ENGM
Oslo, Norway
Runway 19R
Elevation669 ft asl
Weight279,001 kg
Fuel24,187 kg
Wind140° · 3 kn · 2 kn cross

Flight Score

98.04 %
ESGG
Göteborg, Sweden
Runway 21
Elevation489 ft asl
Weight274,934 kg
Fuel19,508 kg
Wind120° · 3 kn · 3 kn cross
10 Oct 2024 0:46 168 nm Boeing 747-8 4,679 kg
Departure Score
100.00 %
Enroute Score
100.00 %
Arrival Score
94.11 %

What went well

Touched down at -122 fpm — a soft arrival
Flare on profile — 100 %
1.06 G at touchdown — inside band

What held you back

Arrival Approach — GPWS warning; 1,000 ft gate 86 %, 500 ft gate 86 %, −0.95 points
Arrival Landing — Threshold height at 73 ft agl was well above target at 60 %, −0.67 points
Arrival Touchdown — Touchdown distance was 713 m at 72 %, −0.28 points

Next time

Arrival

Steepen the descent on final to rejoin the glideslope, aiming to cross the threshold at 50 ft.

What happened: The approach drifted above the glideslope, carrying the aircraft across the threshold at 73 ft against the 50 ft target. Crossing the threshold high like this usually carries the touchdown point long.

Watch for: Watch radio altitude against 50 ft on short final to confirm the glidepath is recaptured before the threshold.

See Arrival ApproachArrival LandingArrival Touchdown

Preparing for a stable approach will give you time to decide on whether to attempt the landing or going around. Too much altitude with a high sink rate will result in carrying too much speed onto the runway. Configuring flaps and the gear late also won't help the speed decay.

Read more in The Stabilised Approach

Start to finish · 16 stages, 13 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 9 minutes and covered 2 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 14 kt0 kt min to max 18 kt 0 11 kt
100 % Average speed turning corners 0 ktmax 0 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle -0.7 °-1.2 ° min to max -0.0 ° -0.6 -0.8 °
Info Average bank angle 0.1 °0.0 ° min to max 0.6 ° 0.1 0.0 °

Events

Info Battery Master On 15 ft agl
Info Engine 1 Started 15 ft agl
Info Engine 4 Started 15 ft agl
Info Beacon Lights Switched On 15 ft agl
Info Navigation Lights Switched On 15 ft agl
Info Autopilot Flight Director Activated 15 ft agl
Info Autopilot Yaw Damper Activated 15 ft agl
Info Landing Gear Down 15 ft agl
Info Pitot Heat Switched On 15 ft agl
Info Engine 2 Started 15 ft agl
Info Engine 3 Started 15 ft agl
Info Taxi Lights Switched On 15 ft agl
Info Parking Brake On 15 ft agl
Info Flaps Position 2 15 ft agl
Info Flaps Position 3 15 ft agl
Info Parking Brake Off 15 ft agl
Info Runway Surface Conditions 15 ft agl · 10 kt
Info Autopilot Vertical Hold Activated 15 ft agl · 13 kt
Info Runway Surface Conditions 15 ft agl · 16 kt
Info Landing Lights Switched On 15 ft agl · 16 kt
Info Strobe Lights Switched On 15 ft agl · 16 kt
Departure Runway Entry Entering runway 19R at ENGM Oslo Airport, Gardermoen, Average speed was 13 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 12 kt12 kt min to max 12 kt 12 12 kt
Info Average pitch angle -0.8 °-0.8 ° min to max -0.8 ° -0.8 -0.8 °
Info Average bank angle 0.0 °0.0 ° min to max 0.1 ° 0.0 0.0 °
Info Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Departure Roll 100.00Departure roll runway 19R at ENGM Oslo Airport, Gardermoen. Takeoff distance 1,098 m 31 % of runway. Rotation speed was 135 kt. Local weather - Temperature 12 °C. Wind 3 kt at 140 °. Crosswind: 2 kt Headwind: 2 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 1,098 m31 % of runway
100 % Rotation speed was 135 ktTarget 142 kt
100 % Runway alignment max 0.54 m right0.45 m left to 0.54 m right 0.00 0.15 m
100 % Average g force 1.00 g1.00 g min to max 1.12 g 1.00 1.12 g
100 % Takeoff Bounce
Info Average pitch angle -0.0 °-0.8 ° min to max 10.7 ° -0.8 10.7 °
Info Average bank angle 0.1 °0.0 ° min to max 0.3 ° 0.0 0.3 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 19R ENGM Oslo Airport, Gardermoen.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.0 °0.0 ° min to max 0.1 ° 0.0 0.1 °
100 % Average speed 153 kt146 kt min to max 160 kt 146 160 kt
100 % Steepest bank angle 0.7 °0.3 ° min to max 0.7 ° 0.3 0.4 °
100 % Average g force 1.09 g0.96 g min to max 1.23 g 1.13 1.05 g
Info Average VSI 598 fpm126 fpm min to max 937 fpm 126 937 fpm
Info Average altitude 19 ft agl0 ft agl min to max 41 ft agl 0 41 ft agl
Info Average pitch angle 10.4 °9.5 ° min to max 11.6 ° 10.8 9.8 °
Departure Climb 2 100.00Departure climb to 400 ft agl from 19R ENGM Oslo Airport, Gardermoen.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.1 °0.1 ° min to max 0.2 ° 0.1 0.2 °
100 % Average speed 168 kt161 kt min to max 192 kt 161 192 kt
100 % Steepest bank angle 0.4 °0.0 ° min to max 0.4 ° 0.4 0.3 °
100 % Average g force 1.04 g0.98 g min to max 1.14 g 1.05 1.04 g
Info Average VSI 1,286 fpm951 fpm min to max 2,620 fpm 951 2,620 fpm
Info Average altitude 88 ft agl42 ft agl min to max 350 ft agl 42 350 ft agl
Info Average pitch angle 9.7 °9.4 ° min to max 10.7 ° 9.8 10.4 °

Events

Info Autopilot Heading Hold Activated 69 ft agl · 166 kt
Info Landing Gear Up 69 ft agl · 166 kt
Info Flaps Position 2 289 ft agl · 192 kt
Departure Climb 3 100.00Departure climb to 1,000 ft agl from 19R ENGM Oslo Airport, Gardermoen.
ScoreDescriptionStartProfileEnd
100 % Climb speed 203 kt194 kt min to max 211 ktTarget 202 kt, 1 kt fast 194 211 kt
100 % Steepest bank angle 0.2 °0.0 ° min to max 0.2 ° 0.2 0.0 °
100 % Average g force 1.06 g1.01 g min to max 1.08 g 1.01 1.08 g
100 % Landing gear up at 44 ft aglTarget by 400 ft agl
Info Heading variation 0.2 °0.2 ° min to max 0.2 ° 0.2 0.2 °
Info Average VSI 3,509 fpm2,770 fpm min to max 4,454 fpm 2,770 4,454 fpm
Info Average altitude 650 ft agl399 ft agl min to max 953 ft agl 399 953 ft agl
Info Average pitch angle 12.1 °10.4 ° min to max 14.1 ° 10.4 14.1 °

Events

Info Flaps Position 1 909 ft agl · 216 kt
Enroute Climb 100.00Enroute climb started overhead ENGM Oslo Airport, Gardermoen Oslo (Viken, Norway). Climbing from 1,725 ft asl to 26,257 ft asl, an increase of 24,532 ft in 8 minutes and covering 50 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 294 kt212 kt min to max 323 kt 212 299 kt
100 % Steepest bank angle 31.3 °0.0 ° min to max 31.3 ° 0.0 3.0 °
99.98 % Average g force 1.04 g0.71 g min to max 1.36 g 1.03 1.00 g
Info Average VSI 3,113 fpm-637 fpm min to max 6,542 fpm 4,672 19 fpm
Info Average altitude 14,470 ft asl1,725 ft asl min to max 26,257 ft asl 1,725 26,257 ft asl
Info Average pitch angle 6.2 °0.7 ° min to max 19.2 ° 14.0 1.0 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Master Switched On 1,316 ft agl · 222 kt
Info Flaps Fully Retracted 1,825 ft agl · 235 kt
Info Autopilot AutoThrottle Arm Armed 1,943 ft agl · 238 kt
Info Autopilot Airspeed Hold Activated 2,032 ft agl · 241 kt
Info Autopilot Airspeed Hold Deactivated 2,554 ft agl · 263 kt
Info Autopilot Vertical Hold Deactivated 2,554 ft agl · 263 kt
Info Autopilot RPM Hold Activated 2,554 ft agl · 263 kt
Info Landing Lights Switched Off 10,061 ft agl · 301 kt
Info Taxi Lights Switched Off 10,157 ft agl · 304 kt
Info Autopilot Airspeed Hold Activated 25,386 ft agl · 445 kt
Info Autopilot Vertical Hold Activated 25,386 ft agl · 445 kt
Info Autopilot RPM Hold Deactivated 25,386 ft agl · 445 kt
Enroute Level 100.00Enroute level cruise started 1 mile south east of Toecksfors (Vaermland County, Sweden) and lasted 3 minutes, covering 22 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±1,813 ft of 26,263 ft asl26,248 ft asl min to max 26,285 ft asl 26,261 26,268 ft asl
100 % Average speed 298 kt298 kt min to max 299 kt 299 298 kt
100 % Steepest bank angle 27.3 °0.1 ° min to max 27.3 ° 3.5 2.5 °
100 % Average g force 1.04 g0.93 g min to max 1.16 g 0.99 1.01 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 1.2 °0.8 ° min to max 1.8 ° 1.0 1.0 °
Enroute Descent 100.00Enroute descent started 10 miles west of Bengtsfors (Vaestra Goetaland County, Sweden). Descent from 26,273 ft asl to 806 ft asl, a decrease of 25,467 ft in 18 minutes and covering 86 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 217 kt144 kt min to max 298 kt 298 147 kt
100 % Steepest bank angle 27.8 °0.0 ° min to max 27.8 ° 4.8 3.6 °
100 % Average g force 1.02 g0.87 g min to max 1.24 g 1.00 0.91 g
Info Average VSI -1,448 fpm-2,165 fpm min to max 9 fpm 9 -1,847 fpm
Info Average altitude 9,030 ft asl806 ft asl min to max 26,276 ft asl 26,273 806 ft asl
Info Average pitch angle -0.1 °-2.0 ° min to max 4.5 ° 1.1 -1.6 °
Info Turn coordination 00 min to max 0 0 0

Events

Fail GPWS Warning Activated 944 ft agl · 149 kt
Fail GPWS Warning Activated 791 ft agl · 148 kt
Fail GPWS Warning Activated 517 ft agl · 150 kt
Info Autopilot Airspeed Hold Deactivated 25,709 ft agl · 443 kt
Info Autopilot Vertical Hold Deactivated 16,252 ft agl · 360 kt
Info Autopilot RPM Hold Activated 16,252 ft agl · 360 kt
Info Autopilot Airspeed Hold Activated 16,074 ft agl · 359 kt
Info Autopilot Vertical Hold Activated 16,074 ft agl · 359 kt
Info Autopilot RPM Hold Deactivated 16,074 ft agl · 359 kt
Info Landing Lights Switched On 10,358 ft agl · 283 kt
Info Taxi Lights Switched On 10,281 ft agl · 283 kt
Info Flaps Position 1 5,176 ft agl · 225 kt
Info Flaps Position 2 4,363 ft agl · 227 kt
Info Flaps Position 3 3,255 ft agl · 206 kt
Info Autopilot Approach Mode Activated 3,181 ft agl · 203 kt
Info Autopilot Heading Hold Deactivated 3,164 ft agl · 203 kt
Info Landing Gear Down 3,096 ft agl · 201 kt
Info Flaps Position 4 2,436 ft agl · 182 kt
Info Flaps Position 5 2,027 ft agl · 162 kt
Info Flaps Position 6 1,698 ft agl · 157 kt
Info GPWS Warning Deactivated 841 ft agl · 149 kt
Info GPWS Warning Deactivated 715 ft agl · 148 kt
Info Autopilot Airspeed Hold Deactivated 599 ft agl · 148 kt
Info Autopilot AutoThrottle Arm Disarmed 599 ft agl · 148 kt
Info Autopilot Master Switched Off 550 ft agl · 149 kt
Go-around Go-Around runway 21 at ESGG Göteborg Landvetter Airport at 220 ft agl.
ScoreDescriptionStartProfileEnd
100 % Average speed 145 kt137 kt min to max 155 kt 155 137 kt
100 % Steepest bank angle 12.2 °0.2 ° min to max 12.2 ° 1.9 7.4 °
100 % Average g force 0.99 g0.82 g min to max 1.24 g 1.13 0.91 g
Info Average altitude 539 ft agl220 ft agl min to max 780 ft agl 220 780 ft agl
Info Average pitch angle 10.5 °6.5 ° min to max 14.1 ° 7.2 6.5 °
Arrival Approach 85.71Final approach to runway 21 at ESGG Göteborg Landvetter Airport. Descent from 404 ft agl to 119 ft agl in 95 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
50 % Sink ratefailed at one of the two gates
50 % On glideslopefailed at one of the two gates
100 % On centrelinepassed at both gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates

Events

Fail GPWS Warning Activated 517 ft agl · 150 kt
Fail GPWS Warning Activated 934 ft agl · 143 kt
Fail GPWS Warning Activated 705 ft agl · 147 kt
Info Autopilot Master Switched Off 550 ft agl · 149 kt
Info GPWS Warning Deactivated 394 ft agl · 158 kt
Info GPWS Warning Deactivated 911 ft agl · 148 kt
Info Autopilot Vertical Hold Deactivated 900 ft agl · 153 kt
Info GPWS Warning Deactivated 684 ft agl · 146 kt
Arrival Landing 89.91Landing on runway 21 at ESGG Göteborg Landvetter Airport, runway length 3,287 m. Threshold height at 73 ft agl was well above target. Threshold speed was good at 140 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 140 kt. Target 138 kt
60 % Threshold height at 73 ft agl was well above target.Target 50 ft agl
100 % The flare tracked the target profile exactly. The aircraft floated down the runway before touching. Touchdown was 713 m past the threshold. Threshold speed was not the cause here - hold the aim point on the approach and let the aircraft settle rather than holding it off, and the touchdown comes back to the numbers.
100 % Runway alignment max 6.23 m left6.23 m left to 0.51 m left 0.51 6.23 m
100 % Steepest bank angle 0.9 °0.0 ° min to max 0.9 ° 0.1 0.0 °
100 % Peak g force 1.09 g0.96 g min to max 1.09 g 0.98 1.03 g
Info Average speed 136 kt131 kt min to max 140 kt 140 131 kt
Info Average VSI -451 fpm-617 fpm min to max -190 fpm -529 -190 fpm
Info Average altitude 33 ft agl7 ft agl min to max 73 ft agl 73 7 ft agl
Info Average pitch angle 5.7 °3.8 ° min to max 7.6 ° 4.0 6.8 °
07515022530037545052560067575082590001429435872Runway Distance mLanding Height ft075150225300375450525600675750825900-25-20-15-10-50510152025Runway Distance mRunway Width m
Arrival Touchdown 95.80Touchdown point was 299 m beyond the touchdown zone. Touchdown speed at 131 kt was good. Touchdown rate was smooth at -122 fpm. Runway touchdown position was slightly misaligned by 6.8 m from centreline. Local weather - Temperature 11 °C. Wind 3 kt at 120 °. Crosswind: 3 kt Headwind: 0 kt.
ScoreDescriptionStartProfileEnd
100 % Touchdown rate was -122 fpm.
72 % Touchdown distance was 713 mTarget 457 m
100 % Speed at touchdown 131 ktTarget below 138 kt
100 % Runway alignment max 6.81 m left6.51 m left 6.23 6.81 m
100 % Steepest bank angle 0.4 °0.0 ° min to max 0.4 ° 0.0 0.3 °
100 % Peak g force 1.06 g0.98 g min to max 1.06 g 1.03 0.98 g
100 % Landing Bounce
Info Average speed 130 kt130 kt min to max 131 kt 131 130 kt
Info Average pitch angle 6.7 °6.6 ° min to max 6.8 ° 6.8 6.7 °
Arrival Rollout 99.14Total landing distance 1,689 m, 51 % of runway. Runway rollout alignment was slightly misaligned by 8.1 m from centreline.
ScoreDescriptionStartProfileEnd
100 % Landing distance 1,689 m51 % of runway.
98 % Runway alignment max 8.10 m left8.10 m left to 0.00 m left 8.10 4.24 m
100 % Average g force 1.01 g0.93 g min to max 1.09 g 0.98 1.02 g
Info Average speed 119 kt71 kt min to max 132 kt 132 71 kt
Info Average pitch angle 3.6 °-1.4 ° min to max 6.7 ° 6.7 -0.4 °
Info Average bank angle 0.4 °0.0 ° min to max 0.7 ° 0.5 0.1 °
Runway Exit Exiting runway, average speed 25 kt
ScoreDescriptionStartProfileEnd
Info Average speed 24 kt12 kt min to max 63 kt 63 12 kt
Info Average pitch angle -0.4 °-1.0 ° min to max 0.1 ° -0.3 0.0 °
Info Average bank angle 0.1 °0.0 ° min to max 0.3 ° 0.3 0.0 °
Info Average g force 1.00 g0.99 g min to max 1.01 g 1.01 1.00 g

Events

Info Flaps Fully Retracted 15 ft agl · 23 kt
Info Landing Lights Switched Off 15 ft agl · 20 kt
Info Strobe Lights Switched Off 15 ft agl · 20 kt
Arrival Taxi 100.00Taxiing to the parking from the runway took 6 minutes and covered 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 14 kt0 kt min to max 21 kt 11 2 kt
100 % Average speed turning corners 10 ktmax 12 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle -0.7 °-1.4 ° min to max 0.0 ° 0.0 -0.7 °
Info Average bank angle 0.2 °0.0 ° min to max 0.4 ° 0.0 0.0 °

Takeoff from ENGM 19R

Taxi out

LightsOk
All on
Taxi speed100.00
18kt peak

The roll

Takeoff roll100.00
1,098m31 %
Runway alignment100.00
0.54m R
Rotation speed100.00
135kttarget 142, 7 early

Rotated early, and the nose came up quickly

Rotation started at 135 kt, 7 kt before the 142 kt rotate speed, and the nose then rose at 4.6° a second, faster than the 2 to 3° a second airliners use.

Early and quick together is the classic tail-strike setup: the nose reaches its liftoff attitude before the aircraft has the speed to fly. Wait for the rotate speed, then pull smoothly at the normal rate for this aircraft and let it lift off at its own attitude.

Liftoff and climb

Liftoff
146ktat 10.8°
Rotation
4.6°/sover 2.4 s, gaining 11 kt
35 ft
159ktat 9.8°, 2.4 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
0.7°steepest
Gear up100.00
44ftfull marks to 400 ft
Climb 3 speed100.00
203kttarget 202

Plan view the roll down the 3,589 m runway.

Rolled from 137 m in, never more than 0.8 m off the centreline. Airborne 30 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

1,0002,0003,000THRESHOLDLEFT ↑RIGHT ↓CROSS2 kn75 %widest 0.80 m LROLL 137 M INAirborne 1,101 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,101 m of 3,589 m · 31 %
Behind the start of the roll, 137 mTakeoff roll, 964 m Left ahead, 2,488 m

Side view from the start of the roll to the end of Climb 3 at 954 ft.

Reached 35 ft with 2,291 m of runway left; gear up at 44 ft, inside the 400 ft that gets full marks; then climbing at 2,530 fpm on average to 954 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3203 kt avgtarget 202THRESHOLDRUNWAY END6080100120KNOTS ALONG THE ROLLnose up on the runway · 179 m · 2.4 sRotate 135 kttarget 142Liftoff 146 ktGear up 44 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 202240 kt16080020°10°0°nose up on the runway · 179 m · 2.4 sROTATELIFTOFFtarget 142held 10.2°10.8° off · 4.6°/s10° at 35 ftAIRSPEEDPITCH02040 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2 to 3° a second, the rates airliners are rotated at: a trace steeper than both is a faster rotation, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 12.1°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 12.1°ROTATELIFTOFF35 FT10.8° off · 4.6°/s3°/s2°/s10° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5 sseconds from rotation
PitchRotation began2 to 3°/s from rotationTail strikeNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 85.716 of 7500 ft 85.716 of 7
Gear down
Landing flap
Sink rate2,410 fpm1,600 fpm
On glideslope1.4°3.0°
On centreline0.4° off0.2° off
On speed+7.4 kt+4.7 kt
Wings level8° bank1° bank

At the 1,000 ft gate: glideslope more than 1° off the runway's 3°.

At the 500 ft gate: sink rate more than 600 fpm beyond what the glideslope needed.

When the approach was stable

Every check met from 2.1 nm, about 670 ft above the runway, to the threshold, after the 1,000 ft gate and before the 500 ft gate. The last to settle was the centreline.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to ESGG 21

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Low from 4 nm to 2.9 nm (up to 1,040 ft under), then back on it to the threshold.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND3676823422011,000 ft gate6 of 7on glideslope466 ft · 145 kt500 ft gate6 of 7sink rate540 ft · 143 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 4× larger than distances along the final.

Inside the 1° band from 4 nm to 2.5 nm, then drifted 90 m right between 2.5 and 2.1 nm, then inside the band from 2.1 nm to the threshold.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR226 m L0226 m RLEFT ↑RIGHT ↓1° BAND5 m R54 m R5 m L2 m R36 m L9 m R
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 35 kt fast at the 1,000 ft gate, closing to 21 at 500 ft and 10 at the threshold.

Inside the speed band all the way, between −1 kt and +17 kt on the approach speed of 138 kt.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

140160180200 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 138+7 kt+12 kt+9 kt+10 kt+3 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on ESGG 21

Over the threshold

Threshold height59.62
73ft
Threshold speed100.00
140kttarget 138, 2 fast
Centreline offset100.00
6.23m L
Bank100.00
0.9°steepest
Flare100.00

The flare tracked the target profile exactly

The aircraft floated down the runway before touching. Touchdown was 713 m past the threshold. Threshold speed was not the cause here - hold the aim point on the approach and let the aircraft settle rather than holding it off, and the touchdown comes back to the numbers.

Touchdown

Past threshold72.00
713m
Centreline100.00
6.81m L
Speed100.00
130kttarget 138 or less
Touchdown rate100.00
-122fpm
Impact100.00
1.06G
BouncesOk
None
Bank100.00
0.4°as the wheels touched

Rollout

Rollout distance100.00
966m50 % used
Rollout alignment98.09
8.10m L

Taxi in

LightsOk
All set
Taxi speed100.00
21kt peak10 kt in turns

Side view — the last 1,801 m of the approach.

Crossed the threshold at 73 ft, 23 ft above the 50 ft target; began the flare at 37 ft. Touched down 713 m in, 408 m past the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,801 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

73 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 37 ft · −484 fpm · 5.3° · 138 ktdescent slowed at 0 ft · −122 fpm · 6.7°−122 fpm · 6.8° nose up · 131 kt Ideal — 50 ft, down at 305 m This flight — 73 ft, down at 713 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 480 fpm at the flare to 120 fpm at touchdown. The nose came up 1.5° on the way down. Into the flare at 138 kt, on the 138 kt approach speed, and 131 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−122 fpm at touchdown6.8° at touchdown, +1.4° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,801 m of the 3,287 m runway, to the same scale as the side view.

Touched down 6.8 m left of the centreline, and stayed about there down the rollout, 8.9 m left at the widest. Little crosswind (2 kt): nothing to correct for. Touched down with the nose 1° left of the track, wings level.

Wind 120° at 3 kt · 0 kt head · 2 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ CROSS 2 kn FULL SCORE TO 503 M 713 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

Touched down 713 m past the threshold — beyond the full-score zone. The arrival was smooth.

Runway used 1,679 m of 3,287 m · 51 %
In the air over the runway, 713 mRollout, 966 m Left over, 1,608 m

The stop — touchdown to taxi speed.

From 133 kt at touchdown to taxi speed (30 kt) in 28 s, an average deceleration of 0.20 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 1,074 m30 kt · 1,201 mtouchdown1,249 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Flight narrative

The flight in the Boeing 747-8 began with a 9-minute taxi from the parking area to the runway at ENGM Gardermoen. The departure roll took place on runway 19R, with a takeoff distance of 955 meters, covering 27% of the runway. The liftoff speed was 146 knots. The local weather at the time of departure was 11°C with a wind speed of 3 knots at 140°, including a 2 knot crosswind and headwind.

The enroute climb started over ENGM Gardermoen in Oslo, ascending from 1,725 feet above sea level to 26,267 feet, covering a distance of 56 nautical miles in 9 minutes. The enroute level cruise began 10 miles south of Toecksfors in Vaermland County, Sweden, lasting 2 minutes and covering 15 nm. The enroute descent started 9 miles west of Bengtsfors in Vaestra Goetaland County, Sweden, descending from 26,272 feet to 2,231 feet over a 17-minute period, covering 80 nm.

A go-around was executed on runway 21 at ESGG Landvetter at 778 feet above ground level. The landing took place on the same runway, with a length of 3,287 meters. The height at the threshold was 73 feet above ground level, with a speed of 140 knots. The touchdown occurred 679 meters from the threshold, with a speed of 131 knots and a vertical speed indicator reading of -190 ft/m. The local weather at the time of landing was 13°C with a wind speed of 3 knots at 120°, including a 3 knot crosswind.

The total landing distance was 1,689 meters, covering 51% of the runway. Finally, taxiing from the runway to the parking area took 7 minutes and covered 1 nautical mile. The total flight distance was 162 nm, with a duration of 56 minutes, and 4,679 kg of fuel was used during the flight.

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
