MY FS FLIGHTS
Flight Score
Departure
Reduce climb power to bring speed back to 78 kt and hold it there.
What happened: Climb speed was 25 kt fast at 103 kt during the climb.
Watch for: Airspeed indicator: 78 kt in the climb
Arrival
Use small, early rudder corrections against a fixed point at the far end of the runway to hold the centreline.
What happened: The aircraft drifted 8.1 m off the centreline on the approach, and that kind of lateral drift usually carries a bank correction into the touchdown, which showed up as 4.8° of bank there.
Watch for: Runway centreline: track straight with wings level through touchdown.
A small uncorrected heading error at 40 knots becomes a metre of offset per second by 100 knots, noticed only at rotation, producing a crabbed liftoff. Root cause is nearly always eyes on the tape instead of the far end of the runway. Small heading changes displace a distant point visibly long before the nearby centreline stripes look wrong.
Read more in Improve Your Take-OffsStart to finish · 12 stages, 11 in the score
Events
Events
Events
Events
Events
Events
Events
Events
Taxi out
The roll
Rotated late
Rotation started at 72 kt, 13 kt after the 59 kt rotate speed.
The pull started after the rotate speed had gone by. Bring the airspeed into the scan as it approaches the rotate speed, so the pull starts on the number rather than when you notice it has passed.
Liftoff and climb
Plan view the roll down the 1,140 m runway.
Rolled from the start of the runway, drifted left of the centreline, 6.3 m at the widest, and lifted off 6.4 m left, in 5 kn of crosswind from the left. Airborne 16 % of the way down the runway, before the 75 % line.
The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.
Side view from the start of the roll to the end of Climb 3 at 888 ft. The distance scale changes past the runway end.
Reached 35 ft with 811 m of runway left; then climbing at 810 fpm on average to 888 ft.
The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The shaded stretch is Climb 3, scored on its average speed against the target.
Speed and pitch from brake release to the end of the climb, against time.
Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The figure at liftoff is the pitch then. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.
The final from 4 nm.
Profile height against the 3° glideslope, with its 2° band in green.
Inside the glideslope band from 0.8 nm, where the final began, to the threshold, never more than 210 ft above the slope.
Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber.
Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 5× larger than distances along the final.
Joined 38 m right of the centreline at 0.8 nm.
Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.
Speed against the approach speed. The green band runs from 5 kt slow to 31 kt fast at the 1,000 ft gate, closing to 18 at 500 ft and 10 at the threshold.
Fast from 0.8 nm, where the final began, to 0.3 nm (up to +25 kt), then inside the band to the threshold.
Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.
Over the threshold
The flare mostly held the target profile
The aircraft was flown onto the runway - pitch changed 4.8° and the descent was barely arrested. Touchdown was 116 m past the threshold. Start the flare with progressive back pressure rather than one pull, and keep it coming.
Touchdown
Rollout
Taxi in
Side view — the last 1,140 m of the approach.
Began the flare at 26 ft, 47 m before the threshold; crossed the threshold at 16 ft, 34 ft below the 50 ft target. Touched down 116 m in, 189 m short of the ideal 305 m.
The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,140 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.
Sink and pitch — through the flare, lined up with the side view.
The sink went from 390 fpm at the flare to 180 fpm at touchdown. The nose came up 3.3° on the way down. Into the flare at 60 kt, on the 61 kt approach speed, and 49 kt at touchdown.
Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.
Plan view — the full 1,140 m runway, to the same scale as the side view.
Touched down 8 m right of the centreline, and steered back to 0.3 m left by the end of the rollout. 5 kt across from the left, which takes about 6° of crab to hold the centreline at 49 kt. Touched down with 5° of it still on, 4.8° of bank.
Wind 350° at 6 kt · 0 kt tail · 5 kt across
The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.
The 116 m touchdown sits inside the full-score zone. The arrival was smooth.
The stop — touchdown to taxi speed.
From 53 kt at touchdown to taxi speed (30 kt) in 14 s, an average deceleration of 0.09 g.
Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.
The rest of the report
The flight began with a taxiing period from the parking area to the runway, which took 4 minutes and covered a distance of 1 nautical mile. The aircraft, a Cessna C172, then departed from runway 08 at EDHK Kiel-Holtenau Airport. The takeoff distance was 229 meters, which accounted for 22% of the runway length. The liftoff speed was 74 knots, and the local weather conditions were quite cold, with a temperature of -28 °C. The wind was blowing at 6 knots from a direction of 356 °, resulting in a 6-knot crosswind and no headwind.
As the aircraft climbed, it started its enroute climb overhead Heikendorf, a location in Schleswig-Holstein, Germany. The climb began at an altitude of 988 feet above sea level and increased to 992 feet, a rise of just 4 feet, over a period of 1 minute and covering less than 1 nautical mile. Following the climb, the aircraft entered a level cruise phase, also starting overhead Heikendorf, and lasted for 17 minutes, during which it covered a distance of 3 nautical miles.
The final approach to runway 08 at EDHK Kiel-Holtenau Airport was made from the west, with the aircraft heading 82.0 ° at an altitude of 253 feet above ground level and 0 nautical miles from the runway. The landing on the runway was successful, with a threshold height that was good, a threshold speed of 57 knots, and a touchdown distance of 112 meters. The touchdown speed was 49 knots, and the touchdown rate was fair at -226 feet per minute. However, the runway touchdown position was slightly misaligned from the centreline by 8.2 meters.
The local weather conditions at the time of landing were the same as during takeoff, with a temperature of -28 °C and a wind blowing at 6 knots from a direction of 347 °, resulting in a 6-knot crosswind and no headwind. The total landing distance was 367 meters, which accounted for 35% of the runway length. The runway rollout alignment was also slightly misaligned from the centreline by 8.0 meters.
The final phase of the flight involved taxiing from the runway to the parking area, which took 2 minutes and covered less than 1 nautical mile. The total flight distance was 8 nautical miles, and the flight duration was 26 minutes. The aircraft used 8 kilograms of fuel during the flight.
