RKSI
Seoul, South Korea
Runway 34R
Elevation23 ft asl
Weight163,701 kg
Fuel23,978 kg
Wind260° · 14 kn · 13 kn cross

Flight Score

89.12 %
RJBB
Osaka, Japan
Runway 06L
Elevation16 ft asl
Weight157,225 kg
Fuel17,225 kg
Wind350° · 19 kn · 17 kn cross
30 Mar 2025 1:18 516 nm Airbus A350-900 6,753 kg
Departure Score
86.74 %
Enroute Score
99.00 %
Arrival Score
81.61 %

What went well

Rollout controlled — 41 % of the runway used
Airborne in 1,967 m — 49 % of the runway

What held you back

Arrival Taxi — peak taxi speed 56 kt at 0 %, peak speed in a turn 23 kt at 85 %, −3.06 points
Departure Climb 3 — gear not retracted; Landing gear up at 0 ft agl at 0 %, climb speed 217 kt against 175 kt at 70 %, −2.80 points
Departure Roll — Runway alignment max 67.53 m left at 0 %, Rotation speed was 173 kt at 88 %, −1.50 points

Next time

Departure

Raise the gear lever promptly once a positive rate of climb is confirmed after liftoff.

What happened: The landing gear was never raised during the initial climb and was still down when the climb ended.

Watch for: Landing gear lever: UP promptly after confirming a positive rate of climb.

See Departure Climb 3

Arrival

Use small rudder inputs against a point at the far end of the runway to hold the centreline during rollout.

What happened: During the rollout the aircraft drifted 21 m off the centreline.

Watch for: Runway centreline marks: hold the aircraft tracking straight down the centreline through rollout

See Arrival Rollout

A small uncorrected heading error at 40 knots becomes a metre of offset per second by 100 knots, noticed only at rotation, producing a crabbed liftoff. Root cause is nearly always eyes on the tape instead of the far end of the runway. Small heading changes displace a distant point visibly long before the nearby centreline stripes look wrong.

Read more in Improve Your Take-Offs

Start to finish · 18 stages, 16 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 8 minutes and covered 2 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 12 kt0 kt min to max 28 kt 3 28 kt
100 % Average speed turning corners 0 ktmax 0 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.00 g 1.00 1.00 g
Info Average pitch angle -0.1 °-0.3 ° min to max 0.8 ° 0.8 -0.3 °
Info Average bank angle 0.0 °0.0 ° min to max 0.1 ° 0.0 0.1 °

Events

Info Battery Master On 15 ft agl
Info Engine 2 Started 15 ft agl
Info Beacon Lights Switched On 15 ft agl
Info Navigation Lights Switched On 15 ft agl
Info Autopilot Wing Leveler Activated 15 ft agl
Info Autopilot Altitude Hold Activated 15 ft agl
Info Autopilot Flight Director Activated 15 ft agl
Info Landing Gear Down 15 ft agl
Info Parking Brake On 15 ft agl
Info Engine 1 Started 15 ft agl
Info Flaps Position 1 15 ft agl
Info Taxi Lights Switched On 15 ft agl
Info Parking Brake Off 15 ft agl
Info Landing Lights Switched On 15 ft agl · 19 kt
Info Strobe Lights Switched On 15 ft agl · 16 kt
Info Taxi Lights Switched Off 15 ft agl · 15 kt
Departure Runway Entry Entering runway 34R at RKSI Incheon International Airport, Average speed was 58 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 46 kt29 kt min to max 57 kt 29 57 kt
Info Average pitch angle -0.2 °-0.3 ° min to max -0.0 ° -0.3 -0.0 °
Info Average bank angle 0.2 °0.1 ° min to max 0.3 ° 0.2 0.1 °
Info Average g force 1.00 g0.98 g min to max 1.01 g 0.98 0.99 g
Departure Roll 77.54Departure roll runway 34R at RKSI Incheon International Airport. Takeoff distance 1,967 m 49 % of runway. Rotation speed was 173 kt. Local weather - Temperature 9 °C. Wind 14 kt at 259 °. Crosswind: 13 kt Headwind: 6 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 1,967 m49 % of runway
88 % Rotation speed was 173 ktTarget 149 kt
0 % Runway alignment max 67.53 m left67.53 m left to 0.00 m left 67.24 16.91 m
100 % Average g force 1.00 g0.90 g min to max 1.13 g 0.99 1.13 g
100 % Takeoff Bounce
Info Average pitch angle 0.1 °-0.6 ° min to max 3.5 ° -0.0 3.5 °
Info Average bank angle 0.2 °0.0 ° min to max 1.9 ° 0.1 1.0 °
Departure Climb 1 99.27Departure climb to 50 ft agl from runway 34R RKSI Incheon International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.5 °-0.6 ° min to max -0.5 ° -0.5 -0.6 °
100 % Average speed 183 kt178 kt min to max 189 kt 178 189 kt
99 % Steepest bank angle 6.6 °1.3 ° min to max 6.6 ° 1.3 6.5 °
95 % Average g force 1.38 g1.27 g min to max 1.52 g 1.31 1.27 g
Info Average VSI 658 fpm30 fpm min to max 1,384 fpm 30 1,384 fpm
Info Average altitude 18 ft agl0 ft agl min to max 47 ft agl 0 47 ft agl
Info Average pitch angle 6.1 °3.8 ° min to max 7.8 ° 3.8 7.8 °
Departure Climb 2 98.93Departure climb to 400 ft agl from 34R RKSI Incheon International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.5 °-0.6 ° min to max -0.3 ° -0.6 -0.3 °
100 % Average speed 193 kt189 kt min to max 206 kt 189 206 kt
96 % Steepest bank angle 6.5 °0.2 ° min to max 6.5 ° 6.5 2.8 °
99.97 % Average g force 1.21 g0.98 g min to max 1.26 g 1.26 0.98 g
Info Average VSI 1,982 fpm1,425 fpm min to max 3,648 fpm 1,425 3,648 fpm
Info Average altitude 100 ft agl49 ft agl min to max 377 ft agl 49 377 ft agl
Info Average pitch angle 9.0 °7.9 ° min to max 10.9 ° 7.9 10.8 °
Departure Climb 3 57.96Departure climb to 1,000 ft agl from 34R RKSI Incheon International Airport.
ScoreDescriptionStartProfileEnd
70 % Climb speed 217 kt208 kt min to max 228 ktTarget 175 kt, 42 kt fast 208 228 kt
100 % Steepest bank angle 2.9 °0.5 ° min to max 2.9 ° 2.9 0.9 °
100 % Average g force 0.97 g0.96 g min to max 0.98 g 0.96 0.98 g
0 % Landing gear up at 0 ft aglTarget by 400 ft agl
Info Heading variation -0.0 °-0.2 ° min to max 0.2 ° -0.2 0.2 °
Info Average VSI 3,773 fpm3,707 fpm min to max 3,836 fpm 3,707 3,836 fpm
Info Average altitude 690 ft agl439 ft agl min to max 945 ft agl 439 945 ft agl
Info Average pitch angle 10.4 °10.2 ° min to max 10.7 ° 10.7 10.2 °

Events

Fail Gear Not Retracted
Enroute Climb 100.00Enroute climb started 1 mile north west of RKSI Incheon International Airport Seoul (Incheon, South Korea). Climbing from 1,052 ft asl to 39,813 ft asl, an increase of 38,761 ft in 22 minutes and covering 161 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 260 kt229 kt min to max 282 kt 229 253 kt
100 % Steepest bank angle 30.0 °0.0 ° min to max 30.0 ° 1.1 0.2 °
100 % Average g force 1.04 g0.85 g min to max 1.19 g 0.98 1.00 g
Info Average VSI 1,702 fpm-166 fpm min to max 5,414 fpm 3,862 10 fpm
Info Average altitude 16,455 ft asl1,052 ft asl min to max 39,813 ft asl 1,052 39,813 ft asl
Info Average pitch angle 4.8 °1.4 ° min to max 14.4 ° 10.1 2.2 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Landing Gear Up 1,090 ft agl · 229 kt
Info Flaps Fully Retracted 1,156 ft agl · 231 kt
Info Autopilot Altitude Hold Deactivated 3,341 ft agl · 249 kt
Info Autopilot Vertical Hold Activated 3,341 ft agl · 249 kt
Info Autopilot Altitude Hold Activated 3,980 ft agl · 249 kt
Info Autopilot Vertical Hold Deactivated 3,980 ft agl · 249 kt
Info Autopilot Altitude Hold Deactivated 5,105 ft agl · 260 kt
Info Autopilot Vertical Hold Activated 5,105 ft agl · 260 kt
Info Autopilot Altitude Hold Activated 5,157 ft agl · 261 kt
Info Autopilot Vertical Hold Deactivated 5,157 ft agl · 261 kt
Info Landing Lights Switched Off 10,162 ft agl · 304 kt
Info Autopilot Altitude Hold Deactivated 39,751 ft agl · 463 kt
Info Autopilot Vertical Hold Activated 39,751 ft agl · 463 kt
Enroute Level 100.00Enroute level cruise started 16 miles north east of RKTB Paekado Helipad Paekado (Ul-do) (Gyeongsangbuk-do, South Korea) and lasted 20 minutes, covering 191 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,491 ft of 40,064 ft asl39,814 ft asl min to max 40,345 ft asl 39,814 40,345 ft asl
100 % Average speed 253 kt253 kt min to max 254 kt 254 253 kt
100 % Steepest bank angle 1.3 °0.0 ° min to max 1.3 ° 0.1 0.1 °
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 2.2 °2.1 ° min to max 2.3 ° 2.2 2.2 °
Enroute Descent 100.00Enroute descent started 8 miles north west of Matsue (Shimane-ken, Japan). Descent from 40,350 ft asl to 18,631 ft asl, a decrease of 21,719 ft in 11 minutes and covering 88 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 294 kt253 kt min to max 307 kt 253 286 kt
100 % Steepest bank angle 29.6 °0.0 ° min to max 29.6 ° 0.1 0.1 °
100 % Average g force 1.03 g0.84 g min to max 1.29 g 1.00 1.00 g
Info Average VSI -2,221 fpm-4,343 fpm min to max 48 fpm 32 39 fpm
Info Average altitude 28,182 ft asl18,612 ft asl min to max 40,378 ft asl 40,350 18,631 ft asl
Info Average pitch angle -1.5 °-3.6 ° min to max 2.2 ° 2.2 1.1 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Altitude Hold Activated 40,346 ft agl · 485 kt
Info Autopilot Vertical Hold Deactivated 18,662 ft agl · 375 kt
Info Autopilot Altitude Hold Deactivated 18,372 ft agl · 375 kt
Info Autopilot Vertical Hold Activated 18,372 ft agl · 375 kt
Enroute Level 2 100.00Enroute level cruise started 8 miles east of Okayama (Okayama-ken, Japan) and lasted 2 minutes, covering 10 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±1,432 ft of 18,608 ft asl18,334 ft asl min to max 18,650 ft asl 18,632 18,334 ft asl
100 % Average speed 285 kt282 kt min to max 286 kt 286 282 kt
100 % Steepest bank angle 27.2 °0.0 ° min to max 27.2 ° 0.0 27.2 °
100 % Average g force 1.03 g0.94 g min to max 1.09 g 1.00 1.01 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 0.6 °-2.7 ° min to max 1.4 ° 1.2 -2.7 °

Events

Info Autopilot Altitude Hold Activated 18,649 ft agl · 380 kt
Enroute Descent 2 100.00Enroute descent started 1 mile north of Tonosho (Kagawa-ken, Japan). Descent from 18,288 ft asl to 4,255 ft asl, a decrease of 14,033 ft in 8 minutes and covering 47 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 253 kt202 kt min to max 305 kt 283 202 kt
100 % Steepest bank angle 29.4 °0.0 ° min to max 29.4 ° 27.2 0.1 °
100 % Average g force 1.04 g0.84 g min to max 1.17 g 1.01 1.02 g
Info Average VSI -1,807 fpm-3,899 fpm min to max -516 fpm -2,678 -1,709 fpm
Info Average altitude 10,315 ft asl4,255 ft asl min to max 18,288 ft asl 18,288 4,255 ft asl
Info Average pitch angle -1.3 °-4.6 ° min to max 1.0 ° -3.0 -2.1 °
Info Turn coordination 00 min to max 0 0 0

Events

Fail Landing Lights OFF should be ON 9,333 ft agl
Info Landing Lights Switched On 9,004 ft agl · 286 kt
Info Autopilot Altitude Hold Deactivated 5,387 ft agl · 215 kt
Info Flaps Position 1 4,706 ft agl · 214 kt
Info Autopilot Altitude Hold Activated 4,282 ft agl · 212 kt
Info Autopilot Vertical Hold Deactivated 4,282 ft agl · 212 kt
Enroute Level 3 93.99Enroute level cruise started 7 miles east of Sumoto (Hyogo, Japan) and lasted 3 minutes, covering 7 nm.
ScoreDescriptionStartProfileEnd
80 % Altitude held within ±699 ft of 2,410 ft asl1,288 ft asl min to max 3,971 ft asl 3,971 1,288 ft asl
100 % Average speed 169 kt141 kt min to max 197 kt 197 172 kt
100 % Steepest bank angle 0.4 °0.0 ° min to max 0.4 ° 0.0 0.1 °
100 % Average g force 1.02 g0.95 g min to max 1.07 g 1.03 1.04 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle -2.5 °-8.1 ° min to max 3.9 ° -2.2 -1.8 °

Events

Info Flaps Position 2 3,719 ft agl · 164 kt
Info Landing Gear Down 3,725 ft agl · 163 kt
Info Autopilot Altitude Hold Activated 3,738 ft agl · 147 kt
Info Autopilot Altitude Hold Deactivated 3,732 ft agl · 147 kt
Info Flaps Position 4 3,707 ft agl · 148 kt
Arrival Approach 100.00Final approach to runway 06L at RJBB Kansai International Airport. Descent from 1,310 ft agl to 83 ft agl in 109 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates
Arrival Landing 82.94Landing on runway 06L at RJBB Kansai International Airport, runway length 4,001 m. Threshold height at 68 ft agl was above target. Threshold speed was good at 126 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 126 kt. Target 125 kt
71 % Threshold height at 68 ft agl was above target.Target 50 ft agl
61 % The flare wandered off the target profile. The aircraft was flown onto the runway - pitch changed 0.3° and the descent was barely arrested. Touchdown was 507 m past the threshold. Start the flare with progressive back pressure rather than one pull, and keep it coming.
100 % Runway alignment max 9.79 m right6.03 m right to 9.79 m right -9.79 -6.03 m
99 % Steepest bank angle 3.8 °0.0 ° min to max 3.8 ° 3.8 1.2 °
100 % Peak g force 1.05 g0.99 g min to max 1.05 g 1.00 1.01 g
Info Average speed 128 kt126 kt min to max 128 kt 126 126 kt
Info Average VSI -434 fpm-484 fpm min to max -304 fpm -468 -304 fpm
Info Average altitude 36 ft agl9 ft agl min to max 68 ft agl 68 9 ft agl
Info Average pitch angle 2.2 °1.6 ° min to max 3.4 ° 1.9 3.4 °
07515022530037545052560001326395265Runway Distance mLanding Height ft075150225300375450525600-30-24-18-12-60612182430Runway Distance mRunway Width m
Arrival Touchdown 90.93Touchdown point was 85 m beyond the touchdown zone. Touchdown speed at 126 kt was a little fast. Touchdown rate was hard at -434 fpm. Runway touchdown position was slightly misaligned by 6.0 m from centreline. Local weather - Temperature 8 °C. Wind 19 kt at 350 °. Crosswind: 17 kt Headwind: 9 kt.
ScoreDescriptionStartProfileEnd
59 % Touchdown rate was -434 fpm.
95 % Touchdown distance was 507 mTarget 457 m
100 % Speed at touchdown 126 ktTarget below 123 kt
100 % Runway alignment max 6.03 m right5.49 m right -6.03 -4.72 m
100 % Steepest bank angle 1.2 °0.0 ° min to max 1.2 ° 1.2 0.2 °
99 % Peak g force 1.34 g1.01 g min to max 1.34 g 1.01 1.19 g
100 % Landing Bounce
Info Average speed 126 kt126 kt min to max 126 kt 126 126 kt
Info Average pitch angle 2.9 °2.4 ° min to max 3.4 ° 3.4 2.4 °
Arrival Rollout 80.04Total landing distance 1,681 m, 42 % of runway. Runway rollout alignment was misaligned by 20.7 m from centreline.
ScoreDescriptionStartProfileEnd
100 % Landing distance 1,681 m42 % of runway.
56 % Runway alignment max 20.69 m left20.69 m left to 6.25 m right 15.50 -6.25 m
100 % Average g force 1.00 g0.92 g min to max 1.13 g 1.13 1.01 g
Info Average speed 102 kt59 kt min to max 112 kt 112 59 kt
Info Average pitch angle 0.5 °-0.6 ° min to max 2.4 ° 2.4 -0.1 °
Info Average bank angle 0.3 °0.0 ° min to max 0.6 ° 0.3 0.1 °
Runway Exit Exiting runway, average speed 36 kt
ScoreDescriptionStartProfileEnd
Info Average speed 35 kt24 kt min to max 51 kt 51 24 kt
Info Average pitch angle 0.2 °0.0 ° min to max 0.3 ° 0.0 0.2 °
Info Average bank angle 0.1 °0.0 ° min to max 0.2 ° 0.0 0.1 °
Info Average g force 1.00 g1.00 g min to max 1.01 g 1.01 1.00 g
Arrival Taxi 54.15Taxiing to the parking from the runway took 6 minutes and covered 2 nm.
ScoreDescriptionStartProfileEnd
0 % Average speed 25 kt0 kt min to max 56 kt 20 0 kt
85 % Average speed turning corners 18 ktmax 23 kt 0 0 kt
100 % Average g force 1.00 g0.96 g min to max 1.02 g 1.00 1.00 g
Info Average pitch angle -0.2 °-1.7 ° min to max 0.1 ° 0.1 -0.1 °
Info Average bank angle 0.1 °0.0 ° min to max 4.1 ° 0.1 0.0 °

Events

Info Taxi Lights Switched On 14 ft agl · 18 kt
Info Landing Lights Switched Off 14 ft agl · 19 kt
Info Flaps Position 3 15 ft agl
Info Flaps Fully Retracted 15 ft agl
Info Strobe Lights Switched Off 15 ft agl
Info Parking Brake On 15 ft agl

Takeoff from RKSI 34R

Taxi out

LightsOk
All on
Taxi speed100.00
28kt peak

The roll

Takeoff roll100.00
1,967m49 %
Runway alignment0.00
67.53m L
Rotation speed87.70
173kttarget 149, 24 late

Rotated late, and the nose came up quickly

Rotation started at 173 kt, 24 kt after the 149 kt rotate speed, and the nose then rose at 5.0° a second, faster than the 1.5 to 2.5° a second other Airbus A350-900 pilots fly.

The pull started late and then came quickly, as if to make up the time. Start it on the rotate speed instead, so there is nothing to catch up, and keep it to the normal rate for this aircraft.

Liftoff and climb

Liftoff
177ktat 3.8°
Rotation
5.0°/sover 0.8 s, gaining 4 kt
35 ft
188ktat 7.2°, 1.8 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff99.07
6.6°steepest
Climb 3 speed69.90
217kttarget 175

Plan view the roll down the 3,990 m runway.

Rolled from 805 m in, drifted left of the centreline, 68 m at the widest, and lifted off 17 m left, in 12 kn of crosswind from the left. Airborne 49 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.

1,0002,0003,000THRESHOLDLEFT ↑RIGHT ↓CROSS12 kn75 %widest 67.75 m LROLL 805 M INAirborne 1,974 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,974 m of 3,990 m · 49 %
Behind the start of the roll, 805 mTakeoff roll, 1,168 m Left ahead, 2,017 m

Side view from the start of the roll to the end of Climb 3 at 946 ft.

Reached 35 ft with 1,856 m of runway left; then climbing at 3,200 fpm on average to 946 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3217 kt avgtarget 175THRESHOLDRUNWAY END6080100120140160KNOTS ALONG THE ROLLnose up on the runway · 70 m · 0.8 sRotate 173 kttarget 149Liftoff 177 kt
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 175240 kt16080020°10°0°nose up on the runway · 70 m · 0.8 sROTATELIFTOFFtarget 149held 9.1°3.8° off · 5.0°/s7° at 35 ftAIRSPEEDPITCH02040 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 1.5 to 2.5° a second, the middle half of rotation rates flown by other Airbus A350-900 pilots over the last 180 days (128 takeoffs); the grey pair are 2 to 3° a second, the rates airliners are rotated at. A trace steeper than both green lines is a faster rotation than most, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate.

20°10°0°ROTATELIFTOFF35 FT3.8° off · 5.0°/s3°/s2.5°/s2°/s1.5°/s7° at 35 ftROTATION DETAIL-2-10+1+2+3 sseconds from rotation
PitchRotation began1.5 to 2.5°/s, other Airbus A350-900 pilots2 to 3°/s from rotation, airlinersNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate670 fpm580 fpm
On glideslope3.1°3.2°
On centreline0.1° off0.1° off
On speed+25 kt+0.9 kt
Wings level0° bank0° bank

When the approach was stable

Every check met from 3.3 nm, about 1,130 ft above the runway, to the threshold, before the 1,000 ft gate, so through both gates. The last to settle was the speed.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to RJBB 06L

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 30 ft below the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,2967083852031,000 ft gate7 of 71,071 ft · 150 kt500 ft gate7 of 7569 ft · 126 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 26× larger than distances along the final.

Inside the 1° band all the way from 4 nm, never more than 14 m off the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR37 m L037 m RLEFT ↑RIGHT ↓1° BAND14 m L7 m L5 m L4 m R9 m L5 m L
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 31 kt fast at the 1,000 ft gate, closing to 19 at 500 ft and 10 at the threshold.

Fast from 4 nm to 3.3 nm (up to +49 kt), then inside the band to the threshold.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

120140160180 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 125+49 kt+8 kt+2 kt+1 kt+1 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on RJBB 06L

Over the threshold

Threshold height70.84
68ft
Threshold speed100.00
126kttarget 125, 1 fast
Centreline offset100.00
9.79m R
Bank99.48
3.8°steepest
Flare61.12

The flare wandered off the target profile

The aircraft was flown onto the runway - pitch changed 0.3° and the descent was barely arrested. Touchdown was 507 m past the threshold. Start the flare with progressive back pressure rather than one pull, and keep it coming.

Touchdown

Past threshold94.51
507m
Centreline100.00
6.03m R
Speed100.00
126kttarget 122, 4 fast
Touchdown rate59.09
-434fpm
Impact98.81
1.34G
BouncesOk
None
Bank100.00
1.2°as the wheels touched

Rollout

Rollout distance100.00
1,139m41 % used
Rollout alignment55.65
20.69m L

Taxi in

LightsOk
All set
Taxi speed42.69
56kt peak18 kt in turns

Side view — the last 1,768 m of the approach.

Crossed the threshold at 68 ft, 18 ft above the 50 ft target; began the flare late, at 11 ft. Touched down 507 m in, 203 m past the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,768 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

68 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare 11 ft · −417 fpm · 3.1° · 127 ktdescent slowed at 9 ft · −415 fpm · 3.2°−434 fpm · 3.4° nose up · 126 kt Ideal — 50 ft, down at 305 m This flight — 68 ft, down at 507 m

Sink and pitch — through the flare, lined up with the side view.

The sink stayed between 420 fpm and 440 fpm from the flare to the runway. The pitch barely changed. Into the flare at 127 kt, on the 125 kt approach speed, and 126 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°flaredescent slowedtouchdown−434 fpm at touchdown3.4° at touchdown, +0.3° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,768 m of the 4,001 m runway, to the same scale as the side view.

Touched down 4.7 m right of the centreline and drifted to 20 m left on the rollout, back to 2.3 m left by the end. 16 kt across from the left, which takes about 7° of crab to hold the centreline at 126 kt. Touched down with the nose 8° into wind, wings level.

Wind 350° at 19 kt · 9 kt head · 16 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ CROSS 16 kn FULL SCORE TO 503 M 507 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

Touched down 507 m past the threshold — beyond the full-score zone. The 434 fpm arrival was firm.

Runway used 1,646 m of 4,001 m · 41 %
In the air over the runway, 507 mRollout, 1,139 m Left over, 2,355 m

The stop — touchdown to taxi speed.

From 114 kt at touchdown to taxi speed (30 kt) in 34 s, an average deceleration of 0.14 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 1,174 m30 kt · 1,331 mtouchdown1,385 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Flight narrative

The flight began with an enroute climb from Incheon International Airport in Seoul, South Korea. The aircraft, an Airbus A350-900, took off from a point 1 mile northwest of the airport and climbed to a height of 39,813 feet above sea level, an increase of 38,761 feet in just 22 minutes. This climb phase covered a distance of 149 nautical miles.

Following the initial climb, the aircraft entered an enroute level cruise phase, which started 16 miles northeast of Paekado Helipad in Gyeongsangbuk-do, South Korea. This phase lasted for 20 minutes and covered a distance of 191 nautical miles.

As the flight continued, the aircraft began its enroute descent phase, starting 8 miles northwest of Matsue in Japan. The descent from 40,350 feet to 18,631 feet took just 11 minutes, covering a distance of 79 nautical miles.

The aircraft then entered another enroute level cruise phase, this time starting 8 miles east of Okayama in Japan. This brief phase lasted only 2 minutes and covered a distance of 9 nautical miles.

The next descent phase began 1 mile north of Tonosho in Japan, with the aircraft descending from 18,288 feet to 4,255 feet in just 8 minutes, covering a distance of 44 nautical miles.

The aircraft then entered another enroute level cruise phase, starting 7 miles east of Sumoto in Japan. This phase lasted for 3 minutes and covered a distance of 7 nautical miles.

The final approach to Kansai International Airport in Japan began from the southwest, with the aircraft heading 51.0 degrees at an altitude of 1,255 feet above ground level and a distance of 4 nautical miles from the runway.

The landing on runway 06L at Kansai International Airport was successful, but with some minor issues. The touchdown point was 80 meters beyond the touchdown zone, and the touchdown speed of 126 knots was slightly above the target speed. The touchdown rate was firm at -304 feet per minute, and the runway touchdown position was slightly misaligned by 6.6 meters from the centerline.

The local weather conditions at the time of landing were a temperature of 8 degrees Celsius, with a wind speed of 19 knots from 350 degrees. The crosswind was 17 knots, and the headwind was 9 knots.

The total landing distance was 1,673 meters, which accounted for 42% of the runway length. The runway rollout alignment was also misaligned by 21.1 meters from the centerline.

After landing, the aircraft took 6 minutes to taxi to the parking area from the runway, covering a distance of 1 nautical mile.

The total flight distance was 489 nautical miles, and the flight duration was 78 minutes. The aircraft used a total of 6,753 kilograms of fuel during the flight.

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
