CYYC
Calgary, Canada
Runway 17L
Elevation3,553 ft asl
Weight40,625 kg
Fuel6,200 kg
Wind270° · 9 kn · 9 kn cross

Flight Score

97.18 %
KSEA
Seattle, United States
Runway 16R
Elevation413 ft asl
Weight37,105 kg
Fuel2,551 kg
Wind169° · 14 kn · 3 kn cross
17 Dec 2025 1:26 474 nm RJ85 3,648 kg
Departure Score
100.00 %
Enroute Score
99.99 %
Arrival Score
91.54 %

What went well

Touchdown 390 m in — inside the full-score zone
Threshold crossed at 45 ft and 111 kt — both inside band
Straight touchdown — 0.49 m off the centreline, no bounce

What held you back

Firm touchdown — 579 fpm, −1.96 points across the landing and the touchdown
  • Arrival Touchdown · sink rate 579 fpm−0.97
  • Arrival Landing · flare: the descent was not taken out−0.95
  • Arrival Touchdown · 1.52 G at contact−0.04
Arrival Approach — GPWS warning; 1,000 ft gate 86 %, 500 ft gate 100 %, −0.48 points
Arrival Landing — Runway alignment max 20.67 m right at 82 %, bank angle up to 6.9 ° at 88 %, −0.33 points

Next time

Arrival

Begin raising the nose earlier, by 11 ft, so the flare has time to arrest the sink before touchdown.

What happened: The flare began late at 1.1 ft, 10 ft below the normal band, and a late flare like this usually leaves too little time to arrest the sink before touchdown.

Watch for: Watch radio altitude and start the flare in the normal band, around 11 ft.

See Arrival LandingArrival Touchdown

On a 3° glideslope your sink rate in feet per minute is roughly your groundspeed in knots times five (5.3, strictly). A Cessna 172 at 65 kt groundspeed is coming down at about 345 fpm. An A320 at 140 kt groundspeed is coming down at about 740 fpm. the entire job of the flare is to take that 350 to 750 fpm and reduce it to something in the normal band, in roughly the last five seconds of the flight.

Read more in How to Land a Plane Smoothly in Microsoft Flight Simulator

Start to finish · 15 stages, 13 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 12 minutes and covered 4 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 18 kt0 kt min to max 25 kt 3 13 kt
100 % Average speed turning corners 13 ktmax 14 kt 0 13 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle -0.1 °-0.5 ° min to max 2.2 ° 2.2 -0.5 °
Info Average bank angle 0.1 °0.0 ° min to max 0.5 ° 0.1 0.4 °

Events

Info Engine 3 Started 8 ft agl
Info Engine 2 Started 8 ft agl
Info Engine 1 Started 8 ft agl
Info Pitot Heat Switched On 8 ft agl · 4 kt
Info Parking Brake On 8 ft agl · 7 kt
Info Taxi Lights Switched On 8 ft agl · 7 kt
Info Flaps Position 1 8 ft agl · 8 kt
Info Parking Brake Off 8 ft agl · 7 kt
Departure Runway Entry Entering runway 17L at CYYC Calgary International Airport, Average speed was 9 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 10 kt5 kt min to max 13 kt 13 5 kt
Info Average pitch angle -0.5 °-0.6 ° min to max -0.5 ° -0.5 -0.6 °
Info Average bank angle 0.1 °0.0 ° min to max 0.2 ° 0.2 0.0 °
Info Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Departure Roll 100.00Departure roll runway 17L at CYYC Calgary International Airport. Takeoff distance 1,542 m 36 % of runway. Rotation speed was 132 kt. Local weather - Temperature 9 °C. Wind 11 kt at 270 °. Crosswind: 11 kt Headwind: 0 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 1,542 m36 % of runway
100 % Rotation speed was 132 ktTarget 120 kt
100 % Runway alignment max 1.28 m right0.00 m left to 1.28 m right -0.63 -1.11 m
100 % Average g force 1.00 g0.96 g min to max 1.15 g 1.00 1.15 g
100 % Takeoff Bounce
Info Average pitch angle 0.1 °-0.7 ° min to max 7.7 ° -0.4 7.7 °
Info Average bank angle 0.1 °0.0 ° min to max 1.0 ° 0.0 1.0 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 17L CYYC Calgary International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.0 °0.0 ° min to max 0.0 ° 0.0 0.0 °
100 % Average speed 142 kt139 kt min to max 144 kt 139 144 kt
100 % Steepest bank angle 1.3 °1.1 ° min to max 1.3 ° 1.1 1.2 °
100 % Average g force 1.13 g0.96 g min to max 1.22 g 1.18 0.96 g
Info Average VSI 864 fpm591 fpm min to max 971 fpm 591 943 fpm
Info Average altitude 14 ft agl0 ft agl min to max 33 ft agl 0 33 ft agl
Info Average pitch angle 8.8 °7.9 ° min to max 9.2 ° 7.9 8.2 °
Departure Climb 2 100.00Departure climb to 400 ft agl from 17L CYYC Calgary International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.0 °-0.3 ° min to max 0.0 ° 0.0 -0.3 °
100 % Average speed 149 kt145 kt min to max 162 kt 145 162 kt
100 % Steepest bank angle 1.6 °0.7 ° min to max 1.6 ° 0.9 0.9 °
100 % Average g force 0.99 g0.93 g min to max 1.07 g 0.93 0.98 g
Info Average VSI 986 fpm819 fpm min to max 1,884 fpm 841 1,872 fpm
Info Average altitude 96 ft agl46 ft agl min to max 368 ft agl 46 368 ft agl
Info Average pitch angle 8.5 °7.9 ° min to max 10.3 ° 7.9 10.1 °

Events

Info Landing Gear Up 82 ft agl · 156 kt
Departure Climb 3 100.00Departure climb to 1,000 ft agl from 17L CYYC Calgary International Airport.
ScoreDescriptionStartProfileEnd
100 % Climb speed 169 kt163 kt min to max 172 ktTarget 158 kt, 11 kt fast 163 169 kt
100 % Steepest bank angle 1.1 °0.6 ° min to max 1.1 ° 1.0 1.1 °
100 % Average g force 1.05 g1.02 g min to max 1.09 g 1.02 1.03 g
100 % Landing gear up at 67 ft aglTarget by 400 ft agl
Info Heading variation -0.6 °-0.8 ° min to max -0.4 ° -0.4 -0.8 °
Info Average VSI 2,678 fpm1,931 fpm min to max 3,504 fpm 1,931 3,504 fpm
Info Average altitude 650 ft agl399 ft agl min to max 924 ft agl 399 924 ft agl
Info Average pitch angle 11.9 °9.9 ° min to max 14.5 ° 10.0 14.5 °
Enroute Climb 100.00Enroute climb started 1 mile south east of CYYC Calgary International Airport Calgary (Alberta, Canada). Climbing from 4,546 ft asl to 28,087 ft asl, an increase of 23,541 ft in 18 minutes and covering 93 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 259 kt150 kt min to max 286 kt 168 257 kt
100 % Steepest bank angle 32.5 °0.0 ° min to max 32.5 ° 1.1 0.2 °
100 % Average g force 1.02 g0.78 g min to max 1.24 g 1.07 1.04 g
Info Average VSI 1,527 fpm136 fpm min to max 3,922 fpm 3,658 987 fpm
Info Average altitude 15,813 ft asl4,546 ft asl min to max 28,087 ft asl 4,546 28,087 ft asl
Info Average pitch angle 5.5 °2.4 ° min to max 16.0 ° 15.2 4.1 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Master Switched On 1,331 ft agl · 171 kt
Info Flaps Fully Retracted 2,219 ft agl · 203 kt
Info Landing Lights Switched Off 6,909 ft agl · 290 kt
Info Autopilot Vertical Hold Activated 15,261 ft agl · 386 kt
Enroute Level 100.00Enroute level cruise started 6 miles west of Sparwood (British Columbia, Canada) and lasted 25 minutes, covering 276 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±1,914 ft of 29,088 ft asl28,274 ft asl min to max 29,297 ft asl 28,274 28,923 ft asl
100 % Average speed 273 kt253 kt min to max 276 kt 256 275 kt
100 % Steepest bank angle 31.9 °0.0 ° min to max 31.9 ° 0.5 0.2 °
100 % Average g force 1.02 g0.87 g min to max 1.19 g 0.98 0.87 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 2.3 °-3.7 ° min to max 4.2 ° 4.0 -3.7 °

Events

Info Autopilot Airspeed Hold Activated 21,663 ft agl · 394 kt
Info Autopilot AutoThrottle Arm Armed 21,663 ft agl · 394 kt
Info Autopilot Altitude Hold Activated 23,842 ft agl · 396 kt
Info Autopilot Vertical Hold Deactivated 23,842 ft agl · 396 kt
Info Autopilot Altitude Hold Deactivated 26,556 ft agl · 428 kt
Info Autopilot Airspeed Hold Deactivated 26,556 ft agl · 428 kt
Info Autopilot AutoThrottle Arm Disarmed 26,556 ft agl · 428 kt
Enroute Descent 99.98Enroute descent started 8 miles west of 5WA5 Ross Airport Orondo (Washington, United States). Descent from 28,138 ft asl to 1,700 ft asl, a decrease of 26,438 ft in 21 minutes and covering 93 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 249 kt175 kt min to max 285 kt 281 177 kt
100 % Steepest bank angle 33.0 °0.0 ° min to max 33.0 ° 0.1 1.3 °
99.8 % Average g force 1.04 g0.71 g min to max 1.48 g 1.12 1.00 g
Info Average VSI -1,197 fpm-3,794 fpm min to max 1,685 fpm -3,794 -872 fpm
Info Average altitude 12,231 ft asl1,700 ft asl min to max 28,138 ft asl 28,138 1,700 ft asl
Info Average pitch angle -0.1 °-2.8 ° min to max 2.1 ° -2.8 -0.6 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Airspeed Hold Activated 23,895 ft agl · 418 kt
Info Autopilot AutoThrottle Arm Armed 23,895 ft agl · 418 kt
Info Autopilot Vertical Hold Activated 23,895 ft agl · 418 kt
Info Autopilot Airspeed Hold Deactivated 15,179 ft agl · 357 kt
Info Autopilot AutoThrottle Arm Disarmed 15,179 ft agl · 357 kt
Info Autopilot Vertical Hold Deactivated 15,179 ft agl · 357 kt
Info Landing Lights Switched On 10,380 ft agl · 294 kt
Info Autopilot Airspeed Hold Activated 5,017 ft agl · 269 kt
Info Autopilot AutoThrottle Arm Armed 5,017 ft agl · 269 kt
Info Autopilot Vertical Hold Activated 4,739 ft agl · 274 kt
Info Flaps Position 1 2,837 ft agl · 199 kt
Info Autopilot Vertical Hold Deactivated 2,846 ft agl · 195 kt
Info Landing Gear Down 2,528 ft agl · 189 kt
Arrival Approach 92.86Final approach to runway 16R at KSEA Seattle–Tacoma International Airport. Descent from 1,316 ft agl to 29 ft agl in 126 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
50 % On speedfailed at one of the two gates
100 % Wings levelpassed at both gates

Events

Fail GPWS Warning Activated 489 ft agl · 116 kt
Fail GPWS Warning Activated 469 ft agl · 129 kt
Fail GPWS Warning Activated 346 ft agl · 119 kt
Info Flaps Position 2 1,368 ft agl · 159 kt
Info Flaps Position 4 683 ft agl · 128 kt
Info Autopilot Master Switched Off 636 ft agl · 127 kt
Info Autopilot AutoThrottle Arm Disarmed 641 ft agl · 129 kt
Info GPWS Warning Deactivated 478 ft agl · 124 kt
Info GPWS Warning Deactivated 457 ft agl · 130 kt
Info GPWS Warning Deactivated 273 ft agl · 127 kt
Arrival Landing 80.85Landing on runway 16R at KSEA Seattle–Tacoma International Airport, runway length 2,588 m. Good threshold height. Threshold speed was good at 111 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 111 kt. Target 113 kt
100 % Good threshold height.Target 50 ft agl
36 % The flare strayed well off the target profile. The flare began at 1 ft agl above the runway, lower than this aircraft wants. Touchdown was 390 m past the threshold. Begin raising the nose earlier - a late flare leaves no time to arrest the sink.
82 % Runway alignment max 20.67 m right0.22 m right to 20.67 m right -20.67 -0.22 m
88 % Steepest bank angle 6.9 °0.0 ° min to max 6.9 ° 6.9 3.5 °
98 % Peak g force 1.28 g0.74 g min to max 1.28 g 0.90 0.74 g
Info Average speed 107 kt105 kt min to max 111 kt 111 105 kt
Info Average VSI -337 fpm-1,267 fpm min to max 133 fpm -1,267 -686 fpm
Info Average altitude 14 ft agl1 ft agl min to max 46 ft agl 46 1 ft agl
Info Average pitch angle 5.8 °0.5 ° min to max 7.6 ° 2.4 0.5 °

Events

Info Stall Warning Activated 34 ft agl · 108 kt
Info Stall Warning Deactivated 27 ft agl · 107 kt
07515022530037545001123344657Runway Distance mLanding Height ft075150225300375450-25-20-15-10-50510152025Runway Distance mRunway Width m
Arrival Touchdown 83.96Touchdown distance was good at 390 m. Touchdown speed at 105 kt was good. Touchdown rate was very hard at -579 fpm. Runway touchdown alignment was perfect. Local weather - Temperature 13 °C. Wind 24 kt at 180 °. Crosswind: 0 kt Headwind: 24 kt.
ScoreDescriptionStartProfileEnd
27 % Touchdown rate was -579 fpm.
100 % Touchdown distance was 390 mTarget 457 m
100 % Speed at touchdown 105 ktTarget below 112 kt
100 % Runway alignment max 0.49 m left0.17 m left -0.22 0.49 m
84 % Steepest bank angle 3.5 °1.1 ° min to max 3.5 ° 3.5 1.2 °
88 % Peak g force 1.52 g0.72 g min to max 1.52 g 0.74 1.19 g
100 % Landing Bounce
Info Average speed 103 kt102 kt min to max 105 kt 105 102 kt
Info Average pitch angle -0.5 °-1.1 ° min to max 0.5 ° 0.5 -1.1 °
Arrival Rollout 100.00Total landing distance 751 m, 29 % of runway. Runway rollout alignment was perfect.
ScoreDescriptionStartProfileEnd
100 % Landing distance 751 m29 % of runway.
100 % Runway alignment max 1.86 m right1.46 m left to 1.86 m right 1.46 -1.86 m
100 % Average g force 1.03 g1.00 g min to max 1.14 g 1.14 1.00 g
Info Average speed 80 kt45 kt min to max 86 kt 86 45 kt
Info Average pitch angle 0.2 °-1.1 ° min to max 1.7 ° -1.1 -0.4 °
Info Average bank angle 0.8 °0.0 ° min to max 1.5 ° 1.3 0.2 °

Events

Info Taxi Lights Switched On 8 ft agl · 75 kt
Info Strobe Lights Switched Off 8 ft agl · 70 kt
Info Landing Lights Switched Off 8 ft agl · 65 kt
Runway Exit Exiting runway, average speed 42 kt
ScoreDescriptionStartProfileEnd
Info Average speed 26 kt18 kt min to max 42 kt 42 18 kt
Info Average pitch angle -0.3 °-0.3 ° min to max -0.2 ° -0.3 -0.3 °
Info Average bank angle 0.0 °0.0 ° min to max 0.1 ° 0.0 0.0 °
Info Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g

Events

Info Flaps Position 3 8 ft agl · 54 kt
Info Flaps Position 2 8 ft agl · 45 kt
Info Flaps Fully Retracted 8 ft agl · 42 kt
Arrival Taxi 100.00Taxiing to the parking from the runway took 8 minutes and covered 2 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 17 kt0 kt min to max 25 kt 17 0 kt
100 % Average speed turning corners 12 ktmax 13 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle -0.3 °-0.4 ° min to max -0.2 ° -0.3 -0.3 °
Info Average bank angle 0.0 °0.0 ° min to max 0.4 ° 0.0 0.0 °

Events

Info Autopilot Airspeed Hold Deactivated 8 ft agl · 39 kt
Info Autopilot Flight Director Deactivated 8 ft agl · 40 kt
Info Autopilot Yaw Damper Activated 8 ft agl
Info Autopilot Yaw Damper Deactivated 8 ft agl
Info Taxi Lights Switched Off 8 ft agl · 15 kt
Info Parking Brake On 8 ft agl · 14 kt
Info Autopilot Yaw Damper Activated 8 ft agl · 14 kt

Takeoff from CYYC 17L

Taxi out

LightsOk
All on
Taxi speed100.00
25kt peak13 kt in turns

The roll

Takeoff roll100.00
1,542m36 %
Runway alignment100.00
1.28m R
Rotation speed100.00
132kttarget 120, 12 late

Rotated late

Rotation started at 132 kt, 12 kt after the 120 kt rotate speed.

The pull started after the rotate speed had gone by. Bring the airspeed into the scan as it approaches the rotate speed, so the pull starts on the number rather than when you notice it has passed.

Liftoff and climb

Liftoff
139ktat 7.9°
Rotation
2.8°/sover 2.7 s, gaining 7 kt
35 ft
145ktat 7.9°, 3.4 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
1.3°steepest
Gear up100.00
67ftfull marks to 400 ft
Climb 3 speed100.00
169kttarget 158

Plan view the roll down the 4,258 m runway.

Rolled from 54 m in, never more than 1.3 m off the centreline, in 8 kn of crosswind from the right. Airborne 36 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

1,0002,0003,0004,000THRESHOLDLEFT ↑RIGHT ↓CROSS8 kn75 %widest 1.28 m RROLL 54 M INAirborne 1,547 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,547 m of 4,258 m · 36 %
Behind the start of the roll, 54 mTakeoff roll, 1,493 m Left ahead, 2,711 m

Side view from the start of the roll to the end of Climb 3 at 924 ft.

Reached 35 ft with 2,446 m of runway left; gear up at 67 ft, inside the 400 ft that gets full marks; then climbing at 1,790 fpm on average to 924 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3169 kt avgtarget 158THRESHOLDRUNWAY END6080100120KNOTS ALONG THE ROLLnose up on the runway · 196 m · 2.7 sRotate 132 kttarget 120Liftoff 139 ktGear up 67 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 158180 kt12060020°10°0°nose up on the runway · 196 m · 2.7 sROTATELIFTOFFtarget 120held 9.1°7.9° off · 2.8°/s8° at 35 ftAIRSPEEDPITCH0204060 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2 to 3° a second, the rates airliners are rotated at: a trace steeper than both is a faster rotation, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate.

20°10°0°ROTATELIFTOFF35 FT3°/s7.9° off · 2.8°/s2°/s8° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5+6+7 sseconds from rotation
PitchRotation began2 to 3°/s from rotationNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 85.716 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate700 fpm630 fpm
On glideslope3.0°3.3°
On centreline0.3° off
On speed+42 kt−3.7 kt
Wings level2° bank2° bank

At the 1,000 ft gate: speed more than 30 kt above the approach speed of 119 kt.

When the approach was stable

Every check met from 1.8 nm, about 640 ft above the runway, to the threshold, after the 1,000 ft gate and before the 500 ft gate. The last to settle was the centreline.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to KSEA 16R

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 100 ft below the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,3346704462061,000 ft gate6 of 7on speed1,049 ft · 161 kt500 ft gate7 of 7592 ft · 115 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 4× larger than distances along the final.

Inside the 1° band from 4 nm to 2.2 nm, then drifted 87 m right between 2.2 and 1.8 nm, then inside the band from 1.8 nm to the threshold.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR219 m L0219 m RLEFT ↑RIGHT ↓1° BAND13 m R87 m R23 m R12 m L0 m L17 m R
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 30 kt fast at the 1,000 ft gate, closing to 18 at 500 ft and 10 at the threshold.

Fast from 4 nm to 2.7 nm (up to +61 kt), then inside the band to the threshold.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

120140160180 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 119+61 kt+8 kt+10 kt−1 kt−8 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on KSEA 16R

Over the threshold

Threshold height100.00
45ft
Threshold speed100.00
111kttarget 113, 2 slow
Centreline offset81.76
20.67m R
Bank87.65
6.9°steepest
Flare36.00

The flare strayed well off the target profile

The flare began at 1 ft agl above the runway, lower than this aircraft wants. Touchdown was 390 m past the threshold. Begin raising the nose earlier - a late flare leaves no time to arrest the sink.

Touchdown

Past threshold100.00
390m
Centreline100.00
0.49m L
Speed100.00
104kttarget 112 or less
Touchdown rate26.90
-579fpm
Impact88.10
1.52G
BouncesOk
None
Bank83.58
3.5°as the wheels touched

Rollout

Rollout distance100.00
336m28 % used
Rollout alignment100.00
1.86m R

Taxi in

LightsOk
All set
Taxi speed100.00
25kt peak12 kt in turns

Side view — the last 1,524 m of the approach.

Crossed the threshold at 45 ft, close to the 50 ft target; began the flare late, at 1 ft. Touched down 390 m in, 85 m past the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,524 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

45 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 1 ft · −592 fpm · 0.5° · 105 ktdescent slowed at 1 ft · −592 fpm · 0.5°−578 fpm · 0.5° nose up · 105 kt Ideal — 50 ft, down at 305 m This flight — 45 ft, down at 390 m

Sink and pitch — through the flare, lined up with the side view.

The sink stayed between 580 fpm and 590 fpm from the flare to the runway. The pitch barely changed. Into the flare at 105 kt, 8 kt under the 113 kt approach speed, and 105 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−750−1,5000°5°10°flaredescent slowedtouchdown−578 fpm at touchdown0.5° at touchdown, +0° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,524 m of the 2,588 m runway, to the same scale as the side view.

Touched down on the centreline, and stayed within 1.9 m of it down the rollout. Little crosswind (2 kt): nothing to correct for. Touched down with the nose 1° right of the track, 3.5° of bank.

Wind 169° at 14 kt · 13 kt head · 2 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ CROSS 2 kn FULL SCORE TO 503 M 390 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

The 390 m touchdown sits inside the full-score zone. The 578 fpm arrival was firm.

Runway used 726 m of 2,588 m · 28 %
In the air over the runway, 390 mRollout, 336 m Left over, 1,862 m

The stop — touchdown to taxi speed.

From 87 kt at touchdown to taxi speed (30 kt) in 30 s, an average deceleration of 0.10 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

02040608010060 kt · 310 m30 kt · 734 mtouchdown763 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Flight narrative

The flight began with a taxiing period from the parking to the runway, which took 12 minutes and covered a distance of 4 nautical miles. The aircraft, an RJ85, then departed from runway 17L at Calgary International Airport (CYYC). The takeoff distance was 1,488 meters, which accounted for 35% of the runway. The liftoff speed was 139 knots.

As the aircraft took off, it encountered local weather conditions with a temperature of 9 degrees Celsius and a wind speed of 11 knots from a direction of 270 degrees. The crosswind component was 11 knots, while the headwind component was zero. After departing from Calgary, the enroute climb began approximately 1 mile south east of the airport, with the aircraft ascending from an altitude of 4,546 feet above sea level to 28,087 feet above sea level. This climb, which covered a distance of 91 nautical miles, took 18 minutes and resulted in an increase of 23,541 feet in altitude.

Following the enroute climb, the aircraft entered a level cruise phase, which started 6 miles west of Sparwood, British Columbia, Canada. This phase lasted for 25 minutes and covered a distance of 239 nautical miles. The enroute descent then began 8 miles west of Ross Airport (5WA5) in Orondo, Washington, United States. During this phase, the aircraft descended from an altitude of 28,138 feet above sea level to 1,700 feet above sea level, resulting in a decrease of 26,438 feet in altitude. This descent, which covered a distance of 81 nautical miles, took 21 minutes.

As the aircraft approached Seattle–Tacoma International Airport (KSEA), it began its final approach to runway 16R from the north, heading 180 degrees. The aircraft was at an altitude of 1,259 feet above ground level and 4 nautical miles from the runway. The local weather conditions at the time of landing were a temperature of 13 degrees Celsius and a wind speed of 24 knots from a direction of 180 degrees. The crosswind component was zero, while the headwind component was 24 knots.

The aircraft landed on runway 16R, which had a length of 2,590 meters. The threshold height was good, and the threshold speed was slightly below the target speed at 111 knots. The touchdown distance was good at 389 meters, and the touchdown speed was 105 knots, which was also good. However, the touchdown rate was heavy at -686 feet per minute. The runway touchdown alignment was perfect, and the runway rollout alignment was also perfect after the landing.

Following the landing, the aircraft taxied to the parking area, which took 8 minutes and covered a distance of less than 1 nautical mile. The total flight distance was 422 nautical miles, and the flight duration was 86 minutes. The aircraft used 3,648 kilograms of fuel during the flight.

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
