EDDM
Munich, Germany
Runway 26R
Elevation1,467 ft asl
Weight276,774 kg
Fuel21,871 kg
Wind250° · 5 kn · 1 kn cross

Flight Score

99.88 %
EDDB
Berlin, Germany
Runway 24L
Elevation151 ft asl
Weight270,464 kg
Fuel14,937 kg
Wind259° · 3 kn
8 Oct 2024 0:58 324 nm Boeing 747-8 6,934 kg
Departure Score
100.00 %
Enroute Score
100.00 %
Arrival Score
99.65 %

What went well

Touched down at -173 fpm — a soft arrival
Threshold crossed at 39 ft and 142 kt — both inside band
Straight touchdown — 4.56 m off the centreline, no bounce

What held you back

Arrival Touchdown — Touchdown distance was 563 m at 88 %, −0.12 points

Next time

Arrival

Adjust your approach path so you touch down at the 457 m aim point instead of beyond it.

What happened: Touchdown point came 106 m past the target, landing at 563 m against the 457 m aim point. Landings that touch down this far beyond the aim point typically leave less runway available for stopping.

Watch for: Touchdown distance marker: 457 m from the threshold.

See Arrival Touchdown

Start to finish · 15 stages, 13 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 9 minutes and covered 2 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 16 kt0 kt min to max 24 kt 3 13 kt
100 % Average speed turning corners 0 ktmax 0 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle -0.7 °-0.8 ° min to max -0.6 ° -0.7 -0.7 °
Info Average bank angle 0.0 °0.0 ° min to max 0.4 ° 0.0 0.1 °

Events

Info Battery Master On 15 ft agl
Info Engine 1 Started 15 ft agl
Info Engine 4 Started 15 ft agl
Info Beacon Lights Switched On 15 ft agl
Info Navigation Lights Switched On 15 ft agl
Info Autopilot Flight Director Activated 15 ft agl
Info Autopilot Yaw Damper Activated 15 ft agl
Info Landing Gear Down 15 ft agl
Info Pitot Heat Switched On 15 ft agl
Info Engine 2 Started 15 ft agl
Info Engine 3 Started 15 ft agl
Info Taxi Lights Switched On 15 ft agl
Info Parking Brake On 15 ft agl
Info Flaps Position 1 15 ft agl
Info Flaps Position 3 15 ft agl
Info Parking Brake Off 15 ft agl
Info Autopilot Vertical Hold Activated 15 ft agl · 3 kt
Info Runway Surface Conditions 15 ft agl · 19 kt
Info Landing Lights Switched On 15 ft agl · 9 kt
Info Strobe Lights Switched On 15 ft agl · 8 kt
Departure Runway Entry Entering runway 26R at EDDM Munich Airport, Average speed was 17 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 14 kt13 kt min to max 14 kt 13 14 kt
Info Average pitch angle -0.7 °-0.7 ° min to max -0.7 ° -0.7 -0.7 °
Info Average bank angle 0.1 °0.0 ° min to max 0.1 ° 0.1 0.0 °
Info Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Departure Roll 100.00Departure roll runway 26R at EDDM Munich Airport. Takeoff distance 1,147 m 29 % of runway. Rotation speed was 132 kt. Local weather - Temperature 15 °C. Wind 4 kt at 250 °. Crosswind: 1 kt Headwind: 4 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 1,147 m29 % of runway
100 % Rotation speed was 132 ktTarget 141 kt
100 % Runway alignment max 1.59 m left1.59 m left to 0.29 m right 0.00 1.34 m
100 % Average g force 1.00 g0.97 g min to max 1.06 g 1.00 1.06 g
100 % Takeoff Bounce
Info Average pitch angle 0.1 °-0.7 ° min to max 8.7 ° -0.7 8.7 °
Info Average bank angle 0.1 °0.0 ° min to max 0.3 ° 0.0 0.1 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 26R EDDM Munich Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.1 °-0.1 ° min to max -0.0 ° -0.1 -0.0 °
100 % Average speed 158 kt146 kt min to max 170 kt 146 170 kt
100 % Steepest bank angle 0.4 °0.0 ° min to max 0.4 ° 0.1 0.4 °
100 % Average g force 1.04 g0.89 g min to max 1.12 g 1.07 1.06 g
Info Average VSI 428 fpm118 fpm min to max 798 fpm 118 798 fpm
Info Average altitude 18 ft agl0 ft agl min to max 44 ft agl 0 44 ft agl
Info Average pitch angle 7.9 °6.7 ° min to max 8.9 ° 8.8 7.9 °
Departure Climb 2 100.00Departure climb to 400 ft agl from 26R EDDM Munich Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.0 °-0.0 ° min to max -0.0 ° -0.0 -0.0 °
100 % Average speed 178 kt170 kt min to max 203 kt 170 203 kt
100 % Steepest bank angle 0.5 °0.2 ° min to max 0.5 ° 0.4 0.3 °
100 % Average g force 1.08 g0.96 g min to max 1.14 g 1.06 1.04 g
Info Average VSI 1,225 fpm817 fpm min to max 2,727 fpm 817 2,727 fpm
Info Average altitude 91 ft agl45 ft agl min to max 377 ft agl 45 377 ft agl
Info Average pitch angle 8.6 °7.9 ° min to max 9.7 ° 7.9 9.4 °

Events

Info Autopilot Heading Hold Activated 90 ft agl · 182 kt
Info Landing Gear Up 90 ft agl · 182 kt
Info Flaps Position 2 181 ft agl · 194 kt
Departure Climb 3 100.00Departure climb to 1,000 ft agl from 26R EDDM Munich Airport.
ScoreDescriptionStartProfileEnd
100 % Climb speed 218 kt206 kt min to max 229 ktTarget 202 kt, 16 kt fast 206 229 kt
100 % Steepest bank angle 0.3 °0.1 ° min to max 0.3 ° 0.3 0.2 °
100 % Average g force 1.02 g0.89 g min to max 1.06 g 1.02 0.89 g
100 % Landing gear up at 68 ft aglTarget by 400 ft agl
Info Heading variation -0.1 °-0.1 ° min to max -0.1 ° -0.1 -0.1 °
Info Average VSI 3,501 fpm2,851 fpm min to max 4,107 fpm 2,851 4,107 fpm
Info Average altitude 678 ft agl425 ft agl min to max 975 ft agl 425 975 ft agl
Info Average pitch angle 10.1 °9.4 ° min to max 10.8 ° 9.4 9.4 °

Events

Info Autopilot Master Switched On 790 ft agl · 232 kt
Enroute Climb 100.00Enroute climb started overhead EDDM Munich Airport Munich (Bavaria, Germany). Climbing from 2,538 ft asl to 34,647 ft asl, an increase of 32,109 ft in 12 minutes and covering 88 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 283 kt229 kt min to max 323 kt 231 280 kt
100 % Steepest bank angle 29.0 °0.0 ° min to max 29.0 ° 0.2 2.5 °
99.97 % Average g force 1.03 g0.70 g min to max 1.36 g 0.84 0.89 g
Info Average VSI 3,064 fpm1,510 fpm min to max 6,344 fpm 3,986 1,809 fpm
Info Average altitude 16,964 ft asl2,538 ft asl min to max 34,647 ft asl 2,538 34,647 ft asl
Info Average pitch angle 6.6 °2.4 ° min to max 17.3 ° 8.5 3.1 °
Info Turn coordination 00 min to max 0 0 0

Events

Fail Exceeded 250 kn below 10000 ft 4,168 ft agl
Info Flaps Fully Retracted 1,327 ft agl · 252 kt
Info Autopilot Airspeed Hold Activated 1,429 ft agl · 256 kt
Info Autopilot AutoThrottle Arm Armed 1,429 ft agl · 256 kt
Info Autopilot Airspeed Hold Deactivated 2,167 ft agl · 266 kt
Info Autopilot Vertical Hold Deactivated 2,167 ft agl · 266 kt
Info Autopilot RPM Hold Activated 2,167 ft agl · 266 kt
Info Autopilot AutoThrottle Arm Disarmed 2,688 ft agl · 274 kt
Info Autopilot RPM Hold Deactivated 2,688 ft agl · 274 kt
Info Autopilot AutoThrottle Arm Armed 3,262 ft agl · 265 kt
Info Autopilot RPM Hold Activated 3,262 ft agl · 265 kt
Info Landing Lights Switched Off 9,034 ft agl · 298 kt
Info Taxi Lights Switched Off 9,146 ft agl · 303 kt
Info Autopilot Airspeed Hold Activated 32,371 ft agl · 477 kt
Info Autopilot Vertical Hold Activated 32,371 ft agl · 477 kt
Info Autopilot RPM Hold Deactivated 32,371 ft agl · 477 kt
Enroute Level 100.00Enroute level cruise started overhead Mutenin (Plzensky kraj, Czech Republic) and lasted 14 minutes, covering 122 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,235 ft of 34,687 ft asl34,610 ft asl min to max 34,718 ft asl 34,691 34,610 ft asl
100 % Average speed 278 kt278 kt min to max 280 kt 279 279 kt
100 % Steepest bank angle 25.8 °0.0 ° min to max 25.8 ° 6.8 2.2 °
100 % Average g force 1.01 g0.80 g min to max 1.17 g 0.81 0.88 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 1.9 °-0.0 ° min to max 3.2 ° 2.1 -0.0 °
Enroute Descent 100.00Enroute descent started overhead Plessa (Brandenburg, Germany). Descent from 34,269 ft asl to 1,443 ft asl, a decrease of 32,826 ft in 18 minutes and covering 105 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 254 kt142 kt min to max 307 kt 284 143 kt
100 % Steepest bank angle 26.7 °0.0 ° min to max 26.7 ° 1.4 0.4 °
100 % Average g force 1.04 g0.75 g min to max 1.26 g 0.90 1.00 g
Info Average VSI -1,802 fpm-3,064 fpm min to max 189 fpm -2,797 -794 fpm
Info Average altitude 14,281 ft asl1,443 ft asl min to max 34,269 ft asl 34,269 1,443 ft asl
Info Average pitch angle -0.4 °-3.7 ° min to max 4.2 ° -2.4 2.6 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Airspeed Hold Deactivated 32,495 ft agl · 482 kt
Info Autopilot Mach Hold Activated 32,495 ft agl · 482 kt
Info Autopilot Mach Hold Deactivated 32,447 ft agl · 482 kt
Info Autopilot Vertical Hold Deactivated 19,847 ft agl · 407 kt
Info Autopilot RPM Hold Activated 19,847 ft agl · 407 kt
Info Autopilot Airspeed Hold Activated 19,806 ft agl · 407 kt
Info Autopilot RPM Hold Deactivated 19,806 ft agl · 407 kt
Info Autopilot Vertical Hold Activated 19,772 ft agl · 407 kt
Info Autopilot Airspeed Hold Deactivated 16,310 ft agl · 378 kt
Info Autopilot Vertical Hold Deactivated 16,310 ft agl · 378 kt
Info Autopilot RPM Hold Activated 16,310 ft agl · 378 kt
Info Autopilot Airspeed Hold Activated 16,192 ft agl · 376 kt
Info Autopilot RPM Hold Deactivated 16,192 ft agl · 376 kt
Info Autopilot Vertical Hold Activated 16,161 ft agl · 376 kt
Info Autopilot Airspeed Hold Deactivated 16,079 ft agl · 376 kt
Info Autopilot Vertical Hold Deactivated 16,079 ft agl · 376 kt
Info Autopilot RPM Hold Activated 16,079 ft agl · 376 kt
Info Autopilot RPM Hold Deactivated 15,658 ft agl · 375 kt
Info Autopilot Airspeed Hold Activated 13,588 ft agl · 364 kt
Info Autopilot Vertical Hold Activated 13,588 ft agl · 364 kt
Info Landing Lights Switched On 9,984 ft agl · 281 kt
Info Taxi Lights Switched On 9,954 ft agl · 281 kt
Info Autopilot Heading Hold Deactivated 7,369 ft agl · 272 kt
Info Autopilot Approach Mode Activated 7,369 ft agl · 272 kt
Info Flaps Position 1 4,208 ft agl · 236 kt
Info Autopilot Vertical Hold Deactivated 4,195 ft agl · 231 kt
Info Flaps Position 2 3,620 ft agl · 212 kt
Info Flaps Position 3 3,452 ft agl · 198 kt
Info Landing Gear Down 3,369 ft agl · 197 kt
Info Flaps Position 4 2,763 ft agl · 183 kt
Info Flaps Position 5 1,910 ft agl · 154 kt
Info Flaps Position 6 1,804 ft agl · 149 kt
Info Autopilot AutoThrottle Arm Disarmed 1,362 ft agl · 148 kt
Info Autopilot Master Switched Off 1,338 ft agl · 148 kt
Arrival Approach 100.00Final approach to runway 24L at EDDB Berlin Brandenburg Airport. Descent from 1,332 ft agl to 57 ft agl in 99 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates

Events

Info Autopilot AutoThrottle Arm Disarmed 1,362 ft agl · 148 kt
Info Autopilot Master Switched Off 1,338 ft agl · 148 kt
Arrival Landing 100.00Landing on runway 24L at EDDB Berlin Brandenburg Airport, runway length 3,986 m. Good threshold height. Threshold speed was good at 142 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 142 kt. Target 138 kt
100 % Good threshold height.Target 50 ft agl
100 % Perfect landing flare
100 % Runway alignment max 4.37 m left4.37 m left to 2.68 m left 2.71 4.37 m
100 % Steepest bank angle 1.3 °0.0 ° min to max 1.3 ° 1.1 1.3 °
100 % Peak g force 1.11 g0.99 g min to max 1.11 g 1.02 1.02 g
Info Average speed 139 kt135 kt min to max 142 kt 142 135 kt
Info Average VSI -357 fpm-669 fpm min to max -190 fpm -669 -190 fpm
Info Average altitude 17 ft agl1 ft agl min to max 40 ft agl 40 1 ft agl
Info Average pitch angle 5.2 °3.8 ° min to max 5.9 ° 3.8 5.9 °
07515022530037545052560067501223354658Runway Distance mLanding Height ft075150225300375450525600675-30-24-18-12-60612182430Runway Distance mRunway Width m
Arrival Touchdown 98.26Touchdown point was 151 m beyond the touchdown zone. Touchdown speed at 135 kt was good. Touchdown rate was good at -173 fpm. Runway touchdown position was slightly misaligned by 4.6 m from centreline. Local weather - Temperature 16 °C. Wind 3 kt at 259 °. Crosswind: 0 kt Headwind: 3 kt.
ScoreDescriptionStartProfileEnd
100 % Touchdown rate was -173 fpm.
88 % Touchdown distance was 563 mTarget 457 m
100 % Speed at touchdown 135 ktTarget below 137 kt
100 % Runway alignment max 4.56 m left4.48 m left 4.37 4.56 m
100 % Steepest bank angle 1.8 °1.0 ° min to max 1.8 ° 1.3 1.6 °
100 % Peak g force 1.09 g1.01 g min to max 1.09 g 1.02 1.04 g
100 % Landing Bounce
Info Average speed 135 kt134 kt min to max 135 kt 135 134 kt
Info Average pitch angle 5.8 °5.7 ° min to max 5.9 ° 5.9 5.7 °
Arrival Rollout 100.00Total landing distance 1,434 m, 36 % of runway. Runway rollout alignment was very good.
ScoreDescriptionStartProfileEnd
100 % Landing distance 1,434 m36 % of runway.
100 % Runway alignment max 3.71 m right1.42 m left to 3.71 m right 1.42 -3.71 m
100 % Average g force 1.02 g0.98 g min to max 1.06 g 1.05 1.01 g
Info Average speed 122 kt69 kt min to max 134 kt 134 69 kt
Info Average pitch angle 3.6 °-0.8 ° min to max 5.7 ° 5.7 -0.6 °
Info Average bank angle 2.4 °0.0 ° min to max 3.9 ° 1.6 0.1 °
Runway Exit Exiting runway, average speed 33 kt
ScoreDescriptionStartProfileEnd
Info Average speed 31 kt16 kt min to max 61 kt 61 16 kt
Info Average pitch angle -0.7 °-0.9 ° min to max -0.4 ° -0.7 -0.9 °
Info Average bank angle 0.4 °0.2 ° min to max 0.8 ° 0.2 0.8 °
Info Average g force 1.00 g0.99 g min to max 1.01 g 1.00 0.99 g

Events

Info Runway Surface Conditions 15 ft agl · 30 kt
Info Flaps Fully Retracted 15 ft agl · 29 kt
Info Landing Lights Switched Off 15 ft agl · 19 kt
Info Strobe Lights Switched Off 15 ft agl · 19 kt
Arrival Taxi 100.00Taxiing to the parking from the runway took 5 minutes and covered 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 15 kt0 kt min to max 22 kt 11 3 kt
100 % Average speed turning corners 0 ktmax 0 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle -0.6 °-1.5 ° min to max -0.2 ° -1.0 -0.6 °
Info Average bank angle 0.5 °0.0 ° min to max 0.9 ° 0.8 0.1 °

Takeoff from EDDM 26R

Taxi out

LightsOk
All on
Taxi speed100.00
24kt peak

The roll

Takeoff roll100.00
1,147m29 %
Runway alignment100.00
1.59m L
Rotation speed100.00
132kttarget 141, 9 early

Rotated early, and the nose came up quickly

Rotation started at 132 kt, 9 kt before the 141 kt rotate speed, and the nose then rose at 3.3° a second, faster than the 2 to 3° a second airliners use.

Early and quick together is the classic tail-strike setup: the nose reaches its liftoff attitude before the aircraft has the speed to fly. Wait for the rotate speed, then pull smoothly at the normal rate for this aircraft and let it lift off at its own attitude.

Liftoff and climb

Liftoff
145ktat 8.8°
Rotation
3.3°/sover 2.7 s, gaining 13 kt
35 ft
168ktat 7.9°, 4.0 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
0.4°steepest
Gear up100.00
68ftfull marks to 400 ft
Climb 3 speed100.00
218kttarget 202

Plan view the roll down the 3,981 m runway.

Rolled from 224 m in, drifted left of the centreline, 2.1 m at the widest, and lifted off 1.9 m left. Airborne 28 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

1,0002,0003,000THRESHOLDLEFT ↑RIGHT ↓CROSS1 kn75 %widest 2.14 m LROLL 224 M INAirborne 1,152 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,152 m of 3,981 m · 29 %
Behind the start of the roll, 224 mTakeoff roll, 928 m Left ahead, 2,829 m

Side view from the start of the roll to the end of Climb 3 at 975 ft.

Reached 35 ft with 2,497 m of runway left; gear up at 68 ft, inside the 400 ft that gets full marks; then climbing at 2,400 fpm on average to 975 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3218 kt avgtarget 202THRESHOLDRUNWAY END6080100120KNOTS ALONG THE ROLLnose up on the runway · 198 m · 2.7 sRotate 132 kttarget 141Liftoff 145 ktGear up 68 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 202240 kt16080020°10°0°nose up on the runway · 198 m · 2.7 sROTATELIFTOFFGEAR UPtarget 141held 8.7°8.8° off · 3.3°/s8° at 35 ftAIRSPEEDPITCH02040 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2 to 3° a second, the rates airliners are rotated at: a trace steeper than both is a faster rotation, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 12.1°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 12.1°ROTATELIFTOFF35 FT8.8° off · 3.3°/s3°/s2°/s8° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5+6+7 sseconds from rotation
PitchRotation began2 to 3°/s from rotationTail strikeNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate660 fpm600 fpm
On glideslope3.1°3.2°
On centreline0.2° off0.2° off
On speed+6.1 kt+5.1 kt
Wings level2° bank2° bank

When the approach was stable

Every check met from 4 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to EDDB 24L

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 90 ft above the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,3157123551851,000 ft gate7 of 71,054 ft · 144 kt500 ft gate7 of 7559 ft · 143 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 13× larger than distances along the final.

Inside the 1° band all the way from 4 nm, never more than 28 m off the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR73 m L073 m RLEFT ↑RIGHT ↓1° BAND3 m R10 m R7 m L9 m L28 m R13 m R
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 35 kt fast at the 1,000 ft gate, closing to 21 at 500 ft and 10 at the threshold.

Inside the speed band all the way, between +5 kt and +9 kt on the approach speed of 138 kt.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

140160180200 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 138+5 kt+5 kt+5 kt+7 kt+5 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on EDDB 24L

Over the threshold

Threshold height100.00
39ft
Threshold speed100.00
142kttarget 138, 4 fast
Centreline offset100.00
4.37m L
Bank100.00
1.3°steepest
Flare100.00

Perfect landing flare

Touchdown

Past threshold88.42
563m
Centreline100.00
4.56m L
Speed100.00
135kttarget 137 or less
Touchdown rate100.00
-173fpm
Impact100.00
1.09G
BouncesOk
None
Bank100.00
1.8°as the wheels touched

Rollout

Rollout distance100.00
823m35 % used
Rollout alignment100.00
3.71m R

Taxi in

LightsOk
All set
Taxi speed100.00
22kt peak

Side view — the last 1,524 m of the approach.

Crossed the threshold at 39 ft, 11 ft below the 50 ft target; began the flare at 36 ft. Touched down 563 m in, 258 m past the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,524 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

39 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 36 ft · −633 fpm · 4.1° · 142 ktdescent slowed at 0 ft · −173 fpm · 5.9°−173 fpm · 5.9° nose up · 135 kt Ideal — 50 ft, down at 305 m This flight — 39 ft, down at 563 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 630 fpm at the flare to 170 fpm at touchdown. The nose came up 1.8° on the way down. Into the flare at 142 kt, 4 kt over the 138 kt approach speed, and 135 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−173 fpm at touchdown5.9° at touchdown, +1.8° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,524 m of the 3,986 m runway, to the same scale as the side view.

Touched down 4.6 m left of the centreline, and stayed about there down the rollout, 4.8 m left at the widest. No crosswind: nothing to correct for. Touched down straight, wings level.

Wind 259° at 3 kt · 2 kt head · 0 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ FULL SCORE TO 503 M 563 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

Touched down 563 m past the threshold — beyond the full-score zone. The arrival was smooth.

Runway used 1,386 m of 3,986 m · 35 %
In the air over the runway, 563 mRollout, 823 m Left over, 2,600 m

The stop — touchdown to taxi speed.

From 135 kt at touchdown to taxi speed (30 kt) in 32 s, an average deceleration of 0.18 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 963 m30 kt · 1,222 mtouchdown1,271 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Flight narrative

The flight in the Boeing 747-8 began with a taxi from the parking area to the runway at EDDM Munich, which took 8 minutes to cover 2 nm. The departure roll occurred on runway 26R, with a takeoff distance of 916 m (23% of the runway). The liftoff speed was 145 kn. The local weather at the time of departure was 13°C with a wind of 4 kn at 250°, resulting in a crosswind of 1 kn and a headwind of 4 kn.

During the enroute climb, the aircraft started to climb from 2,538 ft asl to 34,712 ft asl over 12 minutes, covering a distance of 82 nm. The enroute level cruise began 2 miles north of Hostoun and lasted for 11 minutes, covering 100 nm. The enroute descent started 1 mile north of Niederau, with the aircraft descending from 34,671 ft asl to 1,920 ft asl over 19 minutes, covering 71 nm.

The landing took place on runway 25L at EDDB Berlin Brandenburg Airport, with a runway length of 4,033 m. The height at threshold was 41 ft agl, and the speed at threshold was 142 kn. The touchdown occurred 571 m from the threshold with a speed of 135 kn and a VSI of -190 ft/m. The local weather at the time of landing was 17°C with a wind of 2 kn at 259°, resulting in no crosswind and a headwind of 2 kn. The total landing distance was 1,439 m (36% of the runway).

After landing, the aircraft taxied from the runway to the parking area in 6 minutes, covering less than 1 nm. The total flight distance covered was 264 nm, and the flight took 68 minutes. A total of 6,939 kg of fuel were used for the entire flight.

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
