KELP
El Paso, United States
Runway 08R
Elevation3,924 ft asl
Weight36,761 kg
Fuel3,014 kg
Wind100° · 15 kn · 2 kn cross

Flight Score

97.60 %
KLAX
Los Angeles, United States
Runway 25L
Elevation125 ft asl
Weight34,880 kg
Fuel1,073 kg
Wind250° · 11 kn · 2 kn cross
5 Dec 2024 3:14 688 nm Douglas DC-6B 1,940 kg
Departure Score
98.67 %
Enroute Score
100.00 %
Arrival Score
94.14 %

What went well

Touched down at -180 fpm — a soft arrival
Touchdown 320 m in — inside the full-score zone
Threshold crossed at 39 ft and 89 kt — both inside band

What held you back

Arrival Approach — 1,000 ft gate 71 %, 500 ft gate 86 %, −1.43 points
Departure Roll — Landing Lights at 0 %, −0.44 points
Arrival Rollout — Runway alignment max 11.94 m left at 89 %, −0.33 points

Next time

Departure

Hold the nose down until the speed reaches 108 kt, then rotate.

What happened: You started the rotation at 94 kt, 14 kt before the 108 kt rotation speed.

Watch for: Airspeed indicator: 108 kt at rotation

See Departure Roll

Arrival

Make small rudder corrections against a fixed point at the far end of the runway to stop the drift as soon as it starts in the flare.

What happened: On the landing you drifted 12 m off the centreline, and that kind of lateral drift usually carries through to a touchdown point 12 m off centreline and into a rollout that is still skewed off the runway centreline.

Watch for: Heading indicator: track straight down the extended runway centreline through touchdown and rollout.

See Arrival LandingArrival TouchdownArrival Rollout

Preparing for a stable approach will give you time to decide on whether to attempt the landing or going around. Too much altitude with a high sink rate will result in carrying too much speed onto the runway. Configuring flaps and the gear late also won't help the speed decay.

Read more in The Stabilised Approach

Start to finish · 22 stages, 20 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 11 minutes and covered 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 6 kt0 kt min to max 10 kt 0 2 kt
100 % Average speed turning corners 0 ktmax 0 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle 1.4 °1.1 ° min to max 1.9 ° 1.7 1.9 °
Info Average bank angle 0.2 °0.0 ° min to max 0.4 ° 0.2 0.1 °

Events

Info Engine 4 Started 8 ft agl · 13 kt
Info Engine 2 Started 8 ft agl · 10 kt
Info Engine 1 Started 8 ft agl · 8 kt
Info Parking Brake Off 8 ft agl · 10 kt
Info Parking Brake On 8 ft agl · 11 kt
Info Parking Brake Off 8 ft agl · 11 kt
Departure Runway Entry Entering runway 08R at KELP El Paso International Airport, Average speed was 23 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 7 kt0 kt min to max 20 kt 6 20 kt
Info Average pitch angle 1.7 °1.4 ° min to max 1.8 ° 1.8 1.6 °
Info Average bank angle 0.0 °0.0 ° min to max 0.2 ° 0.0 0.0 °
Info Average g force 1.00 g0.99 g min to max 1.00 g 1.00 1.00 g

Events

Info Parking Brake On 8 ft agl · 21 kt
Info Flaps Position 1 8 ft agl · 14 kt
Info Flaps Position 2 8 ft agl · 14 kt
Info Flaps Position 3 8 ft agl · 14 kt
Info Parking Brake Off 8 ft agl · 15 kt
Departure Roll 93.35Departure roll runway 08R at KELP El Paso International Airport. Takeoff distance 965 m 35 % of runway. Rotation speed was 94 kt. Local weather - Temperature 17 °C. Wind 17 kt at 99 °. Crosswind: 2 kt Headwind: 17 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 965 m35 % of runway
92 % Rotation speed was 94 ktTarget 108 kt
100 % Runway alignment max 2.55 m right0.00 m left to 2.55 m right -1.15 -1.82 m
100 % Average g force 1.00 g0.97 g min to max 1.03 g 1.00 1.03 g
100 % Takeoff Bounce
Info Average pitch angle 1.8 °1.5 ° min to max 4.7 ° 1.6 4.7 °
Info Average bank angle 0.3 °0.0 ° min to max 0.6 ° 0.1 0.0 °

Events

Fail Landing Lights
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 08R KELP El Paso International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.1 °0.1 ° min to max 0.2 ° 0.1 0.1 °
100 % Average speed 105 kt97 kt min to max 112 kt 97 112 kt
100 % Steepest bank angle 2.5 °0.0 ° min to max 2.5 ° 0.0 0.1 °
100 % Average g force 1.04 g0.98 g min to max 1.10 g 1.03 0.99 g
Info Average VSI 447 fpm198 fpm min to max 649 fpm 198 649 fpm
Info Average altitude 18 ft agl0 ft agl min to max 48 ft agl 0 48 ft agl
Info Average pitch angle 5.7 °4.7 ° min to max 6.8 ° 4.7 6.5 °

Events

Info Landing Gear Up 34 ft agl · 117 kt
Departure Climb 2 100.00Departure climb to 400 ft agl from 08R KELP El Paso International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.0 °-0.2 ° min to max 0.1 ° 0.1 -0.2 °
100 % Average speed 114 kt107 kt min to max 142 kt 112 142 kt
100 % Steepest bank angle 2.5 °0.0 ° min to max 2.5 ° 0.3 0.4 °
100 % Average g force 0.97 g0.90 g min to max 1.12 g 1.00 1.02 g
Info Average VSI 631 fpm189 fpm min to max 984 fpm 656 645 fpm
Info Average altitude 140 ft agl52 ft agl min to max 409 ft agl 52 409 ft agl
Info Average pitch angle 6.1 °4.9 ° min to max 7.8 ° 6.7 5.9 °

Events

Info Flaps Position 2 238 ft agl · 127 kt
Info Flaps Position 1 251 ft agl · 129 kt
Info Flaps Fully Retracted 265 ft agl · 127 kt
Info Autopilot Master Switched On 319 ft agl · 132 kt
Info Autopilot Heading Hold Activated 319 ft agl · 132 kt
Info Autopilot Flight Director Activated 319 ft agl · 132 kt
Info Autopilot Nav1 Lock Activated 382 ft agl · 153 kt
Info Autopilot Heading Hold Deactivated 382 ft agl · 153 kt
Departure Climb 3 100.00Departure climb to 1,000 ft agl from 08R KELP El Paso International Airport.
ScoreDescriptionStartProfileEnd
100 % Climb speed 156 kt143 kt min to max 165 ktTarget 145 kt, 11 kt fast 143 164 kt
100 % Steepest bank angle 1.3 °0.0 ° min to max 1.3 ° 0.4 0.1 °
100 % Average g force 1.01 g0.96 g min to max 1.07 g 1.02 1.00 g
100 % Landing gear up at 26 ft aglTarget by 400 ft agl
Info Heading variation -0.4 °-0.6 ° min to max -0.2 ° -0.2 -0.6 °
Info Average VSI 1,137 fpm705 fpm min to max 1,688 fpm 705 1,688 fpm
Info Average altitude 678 ft agl421 ft agl min to max 1,003 ft agl 421 1,003 ft agl
Info Average pitch angle 5.7 °5.2 ° min to max 6.0 ° 5.9 5.8 °
Enroute Climb 100.00Enroute climb started 2 miles east of KELP El Paso International Airport El Paso (Texas, United States). Climbing from 4,985 ft asl to 7,935 ft asl, an increase of 2,950 ft in 2 minutes and covering 7 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 173 kt163 kt min to max 180 kt 163 180 kt
100 % Steepest bank angle 21.1 °0.0 ° min to max 21.1 ° 0.0 14.4 °
100 % Average g force 1.03 g0.90 g min to max 1.08 g 0.91 0.93 g
Info Average VSI 1,255 fpm275 fpm min to max 1,667 fpm 1,667 275 fpm
Info Average altitude 6,558 ft asl4,985 ft asl min to max 7,935 ft asl 4,985 7,935 ft asl
Info Average pitch angle 4.8 °0.4 ° min to max 6.1 ° 6.0 0.4 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Altitude Hold Activated 3,993 ft agl · 204 kt
Enroute Level 100.00Enroute level cruise started 3 miles south east of KELP El Paso International Airport El Paso (Texas, United States) and lasted 34 minutes, covering 143 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±897 ft of 7,980 ft asl7,901 ft asl min to max 8,030 ft asl 7,935 8,024 ft asl
100 % Average speed 206 kt180 kt min to max 212 kt 180 210 kt
100 % Steepest bank angle 20.4 °0.0 ° min to max 20.4 ° 14.6 0.2 °
100 % Average g force 1.00 g0.94 g min to max 1.11 g 0.94 1.01 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle -0.5 °-1.2 ° min to max 0.5 ° 0.0 -0.9 °

Events

Info Pitot Heat Switched On 4,169 ft agl · 234 kt
Enroute Climb 2 100.00Enroute climb started 5 miles north west of NM70 Rodeo Airport Rodeo (New Mexico, United States). Climbing from 8,021 ft asl to 9,378 ft asl, an increase of 1,356 ft in 2 minutes and covering 7 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 197 kt166 kt min to max 212 kt 212 166 kt
100 % Steepest bank angle 0.8 °0.0 ° min to max 0.8 ° 0.6 0.4 °
100 % Average g force 1.00 g0.98 g min to max 1.02 g 1.00 0.98 g
Info Average VSI 769 fpm-62 fpm min to max 2,125 fpm 55 1,414 fpm
Info Average altitude 8,394 ft asl8,019 ft asl min to max 9,378 ft asl 8,021 9,378 ft asl
Info Average pitch angle 1.7 °-0.8 ° min to max 4.9 ° -0.6 4.3 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Altitude Hold Deactivated 3,318 ft agl · 237 kt
Enroute Level 2 100.00Enroute level cruise started 12 miles west of NM70 Rodeo Airport Rodeo (New Mexico, United States) and lasted 9 minutes, covering 35 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±979 ft of 9,988 ft asl9,580 ft asl min to max 10,026 ft asl 9,580 10,004 ft asl
100 % Average speed 198 kt159 kt min to max 207 kt 162 205 kt
100 % Steepest bank angle 19.0 °0.0 ° min to max 19.0 ° 0.0 0.1 °
100 % Average g force 1.00 g0.74 g min to max 1.11 g 0.98 1.09 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle -0.2 °-1.3 ° min to max 4.5 ° 4.5 -0.4 °

Events

Info Autopilot Altitude Hold Activated 3,248 ft agl · 188 kt
Enroute Descent 100.00Enroute descent started 2 miles south of AZ14 Ammon Airport Willcox (Arizona, United States). Descent from 10,008 ft asl to 8,169 ft asl, a decrease of 1,838 ft in 3 minutes and covering 15 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 219 kt205 kt min to max 235 kt 205 231 kt
100 % Steepest bank angle 0.7 °0.0 ° min to max 0.7 ° 0.0 0.0 °
100 % Average g force 1.00 g0.88 g min to max 1.14 g 1.02 0.96 g
Info Average VSI -500 fpm-946 fpm min to max 86 fpm 10 -33 fpm
Info Average altitude 9,345 ft asl8,169 ft asl min to max 10,013 ft asl 10,008 8,169 ft asl
Info Average pitch angle -2.0 °-3.0 ° min to max 0.2 ° -0.6 -1.4 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Altitude Hold Deactivated 5,317 ft agl · 239 kt
Enroute Level 3 100.00Enroute level cruise started 2 miles south east of Benson (Arizona, United States) and lasted 100 minutes, covering 403 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±905 ft of 8,059 ft asl8,013 ft asl min to max 8,109 ft asl 8,109 8,070 ft asl
100 % Average speed 211 kt202 kt min to max 230 kt 230 213 kt
100 % Steepest bank angle 21.2 °0.0 ° min to max 21.2 ° 0.2 0.1 °
100 % Average g force 1.01 g0.88 g min to max 1.20 g 0.97 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle -0.7 °-2.4 ° min to max 0.3 ° -2.4 -0.8 °

Events

Info Autopilot Altitude Hold Activated 4,345 ft agl · 259 kt
Info Landing Lights Switched On 7,531 ft agl · 236 kt
Info Landing Lights Switched Off 7,531 ft agl · 236 kt
Info Landing Lights Switched On 7,420 ft agl · 236 kt
Info Landing Lights Switched Off 7,218 ft agl · 236 kt
Enroute Descent 2 100.00Enroute descent started 11 miles south west of San Clemente (California, United States). Descent from 8,070 ft asl to 6,260 ft asl, a decrease of 1,810 ft in 3 minutes and covering 12 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 210 kt205 kt min to max 213 kt 213 207 kt
100 % Steepest bank angle 20.4 °0.0 ° min to max 20.4 ° 0.0 0.6 °
100 % Average g force 1.04 g0.99 g min to max 1.07 g 1.00 1.00 g
Info Average VSI -826 fpm-1,044 fpm min to max 4 fpm -1 -635 fpm
Info Average altitude 7,187 ft asl6,260 ft asl min to max 8,070 ft asl 8,070 6,260 ft asl
Info Average pitch angle -2.5 °-2.9 ° min to max -0.7 ° -0.8 -2.2 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Altitude Hold Deactivated 8,060 ft agl · 234 kt
Enroute Level 4 100.00Enroute level cruise started 12 miles south west of Dana Point (California, United States) and lasted 12 minutes, covering 37 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±808 ft of 6,026 ft asl5,931 ft asl min to max 6,154 ft asl 6,154 5,931 ft asl
100 % Average speed 166 kt160 kt min to max 207 kt 207 161 kt
100 % Steepest bank angle 27.0 °0.0 ° min to max 27.0 ° 0.0 11.7 °
100 % Average g force 1.01 g0.91 g min to max 1.24 g 1.00 1.01 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 1.0 °-3.0 ° min to max 2.3 ° -2.2 -3.0 °

Events

Info Autopilot Altitude Hold Activated 6,015 ft agl · 226 kt
Info Autopilot Nav1 Lock Deactivated 6,014 ft agl · 182 kt
Info Autopilot Heading Hold Activated 6,014 ft agl · 182 kt
Info Flaps Position 1 5,803 ft agl · 181 kt
Info Autopilot Altitude Hold Deactivated 5,774 ft agl · 181 kt
Info Flaps Position 2 5,766 ft agl · 177 kt
Enroute Descent 3 100.00Enroute descent started overhead La Mirada (California, United States). Descent from 5,916 ft asl to 1,865 ft asl, a decrease of 4,050 ft in 3 minutes and covering 9 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 164 kt135 kt min to max 181 kt 162 135 kt
100 % Steepest bank angle 26.8 °0.0 ° min to max 26.8 ° 11.0 0.6 °
100 % Average g force 1.04 g0.95 g min to max 1.17 g 1.03 0.98 g
Info Average VSI -1,158 fpm-2,270 fpm min to max 274 fpm -947 274 fpm
Info Average altitude 4,148 ft asl1,855 ft asl min to max 5,916 ft asl 5,916 1,865 ft asl
Info Average pitch angle -4.4 °-8.6 ° min to max 0.9 ° -3.0 0.7 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Position 3 4,587 ft agl · 193 kt
Info Flaps Position 4 4,545 ft agl · 196 kt
Info Flaps Position 5 3,399 ft agl · 193 kt
Info Flaps Position 6 3,360 ft agl · 194 kt
Info Flaps Position 5 2,034 ft agl · 150 kt
Info Flaps Position 4 2,016 ft agl · 149 kt
Info Autopilot Altitude Hold Activated 1,706 ft agl · 145 kt
Info Autopilot Heading Hold Deactivated 1,690 ft agl · 140 kt
Info Autopilot Approach Mode Activated 1,690 ft agl · 140 kt
Enroute Level 5 100.00Enroute level cruise started overhead Pico Rivera (California, United States) and lasted 5 minutes, covering 10 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±593 ft of 1,844 ft asl1,386 ft asl min to max 1,889 ft asl 1,870 1,386 ft asl
100 % Average speed 123 kt120 kt min to max 134 kt 134 123 kt
100 % Steepest bank angle 2.9 °0.0 ° min to max 2.9 ° 0.7 1.4 °
100 % Average g force 1.00 g0.90 g min to max 1.09 g 0.96 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 1.6 °-5.6 ° min to max 3.8 ° 0.4 -3.0 °

Events

Info Autopilot Nav1 Lock Activated 1,724 ft agl · 139 kt
Info Autopilot Approach Mode Deactivated 1,724 ft agl · 139 kt
Info Autopilot Nav1 Lock Deactivated 1,723 ft agl · 138 kt
Info Autopilot Heading Hold Activated 1,723 ft agl · 138 kt
Info Autopilot Nav1 Lock Activated 1,720 ft agl · 137 kt
Info Autopilot Heading Hold Deactivated 1,720 ft agl · 137 kt
Info Flaps Position 3 1,725 ft agl · 133 kt
Info Autopilot Nav1 Lock Deactivated 1,762 ft agl · 127 kt
Info Autopilot Approach Mode Activated 1,762 ft agl · 127 kt
Info Autopilot Altitude Hold Deactivated 1,754 ft agl · 126 kt
Info Flaps Position 4 1,722 ft agl · 129 kt
Info Flaps Position 5 1,711 ft agl · 130 kt
Arrival Approach 78.57Final approach to runway 25L at KLAX Los Angeles International Airport. Descent from 1,308 ft agl to 27 ft agl in 131 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
50 % Gear downfailed at one of the two gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
0 % On speedfailed at both gates
100 % Wings levelpassed at both gates

Events

Info Landing Gear Down 856 ft agl · 124 kt
Info Flaps Position 6 637 ft agl · 117 kt
Info Autopilot Master Switched Off 490 ft agl · 111 kt
Info Autopilot Approach Mode Deactivated 490 ft agl · 111 kt
Info Autopilot Flight Director Deactivated 490 ft agl · 111 kt
Arrival Landing 99.31Landing on runway 25L at KLAX Los Angeles International Airport, runway length 3,377 m. Good threshold height. Threshold speed was good at 89 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 89 kt. Target 86 kt
100 % Good threshold height.Target 50 ft agl
100 % Perfect landing flare
93 % Runway alignment max 12.35 m left12.35 m left to 10.17 m left 10.18 12.35 m
100 % Steepest bank angle 1.5 °0.0 ° min to max 1.5 ° 0.2 1.5 °
100 % Peak g force 1.08 g1.00 g min to max 1.08 g 1.04 1.02 g
Info Average speed 84 kt79 kt min to max 89 kt 89 79 kt
Info Average VSI -336 fpm-569 fpm min to max -204 fpm -569 -204 fpm
Info Average altitude 16 ft agl-1 ft agl min to max 40 ft agl 40 -1 ft agl
Info Average pitch angle 5.4 °3.2 ° min to max 7.5 ° 3.2 7.2 °
07515022530037501123344657Runway Distance mLanding Height ft075150225300375-30-24-18-12-60612182430Runway Distance mRunway Width m
Arrival Touchdown 97.69Touchdown distance was good at 320 m. Touchdown speed at 79 kt was good. Touchdown rate was good at -180 fpm. Runway touchdown position was misaligned by 12.4 m from centreline. Local weather - Temperature 14 °C. Wind 11 kt at 249 °. Crosswind: 2 kt Headwind: 10 kt.
ScoreDescriptionStartProfileEnd
100 % Touchdown rate was -180 fpm.
100 % Touchdown distance was 320 mTarget 457 m
100 % Speed at touchdown 79 ktTarget below 86 kt
85 % Runway alignment max 12.43 m left12.38 m left 12.35 12.43 m
100 % Steepest bank angle 1.5 °1.0 ° min to max 1.5 ° 1.5 1.0 °
100 % Peak g force 1.15 g1.02 g min to max 1.15 g 1.02 1.11 g
100 % Landing Bounce
Info Average speed 79 kt79 kt min to max 79 kt 79 79 kt
Info Average pitch angle 6.9 °6.5 ° min to max 7.2 ° 7.2 6.5 °
Arrival Rollout 95.12Total landing distance 837 m, 25 % of runway. Runway rollout alignment was slightly misaligned by 11.9 m from centreline.
ScoreDescriptionStartProfileEnd
100 % Landing distance 837 m25 % of runway.
89 % Runway alignment max 11.94 m left11.94 m left to 0.00 m left 11.94 8.50 m
100 % Average g force 1.01 g0.98 g min to max 1.10 g 1.10 1.00 g
Info Average speed 64 kt36 kt min to max 68 kt 68 36 kt
Info Average pitch angle 3.8 °1.0 ° min to max 6.4 ° 6.4 1.6 °
Info Average bank angle 0.4 °0.0 ° min to max 0.9 ° 0.9 0.1 °

Events

Info Flaps Position 4 9 ft agl · 63 kt
Info Flaps Position 2 9 ft agl · 60 kt
Info Flaps Fully Retracted 9 ft agl · 57 kt
Runway Exit Exiting runway, average speed 39 kt
ScoreDescriptionStartProfileEnd
Info Average speed 29 kt11 kt min to max 47 kt 33 22 kt
Info Average pitch angle 1.7 °1.2 ° min to max 2.1 ° 1.6 1.7 °
Info Average bank angle 0.2 °0.0 ° min to max 0.7 ° 0.0 0.7 °
Info Average g force 1.00 g0.99 g min to max 1.04 g 1.00 1.00 g
Arrival Taxi 100.00Taxiing to the parking from the runway took 7 minutes and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 11 kt0 kt min to max 22 kt 22 2 kt
100 % Average speed turning corners 11 ktmax 11 kt 0 0 kt
100 % Average g force 1.00 g0.96 g min to max 1.11 g 1.00 1.00 g
Info Average pitch angle 1.7 °-2.4 ° min to max 5.9 ° 1.9 2.0 °
Info Average bank angle 0.6 °0.0 ° min to max 2.0 ° 0.8 0.2 °

Takeoff from KELP 08R

Taxi out

Lights75.00
Offlanding
Taxi speed100.00
10kt peak

The roll

Takeoff roll100.00
965m35 %
Runway alignment100.00
2.55m R
Rotation speed91.74
94kttarget 108, 14 early

Rotated early, and the nose came up slowly

Rotation started at 94 kt, 14 kt before the 108 kt rotate speed, and the nose then rose at 1.4° a second, slower than the 2 to 3° a second airliners use.

The nose started up before the rotate speed and then came up slowly, as if easing it off early. Wait for the rotate speed, then make one steady pull at the normal rate for this aircraft.

Liftoff and climb

Liftoff
97ktat 4.7°
Rotation
1.4°/sover 2.2 s, gaining 3 kt
35 ft
110ktat 6.1°, 5.2 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
2.5°steepest
Gear up100.00
26ftfull marks to 400 ft
Climb 3 speed100.00
156kttarget 145

Plan view the roll down the 2,744 m runway.

Rolled from 215 m in, drifted right of the centreline, 2.7 m at the widest, and lifted off 2 m right. Airborne 35 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

1,0002,000THRESHOLDLEFT ↑RIGHT ↓CROSS1 kn75 %widest 2.67 m RROLL 215 M INAirborne 969 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 969 m of 2,744 m · 35 %
Behind the start of the roll, 215 mTakeoff roll, 754 m Left ahead, 1,776 m

Side view from the start of the roll to the end of Climb 3 at 1,004 ft. The distance scale changes past the runway end.

Reached 35 ft with 1,516 m of runway left; gear up at 26 ft, inside the 400 ft that gets full marks; then climbing at 820 fpm on average to 1,004 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,250 ft625 ft0CLIMB 3156 kt avgtarget 145THRESHOLDRUNWAY END304050607080KNOTS ALONG THE ROLLnose up on the runway · 105 m · 2.2 sRotate 94 kttarget 108Liftoff 97 ktGear up 26 ftfull marks to 400 ftSCALE CHANGES3.1 km past the runway
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 145180 kt12060020°10°0°nose up on the runway · 105 m · 2.2 sROTATELIFTOFFtarget 108held 6.1°4.7° off · 1.4°/s6° at 35 ftAIRSPEEDPITCH0306090 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2 to 3° a second, the rates airliners are rotated at: a trace steeper than both is a faster rotation, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate.

20°10°0°ROTATELIFTOFF35 FT2°/s3°/s4.7° off · 1.4°/s6° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5+6+7+8 sseconds from rotation
PitchRotation began2 to 3°/s from rotationNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 71.435 of 7500 ft 85.716 of 7
Gear down
Landing flap
Sink rate630 fpm410 fpm
On glideslope3.0°3.0°
On centreline0.0° off0.2° off
On speed+36 kt+26 kt
Wings level2° bank1° bank

At the 1,000 ft gate: gear still up and speed more than 22 kt above the approach speed of 86 kt.

At the 500 ft gate: speed more than 13 kt above the approach speed of 86 kt.

When the approach was stable

Never every check met at once: fast all the way, gear up until 2.7 nm, left of the centreline from 0.6 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to KLAX 25L

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 40 ft below the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,3216763602161,000 ft gate5 of 7gear downon speed1,043 ft · 122 kt500 ft gate6 of 7on speed542 ft · 112 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 20× larger than distances along the final.

Inside the 1° band from 4 nm to 0.6 nm, then 19 m left of it from 0.6 nm to the threshold.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR49 m L049 m RLEFT ↑RIGHT ↓1° BAND8 m L4 m L0 m R18 m L1 m R7 m L
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 22 kt fast at the 1,000 ft gate, closing to 13 at 500 ft and 10 at the threshold.

Fast from 4 nm to the threshold (up to +38 kt).

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

80100120140 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 86+38 kt+31 kt+21 kt+14 kt+3 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on KLAX 25L

Over the threshold

Threshold height100.00
39ft
Threshold speed100.00
89kttarget 86, 3 fast
Centreline offset93.07
12.35m L
Bank100.00
1.5°steepest
Flare100.00

Perfect landing flare

Touchdown

Past threshold100.00
320m
Centreline84.61
12.43m L
Speed100.00
78kttarget 86 or less
Touchdown rate100.00
-180fpm
Impact100.00
1.15G
BouncesOk
None
Bank100.00
1.5°as the wheels touched

Rollout

Rollout distance100.00
498m24 % used
Rollout alignment89.15
11.94m L

Taxi in

LightsOk
All set
Taxi speed100.00
22kt peak11 kt in turns

Side view — the last 1,524 m of the approach.

Crossed the threshold at 39 ft, 11 ft below the 50 ft target; began the flare at 32 ft. Touched down 320 m in, close to the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,524 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

39 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 32 ft · −494 fpm · 3.6° · 88 ktdescent slowed at 0 ft · −180 fpm · 7.2°−179 fpm · 7.2° nose up · 79 kt Ideal — 50 ft, down at 305 m This flight — 39 ft, down at 320 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 490 fpm at the flare to 180 fpm at touchdown. The nose came up 3.6° on the way down. Into the flare at 88 kt, on the 86 kt approach speed, and 79 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−179 fpm at touchdown7.2° at touchdown, +3.6° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,524 m of the 3,377 m runway, to the same scale as the side view.

Touched down 12 m left of the centreline, and stayed about there down the rollout, 13 m left at the widest. Little crosswind (2 kt): nothing to correct for. Touched down straight, wings level.

Wind 250° at 11 kt · 10 kt head · 2 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ CROSS 2 kn FULL SCORE TO 503 M 320 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

The 320 m touchdown sits inside the full-score zone. The arrival was smooth.

Runway used 818 m of 3,377 m · 24 %
In the air over the runway, 320 mRollout, 498 m Left over, 2,559 m

The stop — touchdown to taxi speed.

From 69 kt at touchdown to taxi speed (30 kt) in 21 s, an average deceleration of 0.10 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

02040608060 kt · 325 m30 kt · 567 mtouchdown590 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Flight narrative

The flight in the Douglas DC-6B began at KELP El Paso International Airport with a 10-minute taxi from the parking area to the runway. The departure roll from runway 08R included a takeoff distance of 821 meters, covering 30% of the runway. The liftoff speed was recorded at 97 knots. The local weather at the time of departure was 17°C with a wind speed of 21 knots coming from 100°, resulting in a crosswind of 2 knots and a headwind of 21 knots.

The enroute climb started 2 miles east of KELP El Paso International Airport, climbing from 4,985 feet above sea level to 7,911 feet above sea level, covering 5 nautical miles in 3 minutes. The enroute level cruise began 3 miles northeast of Ciudad Juarez (Estado de Chihuahua, Mexico) and lasted for 32 minutes, covering 136 nautical miles.

Another enroute climb started 3 miles northwest of NM70 Rodeo Airport in Rodeo, New Mexico. The aircraft climbed from 8,029 feet above sea level to 10,004 feet above sea level, covering 17 nautical miles in 4 minutes. Following this was an enroute descent that began 4 miles northwest of 09AZ Stronghold Airport in St David, Arizona. The aircraft descended from 9,415 feet above sea level to 8,038 feet above sea level, covering 10 nautical miles in 2 minutes.

The total flight distance was 653 nautical miles and the flight duration was 194 minutes. The aircraft used 1,940 kg of fuel during the flight.

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
