My FS Flights logo MY FS FLIGHTS
URKK
Krasnodar, Russia
Runway 05R
Elevation112 ft asl
Weight58,484 kg
Fuel9,737 kg
Wind90° · 2 kn · 1 kn cross

Flight Score

99.47 %
LTAI
Antalya, Turkey
Runway 36R
Elevation171 ft asl
Weight53,890 kg
Fuel5,080 kg
Wind20° · 1 kn
1 Mar 2024 1:28 668 nm Boeing 737-900 4,657 kg
Departure Score
100.00 %
Enroute Score
100.00 %
Arrival Score
98.40 %

What went well

Touched down at -175 fpm — a soft arrival
Touchdown 451 m in — inside the full-score zone
Straight touchdown — 2.30 m off the centreline, no bounce

What held you back

Arrival Approach — 1,000 ft gate 100 %, 500 ft gate 86 %, −0.48 points
Arrival Landing — scored 99.15 %, −0.06 points

Next time

Arrival

Add power at the gate to bring speed up to 134 kt and hold it there.

What happened: The approach was flown too slow, crossing the gate at 129 kt against a target of 134 kt, 5.1 kt under.

Watch for: Airspeed indicator: 134 kt at the gate

See Arrival Approach

Preparing for a stable approach will give you time to decide on whether to attempt the landing or going around. Too much altitude with a high sink rate will result in carrying too much speed onto the runway. Configuring flaps and the gear late also won't help the speed decay.

Read more in The Stabilised Approach

Start to finish · 15 stages, 13 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 4 minutes and covered 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 18 kt0 kt min to max 24 kt 0 14 kt
100 % Average speed turning corners 15 ktmax 15 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.01 g
Info Average pitch angle -1.1 °-1.4 ° min to max -0.9 ° -1.0 -0.9 °
Info Average bank angle 0.1 °0.0 ° min to max 0.3 ° 0.0 0.0 °

Events

Info Engine 1 Started 8 ft agl · 1 kt
Info Parking Brake Off 8 ft agl · 1 kt
Info Landing Lights Switched On 8 ft agl · 14 kt
Info Strobe Lights Switched On 8 ft agl · 14 kt
Info Taxi Lights Switched Off 8 ft agl · 15 kt
Departure Runway Entry Entering runway 05R at URKK Krasnodar Pashkovsky International Airport, Average speed was 16 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 14 kt14 kt min to max 14 kt 14 14 kt
Info Average pitch angle -0.9 °-0.9 ° min to max -0.8 ° -0.9 -0.8 °
Info Average bank angle 0.1 °0.0 ° min to max 0.1 ° 0.1 0.0 °
Info Average g force 1.00 g0.99 g min to max 1.01 g 1.01 1.00 g
Departure Roll 100.00Departure roll runway 05R at URKK Krasnodar Pashkovsky International Airport. Takeoff distance 1,104 m 37 % of runway. Rotation speed was 140 kt. Local weather - Temperature 2 °C. Wind 2 kt at 90 °. Crosswind: 1 kt Headwind: 2 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 1,104 m37 % of runway
100 % Rotation speed was 140 ktTarget 134 kt
100 % Runway alignment max 0.64 m left0.64 m left to 0.14 m right 0.20 -0.14 m
100 % Average g force 1.01 g0.97 g min to max 1.10 g 1.01 1.10 g
100 % Takeoff Bounce
Info Average pitch angle -0.4 °-1.1 ° min to max 6.8 ° -0.8 6.8 °
Info Average bank angle 0.1 °0.0 ° min to max 0.4 ° 0.0 0.4 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 05R URKK Krasnodar Pashkovsky International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.0 °0.0 ° min to max 0.0 ° 0.0 0.0 °
100 % Average speed 160 kt155 kt min to max 165 kt 155 165 kt
100 % Steepest bank angle 0.5 °0.3 ° min to max 0.5 ° 0.4 0.3 °
100 % Average g force 1.29 g1.12 g min to max 1.34 g 1.12 1.30 g
Info Average VSI 787 fpm262 fpm min to max 1,390 fpm 262 1,390 fpm
Info Average altitude 17 ft agl0 ft agl min to max 48 ft agl 0 48 ft agl
Info Average pitch angle 10.7 °7.1 ° min to max 13.3 ° 7.1 13.3 °

Events

Info Landing Gear Up 13 ft agl · 153 kt
Departure Climb 2 99.99Departure climb to 400 ft agl from 05R URKK Krasnodar Pashkovsky International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.0 °0.0 ° min to max 0.0 ° 0.0 0.0 °
100 % Average speed 168 kt165 kt min to max 178 kt 165 178 kt
100 % Steepest bank angle 0.3 °0.3 ° min to max 0.3 ° 0.3 0.3 °
99.9 % Average g force 1.20 g0.97 g min to max 1.29 g 1.29 0.99 g
Info Average VSI 2,058 fpm1,443 fpm min to max 3,378 fpm 1,443 3,378 fpm
Info Average altitude 106 ft agl51 ft agl min to max 348 ft agl 51 348 ft agl
Info Average pitch angle 14.2 °13.4 ° min to max 15.0 ° 13.4 15.0 °

Events

Info Flaps Position 4 134 ft agl · 165 kt
Departure Climb 3 100.00Departure climb to 1,000 ft agl from 05R URKK Krasnodar Pashkovsky International Airport.
ScoreDescriptionStartProfileEnd
100 % Climb speed 186 kt181 kt min to max 190 ktTarget 184 kt, 2 kt fast 181 190 kt
100 % Steepest bank angle 0.3 °0.2 ° min to max 0.3 ° 0.3 0.2 °
100 % Average g force 0.99 g0.97 g min to max 1.02 g 1.01 0.97 g
100 % Landing gear up at 6 ft aglTarget by 400 ft agl
Info Heading variation 0.0 °-0.0 ° min to max 0.0 ° 0.0 -0.0 °
Info Average VSI 3,980 fpm3,591 fpm min to max 4,270 fpm 3,591 4,270 fpm
Info Average altitude 701 ft agl467 ft agl min to max 944 ft agl 467 944 ft agl
Info Average pitch angle 16.1 °15.5 ° min to max 16.4 ° 15.5 16.4 °

Events

Info Flaps Position 2 602 ft agl · 180 kt
Info Flaps Position 1 875 ft agl · 186 kt
Enroute Climb 100.00Enroute climb started 1 mile east of URKK Krasnodar Pashkovsky International Airport Krasnodar (Krasnodarskiy Kray, Russia). Climbing from 1,140 ft asl to 40,256 ft asl, an increase of 39,116 ft in 22 minutes and covering 151 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 251 kt191 kt min to max 298 kt 191 239 kt
100 % Steepest bank angle 30.7 °0.0 ° min to max 30.7 ° 0.2 0.1 °
100 % Average g force 1.02 g0.89 g min to max 1.17 g 0.98 1.02 g
Info Average VSI 2,778 fpm-166 fpm min to max 6,113 fpm 4,328 -166 fpm
Info Average altitude 22,491 ft asl1,140 ft asl min to max 40,263 ft asl 1,140 40,256 ft asl
Info Average pitch angle 8.6 °3.0 ° min to max 16.9 ° 16.5 3.6 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Fully Retracted 1,398 ft agl · 193 kt
Info Landing Lights Switched Off 11,660 ft agl · 267 kt
Enroute Level 100.00Enroute level cruise started 83 miles south west of Arkhipo-Osipovka (Krasnodarskiy Kray, Russia) and lasted 34 minutes, covering 251 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,513 ft of 40,222 ft asl40,176 ft asl min to max 40,281 ft asl 40,260 40,191 ft asl
100 % Average speed 245 kt240 kt min to max 250 kt 240 248 kt
100 % Steepest bank angle 19.1 °0.0 ° min to max 19.1 ° 0.1 0.1 °
100 % Average g force 1.01 g0.97 g min to max 1.06 g 1.00 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 3.5 °3.0 ° min to max 3.8 ° 3.8 3.2 °
Enroute Descent 100.00Enroute descent started overhead Sabanozu (Cankiri, Turkey). Descent from 40,180 ft asl to 1,451 ft asl, a decrease of 38,729 ft in 25 minutes and covering 260 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 235 kt129 kt min to max 336 kt 247 130 kt
100 % Steepest bank angle 27.6 °0.0 ° min to max 27.6 ° 0.0 2.2 °
100 % Average g force 1.02 g0.84 g min to max 1.18 g 1.01 1.00 g
Info Average VSI -771 fpm-2,035 fpm min to max 370 fpm -50 -669 fpm
Info Average altitude 14,552 ft asl1,451 ft asl min to max 40,186 ft asl 40,180 1,451 ft asl
Info Average pitch angle 1.0 °-3.4 ° min to max 3.7 ° 3.3 2.1 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Landing Lights Switched On 17,532 ft agl · 351 kt
Info Taxi Lights Switched On 17,532 ft agl · 351 kt
Info Flaps Position 1 8,676 ft agl · 301 kt
Info Flaps Fully Retracted 8,865 ft agl · 300 kt
Info Flaps Position 1 8,740 ft agl · 299 kt
Info Flaps Position 2 7,711 ft agl · 275 kt
Info Flaps Position 1 7,639 ft agl · 275 kt
Info Flaps Position 3 7,756 ft agl · 274 kt
Info Flaps Position 2 7,730 ft agl · 274 kt
Info Flaps Position 3 7,771 ft agl · 271 kt
Info Landing Gear Down 2,545 ft agl · 250 kt
Info Flaps Position 4 2,080 ft agl · 214 kt
Info Flaps Position 3 2,071 ft agl · 212 kt
Info Flaps Position 4 2,054 ft agl · 208 kt
Info Flaps Position 5 2,034 ft agl · 203 kt
Info Flaps Position 4 2,028 ft agl · 201 kt
Info Flaps Position 5 2,020 ft agl · 197 kt
Info Flaps Position 7 2,003 ft agl · 175 kt
Info Flaps Position 5 2,002 ft agl · 174 kt
Info Flaps Position 6 2,000 ft agl · 170 kt
Info Flaps Position 7 1,994 ft agl · 164 kt
Info Flaps Position 8 1,971 ft agl · 155 kt
Info Landing Gear Up 1,756 ft agl · 140 kt
Info Landing Gear Down 1,753 ft agl · 140 kt
Arrival Approach 92.86Final approach to runway 36R at LTAI Antalya International Airport. Descent from 1,313 ft agl to 50 ft agl in 110 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
50 % On speedfailed at one of the two gates
100 % Wings levelpassed at both gates
Arrival Landing 99.15Landing on runway 36R at LTAI Antalya International Airport, runway length 3,406 m. Good threshold height. Threshold speed was slightly below target at 127 kt.
ScoreDescriptionStartProfileEnd
97 % Threshold speed was slightly below target at 127 kt. Target 134 kt
100 % Good threshold height.Target 50 ft agl
100 % Perfect landing flare
100 % Runway alignment max 3.89 m left3.89 m left to 2.80 m left 3.89 2.80 m
100 % Steepest bank angle 0.5 °0.0 ° min to max 0.5 ° 0.4 0.2 °
100 % Peak g force 1.07 g1.01 g min to max 1.07 g 1.01 1.03 g
Info Average speed 126 kt123 kt min to max 127 kt 127 123 kt
Info Average VSI -471 fpm-656 fpm min to max -196 fpm -656 -196 fpm
Info Average altitude 24 ft agl6 ft agl min to max 53 ft agl 53 6 ft agl
Info Average pitch angle 3.6 °2.4 ° min to max 4.6 ° 2.4 4.6 °
07515022530037545052501123344657Runway Distance mLanding Height ft075150225300375450525-24-20-16-12-8-404812162024Runway Distance mRunway Width m
Arrival Touchdown 100.00Touchdown distance was good at 450 m. Touchdown speed at 123 kt was good. Touchdown rate was good at -175 fpm. Runway touchdown alignment was very good. Local weather - Temperature 14 °C. Wind 1 kt at 20 °. Crosswind: 0 kt Headwind: 1 kt.
ScoreDescriptionStartProfileEnd
100 % Touchdown rate was -175 fpm.
100 % Touchdown distance was 451 mTarget 457 m
100 % Speed at touchdown 123 ktTarget below 132 kt
100 % Runway alignment max 2.80 m left2.57 m left 2.80 2.30 m
100 % Steepest bank angle 0.5 °0.0 ° min to max 0.5 ° 0.2 0.3 °
100 % Peak g force 1.18 g1.02 g min to max 1.18 g 1.03 1.07 g
100 % Landing Bounce
Info Average speed 123 kt122 kt min to max 123 kt 123 122 kt
Info Average pitch angle 4.4 °4.2 ° min to max 4.6 ° 4.6 4.2 °
Arrival Rollout 100.00Total landing distance 924 m, 27 % of runway. Runway rollout alignment was perfect.
ScoreDescriptionStartProfileEnd
100 % Landing distance 924 m27 % of runway.
100 % Runway alignment max 1.18 m right0.03 m left to 1.18 m right -0.83 0.03 m
100 % Average g force 0.99 g0.96 g min to max 1.06 g 1.06 0.99 g
Info Average speed 113 kt65 kt min to max 121 kt 121 65 kt
Info Average pitch angle 1.5 °-1.1 ° min to max 4.1 ° 4.1 -1.1 °
Info Average bank angle 0.3 °0.0 ° min to max 0.5 ° 0.5 0.0 °
Runway Exit Exiting runway, average speed 27 kt
ScoreDescriptionStartProfileEnd
Info Average speed 27 kt12 kt min to max 58 kt 58 13 kt
Info Average pitch angle -1.1 °-1.3 ° min to max -0.9 ° -1.1 -1.0 °
Info Average bank angle 0.1 °0.0 ° min to max 0.5 ° 0.2 0.1 °
Info Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.01 g

Events

Info Flaps Position 7 8 ft agl · 41 kt
Info Flaps Position 8 8 ft agl · 41 kt
Info Flaps Position 7 8 ft agl · 35 kt
Info Flaps Position 6 8 ft agl · 16 kt
Info Flaps Position 5 8 ft agl · 14 kt
Info Flaps Position 4 8 ft agl · 13 kt
Info Landing Lights Switched Off 8 ft agl · 11 kt
Info Strobe Lights Switched Off 8 ft agl · 11 kt
Info Flaps Position 3 8 ft agl · 12 kt
Arrival Taxi 100.00Taxiing to the parking from the runway took 1 minutes and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 15 kt7 kt min to max 26 kt 14 10 kt
100 % Average speed turning corners 0 ktmax 0 kt 0 0 kt
100 % Average g force 1.00 g0.98 g min to max 1.01 g 1.00 0.98 g
Info Average pitch angle -1.0 °-1.3 ° min to max -0.8 ° -1.0 -1.3 °
Info Average bank angle 0.1 °0.0 ° min to max 0.3 ° 0.1 0.1 °

Events

Info Flaps Position 2 8 ft agl · 14 kt
Info Flaps Position 1 8 ft agl · 18 kt
Info Flaps Fully Retracted 8 ft agl · 11 kt

Takeoff from URKK 05R

Taxi out

LightsOk
All on
Taxi speed100.00
24kt peak15 kt in turns

The roll

Takeoff roll100.00
1,104m37 %
Runway alignment100.00
0.64m L
Rotation speed100.00
140kttarget 134, 6 late

Rotated late

Rotation started at 140 kt, 6 kt after the 134 kt rotate speed.

The pull started after the rotate speed had gone by. Bring the airspeed into the scan as it approaches the rotate speed, so the pull starts on the number rather than when you notice it has passed.

Liftoff and climb

Liftoff
154ktat 7.1°
Rotation
3.1°/sover 2.5 s, gaining 14 kt
35 ft
164ktat 12.8°, 2.1 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
0.5°steepest
Gear up100.00
6ftfull marks to 400 ft
Climb 3 speed100.00
186kttarget 184

Plan view the roll down the 2,984 m runway.

Rolled from 86 m in, never more than 0.5 m off the centreline. Airborne 37 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

1,0002,000THRESHOLDLEFT ↑RIGHT ↓CROSS1 kn75 %widest 0.49 m RROLL 86 M INAirborne 1,110 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,110 m of 2,984 m · 37 %
Behind the start of the roll, 86 mTakeoff roll, 1,025 m Left ahead, 1,874 m

Side view from the start of the roll to the end of Climb 3 at 945 ft.

Reached 35 ft with 1,705 m of runway left; gear up at 6 ft, inside the 400 ft that gets full marks; then climbing at 3,220 fpm on average to 945 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3186 kt avgtarget 184THRESHOLDRUNWAY END6080100120KNOTS ALONG THE ROLLnose up on the runway · 188 m · 2.5 sRotate 140 kttarget 134Liftoff 154 ktGear up 6 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 184210 kt14070020°10°0°nose up on the runway · 188 m · 2.5 sROTATELIFTOFFtarget 134held 14.3°7.1° off · 3.1°/s13° at 35 ftAIRSPEEDPITCH02040 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2.1 to 4.1° a second, the middle half of rotation rates flown by other Boeing 737-900 pilots over the last 180 days (116 takeoffs); the grey pair are 2 to 3° a second, the rates airliners are rotated at. A trace steeper than both green lines is a faster rotation than most, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 10°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 10°ROTATELIFTOFF35 FT3°/s4.1°/s7.1° off · 3.1°/s2.1°/s2°/s13° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5 sseconds from rotation
PitchRotation began2.1 to 4.1°/s, other Boeing 737-900 pilots2 to 3°/s from rotation, airlinersTail strikeNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 85.716 of 7
Gear down
Landing flap
Sink rate700 fpm780 fpm
On glideslope3.0°3.1°
On centreline0.1° off0.1° off
On speed−3.7 kt−5.1 kt
Wings level0° bank0° bank

At the 500 ft gate: speed more than 5 kt below the approach speed of 134 kt.

When the approach was stable

Every check met from 2.0 to 1.5 nm, then not again: slow from 1.5 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to LTAI 36R

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 10 ft above the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,3176893732191,000 ft gate7 of 71,054 ft · 130 kt500 ft gate6 of 7on speed542 ft · 129 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 12× larger than distances along the final.

Inside the 1° band all the way from 4 nm, never more than 31 m off the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR79 m L079 m RLEFT ↑RIGHT ↓1° BAND31 m R7 m L6 m L5 m L8 m L7 m L
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 34 kt fast at the 1,000 ft gate, closing to 20 at 500 ft and 10 at the threshold.

Inside the speed band from 4 nm to 2.6 nm, then slow to 2.0 nm (up to −6 kt), then inside the band to 1.5 nm, then slow to the threshold (up to −7 kt).

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

120140160180 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 134−4 kt−6 kt−7 kt−6 kt−7 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on LTAI 36R

Over the threshold

Threshold height100.00
53ft
Threshold speed96.61
126kttarget 134, 8 slow
Centreline offset100.00
3.89m L
Bank100.00
0.5°steepest
Flare100.00

Perfect landing flare

Touchdown

Past threshold100.00
451m
Centreline100.00
2.80m L
Speed100.00
123kttarget 132 or less
Touchdown rate100.00
-175fpm
Impact100.00
1.18G
BouncesOk
None
Bank100.00
0.5°as the wheels touched

Rollout

Rollout distance100.00
435m26 % used
Rollout alignment100.00
1.18m R

Taxi in

LightsOk
All set
Taxi speed100.00
26kt peak

Side view — the last 1,524 m of the approach.

Crossed the threshold at 53 ft, close to the 50 ft target; began the flare at 16 ft. Touched down 451 m in, 146 m past the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,524 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

53 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 16 ft · −386 fpm · 3.9° · 126 ktdescent slowed at 0 ft · −174 fpm · 4.6°−174 fpm · 4.6° nose up · 123 kt Ideal — 50 ft, down at 305 m This flight — 53 ft, down at 451 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 390 fpm at the flare to 170 fpm at touchdown. The nose came up 0.7° on the way down. Into the flare at 126 kt, 8 kt under the 134 kt approach speed, and 123 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−174 fpm at touchdown4.6° at touchdown, +0.7° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,524 m of the 3,406 m runway, to the same scale as the side view.

Touched down 2.3 m left of the centreline, and stayed within 2.8 m of it down the rollout. No crosswind: nothing to correct for. Touched down with the nose 1° right of the track, wings level.

Wind 020° at 1 kt · 1 kt head · 0 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ FULL SCORE TO 503 M 451 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

The 451 m touchdown sits inside the full-score zone. The arrival was smooth.

Runway used 885 m of 3,406 m · 26 %
In the air over the runway, 451 mRollout, 435 m Left over, 2,520 m

The stop — touchdown to taxi speed.

From 122 kt at touchdown to taxi speed (30 kt) in 24 s, an average deceleration of 0.21 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 506 m30 kt · 778 mtouchdown809 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
