VIJP
Jaipur, India
Runway 27
Elevation1,253 ft asl
Weight32,043 kg
Fuel32,095 kg
WindCalm

Flight Score

92.05 %
VIAG
Agra, India
Runway 30
Elevation551 ft asl
Weight31,053 kg
Fuel31,021 kg
WindCalm
21 May 2023 0:44 170 nm Embraer E170 1,074 kg
Departure Score
92.23 %
Enroute Score
100.00 %
Arrival Score
83.92 %

What went well

Touchdown 502 m in — inside the full-score zone
Threshold crossed at 27 ft and 134 kt — both inside band
Straight touchdown — 2.08 m off the centreline, no bounce

What held you back

Departure Climb 3 — gear not retracted; Landing gear up at 0 ft agl at 0 %, bank angle up to 27.1 ° at 90 %, −2.14 points
Arrival Approach — 500 ft gate 71 %, −1.90 points
Firm touchdown — 460 fpm, −1.49 points across the landing and the touchdown
  • Arrival Landing · flare: the descent was not taken out−0.73
  • Arrival Touchdown · sink rate 460 fpm−0.62
  • Arrival Touchdown · 2.03 G at contact−0.14

Next time

Departure

Raise the gear lever promptly once a positive rate of climb is confirmed after liftoff.

What happened: The landing gear was never raised during the initial climb and was still down when the climb ended.

Watch for: Landing gear lever: UP promptly after confirming a positive rate of climb.

See Departure Climb 3

Arrival

Begin the flare with progressive back pressure and keep it coming until the sink is arrested, rather than flying it on flat.

What happened: The nose was barely raised in the flare and little of the sink was taken out, flying the aircraft onto the runway. This pattern usually carries through to a firm touchdown with a noticeable sink rate.

Watch for: Vertical speed indicator: a smoothly reducing sink through the normal flare band, not a steady rate into the runway.

See Arrival LandingArrival Touchdown

Preparing for a stable approach will give you time to decide on whether to attempt the landing or going around. Too much altitude with a high sink rate will result in carrying too much speed onto the runway. Configuring flaps and the gear late also won't help the speed decay.

Read more in The Stabilised Approach

Start to finish · 16 stages, 14 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 9 minutes and covered 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 8 kt1 kt min to max 14 kt 1 4 kt
100 % Average speed turning corners 4 ktmax 4 kt 0 4 kt
100 % Average g force 1.00 g0.95 g min to max 1.04 g 1.00 1.00 g
Info Average pitch angle 0.5 °0.1 ° min to max 1.2 ° 0.1 0.6 °
Info Average bank angle 0.3 °0.0 ° min to max 1.1 ° 0.0 0.5 °

Events

Info Autopilot Master On 1 ft agl · 3 kt
Info Strobe Lights On 1 ft agl · 8 kt
Departure Runway Entry Entering runway 27 at VIJP Jaipur International Airport, Average speed was 12 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 4 kt4 kt min to max 4 kt 4 4 kt
Info Average pitch angle 0.8 °0.7 ° min to max 0.8 ° 0.7 0.8 °
Info Average bank angle 0.2 °0.1 ° min to max 0.4 ° 0.4 0.1 °
Info Average g force 1.00 g1.00 g min to max 1.01 g 1.00 1.00 g
Departure Roll 93.19Departure roll runway 27 at VIJP Jaipur International Airport. Takeoff distance 1,695 m 50 % of runway. Rotation speed was 132 kt. Local weather - Temperature 41 °C. .
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 1,695 m50 % of runway
91 % Rotation speed was 132 ktTarget 114 kt
100 % Runway alignment max 6.02 m right0.00 m left to 6.02 m right -5.68 -3.26 m
99.98 % Average g force 1.00 g0.77 g min to max 1.14 g 1.00 0.98 g
100 % Takeoff Bounce
Info Average pitch angle 1.3 °0.1 ° min to max 7.7 ° 0.8 7.7 °
Info Average bank angle 0.4 °0.0 ° min to max 1.0 ° 0.1 1.0 °

Events

Fail Landing Lights
Info Autopilot Autothrottle Active Off 1 ft agl · 110 kt
Info Autopilot Heading Hold Off 1 ft agl · 110 kt
Info Autopilot Vertical Hold Off 1 ft agl · 110 kt
Info Autopilot Altitude Hold Off 1 ft agl · 110 kt
Info Autopilot Airspeed Hold Off 1 ft agl · 110 kt
Info Autopilot Nav1 Lock Off 1 ft agl · 110 kt
Info Autopilot Pitch Hold On 1 ft agl · 110 kt
Info Autopilot Go Around Mode Off 1 ft agl · 110 kt
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 27 VIJP Jaipur International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.1 °-0.2 ° min to max 0.1 ° 0.1 -0.1 °
100 % Average speed 144 kt139 kt min to max 148 kt 139 148 kt
100 % Steepest bank angle 3.7 °0.0 ° min to max 3.7 ° 1.1 1.2 °
100 % Average g force 1.03 g0.93 g min to max 1.10 g 0.96 0.94 g
Info Average VSI 557 fpm286 fpm min to max 783 fpm 286 783 fpm
Info Average altitude 7 ft agl0 ft agl min to max 32 ft agl 0 32 ft agl
Info Average pitch angle 9.2 °7.6 ° min to max 11.2 ° 7.6 9.7 °
Departure Climb 2 100.00Departure climb to 400 ft agl from 27 VIJP Jaipur International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.1 °-0.1 ° min to max 0.1 ° -0.1 0.1 °
100 % Average speed 150 kt148 kt min to max 161 kt 148 161 kt
100 % Steepest bank angle 2.6 °0.0 ° min to max 2.6 ° 1.1 0.3 °
100 % Average g force 0.98 g0.92 g min to max 1.06 g 0.93 0.99 g
Info Average VSI 887 fpm788 fpm min to max 1,306 fpm 788 1,306 fpm
Info Average altitude 90 ft agl33 ft agl min to max 342 ft agl 33 342 ft agl
Info Average pitch angle 10.4 °9.7 ° min to max 11.4 ° 9.7 10.2 °

Events

Info Landing Gear Down 137 ft agl · 161 kt
Info Autopilot Master 161 ft agl · 162 kt
Info Autopilot Autothrottle Active On 206 ft agl · 164 kt
Departure Climb 3 67.95Departure climb to 1,000 ft agl from 27 VIJP Jaipur International Airport.
ScoreDescriptionStartProfileEnd
100 % Climb speed 163 kt162 kt min to max 164 ktTarget 174 kt, 11 kt slow 162 164 kt
90 % Steepest bank angle 27.0 °1.8 ° min to max 27.0 ° 1.8 27.0 °
100 % Average g force 1.02 g0.96 g min to max 1.09 g 1.00 1.09 g
0 % Landing gear up at 0 ft aglTarget by 400 ft agl
Info Heading variation 0.3 °0.1 ° min to max 0.9 ° 0.1 0.9 °
Info Average VSI 1,293 fpm1,186 fpm min to max 1,358 fpm 1,313 1,186 fpm
Info Average altitude 446 ft agl362 ft agl min to max 526 ft agl 362 526 ft agl
Info Average pitch angle 10.0 °9.8 ° min to max 10.1 ° 10.1 9.8 °

Events

Fail Gear Not Retracted
Enroute Climb 100.00Enroute climb started 1 mile west of VIJP Jaipur International Airport Jaipur (State of Rajasthan, India). Climbing from 1,799 ft asl to 22,702 ft asl, an increase of 20,903 ft in 14 minutes and covering 71 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 232 kt164 kt min to max 253 kt 164 250 kt
100 % Steepest bank angle 31.0 °0.0 ° min to max 31.0 ° 27.0 6.6 °
100 % Average g force 1.04 g0.83 g min to max 1.23 g 1.06 1.00 g
Info Average VSI 1,403 fpm-906 fpm min to max 3,112 fpm 1,179 3 fpm
Info Average altitude 8,133 ft asl1,799 ft asl min to max 22,804 ft asl 1,799 22,702 ft asl
Info Average pitch angle 6.6 °1.0 ° min to max 10.4 ° 9.8 3.0 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Landing Lights On 810 ft agl · 181 kt
Info Autopilot Autothrottle Active Off 1,227 ft agl · 184 kt
Info Autopilot Airspeed Hold On 1,227 ft agl · 184 kt
Info Autopilot Pitch Hold Off 1,227 ft agl · 184 kt
Info Flaps Position 1 1,345 ft agl · 205 kt
Info Flaps Fully Retracted 1,343 ft agl · 220 kt
Info Landing Lights Off 9,153 ft agl · 298 kt
Info Taxi Lights Off 15,901 ft agl · 325 kt
Info Autopilot Autothrottle Active On 22,585 ft agl · 358 kt
Info Autopilot Altitude Hold On 22,585 ft agl · 358 kt
Info Autopilot Airspeed Hold Off 22,585 ft agl · 358 kt
Enroute Descent 99.99Enroute descent started 6 miles east of Bandikui (State of Rajasthan, India). Descent from 22,702 ft asl to 2,836 ft asl, a decrease of 19,866 ft in 14 minutes and covering 75 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 242 kt210 kt min to max 258 kt 250 210 kt
100 % Steepest bank angle 30.3 °0.0 ° min to max 30.3 ° 11.7 0.3 °
99.9 % Average g force 1.04 g0.67 g min to max 1.24 g 1.00 0.99 g
Info Average VSI -1,392 fpm-7,778 fpm min to max 1,889 fpm 0 -643 fpm
Info Average altitude 12,353 ft asl2,836 ft asl min to max 23,165 ft asl 22,702 2,836 ft asl
Info Average pitch angle 0.9 °-8.6 ° min to max 7.2 ° 3.0 3.4 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Autothrottle Active Off 22,558 ft agl · 358 kt
Info Autopilot Altitude Hold Off 22,558 ft agl · 358 kt
Info Autopilot Pitch Hold On 22,558 ft agl · 358 kt
Info Autopilot Autothrottle Active On 22,582 ft agl · 352 kt
Info Autopilot Pitch Hold Off 22,582 ft agl · 352 kt
Info Autopilot Autothrottle Active Off 22,986 ft agl · 323 kt
Info Autopilot Airspeed Hold On 22,986 ft agl · 323 kt
Info Autopilot Autothrottle Active On 19,694 ft agl · 339 kt
Info Autopilot Airspeed Hold Off 19,694 ft agl · 339 kt
Info Autopilot Vertical Hold On 16,977 ft agl · 328 kt
Info Landing Lights On 9,916 ft agl · 298 kt
Info Taxi Lights 9,763 ft agl · 298 kt
Info Autopilot Master On 2,370 ft agl · 247 kt
Info Autopilot Vertical Hold Off 2,370 ft agl · 247 kt
Info Autopilot Nav1 Lock Off 2,370 ft agl · 247 kt
Info Autopilot Pitch Hold On 2,370 ft agl · 247 kt
Enroute Level 100.00Enroute level cruise started 5 miles north west of Shamsabad (Uttar Pradesh, India) and lasted 3 minutes, covering 10 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±636 ft of 2,188 ft asl1,732 ft asl min to max 2,712 ft asl 2,712 1,882 ft asl
100 % Average speed 178 kt138 kt min to max 211 kt 206 142 kt
100 % Steepest bank angle 28.5 °0.0 ° min to max 28.5 ° 0.5 6.2 °
100 % Average g force 1.04 g0.88 g min to max 1.20 g 0.91 1.02 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 5.1 °2.3 ° min to max 10.9 ° 5.0 3.6 °

Events

Info Autopilot Altitude Hold On 1,952 ft agl · 226 kt
Info Autopilot Pitch Hold Off 1,952 ft agl · 226 kt
Info Autopilot Master Off 1,895 ft agl · 227 kt
Info Autopilot Altitude Hold Off 1,895 ft agl · 227 kt
Info Autopilot Pitch Hold On 1,895 ft agl · 227 kt
Info Flaps Position 1 1,637 ft agl · 207 kt
Info Landing Gear Down 1,398 ft agl · 184 kt
Info Flaps Position 2 1,185 ft agl · 176 kt
Info Flaps Position 3 983 ft agl · 165 kt
Enroute Descent 2 100.00Enroute descent started 4 miles south east of Agra (Uttar Pradesh, India). Descent from 1,880 ft asl to 1,014 ft asl, a decrease of 866 ft in 3 minutes and covering 5 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 137 kt127 kt min to max 142 kt 142 136 kt
100 % Steepest bank angle 15.6 °0.2 ° min to max 15.6 ° 6.2 7.0 °
100 % Average g force 1.00 g0.82 g min to max 1.16 g 1.00 1.09 g
Info Average VSI -423 fpm-1,731 fpm min to max 975 fpm -127 -470 fpm
Info Average altitude 1,581 ft asl1,014 ft asl min to max 1,880 ft asl 1,880 1,014 ft asl
Info Average pitch angle 4.2 °-2.1 ° min to max 10.0 ° 4.1 5.6 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Position 4 859 ft agl · 148 kt
Info Flaps Position 5 536 ft agl · 151 kt
Arrival Approach 71.43Final approach to runway 30 at VIAG Agra Airport / Agra Air Force Station. Descent from 954 ft agl to 333 ft agl in 109 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed
100 % Landing flappassed
100 % Sink ratepassed
0 % On glideslopefailed
0 % On centrelinefailed
100 % On speedpassed
100 % Wings levelpassed

Events

Info Flaps Position 5 536 ft agl · 151 kt
Info Autopilot Autothrottle Active Off 36 ft agl · 144 kt
Arrival Landing 87.83Landing on runway 30 at VIAG Agra Airport / Agra Air Force Station, runway length 1,812 m. Good threshold height. Threshold speed was slightly above target at 134 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was slightly above target at 134 kt. Target 126 kt
100 % Good threshold height.Target 50 ft agl
56 % The flare strayed well off the target profile. The aircraft was flown onto the runway - pitch changed 0.3° and the descent was barely arrested. Touchdown was 502 m past the threshold. Start the flare with progressive back pressure rather than one pull, and keep it coming.
99 % Runway alignment max 9.12 m left9.12 m left to 2.07 m left 9.12 2.12 m
89 % Steepest bank angle 6.1 °0.0 ° min to max 6.1 ° 4.1 0.5 °
100 % Peak g force 1.12 g0.88 g min to max 1.12 g 1.11 0.90 g
Info Average speed 135 kt134 kt min to max 136 kt 134 135 kt
Info Average VSI -270 fpm-594 fpm min to max -160 fpm -594 -337 fpm
Info Average altitude 10 ft agl-3 ft agl min to max 28 ft agl 28 -3 ft agl
Info Average pitch angle 4.7 °2.7 ° min to max 6.0 ° 5.8 3.3 °

Events

Info Autopilot Autothrottle Active On 4 ft agl · 145 kt
07515022530037545052560001223354658Runway Distance mLanding Height ft075150225300375450525600-24-20-16-12-8-404812162024Runway Distance mRunway Width m
Arrival Touchdown 87.52Touchdown point was 86 m beyond the touchdown zone. Touchdown speed at 135 kt was fast. Touchdown rate was hard at -460 fpm. Runway touchdown alignment was very good. Local weather - Temperature 44 °C. .
ScoreDescriptionStartProfileEnd
53 % Touchdown rate was -460 fpm.
100 % Touchdown distance was 502 mTarget 457 m
95 % Speed at touchdown 135 ktTarget below 123 kt
100 % Runway alignment max 2.17 m left2.05 m left 2.12 2.08 m
100 % Steepest bank angle 0.7 °0.1 ° min to max 0.7 ° 0.5 0.6 °
58 % Peak g force 2.03 g0.68 g min to max 2.03 g 0.90 0.68 g
100 % Landing Bounce
Info Average speed 135 kt134 kt min to max 135 kt 135 134 kt
Info Average pitch angle 2.6 °1.3 ° min to max 3.4 ° 3.3 1.3 °
Arrival Rollout 77.79Total landing distance 1,463 m, 81 % of runway. Runway rollout alignment was slightly misaligned by 12.7 m from centreline.
ScoreDescriptionStartProfileEnd
77 % Landing distance 1,463 m81 % of runway.
75 % Runway alignment max 12.66 m left12.66 m left to 0.00 m left 5.52 11.52 m
99.7 % Average g force 1.02 g0.81 g min to max 1.34 g 1.12 1.01 g
Info Average speed 61 kt34 kt min to max 66 kt 66 34 kt
Info Average pitch angle 0.3 °-0.4 ° min to max 0.9 ° 0.9 0.5 °
Info Average bank angle 0.6 °0.0 ° min to max 1.5 ° 0.9 0.2 °

Events

Info Autopilot Autothrottle Active Off 2 ft agl · 142 kt
Info Parking Brake On 1 ft agl · 140 kt
Info Parking Brake Off 1 ft agl · 138 kt
Info Autopilot Autothrottle Active On 1 ft agl · 110 kt
Info Autopilot Master 1 ft agl · 99 kt
Info Autopilot Autothrottle Active Off 1 ft agl · 92 kt
Info Autopilot Master On 1 ft agl · 89 kt
Runway Exit Exiting runway, average speed 27 kt
ScoreDescriptionStartProfileEnd
Info Average speed 12 kt6 kt min to max 30 kt 30 6 kt
Info Average pitch angle 0.6 °-0.0 ° min to max 0.9 ° 0.5 0.6 °
Info Average bank angle 0.2 °0.0 ° min to max 0.7 ° 0.2 0.3 °
Info Average g force 1.00 g0.95 g min to max 1.05 g 1.02 1.00 g

Events

Info Flaps Position 4 1 ft agl · 24 kt
Info Flaps Position 1 1 ft agl · 22 kt
Info Flaps Fully Retracted 1 ft agl · 18 kt
Arrival Taxi 95.05Taxiing to the parking from the runway took 2 minutes and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 7 kt3 kt min to max 9 kt 6 3 kt
100 % Average speed turning corners 0 ktmax 0 kt 0 0 kt
100 % Average g force 1.00 g0.98 g min to max 1.02 g 1.00 0.99 g
Info Average pitch angle 0.6 °0.2 ° min to max 1.2 ° 0.6 0.6 °
Info Average bank angle 0.3 °0.0 ° min to max 1.0 ° 0.2 0.1 °

Events

Fail Landing Lights
Info Autopilot Master Off 1 ft agl · 4 kt

Takeoff from VIJP 27

Taxi out

Lights75.00
Offlanding
Taxi speed100.00
14kt peak4 kt in turns

The roll

Takeoff roll100.00
1,695m50 %
Runway alignment100.00
6.02m R
Rotation speed90.95
132kttarget 114, 18 late

Rotated late

Rotation started at 132 kt, 18 kt after the 114 kt rotate speed.

The pull started after the rotate speed had gone by. Bring the airspeed into the scan as it approaches the rotate speed, so the pull starts on the number rather than when you notice it has passed.

Liftoff and climb

Liftoff
138ktat 7.6°
Rotation
2.3°/sover 2.9 s, gaining 6 kt
35 ft
148ktat 10.0°, 8.9 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
3.7°steepest
Climb 3 speed100.00
163kttarget 174

Plan view the roll down the 3,403 m runway.

Rolled from 106 m in, drifted right of the centreline, 5.9 m at the widest, and lifted off 3 m right. Airborne 50 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length.

1,0002,0003,000THRESHOLDLEFT ↑RIGHT ↓75 %widest 5.89 m RROLL 106 M INAirborne 1,703 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,703 m of 3,403 m · 50 %
Behind the start of the roll, 106 mTakeoff roll, 1,597 m Left ahead, 1,700 m

Side view from the start of the roll to the end of Climb 3 at 526 ft.

Reached 35 ft with 1,002 m of runway left; then climbing at 820 fpm on average to 526 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The shaded stretch is Climb 3, scored on its average speed against the target.

750 ft375 ft0CLIMB 3163 kt avgtarget 174THRESHOLDRUNWAY END6080100120KNOTS ALONG THE ROLLnose up on the runway · 216 m · 2.9 sRotate 132 kttarget 114Liftoff 138 kt
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 174180 kt12060020°10°0°nose up on the runway · 216 m · 2.9 sROTATELIFTOFFtarget 114held 10.4°7.6° off · 2.3°/s10° at 35 ftAIRSPEEDPITCH0306090 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2 to 3° a second, the rates airliners are rotated at: a trace steeper than both is a faster rotation, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 14.5°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 14.5°ROTATELIFTOFF35 FT3°/s7.6° off · 2.3°/s2°/s10° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5+6+7+8+9+10+11+12 sseconds from rotation
PitchRotation began2 to 3°/s from rotationTail strikeNose up, wheels on the runway

The stabilisation gates

One stabilised approach gate: seven checks where the approach path is 500 ft above the runway. The 1,000 ft gate was not assessed, because the approach did not join final that far out. These checks are the approach's score.

Seven checks, one gate500 ft 71.435 of 7
Gear down
Landing flap
Sink rate730 fpm
On glideslope4.2°
On centreline10.9° off
On speed+16 kt
Wings level4° bank

At the 500 ft gate: glideslope more than 1° off the runway's 3° and centreline more than 1° off.

When the approach was stable

Never every check met at once: high until 1.3 nm, sinking too fast until 0.6 nm, banked until 0.6 nm, right of the centreline from 0.8 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to VIAG 30

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Low from 4 nm to 2.7 nm (up to 690 ft under), then back on it to 1.7 nm, then high to 1.3 nm (up to 230 ft over), then back on it to the threshold.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND650514753442166500 ft gate5 of 7on glideslopeon centreline787 ft · 141 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 3× larger than distances along the final.

Joined 1,001 m left of the centreline, then 80 m right of it from 0.8 nm to the threshold.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR305 m L0305 m RLEFT ↑RIGHT ↓1° BAND376 m L961 m L849 m L75 m L74 m R579 m L
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 32 kt fast at the 1,000 ft gate, closing to 19 at 500 ft and 10 at the threshold.

Inside the speed band all the way, between +1 kt and +16 kt on the approach speed of 126 kt.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

120140160180 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 126+12 kt+8 kt+12 kt+13 kt+9 kt+8 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on VIAG 30

Over the threshold

Threshold height100.00
27ft
Threshold speed100.00
134kttarget 126, 8 fast
Centreline offset98.78
9.12m L
Bank89.29
6.1°steepest
Flare56.08

The flare strayed well off the target profile

The aircraft was flown onto the runway - pitch changed 0.3° and the descent was barely arrested. Touchdown was 502 m past the threshold. Start the flare with progressive back pressure rather than one pull, and keep it coming.

Touchdown

Past threshold100.00
502m
Centreline100.00
2.17m L
Speed94.86
135kttarget 122, 13 fast
Touchdown rate53.32
-460fpm
Impact57.74
2.03G
BouncesOk
None
Bank100.00
0.7°as the wheels touched

Rollout

Rollout distance86.07
919m78 % used
Rollout alignment75.14
12.66m L

Taxi in

Lights50.50
Onlanding lights, 99% of the taxi
Taxi speed100.00
9kt peak

Side view — the last 1,543 m of the approach.

Crossed the threshold at 27 ft, 23 ft below the 50 ft target; began the flare at 16 ft. Touched down 502 m in, 197 m past the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,543 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

27 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 16 ft · −161 fpm · 4.9° · 135 ktdescent slowed at 14 ft · −125 fpm · 5.2°−460 fpm · 3.3° nose up · 135 kt Ideal — 50 ft, down at 305 m This flight — 27 ft, down at 502 m

Sink and pitch — through the flare, lined up with the side view.

The sink grew from 160 fpm at the flare to 460 fpm at touchdown. The nose went down 1.6° on the way down. Into the flare at 135 kt, 9 kt over the 126 kt approach speed, and 135 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−460 fpm at touchdown3.3° at touchdown, −1.6° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,543 m of the 1,812 m runway, to the same scale as the side view.

Touched down 2.1 m left of the centreline and drifted to 12 m left on the rollout. Calm: nothing to correct for. Touched down with the nose 2° left of the track, wings level.

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ FULL SCORE TO 503 M 502 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

The 502 m touchdown sits inside the full-score zone. The 2.03 G arrival is the firm side of smooth.

Runway used 1,422 m of 1,812 m · 78 %
In the air over the runway, 502 mRollout, 919 m Left over, 390 m

The stop — touchdown to taxi speed.

From 67 kt at touchdown to taxi speed (30 kt) in 19 s, an average deceleration of 0.10 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

02040608060 kt · 358 m30 kt · 996 mtouchdown1,036 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
