LFBP
Pau/Pyrénées (Uzein), France
Runway 31
Elevation597 ft asl
Weight64,784 kg
Fuel21,028 kg
Wind110° · 2 kn

Flight Score

99.21 %
UWSG
Saratov, Russia
Runway 26
Elevation102 ft asl
Weight54,253 kg
Fuel10,452 kg
Wind0° · 1 kn · 1 kn cross
11 Nov 2025 4:16 2011 nm Boeing 737-700 10,576 kg
Departure Score
99.06 %
Enroute Score
100.00 %
Arrival Score
98.57 %

What went well

Touched down at -220 fpm — a soft arrival
Touchdown 310 m in — inside the full-score zone
Threshold crossed at 16 ft and 125 kt — both inside band

What held you back

Arrival Approach — 1,000 ft gate 86 %, 500 ft gate 100 %, −0.48 points
Departure Climb 3 — climb speed 206 kt against 176 kt at 88 %, −0.31 points

Next time

Departure

Reduce climb power to bring speed back to 176 kt and hold it there.

What happened: Climb speed was 30 kt fast at 206 kt during the climb.

Watch for: Airspeed indicator: 176 kt in the climb

See Departure Climb 3

Arrival

Reduce power earlier on approach to bring speed back to 125 kt by the gate.

What happened: The aircraft was too fast at the stabilisation gate, 54 kt above the target of 125 kt.

Watch for: Airspeed indicator: 125 kt at the gate

See Arrival Approach

Preparing for a stable approach will give you time to decide on whether to attempt the landing or going around. Too much altitude with a high sink rate will result in carrying too much speed onto the runway. Configuring flaps and the gear late also won't help the speed decay.

Read more in The Stabilised Approach

Start to finish · 16 stages, 14 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 3 minutes and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 16 kt0 kt min to max 23 kt 0 11 kt
100 % Average speed turning corners 15 ktmax 15 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle -1.1 °-1.4 ° min to max -1.0 ° -1.3 -1.3 °
Info Average bank angle 0.1 °0.0 ° min to max 0.3 ° 0.2 0.2 °

Events

Info Parking Brake Off 8 ft agl
Info Taxi Lights Switched On 8 ft agl
Info Engine 1 Started 8 ft agl
Info Beacon Lights Switched Off 8 ft agl
Info Beacon Lights Switched On 8 ft agl
Info Parking Brake On 8 ft agl · 1 kt
Info Parking Brake Off 8 ft agl · 1 kt
Info Landing Lights Switched On 8 ft agl · 15 kt
Info Strobe Lights Switched On 8 ft agl · 15 kt
Departure Runway Entry Entering runway 31 at LFBP Pau Pyrénées Airport, Average speed was 9 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 11 kt10 kt min to max 11 kt 11 10 kt
Info Average pitch angle -1.4 °-1.4 ° min to max -1.3 ° -1.4 -1.4 °
Info Average bank angle 0.1 °0.0 ° min to max 0.2 ° 0.2 0.0 °
Info Average g force 1.00 g0.99 g min to max 1.01 g 0.99 1.01 g
Departure Roll 100.00Departure roll runway 31 at LFBP Pau Pyrénées Airport. Takeoff distance 1,232 m 50 % of runway. Rotation speed was 138 kt. Local weather - Temperature 23 °C. Wind 2 kt at 109 °. Crosswind: 0 kt Tailwind: 1 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 1,232 m50 % of runway
100 % Rotation speed was 138 ktTarget 134 kt
100 % Runway alignment max 4.63 m left4.63 m left to 0.00 m left 4.63 3.27 m
100 % Average g force 1.01 g0.97 g min to max 1.04 g 0.99 1.03 g
100 % Takeoff Bounce
Info Average pitch angle -0.9 °-1.6 ° min to max 8.2 ° -1.4 8.2 °
Info Average bank angle 0.1 °0.0 ° min to max 0.4 ° 0.1 0.1 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 31 LFBP Pau Pyrénées Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.1 °-0.2 ° min to max -0.0 ° -0.2 -0.0 °
100 % Average speed 158 kt149 kt min to max 167 kt 149 167 kt
100 % Steepest bank angle 1.0 °0.0 ° min to max 1.0 ° 0.1 0.9 °
100 % Average g force 1.05 g1.01 g min to max 1.10 g 1.04 1.09 g
Info Average VSI 423 fpm140 fpm min to max 733 fpm 140 733 fpm
Info Average altitude 15 ft agl0 ft agl min to max 38 ft agl 0 38 ft agl
Info Average pitch angle 8.6 °8.0 ° min to max 9.3 ° 8.4 9.0 °

Events

Info Landing Gear Up 11 ft agl · 154 kt
Departure Climb 2 100.00Departure climb to 400 ft agl from 31 LFBP Pau Pyrénées Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.0 °-0.0 ° min to max 0.4 ° -0.0 0.4 °
100 % Average speed 174 kt167 kt min to max 197 kt 167 197 kt
100 % Steepest bank angle 0.9 °0.1 ° min to max 0.9 ° 0.9 0.1 °
100 % Average g force 1.00 g0.95 g min to max 1.19 g 1.08 0.95 g
Info Average VSI 1,088 fpm759 fpm min to max 2,490 fpm 759 2,490 fpm
Info Average altitude 87 ft agl40 ft agl min to max 362 ft agl 40 362 ft agl
Info Average pitch angle 8.6 °7.9 ° min to max 11.8 ° 8.9 10.4 °

Events

Info Flaps Position 4 106 ft agl · 181 kt
Info Flaps Position 3 223 ft agl · 193 kt
Info Flaps Position 2 392 ft agl · 203 kt
Departure Climb 3 95.29Departure climb to 1,000 ft agl from 31 LFBP Pau Pyrénées Airport.
ScoreDescriptionStartProfileEnd
88 % Climb speed 206 kt201 kt min to max 209 ktTarget 176 kt, 30 kt fast 201 209 kt
100 % Steepest bank angle 2.4 °0.3 ° min to max 2.4 ° 0.7 1.0 °
100 % Average g force 1.08 g0.93 g min to max 1.18 g 0.93 1.00 g
100 % Landing gear up at 5 ft aglTarget by 400 ft agl
Info Heading variation 0.5 °0.4 ° min to max 0.5 ° 0.4 0.5 °
Info Average VSI 3,220 fpm2,404 fpm min to max 4,282 fpm 2,439 4,282 fpm
Info Average altitude 648 ft agl443 ft agl min to max 900 ft agl 443 900 ft agl
Info Average pitch angle 13.2 °9.8 ° min to max 15.2 ° 9.8 15.2 °

Events

Info Flaps Position 1 516 ft agl · 210 kt
Enroute Climb 100.00Enroute climb started overhead Uzein (Nouvelle-Aquitaine, France). Climbing from 1,587 ft asl to 39,070 ft asl, an increase of 37,483 ft in 41 minutes and covering 323 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 275 kt202 kt min to max 341 kt 209 252 kt
100 % Steepest bank angle 30.1 °0.0 ° min to max 30.1 ° 0.8 0.2 °
100 % Average g force 1.02 g0.86 g min to max 1.15 g 0.98 1.01 g
Info Average VSI 1,797 fpm-99 fpm min to max 4,987 fpm 4,386 48 fpm
Info Average altitude 23,188 ft asl1,587 ft asl min to max 39,080 ft asl 1,587 39,070 ft asl
Info Average pitch angle 6.4 °1.8 ° min to max 17.1 ° 15.2 3.7 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Landing Lights Switched Off 9,766 ft agl · 272 kt
Info Taxi Lights Switched Off 9,766 ft agl · 272 kt
Enroute Level 100.00Enroute level cruise started overhead Chindrieux (Auvergne-Rhone-Alpes, France) and lasted 221 minutes, covering 1,571 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,454 ft of 39,061 ft asl38,876 ft asl min to max 39,130 ft asl 39,085 38,876 ft asl
100 % Average speed 254 kt251 kt min to max 257 kt 253 257 kt
100 % Steepest bank angle 18.7 °0.0 ° min to max 18.7 ° 0.1 14.8 °
100 % Average g force 1.00 g0.96 g min to max 1.09 g 0.99 1.03 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 3.2 °2.1 ° min to max 3.8 ° 3.5 2.2 °
Enroute Descent 100.00Enroute descent started 16 miles east of Rtishchevo (Saratovskaya Oblast, Russia). Descent from 38,865 ft asl to 2,568 ft asl, a decrease of 36,297 ft in 14 minutes and covering 101 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 268 kt245 kt min to max 340 kt 257 253 kt
100 % Steepest bank angle 30.1 °0.0 ° min to max 30.1 ° 13.1 5.7 °
99.98 % Average g force 1.05 g0.72 g min to max 1.34 g 1.02 1.00 g
Info Average VSI -2,825 fpm-5,034 fpm min to max -142 fpm -598 -1,487 fpm
Info Average altitude 16,148 ft asl2,568 ft asl min to max 38,865 ft asl 38,865 2,568 ft asl
Info Average pitch angle -3.3 °-7.3 ° min to max 2.6 ° 2.1 -2.3 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Landing Lights Switched On 19,610 ft agl · 438 kt
Info Taxi Lights Switched On 19,610 ft agl · 438 kt
Info Flaps Position 1 13,576 ft agl · 314 kt
Info Flaps Fully Retracted 13,535 ft agl · 312 kt
Info Flaps Position 1 13,428 ft agl · 305 kt
Info Flaps Position 3 13,297 ft agl · 304 kt
Info Flaps Position 1 13,220 ft agl · 304 kt
Info Flaps Position 2 13,033 ft agl · 304 kt
Info Flaps Position 3 12,847 ft agl · 304 kt
Enroute Level 2 100.00Enroute level cruise started 6 miles west of Marks (Saratovskaya Oblast, Russia) and lasted 3 minutes, covering 10 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±617 ft of 1,784 ft asl1,326 ft asl min to max 2,334 ft asl 2,334 1,326 ft asl
100 % Average speed 227 kt194 kt min to max 251 kt 251 194 kt
100 % Steepest bank angle 6.9 °0.0 ° min to max 6.9 ° 3.8 0.3 °
100 % Average g force 1.01 g0.92 g min to max 1.13 g 1.02 0.98 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle -0.0 °-2.4 ° min to max 2.2 ° -1.2 0.6 °

Events

Info Landing Gear Down 1,952 ft agl · 251 kt
Info Flaps Position 4 1,380 ft agl · 203 kt
Arrival Approach 92.86Final approach to runway 26 at UWSG Gagarin International Airport. Descent from 1,251 ft agl to 26 ft agl in 93 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
50 % On speedfailed at one of the two gates
100 % Wings levelpassed at both gates

Events

Info Flaps Position 5 1,213 ft agl · 188 kt
Info Flaps Position 6 992 ft agl · 175 kt
Info Flaps Position 5 976 ft agl · 175 kt
Info Flaps Position 6 959 ft agl · 174 kt
Info Flaps Position 7 739 ft agl · 155 kt
Info Flaps Position 8 690 ft agl · 150 kt
Arrival Landing 100.00Landing on runway 26 at UWSG Gagarin International Airport, runway length 2,742 m. Good threshold height. Threshold speed was good at 125 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 125 kt. Target 125 kt
100 % Good threshold height.Target 50 ft agl
100 % Perfect landing flare
100 % Runway alignment max 2.07 m left2.07 m left to 0.77 m right 2.07 -0.77 m
100 % Steepest bank angle 2.0 °0.0 ° min to max 2.0 ° 2.0 0.2 °
100 % Peak g force 1.12 g0.96 g min to max 1.12 g 1.05 0.96 g
Info Average speed 122 kt119 kt min to max 125 kt 125 119 kt
Info Average VSI -297 fpm-582 fpm min to max -135 fpm -582 -165 fpm
Info Average altitude 5 ft agl-1 ft agl min to max 16 ft agl 16 -1 ft agl
Info Average pitch angle 4.6 °3.5 ° min to max 5.1 ° 3.5 4.5 °
07515022530037501123344657Runway Distance mLanding Height ft075150225300375-25-20-15-10-50510152025Runway Distance mRunway Width m
Arrival Touchdown 100.00Touchdown distance was good at 310 m. Touchdown speed at 119 kt was good. Touchdown rate was fair at -220 fpm. Runway touchdown alignment was perfect. Local weather - Temperature 8 °C. Wind 1 kt at 0 °. Crosswind: 1 kt Headwind: 0 kt.
ScoreDescriptionStartProfileEnd
100 % Touchdown rate was -220 fpm.
100 % Touchdown distance was 310 mTarget 457 m
100 % Speed at touchdown 119 ktTarget below 124 kt
100 % Runway alignment max 1.27 m right1.01 m right -0.77 -1.27 m
100 % Steepest bank angle 0.4 °0.0 ° min to max 0.4 ° 0.2 0.1 °
100 % Peak g force 1.15 g0.96 g min to max 1.15 g 0.96 1.10 g
100 % Landing Bounce
Info Average speed 119 kt118 kt min to max 119 kt 119 118 kt
Info Average pitch angle 4.5 °4.5 ° min to max 4.5 ° 4.5 4.5 °
Arrival Rollout 100.00Total landing distance 759 m, 28 % of runway. Runway rollout alignment was perfect.
ScoreDescriptionStartProfileEnd
100 % Landing distance 759 m28 % of runway.
100 % Runway alignment max 2.84 m right0.00 m left to 2.84 m right -2.75 -2.62 m
100 % Average g force 1.00 g0.97 g min to max 1.09 g 1.09 0.99 g
Info Average speed 109 kt61 kt min to max 117 kt 117 61 kt
Info Average pitch angle 3.1 °-1.4 ° min to max 4.6 ° 4.5 -1.4 °
Info Average bank angle 0.2 °0.0 ° min to max 0.6 ° 0.2 0.0 °
Runway Exit Exiting runway, average speed 29 kt
ScoreDescriptionStartProfileEnd
Info Average speed 28 kt21 kt min to max 54 kt 54 21 kt
Info Average pitch angle -1.4 °-1.7 ° min to max -1.1 ° -1.3 -1.7 °
Info Average bank angle 0.2 °0.0 ° min to max 0.5 ° 0.2 0.0 °
Info Average g force 1.00 g0.98 g min to max 1.00 g 0.98 1.00 g

Events

Info Landing Lights Switched Off 8 ft agl · 22 kt
Info Strobe Lights Switched Off 8 ft agl · 22 kt
Info Flaps Position 7 8 ft agl · 22 kt
Info Flaps Position 6 8 ft agl · 22 kt
Info Flaps Position 5 8 ft agl · 22 kt
Arrival Taxi 100.00

Events

Info Flaps Position 4 8 ft agl · 22 kt

Takeoff from LFBP 31

Taxi out

LightsOk
All on
Taxi speed100.00
23kt peak15 kt in turns

The roll

Takeoff roll100.00
1,232m50 %
Runway alignment100.00
4.63m L
Rotation speed100.00
138kttarget 134, 4 late

The nose wandered in the climb

From 35 ft to the end of the climb the nose moved between 7.9° and 15.2°, and the speed between 166 kt and 209 kt.

Once clear of the runway the nose moved through a wide range, and the speed moved with it. Set the climb attitude, hold it and trim, and give the speed a few seconds to settle before correcting it with a degree or two of pitch. Chasing the airspeed with large pitch changes makes it wander more.

Liftoff and climb

Liftoff
148ktat 8.4°
Rotation
3.9°/sover 2.5 s, gaining 10 kt
35 ft
166ktat 9.2°, 4.2 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
1.0°steepest
Gear up100.00
5ftfull marks to 400 ft
Climb 3 speed88.23
206kttarget 176

Plan view the roll down the 2,486 m runway.

Rolled from 63 m in, drifted left of the centreline, 4.9 m at the widest, and lifted off 3.4 m left. Airborne 49 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length.

1,0002,000THRESHOLDLEFT ↑RIGHT ↓75 %widest 4.91 m LROLL 63 M INAirborne 1,238 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,238 m of 2,486 m · 50 %
Behind the start of the roll, 63 mTakeoff roll, 1,175 m Left ahead, 1,248 m

Side view from the start of the roll to the end of Climb 3 at 900 ft.

Reached 35 ft with 892 m of runway left; gear up at 5 ft, inside the 400 ft that gets full marks; then climbing at 2,130 fpm on average to 900 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3206 kt avgtarget 176THRESHOLDRUNWAY END6080100120KNOTS ALONG THE ROLLnose up on the runway · 191 m · 2.5 sRotate 138 kttarget 134Liftoff 148 ktGear up 5 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 176210 kt14070020°10°0°nose up on the runway · 191 m · 2.5 sROTATELIFTOFFtarget 134held 9.3°8.4° off · 3.9°/s9° at 35 ftAIRSPEEDPITCH0204060 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2.6 to 4.8° a second, the middle half of rotation rates flown by other Boeing 737-700 pilots over the last 180 days (90 takeoffs); the grey pair are 2 to 3° a second, the rates airliners are rotated at. A trace steeper than both green lines is a faster rotation than most, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 14.7°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 14.7°ROTATELIFTOFF35 FT4.8°/s8.4° off · 3.9°/s3°/s2.6°/s2°/s9° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5+6+7 sseconds from rotation
PitchRotation began2.6 to 4.8°/s, other Boeing 737-700 pilots2 to 3°/s from rotation, airlinersTail strikeNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 85.716 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate1,010 fpm940 fpm
On glideslope2.9°2.8°
On centreline0.0° off0.1° off
On speed+54 kt+13 kt
Wings level0° bank1° bank

At the 1,000 ft gate: speed more than 31 kt above the approach speed of 125 kt.

When the approach was stable

Every check met from 1.8 to 0.4 nm, then not again: low from 0.4 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to UWSG 26

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

On the glideslope from 4 nm to 0.4 nm, then low to the threshold (up to 60 ft under).

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,2416222811531,000 ft gate6 of 7on speed994 ft · 179 kt500 ft gate7 of 7506 ft · 138 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 39× larger than distances along the final.

Inside the 1° band all the way from 4 nm, never more than 9 m off the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR24 m L024 m RLEFT ↑RIGHT ↓1° BAND9 m R1 m R2 m R3 m R6 m R4 m R
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 31 kt fast at the 1,000 ft gate, closing to 19 at 500 ft and 10 at the threshold.

Fast from 4 nm to 1.8 nm (up to +72 kt), then inside the band to the threshold.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

120140160180200 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 125+72 kt+26 kt+7 kt+3 kt+0 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on UWSG 26

Over the threshold

Threshold height100.00
16ft
Threshold speed100.00
125kton target
Centreline offset100.00
2.07m L
Bank100.00
2.0°steepest
Flare100.00

Perfect landing flare

Touchdown

Past threshold100.00
310m
Centreline100.00
1.27m R
Speed100.00
119kttarget 124 or less
Touchdown rate100.00
-220fpm
Impact100.00
1.15G
BouncesOk
None
Bank100.00
0.4°as the wheels touched

Rollout

Rollout distance100.00
417m26 % used
Rollout alignment100.00
2.84m R

Taxi in

LightsOk
All set
Taxi speed100.00
21kt peak12 kt in turns

Side view — the last 1,524 m of the approach.

Crossed the threshold at 16 ft, 34 ft below the 50 ft target; began the flare at 13 ft. Touched down 310 m in, close to the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,524 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

16 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 13 ft · −464 fpm · 3.6° · 125 ktdescent slowed at 6 ft · −35 fpm · 4.9°−220 fpm · 4.5° nose up · 119 kt Ideal — 50 ft, down at 305 m This flight — 16 ft, down at 310 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 460 fpm at the flare to 220 fpm at touchdown. The nose came up 0.9° on the way down. Into the flare at 125 kt, on the 125 kt approach speed, and 119 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−220 fpm at touchdown4.5° at touchdown, +0.9° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,524 m of the 2,742 m runway, to the same scale as the side view.

Touched down on the centreline, and stayed within 2.9 m of it down the rollout. No crosswind: nothing to correct for. Touched down straight, wings level.

Wind 000° at 1 kt · 0 kt head · 0 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ FULL SCORE TO 503 M 310 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

The 310 m touchdown sits inside the full-score zone. The arrival was smooth.

Runway used 727 m of 2,742 m · 27 %
In the air over the runway, 310 mRollout, 417 m Left over, 2,015 m

The stop — touchdown to taxi speed.

From 118 kt at touchdown to taxi speed (30 kt) in 16 s, an average deceleration of 0.31 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 479 m30 kt · 581 mtouchdown604 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Flight narrative

The flight began with a taxiing period from the parking area to the runway, which took approximately 3 minutes and covered less than 1 nautical mile. The aircraft, a Boeing 737-700, then departed from runway 31 at LFBP Pau Pyrénées Airport. The takeoff distance was 1,163 meters, which accounted for 47% of the runway. The liftoff speed was 148 knots, and the local weather conditions at the time of departure were characterized by a temperature of 23°C, a wind speed of 2 knots at 109°, with a crosswind of 0 knots and a tailwind of 1 knot.

As the aircraft climbed to cruising altitude, it began its enroute climb from 1,587 feet above sea level to 39,070 feet above sea level, an increase of 37,483 feet in 41 minutes, covering a distance of 304 nautical miles. The climb started overhead Uzein in Nouvelle-Aquitaine, France. Following the climb, the aircraft entered a level cruise phase, which began overhead Chindrieux in Auvergne-Rhone-Alpes, France, and lasted for 221 minutes, covering a distance of 1,540 nautical miles.

The enroute descent phase started 16 miles east of Rtishchevo in Saratovskaya Oblast, Russia, where the aircraft descended from 38,865 feet above sea level to 2,568 feet above sea level, a decrease of 36,297 feet in 14 minutes, covering a distance of 92 nautical miles. The descent was followed by a brief level cruise phase, which started 6 miles west of Marks in Saratovskaya Oblast, Russia, and lasted for 3 minutes, covering a distance of 10 nautical miles.

The final approach to runway 26 at UWSG Gagarin International Airport was made from the east, heading 272.0° at 4 nautical miles and 1,211 feet above ground level. The landing was executed with good threshold height, threshold speed, touchdown distance, touchdown speed, and touchdown rate. The runway touchdown alignment was perfect, and the runway rollout alignment was also perfect. The local weather conditions at the time of landing were characterized by a temperature of 8°C, a wind speed of 1 knot at 0°, with a crosswind of 1 knot and a headwind of 0 knots.

The total flight distance was 1,952 nautical miles, and the flight duration was 256 minutes. The aircraft used 10,576 kilograms of fuel during the flight.

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
