OENG
Najran, Saudi Arabia
Runway 06
Elevation3,963 ft asl
Weight62,998 kg
Fuel14,325 kg
Wind70° · 5 kn · 1 kn cross

Flight Score

99.73 %
URKK
Krasnodar, Russia
Runway 05R
Elevation112 ft asl
Weight51,898 kg
Fuel3,157 kg
Wind50° · 3 kn
29 Feb 2024 4:10 1880 nm Boeing 737-900 11,167 kg
Departure Score
99.63 %
Enroute Score
99.99 %
Arrival Score
99.56 %

What went well

Touched down at -183 fpm — a soft arrival
Threshold crossed at 54 ft and 130 kt — both inside band
Straight touchdown — 1.63 m off the centreline, no bounce

What held you back

Arrival Touchdown — Touchdown distance was 593 m at 85 %, −0.15 points
Departure Climb 3 — scored 98.13 %, −0.12 points

Next time

Arrival

Adjust your approach path so you touch down at the 457 m aim point instead of beyond it.

What happened: Touchdown point came 136 m past the target, landing at 593 m against the 457 m aim point. Landings that touch down this far beyond the aim point typically leave less runway available for stopping.

Watch for: Touchdown distance marker: 457 m from the threshold.

See Arrival Touchdown

Start to finish · 15 stages, 13 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 5 minutes and covered 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 18 kt0 kt min to max 23 kt 0 19 kt
100 % Average speed turning corners 13 ktmax 13 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 0.99 g
Info Average pitch angle -0.9 °-1.3 ° min to max -0.8 ° -1.0 -1.2 °
Info Average bank angle 0.1 °0.0 ° min to max 0.4 ° 0.2 0.1 °

Events

Info Engine 1 Started 8 ft agl
Info Parking Brake Off 8 ft agl
Info Landing Lights Switched On 8 ft agl · 17 kt
Info Strobe Lights Switched On 8 ft agl · 17 kt
Info Taxi Lights Switched Off 8 ft agl · 20 kt
Departure Runway Entry Entering runway 06 at OENG Najran Domestic Airport, Average speed was 22 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 19 kt19 kt min to max 19 kt 19 19 kt
Info Average pitch angle -1.2 °-1.2 ° min to max -1.2 ° -1.2 -1.2 °
Info Average bank angle 0.0 °0.0 ° min to max 0.1 ° 0.0 0.1 °
Info Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Departure Roll 100.00Departure roll runway 06 at OENG Najran Domestic Airport. Takeoff distance 2,062 m 68 % of runway. Rotation speed was 142 kt. Local weather - Temperature 26 °C. Wind 5 kt at 70 °. Crosswind: 1 kt Headwind: 5 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 2,062 m68 % of runway
100 % Rotation speed was 142 ktTarget 138 kt
100 % Runway alignment max 2.16 m right1.10 m left to 2.16 m right -2.16 0.72 m
100 % Average g force 1.01 g0.98 g min to max 1.11 g 1.00 1.11 g
100 % Takeoff Bounce
Info Average pitch angle -0.8 °-1.4 ° min to max 9.0 ° -1.2 9.0 °
Info Average bank angle 0.1 °0.0 ° min to max 0.3 ° 0.0 0.2 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 06 OENG Najran Domestic Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.0 °-0.0 ° min to max 0.0 ° -0.0 0.0 °
100 % Average speed 151 kt148 kt min to max 154 kt 148 154 kt
100 % Steepest bank angle 0.3 °0.2 ° min to max 0.3 ° 0.2 0.2 °
100 % Average g force 1.20 g1.13 g min to max 1.25 g 1.13 1.17 g
Info Average VSI 733 fpm251 fpm min to max 1,185 fpm 251 1,185 fpm
Info Average altitude 18 ft agl0 ft agl min to max 46 ft agl 0 46 ft agl
Info Average pitch angle 11.5 °9.3 ° min to max 13.3 ° 9.3 13.3 °

Events

Info Landing Gear Up 20 ft agl · 163 kt
Departure Climb 2 100.00Departure climb to 400 ft agl from 06 OENG Najran Domestic Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.0 °0.0 ° min to max 0.0 ° 0.0 0.0 °
100 % Average speed 155 kt154 kt min to max 160 kt 154 160 kt
100 % Steepest bank angle 0.2 °0.2 ° min to max 0.2 ° 0.2 0.2 °
100 % Average g force 1.16 g0.95 g min to max 1.21 g 1.17 0.95 g
Info Average VSI 1,794 fpm1,217 fpm min to max 3,201 fpm 1,217 3,201 fpm
Info Average altitude 107 ft agl48 ft agl min to max 382 ft agl 48 382 ft agl
Info Average pitch angle 14.9 °13.5 ° min to max 16.3 ° 13.5 15.8 °

Events

Info Flaps Position 4 186 ft agl · 171 kt
Info Flaps Position 3 344 ft agl · 174 kt
Departure Climb 3 98.13Departure climb to 1,000 ft agl from 06 OENG Najran Domestic Airport.
ScoreDescriptionStartProfileEnd
95 % Climb speed 166 kt160 kt min to max 171 ktTarget 184 kt, 18 kt slow 160 171 kt
100 % Steepest bank angle 0.2 °0.0 ° min to max 0.2 ° 0.2 0.2 °
100 % Average g force 0.95 g0.85 g min to max 1.05 g 0.90 1.00 g
100 % Landing gear up at 9 ft aglTarget by 400 ft agl
Info Heading variation -0.0 °-0.0 ° min to max 0.0 ° 0.0 -0.0 °
Info Average VSI 2,827 fpm2,518 fpm min to max 3,200 fpm 3,200 2,952 fpm
Info Average altitude 689 ft agl435 ft agl min to max 945 ft agl 435 945 ft agl
Info Average pitch angle 14.0 °12.7 ° min to max 15.0 ° 15.0 14.6 °

Events

Info Flaps Position 2 557 ft agl · 178 kt
Info Flaps Position 1 727 ft agl · 183 kt
Enroute Climb 100.00Enroute climb started 1 mile north east of OENG Najran Domestic Airport Najran (Najran Region, Saudi Arabia). Climbing from 4,966 ft asl to 39,971 ft asl, an increase of 35,006 ft in 29 minutes and covering 205 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 252 kt172 kt min to max 280 kt 172 236 kt
100 % Steepest bank angle 29.8 °0.0 ° min to max 29.8 ° 0.2 0.5 °
100 % Average g force 1.03 g0.76 g min to max 1.16 g 1.01 1.00 g
Info Average VSI 1,212 fpm160 fpm min to max 4,057 fpm 3,038 463 fpm
Info Average altitude 29,589 ft asl4,966 ft asl min to max 39,971 ft asl 4,966 39,971 ft asl
Info Average pitch angle 5.6 °3.3 ° min to max 15.4 ° 14.8 4.7 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Fully Retracted 1,132 ft agl · 192 kt
Info Landing Lights Switched Off 6,486 ft agl · 284 kt
Enroute Level 100.00Enroute level cruise started 6 miles north east of OEWD Wadi Al Dawasir Domestic Airport Wadi Al Dawasir (Riyadh Region, Saudi Arabia) and lasted 203 minutes, covering 1,605 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,503 ft of 40,239 ft asl40,031 ft asl min to max 40,423 ft asl 40,050 40,031 ft asl
100 % Average speed 245 kt226 kt min to max 250 kt 235 226 kt
100 % Steepest bank angle 26.2 °0.0 ° min to max 26.2 ° 0.0 0.4 °
100 % Average g force 1.01 g0.94 g min to max 1.20 g 1.00 1.02 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 3.5 °2.1 ° min to max 4.7 ° 4.7 2.6 °

Events

Info Landing Gear Down 40,181 ft agl · 464 kt
Info Landing Gear Up 40,180 ft agl · 464 kt
Info Landing Gear Down 31,921 ft agl · 451 kt
Info Landing Gear Up 31,921 ft agl · 451 kt
Enroute Descent 99.97Enroute descent started 7 miles south west of Tuapse (Krasnodarskiy Kray, Russia). Descent from 39,856 ft asl to 1,292 ft asl, a decrease of 38,564 ft in 11 minutes and covering 62 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 254 kt170 kt min to max 334 kt 221 170 kt
100 % Steepest bank angle 29.9 °0.0 ° min to max 29.9 ° 0.3 0.7 °
99.7 % Average g force 1.01 g0.59 g min to max 1.46 g 1.00 0.94 g
Info Average VSI -2,419 fpm-6,645 fpm min to max -352 fpm -1,044 -1,102 fpm
Info Average altitude 13,897 ft asl1,292 ft asl min to max 39,856 ft asl 39,856 1,292 ft asl
Info Average pitch angle -2.6 °-10.0 ° min to max 3.9 ° 2.8 -2.5 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Landing Lights Switched On 19,763 ft agl · 435 kt
Info Taxi Lights Switched On 19,720 ft agl · 434 kt
Info Flaps Position 3 18,304 ft agl · 325 kt
Info Flaps Fully Retracted 18,402 ft agl · 324 kt
Info Flaps Position 1 18,343 ft agl · 317 kt
Info Flaps Position 2 18,042 ft agl · 315 kt
Info Flaps Position 3 17,964 ft agl · 314 kt
Info Landing Gear Down 15,269 ft agl · 305 kt
Info Flaps Position 4 1,636 ft agl · 202 kt
Info Flaps Position 7 1,625 ft agl · 201 kt
Info Flaps Position 3 1,610 ft agl · 200 kt
Info Flaps Position 4 1,566 ft agl · 197 kt
Info Flaps Position 5 1,500 ft agl · 195 kt
Info Flaps Position 6 1,453 ft agl · 193 kt
Info Flaps Position 7 1,406 ft agl · 191 kt
Arrival Approach 100.00Final approach to runway 05R at URKK Krasnodar Pashkovsky International Airport. Descent from 1,217 ft agl to 62 ft agl in 107 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates

Events

Info Flaps Position 8 1,054 ft agl · 152 kt
Arrival Landing 100.00Landing on runway 05R at URKK Krasnodar Pashkovsky International Airport, runway length 2,984 m. Good threshold height. Threshold speed was good at 130 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 130 kt. Target 133 kt
100 % Good threshold height.Target 50 ft agl
100 % Perfect landing flare
100 % Runway alignment max 4.65 m left4.65 m left to 1.79 m left 4.65 1.79 m
100 % Steepest bank angle 0.2 °0.0 ° min to max 0.2 ° 0.2 0.0 °
100 % Peak g force 1.06 g0.99 g min to max 1.06 g 1.01 0.99 g
Info Average speed 129 kt124 kt min to max 131 kt 130 124 kt
Info Average VSI -351 fpm-548 fpm min to max -169 fpm -548 -179 fpm
Info Average altitude 25 ft agl6 ft agl min to max 55 ft agl 55 6 ft agl
Info Average pitch angle 3.0 °1.9 ° min to max 3.6 ° 1.9 3.6 °
07515022530037545052560067501223354658Runway Distance mLanding Height ft075150225300375450525600675-20-16-12-8-4048121620Runway Distance mRunway Width m
Arrival Touchdown 97.78Touchdown point was 173 m beyond the touchdown zone. Touchdown speed at 124 kt was good. Touchdown rate was good at -183 fpm. Runway touchdown alignment was very good. Local weather - Temperature 4 °C. Wind 3 kt at 50 °. Crosswind: 0 kt Headwind: 3 kt.
ScoreDescriptionStartProfileEnd
100 % Touchdown rate was -183 fpm.
85 % Touchdown distance was 593 mTarget 457 m
100 % Speed at touchdown 124 ktTarget below 131 kt
100 % Runway alignment max 1.79 m left1.71 m left 1.79 1.63 m
100 % Steepest bank angle 0.6 °0.0 ° min to max 0.6 ° 0.0 0.1 °
100 % Peak g force 1.16 g0.99 g min to max 1.16 g 0.99 1.09 g
100 % Landing Bounce
Info Average speed 123 kt122 kt min to max 124 kt 124 122 kt
Info Average pitch angle 3.5 °3.2 ° min to max 3.6 ° 3.6 3.2 °
Arrival Rollout 100.00Total landing distance 1,045 m, 35 % of runway. Runway rollout alignment was perfect.
ScoreDescriptionStartProfileEnd
100 % Landing distance 1,045 m35 % of runway.
100 % Runway alignment max 1.16 m left1.16 m left to 0.00 m left 0.49 1.16 m
100 % Average g force 1.00 g0.97 g min to max 1.08 g 1.08 0.99 g
Info Average speed 109 kt61 kt min to max 116 kt 116 61 kt
Info Average pitch angle 0.3 °-1.2 ° min to max 3.1 ° 3.1 -1.2 °
Info Average bank angle 0.1 °0.0 ° min to max 0.7 ° 0.1 0.1 °
Runway Exit Exiting runway, average speed 20 kt
ScoreDescriptionStartProfileEnd
Info Average speed 19 kt2 kt min to max 54 kt 54 15 kt
Info Average pitch angle -0.9 °-1.2 ° min to max -0.8 ° -1.2 -1.0 °
Info Average bank angle 0.2 °0.0 ° min to max 0.5 ° 0.0 0.5 °
Info Average g force 1.00 g0.98 g min to max 1.01 g 0.99 1.00 g

Events

Info Landing Lights Switched Off 8 ft agl · 10 kt
Info Strobe Lights Switched Off 8 ft agl · 10 kt
Info Flaps Fully Retracted 8 ft agl · 3 kt
Info Flaps Position 8 8 ft agl · 3 kt
Info Flaps Position 7 8 ft agl · 11 kt
Info Flaps Position 6 8 ft agl · 12 kt
Arrival Taxi 100.00Taxiing to the parking from the runway took 1 minutes and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 14 kt6 kt min to max 15 kt 15 6 kt
100 % Average speed turning corners 0 ktmax 0 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 0.99 g
Info Average pitch angle -1.0 °-1.2 ° min to max -0.9 ° -0.9 -1.2 °
Info Average bank angle 0.1 °0.0 ° min to max 0.5 ° 0.4 0.0 °

Events

Info Flaps Position 5 8 ft agl · 12 kt
Info Flaps Position 4 8 ft agl · 13 kt
Info Flaps Position 3 8 ft agl · 14 kt
Info Flaps Position 2 8 ft agl · 15 kt
Info Flaps Position 1 8 ft agl · 16 kt
Info Flaps Fully Retracted 8 ft agl · 15 kt

Takeoff from OENG 06

Taxi out

LightsOk
All on
Taxi speed100.00
23kt peak13 kt in turns

The roll

Takeoff roll100.00
2,062m68 %
Runway alignment100.00
2.16m R
Rotation speed100.00
142kttarget 138, 4 late

Liftoff pitch close to a tail strike

The wheels left at 9.3°, 0.7° short of this aircraft's 10° tail strike.

The tail can only touch while the main wheels are still on the runway, so the margin that matters is the one at liftoff. Rotate at the rotate speed, at the normal rate, and let the aircraft fly itself off at its own attitude: keep the pull going towards the climb attitude only once the wheels have left. Rotating early, or pulling faster than the aircraft can lift off, is what eats the margin.

Liftoff and climb

Liftoff
147ktat 9.3°
Rotation
5.3°/sover 1.9 s, gaining 5 kt
35 ft
153ktat 12.5°, 2.2 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
0.3°steepest
Gear up100.00
9ftfull marks to 400 ft
Climb 3 speed95.32
166kttarget 184

Plan view the roll down the 3,044 m runway.

Rolled from 723 m in, drifted 2.5 m right of the centreline and was back on it to lift off. Airborne 67 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length.

1,0002,0003,000THRESHOLDLEFT ↑RIGHT ↓75 %widest 2.53 m RROLL 723 M INAirborne 2,066 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 2,066 m of 3,044 m · 68 %
Behind the start of the roll, 723 mTakeoff roll, 1,343 m Left ahead, 977 m

Side view from the start of the roll to the end of Climb 3 at 946 ft.

Reached 35 ft with 791 m of runway left; gear up at 9 ft, inside the 400 ft that gets full marks; then climbing at 2,520 fpm on average to 946 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3166 kt avgtarget 184THRESHOLDRUNWAY END6080100120KNOTS ALONG THE ROLLnose up on the runway · 148 m · 1.9 sRotate 142 kttarget 138Liftoff 147 ktGear up 9 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 184180 kt12060020°10°0°nose up on the runway · 148 m · 1.9 sROTATELIFTOFFtarget 138held 14.4°9.3° off · 5.3°/s13° at 35 ftAIRSPEEDPITCH02040 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2.1 to 4.1° a second, the middle half of rotation rates flown by other Boeing 737-900 pilots over the last 180 days (116 takeoffs); the grey pair are 2 to 3° a second, the rates airliners are rotated at. A trace steeper than both green lines is a faster rotation than most, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 10°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 10°ROTATELIFTOFF35 FT9.3° off · 5.3°/s4.1°/s3°/s2.1°/s2°/s13° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5 sseconds from rotation
PitchRotation began2.1 to 4.1°/s, other Boeing 737-900 pilots2 to 3°/s from rotation, airlinersTail strikeNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate830 fpm650 fpm
On glideslope2.7°2.7°
On centreline0.4° off0.4° off
On speed+13 kt−3.3 kt
Wings level0° bank0° bank

When the approach was stable

Every check met from 3.7 nm, about 1,110 ft above the runway, to the threshold, before the 1,000 ft gate, so through both gates. The last to settle was the speed.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to URKK 05R

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 130 ft below the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,2116233511941,000 ft gate7 of 7954 ft · 146 kt500 ft gate7 of 7500 ft · 130 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 7× larger than distances along the final.

Inside the 1° band all the way from 4 nm, never more than 51 m off the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR128 m L0128 m RLEFT ↑RIGHT ↓1° BAND51 m L26 m L15 m L10 m L42 m L21 m L
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 33 kt fast at the 1,000 ft gate, closing to 20 at 500 ft and 10 at the threshold.

Fast from 4 nm to 3.7 nm (up to +41 kt), then inside the band to the threshold.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

120140160180 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 133+41 kt−1 kt−3 kt−3 kt−3 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on URKK 05R

Over the threshold

Threshold height100.00
54ft
Threshold speed100.00
130kttarget 133, 3 slow
Centreline offset100.00
4.65m L
Bank100.00
0.2°steepest
Flare100.00

Perfect landing flare

Touchdown

Past threshold85.18
593m
Centreline100.00
1.79m L
Speed100.00
123kttarget 131 or less
Touchdown rate100.00
-183fpm
Impact100.00
1.16G
BouncesOk
None
Bank100.00
0.6°as the wheels touched

Rollout

Rollout distance100.00
414m34 % used
Rollout alignment100.00
1.16m L

Taxi in

LightsOk
All set
Taxi speed100.00
15kt peak

Side view — the last 1,524 m of the approach.

Crossed the threshold at 54 ft, close to the 50 ft target; began the flare at 15 ft. Touched down 593 m in, 288 m past the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,524 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

54 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 15 ft · −275 fpm · 3.4° · 130 ktdescent slowed at 4 ft · −140 fpm · 3.6°−183 fpm · 3.6° nose up · 124 kt Ideal — 50 ft, down at 305 m This flight — 54 ft, down at 593 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 280 fpm at the flare to 180 fpm at touchdown. The pitch barely changed. Into the flare at 130 kt, 3 kt under the 133 kt approach speed, and 124 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−183 fpm at touchdown3.6° at touchdown, +0.2° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,524 m of the 2,984 m runway, to the same scale as the side view.

Touched down 1.6 m left of the centreline, and stayed within 1.8 m of it down the rollout. No crosswind: nothing to correct for. Touched down straight, wings level.

Wind 050° at 3 kt · 3 kt head · 0 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ FULL SCORE TO 503 M 593 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

Touched down 593 m past the threshold — beyond the full-score zone. The arrival was smooth.

Runway used 1,007 m of 2,984 m · 34 %
In the air over the runway, 593 mRollout, 414 m Left over, 1,978 m

The stop — touchdown to taxi speed.

From 118 kt at touchdown to taxi speed (30 kt) in 15 s, an average deceleration of 0.32 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 483 m30 kt · 565 mtouchdown588 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
