YMML
Melbourne, Australia
Runway 27
Elevation390 ft asl
Weight281,032 kg
Fuel25,941 kg
Wind280° · 8 kn · 1 kn cross

Flight Score

99.91 %
YPAD
Adelaide, Australia
Runway 23
Elevation13 ft asl
Weight272,546 kg
Fuel17,120 kg
Wind270° · 8 kn · 5 kn cross
5 Oct 2024 1:10 365 nm Boeing 747-8 8,821 kg
Departure Score
99.74 %
Enroute Score
100.00 %
Arrival Score
100.00 %

What went well

Touched down at -5 fpm — a soft arrival
Touchdown 257 m in — inside the full-score zone
Threshold crossed at 29 ft and 139 kt — both inside band

What held you back

Departure Roll — Rotation speed was 126 kt at 93 %, −0.09 points

Next time

Departure

Hold the nose down until the speed reaches 142 kt, then rotate.

What happened: You started the rotation at 126 kt, 16 kt before the 142 kt rotation speed.

Watch for: Airspeed indicator: 142 kt at rotation

See Departure Roll

A typical trainer rotates in the mid-50s of knots - a 172 at around 55 KIAS, climbing out at a Vy in the low 70s, though check your own POH rather than memorising Cessna's numbers - and the transferable rule is that Vr sits just above the stall speed in takeoff configuration. Rotate early because "it felt ready" and the aircraft lifts off inside ground effect, where induced drag is reduced, then climbs out of it into more drag. On a marginal-performance day the result is an aircraft that lifts off and then refuses to climb, sagging back towards the runway.

Read more in Improve Your Take-Offs

Start to finish · 15 stages, 13 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 5 minutes and covered 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 13 kt0 kt min to max 17 kt 0 13 kt
100 % Average speed turning corners 0 ktmax 0 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle -0.3 °-0.8 ° min to max 0.1 ° -0.3 -0.6 °
Info Average bank angle 0.3 °0.0 ° min to max 1.1 ° 0.1 0.2 °

Events

Info Battery Master On 15 ft agl
Info Engine 1 Started 15 ft agl
Info Engine 4 Started 15 ft agl
Info Beacon Lights Switched On 15 ft agl
Info Navigation Lights Switched On 15 ft agl
Info Autopilot Flight Director Activated 15 ft agl
Info Autopilot Yaw Damper Activated 15 ft agl
Info Landing Gear Down 15 ft agl
Info Pitot Heat Switched On 15 ft agl
Info Engine 2 Started 15 ft agl
Info Engine 3 Started 15 ft agl
Info Taxi Lights Switched On 15 ft agl
Info Parking Brake On 15 ft agl · 2 kt
Info Parking Brake Off 15 ft agl · 2 kt
Info Flaps Position 2 15 ft agl · 2 kt
Info Flaps Position 3 15 ft agl · 2 kt
Info Autopilot Vertical Hold Activated 15 ft agl · 10 kt
Info Landing Lights Switched On 15 ft agl · 8 kt
Info Strobe Lights Switched On 15 ft agl · 8 kt
Departure Runway Entry Entering runway 27 at YMML Melbourne International Airport, Average speed was 20 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 12 kt12 kt min to max 12 kt 12 12 kt
Info Average pitch angle -0.6 °-0.6 ° min to max -0.6 ° -0.6 -0.6 °
Info Average bank angle 0.1 °0.1 ° min to max 0.2 ° 0.2 0.1 °
Info Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Departure Roll 98.68Departure roll runway 27 at YMML Melbourne International Airport. Takeoff distance 869 m 38 % of runway. Rotation speed was 126 kt. Local weather - Temperature 15 °C. Wind 8 kt at 280 °. Crosswind: 1 kt Headwind: 8 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 869 m38 % of runway
93 % Rotation speed was 126 ktTarget 142 kt
100 % Runway alignment max 1.40 m left1.40 m left to 0.00 m left 1.04 0.58 m
100 % Average g force 1.00 g0.96 g min to max 1.08 g 1.00 1.02 g
100 % Takeoff Bounce
Info Average pitch angle 0.4 °-0.8 ° min to max 9.4 ° -0.6 9.4 °
Info Average bank angle 0.2 °0.0 ° min to max 1.0 ° 0.1 1.0 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 27 YMML Melbourne International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.0 °-0.0 ° min to max -0.0 ° -0.0 -0.0 °
100 % Average speed 154 kt143 kt min to max 164 kt 143 164 kt
100 % Steepest bank angle 1.2 °0.7 ° min to max 1.2 ° 1.0 0.7 °
100 % Average g force 1.07 g1.02 g min to max 1.16 g 1.02 1.16 g
Info Average VSI 470 fpm114 fpm min to max 952 fpm 114 952 fpm
Info Average altitude 17 ft agl0 ft agl min to max 44 ft agl 0 44 ft agl
Info Average pitch angle 10.1 °9.4 ° min to max 11.6 ° 9.4 11.6 °

Events

Info Landing Gear Up 47 ft agl · 162 kt
Departure Climb 2 100.00Departure climb to 400 ft agl from 27 YMML Melbourne International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.1 °-0.2 ° min to max -0.0 ° -0.0 -0.2 °
100 % Average speed 171 kt164 kt min to max 191 kt 164 191 kt
100 % Steepest bank angle 1.2 °0.0 ° min to max 1.2 ° 0.7 1.2 °
100 % Average g force 1.14 g1.01 g min to max 1.20 g 1.17 1.03 g
Info Average VSI 1,512 fpm975 fpm min to max 3,012 fpm 975 3,012 fpm
Info Average altitude 96 ft agl46 ft agl min to max 333 ft agl 46 333 ft agl
Info Average pitch angle 11.6 °11.4 ° min to max 12.2 ° 11.6 11.4 °

Events

Info Autopilot Heading Hold Activated 95 ft agl · 172 kt
Departure Climb 3 100.00Departure climb to 1,000 ft agl from 27 YMML Melbourne International Airport.
ScoreDescriptionStartProfileEnd
100 % Climb speed 204 kt193 kt min to max 215 ktTarget 202 kt, 2 kt fast 193 215 kt
100 % Steepest bank angle 1.2 °0.0 ° min to max 1.2 ° 1.2 0.3 °
100 % Average g force 1.01 g0.95 g min to max 1.07 g 0.95 1.05 g
100 % Landing gear up at 27 ft aglTarget by 400 ft agl
Info Heading variation -0.3 °-0.4 ° min to max -0.2 ° -0.2 -0.4 °
Info Average VSI 3,430 fpm3,122 fpm min to max 4,000 fpm 3,122 4,000 fpm
Info Average altitude 637 ft agl386 ft agl min to max 912 ft agl 386 912 ft agl
Info Average pitch angle 11.2 °10.7 ° min to max 12.1 ° 10.8 12.1 °

Events

Info Autopilot Vertical Hold Deactivated 472 ft agl · 199 kt
Info Flaps Position 2 472 ft agl · 199 kt
Info Flaps Position 1 942 ft agl · 220 kt
Enroute Climb 100.00Enroute climb started 1 mile south of Bulla (State of Victoria, Australia). Climbing from 1,409 ft asl to 35,996 ft asl, an increase of 34,587 ft in 13 minutes and covering 78 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 287 kt217 kt min to max 324 kt 217 275 kt
100 % Steepest bank angle 28.7 °0.0 ° min to max 28.7 ° 0.2 1.9 °
100 % Average g force 0.99 g0.70 g min to max 1.18 g 1.02 1.00 g
Info Average VSI 2,809 fpm-187 fpm min to max 5,545 fpm 4,156 -51 fpm
Info Average altitude 19,446 ft asl1,409 ft asl min to max 35,996 ft asl 1,409 35,996 ft asl
Info Average pitch angle 5.9 °1.8 ° min to max 14.3 ° 12.2 2.0 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Fully Retracted 1,225 ft agl · 228 kt
Info Autopilot Master Switched On 3,572 ft agl · 264 kt
Info Autopilot AutoThrottle Arm Armed 4,269 ft agl · 268 kt
Info Autopilot RPM Hold Activated 4,269 ft agl · 268 kt
Info Landing Lights Switched Off 12,699 ft agl · 383 kt
Info Taxi Lights Switched Off 12,790 ft agl · 385 kt
Info Autopilot Airspeed Hold Activated 34,672 ft agl · 484 kt
Info Autopilot RPM Hold Deactivated 34,672 ft agl · 484 kt
Info Autopilot Vertical Hold Activated 34,703 ft agl · 484 kt
Enroute Level 100.00Enroute level cruise started 11 miles south west of Avoca (State of Victoria, Australia) and lasted 24 minutes, covering 161 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,300 ft of 36,069 ft asl35,982 ft asl min to max 36,157 ft asl 35,992 36,152 ft asl
100 % Average speed 275 kt274 kt min to max 276 kt 275 274 kt
100 % Steepest bank angle 28.3 °0.0 ° min to max 28.3 ° 1.5 2.8 °
100 % Average g force 1.01 g0.93 g min to max 1.21 g 1.02 0.96 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 2.2 °1.6 ° min to max 3.4 ° 2.2 2.0 °
Enroute Descent 100.00Enroute descent started 3 miles north of YKTH Keith Airport Keith (State of South Australia, Australia). Descent from 36,150 ft asl to 1,325 ft asl, a decrease of 34,826 ft in 23 minutes and covering 118 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 230 kt142 kt min to max 311 kt 274 142 kt
100 % Steepest bank angle 29.3 °0.0 ° min to max 29.3 ° 1.6 0.1 °
100 % Average g force 1.01 g0.82 g min to max 1.21 g 1.01 0.94 g
Info Average VSI -1,368 fpm-2,418 fpm min to max 215 fpm 0 -652 fpm
Info Average altitude 11,347 ft asl1,325 ft asl min to max 36,151 ft asl 36,150 1,325 ft asl
Info Average pitch angle 0.3 °-2.9 ° min to max 4.6 ° 2.1 2.4 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Airspeed Hold Deactivated 33,641 ft agl · 480 kt
Info Autopilot Mach Hold Activated 33,641 ft agl · 480 kt
Info Autopilot Mach Hold Deactivated 33,603 ft agl · 480 kt
Info Autopilot Airspeed Hold Activated 14,158 ft agl · 387 kt
Info Landing Lights Switched On 9,564 ft agl · 290 kt
Info Taxi Lights Switched On 9,505 ft agl · 290 kt
Info Autopilot Airspeed Hold Deactivated 7,997 ft agl · 287 kt
Info Autopilot Vertical Hold Deactivated 7,997 ft agl · 287 kt
Info Autopilot RPM Hold Activated 7,997 ft agl · 287 kt
Info Autopilot Airspeed Hold Activated 7,966 ft agl · 288 kt
Info Autopilot RPM Hold Deactivated 7,966 ft agl · 288 kt
Info Autopilot Vertical Hold Activated 7,869 ft agl · 288 kt
Info Flaps Position 1 4,980 ft agl · 232 kt
Info Flaps Position 2 4,347 ft agl · 214 kt
Info Autopilot Heading Hold Deactivated 2,708 ft agl · 210 kt
Info Autopilot Approach Mode Activated 2,708 ft agl · 210 kt
Info Flaps Position 3 2,547 ft agl · 197 kt
Info Landing Gear Down 2,574 ft agl · 192 kt
Info Autopilot Vertical Hold Deactivated 2,671 ft agl · 178 kt
Info Flaps Position 4 2,137 ft agl · 168 kt
Info Flaps Position 6 1,386 ft agl · 148 kt
Arrival Approach 100.00Final approach to runway 23 at YPAD Adelaide International Airport. Descent from 1,358 ft agl to 54 ft agl in 105 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates

Events

Info Autopilot AutoThrottle Arm Disarmed 846 ft agl · 145 kt
Info Autopilot Master Switched Off 827 ft agl · 145 kt
Arrival Landing 100.00Landing on runway 23 at YPAD Adelaide International Airport, runway length 3,100 m. Good threshold height. Threshold speed was good at 139 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 139 kt. Target 138 kt
100 % Good threshold height.Target 50 ft agl
100 % Perfect landing flare
100 % Runway alignment max 1.52 m left1.52 m left to 0.53 m left 0.53 1.52 m
100 % Steepest bank angle 0.4 °0.0 ° min to max 0.4 ° 0.3 0.4 °
100 % Peak g force 1.12 g1.01 g min to max 1.12 g 1.01 1.06 g
Info Average speed 137 kt136 kt min to max 139 kt 139 136 kt
Info Average VSI -445 fpm-725 fpm min to max -313 fpm -725 -313 fpm
Info Average altitude 6 ft agl0 ft agl min to max 29 ft agl 29 0 ft agl
Info Average pitch angle 6.3 °3.8 ° min to max 6.9 ° 3.8 6.9 °
07515022530001223354658Runway Distance mLanding Height ft075150225300-24-20-16-12-8-404812162024Runway Distance mRunway Width m
Arrival Touchdown 100.00Touchdown distance was good at 256 m. Touchdown speed at 136 kt was good. Touchdown rate was perfect at -5 fpm. Runway touchdown alignment was very good. Local weather - Temperature 17 °C. Wind 8 kt at 270 °. Crosswind: 5 kt Headwind: 6 kt.
ScoreDescriptionStartProfileEnd
100 % Touchdown rate was -5 fpm.
100 % Touchdown distance was 257 mTarget 457 m
100 % Speed at touchdown 136 ktTarget below 137 kt
100 % Runway alignment max 1.55 m left1.50 m left 1.52 1.47 m
100 % Steepest bank angle 1.3 °0.4 ° min to max 1.3 ° 0.4 1.3 °
100 % Peak g force 1.12 g1.01 g min to max 1.12 g 1.06 1.01 g
100 % Landing Bounce
Info Average speed 135 kt134 kt min to max 136 kt 136 134 kt
Info Average pitch angle 6.8 °6.5 ° min to max 7.0 ° 6.9 6.5 °
Arrival Rollout 100.00Total landing distance 1,192 m, 38 % of runway. Runway rollout alignment was perfect.
ScoreDescriptionStartProfileEnd
100 % Landing distance 1,192 m38 % of runway.
100 % Runway alignment max 2.44 m right0.00 m left to 2.44 m right -2.27 -1.71 m
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.01 1.00 g
Info Average speed 116 kt67 kt min to max 128 kt 128 67 kt
Info Average pitch angle 3.7 °-0.6 ° min to max 6.5 ° 6.5 -0.6 °
Info Average bank angle 1.9 °0.2 ° min to max 3.5 ° 1.1 0.3 °
Runway Exit Exiting runway, average speed 22 kt
ScoreDescriptionStartProfileEnd
Info Average speed 17 kt4 kt min to max 54 kt 54 7 kt
Info Average pitch angle -0.7 °-0.8 ° min to max -0.6 ° -0.7 -0.7 °
Info Average bank angle 0.2 °0.0 ° min to max 0.5 ° 0.3 0.4 °
Info Average g force 1.00 g0.99 g min to max 1.00 g 0.99 1.00 g

Events

Info Flaps Fully Retracted 15 ft agl · 9 kt
Info Landing Lights Switched Off 15 ft agl · 5 kt
Info Strobe Lights Switched Off 15 ft agl · 5 kt
Arrival Taxi 100.00Taxiing to the parking from the runway took 4 minutes and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 13 kt3 kt min to max 21 kt 8 4 kt
100 % Average speed turning corners 10 ktmax 13 kt 0 0 kt
100 % Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Info Average pitch angle -0.7 °-0.7 ° min to max -0.7 ° -0.7 -0.7 °
Info Average bank angle 0.1 °0.0 ° min to max 0.4 ° 0.4 0.0 °

Takeoff from YMML 27

Taxi out

LightsOk
All on
Taxi speed100.00
17kt peak

The roll

Takeoff roll100.00
869m38 %
Runway alignment100.00
1.40m L
Rotation speed93.38
126kttarget 142, 16 early

Rotated early, and the nose came up quickly

Rotation started at 126 kt, 16 kt before the 142 kt rotate speed, and the nose then rose at 3.1° a second, faster than the 2 to 3° a second airliners use.

Early and quick together is the classic tail-strike setup: the nose reaches its liftoff attitude before the aircraft has the speed to fly. Wait for the rotate speed, then pull smoothly at the normal rate for this aircraft and let it lift off at its own attitude.

Liftoff and climb

Liftoff
142ktat 9.4°
Rotation
3.1°/sover 3.0 s, gaining 16 kt
35 ft
162ktat 11.0°, 3.4 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
1.2°steepest
Gear up100.00
27ftfull marks to 400 ft
Climb 3 speed100.00
204kttarget 202

Plan view the roll down the 2,274 m runway.

Rolled from 107 m in, drifted 1.6 m left of the centreline and was back on it to lift off. Airborne 38 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length.

5001,0001,5002,000THRESHOLDLEFT ↑RIGHT ↓75 %widest 1.60 m LROLL 107 M INAirborne 874 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 874 m of 2,274 m · 38 %
Behind the start of the roll, 107 mTakeoff roll, 766 m Left ahead, 1,401 m

Side view from the start of the roll to the end of Climb 3 at 913 ft.

Reached 35 ft with 1,140 m of runway left; gear up at 27 ft, inside the 400 ft that gets full marks; then climbing at 2,520 fpm on average to 913 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3204 kt avgtarget 202THRESHOLDRUNWAY END6080100KNOTS ALONG THE ROLLnose up on the runway · 202 m · 3.0 sRotate 126 kttarget 142Liftoff 142 ktGear up 27 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 202240 kt16080020°10°0°nose up on the runway · 202 m · 3.0 sROTATELIFTOFFtarget 142held 11.5°9.4° off · 3.1°/s11° at 35 ftAIRSPEEDPITCH02040 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2 to 3° a second, the rates airliners are rotated at: a trace steeper than both is a faster rotation, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 12.1°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 12.1°ROTATELIFTOFF35 FT9.4° off · 3.1°/s3°/s2°/s11° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5+6+7 sseconds from rotation
PitchRotation began2 to 3°/s from rotationTail strikeNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate1,040 fpm670 fpm
On glideslope3.0°3.0°
On centreline0.2° off0.2° off
On speed+4.8 kt+2.9 kt
Wings level0° bank0° bank

When the approach was stable

Every check met from 4 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to YPAD 23

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 40 ft below the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,3346653742101,000 ft gate7 of 71,039 ft · 143 kt500 ft gate7 of 7533 ft · 141 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 9× larger than distances along the final.

Inside the 1° band all the way from 4 nm, never more than 43 m off the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR110 m L0110 m RLEFT ↑RIGHT ↓1° BAND31 m L6 m L2 m L0 m R22 m R10 m L
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 35 kt fast at the 1,000 ft gate, closing to 21 at 500 ft and 10 at the threshold.

Inside the speed band all the way, between +1 kt and +8 kt on the approach speed of 138 kt.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

140160180200 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 138+4 kt+4 kt+6 kt+5 kt+1 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on YPAD 23

Over the threshold

Threshold height100.00
29ft
Threshold speed100.00
139kttarget 138, 1 fast
Centreline offset100.00
1.52m L
Bank100.00
0.4°steepest
Flare100.00

Perfect landing flare

Touchdown

Past threshold100.00
257m
Centreline100.00
1.55m L
Speed100.00
135kttarget 137 or less
Touchdown rate100.00
-5fpm
Impact100.00
1.12G
BouncesOk
None
Bank100.00
1.3°as the wheels touched

Rollout

Rollout distance100.00
864m36 % used
Rollout alignment100.00
2.44m R

Taxi in

LightsOk
All set
Taxi speed100.00
21kt peak10 kt in turns

Side view — the last 1,524 m of the approach.

Crossed the threshold at 29 ft, 21 ft below the 50 ft target; began the flare at 23 ft. Touched down 257 m in, 48 m short of the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,524 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

29 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 23 ft · −695 fpm · 4.4° · 139 ktdescent slowed at 0 ft · −5 fpm · 7°−5 fpm · 6.9° nose up · 136 kt Ideal — 50 ft, down at 305 m This flight — 29 ft, down at 257 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 700 fpm at the flare to 0 fpm at touchdown. The nose came up 2.6° on the way down. Into the flare at 139 kt, on the 138 kt approach speed, and 136 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−5 fpm at touchdown6.9° at touchdown, +2.6° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,524 m of the 3,100 m runway, to the same scale as the side view.

Touched down on the centreline, and stayed within 2.2 m of it down the rollout.

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ CROSS 4 kn FULL SCORE TO 503 M 257 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

The 257 m touchdown sits inside the full-score zone. The arrival was smooth.

Runway used 1,121 m of 3,100 m · 36 %
In the air over the runway, 257 mRollout, 864 m Left over, 1,979 m

The stop — touchdown to taxi speed.

From 131 kt at touchdown to taxi speed (30 kt) in 30 s, an average deceleration of 0.18 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 997 m30 kt · 1,201 mtouchdown1,249 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Flight narrative

The flight in the Boeing 747-8 began with a smooth taxi from the parking area to the runway at Melbourne International Airport (YMML). The taxiing took 5 minutes to cover a distance of 1 nautical mile.

Upon reaching the runway, the aircraft was cleared for departure on runway 27. The takeoff roll was 756 meters, which accounted for 33% of the runway length. The liftoff speed reached 143 knots. The local weather at the time of departure was 14°C with a wind of 8 knots coming from 280°. There was a crosswind of 1 knot and a headwind of 8 knots.

The enroute climb started 1 mile south of Bulla in the State of Victoria, Australia. The climb took the aircraft from 1,482 feet above sea level to 35,986 feet above sea level, covering a distance of 71 nautical miles in 12 minutes.

Once reaching cruising altitude, the aircraft maintained level flight for 25 minutes, covering 172 nautical miles while flying 9 miles south of Avoca in Victoria, Australia.

The descent phase of the flight began 8 miles southeast of Tintinara in the State of South Australia. The descent took the aircraft from 36,136 feet above sea level to 1,993 feet above sea level, covering a distance of 100 nautical miles in 21 minutes.

The landing was smoothly executed on runway 23 at Adelaide International Airport (YPAD). The runway length was 2,951 meters. The aircraft touched down 255 meters from the threshold at a speed of 136 knots. The vertical speed indicator showed a descent rate of -313 feet per minute. The local weather at the time of landing was 19°C with a wind of 8 knots from 270°. There was a crosswind of 5 knots and a headwind of 6 knots. The total landing distance was 1,188 meters, which accounted for 40% of the runway length.

After landing, the aircraft taxied from the runway to the parking area, covering less than 1 nautical mile in 4 minutes.

Overall, the total flight distance covered was 353 nautical miles, taking a total of 77 minutes. The flight consumed 8,826 kilograms of fuel during this journey.

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
