TNCM
Saint Martin, Saint Martin
Runway 10
Elevation10 ft asl
Weight196,151 kg
Fuel53,590 kg
Wind65° · 9 kn · 3 kn cross

Flight Score

99.20 %
ESGG
Göteborg, Sweden
Runway 03
Elevation489 ft asl
Weight146,007 kg
Fuel3,279 kg
Wind50° · 12 kn · 5 kn cross
12 Jul 2025 8:42 4084 nm A330 50,310 kg
Departure Score
98.76 %
Enroute Score
100.00 %
Arrival Score
98.83 %

What went well

Touched down at -247 fpm — a soft arrival
Touchdown 203 m in — inside the full-score zone
Flare on profile — 100 %

What held you back

Departure Roll — Strobe Lights at 0 %, −0.36 points
Arrival Taxi — Landing Lights at 1 %, −0.33 points
Arrival Landing — scored 99.12 %, −0.06 points

Next time

Know your rotation speed

See Departure Roll

A typical trainer rotates in the mid-50s of knots - a 172 at around 55 KIAS, climbing out at a Vy in the low 70s, though check your own POH rather than memorising Cessna's numbers - and the transferable rule is that Vr sits just above the stall speed in takeoff configuration. Rotate early because "it felt ready" and the aircraft lifts off inside ground effect, where induced drag is reduced, then climbs out of it into more drag. On a marginal-performance day the result is an aircraft that lifts off and then refuses to climb, sagging back towards the runway.

Read more in Improve Your Take-Offs

Start to finish · 19 stages, 17 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 7 minutes and covered 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 10 kt0 kt min to max 14 kt 3 5 kt
100 % Average speed turning corners 6 ktmax 6 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle -0.6 °-0.8 ° min to max 0.1 ° 0.1 -0.6 °
Info Average bank angle 0.1 °0.0 ° min to max 0.3 ° 0.0 0.0 °

Events

Info Parking Brake On 12 ft agl · 3 kt
Info Landing Lights Switched On 12 ft agl · 3 kt
Info Engine 2 Started 12 ft agl · 2 kt
Info Parking Brake Off 12 ft agl · 1 kt
Info Flaps Position 1 12 ft agl · 5 kt
Departure Runway Entry Entering runway 10 at TNCM Princess Juliana International Airport, Average speed was 9 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 5 kt4 kt min to max 5 kt 5 4 kt
Info Average pitch angle -0.6 °-0.6 ° min to max -0.6 ° -0.6 -0.6 °
Info Average bank angle 0.1 °0.1 ° min to max 0.1 ° 0.1 0.1 °
Info Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Departure Roll 94.54Departure roll runway 10 at TNCM Princess Juliana International Airport. Takeoff distance 1,301 m 59 % of runway. Rotation speed was 137 kt. Local weather - Temperature 29 °C. Wind 11 kt at 65 °. Crosswind: 3 kt Headwind: 10 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 1,301 m59 % of runway
98 % Rotation speed was 137 ktTarget 151 kt
100 % Runway alignment max 3.43 m left3.43 m left to 0.00 m left 0.38 3.43 m
100 % Average g force 1.00 g0.95 g min to max 1.07 g 1.00 1.07 g
100 % Takeoff Bounce
Info Average pitch angle 0.0 °-0.7 ° min to max 6.4 ° -0.6 6.4 °
Info Average bank angle 0.2 °0.0 ° min to max 0.5 ° 0.1 0.5 °

Events

Fail Strobe Lights
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 10 TNCM Princess Juliana International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.2 °-0.2 ° min to max -0.2 ° -0.2 -0.2 °
100 % Average speed 154 kt151 kt min to max 157 kt 151 157 kt
100 % Steepest bank angle 0.5 °0.0 ° min to max 0.5 ° 0.5 0.0 °
100 % Average g force 1.10 g1.08 g min to max 1.12 g 1.08 1.09 g
Info Average VSI 447 fpm55 fpm min to max 913 fpm 55 913 fpm
Info Average altitude 16 ft agl0 ft agl min to max 43 ft agl 0 43 ft agl
Info Average pitch angle 7.9 °6.5 ° min to max 9.5 ° 6.5 9.5 °

Events

Info Strobe Lights Switched On 19 ft agl · 156 kt
Info Landing Gear Up 39 ft agl · 158 kt
Departure Climb 2 100.00Departure climb to 400 ft agl from 10 TNCM Princess Juliana International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.2 °-0.3 ° min to max -0.2 ° -0.2 -0.3 °
100 % Average speed 161 kt158 kt min to max 170 kt 158 170 kt
100 % Steepest bank angle 0.7 °0.0 ° min to max 0.7 ° 0.0 0.0 °
100 % Average g force 1.09 g0.98 g min to max 1.11 g 1.09 0.98 g
Info Average VSI 1,351 fpm932 fpm min to max 2,647 fpm 932 2,647 fpm
Info Average altitude 96 ft agl45 ft agl min to max 356 ft agl 45 356 ft agl
Info Average pitch angle 10.5 °9.6 ° min to max 12.5 ° 9.6 10.9 °

Events

Info Taxi Lights Switched Off 243 ft agl · 170 kt
Departure Climb 3 99.24Departure climb to 1,000 ft agl from 10 TNCM Princess Juliana International Airport.
ScoreDescriptionStartProfileEnd
98 % Climb speed 173 kt171 kt min to max 174 ktTarget 189 kt, 16 kt slow 173 174 kt
100 % Steepest bank angle 28.4 °0.3 ° min to max 28.4 ° 0.3 28.4 °
100 % Average g force 1.03 g0.87 g min to max 1.08 g 1.00 1.08 g
100 % Landing gear up at 22 ft aglTarget by 400 ft agl
Info Heading variation 0.1 °-0.2 ° min to max 1.0 ° -0.2 1.0 °
Info Average VSI 3,057 fpm2,725 fpm min to max 3,438 fpm 2,792 3,438 fpm
Info Average altitude 698 ft agl449 ft agl min to max 970 ft agl 449 970 ft agl
Info Average pitch angle 15.0 °12.0 ° min to max 16.4 ° 12.0 16.4 °
Enroute Climb 100.00Enroute climb started 1 mile south of Marigot (Arrondissement de Saint-Martin-Saint-Barthelemy, Saint Martin). Climbing from 1,056 ft asl to 38,216 ft asl, an increase of 37,160 ft in 25 minutes and covering 178 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 274 kt174 kt min to max 314 kt 174 266 kt
100 % Steepest bank angle 30.2 °0.0 ° min to max 30.2 ° 29.9 0.0 °
100 % Average g force 1.05 g0.88 g min to max 1.23 g 1.09 1.00 g
Info Average VSI 1,778 fpm17 fpm min to max 3,450 fpm 3,446 17 fpm
Info Average altitude 15,682 ft asl1,056 ft asl min to max 38,216 ft asl 1,056 38,216 ft asl
Info Average pitch angle 5.9 °3.1 ° min to max 16.6 ° 16.6 3.1 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Fully Retracted 1,281 ft agl · 206 kt
Info Landing Lights Switched Off 10,687 ft agl · 303 kt
Info Autopilot Altitude Hold Deactivated 38,171 ft agl · 473 kt
Info Autopilot Vertical Hold Activated 38,171 ft agl · 473 kt
Enroute Level 100.00Enroute level cruise started Latitude: 19.897038 Longitude: -61.1814427 and lasted 268 minutes, covering 1,927 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,411 ft of 38,249 ft asl37,920 ft asl min to max 38,424 ft asl 38,218 37,922 ft asl
100 % Average speed 265 kt259 kt min to max 269 kt 266 265 kt
100 % Steepest bank angle 15.5 °0.0 ° min to max 15.5 ° 0.0 0.0 °
100 % Average g force 1.00 g0.97 g min to max 1.04 g 1.00 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 2.9 °2.4 ° min to max 3.3 ° 3.1 2.7 °
Enroute Descent 100.00Enroute descent started Latitude: 43.2494638 Longitude: -35.2238208. Descent from 37,920 ft asl to 37,209 ft asl, a decrease of 710 ft in 31 minutes and covering 254 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 265 kt264 kt min to max 266 kt 265 265 kt
100 % Steepest bank angle 2.4 °0.0 ° min to max 2.4 ° 0.1 0.1 °
100 % Average g force 1.00 g0.95 g min to max 1.02 g 0.97 0.96 g
Info Average VSI -24 fpm-304 fpm min to max 35 fpm -66 -97 fpm
Info Average altitude 37,568 ft asl37,209 ft asl min to max 37,920 ft asl 37,920 37,209 ft asl
Info Average pitch angle 2.6 °2.2 ° min to max 2.7 ° 2.4 2.3 °
Info Turn coordination 00 min to max 0 0 0
Enroute Level 2 100.00Enroute level cruise started Latitude: 45.8386339 Longitude: -30.4759805 and lasted 197 minutes, covering 1,587 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,359 ft of 37,167 ft asl36,565 ft asl min to max 37,565 ft asl 37,182 37,488 ft asl
100 % Average speed 265 kt262 kt min to max 268 kt 265 265 kt
100 % Steepest bank angle 15.4 °0.0 ° min to max 15.4 ° 0.1 0.1 °
100 % Average g force 1.00 g0.96 g min to max 1.06 g 1.01 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 2.4 °2.1 ° min to max 2.8 ° 2.6 2.2 °

Events

Info Autopilot Altitude Hold Activated 37,513 ft agl · 471 kt
Enroute Descent 2 100.00Enroute descent started 1 mile north west of Thisted (North Denmark Region, Denmark). Descent from 37,459 ft asl to 3,006 ft asl, a decrease of 34,454 ft in 23 minutes and covering 121 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 253 kt220 kt min to max 286 kt 264 220 kt
100 % Steepest bank angle 18.4 °0.0 ° min to max 18.4 ° 0.1 0.3 °
100 % Average g force 1.01 g0.88 g min to max 1.13 g 0.96 1.01 g
Info Average VSI -1,258 fpm-2,905 fpm min to max 7 fpm -537 7 fpm
Info Average altitude 14,099 ft asl3,006 ft asl min to max 37,459 ft asl 37,459 3,006 ft asl
Info Average pitch angle -0.5 °-1.9 ° min to max 1.9 ° 1.4 1.8 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Landing Lights Switched On 10,559 ft agl · 312 kt
Info Flaps Position 1 9,265 ft agl · 269 kt
Info Landing Gear Down 2,998 ft agl · 233 kt
Enroute Level 3 100.00Enroute level cruise started 1 mile south east of Kungsbacka (Halland County, Sweden) and lasted 2 minutes, covering 4 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±651 ft of 3,019 ft asl3,006 ft asl min to max 3,025 ft asl 3,016 3,011 ft asl
100 % Average speed 147 kt124 kt min to max 206 kt 206 126 kt
100 % Steepest bank angle 0.8 °0.0 ° min to max 0.8 ° 0.5 0.1 °
100 % Average g force 1.00 g0.98 g min to max 1.08 g 1.00 0.99 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 4.2 °1.9 ° min to max 5.5 ° 1.9 4.9 °

Events

Info Taxi Lights Switched On 2,980 ft agl · 212 kt
Info Flaps Position 2 2,981 ft agl · 211 kt
Info Flaps Position 3 2,980 ft agl · 197 kt
Info Flaps Position 4 2,994 ft agl · 178 kt
Enroute Descent 3 100.00Enroute descent started 3 miles south east of Lindome (Vaestra Goetaland County, Sweden). Descent from 2,983 ft asl to 1,760 ft asl, a decrease of 1,223 ft in 2 minutes and covering 4 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 126 kt123 kt min to max 128 kt 127 127 kt
100 % Steepest bank angle 0.5 °0.0 ° min to max 0.5 ° 0.2 0.2 °
100 % Average g force 1.00 g0.93 g min to max 1.07 g 0.98 0.95 g
Info Average VSI -627 fpm-822 fpm min to max -364 fpm -364 -822 fpm
Info Average altitude 2,102 ft asl1,760 ft asl min to max 2,983 ft asl 2,983 1,760 ft asl
Info Average pitch angle 3.2 °0.9 ° min to max 4.4 ° 3.9 1.1 °
Info Turn coordination 00 min to max 0 0 0
Arrival Approach 100.00Final approach to runway 03 at ESGG Göteborg Landvetter Airport. Descent from 1,318 ft agl to 48 ft agl in 120 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates

Events

Fail GPWS Warning Activated 946 ft agl · 120 kt
Fail GPWS Warning Activated 526 ft agl · 124 kt
Fail GPWS Warning Activated 357 ft agl · 128 kt
Info Autopilot Vertical Hold Deactivated 958 ft agl · 119 kt
Info GPWS Warning Deactivated 912 ft agl · 126 kt
Info GPWS Warning Deactivated 461 ft agl · 124 kt
Info GPWS Warning Deactivated 212 ft agl · 132 kt
Arrival Landing 99.12Landing on runway 03 at ESGG Göteborg Landvetter Airport, runway length 3,288 m. Good threshold height. Threshold speed was slightly below target at 117 kt.
ScoreDescriptionStartProfileEnd
96 % Threshold speed was slightly below target at 117 kt. Target 124 kt
100 % Good threshold height.Target 50 ft agl
100 % Perfect landing flare
100 % Runway alignment max 6.04 m left6.04 m left to 5.48 m left 5.97 5.48 m
100 % Steepest bank angle 1.3 °0.5 ° min to max 1.3 ° 0.5 0.6 °
100 % Peak g force 1.08 g0.95 g min to max 1.08 g 0.95 1.01 g
Info Average speed 115 kt114 kt min to max 117 kt 117 114 kt
Info Average VSI -373 fpm-456 fpm min to max -249 fpm -417 -249 fpm
Info Average altitude 13 ft agl5 ft agl min to max 24 ft agl 24 5 ft agl
Info Average pitch angle 6.1 °4.3 ° min to max 7.5 ° 4.3 7.5 °
07515022501223354658Runway Distance mLanding Height ft075150225-25-20-15-10-50510152025Runway Distance mRunway Width m
Arrival Touchdown 100.00Touchdown distance was good at 203 m. Touchdown speed at 114 kt was good. Touchdown rate was fair at -247 fpm. Runway touchdown position was slightly misaligned by 5.5 m from centreline. Local weather - Temperature 20 °C. Wind 13 kt at 16 °. Crosswind: 2 kt Headwind: 12 kt.
ScoreDescriptionStartProfileEnd
100 % Touchdown rate was -247 fpm.
100 % Touchdown distance was 203 mTarget 457 m
100 % Speed at touchdown 114 ktTarget below 123 kt
100 % Runway alignment max 5.48 m left5.31 m left 5.48 5.10 m
100 % Steepest bank angle 0.6 °0.1 ° min to max 0.6 ° 0.6 0.1 °
100 % Peak g force 1.15 g1.01 g min to max 1.15 g 1.01 1.09 g
100 % Landing Bounce
Info Average speed 114 kt114 kt min to max 114 kt 114 114 kt
Info Average pitch angle 7.4 °6.9 ° min to max 7.6 ° 7.5 6.9 °
Arrival Rollout 100.00Total landing distance 1,167 m, 35 % of runway. Runway rollout alignment was perfect.
ScoreDescriptionStartProfileEnd
100 % Landing distance 1,167 m35 % of runway.
100 % Runway alignment max 2.32 m right1.69 m left to 2.32 m right 0.53 -0.83 m
100 % Average g force 1.02 g0.98 g min to max 1.07 g 1.07 1.00 g
Info Average speed 91 kt53 kt min to max 104 kt 104 53 kt
Info Average pitch angle 3.1 °-0.9 ° min to max 6.6 ° 6.6 -0.4 °
Info Average bank angle 0.2 °0.0 ° min to max 0.4 ° 0.1 0.0 °
Runway Exit Exiting runway, average speed 48 kt
ScoreDescriptionStartProfileEnd
Info Average speed 36 kt15 kt min to max 52 kt 52 17 kt
Info Average pitch angle -0.5 °-0.8 ° min to max -0.0 ° -0.4 -0.6 °
Info Average bank angle 0.1 °0.0 ° min to max 0.3 ° 0.1 0.1 °
Info Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g

Events

Info Flaps Fully Retracted 12 ft agl · 63 kt
Arrival Taxi 95.05Taxiing to the parking from the runway took 4 minutes and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 12 kt0 kt min to max 19 kt 17 0 kt
100 % Average speed turning corners 0 ktmax 0 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle -0.6 °-0.8 ° min to max -0.5 ° -0.6 -0.7 °
Info Average bank angle 0.1 °0.0 ° min to max 0.3 ° 0.1 0.1 °

Events

Fail Landing Lights
Info Parking Brake On 12 ft agl · 4 kt

Takeoff from TNCM 10

Taxi out

Lights75.00
Offstrobes
Taxi speed100.00
14kt peak6 kt in turns

The roll

Takeoff roll100.00
1,301m59 %
Runway alignment100.00
3.43m L
Rotation speed97.70
137kttarget 151, 14 early

Rotated early, and the nose came up slowly

Rotation started at 137 kt, 14 kt before the 151 kt rotate speed, and the nose then rose at 1.8° a second, slower than the 2 to 3° a second airliners use.

The nose started up before the rotate speed and then came up slowly, as if easing it off early. Wait for the rotate speed, then make one steady pull at the normal rate for this aircraft.

Liftoff and climb

Liftoff
150ktat 6.5°
Rotation
1.8°/sover 3.9 s, gaining 13 kt
35 ft
157ktat 9.1°, 3.4 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
0.5°steepest
Gear up100.00
22ftfull marks to 400 ft
Climb 3 speed98.10
173kttarget 189

Plan view the roll down the 2,190 m runway.

Rolled from the start of the runway, drifted left of the centreline, 3.4 m at the widest, and lifted off 3.4 m left. Airborne 59 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

5001,0001,5002,000THRESHOLDLEFT ↑RIGHT ↓CROSS2 kn75 %widest 3.37 m LAirborne 1,305 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,305 m of 2,190 m · 60 %
Takeoff roll, 1,305 m Left ahead, 885 m

Side view from the start of the roll to the end of Climb 3 at 970 ft.

Reached 35 ft with 618 m of runway left; gear up at 22 ft, inside the 400 ft that gets full marks; then climbing at 2,340 fpm on average to 970 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3173 kt avgtarget 189THRESHOLDRUNWAY END6080100120KNOTS ALONG THE ROLLnose up on the runway · 279 m · 3.9 sRotate 137 kttarget 151Liftoff 150 ktGear up 22 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 189180 kt12060020°10°0°nose up on the runway · 279 m · 3.9 sROTATELIFTOFFtarget 151held 11.3°6.5° off · 1.8°/s9° at 35 ftAIRSPEEDPITCH0306090120 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2 to 3° a second, the rates airliners are rotated at: a trace steeper than both is a faster rotation, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate.

20°10°0°ROTATELIFTOFF35 FT2°/s3°/s6.5° off · 1.8°/s9° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5+6+7+8 sseconds from rotation
PitchRotation began2 to 3°/s from rotationNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate570 fpm580 fpm
On glideslope2.9°2.9°
On centreline0.0° off0.1° off
On speed+5.3 kt+7.6 kt
Wings level0° bank0° bank

When the approach was stable

Every check met from 4 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to ESGG 03

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 70 ft below the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,2956553351491,000 ft gate7 of 71,009 ft · 129 kt500 ft gate7 of 7516 ft · 132 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 52× larger than distances along the final.

Inside the 1° band all the way from 4 nm, never more than 6 m off the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR18 m L018 m RLEFT ↑RIGHT ↓1° BAND0 m R2 m R2 m R2 m R1 m R2 m R
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 31 kt fast at the 1,000 ft gate, closing to 19 at 500 ft and 10 at the threshold.

Inside the speed band all the way, between −8 kt and +12 kt on the approach speed of 124 kt.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

120140160180 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 124+3 kt−2 kt−3 kt+2 kt−7 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on ESGG 03

Over the threshold

Threshold height100.00
24ft
Threshold speed96.49
117kttarget 124, 7 slow
Centreline offset100.00
6.04m L
Bank100.00
1.3°steepest
Flare100.00

Perfect landing flare

Touchdown

Past threshold100.00
203m
Centreline100.00
5.48m L
Speed100.00
114kttarget 123 or less
Touchdown rate100.00
-247fpm
Impact100.00
1.15G
BouncesOk
None
Bank100.00
0.6°as the wheels touched

Rollout

Rollout distance100.00
931m35 % used
Rollout alignment100.00
2.32m R

Taxi in

Lights50.50
Onlanding lights, 99% of the taxi
Taxi speed100.00
19kt peak

Side view — the last 1,524 m of the approach.

Crossed the threshold at 24 ft, 26 ft below the 50 ft target; began the flare at 19 ft. Touched down 203 m in, 102 m short of the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,524 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

24 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 19 ft · −519 fpm · 5.4° · 116 ktdescent slowed at 0 ft · −176 fpm · 7.5°−247 fpm · 7.5° nose up · 114 kt Ideal — 50 ft, down at 305 m This flight — 24 ft, down at 203 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 520 fpm at the flare to 250 fpm at touchdown. The nose came up 2.1° on the way down. Into the flare at 116 kt, 8 kt under the 124 kt approach speed, and 114 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−247 fpm at touchdown7.5° at touchdown, +2.1° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,524 m of the 3,288 m runway, to the same scale as the side view.

Touched down 5.1 m left of the centreline, and steered back to 1.5 m right by the end of the rollout. 4 kt across from the right, which takes about 2° of crab to hold the centreline at 114 kt. Touched down with 2° of it still on, wings level.

Wind 050° at 12 kt · 11 kt head · 4 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ CROSS 4 kn FULL SCORE TO 503 M 203 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

The 203 m touchdown sits inside the full-score zone. The arrival was smooth.

Runway used 1,133 m of 3,288 m · 34 %
In the air over the runway, 203 mRollout, 931 m Left over, 2,154 m

The stop — touchdown to taxi speed.

From 105 kt at touchdown to taxi speed (30 kt) in 57 s, an average deceleration of 0.07 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 822 m30 kt · 1,694 mtouchdown1,762 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Flight narrative

The flight began with a taxiing period from the parking to the runway, which took 6 minutes and covered less than 1 nautical mile. The aircraft then departed from runway 10 at Princess Juliana International Airport (TNCM) and took off with a takeoff distance of 1,359 meters, which was 59% of the runway length. The liftoff speed was 151 knots.

The local weather conditions at the time of departure were characterized by a temperature of 29°C, with a wind speed of 11 knots at a direction of 65°. This resulted in a crosswind of 3 knots and a headwind of 10 knots. The aircraft then began its enroute climb, starting 1 mile south of Marigot, and climbed from an altitude of 1,056 feet above sea level to 38,216 feet above sea level, an increase of 37,160 feet, in 25 minutes and covering 154 nautical miles.

The enroute level cruise phase began at a latitude of 19.897038 and a longitude of -61.1814427, and lasted for 496 minutes, covering a distance of 3,751 nautical miles. The aircraft then started its enroute descent, beginning 1 mile northwest of Thisted, Denmark, and descended from 37,459 feet above sea level to 3,006 feet above sea level, a decrease of 34,454 feet, in 23 minutes and covering 115 nautical miles.

The aircraft then entered another level cruise phase, starting 1 mile southeast of Kungsbacka, Sweden, and lasted for 2 minutes, covering 4 nautical miles. The final descent phase began 3 miles southeast of Lindome, Sweden, and the aircraft descended from 2,983 feet above sea level to 1,760 feet above sea level, a decrease of 1,223 feet, in 2 minutes and covering 4 nautical miles.

The final approach to runway 03 at Göteborg Landvetter Airport (ESGG) was made from the southwest, heading 26.0° at a distance of 4 nautical miles and an altitude of 1,256 feet above ground level. The landing was made on runway 03, which had a length of 3,287 meters. The threshold height was good, and the threshold speed was slightly below the target at 117 knots.

The touchdown distance was good at 204 meters, and the touchdown speed was 114 knots, which was also good. However, the touchdown rate was fair at -249 feet per minute. The runway touchdown alignment was very good, and the local weather conditions at the time of landing were characterized by a temperature of 20°C, with a wind speed of 13 knots at a direction of 16°. This resulted in a crosswind of 2 knots and a headwind of 12 knots.

The total landing distance was 1,167 meters, which was 36% of the runway length. The runway rollout alignment was also very good. The taxiing period from the runway to the parking took 4 minutes and covered less than 1 nautical mile. The total flight distance was 4,035 nautical miles, and the flight duration was 522 minutes. The aircraft used a total of 50,310 kilograms of fuel during the flight.

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
