KLAX
Los Angeles, United States
Runway 24L
Elevation125 ft asl
Weight373,402 kg
Fuel119,536 kg
Wind260° · 6 kn

Flight Score

99.36 %
RJAA
Narita, Japan
Runway 34L
Elevation135 ft asl
Weight277,436 kg
Fuel23,122 kg
Wind340° · 7 kn · 1 kn cross
30 Sep 2024 10:48 4927 nm Boeing 747-8 96,413 kg
Departure Score
99.90 %
Enroute Score
99.50 %
Arrival Score
98.67 %

What went well

Touched down at -207 fpm — a soft arrival
Threshold crossed at 50 ft and 145 kt — both inside band
Flare on profile — 93 %

What held you back

Arrival Touchdown — Touchdown distance was 758 m at 67 %, −0.33 points
Enroute Climb — 250 kt exceeded below 10,000 ft; speed limits at 89 %, −0.17 points
Arrival Landing — Flare profile at 93 %, −0.11 points

Next time

Arrival

Hold the aim point and wait for the proper flare height before you start rotating; let the runway come up to you rather than anticipating it.

What happened: The flare began early, well above the normal flare band, and touchdown followed at 758 m past the threshold, 301 m beyond the 457 m target. Starting the flare early like this usually carries the touchdown long.

Watch for: Radio altimeter against the normal flare band, then touchdown distance against 457 m.

See Arrival LandingArrival Touchdown

Ground effect becomes significant below about one wingspan of height. A Cessna 172, with a 36 ft span, enters ground effect at flare height - the float it feels in the hold-off is ground effect arriving on cue. An A320, with a span around 117 ft, has been in ground effect since before the threshold and there is no sudden cushion to feel, only a gradual reduction in induced drag that lengthens any float you allow.

Read more in Flare Timing

Start to finish · 21 stages, 19 in the score

The flight story

Departure One segment per stage, in flight order — colour is the score band. Drag the bar to move along the flight, or click a stage card to open its detail. Arrival
Departure Taxi 100.00Taxiing from the parking to the runway took 6 minutes and covered 2 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 15 kt0 kt min to max 22 kt 2 10 kt
100 % Average speed turning corners 9 ktmax 9 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.01 g 1.00 1.00 g
Info Average pitch angle -0.4 °-0.8 ° min to max 1.1 ° -0.6 -0.6 °
Info Average bank angle 0.8 °0.0 ° min to max 1.7 ° 0.0 0.1 °

Events

Info Engine 2 Started 15 ft agl · 2 kt
Info Engine 3 Started 15 ft agl · 2 kt
Info Taxi Lights Switched On 15 ft agl
Info Parking Brake On 15 ft agl
Info Flaps Position 3 15 ft agl
Info Flaps Position 4 15 ft agl
Info Parking Brake Off 15 ft agl
Info Landing Lights Switched On 15 ft agl · 11 kt
Info Strobe Lights Switched On 15 ft agl · 11 kt
Info Autopilot AutoThrottle Arm Armed 15 ft agl · 15 kt
Departure Runway Entry Entering runway 24L at KLAX Los Angeles International Airport, Average speed was 17 kt.
ScoreDescriptionStartProfileEnd
Info Average speed 12 kt10 kt min to max 14 kt 10 14 kt
Info Average pitch angle -0.6 °-0.7 ° min to max -0.6 ° -0.6 -0.6 °
Info Average bank angle 0.2 °0.1 ° min to max 0.3 ° 0.2 0.1 °
Info Average g force 1.00 g1.00 g min to max 1.00 g 1.00 1.00 g
Departure Roll 100.00Departure roll runway 24L at KLAX Los Angeles International Airport. Takeoff distance 1,376 m 45 % of runway. Rotation speed was 156 kt. Local weather - Temperature 22 °C. Wind 6 kt at 260 °. Crosswind: 0 kt Headwind: 5 kt.
ScoreDescriptionStartProfileEnd
100 % Takeoff distance 1,376 m45 % of runway
100 % Rotation speed was 156 ktTarget 155 kt
100 % Runway alignment max 0.74 m right0.02 m left to 0.74 m right -0.54 -0.74 m
100 % Average g force 1.00 g0.96 g min to max 1.10 g 1.00 1.09 g
100 % Takeoff Bounce
Info Average pitch angle -0.2 °-0.7 ° min to max 9.4 ° -0.6 9.4 °
Info Average bank angle 0.1 °0.0 ° min to max 0.5 ° 0.0 0.2 °
Departure Climb 1 100.00Departure climb to 50 ft agl from runway 24L KLAX Los Angeles International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation 0.0 °0.0 ° min to max 0.0 ° 0.0 0.0 °
100 % Average speed 167 kt161 kt min to max 172 kt 161 172 kt
100 % Steepest bank angle 1.5 °0.3 ° min to max 1.5 ° 0.3 1.5 °
100 % Average g force 1.09 g1.01 g min to max 1.15 g 1.10 1.08 g
Info Average VSI 512 fpm124 fpm min to max 945 fpm 124 945 fpm
Info Average altitude 17 ft agl0 ft agl min to max 43 ft agl 0 43 ft agl
Info Average pitch angle 10.1 °9.4 ° min to max 10.9 ° 9.6 10.1 °
Departure Climb 2 99.52Departure climb to 400 ft agl from 24L KLAX Los Angeles International Airport.
ScoreDescriptionStartProfileEnd
100 % Heading variation -0.1 °-0.5 ° min to max 0.0 ° 0.0 -0.5 °
100 % Average speed 180 kt172 kt min to max 203 kt 172 203 kt
98 % Steepest bank angle 5.7 °0.1 ° min to max 5.7 ° 1.5 0.9 °
100 % Average g force 1.01 g0.91 g min to max 1.14 g 1.07 0.93 g
Info Average VSI 1,237 fpm962 fpm min to max 1,796 fpm 962 1,796 fpm
Info Average altitude 114 ft agl44 ft agl min to max 383 ft agl 44 383 ft agl
Info Average pitch angle 9.0 °6.5 ° min to max 10.1 ° 10.1 6.6 °

Events

Info Autopilot Heading Hold Activated 76 ft agl · 176 kt
Info Landing Gear Up 119 ft agl · 181 kt
Departure Climb 3 100.00Departure climb to 1,000 ft agl from 24L KLAX Los Angeles International Airport.
ScoreDescriptionStartProfileEnd
100 % Climb speed 218 kt208 kt min to max 224 ktTarget 202 kt, 16 kt fast 208 224 kt
100 % Steepest bank angle 11.9 °0.4 ° min to max 11.9 ° 4.1 11.9 °
100 % Average g force 1.01 g0.90 g min to max 1.15 g 0.96 1.09 g
100 % Landing gear up at 88 ft aglTarget by 400 ft agl
Info Heading variation -1.1 °-1.5 ° min to max -0.7 ° -0.7 -1.5 °
Info Average VSI 1,984 fpm1,530 fpm min to max 2,612 fpm 1,684 2,408 fpm
Info Average altitude 620 ft agl440 ft agl min to max 847 ft agl 440 847 ft agl
Info Average pitch angle 6.9 °5.8 ° min to max 8.4 ° 6.0 8.1 °

Events

Info Flaps Fully Retracted 787 ft agl · 228 kt
Enroute Climb 95.47Enroute climb started 2 miles south of Marina del Rey (California, United States). Climbing from 1,008 ft asl to 33,923 ft asl, an increase of 32,915 ft in 18 minutes and covering 127 nm.
ScoreDescriptionStartProfileEnd
89 % Average speed 312 kt225 kt min to max 348 kt 225 297 kt
100 % Steepest bank angle 26.7 °0.0 ° min to max 26.7 ° 20.2 0.3 °
100.00 % Average g force 1.01 g0.78 g min to max 1.32 g 0.97 1.01 g
Info Average VSI 1,817 fpm-510 fpm min to max 3,388 fpm 2,476 -35 fpm
Info Average altitude 14,746 ft asl1,008 ft asl min to max 33,937 ft asl 1,008 33,923 ft asl
Info Average pitch angle 4.5 °1.8 ° min to max 11.2 ° 7.1 2.9 °
Info Turn coordination 00 min to max 0 0 0

Events

Fail Exceeded 250 kn below 10000 ft 2,013 ft agl
Fail Exceeded 250 kn below 10000 ft 3,317 ft agl
Info Autopilot Master Switched On 3,234 ft agl · 264 kt
Info Autopilot Airspeed Hold Activated 3,338 ft agl · 274 kt
Info Autopilot Vertical Hold Activated 3,338 ft agl · 274 kt
Info Autopilot Airspeed Hold Deactivated 10,169 ft agl · 298 kt
Info Autopilot Vertical Hold Deactivated 10,169 ft agl · 298 kt
Info Autopilot RPM Hold Activated 10,169 ft agl · 298 kt
Info Landing Lights Switched Off 10,472 ft agl · 326 kt
Info Taxi Lights Switched Off 10,492 ft agl · 330 kt
Info Autopilot Airspeed Hold Activated 32,680 ft agl · 518 kt
Info Autopilot RPM Hold Deactivated 32,680 ft agl · 518 kt
Info Autopilot Vertical Hold Activated 32,847 ft agl · 518 kt
Enroute Level 100.00Enroute level cruise started 1 mile north of Nipomo (California, United States) and lasted 305 minutes, covering 2,421 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,197 ft of 33,935 ft asl33,611 ft asl min to max 34,257 ft asl 33,932 33,991 ft asl
100 % Average speed 293 kt289 kt min to max 297 kt 297 290 kt
100 % Steepest bank angle 27.0 °0.0 ° min to max 27.0 ° 0.7 3.0 °
100 % Average g force 1.00 g0.86 g min to max 1.15 g 1.02 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 2.6 °1.9 ° min to max 3.8 ° 3.1 2.4 °
Enroute Climb 2 100.00Enroute climb started 45 miles south west of PAPB St George Airport St George (Alaska, United States). Climbing from 33,991 ft asl to 37,995 ft asl, an increase of 4,004 ft in 5 minutes and covering 41 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 284 kt273 kt min to max 291 kt 290 273 kt
100 % Steepest bank angle 3.9 °0.1 ° min to max 3.9 ° 1.9 0.5 °
100 % Average g force 1.00 g0.87 g min to max 1.07 g 1.00 0.99 g
Info Average VSI 730 fpm-256 fpm min to max 2,269 fpm -30 35 fpm
Info Average altitude 35,834 ft asl33,988 ft asl min to max 38,000 ft asl 33,991 37,995 ft asl
Info Average pitch angle 3.5 °2.3 ° min to max 4.9 ° 2.4 3.2 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Airspeed Hold Deactivated 33,992 ft agl · 475 kt
Info Autopilot Airspeed Hold Activated 33,993 ft agl · 475 kt
Info Autopilot Airspeed Hold Deactivated 34,524 ft agl · 470 kt
Info Autopilot Vertical Hold Deactivated 34,524 ft agl · 470 kt
Info Autopilot RPM Hold Activated 34,524 ft agl · 470 kt
Info Autopilot Airspeed Hold Activated 37,867 ft agl · 490 kt
Info Autopilot RPM Hold Deactivated 37,867 ft agl · 490 kt
Info Autopilot Vertical Hold Activated 37,885 ft agl · 490 kt
Enroute Level 2 100.00Enroute level cruise started 80 miles south west of PAPB St George Airport St George (Alaska, United States) and lasted 253 minutes, covering 1,933 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,400 ft of 37,863 ft asl37,767 ft asl min to max 38,216 ft asl 37,997 38,216 ft asl
100 % Average speed 271 kt265 kt min to max 274 kt 273 265 kt
100 % Steepest bank angle 26.4 °0.0 ° min to max 26.4 ° 0.6 0.6 °
100.00 % Average g force 1.00 g0.68 g min to max 1.32 g 1.00 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 2.9 °1.1 ° min to max 5.1 ° 3.2 4.5 °
Enroute Climb 3 100.00Enroute climb started Latitude: 38.5622722 Longitude: 147.287649. Climbing from 38,465 ft asl to 39,845 ft asl, an increase of 1,381 ft in 2 minutes and covering 13 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 265 kt261 kt min to max 269 kt 264 261 kt
100 % Steepest bank angle 1.1 °0.0 ° min to max 1.1 ° 0.1 0.3 °
100 % Average g force 1.00 g0.90 g min to max 1.08 g 1.00 1.02 g
Info Average VSI 810 fpm-397 fpm min to max 1,478 fpm 1,478 140 fpm
Info Average altitude 39,222 ft asl38,465 ft asl min to max 39,847 ft asl 38,465 39,845 ft asl
Info Average pitch angle 3.8 °2.4 ° min to max 4.5 ° 4.5 3.3 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Airspeed Hold Deactivated 38,513 ft agl · 482 kt
Info Autopilot Vertical Hold Deactivated 38,513 ft agl · 482 kt
Info Autopilot RPM Hold Activated 38,513 ft agl · 482 kt
Info Autopilot Airspeed Hold Activated 39,723 ft agl · 491 kt
Info Autopilot Vertical Hold Activated 39,723 ft agl · 491 kt
Info Autopilot RPM Hold Deactivated 39,723 ft agl · 491 kt
Enroute Level 3 100.00Enroute level cruise started Latitude: 38.3906924 Longitude: 147.0790781 and lasted 31 minutes, covering 236 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±2,493 ft of 39,825 ft asl39,789 ft asl min to max 39,863 ft asl 39,852 39,789 ft asl
100 % Average speed 260 kt259 kt min to max 261 kt 261 260 kt
100 % Steepest bank angle 26.5 °0.0 ° min to max 26.5 ° 0.1 0.6 °
100 % Average g force 1.01 g0.93 g min to max 1.18 g 1.00 1.02 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 3.1 °2.5 ° min to max 4.2 ° 3.0 3.1 °
Enroute Descent 100.00Enroute descent started Latitude: 36.3628595 Longitude: 142.9750717. Descent from 39,793 ft asl to 3,736 ft asl, a decrease of 36,057 ft in 19 minutes and covering 126 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 295 kt236 kt min to max 357 kt 260 239 kt
100 % Steepest bank angle 28.3 °0.0 ° min to max 28.3 ° 0.0 7.4 °
100 % Average g force 1.03 g0.87 g min to max 1.19 g 1.00 0.98 g
Info Average VSI -2,062 fpm-3,203 fpm min to max 221 fpm 5 -53 fpm
Info Average altitude 20,475 ft asl3,727 ft asl min to max 39,811 ft asl 39,793 3,736 ft asl
Info Average pitch angle -1.1 °-3.4 ° min to max 3.0 ° 3.0 3.0 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Autopilot Airspeed Hold Deactivated 34,959 ft agl · 500 kt
Info Autopilot Mach Hold Activated 34,959 ft agl · 500 kt
Info Autopilot Mach Hold Deactivated 34,918 ft agl · 500 kt
Info Autopilot Airspeed Hold Activated 13,363 ft agl · 394 kt
Info Landing Lights Switched On 10,294 ft agl · 286 kt
Info Taxi Lights Switched On 10,274 ft agl · 286 kt
Enroute Level 4 100.00Enroute level cruise started 12 miles south east of Asahi (Chiba-ken, Japan) and lasted 3 minutes, covering 14 nm.
ScoreDescriptionStartProfileEnd
100 % Altitude held within ±687 ft of 3,731 ft asl3,706 ft asl min to max 3,759 ft asl 3,733 3,726 ft asl
100 % Average speed 239 kt230 kt min to max 241 kt 239 230 kt
100 % Steepest bank angle 30.0 °0.0 ° min to max 30.0 ° 11.4 0.8 °
100 % Average g force 1.07 g0.91 g min to max 1.25 g 1.03 1.00 g
Info Turn coordination 00 min to max 0 0 0
Info Average pitch angle 3.6 °2.5 ° min to max 5.5 ° 3.3 3.6 °
Enroute Descent 2 100.00Enroute descent started 5 miles south east of Naruto (Chiba-ken, Japan). Descent from 3,727 ft asl to 1,502 ft asl, a decrease of 2,224 ft in 2 minutes and covering 9 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 192 kt162 kt min to max 232 kt 229 168 kt
100 % Steepest bank angle 9.1 °0.2 ° min to max 9.1 ° 7.1 0.9 °
100 % Average g force 1.01 g0.82 g min to max 1.15 g 0.97 1.03 g
Info Average VSI -1,257 fpm-2,313 fpm min to max 160 fpm -30 -1,974 fpm
Info Average altitude 2,596 ft asl1,502 ft asl min to max 3,727 ft asl 3,727 1,502 ft asl
Info Average pitch angle 1.6 °-1.4 ° min to max 4.2 ° 3.4 0.8 °
Info Turn coordination 00 min to max 0 0 0

Events

Info Flaps Position 1 3,115 ft agl · 221 kt
Info Flaps Position 2 3,084 ft agl · 222 kt
Info Landing Gear Down 2,620 ft agl · 214 kt
Info Flaps Position 3 2,434 ft agl · 194 kt
Info Flaps Position 4 1,542 ft agl · 173 kt
Arrival Approach 100.00Final approach to runway 34L at RJAA Narita International Airport. Descent from 1,467 ft agl to 67 ft agl in 93 seconds. Scored on the stabilisation gates.
ScoreDescriptionStartProfileEnd
100 % Gear downpassed at both gates
100 % Landing flappassed at both gates
100 % Sink ratepassed at both gates
100 % On glideslopepassed at both gates
100 % On centrelinepassed at both gates
100 % On speedpassed at both gates
100 % Wings levelpassed at both gates

Events

Fail GPWS Warning Activated 891 ft agl · 171 kt
Fail GPWS Warning Activated 550 ft agl · 145 kt
Info Autopilot AutoThrottle Arm Disarmed 1,054 ft agl · 166 kt
Info Autopilot Master Switched Off 1,023 ft agl · 165 kt
Info GPWS Warning Deactivated 839 ft agl · 171 kt
Info Flaps Position 6 768 ft agl · 169 kt
Info GPWS Warning Deactivated 479 ft agl · 151 kt
Info Autopilot Airspeed Hold Deactivated 262 ft agl · 156 kt
Arrival Landing 98.31Landing on runway 34L at RJAA Narita International Airport, runway length 4,014 m. Good threshold height. Threshold speed was good at 145 kt.
ScoreDescriptionStartProfileEnd
100 % Threshold speed was good at 145 kt. Target 139 kt
100 % Good threshold height.Target 50 ft agl
93 % The flare held the target profile well. The flare began at 73 ft agl above the runway, higher than this aircraft wants. Touchdown was 758 m past the threshold. Hold the aim point and let the runway come to you rather than anticipating the flare.
100 % Runway alignment max 7.82 m left7.82 m left to 6.23 m left 7.57 7.82 m
100 % Steepest bank angle 1.0 °0.0 ° min to max 1.0 ° 0.6 0.6 °
100 % Peak g force 1.11 g0.94 g min to max 1.11 g 1.06 1.03 g
Info Average speed 142 kt138 kt min to max 145 kt 145 138 kt
Info Average VSI -303 fpm-708 fpm min to max -114 fpm -708 -222 fpm
Info Average altitude 23 ft agl5 ft agl min to max 51 ft agl 51 5 ft agl
Info Average pitch angle 5.0 °3.8 ° min to max 5.7 ° 3.8 5.7 °
07515022530037545052560067575082590001223354658Runway Distance mLanding Height ft075150225300375450525600675750825900-30-24-18-12-60612182430Runway Distance mRunway Width m
Arrival Touchdown 95.06Touchdown point was 343 m beyond the touchdown zone. Touchdown speed at 138 kt was good. Touchdown rate was fair at -207 fpm. Runway touchdown position was misaligned by 7.9 m from centreline. Local weather - Temperature 24 °C. Wind 6 kt at 350 °. Crosswind: 2 kt Headwind: 6 kt.
ScoreDescriptionStartProfileEnd
100 % Touchdown rate was -207 fpm.
67 % Touchdown distance was 758 mTarget 457 m
100 % Speed at touchdown 138 ktTarget below 138 kt
100 % Runway alignment max 7.86 m left7.85 m left 7.82 7.85 m
100 % Steepest bank angle 1.1 °0.4 ° min to max 1.1 ° 0.6 1.0 °
100 % Peak g force 1.13 g1.02 g min to max 1.13 g 1.03 1.05 g
100 % Landing Bounce
Info Average speed 137 kt137 kt min to max 138 kt 138 137 kt
Info Average pitch angle 5.5 °5.3 ° min to max 5.7 ° 5.7 5.3 °
Arrival Rollout 100.00Total landing distance 1,689 m, 42 % of runway. Runway rollout alignment was very good.
ScoreDescriptionStartProfileEnd
100 % Landing distance 1,689 m42 % of runway.
100 % Runway alignment max 5.81 m left5.81 m left to 0.00 m left 5.81 1.63 m
100 % Average g force 1.01 g0.98 g min to max 1.05 g 1.05 0.99 g
Info Average speed 123 kt68 kt min to max 133 kt 133 68 kt
Info Average pitch angle 2.8 °-0.7 ° min to max 5.3 ° 5.3 -0.7 °
Info Average bank angle 1.8 °0.0 ° min to max 2.8 ° 1.0 0.2 °
Runway Exit Exiting runway, average speed 33 kt
ScoreDescriptionStartProfileEnd
Info Average speed 26 kt17 kt min to max 57 kt 57 17 kt
Info Average pitch angle -0.8 °-1.0 ° min to max -0.6 ° -0.8 -1.0 °
Info Average bank angle 0.1 °0.0 ° min to max 0.2 ° 0.2 0.1 °
Info Average g force 1.00 g0.99 g min to max 1.01 g 0.99 1.00 g

Events

Info Flaps Fully Retracted 15 ft agl · 29 kt
Arrival Taxi 100.00Taxiing to the parking from the runway took 2 minutes and covered less than 1 nm.
ScoreDescriptionStartProfileEnd
100 % Average speed 8 kt3 kt min to max 11 kt 11 6 kt
100 % Average speed turning corners 0 ktmax 0 kt 0 0 kt
100 % Average g force 1.00 g0.99 g min to max 1.00 g 1.00 1.00 g
Info Average pitch angle -0.7 °-1.1 ° min to max -0.6 ° -1.1 -0.7 °
Info Average bank angle 0.1 °0.0 ° min to max 0.2 ° 0.1 0.0 °

Events

Info Landing Lights Switched Off 15 ft agl · 7 kt
Info Strobe Lights Switched Off 15 ft agl · 7 kt

Takeoff from KLAX 24L

Taxi out

LightsOk
All on
Taxi speed100.00
22kt peak9 kt in turns

The roll

Takeoff roll100.00
1,376m45 %
Runway alignment100.00
0.74m R
Rotation speed100.00
156kttarget 155, 1 late

On speed, but the nose came up quickly

Rotation started at 156 kt, 1 kt after the 155 kt rotate speed. The nose then rose at 4.9° a second, faster than the 2 to 3° a second airliners use.

The rotation started on speed but the nose came up quickly. A fast pull raises the nose faster than the aircraft can lift off, which brings the tail closer to the runway. Pull smoothly at the normal rate for this aircraft and let it fly off at its own attitude.

Liftoff and climb

Liftoff
161ktat 9.6°
Rotation
4.9°/sover 2.0 s, gaining 5 kt
35 ft
171ktat 10.7°, 2.9 s after liftoff
Bounce on takeoffOk
None
Bank after liftoff100.00
1.5°steepest
Gear up100.00
88ftfull marks to 400 ft
Climb 3 speed100.00
218kttarget 202

Plan view the roll down the 3,068 m runway.

Rolled from the start of the runway, never more than 0.6 m off the centreline. Airborne 45 % of the way down the runway, before the 75 % line.

How to read this

The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length.

1,0002,0003,000THRESHOLDLEFT ↑RIGHT ↓75 %widest 0.63 m RAirborne 1,382 m from the threshold
Your trackRunway used in the rollCentreline75 %: lift off before it for full marks
Runway to liftoff 1,382 m of 3,068 m · 45 %
Takeoff roll, 1,382 m Left ahead, 1,685 m

Side view from the start of the roll to the end of Climb 3 at 848 ft.

Reached 35 ft with 1,437 m of runway left; gear up at 88 ft, inside the 400 ft that gets full marks; then climbing at 1,640 fpm on average to 848 ft.

How to read this

The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The dark stretch of the roll is the run with the nose up and the wheels still on, with its length and time under the runway. The gear-up ring is coloured by its mark. The shaded stretch is Climb 3, scored on its average speed against the target.

1,000 ft500 ft0CLIMB 3218 kt avgtarget 202THRESHOLDRUNWAY END6080100120140KNOTS ALONG THE ROLLnose up on the runway · 159 m · 2.0 sRotate 156 kttarget 155Liftoff 161 ktGear up 88 ftfull marks to 400 ft
On the runwayNose up, wheels on the runwayClimbingLast quarter of the runwayGear upClimb 3

Speed and pitch from brake release to the end of the climb, against time.

How to read this

Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The dashed green line is the speed to rotate at for this aircraft at its weight, and the green dot is where the nose started to come up. The grey band is the run between the nose coming up and the wheels leaving the runway. The figures at liftoff are the pitch then and how fast the nose came up, in degrees a second. The rotation detail below draws the rotation against the rates for this aircraft and its tail-strike pitch, where the slope reads properly. The grey dashed line across the pitch is the attitude held from 35 ft to the end: a nose held steady is a climb speed that holds, and the airspeed trace sits directly above it to compare. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.

Climb 3 target 202240 kt16080020°10°0°nose up on the runway · 159 m · 2.0 sROTATELIFTOFFGEAR UPtarget 155held 8.8°9.6° off · 4.9°/s11° at 35 ftAIRSPEEDPITCH0204060 sfrom brake release
AirspeedPitchRotation speed targetRotation beganNose up, wheels on the runwayClimb attitude heldClimb 3

Rotation detail the pitch over the seconds from rotation to 35 ft, where the slope reads properly.

How to read this

The pitch over the seconds from the nose starting to come up to 35 ft, stretched so the slope reads properly. The green dot is where the nose started up, the grey band runs to the wheels leaving, and the figures at liftoff are the pitch then and how fast the nose came up. The two dashed green lines rising from the rotation point are 2 to 3° a second, the rates airliners are rotated at: a trace steeper than both is a faster rotation, one shallower than both a slower one. Each line runs from the rotation to the liftoff, so where it ends is the pitch the nose would have reached by the time the wheels left at that rate; a line that reaches the tail strike first stops on it. The red dashed line is 12.1°, the pitch at which this aircraft's tail touches the runway with the wheels still on it, drawn from rotation to liftoff only: once the wheels leave, every foot climbed adds tail clearance.

20°10°0°TAIL STRIKE 12.1°ROTATELIFTOFF35 FT9.6° off · 4.9°/s3°/s2°/s11° at 35 ftROTATION DETAIL-2-10+1+2+3+4+5 sseconds from rotation
PitchRotation began2 to 3°/s from rotationTail strikeNose up, wheels on the runway

The stabilisation gates

Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway. They are the approach's score: the checks passed out of the checks that ran.

Seven checks, two gates1,000 ft 100.007 of 7500 ft 100.007 of 7
Gear down
Landing flap
Sink rate980 fpm400 fpm
On glideslope3.1°2.6°
On centreline0.1° off0.2° off
On speed+22 kt+7.3 kt
Wings level2° bank2° bank

When the approach was stable

Every check met from 2.5 nm, about 740 ft above the runway, to the threshold, after the 1,000 ft gate and before the 500 ft gate. The last to settle was the sink rate.

How to read this

Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.

Gear downLanding flapSink rateOn glideslopeOn centrelineOn speedWings levelAll checks4 nm321THR
Check metNot metStabilisation gate

The approach to RJAA 34L

The final from 4 nm, with the stabilisation gates on it.

Profile height against the 3° glideslope, with its 1° band in green.

Inside the glideslope band from 4 nm to the threshold, never more than 130 ft below the slope.

How to read this

Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.

5001,0001,5002,000 ft4 nm3 nm2 nm1 nmTHRON SLOPE1,3301,0106903703° GLIDESLOPE · 1° BAND1,4516273371951,000 ft gate7 of 71,056 ft · 161 kt500 ft gate7 of 7462 ft · 146 kt
GlideslopeAllowed bandYou, inside the bandYou, outside itYour height thereStabilisation gate

Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 8× larger than distances along the final.

Inside the 1° band all the way from 4 nm, never more than 48 m off the centreline.

How to read this

Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.

4 nm3 nm2 nm1 nmTHR122 m L0122 m RLEFT ↑RIGHT ↓1° BAND28 m R7 m R26 m L3 m L7 m L9 m R
Extended centreline1° either sideYour trackOutside the bandStabilisation gate

Speed against the approach speed. The green band runs from 5 kt slow to 35 kt fast at the 1,000 ft gate, closing to 21 at 500 ft and 10 at the threshold.

Inside the speed band all the way, between +2 kt and +29 kt on the approach speed of 139 kt.

How to read this

Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.

140160180200 kt4 nm3 nm2 nm1 nmTHRAPPROACH SPEED 139+27 kt+6 kt+16 kt+13 kt+6 kt
Your airspeedApproach speedWhat the gates allowOutside the bandStabilisation gate

Landing and touchdown on RJAA 34L

Over the threshold

Threshold height100.00
50ft
Threshold speed100.00
145kttarget 139, 6 fast
Centreline offset100.00
7.82m L
Bank100.00
1.0°steepest
Flare93.25

The flare held the target profile well

The flare began at 73 ft agl above the runway, higher than this aircraft wants. Touchdown was 758 m past the threshold. Hold the aim point and let the runway come to you rather than anticipating the flare.

Touchdown

Past threshold67.08
758m
Centreline100.00
7.86m L
Speed100.00
137kttarget 138 or less
Touchdown rate100.00
-207fpm
Impact100.00
1.13G
BouncesOk
None
Bank100.00
1.1°as the wheels touched

Rollout

Rollout distance100.00
887m41 % used
Rollout alignment100.00
5.81m L

Taxi in

LightsOk
All set
Taxi speed100.00
11kt peak

Side view — the last 1,767 m of the approach.

Began the flare high, at 73 ft, 119 m before the threshold; crossed the threshold at 50 ft, close to the 50 ft target. Touched down 758 m in, 453 m past the ideal 305 m.

How to read this

The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,767 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.

50 ft over the threshold · target 50 ft FLARE NORMALLY STARTS 11–45 FT 80 ft400 Flare began at 73 ft, 119 m before the threshold−1,352 fpm · 3.2° · 146 ktdescent slowed at 15 ft · −97 fpm · 5.2°−206 fpm · 5.7° nose up · 138 kt Ideal — 50 ft, down at 305 m This flight — 50 ft, down at 758 m

Sink and pitch — through the flare, lined up with the side view.

The sink went from 1,350 fpm at the flare to 210 fpm at touchdown. The nose came up 2.5° on the way down. Into the flare at 146 kt, 7 kt over the 139 kt approach speed, and 138 kt at touchdown.

How to read this

Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.

SINK RATE FPM · 0 IS LEVEL, LOWER IS COMING DOWN FASTERPITCH · HIGHER IS NOSE UP0−500−1,0000°5°10°descent slowedtouchdown−206 fpm at touchdown5.7° at touchdown, +2.5° from the flare
Sink ratePitchFlare began, descent slowedTouchdown

Plan view — the first 1,767 m of the 4,014 m runway, to the same scale as the side view.

Touched down 7.8 m left of the centreline, and steered back to 2.4 m left by the end of the rollout. Little crosswind (1 kt): nothing to correct for. Touched down straight, wings level.

Wind 340° at 7 kt · 7 kt head · 1 kt across

How to read this

The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.

5001,0001,500 THRESHOLD LEFT ↑ RIGHT ↓ CROSS 1 kn FULL SCORE TO 503 M 758 m past threshold ROLLOUT ENDED
Your trackTouchdownRolloutCentreline

Touched down 758 m past the threshold — beyond the full-score zone. The arrival was smooth.

Runway used 1,646 m of 4,014 m · 41 %
In the air over the runway, 758 mRollout, 887 m Left over, 2,368 m

The stop — touchdown to taxi speed.

From 134 kt at touchdown to taxi speed (30 kt) in 27 s, an average deceleration of 0.21 g.

How to read this

Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.

0408012060 kt · 961 m30 kt · 1,129 mtouchdown1,174 mkt
Your ground speed60 kt and taxi speed

The rest of the report

Explore in detail

Flight narrative

The flight in the Boeing 747-8 began with a taxi to runway 24L at KLAX Los Angeles Intl. The distance from parking to the runway was 2 nm, and the taxi duration was 6 minutes. The departure roll took place on runway 24L at KLAX, with a takeoff distance of 4,922 ft (52% of the runway). The liftoff speed was 161 kn, with the local weather indicating a temperature of 67 °F and a wind speed of 6 kn at 260 °, resulting in a headwind of 5 kn.

The enroute climb started 2 miles south of Marina del Rey (California, United States), climbing from 1,048 ft asl to 33,937 ft asl, an increase of 32,890 ft in 17 minutes over a distance of 115 nm, finishing 3 miles east of 0CA1 Northside Airpark Santa Maria (California, United States). The flight then proceeded to the enroute level cruise, starting 2 miles northeast of 0CA1 Northside Airpark Santa Maria, covering a distance of 2,387 nm in 306 minutes and finishing 49 miles southwest of PAPB St George St George (Alaska, United States).

Another enroute climb began 50 miles southwest of PAPB St George, climbing from 33,988 ft asl to 37,994 ft asl, an increase of 4,006 ft in 4 minutes over a distance of 31 nm, finishing 75 miles southwest of PAPB St George. This was followed by an enroute level cruise that covered 1,927 nm in 253 minutes, starting 77 miles southwest of PAPB St George and finishing at Latitude: 38.6078588, Longitude: 147.3437697.

The descent phase of the flight started at Latitude: 36.3467076, Longitude: 142.9260834, descending from 39,811 ft asl to 3,854 ft asl, a decrease of 35,957 ft in 18 minutes over a distance of 115 nm, finishing 11 miles southeast of Asahi (Chiba-ken, Japan). The flight then leveled off briefly before commencing another descent, starting 3 miles east of Naruto (Chiba-ken, Japan), descending from 3,612 ft asl to 1,926 ft asl, a decrease of 1,686 ft in 2 minutes over a distance of 6 nm, finishing 4 miles north of Naruto.

The final phase of the flight involved landing on runway 34L at RJAA Narita Intl, with a touchdown speed of 138 kn and a touchdown VSI of -222 ft/min. The landing rollout covered a distance of 2,911 ft, with a total landing distance of 3,105 ft (29% of the runway). The flight then taxied to parking from runway 34L at RJAA Narita Intl, with a distance to parking of less than 1 nm and a taxi duration of 2 minutes.

Overall, the total flight distance was 4,850 nm, taking 648 minutes and using 212,564 lbs of fuel. The flight covered a variety of altitudes, speeds, and distances, showcasing the capabilities of the Boeing 747-8 aircraft on this journey from Los Angeles to Tokyo.

Metrics
Metrics

Scroll or drag the slider to zoom · double-click to reset · hover for values
