My FS Flights logo MY FS FLIGHTS
EDDN
Nuremberg, Germany
Runway 28
Elevation1,033 ft asl
Weight57,798 kg
Fuel11,430 kg
Wind230° · 8 kn · 6 kn cross

Flight Score

94.57 %
EDDB
Berlin, Germany
Runway 24R
Elevation151 ft asl
Weight56,538 kg
Fuel10,016 kg
Wind230° · 14 kn · 4 kn cross
19 Dec 2023 0:50 265 nm Airbus A318 1,413 kg
Departure Score
90.57 %
Enroute Score
100.00 %
Arrival Score
93.14 %

What went well

Touched down at -264 fpm — a soft arrival
Straight touchdown — 3.75 m off the centreline, no bounce
Flare on profile — 98 %

What held you back

Departure Climb 3 — Landing gear up at 1,025 ft agl at 0 %, −2.60 points
Arrival Taxi — Taxi Lights at 0 %, Landing Lights at 1 %, −0.66 points
Departure Roll — Strobe Lights at 0 %, −0.53 points

Next time

Departure

Raise the gear lever promptly once a positive climb is confirmed, before reaching the target retraction height.

What happened: Gear retraction was delayed, with the gear not coming up until 1,025 ft agl.

Watch for: Landing gear: up by the normal retraction gate

See Departure Climb 3

Arrival

Reduce power earlier on final so the speed settles to 123 kt before the gate.

What happened: The approach was 19 kt fast at the stabilisation gate, and carrying that extra speed over the threshold usually carries the touchdown long, which happened here by 282 m.

Watch for: Airspeed indicator: 123 kt at the threshold.

See Arrival ApproachArrival LandingArrival Touchdown

A small uncorrected heading error at 40 knots becomes a metre of offset per second by 100 knots, noticed only at rotation, producing a crabbed liftoff. Root cause is nearly always eyes on the tape instead of the far end of the runway. Small heading changes displace a distant point visibly long before the nearby centreline stripes look wrong.

Read more in Improve Your Take-Offs

Start to finish · 16 stages, 14 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Runway Entry Entering runway 28 at EDDN Nuremberg Airport, Average speed was 6 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 1 kt0 kt min to max 17 kt 0 17 kt
Info Average pitch angle -0.0 °-0.1 ° min to max 0.0 ° 0.0 0.0 °
Info Average bank angle 0.3 °0.0 ° min to max 0.4 ° 0.0 0.4 °
Info Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g

Events

Info Battery Master On 1,034 ft agl
Info Engine 1 Started 1,034 ft agl
Info Engine 2 Started 1,034 ft agl
Info Autopilot Wing Leveler Deactivated 1,034 ft agl
Info Autopilot Heading Hold Activated 1,034 ft agl
Info Autopilot Flight Director Activated 1,034 ft agl
Info Landing Gear Down 1,034 ft agl
Info Parking Brake On 1,034 ft agl
Info Flaps Position 1 1,034 ft agl
Info Parking Brake Off 8 ft agl
Info Landing Lights Switched Off 8 ft agl
Info Taxi Lights Switched On 8 ft agl
Info Autopilot Wing Leveler Activated 8 ft agl
Info Autopilot Heading Hold Deactivated 8 ft agl
Info Parking Brake On 8 ft agl
Info Flaps Fully Retracted 8 ft agl
Info Autopilot Wing Leveler Deactivated 8 ft agl
Info Autopilot Heading Hold Activated 8 ft agl
Info Autopilot Heading Hold Deactivated 8 ft agl
Info Autopilot Heading Hold Activated 8 ft agl
Info Autopilot Vertical Hold Activated 8 ft agl
Info Autopilot Heading Hold Deactivated 8 ft agl
Info Autopilot Vertical Hold Deactivated 8 ft agl
Info Beacon Lights Switched Off 8 ft agl · 5 kt
Info Landing Lights Switched On 8 ft agl · 5 kt
Info Taxi Lights Switched Off 8 ft agl · 5 kt
Info Autopilot Heading Hold Activated 8 ft agl · 5 kt
Info Flaps Position 1 8 ft agl · 5 kt
Info Beacon Lights Switched On 8 ft agl · 5 kt
Info Taxi Lights Switched On 8 ft agl · 5 kt
Info Parking Brake Off 8 ft agl · 5 kt
Departure Roll 93.59Departure roll runway 28 at EDDN Nuremberg Airport. Takeoff distance 1,319 m 49 % of runway. Rotation speed was 135 kt. Local weather - Temperature 8 °C. Wind 9 kt at 229 °. Crosswind: 6 kt Headwind: 6 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 1,319 m49 % of runway
100 % Rotation speed was 135 ktTarget 132 kt
93 % Runway alignment max 9.76 m left9.76 m left to 0.00 m left 0.99 1.14 m
100 % Average g force 1.00 g0.93 g min to max 1.09 g 1.00 1.00 g
100 % Takeoff Bounce
Info Average pitch angle 0.1 °-0.5 ° min to max 5.5 ° 0.0 5.5 °
Info Average bank angle 0.5 °0.0 ° min to max 1.1 ° 0.5 0.9 °

Events

Fail Strobe Lights
Info Autopilot AutoThrottle Arm Armed 9 ft agl · 43 kt
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 28 EDDN Nuremberg Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.0 °-0.1 ° min to max 0.2 ° -0.1 0.2 °
100 % Average speed 151 kt139 kt min to max 162 kt 139 162 kt
100 % Steepest bank angle 3.3 °0.3 ° min to max 3.3 ° 1.0 0.7 °
100 % Average g force 1.05 g0.94 g min to max 1.11 g 1.01 1.11 g
Info Average VSI 339 fpm135 fpm min to max 752 fpm 141 752 fpm
Info Average altitude 13 ft agl0 ft agl min to max 40 ft agl 0 40 ft agl
Info Average pitch angle 5.8 °4.4 ° min to max 7.6 ° 5.8 7.6 °

Events

Info Landing Gear Up 10 ft agl · 140 kt
Departure Climb 2 99.94Departure climb to 400 ft agl from 28 EDDN Nuremberg Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.2 °0.2 ° min to max 0.5 ° 0.2 0.5 °
100 % Average speed 165 kt162 kt min to max 170 kt 162 170 kt
100 % Steepest bank angle 0.7 °0.4 ° min to max 0.7 ° 0.6 0.4 °
99 % Average g force 1.20 g1.05 g min to max 1.27 g 1.12 1.05 g
Info Average VSI 1,322 fpm771 fpm min to max 3,712 fpm 771 3,712 fpm
Info Average altitude 84 ft agl41 ft agl min to max 368 ft agl 41 368 ft agl
Info Average pitch angle 10.4 °7.7 ° min to max 15.4 ° 7.7 15.4 °

Events

Info Autopilot Yaw Damper Activated 62 ft agl · 163 kt
Departure Climb 3 68.75Departure climb to 1,000 ft agl from 28 EDDN Nuremberg Airport.
ScoreDescriptionStartProfileEnd
97 % Climb speed 168 kt168 kt min to max 169 ktTarget 147 kt, 21 kt fast 169 168 kt
100 % Steepest bank angle 0.7 °0.1 ° min to max 0.7 ° 0.2 0.4 °
100 % Average g force 0.99 g0.98 g min to max 1.00 g 1.00 0.99 g
0 % Landing gear up at 1,025 ft aglTarget by 400 ft agl, 625 ft agl late
Info Heading variation 0.7 °0.6 ° min to max 0.8 ° 0.6 0.8 °
Info Average VSI 4,040 fpm3,880 fpm min to max 4,159 fpm 3,880 4,159 fpm
Info Average altitude 672 ft agl436 ft agl min to max 912 ft agl 436 912 ft agl
Info Average pitch angle 15.8 °15.4 ° min to max 16.0 ° 15.4 16.0 °
Enroute Climb 99.99Enroute climb started overhead EDDN Nuremberg Airport Nuremberg (Bavaria, Germany). Climbing from 2,032 ft asl to 27,026 ft asl, an increase of 24,995 ft in 13 minutes and covering 76 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 287 kt166 kt min to max 320 kt 169 286 kt
100 % Steepest bank angle 29.1 °0.1 ° min to max 29.1 ° 0.8 25.5 °
99.9 % Average g force 1.05 g0.79 g min to max 1.40 g 1.00 1.09 g
Info Average VSI 2,479 fpm-40 fpm min to max 5,358 fpm 4,204 238 fpm
Info Average altitude 14,312 ft asl2,032 ft asl min to max 27,026 ft asl 2,032 27,026 ft asl
Info Average pitch angle 5.5 °-0.5 ° min to max 17.5 ° 16.1 1.7 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Master Switched On 2,713 ft agl · 173 kt
Info Autopilot Yaw Damper Deactivated 2,713 ft agl · 173 kt
Info Flaps Fully Retracted 2,841 ft agl · 218 kt
Info Overspeed Warning Activated 2,849 ft agl · 234 kt
Info Overspeed Warning Deactivated 2,856 ft agl · 238 kt
Info Autopilot Master Switched Off 3,109 ft agl · 263 kt
Info Autopilot Airspeed Hold Activated 3,109 ft agl · 263 kt
Info Autopilot Yaw Damper Activated 3,109 ft agl · 263 kt
Info Autopilot Vertical Hold Activated 3,109 ft agl · 263 kt
Info Autopilot Wing Leveler Activated 3,163 ft agl · 264 kt
Info Autopilot Heading Hold Deactivated 3,163 ft agl · 264 kt
Info Autopilot Altitude Hold Activated 3,163 ft agl · 264 kt
Info Autopilot Vertical Hold Deactivated 3,163 ft agl · 264 kt
Info Autopilot Wing Leveler Deactivated 3,227 ft agl · 265 kt
Info Autopilot Heading Hold Activated 3,227 ft agl · 265 kt
Info Autopilot Master Switched On 3,691 ft agl · 261 kt
Info Autopilot Yaw Damper Deactivated 3,691 ft agl · 261 kt
Info Autopilot Altitude Hold Deactivated 3,886 ft agl · 264 kt
Info Autopilot Airspeed Hold Deactivated 3,886 ft agl · 264 kt
Info Taxi Lights Switched Off 8,974 ft agl · 290 kt
Info Landing Lights Switched Off 9,646 ft agl · 308 kt
Info Autopilot Altitude Hold Activated 23,910 ft agl · 464 kt
Info Autopilot Airspeed Hold Activated 23,910 ft agl · 464 kt
Info Autopilot Airspeed Hold Deactivated 25,253 ft agl · 424 kt
Info Autopilot Airspeed Hold Activated 25,256 ft agl · 425 kt
Enroute Level 100.00Enroute level cruise started 3 miles south east of Leutenberg (Thuringia, Germany) and lasted 11 minutes, covering 83 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±1,852 ft of 27,001 ft asl26,719 ft asl min to max 27,054 ft asl 27,030 26,719 ft asl
100 % Average speed 278 kt267 kt min to max 287 kt 286 274 kt
100 % Steepest bank angle 25.6 °0.0 ° min to max 25.6 ° 25.6 0.0 °
100 % Average g force 1.02 g0.99 g min to max 1.10 g 1.09 0.99 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 1.4 °-2.2 ° min to max 1.9 ° 1.7 -2.2 °

Events

Info Autopilot Altitude Hold Deactivated 26,651 ft agl · 405 kt
Info Autopilot Airspeed Hold Deactivated 26,651 ft agl · 405 kt
Info Autopilot Airspeed Hold Activated 26,640 ft agl · 405 kt
Info Autopilot Vertical Hold Activated 26,640 ft agl · 405 kt
Enroute Descent 100.00Enroute descent started overhead Arzberg (Saxony, Germany). Descent from 26,315 ft asl to 4,002 ft asl, a decrease of 22,313 ft in 12 minutes and covering 70 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 239 kt223 kt min to max 277 kt 277 223 kt
100 % Steepest bank angle 25.0 °0.0 ° min to max 25.0 ° 0.1 22.9 °
100 % Average g force 1.03 g0.82 g min to max 1.21 g 1.00 1.14 g
Info Average VSI -1,739 fpm-2,962 fpm min to max -166 fpm -2,426 -166 fpm
Info Average altitude 11,695 ft asl4,002 ft asl min to max 26,315 ft asl 26,315 4,002 ft asl
Info Average pitch angle 0.2 °-3.8 ° min to max 5.2 ° -1.9 5.2 °
Info Turn coordination 00 min to max 0 0 0

Events

Fail Landing Lights OFF should be ON 7,518 ft agl
Info Autopilot Airspeed Hold Deactivated 16,686 ft agl · 349 kt
Info Autopilot Vertical Hold Deactivated 16,686 ft agl · 349 kt
Info Taxi Lights Switched On 7,241 ft agl · 253 kt
Info Landing Lights Switched On 7,220 ft agl · 253 kt
Info Autopilot Altitude Hold Activated 4,283 ft agl · 240 kt
Info Autopilot Airspeed Hold Activated 4,251 ft agl · 240 kt
Info Autopilot Altitude Hold Deactivated 3,872 ft agl · 236 kt
Info Autopilot Vertical Hold Activated 3,872 ft agl · 236 kt
Enroute Level 2 100.00Enroute level cruise started 3 miles south of Jacobsdorf (Brandenburg, Germany) and lasted 7 minutes, covering 23 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±700 ft of 3,966 ft asl3,810 ft asl min to max 4,030 ft asl 4,003 3,810 ft asl
100 % Average speed 218 kt198 kt min to max 230 kt 223 203 kt
100 % Steepest bank angle 25.1 °0.0 ° min to max 25.1 ° 24.8 0.0 °
100 % Average g force 1.01 g0.95 g min to max 1.25 g 1.15 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 3.0 °-2.8 ° min to max 5.6 ° 5.5 -2.8 °

Events

Info Autopilot Altitude Hold Activated 3,889 ft agl · 239 kt
Info Autopilot Vertical Hold Deactivated 3,889 ft agl · 239 kt
Info Flaps Position 1 3,771 ft agl · 234 kt
Info Autopilot Heading Hold Deactivated 3,760 ft agl · 211 kt
Info Autopilot Approach Mode Activated 3,760 ft agl · 211 kt
Info Landing Gear Down 3,774 ft agl · 208 kt
Info Autopilot Altitude Hold Deactivated 3,767 ft agl · 210 kt
Enroute Descent 2 100.00Enroute descent started 1 mile north west of Gruenheide (Brandenburg, Germany). Descent from 3,601 ft asl to 1,450 ft asl, a decrease of 2,151 ft in 3 minutes and covering 7 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 147 kt140 kt min to max 202 kt 202 143 kt
100 % Steepest bank angle 0.6 °0.0 ° min to max 0.6 ° 0.1 0.2 °
100 % Average g force 1.00 g0.98 g min to max 1.02 g 1.01 1.00 g
Info Average VSI -638 fpm-1,202 fpm min to max -541 fpm -1,202 -562 fpm
Info Average altitude 1,914 ft asl1,450 ft asl min to max 3,601 ft asl 3,601 1,450 ft asl
Info Average pitch angle 0.0 °-4.4 ° min to max 0.8 ° -2.4 -0.1 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Position 2 3,405 ft agl · 210 kt
Info Flaps Position 3 2,586 ft agl · 181 kt
Info Flaps Position 4 2,494 ft agl · 171 kt
Arrival Approach 92.86Final approach to runway 24R at EDDB Berlin Brandenburg Airport. Descent from 1,327 ft agl to 52 ft agl in 113 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
50 % On speedfailed at one of the two gates
100 % Wings levelpassed at both gates

Events

Fail GPWS Warning Activated 993 ft agl · 142 kt
Info Autopilot Master Switched Off 475 ft agl · 142 kt
Info Autopilot Yaw Damper Activated 475 ft agl · 142 kt
Info Autopilot Vertical Hold Activated 475 ft agl · 142 kt
Info Autopilot Yaw Damper Deactivated 49 ft agl · 138 kt
Arrival Landing 96.26Landing on runway 24R at EDDB Berlin Brandenburg Airport, runway length 3,288 m. Good threshold height. Threshold speed was well above target at 140 kt.
ScoreDescriptionStartProfileEnd
87 % Threshold speed was well above target at 140 kt. Target 123 kt
100 % Good threshold height.Target 50 ft agl
98 % The flare tracked the target profile closely. Crossing the threshold 17 kt above target, the aircraft floated down the runway before touching. Touchdown was 739 m past the threshold. The flare cannot burn off excess energy - fix the approach speed and the float goes with it.
100 % Runway alignment max 3.54 m left3.54 m left to 2.84 m right -2.42 3.53 m
100 % Steepest bank angle 2.2 °0.0 ° min to max 2.2 ° 0.9 1.6 °
100 % Peak g force 1.04 g0.96 g min to max 1.04 g 1.02 0.96 g
Info Average speed 139 kt133 kt min to max 140 kt 140 133 kt
Info Average VSI -231 fpm-378 fpm min to max -105 fpm -378 -185 fpm
Info Average altitude 13 ft agl-3 ft agl min to max 38 ft agl 38 -3 ft agl
Info Average pitch angle 2.0 °1.4 ° min to max 2.8 ° 1.6 2.8 °

Events

Fail GPWS Warning Activated still on from Arrival Approach 993 ft agl · 142 kt
Info GPWS Warning Deactivated 24 ft agl · 139 kt
Info Autopilot AutoThrottle Arm Disarmed 21 ft agl · 139 kt
07515022530037545052560067575082501223354658Runway Distance mLanding Height ft075150225300375450525600675750825-24-20-16-12-8-404812162024Runway Distance mRunway Width m
Arrival Touchdown 93.58Touchdown point was 320 m beyond the touchdown zone. Touchdown speed at 133 kt was fast. Touchdown rate was fair at -264 fpm. Runway touchdown position was slightly misaligned by 3.8 m from centreline. Local weather - Temperature 8 °C. Wind 14 kt at 230 °. Crosswind: 4 kt Headwind: 13 kt.
ScoreDescriptionStartProfileEnd
97 % Touchdown rate was -264 fpm.
69 % Touchdown distance was 739 mTarget 457 m
94 % Speed at touchdown 133 ktTarget below 120 kt
100 % Runway alignment max 3.75 m left3.60 m left 3.53 3.75 m
100 % Steepest bank angle 1.6 °0.4 ° min to max 1.6 ° 1.6 0.4 °
100 % Peak g force 1.23 g0.96 g min to max 1.23 g 0.96 1.12 g
100 % Landing Bounce
Info Average speed 132 kt131 kt min to max 133 kt 133 131 kt
Info Average pitch angle 2.9 °2.8 ° min to max 3.0 ° 2.8 2.8 °
Arrival Rollout 92.96Total landing distance 1,327 m, 40 % of runway. Runway rollout alignment was slightly misaligned by 10.9 m from centreline.
ScoreDescriptionStartProfileEnd
100 % Landing distance 1,327 m40 % of runway.
84 % Runway alignment max 10.91 m left10.91 m left to 0.00 m left 9.58 8.13 m
100 % Average g force 1.01 g0.97 g min to max 1.08 g 1.08 1.00 g
Info Average speed 106 kt60 kt min to max 116 kt 116 60 kt
Info Average pitch angle 1.0 °-0.3 ° min to max 2.8 ° 2.8 -0.3 °
Info Average bank angle 0.3 °0.0 ° min to max 0.8 ° 0.3 0.2 °
Runway Exit Exiting runway, average speed 50 kt
ScoreDescriptionStartProfileEnd
Info Average speed 35 kt24 kt min to max 55 kt 55 24 kt
Info Average pitch angle 0.2 °-0.3 ° min to max 0.3 ° -0.3 0.0 °
Info Average bank angle 0.3 °0.1 ° min to max 0.6 ° 0.2 0.4 °
Info Average g force 1.00 g0.99 g min to max 1.01 g 1.01 0.99 g

Events

Info Flaps Position 2 9 ft agl · 46 kt
Info Flaps Fully Retracted 9 ft agl · 46 kt
Info Autopilot Heading Hold Activated 9 ft agl · 39 kt
Info Autopilot Approach Mode Deactivated 9 ft agl · 39 kt
Arrival Taxi 90.05Taxiing to the parking from the runway took 3 minutes and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 12 kt0 kt min to max 23 kt 23 0 kt
100 % Average speed turning corners 10 ktmax 12 kt 0 0 kt
100 % Average g force 1.00 g1.00 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle 0.2 °-0.1 ° min to max 0.3 ° 0.0 0.3 °
Info Average bank angle 0.1 °0.0 ° min to max 0.6 ° 0.6 0.0 °

Events

Fail Landing Lights
Fail Taxi Lights
Info Parking Brake On 8 ft agl
Info Taxi Lights Switched Off 8 ft agl
Info Landing Lights Switched Off 8 ft agl
Info Taxi Lights Switched On 8 ft agl
Info Strobe Lights Switched Off 8 ft agl

Takeoff from EDDN 28

Taxi out

Lights50.00
Offstrobes

The roll

Takeoff roll100.00
1,319m49 %
Runway alignment92.94
9.76m L
Rotation speed100.00
135kttarget 132, 3 late

On speed, but the nose came up quickly

Rotation started at 135 kt, 3 kt after the 132 kt rotate speed. The nose then rose at 5.6° a second, faster than the 2 to 3° a second airliners use.

The rotation started on speed but the nose came up quickly. A fast pull raises the nose faster than the aircraft can lift off, which brings the tail closer to the runway. Pull smoothly at the normal rate for this aircraft and let it fly off at its own attitude.

Liftoff and climb

Liftoff
138ktat 5.8°
Rotation
5.6°/sover 1.0 s, gaining 3 kt
35 ft
161ktat 7.1°, 5.5 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
3.3°steepest
Gear up0.00
1,025ftfull marks to 400 ft
Climb 3 speed96.86
168kttarget 147

Plan view the roll down the 2,694 m runway.

Rolled from 385 m in, drifted 10 m left of the centreline and was back on it to lift off, in 6 kn of crosswind from the left. Airborne 49 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

1,0002,000THRESHOLDLEFT ↑RIGHT ↓CROSS6 kn75 %widest 9.99 m LROLL 385 M INAirborne 1,324 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,324 m of 2,694 m · 49 %
Behind the start of the roll, 385 mTakeoff roll, 939 m Left ahead, 1,370 m

Side view from the start of the roll to the end of Climb 3 at 912 ft.

Reached 35 ft with 954 m of runway left; then climbing at 2,530 fpm on average to 912 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3168 kt avgtarget 147THRESHOLDRUNWAY END6080100120KNOTS ALONG THE ROLLnose up on the runway · 69 m · 1.0 sRotate 135 kttarget 132Liftoff 138 kt
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 147180 kt12060020°10°0°nose up on the runway · 69 m · 1.0 sROTATELIFTOFFtarget 132held 10.9°5.8° off · 5.6°/s7° at 35 ftAIRSPEEDPITCH02040 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2 to 3° a second, the rates airliners are rotated at: a trace steeper than both is a faster rotation, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate.

20°10°0°ROTATELIFTOFF35 FT5.8° off · 5.6°/s3°/s2°/s7° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5+6+7 sseconds from rotation
PitchRotation began2 to 3°/s from rotationNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 85.716 of 7
Gear down
Landing flap
Sink rate670 fpm590 fpm
On glideslope3.1°3.2°
On centreline0.1° off0.2° off
On speed+18 kt+19 kt
Wings level0° bank0° bank

At the 500 ft gate: speed more than 18 kt above the approach speed of 123 kt.

When the approach was stable

Every check met from 4 nm to 1.6 nm, then not again: fast from 1.6 nm to the threshold.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to EDDB 24R

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 30 ft below the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,3136883841921,000 ft gate7 of 71,069 ft · 141 kt500 ft gate6 of 7on speed577 ft · 142 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 17× larger than distances along the final.

Inside the 1° band all the way from 4 nm, never more than 21 m off the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR55 m L055 m RLEFT ↑RIGHT ↓1° BAND18 m R12 m R9 m R7 m R16 m R12 m R
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 31 kt fast at the 1,000 ft gate, closing to 18 at 500 ft and 10 at the threshold.

Inside the speed band from 4 nm to 1.6 nm, then fast to the threshold (up to +21 kt).

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

120140160180 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 123+20 kt+18 kt+17 kt+21 kt+17 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on EDDB 24R

Over the threshold

Threshold height100.00
37ft
Threshold speed86.60
139kttarget 123, 16 fast
Centreline offset100.00
3.54m L
Bank100.00
2.2°steepest
Flare98.43

The flare tracked the target profile closely

Crossing the threshold 17 kt above target, the aircraft floated down the runway before touching. Touchdown was 739 m past the threshold. The flare cannot burn off excess energy - fix the approach speed and the float goes with it.

Touchdown

Past threshold69.15
739m
Centreline100.00
3.75m L
Speed94.20
132kttarget 119, 13 fast
Touchdown rate96.87
-264fpm
Impact100.00
1.23G
BouncesOk
None
Bank100.00
1.6°as the wheels touched

Rollout

Rollout distance100.00
547m39 % used
Rollout alignment84.35
10.91m L

Taxi in

Lights0.50
Wrongtaxi lights off, landing lights on
Taxi speed100.00
23kt peak10 kt in turns

Side view — the last 1,524 m of the approach.

Crossed the threshold at 37 ft, 13 ft below the 50 ft target; began the flare at 12 ft. Touched down 739 m in, 434 m past the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,524 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

37 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 12 ft · −145 fpm · 2.2° · 140 ktdescent slowed at 10 ft · −63 fpm · 1.9°−264 fpm · 2.8° nose up · 133 kt Ideal — 50 ft, down at 305 m This flight — 37 ft, down at 739 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 140 fpm at the flare to 60 fpm at 10 ft, then back up to 260 fpm at touchdown. The nose came up 0.6° on the way down. Into the flare at 140 kt, 17 kt over the 123 kt approach speed, and 133 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−264 fpm at touchdown2.8° at touchdown, +0.6° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,524 m of the 3,288 m runway, to the same scale as the side view.

Touched down 3.8 m left of the centreline and drifted to 10 m left on the rollout. 4 kt across from the left, which takes about 2° of crab to hold the centreline at 133 kt. Touched down with 2° of it still on, wings level.

Wind 230° at 14 kt · 13 kt head · 4 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ CROSS 4 kn FULL SCORE TO 503 M 739 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

Touched down 739 m past the threshold — beyond the full-score zone. The arrival was smooth.

Runway used 1,286 m of 3,288 m · 39 %
In the air over the runway, 739 mRollout, 547 m Left over, 2,001 m

The stop — touchdown to taxi speed.

From 118 kt at touchdown to taxi speed (30 kt) in 30 s, an average deceleration of 0.15 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 586 m30 kt · 930 mtouchdown967 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
