ZPPP
Kunming, China
Runway 22L
Elevation6,831 ft asl
Weight34,820 kg
Fuel7,524 kg
Wind15° · 3 kn · 1 kn cross

Flight Score

97.34 %
VECA
Chabua, India
Runway 05
Elevation361 ft asl
Weight31,062 kg
Fuel3,611 kg
Wind0° · 1 kn · 1 kn cross
29 Oct 2023 2:07 643 nm British Aerospace 146-100 3,913 kg
Departure Score
97.66 %
Enroute Score
98.62 %
Arrival Score
95.74 %

What went well

Touched down at -203 fpm — a soft arrival
Touchdown 391 m in — inside the full-score zone
Straight touchdown — 2.85 m off the centreline, no bounce

What held you back

Arrival Approach — GPWS warning; 1,000 ft gate 100 %, 500 ft gate 71 %, −1.19 points
Departure Roll — Landing Lights at 0 %, Strobe Lights at 0 %, −0.67 points
Enroute Descent — 250 kt exceeded below 10,000 ft; speed limits at 91 %, −0.29 points

Next time

Arrival

Reduce power earlier on final to bring the speed back to 114 kt well before the gate.

What happened: This flight was 21 kt fast at the stabilisation gate, and excess speed like this usually rides down the approach to cross the threshold still fast, as it did here at 126 kt against 114 kt.

Watch for: Airspeed indicator: 114 kt at the gate, 114 kt at the threshold

See Arrival ApproachArrival Landing

Preparing for a stable approach will give you time to decide on whether to attempt the landing or going around. Too much altitude with a high sink rate will result in carrying too much speed onto the runway. Configuring flaps and the gear late also won't help the speed decay.

Read more in The Stabilised Approach

Start to finish · 15 stages, 13 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 19 minutes and covered 5 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 15 kt0 kt min to max 22 kt 0 8 kt
100 % Average speed turning corners 15 ktmax 17 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle -0.2 °-0.6 ° min to max -0.1 ° -0.2 -0.4 °
Info Average bank angle 0.1 °0.0 ° min to max 0.4 ° 0.0 0.2 °

Events

Info Autopilot Master Switched On 8 ft agl · 2 kt
Info Autopilot Heading Hold Activated 8 ft agl · 2 kt
Info Autopilot Master Switched Off 8 ft agl · 3 kt
Info Autopilot Heading Hold Deactivated 8 ft agl · 3 kt
Info Engine 3 Started 8 ft agl · 3 kt
Info Engine 2 Started 8 ft agl · 3 kt
Info Engine 1 Started 8 ft agl · 2 kt
Info Beacon Lights Switched On 8 ft agl · 2 kt
Info Pitot Heat Switched On 8 ft agl · 2 kt
Info Parking Brake Off 8 ft agl · 3 kt
Info Autopilot Heading Hold Activated 8 ft agl · 3 kt
Info Autopilot Flight Director Activated 8 ft agl · 3 kt
Info Landing Lights Switched On 8 ft agl · 3 kt
Info Landing Lights Switched Off 8 ft agl · 3 kt
Info Taxi Lights Switched On 8 ft agl · 3 kt
Info Flaps Position 1 8 ft agl · 16 kt
Departure Runway Entry Entering runway 22L at ZPPP Kunming Changshui International Airport, Average speed was 5 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 8 kt8 kt min to max 9 kt 8 9 kt
Info Average pitch angle -0.3 °-0.4 ° min to max -0.3 ° -0.4 -0.3 °
Info Average bank angle 0.3 °0.1 ° min to max 0.4 ° 0.3 0.1 °
Info Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Departure Roll 90.00Departure roll runway 22L at ZPPP Kunming Changshui International Airport. Takeoff distance 1,862 m 47 % of runway. Rotation speed was 131 kt. Local weather - Temperature 16 °C. Wind 4 kt at 15 °. Crosswind: 2 kt Tailwind: 4 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 1,862 m47 % of runway
100 % Rotation speed was 131 ktTarget 127 kt
100 % Runway alignment max 5.06 m left5.06 m left to 1.05 m right 3.21 -1.05 m
100 % Average g force 1.00 g0.95 g min to max 1.15 g 1.00 1.15 g
100 % Takeoff Bounce
Info Average pitch angle 0.3 °-0.5 ° min to max 8.0 ° -0.2 8.0 °
Info Average bank angle 0.2 °0.0 ° min to max 0.5 ° 0.2 0.3 °

Events

Fail Landing Lights
Fail Strobe Lights
Info Parking Brake On 8 ft agl
Info Parking Brake Off 8 ft agl
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 22L ZPPP Kunming Changshui International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.1 °0.0 ° min to max 0.1 ° 0.0 0.1 °
100 % Average speed 139 kt136 kt min to max 140 kt 136 140 kt
100 % Steepest bank angle 1.2 °0.3 ° min to max 1.2 ° 0.3 1.0 °
100 % Average g force 1.12 g0.94 g min to max 1.25 g 1.19 0.94 g
Info Average VSI 749 fpm303 fpm min to max 1,021 fpm 303 1,021 fpm
Info Average altitude 21 ft agl0 ft agl min to max 48 ft agl 0 48 ft agl
Info Average pitch angle 9.0 °8.2 ° min to max 9.6 ° 8.3 8.2 °
Departure Climb 2 100.00Departure climb to 400 ft agl from 22L ZPPP Kunming Changshui International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.1 °0.0 ° min to max 0.1 ° 0.1 0.0 °
100 % Average speed 143 kt141 kt min to max 147 kt 141 146 kt
100 % Steepest bank angle 1.0 °0.1 ° min to max 1.0 ° 1.0 0.3 °
100 % Average g force 0.99 g0.93 g min to max 1.11 g 0.93 1.00 g
Info Average VSI 1,129 fpm996 fpm min to max 2,336 fpm 1,024 2,336 fpm
Info Average altitude 103 ft agl49 ft agl min to max 389 ft agl 49 389 ft agl
Info Average pitch angle 8.8 °8.1 ° min to max 12.6 ° 8.1 12.5 °

Events

Info Landing Gear Up 229 ft agl · 165 kt
Departure Climb 3 98.28Departure climb to 1,000 ft agl from 22L ZPPP Kunming Changshui International Airport.
ScoreDescriptionStartProfileEnd
96 % Climb speed 145 kt144 kt min to max 146 ktTarget 161 kt, 16 kt slow 146 145 kt
100 % Steepest bank angle 1.3 °0.4 ° min to max 1.3 ° 0.4 1.3 °
100 % Average g force 0.97 g0.94 g min to max 1.00 g 0.99 0.94 g
100 % Landing gear up at 190 ft aglTarget by 400 ft agl
Info Heading variation 0.1 °0.0 ° min to max 0.1 ° 0.0 0.1 °
Info Average VSI 2,520 fpm2,401 fpm min to max 2,607 fpm 2,401 2,469 fpm
Info Average altitude 662 ft agl430 ft agl min to max 895 ft agl 430 895 ft agl
Info Average pitch angle 12.7 °12.1 ° min to max 13.1 ° 12.5 12.1 °

Events

Info Flaps Fully Retracted 865 ft agl · 165 kt
Enroute Climb 100.00Enroute climb started 1 mile south west of ZPPP Kunming Changshui International Airport Kunming (Yunnan Sheng, China). Climbing from 7,870 ft asl to 32,714 ft asl, an increase of 24,844 ft in 24 minutes and covering 119 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 215 kt146 kt min to max 262 kt 146 262 kt
100 % Steepest bank angle 26.8 °0.0 ° min to max 26.8 ° 1.4 0.0 °
100 % Average g force 1.01 g0.85 g min to max 1.16 g 0.90 1.00 g
Info Average VSI 1,173 fpm188 fpm min to max 2,728 fpm 2,302 196 fpm
Info Average altitude 19,953 ft asl7,870 ft asl min to max 32,714 ft asl 7,870 32,714 ft asl
Info Average pitch angle 5.8 °2.2 ° min to max 11.4 ° 11.4 2.2 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Yaw Damper Activated 4,557 ft agl · 246 kt
Info Autopilot Master Switched On 4,617 ft agl · 246 kt
Info Strobe Lights Switched On 8,833 ft agl · 261 kt
Info Landing Lights Switched On 9,044 ft agl · 261 kt
Info Taxi Lights Switched Off 9,094 ft agl · 261 kt
Info Landing Lights Switched Off 9,306 ft agl · 263 kt
Info Autopilot Altitude Hold Activated 18,127 ft agl · 304 kt
Info Autopilot Altitude Hold Deactivated 17,785 ft agl · 306 kt
Info Autopilot Altitude Hold Activated 18,504 ft agl · 312 kt
Enroute Level 98.01Enroute level cruise started 37 miles south of ZXIA Xiangyun Midu Air Base Xiangcheng (Yunnan Sheng, China) and lasted 58 minutes, covering 355 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,137 ft of 32,745 ft asl32,647 ft asl min to max 32,799 ft asl 32,737 32,653 ft asl
90 % Average speed 250 kt177 kt min to max 281 kt 264 280 kt
100 % Steepest bank angle 26.8 °0.0 ° min to max 26.8 ° 0.9 1.2 °
100 % Average g force 1.01 g0.84 g min to max 1.14 g 0.98 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 2.4 °1.2 ° min to max 5.6 ° 2.1 1.5 °

Events

Fail Overspeed Warning Activated 30,716 ft agl · 457 kt
Fail Overspeed Warning Activated 31,020 ft agl · 456 kt
Fail Overspeed Warning Activated 29,767 ft agl · 456 kt
Fail Overspeed Warning Activated 30,191 ft agl · 456 kt
Info Overspeed Warning Deactivated 32,205 ft agl · 454 kt
Info Overspeed Warning Deactivated 30,860 ft agl · 456 kt
Info Overspeed Warning Deactivated 29,884 ft agl · 456 kt
Info Overspeed Warning Activated 30,019 ft agl · 456 kt
Info Overspeed Warning Deactivated 27,410 ft agl · 456 kt
Info Overspeed Warning Deactivated 28,091 ft agl · 456 kt
Info Overspeed Warning Activated 27,989 ft agl · 456 kt
Info Overspeed Warning Deactivated 27,989 ft agl · 456 kt
Info Overspeed Warning Activated 28,033 ft agl · 456 kt
Info Overspeed Warning Deactivated 28,034 ft agl · 456 kt
Info Overspeed Warning Activated 27,747 ft agl · 456 kt
Enroute Descent 96.48Enroute descent started 8 miles east of Sonari (Assam, India). Descent from 32,650 ft asl to 1,911 ft asl, a decrease of 30,739 ft in 30 minutes and covering 151 nm.
ScoreDescriptionStartProfileEnd
91 % Average speed 230 kt159 kt min to max 280 kt 280 159 kt
100 % Steepest bank angle 26.8 °0.0 ° min to max 26.8 ° 0.9 0.8 °
99.96 % Average g force 1.05 g0.65 g min to max 1.26 g 1.01 1.02 g
Info Average VSI -975 fpm-1,590 fpm min to max 116 fpm -19 19 fpm
Info Average altitude 12,231 ft asl1,910 ft asl min to max 32,653 ft asl 32,650 1,911 ft asl
Info Average pitch angle 0.4 °-1.9 ° min to max 2.3 ° 1.5 2.2 °
Info Turn coordination 00 min to max 0 0 0

Events

Fail Exceeded 250 kn below 10000 ft 3,079 ft agl
Info Overspeed Warning Deactivated 32,228 ft agl · 455 kt
Info Autopilot Altitude Hold Deactivated 32,288 ft agl · 438 kt
Info Autopilot Altitude Hold Activated 31,740 ft agl · 438 kt
Info Landing Lights Switched On 9,742 ft agl · 282 kt
Info Landing Gear Down 2,554 ft agl · 276 kt
Info Flaps Position 1 1,695 ft agl · 208 kt
Enroute Level 2 100.00Enroute level cruise started 8 miles south east of Dibrugarh (Assam, India) and lasted 2 minutes, covering 6 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±596 ft of 1,790 ft asl1,326 ft asl min to max 1,922 ft asl 1,911 1,326 ft asl
100 % Average speed 147 kt137 kt min to max 158 kt 158 137 kt
100 % Steepest bank angle 2.6 °0.0 ° min to max 2.6 ° 0.8 0.5 °
100 % Average g force 1.00 g0.84 g min to max 1.08 g 0.98 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 0.8 °-2.2 ° min to max 2.5 ° 2.2 -0.1 °

Events

Fail GPWS Warning Activated 996 ft agl · 144 kt
Info Flaps Position 2 1,549 ft agl · 164 kt
Info Flaps Position 3 1,555 ft agl · 155 kt
Info Autopilot Master Switched Off 1,544 ft agl · 148 kt
Info Flaps Position 4 1,244 ft agl · 157 kt
Arrival Approach 85.71Final approach to runway 05 at VECA Chabua Air Force Station. Descent from 994 ft agl to 33 ft agl in 101 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
50 % On glideslopefailed at one of the two gates
100 % On centrelinepassed at both gates
50 % On speedfailed at one of the two gates
100 % Wings levelpassed at both gates

Events

Fail GPWS Warning Activated still on from Enroute Level 2 996 ft agl · 144 kt
Info GPWS Warning Deactivated 32 ft agl · 131 kt
Arrival Landing 97.68Landing on runway 05 at VECA Chabua Air Force Station, runway length 2,436 m. Good threshold height. Threshold speed was well above target at 127 kt.
ScoreDescriptionStartProfileEnd
94 % Threshold speed was well above target at 127 kt. Target 114 kt
100 % Good threshold height.Target 50 ft agl
96 % Excellent landing flare. It lost 3.5 points, for starting the flare at 10 ft agl, below the usual 11 ft agl–45 ft agl.
100 % Runway alignment max 3.54 m right2.71 m right to 3.54 m right -3.54 -2.91 m
100 % Steepest bank angle 0.6 °0.3 ° min to max 0.6 ° 0.5 0.4 °
100 % Peak g force 1.04 g0.96 g min to max 1.04 g 1.02 0.99 g
Info Average speed 120 kt114 kt min to max 127 kt 127 114 kt
Info Average VSI -185 fpm-254 fpm min to max -132 fpm -254 -198 fpm
Info Average altitude 10 ft agl1 ft agl min to max 19 ft agl 19 1 ft agl
Info Average pitch angle 3.0 °2.2 ° min to max 3.8 ° 2.2 3.8 °
07515022530037545001223354658Runway Distance mLanding Height ft075150225300375450-24-20-16-12-8-404812162024Runway Distance mRunway Width m
Arrival Touchdown 100.00Touchdown distance was good at 390 m. Touchdown speed at 114 kt was good. Touchdown rate was fair at -203 fpm. Runway touchdown alignment was very good. Local weather - Temperature 23 °C. Wind 1 kt at 360 °. Crosswind: 1 kt Headwind: 1 kt.
ScoreDescriptionStartProfileEnd
100 % Touchdown rate was -203 fpm.
100 % Touchdown distance was 391 mTarget 457 m
100 % Speed at touchdown 114 ktTarget below 114 kt
100 % Runway alignment max 2.92 m right2.89 m right -2.91 -2.85 m
100 % Steepest bank angle 0.5 °0.2 ° min to max 0.5 ° 0.4 0.5 °
100 % Peak g force 1.26 g0.99 g min to max 1.26 g 0.99 1.08 g
100 % Landing Bounce
Info Average speed 113 kt113 kt min to max 114 kt 114 113 kt
Info Average pitch angle 3.9 °3.8 ° min to max 3.9 ° 3.8 3.9 °

Events

Info Autopilot Yaw Damper Deactivated 10 ft agl · 116 kt
Arrival Rollout 99.54Total landing distance 1,643 m, 67 % of runway. Runway rollout alignment was very good.
ScoreDescriptionStartProfileEnd
100 % Landing distance 1,643 m67 % of runway.
99 % Runway alignment max 7.08 m left7.08 m left to 0.96 m right -0.72 2.53 m
100 % Average g force 1.00 g0.98 g min to max 1.06 g 1.06 0.99 g
Info Average speed 102 kt60 kt min to max 114 kt 114 60 kt
Info Average pitch angle 1.8 °-0.8 ° min to max 3.9 ° 3.9 -0.6 °
Info Average bank angle 0.7 °0.0 ° min to max 1.4 ° 0.5 0.1 °
Runway Exit Exiting runway, average speed 19 kt
ScoreDescriptionStartProfileEnd
Info Average speed 18 kt0 kt min to max 57 kt 57 0 kt
Info Average pitch angle -0.3 °-0.6 ° min to max -0.0 ° -0.6 -0.4 °
Info Average bank angle 0.1 °0.0 ° min to max 0.4 ° 0.0 0.0 °
Info Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g

Events

Info Autopilot Altitude Hold Deactivated 8 ft agl · 9 kt
Info Parking Brake On 8 ft agl · 1 kt

Takeoff from ZPPP 22L

Taxi out

Lights50.00
Offlanding and strobes
Taxi speed100.00
22kt peak15 kt in turns

The roll

Takeoff roll100.00
1,862m47 %
Runway alignment100.00
5.06m L
Rotation speed100.00
131kttarget 127, 4 late

A clean takeoff

Rotated at 131 kt against the 127 kt rotate speed, the nose rising at 2.9° a second, then held 9.3° from 35 ft, within 5.0° top to bottom.

Rotated on speed at a steady rate, and the climb attitude held. This is the takeoff to repeat: the same speed check, the same pull, the same attitude.

Liftoff and climb

Liftoff
136ktat 8.3°
Rotation
2.9°/sover 2.6 s, gaining 5 kt
35 ft
140ktat 8.7°, 2.3 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
1.2°steepest
Gear up100.00
190ftfull marks to 400 ft
Climb 3 speed95.70
145kttarget 161

Plan view the roll down the 4,004 m runway.

Rolled from 64 m in, drifted 5.2 m left of the centreline and was back on it to lift off. Airborne 46 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

1,0002,0003,0004,000THRESHOLDLEFT ↑RIGHT ↓CROSS1 kn75 %widest 5.16 m LROLL 64 M INAirborne 1,869 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,869 m of 4,004 m · 47 %
Behind the start of the roll, 64 mTakeoff roll, 1,805 m Left ahead, 2,135 m

Side view from the start of the roll to the end of Climb 3 at 896 ft.

Reached 35 ft with 1,947 m of runway left; gear up at 190 ft, inside the 400 ft that gets full marks; then climbing at 1,850 fpm on average to 896 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3145 kt avgtarget 161THRESHOLDRUNWAY END6080100120KNOTS ALONG THE ROLLnose up on the runway · 207 m · 2.6 sRotate 131 kttarget 127Liftoff 136 ktGear up 190 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 161150 kt10050020°10°0°nose up on the runway · 207 m · 2.6 sROTATELIFTOFFtarget 127held 9.3°8.3° off · 2.9°/s9° at 35 ftAIRSPEEDPITCH0306090120150180210240270 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2 to 3° a second, the rates airliners are rotated at: a trace steeper than both is a faster rotation, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate.

20°10°0°ROTATELIFTOFF35 FT3°/s8.3° off · 2.9°/s2°/s9° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5 sseconds from rotation
PitchRotation began2 to 3°/s from rotationNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 71.435 of 7
Gear down
Landing flap
Sink rate630 fpm440 fpm
On glideslope2.2°1.8°
On centreline0.1° off0.3° off
On speed+23 kt+21 kt
Wings level0° bank0° bank

At the 500 ft gate: glideslope more than 1° off the runway's 3° and speed more than 17 kt above the approach speed of 114 kt.

When the approach was stable

Every check met from 4 nm to 2.3 nm, then not again: low from 2.3 nm and fast from 2.2 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to VECA 05

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

On the glideslope from 4 nm to 2.3 nm, then low to the threshold (up to 270 ft under).

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND980425205971,000 ft gate7 of 7747 ft · 137 kt500 ft gate5 of 7on glideslopeon speed317 ft · 135 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 20× larger than distances along the final.

Inside the 1° band all the way from 4 nm, never more than 18 m off the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR49 m L049 m RLEFT ↑RIGHT ↓1° BAND12 m L13 m R11 m R9 m R11 m R14 m R
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 29 kt fast at the 1,000 ft gate, closing to 17 at 500 ft and 10 at the threshold.

Inside the speed band from 4 nm to 2.2 nm, then fast to the threshold (up to +23 kt).

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

100120140160 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 114+24 kt+23 kt+17 kt+16 kt+13 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on VECA 05

Over the threshold

Threshold height100.00
19ft
Threshold speed94.26
126kttarget 114, 12 fast
Centreline offset100.00
3.54m R
Bank100.00
0.6°steepest
Flare96.48

Excellent landing flare

It lost 3.5 points, for starting the flare at 10 ft agl, below the usual 11 ft agl–45 ft agl.

Touchdown

Past threshold100.00
391m
Centreline100.00
2.92m R
Speed100.00
113kttarget 114 or less
Touchdown rate100.00
-203fpm
Impact100.00
1.26G
BouncesOk
None
Bank100.00
0.5°as the wheels touched

Rollout

Rollout distance100.00
1,214m66 % used
Rollout alignment98.99
7.08m L

Side view — the last 1,727 m of the approach.

Crossed the threshold at 19 ft, 31 ft below the 50 ft target; began the flare late, at 10 ft. Touched down 391 m in, 86 m past the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,727 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

19 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 10 ft · −169 fpm · 3° · 122 ktdescent slowed at 7 ft · −72 fpm · 3.3°−203 fpm · 3.8° nose up · 114 kt Ideal — 50 ft, down at 305 m This flight — 19 ft, down at 391 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 170 fpm at the flare to 70 fpm at 7 ft, then back up to 200 fpm at touchdown. The nose came up 0.9° on the way down. Into the flare at 122 kt, 8 kt over the 114 kt approach speed, and 114 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−203 fpm at touchdown3.8° at touchdown, +0.9° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,727 m of the 2,436 m runway, to the same scale as the side view.

Touched down 2.8 m right of the centreline, and stayed about there down the rollout, 5.5 m left at the widest. No crosswind: nothing to correct for. Touched down straight, wings level.

Wind 000° at 1 kt · 1 kt head · 0 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ FULL SCORE TO 503 M 391 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

The 391 m touchdown sits inside the full-score zone. The arrival was smooth.

Runway used 1,605 m of 2,436 m · 66 %
In the air over the runway, 391 mRollout, 1,214 m Left over, 831 m

The stop — touchdown to taxi speed.

From 115 kt at touchdown to taxi speed (30 kt) in 39 s, an average deceleration of 0.12 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 1,252 m30 kt · 1,524 mtouchdown1,585 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
