My FS Flights logo MY FS FLIGHTS
KJFK
New York, United States
Runway 13L
Elevation10 ft asl
Weight206,138 kg
Fuel26,781 kg
Wind60° · 5 kn · 4 kn cross

Flight Score

92.53 %
KORD
Chicago, United States
Runway 27C
Elevation663 ft asl
Weight190,871 kg
Fuel11,238 kg
Wind229° · 16 kn · 10 kn cross
28 Dec 2024 2:22 758 nm Boeing 777F 15,544 kg
Departure Score
96.27 %
Enroute Score
100.00 %
Arrival Score
81.31 %

What went well

Landed straight in a 10 kn crosswind — 3.58 m off the centreline, no bounce
Flare on profile — 100 %
1.28 G at touchdown — inside band

What held you back

Arrival Taxi — peak taxi speed 47 kt at 16 %, peak speed in a turn 35 kt at 34 %, −4.00 points
Arrival Landing — Threshold height at 86 ft agl was significantly above target at 31 %, −1.16 points
Departure Roll — Runway alignment max 19.67 m left at 48 %, Rotation speed was 168 kt at 89 %, −0.85 points

Next time

Departure

Make small rudder corrections against a point at the far end to hold the centreline.

What happened: During the ground roll you drifted 20 m off the runway centreline.

Watch for: Watch runway alignment against the centreline, correcting with small rudder inputs.

See Departure Roll

Arrival

Fly a slightly steeper approach path to cross the threshold at 50 ft agl instead of 86 ft agl.

What happened: The aircraft crossed the threshold at 86 ft agl against a 50 ft agl target, above the normal profile. This fault pattern is often followed by a long touchdown beyond the target point, and here the aircraft touched down at 673 m against a 457 m target.

Watch for: Radio altimeter against the 50 ft threshold crossing target on short final.

See Arrival LandingArrival Touchdown

Twenty knots on a monitor produces the visual sensation of about ten. The advice to "taxi at a walking pace" cannot fix this, because your sense of walking pace is exactly the thing that's broken. Put the groundspeed readout in your scan and obey it for the next fifty flights, the way a student pilot leans on the airspeed indicator before learning to read attitude.

Read more in How to Taxi Anywhere

Start to finish · 19 stages, 17 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 99.14Taxiing from the parking to the runway took 6 minutes and covered 2 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 16 kt0 kt min to max 29 kt 3 28 kt
98 % Average speed turning corners 17 ktmax 29 kt 0 28 kt
100 % Average g force 1.00 g0.99 g min to max 1.00 g 1.00 1.00 g
Info Average pitch angle -0.3 °-0.7 ° min to max 0.2 ° -0.3 -0.5 °
Info Average bank angle 0.1 °0.0 ° min to max 0.6 ° 0.0 0.6 °

Events

Info Battery Master On 13 ft agl
Info Engine 2 Started 13 ft agl
Info Beacon Lights Switched On 13 ft agl
Info Navigation Lights Switched On 13 ft agl
Info Landing Gear Down 13 ft agl
Info Engine 1 Started 13 ft agl
Info Parking Brake On 13 ft agl
Info Flaps Position 1 13 ft agl
Info Flaps Position 2 13 ft agl
Info Taxi Lights Switched On 13 ft agl
Info Parking Brake Off 13 ft agl
Info Landing Lights Switched On 13 ft agl
Info Taxi Lights Switched Off 13 ft agl
Info Strobe Lights Switched On 13 ft agl
Departure Runway Entry Entering runway 13L at KJFK John F Kennedy International Airport, Average speed was 31 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 29 kt28 kt min to max 29 kt 28 29 kt
Info Average pitch angle -0.4 °-0.5 ° min to max -0.4 ° -0.5 -0.4 °
Info Average bank angle 0.6 °0.5 ° min to max 0.7 ° 0.7 0.5 °
Info Average g force 1.00 g0.99 g min to max 1.00 g 1.00 0.99 g
Departure Roll 87.27Departure roll runway 13L at KJFK John F Kennedy International Airport. Takeoff distance 1,141 m 41 % of runway. Rotation speed was 168 kt. Local weather - Temperature 8 °C. Wind 5 kt at 60 °. Crosswind: 4 kt Headwind: 2 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 1,141 m41 % of runway
89 % Rotation speed was 168 ktTarget 145 kt
48 % Runway alignment max 19.67 m left19.67 m left to 10.17 m right -10.17 19.67 m
100 % Average g force 1.00 g0.97 g min to max 1.08 g 1.00 1.08 g
100 % Takeoff Bounce
Info Average pitch angle 0.2 °-0.3 ° min to max 5.2 ° -0.3 5.2 °
Info Average bank angle 0.3 °0.0 ° min to max 0.9 ° 0.1 0.9 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 13L KJFK John F Kennedy International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.7 °-0.8 ° min to max -0.6 ° -0.8 -0.6 °
100 % Average speed 195 kt183 kt min to max 204 kt 183 204 kt
100 % Steepest bank angle 2.3 °1.0 ° min to max 2.3 ° 1.1 1.2 °
100 % Average g force 1.15 g1.08 g min to max 1.19 g 1.09 1.08 g
Info Average VSI 576 fpm66 fpm min to max 1,130 fpm 66 1,130 fpm
Info Average altitude 19 ft agl0 ft agl min to max 49 ft agl 0 49 ft agl
Info Average pitch angle 6.6 °5.3 ° min to max 7.3 ° 5.3 7.3 °

Events

Info Flaps Position 1 55 ft agl · 199 kt
Departure Climb 2 100.00Departure climb to 400 ft agl from 13L KJFK John F Kennedy International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.5 °-0.6 ° min to max -0.1 ° -0.6 -0.1 °
100 % Average speed 210 kt204 kt min to max 227 kt 204 227 kt
100 % Steepest bank angle 1.3 °1.2 ° min to max 1.3 ° 1.2 1.2 °
100 % Average g force 1.10 g1.08 g min to max 1.15 g 1.08 1.15 g
Info Average VSI 1,648 fpm1,149 fpm min to max 3,357 fpm 1,149 3,357 fpm
Info Average altitude 111 ft agl51 ft agl min to max 365 ft agl 51 365 ft agl
Info Average pitch angle 8.4 °7.3 ° min to max 12.2 ° 7.3 12.2 °

Events

Info Flaps Position 2 79 ft agl · 203 kt
Info Flaps Fully Retracted 101 ft agl · 206 kt
Info Flaps Position 2 108 ft agl · 207 kt
Info Landing Gear Up 176 ft agl · 213 kt
Departure Climb 3 94.92Departure climb to 1,000 ft agl from 13L KJFK John F Kennedy International Airport.
ScoreDescriptionStartProfileEnd
89 % Climb speed 231 kt229 kt min to max 232 ktTarget 198 kt, 33 kt fast 229 231 kt
100 % Steepest bank angle 6.4 °0.4 ° min to max 6.4 ° 1.2 6.4 °
93 % Average g force 1.23 g1.12 g min to max 1.41 g 1.14 1.12 g
100 % Landing gear up at 163 ft aglTarget by 400 ft agl
Info Heading variation 0.1 °0.0 ° min to max 0.2 ° 0.0 0.2 °
Info Average VSI 4,959 fpm3,710 fpm min to max 6,534 fpm 3,710 6,534 fpm
Info Average altitude 638 ft agl428 ft agl min to max 884 ft agl 428 884 ft agl
Info Average pitch angle 17.3 °12.9 ° min to max 20.9 ° 12.9 20.9 °
Enroute Climb 100.00Enroute climb started 1 mile north of Inwood (New York, United States). Climbing from 1,026 ft asl to 35,942 ft asl, an increase of 34,916 ft in 11 minutes and covering 73 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 285 kt226 kt min to max 321 kt 229 280 kt
100 % Steepest bank angle 30.9 °0.0 ° min to max 30.9 ° 10.3 0.2 °
100 % Average g force 1.02 g0.72 g min to max 1.30 g 0.92 0.96 g
Info Average VSI 3,669 fpm1,082 fpm min to max 6,852 fpm 6,852 1,715 fpm
Info Average altitude 17,810 ft asl1,026 ft asl min to max 35,942 ft asl 1,026 35,942 ft asl
Info Average pitch angle 8.4 °3.3 ° min to max 20.3 ° 20.3 3.7 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Fully Retracted 1,516 ft agl · 224 kt
Info Landing Lights Switched Off 9,954 ft agl · 289 kt
Enroute Level 100.00Enroute level cruise started 2 miles south west of Conashaugh Lakes (Pennsylvania, United States) and lasted 29 minutes, covering 218 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,305 ft of 36,031 ft asl35,815 ft asl min to max 36,112 ft asl 36,110 35,815 ft asl
100 % Average speed 279 kt276 kt min to max 286 kt 281 280 kt
100 % Steepest bank angle 12.8 °0.0 ° min to max 12.8 ° 0.1 0.0 °
100 % Average g force 1.00 g0.89 g min to max 1.05 g 0.89 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 2.0 °1.6 ° min to max 2.1 ° 1.7 1.9 °
Enroute Descent 100.00Enroute descent started 7 miles north west of 0D4 Camp Vernon Westfield (New York, United States). Descent from 35,811 ft asl to 9,750 ft asl, a decrease of 26,061 ft in 51 minutes and covering 329 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 271 kt214 kt min to max 331 kt 280 263 kt
100 % Steepest bank angle 22.1 °0.0 ° min to max 22.1 ° 0.0 0.1 °
100 % Average g force 1.00 g0.98 g min to max 1.12 g 1.00 1.00 g
Info Average VSI -487 fpm-2,605 fpm min to max 120 fpm -24 -29 fpm
Info Average altitude 31,643 ft asl9,750 ft asl min to max 35,811 ft asl 35,811 9,750 ft asl
Info Average pitch angle 1.6 °-2.9 ° min to max 3.8 ° 1.9 2.7 °
Info Turn coordination 00 min to max 0 0 0
Enroute Level 2 100.00Enroute level cruise started 32 miles west of South Haven (Michigan, United States) and lasted 18 minutes, covering 62 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±987 ft of 9,767 ft asl9,735 ft asl min to max 9,779 ft asl 9,742 9,767 ft asl
100 % Average speed 210 kt206 kt min to max 245 kt 245 206 kt
100 % Steepest bank angle 23.4 °0.0 ° min to max 23.4 ° 0.1 18.8 °
100 % Average g force 1.00 g0.97 g min to max 1.12 g 1.00 1.06 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 4.8 °3.2 ° min to max 5.9 ° 3.2 5.9 °

Events

Info Flaps Position 1 9,189 ft agl · 243 kt
Enroute Descent 2 100.00Enroute descent started 2 miles south west of Carpentersville (Illinois, United States). Descent from 9,771 ft asl to 3,294 ft asl, a decrease of 6,477 ft in 7 minutes and covering 30 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 205 kt182 kt min to max 211 kt 206 182 kt
100 % Steepest bank angle 25.6 °0.0 ° min to max 25.6 ° 20.8 0.8 °
100 % Average g force 1.05 g0.93 g min to max 1.12 g 1.05 0.99 g
Info Average VSI -471 fpm-1,810 fpm min to max 430 fpm 224 22 fpm
Info Average altitude 7,702 ft asl3,219 ft asl min to max 9,782 ft asl 9,771 3,294 ft asl
Info Average pitch angle 3.8 °0.3 ° min to max 7.2 ° 5.7 4.5 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Landing Lights Switched On 8,871 ft agl · 242 kt
Info Flaps Position 2 2,786 ft agl · 200 kt
Info Flaps Position 1 2,786 ft agl · 200 kt
Info Flaps Position 2 2,547 ft agl · 198 kt
Enroute Level 3 100.00Enroute level cruise started 2 miles north east of Evanston (Illinois, United States) and lasted 11 minutes, covering 32 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±664 ft of 3,281 ft asl3,136 ft asl min to max 3,329 ft asl 3,289 3,136 ft asl
100 % Average speed 175 kt135 kt min to max 182 kt 181 135 kt
100 % Steepest bank angle 25.8 °0.0 ° min to max 25.8 ° 0.1 0.0 °
100 % Average g force 1.06 g0.94 g min to max 1.14 g 1.00 0.99 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 5.4 °3.0 ° min to max 6.9 ° 4.6 3.0 °

Events

Info Flaps Position 3 2,728 ft agl · 188 kt
Info Flaps Position 4 2,736 ft agl · 187 kt
Info Flaps Position 6 2,678 ft agl · 156 kt
Info Flaps Position 4 2,678 ft agl · 156 kt
Info Flaps Position 5 2,664 ft agl · 156 kt
Info Flaps Position 6 2,714 ft agl · 156 kt
Info Landing Gear Down 2,700 ft agl · 153 kt
Enroute Descent 3 100.00Enroute descent started overhead Lincolnwood (Illinois, United States). Descent from 3,053 ft asl to 1,929 ft asl, a decrease of 1,124 ft in 2 minutes and covering 4 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 135 kt133 kt min to max 138 kt 135 134 kt
100 % Steepest bank angle 3.5 °0.0 ° min to max 3.5 ° 0.0 0.3 °
100 % Average g force 1.00 g0.95 g min to max 1.02 g 1.00 1.00 g
Info Average VSI -512 fpm-650 fpm min to max -237 fpm -491 -488 fpm
Info Average altitude 2,293 ft asl1,929 ft asl min to max 3,053 ft asl 3,053 1,929 ft asl
Info Average pitch angle 2.8 °2.1 ° min to max 4.2 ° 3.0 2.7 °
Info Turn coordination 00 min to max 0 0 0
Arrival Approach 100.00Final approach to runway 27C at KORD Chicago O'Hare International Airport. Descent from 1,300 ft agl to 107 ft agl in 119 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates

Events

Fail GPWS Warning Activated 937 ft agl · 137 kt
Fail GPWS Warning Activated 870 ft agl · 136 kt
Fail GPWS Warning Activated 769 ft agl · 139 kt
Fail GPWS Warning Activated 542 ft agl · 135 kt
Fail GPWS Warning Activated 434 ft agl · 136 kt
Fail GPWS Warning Activated 449 ft agl · 137 kt
Fail GPWS Warning Activated 231 ft agl · 142 kt
Info GPWS Warning Deactivated 863 ft agl · 136 kt
Info GPWS Warning Deactivated 764 ft agl · 138 kt
Info GPWS Warning Deactivated 719 ft agl · 139 kt
Info GPWS Warning Deactivated 474 ft agl · 134 kt
Info GPWS Warning Deactivated 457 ft agl · 139 kt
Info GPWS Warning Deactivated 258 ft agl · 139 kt
Info GPWS Warning Deactivated 211 ft agl · 149 kt
Arrival Landing 82.63Landing on runway 27C at KORD Chicago O'Hare International Airport, runway length 3,530 m. Threshold height at 86 ft agl was significantly above target. Threshold speed was slightly above target at 145 kt.
ScoreDescriptionStartProfileEnd
99 % Threshold speed was slightly above target at 145 kt. Target 135 kt
31 % Threshold height at 86 ft agl was significantly above target.Target 50 ft agl
100 % The flare tracked the target profile exactly. Crossing the threshold 10 kt above target, the aircraft floated down the runway before touching. Touchdown was 673 m past the threshold. The flare cannot burn off excess energy - fix the approach speed and the float goes with it.
100 % Runway alignment max 4.59 m right2.64 m right to 4.59 m right -4.59 -4.36 m
100 % Steepest bank angle 2.3 °0.0 ° min to max 2.3 ° 2.3 1.8 °
100 % Peak g force 1.15 g0.95 g min to max 1.15 g 1.06 0.96 g
Info Average speed 144 kt139 kt min to max 150 kt 145 142 kt
Info Average VSI -620 fpm-901 fpm min to max -242 fpm -901 -280 fpm
Info Average altitude 30 ft agl-3 ft agl min to max 86 ft agl 86 -3 ft agl
Info Average pitch angle 1.2 °-0.4 ° min to max 3.0 ° 0.6 1.2 °
07515022530037545052560067575001733506783Runway Distance mLanding Height ft075150225300375450525600675750-30-24-18-12-60612182430Runway Distance mRunway Width m
Arrival Touchdown 93.41Touchdown point was 256 m beyond the touchdown zone. Touchdown speed at 142 kt was a little fast. Touchdown rate was firm at -319 fpm. Runway touchdown position was slightly misaligned by 4.4 m from centreline. Local weather - Temperature 9 °C. Wind 25 kt at 229 °. Crosswind: 16 kt Headwind: 19 kt.
ScoreDescriptionStartProfileEnd
85 % Touchdown rate was -319 fpm.
76 % Touchdown distance was 673 mTarget 457 m
100 % Speed at touchdown 142 ktTarget below 135 kt
100 % Runway alignment max 4.36 m right4.13 m right -4.36 -3.58 m
100 % Steepest bank angle 1.8 °0.1 ° min to max 1.8 ° 1.8 0.4 °
100 % Peak g force 1.28 g0.96 g min to max 1.28 g 0.96 1.19 g
100 % Landing Bounce
Info Average speed 141 kt139 kt min to max 142 kt 142 139 kt
Info Average pitch angle 0.7 °0.1 ° min to max 1.2 ° 1.2 0.1 °
Arrival Rollout 90.47Total landing distance 1,278 m, 36 % of runway. Runway rollout alignment was misaligned by 15.5 m from centreline.
ScoreDescriptionStartProfileEnd
100 % Landing distance 1,278 m36 % of runway.
79 % Runway alignment max 15.49 m left15.49 m left to 0.00 m left 14.28 12.83 m
100 % Average g force 1.02 g0.97 g min to max 1.14 g 1.14 1.00 g
Info Average speed 115 kt65 kt min to max 122 kt 122 65 kt
Info Average pitch angle -0.2 °-0.8 ° min to max 0.1 ° 0.1 -0.5 °
Info Average bank angle 1.0 °0.0 ° min to max 1.6 ° 0.4 0.3 °
Runway Exit Exiting runway, average speed 51 kt
ScoreDescriptionStartProfileEnd
Info Average speed 37 kt4 kt min to max 58 kt 58 18 kt
Info Average pitch angle -0.3 °-0.8 ° min to max 0.3 ° -0.7 0.0 °
Info Average bank angle 0.3 °0.0 ° min to max 1.0 ° 0.1 0.2 °
Info Average g force 1.00 g0.98 g min to max 1.05 g 0.98 1.00 g

Events

Info Flaps Position 1 13 ft agl · 49 kt
Info Flaps Position 6 13 ft agl · 48 kt
Info Taxi Lights Switched On 13 ft agl · 5 kt
Info Flaps Position 5 13 ft agl
Info Landing Lights Switched Off 13 ft agl
Info Flaps Position 4 13 ft agl
Info Flaps Position 3 13 ft agl · 8 kt
Arrival Taxi 40.07Taxiing to the parking from the runway took 5 minutes and covered 2 nm.
ScoreDescriptionStartProfileEnd
16 % Average speed 23 kt2 kt min to max 47 kt 18 7 kt
34 % Average speed turning corners 22 ktmax 34 kt 0 0 kt
100 % Average g force 1.00 g0.97 g min to max 1.02 g 1.00 1.00 g
Info Average pitch angle -0.5 °-1.4 ° min to max 0.1 ° -0.0 -0.8 °
Info Average bank angle 0.2 °0.0 ° min to max 1.8 ° 0.0 0.8 °

Events

Info Flaps Position 2 13 ft agl · 8 kt
Info Flaps Position 1 13 ft agl
Info Flaps Fully Retracted 13 ft agl · 8 kt
Info Strobe Lights Switched Off 13 ft agl · 25 kt

Takeoff from KJFK 13L

Taxi out

LightsOk
All on
Taxi speed98.93
29kt peak17 kt in turns

The roll

Takeoff roll100.00
1,141m41 %
Runway alignment47.79
19.67m L
Rotation speed88.55
168kttarget 145, 23 late

Rotated late, and the nose came up slowly

Rotation started at 168 kt, 23 kt after the 145 kt rotate speed, and the nose then rose at 2.4° a second, slower than the 2.5 to 3.4° a second other Boeing 777F pilots fly.

The pull started after the rotate speed and was then slow. Start it on the rotate speed and make it one positive, continuous movement at the normal rate for this aircraft.

Liftoff and climb

Liftoff
182ktat 5.3°
Rotation
2.4°/sover 1.9 s, gaining 14 kt
35 ft
201ktat 7.0°, 2.6 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
2.3°steepest
Gear up100.00
163ftfull marks to 400 ft
Climb 3 speed88.99
231kttarget 198

Plan view the roll down the 2,768 m runway.

Rolled from 116 m in, drifted left of the centreline, 19 m at the widest, and lifted off 19 m left. Airborne 41 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

1,0002,000THRESHOLDLEFT ↑RIGHT ↓CROSS4 kn75 %widest 19.45 m LROLL 116 M INAirborne 1,148 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,148 m of 2,768 m · 41 %
Behind the start of the roll, 116 mTakeoff roll, 1,033 m Left ahead, 1,620 m

Side view from the start of the roll to the end of Climb 3 at 885 ft.

Reached 35 ft with 1,370 m of runway left; gear up at 163 ft, inside the 400 ft that gets full marks; then climbing at 3,030 fpm on average to 885 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3231 kt avgtarget 198THRESHOLDRUNWAY END6080100120140KNOTS ALONG THE ROLLnose up on the runway · 170 m · 1.9 sRotate 168 kttarget 145Liftoff 182 ktGear up 163 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 198240 kt16080025°13°0°nose up on the runway · 170 m · 1.9 sROTATELIFTOFFGEAR UPtarget 145held 9.5°5.3° off · 2.4°/s7° at 35 ftAIRSPEEDPITCH0102030 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2.5 to 3.4° a second, the middle half of rotation rates flown by other Boeing 777F pilots over the last 180 days (76 takeoffs); the grey pair are 2 to 3° a second, the rates airliners are rotated at. A trace steeper than both green lines is a faster rotation than most, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 12.1°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 12.1°ROTATELIFTOFF35 FT2.5°/s3°/s3.4°/s5.3° off · 2.4°/s2°/s7° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5 sseconds from rotation
PitchRotation began2.5 to 3.4°/s, other Boeing 777F pilots2 to 3°/s from rotation, airlinersTail strikeNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate600 fpm750 fpm
On glideslope3.0°3.0°
On centreline0.1° off0.1° off
On speed−3.0 kt−2.4 kt
Wings level0° bank1° bank

When the approach was stable

Every check met from 4 nm to 0.9 nm, then not again: right of the centreline from 0.9 nm and high from 0.2 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to KORD 27C

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

On the glideslope from 4 nm to 0.2 nm, then high to the threshold (up to 50 ft over).

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,2956733552281,000 ft gate7 of 71,034 ft · 135 kt500 ft gate7 of 7531 ft · 136 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 11× larger than distances along the final.

Inside the 1° band from 4 nm to 0.9 nm, then 34 m right of it from 0.9 nm to the threshold.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR88 m L088 m RLEFT ↑RIGHT ↓1° BAND4 m L3 m L27 m R34 m R4 m L3 m L
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 35 kt fast at the 1,000 ft gate, closing to 21 at 500 ft and 10 at the threshold.

Inside the speed band all the way, between −7 kt and +14 kt on the approach speed of 138 kt.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

140160180200 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 138−3 kt−3 kt−3 kt+2 kt+14 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on KORD 27C

Over the threshold

Threshold height31.20
85ft
Threshold speed99.30
145kttarget 135, 10 fast
Centreline offset100.00
4.59m R
Bank100.00
2.3°steepest
Flare100.00

The flare tracked the target profile exactly

Crossing the threshold 10 kt above target, the aircraft floated down the runway before touching. Touchdown was 673 m past the threshold. The flare cannot burn off excess energy - fix the approach speed and the float goes with it.

Touchdown

Past threshold76.45
673m
Centreline100.00
4.36m R
Speed100.00
141kttarget 134, 7 fast
Touchdown rate84.70
-319fpm
Impact100.00
1.28G
BouncesOk
None
Bank100.00
1.8°as the wheels touched

Rollout

Rollout distance100.00
598m35 % used
Rollout alignment78.83
15.49m L

Taxi in

LightsOk
All set
Taxi speed25.08
47kt peak22 kt in turns

Side view — the last 1,524 m of the approach.

Crossed the threshold at 85 ft, 35 ft above the 50 ft target; began the flare at 31 ft. Touched down 673 m in, 368 m past the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,524 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

85 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 31 ft · −685 fpm · 1.1° · 146 ktdescent slowed at 7 ft · −121 fpm · 2.2°−318 fpm · 1.2° nose up · 142 kt Ideal — 50 ft, down at 305 m This flight — 85 ft, down at 673 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 680 fpm at the flare to 320 fpm at touchdown. The pitch barely changed. Into the flare at 146 kt, 11 kt over the 135 kt approach speed, and 142 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−750−1,500−1°4°10°flaredescent slowedtouchdown−318 fpm at touchdown1.2° at touchdown, +0.1° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,524 m of the 3,530 m runway, to the same scale as the side view.

Touched down 3.6 m right of the centreline and drifted to 15 m left on the rollout. 10 kt across from the left, which takes about 4° of crab to hold the centreline at 142 kt. Touched down with the nose 7° into wind, wings level.

Wind 229° at 16 kt · 12 kt head · 10 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ CROSS 10 kn FULL SCORE TO 503 M 673 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

Touched down 673 m past the threshold — beyond the full-score zone. The arrival was smooth.

Runway used 1,271 m of 3,530 m · 36 %
In the air over the runway, 673 mRollout, 598 m Left over, 2,259 m

The stop — touchdown to taxi speed.

From 124 kt at touchdown to taxi speed (30 kt) in 19 s, an average deceleration of 0.27 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 667 m30 kt · 775 mtouchdown805 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Flight narrative

The flight began with a taxiing period from the parking to the runway, which took 5 minutes and covered a distance of 1 nautical mile. The aircraft, a Boeing 777F, then departed from runway 13L at John F. Kennedy International Airport (KJFK). The takeoff distance was 1,026 meters, which accounted for 42% of the runway. The liftoff speed was 183 knots.

The local weather conditions at the time of departure were characterized by a temperature of 8 degrees Celsius, with a wind speed of 5 knots at a direction of 60 degrees. This resulted in a crosswind of 4 knots and a headwind of 2 knots. The aircraft began its enroute climb 1 mile north of Inwood, New York, and ascended from an initial altitude of 1,026 feet above sea level to a cruising altitude of 35,942 feet, an increase of 34,916 feet in 11 minutes and covering a distance of 67 nautical miles.

Following the initial climb, the aircraft entered a level cruise phase, which started 2 miles southwest of Conashaugh Lakes, Pennsylvania, and lasted for 61 minutes, covering a distance of 447 nautical miles. The aircraft then began its enroute descent 2 miles east of Portland, Michigan, and descended from 34,946 feet to 10,154 feet, a decrease of 24,792 feet in 18 minutes and covering a distance of 93 nautical miles.

The aircraft then entered another level cruise phase, which started 29 miles west of South Haven, Michigan, and lasted for 18 minutes, covering a distance of 65 nautical miles. The enroute descent phase began again 1 mile south of Carpentersville, Illinois, and the aircraft descended from 9,779 feet to 3,300 feet, a decrease of 6,479 feet in 6 minutes and covering a distance of 24 nautical miles.

The aircraft then entered another level cruise phase, which started overhead Wilmette, Illinois, and lasted for 13 minutes, covering a distance of 5 nautical miles. The enroute descent phase began once more overhead Lincolnwood, Illinois, and the aircraft descended from 2,970 feet to 1,929 feet, a decrease of 1,041 feet in 2 minutes and covering a distance of 4 nautical miles.

The final approach to runway 27C at Chicago O'Hare International Airport (KORD) was made from the east, with a heading of 270.0 degrees at an altitude of 1,258 feet above ground level and a distance of 4 nautical miles from the runway. The landing was made on runway 27C, which had a length of 3,237 meters. The threshold height was significantly above the target, but the threshold speed was good at 145 knots.

The touchdown point was 223 meters beyond the touchdown zone, with a touchdown speed of 142 knots, which was good. However, the touchdown rate was fair at -280 feet per minute. The runway touchdown position was slightly misaligned by 4.3 meters from the centerline. The local weather conditions at the time of landing were characterized by a temperature of 9 degrees Celsius, with a wind speed of 25 knots at a direction of 229 degrees. This resulted in a crosswind of 16 knots and a headwind of 19 knots.

The total landing distance was 1,277 meters, which accounted for 39% of the runway. The runway rollout alignment was misaligned by 15.5 meters from the centerline. The taxiing period from the runway to the parking took 5 minutes and covered a distance of 1 nautical mile. The total flight distance was 713 nautical miles, with a total flight time of 142 minutes and a fuel consumption of

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
