380 kt
Info Overspeed Warning Deactivated 30,145 ft agl · 446 kt
Info Overspeed Warning Activated 30,145 ft agl · 446 kt
Info Overspeed Warning Deactivated 29,909 ft agl · 445 kt
Enroute Descent 99.96Enroute descent started 102 miles north west of SCRM Teniente Rodolfo Marsh Martin Airport Villa Las Estrellas (Falkland Islands, Falkland Islands). Descent from 29,371 ft asl to 1,813 ft asl, a decrease of 27,558 ft in 18 minutes and covering 104 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 243 kt197 kt min to max 276 kt 276 197 kt
100 % Steepest bank angle 26.7 °0.0 ° min to max 26.7 ° 0.5 3.0 °
99.6 % Average g force 1.03 g0.80 g min to max 1.54 g 1.00 0.99 g
Info Average VSI -1,637 fpm-3,850 fpm min to max 1 fpm -27 -988 fpm
Info Average altitude 13,122 ft asl1,813 ft asl min to max 29,371 ft asl 29,371 1,813 ft asl
Info Average pitch angle -0.4 °-7.0 ° min to max 2.6 ° 2.1 1.2 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Altitude Hold Deactivated 29,370 ft agl · 437 kt
Info Landing Lights Switched On 9,258 ft agl · 282 kt
Info Autopilot Master Switched Off 4,752 ft agl · 262 kt
Info Autopilot Altitude Hold Activated 3,753 ft agl · 226 kt
Info Autopilot Altitude Hold Deactivated 2,244 ft agl · 250 kt
Info Autopilot Master Switched On 2,239 ft agl · 248 kt
Go-around Go-Around runway 11 at SCRM Teniente Rodolfo Marsh Martin Airport at 2,819 ft agl.
ScoreDescriptionStartProfileEnd
100 % Average speed 136 kt128 kt min to max 152 kt 143 129 kt
100 % Steepest bank angle 25.2 °1.2 ° min to max 25.2 ° 15.3 1.2 °
100 % Average g force 1.05 g0.86 g min to max 1.21 g 0.94 0.96 g
Info Average altitude 2,266 ft agl1,663 ft agl min to max 2,819 ft agl 2,819 1,663 ft agl
Info Average pitch angle -0.7 °-5.0 ° min to max 5.0 ° -4.0 -1.4 °

Events

Info Flaps Position 4 2,553 ft agl · 148 kt
Info Landing Gear Down 2,554 ft agl · 137 kt
Arrival Approach 85.71Final approach to runway 11 at SCRM Teniente Rodolfo Marsh Martin Airport. Descent from 1,760 ft agl to 19 ft agl in 106 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
50 % Sink ratefailed at one of the two gates
100 % On glideslopepassed at both gates
50 % On centrelinefailed at one of the two gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates

Events

Fail GPWS Warning Activated 544 ft agl · 126 kt
Info GPWS Warning Deactivated 31 ft agl · 124 kt
Arrival Landing 82.13Landing on runway 11 at SCRM Teniente Rodolfo Marsh Martin Airport, runway length 1,272 m. Good threshold height. Threshold speed was good at 124 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 124 kt. Target 118 kt
100 % Good threshold height.Target 50 ft agl
56 % The flare strayed well off the target profile. The aircraft was flown onto the runway - pitch changed 2.5° and the descent was barely arrested. Touchdown was 100 m past the threshold. Start the flare with progressive back pressure rather than one pull, and keep it coming.
31 % Runway alignment max 23.80 m left23.80 m left to 22.11 m left 23.80 22.11 m
100 % Steepest bank angle 1.8 °1.6 ° min to max 1.8 ° 1.6 1.8 °
100 % Peak g force 1.08 g1.05 g min to max 1.08 g 1.05 1.08 g
Info Average speed 123 kt122 kt min to max 124 kt 124 122 kt
Info Average VSI -584 fpm-664 fpm min to max -482 fpm -664 -482 fpm
Info Average altitude 8 ft agl3 ft agl min to max 14 ft agl 14 3 ft agl
Info Average pitch angle 4.0 °3.0 ° min to max 5.7 ° 3.0 5.7 °
07501123344657Runway Distance mLanding Height ft075-20-16-12-8-4048121620Runway Distance mRunway Width m
Arrival Touchdown 72.13Touchdown distance was good at 100 m. Touchdown speed at 122 kt was a little fast. Touchdown rate was hard at -449 fpm. Runway touchdown position was significantly misaligned by 22.1 m from centreline. Local weather - Temperature 15 °C. Wind 1 kt at 270 °. Crosswind: 0 kt Tailwind: 1 kt.
ScoreDescriptionStartProfileEnd
56 % Touchdown rate was -449 fpm.
100 % Touchdown distance was 100 mTarget 457 m
100 % Speed at touchdown 122 ktTarget below 118 kt
34 % Runway alignment max 22.11 m left21.96 m left 22.11 21.74 m
97 % Steepest bank angle 2.3 °1.8 ° min to max 2.3 ° 1.8 2.3 °
80 % Peak g force 1.65 g1.08 g min to max 1.65 g 1.08 1.33 g
60 % Landing Bounce
Info Average speed 122 kt122 kt min to max 122 kt 122 122 kt
Info Average pitch angle 5.9 °5.7 ° min to max 6.2 ° 5.7 6.2 °
Arrival Rollout 68.47Total landing distance 895 m, 70 % of runway. Runway rollout alignment was misaligned by 23.0 m from centreline.
ScoreDescriptionStartProfileEnd
100 % Landing distance 895 m70 % of runway.
30 % Runway alignment max 23.02 m left23.02 m left to 0.00 m left 21.27 20.61 m
98 % Average g force 0.96 g0.73 g min to max 1.53 g 1.01 0.98 g
Info Average speed 113 kt71 kt min to max 123 kt 123 71 kt
Info Average pitch angle 4.4 °-0.3 ° min to max 7.4 ° 6.3 -0.0 °
Info Average bank angle 1.0 °0.0 ° min to max 2.2 ° 2.2 1.0 °

Events

Info Autopilot Yaw Damper Deactivated 10 ft agl · 115 kt
Info Autopilot Yaw Damper Activated 11 ft agl · 113 kt
Info Autopilot Yaw Damper Deactivated 10 ft agl · 107 kt
Runway Exit Exiting runway, average speed 14 kt
ScoreDescriptionStartProfileEnd
Info Average speed 14 kt1 kt min to max 62 kt 62 6 kt
Info Average pitch angle -0.4 °-1.5 ° min to max 0.2 ° -0.9 -0.4 °
Info Average bank angle 0.2 °0.0 ° min to max 0.8 ° 0.0 0.2 °
Info Average g force 1.00 g0.97 g min to max 1.01 g 0.97 1.00 g

Events

Info Flaps Fully Retracted 8 ft agl · 11 kt
Arrival Taxi 100.00Taxiing to the parking from the runway took less than 1 minute. and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 2 kt0 kt min to max 6 kt 6 0 kt
100 % Average speed turning corners 0 ktmax 0 kt 0 0 kt
100 % Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Info Average pitch angle -0.4 °-0.5 ° min to max -0.3 ° -0.4 -0.4 °
Info Average bank angle 0.1 °0.0 ° min to max 0.2 ° 0.0 0.1 °

Events

Info Parking Brake On 8 ft agl

Takeoff from SAWH 25

Taxi out

LightsOk
All on
Taxi speed100.00
29kt peak7 kt in turns

The roll

Takeoff roll100.00
1,402m53 %
Runway alignment100.00
4.28m R
Rotation speed100.00
146kttarget 132, 14 late

Rotated late, and the nose came up quickly

Rotation started at 146 kt, 14 kt after the 132 kt rotate speed, and the nose then rose at 3.1° a second, faster than the 2 to 3° a second airliners use.

The pull started late and then came quickly, as if to make up the time. Start it on the rotate speed instead, so there is nothing to catch up, and keep it to the normal rate for this aircraft.

Liftoff and climb

Liftoff
152ktat 7.7°
Rotation
3.1°/sover 2.3 s, gaining 6 kt
35 ft
157ktat 6.8°, 2.3 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
2.9°steepest
Gear up100.00
154ftfull marks to 400 ft
Climb 3 speed48.04
175kttarget 132

Plan view the roll down the 2,635 m runway.

Rolled from the start of the runway, drifted right of the centreline, 4.7 m at the widest, and lifted off 4.8 m right. Airborne 53 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

1,0002,000THRESHOLDLEFT ↑RIGHT ↓CROSS2 kn75 %widest 4.66 m RAirborne 1,407 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,407 m of 2,635 m · 53 %
Takeoff roll, 1,407 m Left ahead, 1,228 m

Side view from the start of the roll to the end of Climb 3 at 687 ft.

Reached 35 ft with 1,043 m of runway left; gear up at 154 ft, inside the 400 ft that gets full marks; then climbing at 1,590 fpm on average to 687 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

750 ft375 ft0CLIMB 3175 kt avgtarget 132THRESHOLDRUNWAY END6080100120KNOTS ALONG THE ROLLnose up on the runway · 180 m · 2.3 sRotate 146 kttarget 132Liftoff 152 ktGear up 154 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 132180 kt12060020°10°0°nose up on the runway · 180 m · 2.3 sROTATELIFTOFFGEAR UPtarget 132held 7.6°7.7° off · 3.1°/s7° at 35 ftAIRSPEEDPITCH0306090 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2 to 3° a second, the rates airliners are rotated at: a trace steeper than both is a faster rotation, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate.

20°10°0°ROTATELIFTOFF35 FT7.7° off · 3.1°/s3°/s2°/s7° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5 sseconds from rotation
PitchRotation began2 to 3°/s from rotationNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 71.435 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate1,380 fpm920 fpm
On glideslope3.9°3.0°
On centreline1.5° off0.7° off
On speed+9.0 kt+7.6 kt
Wings level1° bank0° bank

At the 1,000 ft gate: sink rate more than 600 fpm beyond what the glideslope needed and centreline more than 1° off.

When the approach was stable

Every check met from 2.8 to 1.4 nm, then not again: left of the centreline from 1.4 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to SCRM 11

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

High from 3.8 nm, where the final began, to 3.4 nm (up to 480 ft over), then back on it to the threshold.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND7262721601,000 ft gate5 of 7sink rateon centreline1,358 ft · 127 kt500 ft gate7 of 7530 ft · 126 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 3× larger than distances along the final.

Joined 273 m left of the centreline at 3.8 nm, then inside it from 2.8 to 1.4 nm, then 56 m left of it from 1.4 nm to the threshold.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR305 m L0305 m RLEFT ↑RIGHT ↓1° BAND3 m L56 m L46 m L144 m L35 m L
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 30 kt fast at the 1,000 ft gate, closing to 18 at 500 ft and 10 at the threshold.

Inside the speed band all the way, between +3 kt and +12 kt on the approach speed of 118 kt.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

120140160180 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 118+9 kt+7 kt+4 kt+6 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on SCRM 11

Over the threshold

Threshold height100.00
14ft
Threshold speed100.00
123kttarget 118, 5 fast
Centreline offset31.14
23.80m L
Bank100.00
1.8°steepest
Flare56.07

The flare strayed well off the target profile

The aircraft was flown onto the runway - pitch changed 2.5° and the descent was barely arrested. Touchdown was 100 m past the threshold. Start the flare with progressive back pressure rather than one pull, and keep it coming.

Touchdown

Past threshold100.00
100m
Centreline33.99
22.11m L
Speed100.00
122kttarget 118, 4 fast
Touchdown rate55.78
-449fpm
Impact80.36
1.65G
Bounces60.00
2
Bank97.17
2.3°as the wheels touched

Rollout

Rollout distance100.00
771m68 % used
Rollout alignment30.40
23.02m L

Taxi in

LightsOk
All set
Taxi speed100.00
6kt peak

Side view — the last 1,272 m of the approach.

Crossed the threshold at 14 ft, 36 ft below the 50 ft target; began the flare late, at 9 ft. Touched down 100 m in, 204 m short of the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,272 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

14 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 9 ft · −520 fpm · 3.3° · 123 ktdescent slowed at 0 ft · −461 fpm · 5.7°−449 fpm · 5.7° nose up · 122 kt Ideal — 50 ft, down at 305 m This flight — 14 ft, down at 100 m

Sink and pitch — through the flare, lined up with the side view.

The sink stayed between 450 fpm and 520 fpm from the flare to the runway. The nose came up 2.4° on the way down. Into the flare at 123 kt, 5 kt over the 118 kt approach speed, and 122 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−449 fpm at touchdown5.7° at touchdown, +2.4° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the full 1,272 m runway, to the same scale as the side view.

Touched down 22 m left of the centreline, and steered back to 0.9 m left by the end of the rollout. No crosswind: nothing to correct for. Touched down straight, 2.3° of bank.

Wind 270° at 1 kt · 1 kt tail · 0 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,000 THRESHOLD LEFT ↑ RIGHT ↓ FULL SCORE TO 503 M 100 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

The 100 m touchdown sits inside the full-score zone. The 1.65 G arrival bounced 2 times.

Runway used 872 m of 1,272 m · 69 %
In the air over the runway, 100 mRollout, 771 m Left over, 400 m

The rest of the report

Explore in detail

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
