KPHX
Phoenix, United States
Runway 25R
Elevation1,119 ft asl
Weight181,303 lbs
Fuel45,538 lbs
WindCalm

Flight Score

99.30 %
PHNL
Honolulu, United States
Runway 04R
Elevation7 ft asl
Weight149,818 lbs
Fuel13,680 lbs
Wind83° · 11 kn · 5 kn cross
22 May 2025 6:23 2565 nm Boeing 737-MAX8 31,858 lbs
Departure Score
99.11 %
Enroute Score
100.00 %
Arrival Score
98.78 %

What went well

Touched down at -197 fpm — a soft arrival
Straight touchdown — 3.9 ft off the centreline, no bounce
Flare on profile — 100 %

What held you back

Departure Roll — Takeoff distance 8,279 ft at 78 %, −0.30 points
Arrival Touchdown — Touchdown distance was 2,340 ft at 72 %, −0.28 points
Arrival Landing — Threshold height at 58 ft agl was slightly above target at 92 %, −0.13 points

Next time

Arrival

Fly a slightly steeper approach path to cross the threshold at 50 ft agl instead of 58 ft agl.

What happened: The aircraft crossed the threshold at 58 ft agl against a 50 ft agl target, above the normal profile. This fault pattern is often followed by a long touchdown beyond the target point, and here the aircraft touched down at 2,340 ft against a 1,500 ft target.

Watch for: Radio altimeter against the 50 ft threshold crossing target on short final.

See Arrival LandingArrival Touchdown

The rudder input is a changing profile through the roll rather than one that is held. So the demand on your right foot starts large at power application, eases as speed builds and the rudder gains authority, then jumps again at rotation.

Read more in Improve Your Take-Offs

Start to finish · 19 stages, 17 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 10 minutes and covered 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 9 kt0 kt min to max 17 kt 2 9 kt
100 % Average speed turning corners 9 ktmax 9 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle -0.4 °-0.7 ° min to max -0.3 ° -0.4 -0.4 °
Info Average bank angle 0.1 °0.0 ° min to max 0.4 ° 0.0 0.1 °

Events

Info Battery Master On 11 ft agl
Info Engine 2 Started 11 ft agl
Info Beacon Lights Switched On 11 ft agl
Info Landing Gear Down 11 ft agl
Info Parking Brake On 11 ft agl
Info Engine 1 Started 11 ft agl
Info Parking Brake Off 11 ft agl
Info Taxi Lights Switched On 11 ft agl
Info Flaps Position 1 11 ft agl
Info Landing Lights Switched On 11 ft agl
Info Navigation Lights Switched On 11 ft agl
Info Strobe Lights Switched On 11 ft agl
Info Flaps Position 2 11 ft agl · 2 kt
Info Flaps Position 3 11 ft agl · 3 kt
Departure Runway Entry Entering runway 25R at KPHX Phoenix Sky Harbor International Airport, Average speed was 9 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 9 kt9 kt min to max 10 kt 9 10 kt
Info Average pitch angle -0.4 °-0.5 ° min to max -0.4 ° -0.4 -0.5 °
Info Average bank angle 0.2 °0.0 ° min to max 0.3 ° 0.0 0.3 °
Info Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Departure Roll 95.53Departure roll runway 25R at KPHX Phoenix Sky Harbor International Airport. Takeoff distance 8,279 ft 81 % of runway. Rotation speed was 164 kt. Local weather - Temperature 104 °F. .
ScoreDescriptionStartProfileEnd
78 % Takeoff distance 8,279 ft81 % of runway
100 % Rotation speed was 164 ktTarget 152 kt
100 % Runway alignment max 6.6 ft right0.0 ft left to 6.6 ft right -1.5 -0.7 ft
100 % Average g force 1.00 g0.97 g min to max 1.08 g 1.00 1.08 g
100 % Takeoff Bounce
Info Average pitch angle -0.0 °-0.6 ° min to max 10.1 ° -0.6 10.1 °
Info Average bank angle 0.2 °0.0 ° min to max 0.4 ° 0.2 0.2 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 25R KPHX Phoenix Sky Harbor International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.0 °0.0 ° min to max 0.0 ° 0.0 0.0 °
100 % Average speed 170 kt169 kt min to max 172 kt 169 172 kt
100 % Steepest bank angle 0.9 °0.2 ° min to max 0.9 ° 0.2 0.9 °
100 % Average g force 1.17 g1.09 g min to max 1.24 g 1.09 1.09 g
Info Average VSI 638 fpm130 fpm min to max 1,151 fpm 130 1,151 fpm
Info Average altitude 19 ft agl0 ft agl min to max 47 ft agl 0 47 ft agl
Info Average pitch angle 12.5 °10.3 ° min to max 13.0 ° 10.3 13.0 °
Departure Climb 2 100.00Departure climb to 400 ft agl from 25R KPHX Phoenix Sky Harbor International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.0 °0.0 ° min to max 0.2 ° 0.0 0.2 °
100 % Average speed 172 kt172 kt min to max 173 kt 172 172 kt
100 % Steepest bank angle 3.6 °1.0 ° min to max 3.6 ° 1.0 1.8 °
100 % Average g force 1.08 g0.97 g min to max 1.11 g 1.09 0.97 g
Info Average VSI 1,584 fpm1,181 fpm min to max 2,738 fpm 1,181 2,738 fpm
Info Average altitude 105 ft agl49 ft agl min to max 396 ft agl 49 396 ft agl
Info Average pitch angle 14.3 °13.1 ° min to max 16.1 ° 13.1 15.9 °

Events

Info Landing Gear Up 87 ft agl · 182 kt
Departure Climb 3 100.00Departure climb to 1,000 ft agl from 25R KPHX Phoenix Sky Harbor International Airport.
ScoreDescriptionStartProfileEnd
100 % Climb speed 170 kt168 kt min to max 172 ktTarget 183 kt, 13 kt slow 172 168 kt
100 % Steepest bank angle 2.0 °1.8 ° min to max 2.0 ° 1.8 2.0 °
100 % Average g force 0.97 g0.95 g min to max 0.99 g 0.98 0.95 g
100 % Landing gear up at 71 ft aglTarget by 400 ft agl
Info Heading variation 0.6 °0.3 ° min to max 0.9 ° 0.3 0.9 °
Info Average VSI 2,912 fpm2,766 fpm min to max 2,977 fpm 2,766 2,932 fpm
Info Average altitude 686 ft agl442 ft agl min to max 932 ft agl 442 932 ft agl
Info Average pitch angle 16.6 °16.2 ° min to max 16.8 ° 16.2 16.7 °
Enroute Climb 100.00Enroute climb started overhead Central City (Arizona, United States). Climbing from 2,110 ft asl to 27,318 ft asl, an increase of 25,208 ft in 17 minutes and covering 103 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 265 kt167 kt min to max 306 kt 168 305 kt
100 % Steepest bank angle 22.5 °0.0 ° min to max 22.5 ° 2.0 0.2 °
100 % Average g force 0.98 g0.82 g min to max 1.08 g 0.95 1.00 g
Info Average VSI 1,566 fpm170 fpm min to max 3,087 fpm 2,908 170 fpm
Info Average altitude 15,236 ft asl2,110 ft asl min to max 27,318 ft asl 2,110 27,318 ft asl
Info Average pitch angle 6.8 °2.8 ° min to max 16.6 ° 16.6 2.8 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Position 1 2,475 ft agl · 236 kt
Info Flaps Fully Retracted 2,501 ft agl · 237 kt
Info Landing Lights Switched Off 9,160 ft agl · 290 kt
Info Taxi Lights Switched Off 9,276 ft agl · 292 kt
Enroute Level 100.00Enroute level cruise started 21 miles south of La Paz Valley (Arizona, United States) and lasted 2 minutes, covering 12 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±1,868 ft of 27,511 ft asl27,350 ft asl min to max 27,650 ft asl 27,350 27,650 ft asl
100 % Average speed 305 kt304 kt min to max 305 kt 305 304 kt
100 % Steepest bank angle 0.4 °0.0 ° min to max 0.4 ° 0.2 0.4 °
100 % Average g force 1.00 g0.99 g min to max 1.02 g 1.00 1.01 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 2.8 °2.7 ° min to max 2.9 ° 2.9 2.7 °
Enroute Climb 2 100.00Enroute climb started 17 miles east of CN98 Walters Camp Airport Palo Verde (California, United States). Climbing from 27,661 ft asl to 35,767 ft asl, an increase of 8,107 ft in 9 minutes and covering 64 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 285 kt260 kt min to max 306 kt 305 260 kt
100 % Steepest bank angle 0.4 °0.0 ° min to max 0.4 ° 0.3 0.1 °
100 % Average g force 1.00 g0.97 g min to max 1.11 g 1.00 1.00 g
Info Average VSI 889 fpm29 fpm min to max 1,501 fpm 29 620 fpm
Info Average altitude 31,652 ft asl27,661 ft asl min to max 35,767 ft asl 27,661 35,767 ft asl
Info Average pitch angle 4.3 °2.7 ° min to max 5.0 ° 2.7 5.0 °
Info Turn coordination 00 min to max 0 0 0
Enroute Level 2 100.00Enroute level cruise started 3 miles north west of Westmorland (California, United States) and lasted 317 minutes, covering 2,238 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,293 ft of 36,088 ft asl35,857 ft asl min to max 36,178 ft asl 35,857 36,165 ft asl
100 % Average speed 263 kt258 kt min to max 269 kt 259 264 kt
100 % Steepest bank angle 24.7 °0.0 ° min to max 24.7 ° 0.4 0.2 °
100 % Average g force 1.00 g0.97 g min to max 1.11 g 0.98 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 3.7 °3.1 ° min to max 4.6 ° 4.6 3.2 °
Enroute Descent 100.00Enroute descent started 84 miles north east of 18HI Brandt Field Port Saint Joe (Hawaii, United States). Descent from 36,165 ft asl to 2,581 ft asl, a decrease of 33,584 ft in 23 minutes and covering 130 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 258 kt175 kt min to max 280 kt 264 175 kt
100 % Steepest bank angle 25.1 °0.0 ° min to max 25.1 ° 0.0 0.2 °
100 % Average g force 1.02 g0.88 g min to max 1.14 g 1.00 0.99 g
Info Average VSI -1,639 fpm-3,400 fpm min to max 16 fpm 0 -544 fpm
Info Average altitude 17,603 ft asl2,581 ft asl min to max 36,165 ft asl 36,165 2,581 ft asl
Info Average pitch angle 0.5 °-2.3 ° min to max 3.6 ° 3.2 3.6 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Landing Lights Switched On 9,917 ft agl · 296 kt
Info Taxi Lights Switched On 9,853 ft agl · 296 kt
Info Flaps Position 1 4,772 ft agl · 248 kt
Info Flaps Position 2 3,196 ft agl · 217 kt
Info Flaps Position 3 3,189 ft agl · 216 kt
Enroute Level 3 100.00Enroute level cruise started 7 miles south of 'Ewa Beach (Hawaii, United States) and lasted 2 minutes, covering 5 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±626 ft of 2,363 ft asl2,286 ft asl min to max 2,522 ft asl 2,522 2,358 ft asl
100 % Average speed 170 kt145 kt min to max 175 kt 175 145 kt
100 % Steepest bank angle 25.2 °0.1 ° min to max 25.2 ° 0.7 0.1 °
100 % Average g force 1.06 g0.96 g min to max 1.13 g 0.98 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 5.0 °3.6 ° min to max 6.0 ° 4.4 4.0 °

Events

Info Landing Gear Down 2,293 ft agl · 182 kt
Info Flaps Position 4 2,288 ft agl · 181 kt
Info Flaps Position 5 2,286 ft agl · 181 kt
Info Flaps Position 6 2,286 ft agl · 179 kt
Info Flaps Position 7 2,293 ft agl · 177 kt
Info Flaps Position 8 2,314 ft agl · 169 kt
Enroute Descent 2 100.00Enroute descent started 4 miles south of Ocean Pointe (Hawaii, United States). Descent from 2,360 ft asl to 1,313 ft asl, a decrease of 1,047 ft in 2 minutes and covering 4 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 145 kt144 kt min to max 148 kt 145 146 kt
100 % Steepest bank angle 22.7 °0.1 ° min to max 22.7 ° 0.5 2.3 °
100 % Average g force 1.02 g0.91 g min to max 1.13 g 1.00 1.00 g
Info Average VSI -595 fpm-873 fpm min to max -10 fpm -10 -854 fpm
Info Average altitude 1,865 ft asl1,313 ft asl min to max 2,360 ft asl 2,360 1,313 ft asl
Info Average pitch angle 2.0 °0.4 ° min to max 4.1 ° 4.1 0.8 °
Info Turn coordination 00 min to max 0 0 0
Arrival Approach 100.00Final approach to runway 04R at PHNL Daniel K Inouye International Airport. Descent from 1,349 ft agl to 79 ft agl in 104 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates
Arrival Landing 98.10Landing on runway 04R at PHNL Daniel K Inouye International Airport, runway length 8,991 ft. Threshold height at 58 ft agl was slightly above target. Threshold speed was slightly above target at 146 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was slightly above target at 146 kt. Target 138 kt
92 % Threshold height at 58 ft agl was slightly above target.Target 50 ft agl
100 % The flare tracked the target profile exactly. The aircraft floated down the runway before touching. Touchdown was 2,340 ft past the threshold. Threshold speed was not the cause here - hold the aim point on the approach and let the aircraft settle rather than holding it off, and the touchdown comes back to the numbers.
100 % Runway alignment max 20.3 ft right4.6 ft right to 20.3 ft right -20.3 -4.6 ft
100 % Steepest bank angle 0.6 °0.0 ° min to max 0.6 ° 0.2 0.5 °
100 % Peak g force 1.07 g1.00 g min to max 1.07 g 1.05 1.04 g
Info Average speed 141 kt134 kt min to max 146 kt 146 134 kt
Info Average VSI -365 fpm-604 fpm min to max -238 fpm -604 -238 fpm
Info Average altitude 27 ft agl2 ft agl min to max 58 ft agl 58 2 ft agl
Info Average pitch angle 3.3 °2.3 ° min to max 4.8 ° 2.3 4.8 °
02505007501,0001,2501,5001,7502,0002,2502,5002,75001223354658Runway Distance ftLanding Height ft02505007501,0001,2501,5001,7502,0002,2502,5002,750-90-72-54-36-1801836547290Runway Distance ftRunway Width ft
Arrival Touchdown 95.80Touchdown point was 961 ft beyond the touchdown zone. Touchdown speed at 134 kt was good. Touchdown rate was good at -197 fpm. Runway touchdown alignment was perfect. Local weather - Temperature 84 °F. Wind 10 kt at 81 °. Crosswind: 5 kt Headwind: 9 kt.
ScoreDescriptionStartProfileEnd
100 % Touchdown rate was -197 fpm.
72 % Touchdown distance was 2,340 ftTarget 1,500 ft
100 % Speed at touchdown 134 ktTarget below 138 kt
100 % Runway alignment max 4.6 ft right4.2 ft right -4.6 -3.9 ft
100 % Steepest bank angle 1.1 °0.5 ° min to max 1.1 ° 0.5 1.1 °
100 % Peak g force 1.18 g1.04 g min to max 1.18 g 1.04 1.10 g
100 % Landing Bounce
Info Average speed 133 kt132 kt min to max 134 kt 134 133 kt
Info Average pitch angle 4.8 °4.8 ° min to max 4.8 ° 4.8 4.8 °
Arrival Rollout 100.00Total landing distance 4,633 ft, 52 % of runway. Runway rollout alignment was very good.
ScoreDescriptionStartProfileEnd
100 % Landing distance 4,633 ft52 % of runway.
100 % Runway alignment max 12.4 ft right0.0 ft left to 12.4 ft right -3.5 -11.0 ft
100 % Average g force 1.00 g0.97 g min to max 1.09 g 1.09 1.00 g
Info Average speed 118 kt65 kt min to max 127 kt 127 65 kt
Info Average pitch angle 2.6 °-0.6 ° min to max 4.7 ° 4.7 -0.5 °
Info Average bank angle 1.4 °0.0 ° min to max 2.0 ° 1.2 0.2 °
Runway Exit Exiting runway, average speed 38 kt
ScoreDescriptionStartProfileEnd
Info Average speed 32 kt2 kt min to max 60 kt 60 2 kt
Info Average pitch angle -0.5 °-0.8 ° min to max -0.4 ° -0.5 -0.5 °
Info Average bank angle 0.1 °0.0 ° min to max 0.7 ° 0.2 0.0 °
Info Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g

Events

Info Landing Lights Switched Off 11 ft agl · 22 kt
Info Navigation Lights Switched Off 11 ft agl · 16 kt
Info Strobe Lights Switched Off 11 ft agl · 16 kt
Info Navigation Lights Switched On 11 ft agl · 16 kt
Info Flaps Fully Retracted 11 ft agl · 7 kt
Arrival Taxi 100.00Taxiing to the parking from the runway took 4 minutes and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 11 kt3 kt min to max 18 kt 6 3 kt
100 % Average speed turning corners 8 ktmax 9 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.00 g 1.00 1.00 g
Info Average pitch angle -0.4 °-0.6 ° min to max -0.4 ° -0.4 -0.4 °
Info Average bank angle 0.1 °0.0 ° min to max 0.4 ° 0.0 0.0 °

Takeoff from KPHX 25R

Taxi out

LightsOk
All on
Taxi speed100.00
17kt peak9 kt in turns

The roll

Takeoff roll77.67
8,279ft81 %
Runway alignment100.00
6.6ft R
Rotation speed100.00
164kttarget 152, 12 late

Liftoff pitch close to a tail strike

The wheels left at 10.3°, 0.7° short of this aircraft's 11° tail strike.

The tail can only touch while the main wheels are still on the runway, so the margin that matters is the one at liftoff. Rotate at the rotate speed, at the normal rate, and let the aircraft fly itself off at its own attitude: keep the pull going towards the climb attitude only once the wheels have left. Rotating early, or pulling faster than the aircraft can lift off, is what eats the margin.

Liftoff and climb

Liftoff
169ktat 10.3°
Rotation
3.5°/sover 2.9 s, gaining 5 kt
35 ft
172ktat 12.8°, 2.4 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
0.9°steepest
Gear up100.00
71ftfull marks to 400 ft
Climb 3 speed100.00
170kttarget 183

Plan view the roll down the 10,274 ft runway.

Rolled from 296 ft in, drifted 6 ft right of the centreline and was back on it to lift off. Airborne 81 % of the way down the runway, past the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length.

2,0004,0006,0008,00010,000THRESHOLDLEFT ↑RIGHT ↓75 %widest 5.8 ft RROLL 296 FT INAirborne 8,294 ft from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 8,294 ft of 10,274 ft · 81 %
Behind the start of the roll, 296 ftTakeoff roll, 7,998 ft Left ahead, 1,980 ft

Side view from the start of the roll to the end of Climb 3 at 932 ft.

Reached 35 ft with 1,224 ft of runway left; gear up at 71 ft, inside the 400 ft that gets full marks; then climbing at 2,390 fpm on average to 932 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3170 kt avgtarget 183THRESHOLDRUNWAY END6080100120140KNOTS ALONG THE ROLLnose up on the runway · 882 ft · 2.9 sRotate 164 kttarget 152Liftoff 169 ktGear up 71 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 183180 kt12060020°10°0°nose up on the runway · 882 ft · 2.9 sROTATELIFTOFFtarget 152held 14.5°10.3° off · 3.5°/s13° at 35 ftAIRSPEEDPITCH020406080 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2.4 to 3.5° a second, the middle half of rotation rates flown by other Boeing 737-MAX8 pilots over the last 180 days (177 takeoffs); the grey pair are 2 to 3° a second, the rates airliners are rotated at. A trace steeper than both green lines is a faster rotation than most, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 11°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 11°ROTATELIFTOFF35 FT3.5°/s10.3° off · 3.5°/s3°/s2.4°/s2°/s13° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5+6 sseconds from rotation
PitchRotation began2.4 to 3.5°/s, other Boeing 737-MAX8 pilots2 to 3°/s from rotation, airlinersTail strikeNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate690 fpm740 fpm
On glideslope3.0°3.0°
On centreline0.0° off0.0° off
On speed+8.4 kt+6.2 kt
Wings level0° bank0° bank

When the approach was stable

Every check met from 4 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to PHNL 04R

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 20 ft below the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 1,000 ft past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,3306793632041,000 ft gate7 of 71,045 ft · 146 kt500 ft gate7 of 7533 ft · 144 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 6× larger than distances along the final.

Inside the 1° band all the way from 4 nm, never more than 200 ft off the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR510 ft L0510 ft RLEFT ↑RIGHT ↓1° BAND204 ft L4 ft L5 ft R25 ft R12 ft L2 ft R
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 35 kt fast at the 1,000 ft gate, closing to 21 at 500 ft and 10 at the threshold.

Inside the speed band all the way, between +4 kt and +11 kt on the approach speed of 138 kt.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

140160180200 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 138+9 kt+8 kt+8 kt+11 kt+8 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on PHNL 04R

Over the threshold

Threshold height92.40
58ft
Threshold speed100.00
145kttarget 138, 7 fast
Centreline offset100.00
20.3ft R
Bank100.00
0.6°steepest
Flare100.00

The flare tracked the target profile exactly

The aircraft floated down the runway before touching. Touchdown was 2,340 ft past the threshold. Threshold speed was not the cause here - hold the aim point on the approach and let the aircraft settle rather than holding it off, and the touchdown comes back to the numbers.

Touchdown

Past threshold71.99
2,340ft
Centreline100.00
4.6ft R
Speed100.00
133kttarget 138 or less
Touchdown rate100.00
-197fpm
Impact100.00
1.18G
BouncesOk
None
Bank100.00
1.1°as the wheels touched

Rollout

Rollout distance100.00
2,162ft50 % used
Rollout alignment100.00
12.4ft R

Taxi in

LightsOk
All set
Taxi speed100.00
18kt peak8 kt in turns

Side view — the last 5,000 ft of the approach.

Crossed the threshold at 58 ft, close to the 50 ft target; began the flare at 35 ft. Touched down 2,340 ft in, 1,340 ft past the ideal 1,000 ft.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 5,000 ft across. The dashed line is the ideal, 50 ft over the threshold and down 1,000 ft in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

58 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 35 ft · −350 fpm · 2.9° · 144 ktdescent slowed at 0 ft · −197 fpm · 4.8°−197 fpm · 4.8° nose up · 134 kt Ideal — 50 ft, down at 1,000 ft This flight — 58 ft, down at 2,340 ft

Sink and pitch — through the flare, lined up with the side view.

The sink went from 350 fpm at the flare to 200 fpm at touchdown. The nose came up 1.9° on the way down. Into the flare at 144 kt, 6 kt over the 138 kt approach speed, and 134 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−197 fpm at touchdown4.8° at touchdown, +1.9° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 5,000 ft of the 8,991 ft runway, to the same scale as the side view.

Touched down on the centreline, and stayed about there down the rollout, 12 ft right at the widest. 5 kt across from the right, which takes about 2° of crab to hold the centreline at 134 kt. Touched down with 2° of it still on, wings level.

Wind 083° at 11 kt · 9 kt head · 5 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

1,0002,0003,0004,0005,000 THRESHOLD LEFT ↑ RIGHT ↓ CROSS 5 kn FULL SCORE TO 1,650 FT 2,340 ft past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

Touched down 2,340 ft past the threshold — beyond the full-score zone. The arrival was smooth.

Runway used 4,502 ft of 8,991 ft · 50 %
In the air over the runway, 2,340 ftRollout, 2,162 ft Left over, 4,489 ft

The stop — touchdown to taxi speed.

From 128 kt at touchdown to taxi speed (30 kt) in 28 s, an average deceleration of 0.19 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 2,488 ft30 kt · 3,297 fttouchdown3,429 ftkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Flight narrative

The flight in question was operated by a Boeing 737-MAX8 aircraft. The pre-flight taxiing process from the parking area to the runway took approximately 7 minutes and covered a distance of 1 nautical mile. The aircraft then departed from runway 25R at Phoenix Sky Harbor International Airport, with a takeoff distance of 7,970 feet, which accounted for 78% of the runway length. The liftoff speed was recorded at 169 knots.

As the aircraft climbed to its cruising altitude, it encountered local weather conditions with a temperature of 104 degrees Fahrenheit. The enroute climb started over Central City, Arizona, where the aircraft ascended from 2,110 feet above sea level to 27,318 feet above sea level, an increase of 25,208 feet in 17 minutes, covering a distance of 103 nautical miles. The aircraft then entered a level cruise phase, which lasted for 2 minutes and covered 12 nautical miles, starting 21 miles south of La Paz Valley, Arizona.

The aircraft continued its journey, entering another climb phase 17 miles east of CN98 Walters Camp Airport Palo Verde, California, where it ascended from 27,661 feet above sea level to 35,767 feet above sea level, an increase of 8,107 feet in 9 minutes, covering a distance of 64 nautical miles. The aircraft then entered a prolonged level cruise phase, lasting 317 minutes and covering 2,225 nautical miles, starting 3 miles northwest of Westmorland, California.

As the aircraft began its descent, it started 84 miles northeast of 18HI Brandt Field Port Saint Joe, Hawaii, where it descended from 36,165 feet above sea level to 2,581 feet above sea level, a decrease of 33,584 feet in 23 minutes, covering a distance of 127 nautical miles. The aircraft then entered another level cruise phase, lasting 2 minutes and covering 4 nautical miles, starting 7 miles south of 'Ewa Beach, Hawaii.

The final descent phase started 4 miles south of Ocean Pointe, Hawaii, where the aircraft descended from 2,360 feet above sea level to 1,313 feet above sea level, a decrease of 1,047 feet in 2 minutes, covering a distance of 3 nautical miles. The aircraft then began its final approach to runway 04R at PHNL Daniel K Inouye International Airport, coming in from the southwest at a heading of 54.0 degrees, 4 nautical miles from the runway and 1,292 feet above ground level.

The landing was successful, with the aircraft touching down on the runway at a speed of 134 knots, which was within the target range. The touchdown point was 971 feet beyond the touchdown zone, and the touchdown rate was fair at -238 feet per minute. The runway touchdown alignment was very good, and the local weather conditions at the time of landing were a temperature of 84 degrees Fahrenheit and a wind speed of 10 knots at 81 degrees.

The total landing distance was 4,633 feet, which accounted for 52% of the runway length. The runway rollout alignment was also very good. The post-landing taxiing process from the runway to the parking area took approximately 4 minutes and covered a distance of less than 1 nautical mile. The total flight distance was 2,546 nautical miles, and the flight duration was 383 minutes, with a total fuel consumption of 31,858 pounds.

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
