MY FS FLIGHTS
Flight Score
Arrival
Keep the back pressure coming through the flare so the sink does not return at 116 fpm.
What happened: The flare arrested the sink, but then the sink returned before touchdown.
Watch for: Watch the VSI in the flare and keep arrested sink from returning before touchdown at 137 fpm.
See Arrival Landing
Arrive slow and the sink rate at the threshold is already above schedule, the flare is short because there is no energy to extend it, and the touchdown is hard in a way that feels exactly like a late flare. Diagnosing a slow arrival as a late flare is the catastrophic misread: you respond by flaring earlier, which bleeds more speed, which makes the next one worse. The tiebreaker is threshold speed against VRef, not feel. Never diagnose a flare without it.
Read more in Flare TimingStart to finish · 19 stages, 17 in the score
Events
Events
Events
Events
Events
Events
Events
Events
Events
Events
Events
From brake release to the end of the climb, against time, then the takeoff point by point.
Lifted off at 147 kt with 9.9° of pitch.
Two traces from brake release: the airspeed on top, and below it the pitch, which is how far the nose is above the horizon. The figure at liftoff is the pitch then. The shaded stretch is Climb 3, the part of the climb scored on holding the climb speed.
The takeoff, point by point
Side view from the start of the roll to the end of Climb 3 at 879 ft.
Reached 35 ft with 2,387 m of runway left; then climbing at 2,800 fpm on average to 879 ft.
The takeoff from the side: the height above the runway against the distance along it. The numbers along the runway are the speeds reached at each point. Lifting off in the amber last quarter of the runway costs marks for the roll length. The shaded stretch is Climb 3, scored on its average speed against the target.
Plan view the roll down the 3,570 m runway.
Rolled from the start of the runway, drifted 3 m right of the centreline and was back on it to lift off. Airborne 26 % of the way down the runway, before the 75 % line.
The roll from above, with your left at the top. The line is where the wheels went, and "widest" is the furthest you drifted off the centreline. Lifting off before the amber 75 % line gets full marks for the roll length. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way.
Two stabilised approach gates, each with seven checks, where the approach path is 1,000 ft and 500 ft above the runway.
When the approach was stable
Every check met from 4 nm to the threshold.
Each line is one of the gate checks, run along the whole final rather than only at the gates: green where it would have passed, amber where it would not. The glideslope, centreline and speed lines use the bands in the charts beside this card. The sink rate is allowed what the glideslope needs at your ground speed plus 600 fpm, the wings 10° of bank, and the gear and flap are read from when you moved the levers. The bottom line is green where every check held at once, ignoring blips shorter than 0.2 nm, and the sentence above it says from where it held to the threshold. A ring is a stabilisation gate, where the checks in the table were taken.
The final from 4 nm, with the stabilisation gates on it.
Profile height against the 3° glideslope, with its 1° band in green.
Inside the glideslope band from 4 nm to the threshold, never more than 30 ft below the slope.
Your height above the runway against the distance still to go. The glideslope is the steady descent path to the aiming point, 305 m past the threshold: 3° here, which is about 320 ft for every nautical mile out, crossing the threshold at about 50 ft. The row under the distances is the height it puts you at. Inside the green band your path is drawn green; outside it, amber. A ring is a stabilisation gate: green when every check there passed, amber with the failed checks named beside it.
Plan distance off the extended centreline, your left at the top, with the 1° band. Sideways distances are drawn 52× larger than distances along the final.
Inside the 1° band all the way from 4 nm, never more than 6 m off the centreline.
Looking down from above, flying left to right towards the runway: up the page is left of the centreline, down is right. Sideways distances are stretched so that small drifts show, so a line that looks wild here may be only a few tens of feet. The labels are how far off you were at each distance, amber when outside the band.
Speed against the approach speed. The green band runs from 5 kt slow to 34 kt fast at the 1,000 ft gate, closing to 20 at 500 ft and 10 at the threshold.
Inside the speed band all the way, between −1 kt and +27 kt on the approach speed of 136 kt.
Your indicated airspeed down the final, against the approach speed for this aircraft at its landing weight. The band allows 5 kt slow and more on the fast side further out, closing as you get lower, because the speed is expected to come off on the way down. The figures are knots above (+) or below (−) the approach speed.
Over the threshold
Poor landing flare
Touchdown
Rollout
Taxi in
Side view — the last 1,524 m of the approach.
Crossed the threshold at 40 ft, close to the 50 ft target. Touched down 737 m in, 432 m past the ideal 305 m.
The last stretch of the approach and the touchdown, from the side. The height is stretched so that the last few feet show: 80 ft top to bottom, against 1,524 m across. The dashed line is the ideal, 50 ft over the threshold and down 305 m in. The flare ring is where you began raising the nose, and "descent slowed" is where the sink came off; the figures beside them are the sink rate, pitch and speed at that point.
Sink and pitch — through the flare, lined up with the side view.
The sink went from 580 fpm at 41 ft to 140 fpm at touchdown. The nose came up 3.1° on the way down.
Lined up with the side view above, so a point on one sits under the same point of the other. On top, how fast you were coming down: 0 is level, and −600 is 600 ft a minute down. Below, the pitch. In a flare the nose comes up and the descent slows towards 0. The figure at the touchdown line is your touchdown rate.
Plan view — the first 1,524 m of the 2,822 m runway, to the same scale as the side view.
Touched down on the centreline, and stayed within 2.6 m of it down the rollout. Little crosswind (2 kt): nothing to correct for. Touched down with the nose 1° right of the track, wings level.
Wind 110° at 3 kt · 1 kt tail · 2 kt across
The runway from above, with your left at the top. Touching down inside the green bracket scores full marks for the distance. The shaded part is the rollout, up to where it ended. The arrow beside the runway is the crosswind, pointing the way the air was moving, so it pushed the aircraft that way. The wind is the one recorded at the landing, split along the runway (headwind or tailwind) and across it. To hold the centreline in a crosswind the nose points a little into wind - the crab - and is straightened with rudder just before the wheels touch, often with the into-wind wing lowered to stop the drift. The sentence gives the nose against the direction you were actually moving as the wheels touched, and the steepest bank as they touched, the figure the touchdown's Bank tile marks. The rest of it is shown for reading, not marked.
Touched down 737 m past the threshold — beyond the full-score zone. The arrival was smooth.
The stop — touchdown to taxi speed.
From 126 kt at touchdown to taxi speed (30 kt) in 17 s, an average deceleration of 0.30 g.
Your ground speed from the moment the wheels touched until you were down to taxi speed, against the distance rolled. A steep line is hard braking, a shallow one a long, gentle roll. For scale, an airliner's lowest autobrake setting decelerates at about 0.15 g, a medium one about 0.3 g. Shown for reading; not marked.
The rest of the report
Departing Geneva Cointrin International Airport (LSGG), the Boeing 737-800 began its journey by taxiing from the parking area to the runway, a process that took approximately 4 minutes and covered a distance of 1 nautical mile. As the aircraft reached the runway threshold, it initiated its departure roll on runway 04, accelerating to a liftoff speed of 148 knots. The takeoff distance of 935 meters, which accounted for 26% of the runway, was achieved in a relatively short period.
As the aircraft climbed to its enroute cruise altitude, it encountered a local weather condition of 9°C temperature and a wind speed of 4 knots from 290°. The climb phase started overhead Le Grand-Saconnex, with the aircraft ascending from 2,340 feet above sea level to 25,762 feet, an increase of 23,422 feet in 11 minutes and covering a distance of 72 nautical miles. The enroute level cruise phase followed, lasting 27 minutes and covering 226 nautical miles, before the aircraft began its descent phase overhead Leefdaal. The descent from 25,997 feet to 2,248 feet, a decrease of 23,749 feet in 16 minutes and covering 100 nautical miles, was a critical phase of the flight. The aircraft then entered a brief level cruise phase overhead Gouderak, lasting 4 minutes and covering 16 nautical miles, before initiating its final approach to runway 36R at Amsterdam Airport Schiphol (EHAM).
The final approach was conducted from the south, with the aircraft maintaining a heading of 3.0° at 4 nautical miles and 1,297 feet above ground level. The landing was executed with a threshold speed slightly above the target at 140 knots, and the touchdown point was 321 meters beyond the touchdown zone. The touchdown speed of 125 knots and the touchdown rate of -189 feet per minute were both within acceptable limits. The runway touchdown alignment was perfect, and the runway rollout alignment was very good. The total landing distance of 1,376 meters, which accounted for 49% of the runway, was a testament to the aircraft's performance. The flight concluded with a taxiing time of 1 minute and a fuel consumption of 3,944 kilograms, covering a total distance of 421 nautical miles in 65 minutes.
Scroll or drag the slider to zoom · double-click to reset · hover for values
