MY FS FLIGHTS
Flight Score
Departure
Use smoother, smaller aileron inputs to keep the wings level and hold bank angle near wings-level during the climb.
What happened: During the climb, bank angle rose to 9.7°, more roll than the climb out called for.
Watch for: Attitude indicator: wings level during the climb
Arrival
Keep the back pressure coming once the flare is established, holding the nose up through to touchdown instead of easing it.
What happened: The flare arrested the sink but 476 fpm of it came back before touchdown, and in flights like this one that returning sink usually carries through to a firm or hard touchdown at 391 fpm.
Watch for: Vertical speed indicator: the sink held near zero all the way through touchdown, not allowed to build back up.
Preparing for a stable approach will give you time to decide on whether to attempt the landing or going around. Too much altitude with a high sink rate will result in carrying too much speed onto the runway. Configuring flaps and the gear late also won't help the speed decay.
Read more in The Stabilised ApproachStart to finish · 22 stages, 20 in the score
Events
Events
Events
Events
Events
Events
Events
Events
Events
Events
Events
Events
Events
Events
Events
Events
Events
Taxi out
The roll
On speed, but the nose came up quickly
Rotation started at 146 kt, 1 kt after the 145 kt rotate speed. The nose then rose at 3.2° a second, faster than the 2 to 3° a second airliners use.
The rotation started on speed but the nose came up quickly. A fast pull raises the nose faster than the aircraft can lift off, which brings the tail closer to the runway. Pull smoothly at the normal rate for this aircraft and let it fly off at its own attitude.
Liftoff and climb
Plan view the roll down the 2,695 m runway.
Rolled from 157 m in, drifted right of the centreline, 4.6 m at the widest, and lifted off 3.6 m right. Airborne 47 % of the way down the runway, before the 75 % line.
The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.
Side view from the start of the roll to the end of Climb 3 at 896 ft.
Reached 35 ft with 1,056 m of runway left; gear up at 110 ft, inside the 400 ft that gets full marks; then climbing at 3,140 fpm on average to 896 ft.
The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.
Speed and pitch from brake release to the end of the climb, against time.
Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.
Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.
The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2 to 3° a second, the rates airliners are rotated at: a trace steeper than both is a faster rotation, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 9.6°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.
One stabilised approach gate: seven checks where the approach path is 500 ft above the runway. The 1,000 ft gate was not assessed, because the approach did not join final that far out. These checks are the approach's score.
At the 500 ft gate: sink rate more than 600 fpm beyond what the glideslope needed and glideslope more than 1° off the runway's 3°.
When the approach was stable
Never every check met at once: slow until 2.8 nm, banked until 2.2 nm, sinking too fast until 0.6 nm, high until 0.3 nm, left of the centreline from 0.2 nm to the threshold.
Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.
The final from 4 nm, with the stabilisation gates on it.
Profile height against the 3° glideslope, with its 1° band in green.
High from 3.8 nm, where the final began, to 0.3 nm (up to 1,180 ft over), then back on it to the threshold.
Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.
Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 3× larger than distances along the final.
Outside the 1° band 3 times; furthest 1,479 m left at 3.8 nm.
Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.
Speed against the approach speed. The green band runs from 5 kt slow to 45 kt fast at the 1,000 ft gate, closing to 27 at 500 ft and 10 at the threshold.
Slow from 3.8 nm, where the final began, to 2.8 nm (up to −25 kt), then inside the band to the threshold.
Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.
Over the threshold
The flare held the target profile well
The flare began at 47 ft agl above the runway, higher than this aircraft wants. Touchdown was 635 m past the threshold. Hold the aim point and let the runway come to you rather than anticipating the flare.
Touchdown
Rollout
Taxi in
Side view — the last 1,524 m of the approach.
Crossed the threshold at 54 ft, close to the 50 ft target; began the flare high, at 47 ft; ballooned 2 ft from 4 ft. Touched down 635 m in, 330 m past the ideal 305 m.
The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,524 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.
Sink and pitch — through the flare, lined up with the side view.
From the flare the descent stopped and turned into a climb of 120 fpm before coming down at 390 fpm to touch. The nose came up 1.6° on the way down. Into the flare at 181 kt, on the 180 kt approach speed, and 168 kt at touchdown.
Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.
Plan view — the first 1,524 m of the 2,176 m runway, to the same scale as the side view.
Touched down 2.7 m right of the centreline and drifted to 7.6 m right on the rollout. No crosswind: nothing to correct for. Touched down straight, wings level.
Wind 258° at 2 kt · 1 kt head · 0 kt across
The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.
Touched down 635 m past the threshold — beyond the full-score zone. The 391 fpm arrival was firm.
The stop — touchdown to taxi speed.
From 167 kt at touchdown to taxi speed (30 kt) in 20 s, an average deceleration of 0.37 g.
Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.
The rest of the report
The flight in question was operated by a Boeing 747-8 aircraft. The aircraft began its journey by taxiing from the parking area to the runway, a process that took approximately 1 minute and covered less than 1 nautical mile. The departure roll took place on runway 05R at EDDL Düsseldorf Airport, with a takeoff distance of 1,122 meters, which accounted for 47% of the runway. The aircraft lifted off at a speed of 157 knots.
The local weather conditions at the time of departure were characterized by a temperature of 15°C, with a wind speed of 3 knots at 19°. The crosswind and headwind components were both 2 knots. The enroute climb began approximately 1 mile northeast of EDDL Düsseldorf Airport, where the aircraft ascended from 1,183 feet above sea level to 9,981 feet, an increase of 8,798 feet in just 3 minutes, covering a distance of 10 nautical miles.
The aircraft then entered a level cruise phase, which lasted for 2 minutes and covered 8 nautical miles, before initiating another climb phase 1 mile west of Gevelsberg. This climb took the aircraft from 10,456 feet to 19,024 feet, an increase of 8,568 feet in 4 minutes, covering a distance of 22 nautical miles.
The flight continued with a series of enroute descents and level cruises, with notable stops including 2 miles north of Plettenberg, 2 miles west of Brilon, 1 mile west of EDVO Dehausen Airfield Volkmarsen, and 2 miles north west of Warburg. The aircraft also experienced a final climb phase 3 miles south east of Bad Lippspringe, before initiating a descent 3 miles south west of Altenbeken.
The final approach to runway 24 at EDLP Paderborn Lippstadt Airport was made from the north east, with the aircraft heading 237.0° at 2 nautical miles and 903 feet above ground level. The landing took place on a runway length of 2,175 meters, with a threshold speed that was well above the target at 181 knots. The touchdown point was 233 meters beyond the touchdown zone, with a touchdown speed of 168 knots, which was slightly fast. However, the touchdown rate was excellent at -72 feet per minute, and the runway touchdown alignment was very good.
The local weather conditions at the time of landing were characterized by a temperature of 11°C, with a wind speed of 2 knots at 258°. The crosswind and headwind components were 1 and 2 knots, respectively. The total landing distance was 1,310 meters, which accounted for 60% of the runway. The runway rollout alignment was slightly misaligned by 8.0 meters from the centerline.
The aircraft then taxied to the parking area from the runway, a process that took approximately 3 minutes and covered less than 1 nautical mile. The total flight distance was 120 nautical miles, with a total flight time of 30 minutes. The aircraft used 124 kilograms of fuel during the flight.
