EHAM
Amsterdam, The Netherlands
Runway 24
Elevation-10 ft asl
Weight188,344 kg
Fuel17,007 kg
Wind0° · 1 kn

Flight Score

99.75 %
LIMC
Ferno (VA), Italy
Runway 35R
Elevation722 ft asl
Weight179,920 kg
Fuel8,406 kg
Wind20° · 2 kn · 1 kn cross
6 Sep 2025 1:31 550 nm Boeing 777-200ER 8,601 kg
Departure Score
100.00 %
Enroute Score
100.00 %
Arrival Score
99.25 %

What went well

Touched down at -257 fpm — a soft arrival
Straight touchdown — 0.84 m off the centreline, no bounce
Flare on profile — 99 %

What held you back

Arrival Touchdown — Touchdown distance was 634 m at 81 %, −0.19 points
Firm touchdown — 257 fpm, −0.03 points across the landing and the touchdown
  • Arrival Touchdown · sink rate 257 fpm−0.02
  • Arrival Landing · flare: the descent was not taken out−0.01

Next time

Arrival

Adjust your approach path so you touch down at the 457 m aim point instead of beyond it.

What happened: Touchdown point came 177 m past the target, landing at 634 m against the 457 m aim point. Landings that touch down this far beyond the aim point typically leave less runway available for stopping.

Watch for: Touchdown distance marker: 457 m from the threshold.

See Arrival Touchdown

Start to finish · 19 stages, 17 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 7 minutes and covered 2 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 15 kt0 kt min to max 17 kt 3 15 kt
100 % Average speed turning corners 0 ktmax 0 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle -0.9 °-1.1 ° min to max -0.7 ° -0.9 -1.0 °
Info Average bank angle 0.0 °0.0 ° min to max 0.2 ° 0.0 0.0 °

Events

Info Pitot Heat Switched On 13 ft agl
Info Parking Brake On 13 ft agl
Info Taxi Lights Switched On 13 ft agl
Info Flaps Position 1 13 ft agl
Info Engine 1 Started 13 ft agl
Info Flaps Position 2 13 ft agl
Info Flaps Position 3 13 ft agl
Info Parking Brake Off 13 ft agl
Info Landing Lights Switched On 13 ft agl · 17 kt
Info Strobe Lights Switched On 13 ft agl · 17 kt
Departure Runway Entry Entering runway 24 at EHAM Amsterdam Airport Schiphol, Average speed was 14 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 15 kt15 kt min to max 15 kt 15 15 kt
Info Average pitch angle -0.9 °-1.0 ° min to max -0.9 ° -1.0 -0.9 °
Info Average bank angle 0.1 °0.0 ° min to max 0.1 ° 0.0 0.1 °
Info Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Departure Roll 100.00Departure roll runway 24 at EHAM Amsterdam Airport Schiphol. Takeoff distance 999 m 29 % of runway. Rotation speed was 143 kt. Local weather - Temperature 15 °C. Wind 0 kt at 0 °. Crosswind: 0 kt Headwind: 0 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 999 m29 % of runway
100 % Rotation speed was 143 ktTarget 132 kt
100 % Runway alignment max 1.55 m right0.02 m left to 1.55 m right 0.01 -1.55 m
100 % Average g force 1.00 g0.96 g min to max 1.05 g 1.00 1.01 g
100 % Takeoff Bounce
Info Average pitch angle -0.4 °-0.9 ° min to max 5.6 ° -0.8 5.6 °
Info Average bank angle 0.2 °0.0 ° min to max 0.4 ° 0.1 0.3 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 24 EHAM Amsterdam Airport Schiphol.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.1 °0.1 ° min to max 0.1 ° 0.1 0.1 °
100 % Average speed 165 kt157 kt min to max 172 kt 157 172 kt
100 % Steepest bank angle 0.3 °0.2 ° min to max 0.3 ° 0.3 0.2 °
100 % Average g force 1.21 g1.03 g min to max 1.25 g 1.03 1.21 g
Info Average VSI 533 fpm28 fpm min to max 1,205 fpm 28 1,205 fpm
Info Average altitude 17 ft agl0 ft agl min to max 45 ft agl 0 45 ft agl
Info Average pitch angle 8.8 °5.8 ° min to max 10.5 ° 5.8 10.5 °
Departure Climb 2 100.00Departure climb to 400 ft agl from 24 EHAM Amsterdam Airport Schiphol.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.1 °0.1 ° min to max 0.1 ° 0.1 0.1 °
100 % Average speed 179 kt173 kt min to max 198 kt 173 198 kt
100 % Steepest bank angle 0.2 °0.1 ° min to max 0.2 ° 0.2 0.1 °
100 % Average g force 1.13 g1.01 g min to max 1.20 g 1.20 1.09 g
Info Average VSI 1,825 fpm1,253 fpm min to max 3,368 fpm 1,253 3,368 fpm
Info Average altitude 111 ft agl48 ft agl min to max 382 ft agl 48 382 ft agl
Info Average pitch angle 11.1 °10.6 ° min to max 13.4 ° 10.6 13.4 °

Events

Info Landing Gear Up 79 ft agl · 174 kt
Departure Climb 3 100.00Departure climb to 1,000 ft agl from 24 EHAM Amsterdam Airport Schiphol.
ScoreDescriptionStartProfileEnd
100 % Climb speed 204 kt200 kt min to max 205 ktTarget 187 kt, 17 kt fast 200 205 kt
100 % Steepest bank angle 0.4 °0.1 ° min to max 0.4 ° 0.1 0.4 °
100 % Average g force 1.03 g0.96 g min to max 1.09 g 1.09 0.96 g
100 % Landing gear up at 60 ft aglTarget by 400 ft agl
Info Heading variation 0.1 °0.1 ° min to max 0.1 ° 0.1 0.1 °
Info Average VSI 4,422 fpm3,661 fpm min to max 4,867 fpm 3,661 4,867 fpm
Info Average altitude 707 ft agl446 ft agl min to max 986 ft agl 446 986 ft agl
Info Average pitch angle 15.6 °14.0 ° min to max 16.4 ° 14.0 16.0 °
Enroute Climb 100.00Enroute climb started 1 mile north of Aalsmeerderbrug (Provincie Noord-Holland, The Netherlands). Climbing from 1,069 ft asl to 36,874 ft asl, an increase of 35,805 ft in 15 minutes and covering 102 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 268 kt205 kt min to max 299 kt 205 273 kt
100 % Steepest bank angle 31.3 °0.0 ° min to max 31.3 ° 0.3 11.5 °
99.99 % Average g force 1.02 g0.77 g min to max 1.35 g 0.80 1.22 g
Info Average VSI 2,747 fpm916 fpm min to max 4,798 fpm 4,798 1,866 fpm
Info Average altitude 17,764 ft asl1,069 ft asl min to max 36,874 ft asl 1,069 36,874 ft asl
Info Average pitch angle 7.7 °3.5 ° min to max 14.7 ° 14.7 5.7 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Position 1 1,154 ft agl · 207 kt
Info Flaps Fully Retracted 1,809 ft agl · 238 kt
Info Landing Lights Switched Off 10,927 ft agl · 303 kt
Info Taxi Lights Switched Off 10,958 ft agl · 307 kt
Enroute Level 100.00Enroute level cruise started 2 miles south west of EDLE Essen Mülheim Airport Essen-Mulheim (Nordrhein-Westfalen, Germany) and lasted 35 minutes, covering 285 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,346 ft of 37,309 ft asl36,911 ft asl min to max 37,334 ft asl 36,911 37,320 ft asl
100 % Average speed 270 kt268 kt min to max 273 kt 273 269 kt
100 % Steepest bank angle 20.6 °0.0 ° min to max 20.6 ° 11.8 0.0 °
100 % Average g force 1.01 g0.85 g min to max 1.12 g 1.12 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 2.5 °1.6 ° min to max 5.6 ° 5.6 2.3 °
Enroute Descent 100.00Enroute descent started 1 mile east of Emmetten (Kanton Nidwalden, Switzerland). Descent from 37,320 ft asl to 6,213 ft asl, a decrease of 31,107 ft in 17 minutes and covering 109 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 285 kt214 kt min to max 304 kt 269 220 kt
100 % Steepest bank angle 26.6 °0.0 ° min to max 26.6 ° 0.0 0.1 °
100 % Average g force 1.03 g0.83 g min to max 1.21 g 1.00 1.00 g
Info Average VSI -2,113 fpm-4,308 fpm min to max 156 fpm 34 -19 fpm
Info Average altitude 20,179 ft asl6,203 ft asl min to max 37,331 ft asl 37,320 6,213 ft asl
Info Average pitch angle -0.8 °-3.2 ° min to max 4.7 ° 2.4 4.2 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Landing Lights Switched On 9,705 ft agl · 280 kt
Info Taxi Lights Switched On 9,689 ft agl · 280 kt
Enroute Level 2 100.00Enroute level cruise started 2 miles north west of Zerbolo (Lombardia, Italy) and lasted 2 minutes, covering 7 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±810 ft of 6,198 ft asl6,184 ft asl min to max 6,208 ft asl 6,208 6,206 ft asl
100 % Average speed 211 kt208 kt min to max 220 kt 220 210 kt
100 % Steepest bank angle 0.2 °0.0 ° min to max 0.2 ° 0.0 0.0 °
100 % Average g force 1.00 g0.99 g min to max 1.00 g 1.00 0.99 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 4.8 °4.2 ° min to max 5.1 ° 4.2 4.8 °
Enroute Descent 2 100.00Enroute descent started 1 mile south west of Zinasco Vecchio (Lombardia, Italy). Descent from 6,204 ft asl to 4,753 ft asl, a decrease of 1,451 ft in 3 minutes and covering 13 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 206 kt203 kt min to max 212 kt 211 209 kt
100 % Steepest bank angle 27.0 °0.0 ° min to max 27.0 ° 0.0 0.4 °
100 % Average g force 1.06 g0.98 g min to max 1.15 g 1.00 1.00 g
Info Average VSI -415 fpm-1,243 fpm min to max 83 fpm -2 -182 fpm
Info Average altitude 5,570 ft asl4,753 ft asl min to max 6,204 ft asl 6,204 4,753 ft asl
Info Average pitch angle 4.4 °2.0 ° min to max 5.9 ° 4.8 4.5 °
Info Turn coordination 00 min to max 0 0 0
Enroute Level 3 100.00Enroute level cruise started 1 mile north of Ferrera Erbognone (Lombardia, Italy) and lasted 3 minutes, covering 13 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±736 ft of 4,420 ft asl4,068 ft asl min to max 4,721 ft asl 4,721 4,068 ft asl
100 % Average speed 208 kt204 kt min to max 213 kt 209 212 kt
100 % Steepest bank angle 10.4 °0.0 ° min to max 10.4 ° 0.3 0.0 °
100 % Average g force 1.00 g0.99 g min to max 1.03 g 1.00 1.01 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 4.5 °4.2 ° min to max 5.0 ° 4.5 4.4 °

Events

Info Flaps Position 1 3,693 ft agl · 227 kt
Enroute Descent 3 100.00Enroute descent started overhead Cassolnovo (Lombardia, Italy). Descent from 4,033 ft asl to 1,995 ft asl, a decrease of 2,038 ft in 4 minutes and covering 12 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 150 kt133 kt min to max 207 kt 207 135 kt
100 % Steepest bank angle 0.5 °0.0 ° min to max 0.5 ° 0.0 0.1 °
100 % Average g force 1.00 g0.95 g min to max 1.02 g 1.00 1.00 g
Info Average VSI -633 fpm-908 fpm min to max -62 fpm -340 -713 fpm
Info Average altitude 2,638 ft asl1,995 ft asl min to max 4,033 ft asl 4,033 1,995 ft asl
Info Average pitch angle 2.0 °0.5 ° min to max 5.5 ° 4.2 1.1 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Position 2 3,391 ft agl · 200 kt
Info Landing Gear Down 3,156 ft agl · 189 kt
Info Flaps Position 3 2,728 ft agl · 187 kt
Info Flaps Position 4 2,675 ft agl · 179 kt
Info Flaps Position 5 2,220 ft agl · 150 kt
Info Flaps Position 6 2,143 ft agl · 143 kt
Arrival Approach 100.00Final approach to runway 35R at LIMC Milan Malpensa International Airport. Descent from 1,308 ft agl to 74 ft agl in 105 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates
Arrival Landing 99.44Landing on runway 35R at LIMC Milan Malpensa International Airport, runway length 3,906 m. Threshold height at 56 ft agl was slightly above target. Threshold speed was good at 136 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 136 kt. Target 131 kt
98 % Threshold height at 56 ft agl was slightly above target.Target 50 ft agl
99 % The flare tracked the target profile closely. The aircraft floated down the runway before touching. Touchdown was 634 m past the threshold. Threshold speed was not the cause here - hold the aim point on the approach and let the aircraft settle rather than holding it off, and the touchdown comes back to the numbers.
100 % Runway alignment max 0.98 m left0.98 m left to 0.59 m left 0.67 0.98 m
100 % Steepest bank angle 0.7 °0.0 ° min to max 0.7 ° 0.7 0.1 °
100 % Peak g force 1.10 g0.96 g min to max 1.10 g 1.01 0.98 g
Info Average speed 134 kt129 kt min to max 136 kt 136 129 kt
Info Average VSI -377 fpm-515 fpm min to max -199 fpm -505 -239 fpm
Info Average altitude 26 ft agl3 ft agl min to max 56 ft agl 56 3 ft agl
Info Average pitch angle 2.0 °1.2 ° min to max 2.9 ° 1.4 1.8 °
07515022530037545052560067575001123344657Runway Distance mLanding Height ft075150225300375450525600675750-30-24-18-12-60612182430Runway Distance mRunway Width m
Arrival Touchdown 96.79Touchdown point was 217 m beyond the touchdown zone. Touchdown speed at 129 kt was a little fast. Touchdown rate was fair at -257 fpm. Runway touchdown alignment was perfect. Local weather - Temperature 12 °C. Wind 2 kt at 20 °. Crosswind: 1 kt Headwind: 1 kt.
ScoreDescriptionStartProfileEnd
98 % Touchdown rate was -257 fpm.
81 % Touchdown distance was 634 mTarget 457 m
100 % Speed at touchdown 129 ktTarget below 128 kt
100 % Runway alignment max 0.98 m left0.93 m left 0.98 0.84 m
100 % Steepest bank angle 0.2 °0.0 ° min to max 0.2 ° 0.1 0.2 °
100 % Peak g force 1.24 g0.98 g min to max 1.24 g 0.98 1.13 g
100 % Landing Bounce
Info Average speed 129 kt128 kt min to max 129 kt 129 128 kt
Info Average pitch angle 1.5 °1.0 ° min to max 1.8 ° 1.8 1.0 °
Arrival Rollout 100.00Total landing distance 1,786 m, 46 % of runway. Runway rollout alignment was perfect.
ScoreDescriptionStartProfileEnd
100 % Landing distance 1,786 m46 % of runway.
100 % Runway alignment max 0.81 m left0.81 m left to 0.65 m right 0.69 -0.59 m
100 % Average g force 1.01 g0.97 g min to max 1.11 g 1.11 1.00 g
Info Average speed 113 kt69 kt min to max 127 kt 127 69 kt
Info Average pitch angle -0.6 °-1.3 ° min to max 0.9 ° 0.9 -0.8 °
Info Average bank angle 0.1 °0.0 ° min to max 0.2 ° 0.2 0.1 °
Runway Exit Exiting runway, average speed 40 kt
ScoreDescriptionStartProfileEnd
Info Average speed 39 kt25 kt min to max 62 kt 62 25 kt
Info Average pitch angle -0.9 °-1.2 ° min to max -0.6 ° -1.0 -1.2 °
Info Average bank angle 0.1 °0.0 ° min to max 0.4 ° 0.0 0.3 °
Info Average g force 1.00 g0.98 g min to max 1.00 g 0.98 0.99 g

Events

Info Landing Lights Switched Off 13 ft agl · 31 kt
Info Strobe Lights Switched Off 13 ft agl · 31 kt
Arrival Taxi 100.00Taxiing to the parking from the runway took 3 minutes and covered 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 19 kt4 kt min to max 24 kt 24 4 kt
100 % Average speed turning corners 15 ktmax 21 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle -0.9 °-1.2 ° min to max -0.8 ° -1.2 -1.0 °
Info Average bank angle 0.1 °0.0 ° min to max 0.3 ° 0.2 0.0 °

Events

Info Flaps Position 5 13 ft agl · 24 kt
Info Flaps Position 4 13 ft agl · 24 kt
Info Flaps Position 3 13 ft agl · 22 kt
Info Flaps Position 2 13 ft agl · 21 kt
Info Flaps Position 1 13 ft agl · 21 kt
Info Flaps Fully Retracted 13 ft agl · 21 kt

Takeoff from EHAM 24

Taxi out

LightsOk
All on
Taxi speed100.00
17kt peak

The roll

Takeoff roll100.00
999m29 %
Runway alignment100.00
1.55m R
Rotation speed100.00
143kttarget 132, 11 late

Rotated late

Rotation started at 143 kt, 11 kt after the 132 kt rotate speed.

The pull started after the rotate speed had gone by. Bring the airspeed into the scan as it approaches the rotate speed, so the pull starts on the number rather than when you notice it has passed.

Liftoff and climb

Liftoff
156ktat 5.8°
Rotation
3.1°/sover 2.0 s, gaining 13 kt
35 ft
171ktat 10.2°, 2.5 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
0.3°steepest
Gear up100.00
60ftfull marks to 400 ft
Climb 3 speed100.00
204kttarget 187

Plan view the roll down the 3,439 m runway.

Rolled from 120 m in, never more than 1.1 m off the centreline. Airborne 29 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length.

1,0002,0003,000THRESHOLDLEFT ↑RIGHT ↓75 %widest 1.13 m RROLL 120 M INAirborne 1,003 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,003 m of 3,439 m · 29 %
Behind the start of the roll, 120 mTakeoff roll, 883 m Left ahead, 2,437 m

Side view from the start of the roll to the end of Climb 3 at 986 ft.

Reached 35 ft with 2,220 m of runway left; gear up at 60 ft, inside the 400 ft that gets full marks; then climbing at 3,120 fpm on average to 986 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3204 kt avgtarget 187THRESHOLDRUNWAY END6080100120KNOTS ALONG THE ROLLnose up on the runway · 155 m · 2.0 sRotate 143 kttarget 132Liftoff 156 ktGear up 60 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 187210 kt14070020°10°0°nose up on the runway · 155 m · 2.0 sROTATELIFTOFFGEAR UPtarget 132held 11.9°5.8° off · 3.1°/s10° at 35 ftAIRSPEEDPITCH02040 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2.1 to 3.1° a second, the middle half of rotation rates flown by other Boeing 777-200ER pilots over the last 180 days (72 takeoffs); the grey pair are 2 to 3° a second, the rates airliners are rotated at. A trace steeper than both green lines is a faster rotation than most, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 12.1°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 12.1°ROTATELIFTOFF35 FT3°/s3.1°/s5.8° off · 3.1°/s2.1°/s2°/s10° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5 sseconds from rotation
PitchRotation began2.1 to 3.1°/s, other Boeing 777-200ER pilots2 to 3°/s from rotation, airlinersTail strikeNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate680 fpm800 fpm
On glideslope3.0°2.9°
On centreline0.0° off0.0° off
On speed+3.9 kt+4.0 kt
Wings level0° bank1° bank

When the approach was stable

Every check met from 4 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to LIMC 35R

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 40 ft below the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,2906743442121,000 ft gate7 of 71,032 ft · 135 kt500 ft gate7 of 7520 ft · 135 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 31× larger than distances along the final.

Inside the 1° band all the way from 4 nm, never more than 12 m off the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR30 m L030 m RLEFT ↑RIGHT ↓1° BAND5 m L11 m R5 m L0 m L2 m L0 m L
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 33 kt fast at the 1,000 ft gate, closing to 20 at 500 ft and 10 at the threshold.

Inside the speed band all the way, between +3 kt and +5 kt on the approach speed of 131 kt.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

120140160180 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 131+4 kt+4 kt+4 kt+4 kt+5 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on LIMC 35R

Over the threshold

Threshold height98.49
55ft
Threshold speed100.00
135kttarget 131, 4 fast
Centreline offset100.00
0.98m L
Bank100.00
0.7°steepest
Flare99.27

The flare tracked the target profile closely

The aircraft floated down the runway before touching. Touchdown was 634 m past the threshold. Threshold speed was not the cause here - hold the aim point on the approach and let the aircraft settle rather than holding it off, and the touchdown comes back to the numbers.

Touchdown

Past threshold80.63
634m
Centreline100.00
0.98m L
Speed100.00
129kttarget 128, 1 fast
Touchdown rate98.49
-257fpm
Impact100.00
1.24G
BouncesOk
None
Bank100.00
0.2°as the wheels touched

Rollout

Rollout distance100.00
1,110m45 % used
Rollout alignment100.00
0.81m L

Taxi in

LightsOk
All set
Taxi speed100.00
24kt peak15 kt in turns

Side view — the last 1,867 m of the approach.

Crossed the threshold at 55 ft, close to the 50 ft target; began the flare at 16 ft. Touched down 634 m in, 330 m past the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,867 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

55 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 16 ft · −304 fpm · 2.7° · 135 ktdescent slowed at 9 ft · −193 fpm · 2.5°−256 fpm · 1.8° nose up · 129 kt Ideal — 50 ft, down at 305 m This flight — 55 ft, down at 634 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 300 fpm at the flare to 260 fpm at touchdown. The nose went down 0.9° on the way down. Into the flare at 135 kt, 4 kt over the 131 kt approach speed, and 129 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−256 fpm at touchdown1.8° at touchdown, −0.9° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,867 m of the 3,906 m runway, to the same scale as the side view.

Touched down on the centreline, and stayed within 1 m of it down the rollout. No crosswind: nothing to correct for. Touched down straight, wings level.

Wind 020° at 2 kt · 1 kt head · 0 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ FULL SCORE TO 503 M 634 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

Touched down 634 m past the threshold — beyond the full-score zone. The arrival was smooth.

Runway used 1,745 m of 3,906 m · 45 %
In the air over the runway, 634 mRollout, 1,110 m Left over, 2,161 m

The stop — touchdown to taxi speed.

From 128 kt at touchdown to taxi speed (30 kt) in 43 s, an average deceleration of 0.12 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 1,218 m30 kt · 1,643 mtouchdown1,709 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Flight narrative

The Boeing 777-200ER aircraft took off from runway 24 at EHAM Amsterdam Airport Schiphol on a beautiful day with perfect weather conditions. The takeoff distance of 871 meters was 27% of the total runway length, and the liftoff speed was an impressive 156 knots. The temperature was a comfortable 15 degrees Celsius, with zero wind speed and direction, making it an ideal takeoff conditions.

As the aircraft climbed out of Schiphol, it began its ascent from 1,069 feet above sea level to 36,874 feet, an increase of 35,805 feet in just 15 minutes. This steep climb was achieved while covering a distance of 97 nautical miles. The aircraft then entered into a level cruise, starting 2 miles southwest of EDLE Essen Mülheim Airport Essen-Mulheim, Germany, and flying at a steady altitude for 35 minutes while covering an additional 271 nautical miles.

As the aircraft approached the European continent, it began its descent from 37,320 feet above sea level to 6,213 feet, a decrease of 31,107 feet in just 17 minutes. This significant descent covered a distance of 104 nautical miles. After briefly leveling out 2 miles northwest of Zerbolo, Italy, the aircraft began its next descent from 6,204 feet above sea level to 4,753 feet in just 3 minutes, covering a short distance of 6 nautical miles.

The aircraft entered into another level cruise, this time starting 1 mile north of Ferrera Erbognone, Italy, for 3 minutes and covering 13 nautical miles. However, the final descent of the day began over Cassolnovo, Italy, where the aircraft descended from 4,033 feet above sea level to 1,995 feet, a decrease of 2,038 feet in 4 minutes, covering a distance of 12 nautical miles.

With its final approach path set for runway 35R at LIMC Milan Malpensa International Airport from the south, heading 349.0 degrees, the aircraft flew for 4 nautical miles at 1,261 feet above ground level. The landing on runway 35R, which was 2,977 meters long, was good, with a threshold height and speed within acceptable limits.

However, the touchdown speed was a little fast at 129 knots, and the touchdown rate was fair at -239 feet per minute. Despite this, the runway touchdown alignment was very good. The total landing distance was 1,791 meters, covering 60% of the runway. The aircraft taxied to the parking area from the runway in just 3 minutes, with a distance of less than 1 nautical mile traveled.

The total flight distance was 519 nautical miles, with a total flight time of 1 hour and 31 minutes. The aircraft used a significant amount of fuel, with 8,601 kilograms being consumed during the flight.

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
