Flight Score
Departure
Reduce climb power to bring speed back to 78 kt and hold it there.
What happened: Climb speed was 20 kt fast at 98 kt during the climb.
Watch for: Airspeed indicator: 78 kt in the climb
Arrival
Make one smooth, continuous back-pressure through the flare to about 6° nose-up, holding it steady rather than pumping the elevator before touchdown.
What happened: The flare was pumped, with pitch reversing several times as the sink was most arrested at 8.2 ft; pumped flares like this usually carry through to a firm touchdown, which happened here at 287 fpm.
Watch for: Attitude indicator: hold a steady nose-up pitch of 6° through the flare, smoothly to touchdown.
Speed at this height is usually bought with gradient. It's rarely dangerous and it's often just an early acceleration, but with flaps still out you may be heading towards the flap limit and a flat fast climb puts you at the acceleration altitude with the cleaning-up still to do.
Read more in Improve Your Take-OffsStart to finish · 13 stages, 11 in the score
Events
Events
Events
Events
Events
Taxi out
The roll
Rotated late
Rotation started at 73 kt, 13 kt after the 60 kt rotate speed.
The pull started after the rotate speed had gone by. Bring the airspeed into the scan as it approaches the rotate speed, so the pull starts on the number rather than when you notice it has passed.
Liftoff and climb
Plan view the roll down the 1,277 m runway.
Rolled from 77 m in, drifted right of the centreline, 6.7 m at the widest, and lifted off 6.8 m right. Airborne 33 % of the way down the runway, before the 75 % line.
The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length.
Side view from the start of the roll to the end of Climb 3 at 544 ft.
Reached 35 ft with 657 m of runway left; then climbing at 760 fpm on average to 544 ft.
The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The shaded stretch is Climb 3, scored on its average speed against the target.
Speed and pitch from brake release to the end of the climb, against time.
Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The figure at liftoff is the pitch then. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.
The final from 4 nm.
Profile height against the 3° glideslope, with its 2° band in green.
Inside the glideslope band from 0.9 nm, where the final began, to the threshold, never more than 210 ft above the slope.
Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber.
Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 5× larger than distances along the final.
Inside the 1° band all the way from 0.9 nm, never more than 81 m off the centreline.
Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.
Speed against the approach speed. The green band runs from 5 kt slow to 31 kt fast at the 1,000 ft gate, closing to 18 at 500 ft and 10 at the threshold.
Slow from 0.9 nm, where the final began, to 0.6 nm (up to −6 kt), then inside the band to the threshold.
Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.
Over the threshold
The flare mostly held the target profile
The flare was pumped rather than held: pitch changed direction 2 times on the way down. Touchdown was 133 m past the threshold. One smooth continuous input - chasing the runway with the elevator makes the next correction bigger, not smaller.
Touchdown
Rollout
Taxi in
Side view — the last 1,277 m of the approach.
Crossed the threshold at 23 ft, 27 ft below the 50 ft target; began the flare at 19 ft. Touched down 133 m in, 172 m short of the ideal 305 m.
The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,277 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.
Sink and pitch — through the flare, lined up with the side view.
The sink went from 450 fpm at the flare to 140 fpm at 8 ft, then back up to 290 fpm at touchdown. The nose came up 5.4° on the way down. Into the flare at 58 kt, 3 kt under the 61 kt approach speed, and 51 kt at touchdown.
Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.
Plan view — the full 1,277 m runway, to the same scale as the side view.
Touched down on the centreline, and stayed about there down the rollout, 3.1 m right at the widest. Calm: nothing to correct for. Touched down straight, wings level.
The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.
The 133 m touchdown sits inside the full-score zone. The 287 fpm arrival was firm.
The stop — touchdown to taxi speed.
From 60 kt at touchdown to taxi speed (30 kt) in 10 s, an average deceleration of 0.15 g.
Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.
The rest of the report
The flight began with a taxiing period from the parking area to the runway, which took approximately 3 minutes and covered a distance of less than 1 nautical mile. The aircraft, a Cessna C172, then departed from runway 26 at EDHK Kiel-Holtenau Airport. The takeoff distance was 482 meters, which accounted for 47% of the runway length. The liftoff speed was 74 knots.
As the aircraft climbed, it started to ascend from an altitude of 653 feet above sea level to 925 feet above sea level, an increase of 273 feet in just 1 minute, covering a distance of 1 nautical mile. This enroute climb phase took place approximately 1 mile southwest of Altenholz, a location in the Schleswig-Holstein region of Germany. Following the climb, the aircraft entered a level cruise phase, which lasted for 16 minutes and covered a distance of 2 nautical miles. This phase took place overhead Altenholz.
The final approach to runway 26 at EDHK Kiel-Holtenau Airport was initiated from the east, with the aircraft heading 262.0 degrees at an altitude of 349 feet above ground level and a distance of 1 nautical mile from the runway. The landing on the runway was successful, with a touchdown distance of 130 meters, which was 34% of the runway length. The touchdown speed was 51 knots, and the touchdown rate was fair at -291 feet per minute. The runway touchdown alignment was perfect, and the runway rollout alignment was very good.
The local weather conditions during the flight were characterized by a temperature of 15 degrees Celsius and a wind speed of 1 knot from a direction of 72 degrees. There was no crosswind, but a tailwind of 1 knot was present. The aircraft used 7 kilograms of fuel during the flight, which lasted for 25 minutes and covered a total distance of 6 nautical miles. The taxiing period from the runway to the parking area took approximately 2 minutes and covered a distance of less than 1 nautical mile.
