My FS Flights logo MY FS FLIGHTS
KORD
Chicago, United States
Runway 22L
Elevation659 ft asl
Weight377,710 lbs
Fuel29,930 lbs
WindCalm

Flight Score

96.62 %
CYUL
Montréal, Canada
Runway 24R
Elevation102 ft asl
Weight360,336 lbs
Fuel11,282 lbs
WindCalm
7 Mar 2025 1:52 697 nm Airbus A330-900 18,648 lbs
Departure Score
91.08 %
Enroute Score
100.00 %
Arrival Score
98.78 %

What went well

Touched down at -251 fpm — a soft arrival
Touchdown 1,296 ft in — inside the full-score zone
Threshold crossed at 47 ft and 138 kt — both inside band

What held you back

Departure Climb 3 — gear not retracted; Landing gear up at 0 ft agl at 0 %, climb speed 146 kt against 184 kt at 69 %, −2.82 points
Arrival Taxi — Taxi Lights at 0 %, −0.33 points
Departure Roll — Runway alignment max 29.6 ft left at 91 %, −0.12 points

Next time

Departure

Raise the gear lever promptly once a positive rate of climb is confirmed after liftoff.

What happened: The landing gear was never raised during the initial climb and was still down when the climb ended.

Watch for: Landing gear lever: UP promptly after confirming a positive rate of climb.

See Departure Climb 3

Arrival

Nothing to change in the speed, the height or the flare. Keep the landing attitude held until the mains are on, so the aircraft is not let down onto the runway in the last moment.

What happened: The touchdown reached 1.6 g. Nothing before it explains that: threshold speed and height were within limits and the flare was flown normally.

Watch for: G meter at touchdown: a little less than 1.6 g next time

See Arrival Touchdown

Make sure that you retract the landing gear once you have a positive rate of climb and there is no usable runway left to land back on.

Read more in Improve Your Take-Offs

Start to finish · 17 stages, 15 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 16 minutes and covered 2 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 6 kt0 kt min to max 8 kt 0 4 kt
100 % Average speed turning corners 0 ktmax 0 kt 0 0 kt
100 % Average g force 1.00 g0.98 g min to max 1.02 g 1.00 1.00 g
Info Average pitch angle -0.6 °-1.0 ° min to max -0.0 ° -0.8 -0.5 °
Info Average bank angle 0.3 °0.0 ° min to max 0.7 ° 0.4 0.3 °

Events

Info Taxi Lights On  · 3 kt
Info Parking Brake Off  · 7 kt
Info Parking Brake On  · 4 kt
Info Parking Brake Off  · 4 kt
Info Landing Lights On  · 16 kt
Info Beacon Lights Off  · 3 kt
Info Beacon Lights On  · 3 kt
Info Taxi Lights Off  · 3 kt
Info Taxi Lights On  · 3 kt
Info Strobe Lights On  · 3 kt
Info Parking Brake On  · 4 kt
Info Parking Brake Off  · 4 kt
Departure Runway Entry Entering runway 22L at KORD Chicago O'Hare International Airport, Average speed was 10 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 9 kt0 kt min to max 20 kt 0 20 kt
Info Average pitch angle -0.3 °-0.5 ° min to max 0.2 ° -0.5 0.2 °
Info Average bank angle 0.4 °0.3 ° min to max 0.8 ° 0.3 0.8 °
Info Average g force 1.01 g0.99 g min to max 1.02 g 1.00 1.01 g
Departure Roll 98.15Departure roll runway 22L at KORD Chicago O'Hare International Airport. Takeoff distance 5,885 ft 73 % of runway. Rotation speed was 146 kt. Local weather - Temperature 37 °F. .
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 5,885 ft73 % of runway
100 % Rotation speed was 146 ktTarget 148 kt
91 % Runway alignment max 29.6 ft left29.6 ft left to 0.0 ft left 10.5 4.6 ft
100 % Average g force 1.01 g0.94 g min to max 1.15 g 0.99 1.13 g
100 % Takeoff Bounce
Info Average pitch angle 0.8 °-0.5 ° min to max 15.6 ° 0.1 15.6 °
Info Average bank angle 0.3 °0.0 ° min to max 1.6 ° 0.7 1.2 °
Departure Climb 1 99.87Departure climb to 50 ft agl from runway 22L KORD Chicago O'Hare International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.1 °-0.1 ° min to max -0.0 ° -0.0 -0.1 °
100 % Average speed 152 kt151 kt min to max 153 kt 153 151 kt
100 % Steepest bank angle 1.9 °1.3 ° min to max 1.9 ° 1.3 1.9 °
99 % Average g force 1.40 g1.34 g min to max 1.43 g 1.34 1.40 g
Info Average VSI 840 fpm569 fpm min to max 1,352 fpm 569 1,352 fpm
Info Average altitude 6 ft agl0 ft agl min to max 19 ft agl 0 19 ft agl
Info Average pitch angle 18.2 °16.2 ° min to max 21.0 ° 16.2 21.0 °
Departure Climb 2 99.75Departure climb to 400 ft agl from 22L KORD Chicago O'Hare International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.1 °-0.4 ° min to max -0.1 ° -0.1 -0.4 °
100 % Average speed 151 kt149 kt min to max 151 kt 151 149 kt
100 % Steepest bank angle 2.5 °1.0 ° min to max 2.5 ° 1.9 2.5 °
98 % Average g force 1.25 g0.78 g min to max 1.38 g 1.38 0.82 g
Info Average VSI 2,196 fpm1,435 fpm min to max 3,634 fpm 1,435 3,071 fpm
Info Average altitude 77 ft agl21 ft agl min to max 340 ft agl 21 340 ft agl
Info Average pitch angle 21.9 °17.7 ° min to max 23.6 ° 21.3 17.7 °

Events

Info Taxi Lights Off 163 ft agl · 150 kt
Departure Climb 3 57.63Departure climb to 1,000 ft agl from 22L KORD Chicago O'Hare International Airport.
ScoreDescriptionStartProfileEnd
69 % Climb speed 146 kt144 kt min to max 147 ktTarget 184 kt, 38 kt slow 147 147 kt
100 % Steepest bank angle 2.5 °0.8 ° min to max 2.5 ° 2.5 0.8 °
100 % Average g force 0.94 g0.87 g min to max 0.99 g 0.87 0.96 g
0 % Landing gear up at 0 ft aglTarget by 400 ft agl
Info Heading variation -0.7 °-0.8 ° min to max -0.5 ° -0.5 -0.8 °
Info Average VSI 2,329 fpm2,142 fpm min to max 2,772 fpm 2,772 2,351 fpm
Info Average altitude 719 ft agl399 ft agl min to max 994 ft agl 399 994 ft agl
Info Average pitch angle 17.6 °17.3 ° min to max 18.0 ° 17.8 17.5 °

Events

Fail Gear Not Retracted
Info Landing Gear Down 487 ft agl · 146 kt
Enroute Climb 100.00Enroute climb started 1 mile south east of Bensenville (Illinois, United States). Climbing from 1,692 ft asl to 41,014 ft asl, an increase of 39,322 ft in 24 minutes and covering 190 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 234 kt147 kt min to max 285 kt 147 241 kt
100 % Steepest bank angle 31.6 °0.0 ° min to max 31.6 ° 0.9 0.2 °
100 % Average g force 1.01 g0.82 g min to max 1.22 g 0.95 1.00 g
Info Average VSI 1,669 fpm-4 fpm min to max 3,338 fpm 2,354 -4 fpm
Info Average altitude 21,015 ft asl1,692 ft asl min to max 41,014 ft asl 1,692 41,014 ft asl
Info Average pitch angle 6.9 °2.4 ° min to max 17.5 ° 17.5 2.4 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Fully Retracted 2,253 ft agl · 173 kt
Info Landing Lights Off 6,683 ft agl · 271 kt
Info Beacon Lights Off 8,399 ft agl · 283 kt
Info Beacon Lights On 8,478 ft agl · 283 kt
Enroute Level 100.00Enroute level cruise started overhead MI29 Gooding Airport Whitmore Lake (Michigan, United States) and lasted 31 minutes, covering 291 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,551 ft of 41,009 ft asl40,716 ft asl min to max 41,032 ft asl 41,016 40,716 ft asl
100 % Average speed 241 kt239 kt min to max 243 kt 241 239 kt
100 % Steepest bank angle 7.6 °0.0 ° min to max 7.6 ° 0.0 0.0 °
100 % Average g force 0.99 g0.94 g min to max 1.01 g 0.98 0.95 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 2.4 °-0.0 ° min to max 2.5 ° 2.4 -0.0 °
Enroute Descent 100.00Enroute descent started 3 miles south of CYTR CFB Trenton Trenton (Ontario, Canada). Descent from 40,351 ft asl to 20,010 ft asl, a decrease of 20,341 ft in 18 minutes and covering 129 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 232 kt207 kt min to max 265 kt 242 208 kt
100 % Steepest bank angle 7.4 °0.0 ° min to max 7.4 ° 6.1 0.5 °
100 % Average g force 1.00 g0.95 g min to max 1.08 g 0.97 1.00 g
Info Average VSI -1,676 fpm-2,713 fpm min to max -30 fpm -2,415 -30 fpm
Info Average altitude 32,271 ft asl20,010 ft asl min to max 40,351 ft asl 40,351 20,010 ft asl
Info Average pitch angle 0.8 °-1.3 ° min to max 4.7 ° -0.7 4.7 °
Info Turn coordination 00 min to max 0 0 0
Enroute Level 2 100.00Enroute level cruise started 1 mile south east of KMAA Long Sault Airstrip Massena (Ontario, Canada) and lasted 2 minutes, covering 9 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±1,501 ft of 19,977 ft asl19,788 ft asl min to max 20,016 ft asl 20,013 19,788 ft asl
100 % Average speed 209 kt204 kt min to max 211 kt 209 204 kt
100 % Steepest bank angle 0.5 °0.0 ° min to max 0.5 ° 0.1 0.3 °
100 % Average g force 0.99 g0.97 g min to max 1.01 g 1.01 0.97 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 4.3 °3.0 ° min to max 4.7 ° 4.7 3.0 °
Enroute Descent 2 100.00Enroute descent started 2 miles west of CYCC Cornwall Regional Airport Cornwall (Quebec, Canada). Descent from 19,642 ft asl to 1,479 ft asl, a decrease of 18,163 ft in 20 minutes and covering 69 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 159 kt136 kt min to max 206 kt 205 140 kt
100 % Steepest bank angle 26.2 °0.0 ° min to max 26.2 ° 0.1 0.1 °
100 % Average g force 1.01 g0.86 g min to max 1.15 g 1.00 0.97 g
Info Average VSI -608 fpm-1,298 fpm min to max 279 fpm -946 -542 fpm
Info Average altitude 5,336 ft asl1,479 ft asl min to max 19,642 ft asl 19,642 1,479 ft asl
Info Average pitch angle 1.6 °-3.5 ° min to max 7.5 ° 3.0 3.0 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Position 1 16,154 ft agl · 261 kt
Info Flaps Position 1 14,934 ft agl · 250 kt
Info Flaps Position 2 14,912 ft agl · 250 kt
Info Flaps Position 3 12,768 ft agl · 225 kt
Info Landing Lights On 12,505 ft agl · 222 kt
Info Flaps Position 3 4,662 ft agl · 190 kt
Info Flaps Position 4 4,652 ft agl · 189 kt
Info Landing Gear Down 2,563 ft agl · 151 kt
Info Taxi Lights On 2,521 ft agl · 151 kt
Arrival Approach 100.00Final approach to runway 24R at CYUL Montreal / Pierre Elliott Trudeau International Airport. Descent from 1,403 ft agl to 85 ft agl in 146 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates
Arrival Landing 99.87Landing on runway 24R at CYUL Montreal / Pierre Elliott Trudeau International Airport, runway length 10,970 ft. Good threshold height. Threshold speed was good at 138 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 138 kt. Target 132 kt
100 % Good threshold height.Target 50 ft agl
99.9 % Excellent landing flare. It lost 0.1 points, for taking only 233 fpm of the sink out.
100 % Runway alignment max 21.8 ft left21.8 ft left to 18.5 ft left 20.0 19.4 ft
99 % Steepest bank angle 2.4 °0.0 ° min to max 2.4 ° 0.7 1.0 °
100 % Peak g force 1.14 g0.92 g min to max 1.14 g 0.95 1.01 g
Info Average speed 138 kt134 kt min to max 139 kt 138 134 kt
Info Average VSI -455 fpm-610 fpm min to max -304 fpm -510 -385 fpm
Info Average altitude 19 ft agl-5 ft agl min to max 48 ft agl 48 -5 ft agl
Info Average pitch angle 3.9 °2.5 ° min to max 5.1 ° 2.5 4.1 °
02505007501,0001,2501,50001223354658Runway Distance ftLanding Height ft02505007501,0001,2501,500-110-88-66-44-22022446688110Runway Distance ftRunway Width ft
Arrival Touchdown 99.02Touchdown distance was good at 1,295 ft. Touchdown speed at 134 kt was a little fast. Touchdown rate was fair at -251 fpm. Runway touchdown position was slightly misaligned by 20 ft from centreline. Local weather - Temperature 32 °F. .
ScoreDescriptionStartProfileEnd
99.9 % Touchdown rate was -251 fpm.
100 % Touchdown distance was 1,296 ftTarget 1,500 ft
100 % Speed at touchdown 134 ktTarget below 132 kt
100 % Runway alignment max 20.2 ft left19.4 ft left 19.4 19.5 ft
100 % Steepest bank angle 1.0 °0.0 ° min to max 1.0 ° 1.0 0.3 °
81 % Peak g force 1.64 g1.01 g min to max 1.64 g 1.01 1.26 g
100 % Landing Bounce
Info Average speed 134 kt134 kt min to max 134 kt 134 134 kt
Info Average pitch angle 3.9 °3.6 ° min to max 4.1 ° 4.1 3.6 °
Arrival Rollout 100.00Total landing distance 3,112 ft, 28 % of runway. Runway rollout alignment was slightly misaligned by 25 ft from centreline.
ScoreDescriptionStartProfileEnd
100 % Landing distance 3,112 ft28 % of runway.
100 % Runway alignment max 25.2 ft left25.2 ft left to 0.0 ft left 25.2 22.6 ft
100 % Average g force 0.99 g0.89 g min to max 1.10 g 1.08 0.97 g
Info Average speed 55 kt32 kt min to max 58 kt 58 32 kt
Info Average pitch angle 2.7 °-1.0 ° min to max 3.6 ° 3.6 -0.7 °
Info Average bank angle 0.9 °0.3 ° min to max 1.2 ° 0.3 0.5 °
Runway Exit Exiting runway, average speed 39 kt
ScoreDescriptionStartProfileEnd
Info Average speed 13 kt3 kt min to max 30 kt 30 6 kt
Info Average pitch angle -0.8 °-1.0 ° min to max -0.5 ° -0.7 -0.6 °
Info Average bank angle 0.4 °0.1 ° min to max 0.9 ° 0.6 0.1 °
Info Average g force 1.00 g0.96 g min to max 1.03 g 1.02 1.00 g

Events

Info Flaps Fully Retracted  · 60 kt
Info Flaps Fully Retracted  · 56 kt
Info Landing Lights Off  · 45 kt
Info Taxi Lights Off  · 44 kt
Arrival Taxi 95.00Taxiing to the parking from the runway took 4 minutes and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 11 kt0 kt min to max 17 kt 7 0 kt
100 % Average speed turning corners 0 ktmax 0 kt 0 0 kt
100 % Average g force 1.00 g0.96 g min to max 1.03 g 0.99 1.00 g
Info Average pitch angle -0.7 °-1.0 ° min to max -0.5 ° -0.6 -0.6 °
Info Average bank angle 0.2 °0.0 ° min to max 0.5 ° 0.1 0.1 °

Events

Fail Taxi Lights
Info Strobe Lights Off  · 1 kt
Info Parking Brake On  · 1 kt

Takeoff from KORD 22L

Taxi out

LightsOk
All on
Taxi speed100.00
8kt peak

The roll

Takeoff roll100.00
5,885ft73 %
Runway alignment90.77
29.6ft L
Rotation speed100.00
146kttarget 148, 2 early

Liftoff pitch close to a tail strike

The wheels left at 16.2°, at or past this aircraft's 14.4° tail strike.

The tail can only touch while the main wheels are still on the runway, so the margin that matters is the one at liftoff. Rotate at the rotate speed, at the normal rate, and let the aircraft fly itself off at its own attitude: keep the pull going towards the climb attitude only once the wheels have left. Rotating early, or pulling faster than the aircraft can lift off, is what eats the margin.

Liftoff and climb

Liftoff
152ktat 16.2°
Rotation
3.4°/sover 4.8 s, gaining 6 kt
35 ft
151ktat 22.4°, 1.7 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
1.9°steepest
Climb 3 speed69.08
146kttarget 184

Plan view the roll down the 8,058 ft runway.

Rolled from 648 ft in, drifted 30 ft left of the centreline and was back on it to lift off. Airborne 73 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length.

2,0004,0006,0008,000THRESHOLDLEFT ↑RIGHT ↓75 %widest 30.1 ft LROLL 648 FT INAirborne 5,912 ft from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 5,912 ft of 8,058 ft · 73 %
Behind the start of the roll, 648 ftTakeoff roll, 5,264 ft Left ahead, 2,146 ft

Side view from the start of the roll to the end of Climb 3 at 996 ft.

Reached 35 ft with 1,686 ft of runway left; then climbing at 2,430 fpm on average to 996 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3146 kt avgtarget 184THRESHOLDRUNWAY END6080100120KNOTS ALONG THE ROLLnose up on the runway · 928 ft · 4.8 sRotate 146 kttarget 148Liftoff 152 kt
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 184180 kt12060025°13°0°nose up on the runway · 928 ft · 4.8 sROTATELIFTOFFtarget 148held 19.6°16.2° off · 3.4°/s22° at 35 ftAIRSPEEDPITCH02040 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 1.6 to 2.4° a second, the middle half of rotation rates flown by other Airbus A330-900 pilots over the last 180 days (56 takeoffs); the grey pair are 2 to 3° a second, the rates airliners are rotated at. A trace steeper than both green lines is a faster rotation than most, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 14.4°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

25°13°0°TAIL STRIKE 14.4°ROTATELIFTOFF35 FT16.2° off · 3.4°/s3°/s2.4°/s2°/s1.6°/s22° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5+6+7 sseconds from rotation
PitchRotation began1.6 to 2.4°/s, other Airbus A330-900 pilots2 to 3°/s from rotation, airlinersTail strikeNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate750 fpm610 fpm
On glideslope3.1°3.1°
On centreline0.0° off0.1° off
On speed+4.0 kt+6.0 kt
Wings level0° bank1° bank

When the approach was stable

Every check met from 4 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to CYUL 24R

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 70 ft above the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 1,000 ft past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,3677203742131,000 ft gate7 of 71,094 ft · 136 kt500 ft gate7 of 7566 ft · 138 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 35× larger than distances along the final.

Inside the 1° band all the way from 4 nm, never more than 30 ft off the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR90 ft L090 ft RLEFT ↑RIGHT ↓1° BAND32 ft R1 ft R11 ft L21 ft L16 ft R5 ft L
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 33 kt fast at the 1,000 ft gate, closing to 20 at 500 ft and 10 at the threshold.

Inside the speed band all the way, between +2 kt and +9 kt on the approach speed of 132 kt.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

120140160180 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 132+6 kt+8 kt+5 kt+7 kt+6 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on CYUL 24R

Over the threshold

Threshold height100.00
47ft
Threshold speed100.00
138kttarget 132, 6 fast
Centreline offset100.00
21.8ft L
Bank98.87
2.4°steepest
Flare99.94

Excellent landing flare

It lost 0.1 points, for taking only 233 fpm of the sink out.

Touchdown

Past threshold100.00
1,296ft
Centreline100.00
20.2ft L
Speed100.00
134kttarget 132, 2 fast
Touchdown rate99.87
-251fpm
Impact80.95
1.64G
BouncesOk
None
Bank100.00
1.0°as the wheels touched

Rollout

Rollout distance100.00
1,718ft28 % used
Rollout alignment100.00
25.2ft L

Taxi in

Lights50.00
Offtaxi lights, on 0% of the taxi
Taxi speed100.00
17kt peak

Side view — the last 5,000 ft of the approach.

Crossed the threshold at 47 ft, close to the 50 ft target; began the flare at 33 ft. Touched down 1,296 ft in, 296 ft past the ideal 1,000 ft.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 5,000 ft across. The dashed line is the ideal, 50 ft over the threshold and down 1,000 ft in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

47 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 33 ft · −468 fpm · 4° · 138 ktdescent slowed at 1 ft · −238 fpm · 4.1°−250 fpm · 4.1° nose up · 134 kt Ideal — 50 ft, down at 1,000 ft This flight — 47 ft, down at 1,296 ft

Sink and pitch — through the flare, lined up with the side view.

The sink went from 470 fpm at the flare to 250 fpm at touchdown. The pitch barely changed. Into the flare at 138 kt, 6 kt over the 132 kt approach speed, and 134 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−250 fpm at touchdown4.1° at touchdown, +0° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 5,000 ft of the 10,970 ft runway, to the same scale as the side view.

Touched down 20 ft left of the centreline, and stayed about there down the rollout, 24 ft left at the widest. Calm: nothing to correct for. Touched down with the nose 3° right of the track, wings level.

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

1,0002,0003,0004,0005,000 THRESHOLD LEFT ↑ RIGHT ↓ FULL SCORE TO 1,650 FT 1,296 ft past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

The 1,296 ft touchdown sits inside the full-score zone. The arrival was smooth.

Runway used 3,014 ft of 10,970 ft · 27 %
In the air over the runway, 1,296 ftRollout, 1,718 ft Left over, 7,956 ft

The stop — touchdown to taxi speed.

From 59 kt at touchdown to taxi speed (30 kt) in 14 s, an average deceleration of 0.11 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

02040608030 kt · 1,898 fttouchdown1,974 ftkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Flight narrative

The flight began with a taxiing period from the parking to the runway, which took 15 minutes and covered a distance of 1 nautical mile. The aircraft, an Airbus A330-900, then departed from runway 22L at KORD Chicago O'Hare International Airport. The takeoff distance was 5,164 feet, which accounted for 64% of the runway. The liftoff speed was 153 knots.

As the aircraft climbed, it started its enroute climb 1 mile south east of Bensenville, Illinois. The climb took 24 minutes and covered a distance of 183 nautical miles, with an increase in altitude from 1,692 feet above sea level to 41,014 feet above sea level, a total increase of 39,322 feet.

The enroute level cruise started overhead MI29 Gooding Airport Whitmore Lake, Michigan, and lasted for 31 minutes, covering a distance of 290 nautical miles. The aircraft then began its enroute descent 3 miles south of CYTR CFB Trenton, Ontario, Canada. The descent took 18 minutes and covered a distance of 128 nautical miles, with a decrease in altitude from 40,351 feet above sea level to 20,010 feet above sea level, a total decrease of 20,341 feet.

The aircraft then entered another enroute level cruise, this time starting 1 mile south east of KMAA Long Sault Airstrip Massena, Ontario, Canada, and lasting for 2 minutes, covering a distance of 9 nautical miles. The enroute descent started 2 miles west of CYCC Cornwall Regional Airport Cornwall, Quebec, Canada. The descent took 20 minutes and covered a distance of 47 nautical miles, with a decrease in altitude from 19,642 feet above sea level to 1,488 feet above sea level, a total decrease of 18,154 feet.

The final approach to runway 24R at CYUL Montreal / Pierre Elliott Trudeau International Airport was made from the north east, with a heading of 222.0 degrees at 4 nautical miles and 1,377 feet above ground level. The landing was successful, with a touchdown distance of 1,447 feet, which was 28% of the runway length. The touchdown speed was 134 knots, which was a little fast, and the touchdown rate was fair at -257 feet per minute. The runway touchdown alignment was very good.

The local weather at the time of landing was 32 degrees Fahrenheit. The total landing distance was 3,106 feet, and the runway rollout alignment was very good. The taxiing period from the runway to the parking took 4 minutes and covered less than 1 nautical mile. The total flight distance was 667 nautical miles, and the flight duration was 112 minutes. The aircraft used 18,648 pounds of fuel during the flight.

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
